Resolution 1920 x 1080, 30 fps (FHD)
Automatic lighting correction YES
Viewing angle 85 °
04 Troubleshooting and
Maintenance
Troubleshooting
Formore information, referto "Troubleshooting" in the e-Manual.
> Menu > Settings > Support > Open e-Manual >
Troubleshooting
If none of the troubleshooting tips apply, please visit "www.
samsung.com" and click Support or contact the Samsung
service centre.
•
This panel is made up of sub pixels which require
sophisticated technology to produce. There may be, however,
a few bright ordark pixels on the screen. These pixels will
have no impact on the performance of the product.
•
To keep your TV in optimum condition, upgrade to the
latest software. Use the Update Now or Auto update
functions on the TV's menu ( > Menu > Settings >
Support > Software Update > Update Now or Auto update).
The TVwon’t turn on.
•Make sure that the power cord is securely plugged into
the product and the wall outlet.
•Make sure that the wall outlet is working and the remote
control sensorat the bottom of the TV is lit and glowing
a solid red.
•Try pressing the TV Controller button at the bottom of the
TV to make sure that the problem is not with the remote
control. If the TV turns on, referto "The remote control
does not work".
The remote control does notwork.
•Check if the remote control sensor at the bottom of the TV
blinks when you press the button on the remote control.
– CU7 Series (except for CU77** model), Standard Remote
Control: If it does not blink, replace the remote control's
batteries. Make sure that the batteries are installed
with their poles (+/–) in the correct direction. Alkaline
batteries are recommended for longer battery life.
–
Other models: When the remote's battery is discharged,
charge the battery using the USB charging port (C-type),
or turn over the remote to expose the solar cell to light.
•Trypointing the remote directlyat the TV from1.5-1.8 m away.
•If yourTV came with a Samsung Smart Remote (Bluetooth
Remote), make sure to pairthe remote to the TV. To pair
a Samsung Smart Remote, press the and buttons
together for 3 seconds.
Warning: Screens can be damaged from direct
pressure when handled incorrectly. We recommend
lifting the TV at the edges, as shown. Formore
information about handling, referto the Unpacking
and Installation Guide came with this product.
Do Not Touch
This Screen!
02 Connecting the TV to
the One Connect Box
(One Connect Box Supported Model only)
Formore information about howto connect via the One
Connect Box, referto Unpacking and Installation Guide.
•Do not use the One Connect Box in the
upside-down or upright position.
•Take care not to subject the cable to any of
the actions below. The One Connect Cable
contains a powercircuit.
Bending Twisting Pulling
Pressing on Electric shock
Using the One Connect cable holder
You can use the One Connect cable holderto tidy up the
cables while installing the wall mount.
03 Initial Setup
When you turn on yourTV forthe first time, it immediately
starts the Initial Setup. Follow the instructions displayed on
the screen and configure the TV's basic settings to suit your
viewing environment.
•You will need a Samsung Account to access ournetwork-
based smart services. If you choose not to log in,you will
only get a connection to terrestrial TV (applicable to devices
with tuners only) and external devices, e.g. via HDMI.
Eco Sensorand screen
brightness
Eco Sensoradjusts the brightness of the TV automatically.
This feature measures the light in yourroom and optimises
the brightness of the TV automatically to reduce power
consumption. If you want to turn this off, go to > Menu
> Settings > All Settings > General & Privacy > Power and
Energy Saving > Brightness Optimisation.
•The eco sensoris located at the bottom of the TV. Do
not block the sensorwith any object. This can decrease
picture brightness.
05 Specifications and
Other Information
Specifications
Display Resolution
QN7**C/QN8**C/QN9**C Series: 7680 x 4320
Other models: 3840 x 2160
Sound (Output)
CU7/CU8/Q6*C/Q7*C Series: 20 W
S9*C/Q8*C Series: 40 W
QN8*C/QN7**C Series: 60 W
QN9*C Series (43"): 20 W, QN9*C Series (50"): 40 W
QN9*C Series (55"-85"): 60 W
S95C/QN95C/QN8**C Series: 70 W
QN9**C Series: 90 W
Operating Temperature
10 °C to 40 °C (50 °F to 104 °F)
Operating Humidity
10 % to 80 %, non-condensing
Storage Temperature
-20 °C to 45 °C (-4 °F to 113 °F)
Storage Humidity
5 % to 95 %, non-condensing
Notes
•This device is a Class B digital apparatus.
•Forinformation about the power supply, and more
information about power consumption, referto the
information on the label attached to the product.
– On most models, the label is attached to the back of the TV.
(On some models, the label is inside the coverterminal.)
– On One Connect Box models, the label is attached to
the bottom of the One Connect Box.
•Typical powerconsumption is measured according to IEC 62087.
•To connect a LAN cable, use a CAT 7 (*STP type) cable for
the connection. (100/10 Mbps)
* Shielded Twisted Pair
•The images and specifications of the Unpacking and
Installation Guide may differfrom the actual product.
Using the TV Controller
You can turn on the TV with the TV Controller button at
the bottom of the TV, and then use the Control menu. The
Control menu appears when the TV Controller button is
pressed while the TV is On.
•The position and shape of the buttons at the bottom of
the TV may differ depending on the model.
•The screen may dim if the protective film on the
SAMSUNG logo orthe bottom of the TV is not detached. If
protective film is attached, remove the film.
Control menu
TV Controller button / Remote control sensor /
Microphone switch
TV Controller button / Remote control sensor
Microphone switch
How to turn on and off the Microphone
Type A Type B Type C
: On Off
You can turn on oroff the microphone by using the switch
at the bottom of the TV. If microphone is turned off, All voice
and sound features using microphone are not available.
•This function is supported only in QN7**C/QN8**C/
QN9**C/Q7*C/Q8*C/QN8*C/QN9*C/S9*C Series.
•The position and shape of the microphone switch may
differdepending on the model.
•During analysis using data from the microphone, the data
is not saved.
Connecting the camera to the
product (QN95C Series only)
When you connect a camera, you can use video calls, home
workouts, and othernew features with the camera.
An administration fee maybe charged in the following situations:
(a) An engineer is called out at your request, but it is found
that the product has no defect (i.e., where the user manual
has not been read).
(b) You bring the unit to the Samsung service centre, but
it is found that the product has no defect (i.e., where the
user manual has not been read).
You will be informed of the administration fee amount
before a technician visits.
Decreasing power consumption
When you shut the TV off, it enters Standby mode. In Standby
mode, it continues to draw a small amount of power. To
decrease power consumption, unplug the power cord when
you don't intend to use the TV for a long time.
Licences
The terms HDMI, HDMI High-Definition Multimedia Interface,
HDMI trade dress and the HDMI Logos are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc.
Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
(Applicable in countries with separate
collection systems)
This marking on the product, accessories orliterature
indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with
other household waste at the end of theirworking life. To
prevent possible harm to the environment orhuman health
from uncontrolled waste disposal, please separate these
items from other types of waste and recycle them responsibly
to promote the sustainable reuse of material resources.
Household users should contact eitherthe retailerwhere
they purchased this product, ortheir local government office,
fordetails of where and how they can take these items for
environmentally safe recycling.
Business users should contact theirsupplier and check the
terms and conditions of the purchase contract. This product
and its electronic accessories should not be mixed with other
commercial wastes for disposal.
Correct disposal of the batteries in this
product
(Applicable in countries with separate
collection systems)
This marking on the battery, manual orpackaging indicates
that the batteries in this product should not be disposed of
with other household waste at the end of theirworking life.
Where marked, the chemical symbols Hg, Cd or Pb indicate
that the battery contains mercury, cadmium orlead above
the reference levels in EC Directive 2006/66. If batteries are
not properly disposed of, these substances can cause harm
to human health orthe environment.
To protect natural resources and to promote material reuse,
please separate batteries from other types of waste and
recycle them through yourlocal, free battery return system.
•The type of battery mayvary depending on the model.
Correct disposal of the batteries in this
product
(Applicable in countries with separate
collection systems)
The marking on the battery, manual orpackaging indicates
that the battery in this product should not be disposed of
with other household waste. Where marked, the chemical
symbols Hg, Cd orPb indicate that the battery contains
mercury, cadmium orlead above the reference levels in EC
Directive 2006/66.
The battery incorporated in this product is not user
replaceable. Forinformation on its replacement, please
contact yourservice provider. Do not attempt to remove the
battery or dispose it in a fire. Do not disassemble, crush, or
puncture the battery. If you intend to discard the product, the
waste collection site will take the appropriate measures forthe
recycling and treatment of the product, including the battery.
•The type of battery mayvary depending on the model.
Removing the battery
•To remove the battery, contact an authorised service
centre. To obtain battery removal instructions, please visit
www.samsung.com/global/ecodesign_energy.
•Foryour safety, you must not attempt to remove the
battery. If the battery is not properly removed, it may
lead to damage to the battery and device, cause personal
injury, and/or result in the device being unsafe.
Warranty Card
United Kingdom Republic of Ireland (EIRE)
This Samsung product is warranted forthe period of twelve (12) months from the original date of purchase, against defective
materials and workmanship. In the event that warranty service is required, you should return the product to the retailerfrom
whom it was purchased. However, Samsung Authorised Dealers and Authorised Service Centres in the countries listed in Warranty
Conditions will complywith the warranty on the terms issued to purchasers in the country concerned. In case of difficulty, details of
ourAuthorised Service Centres are available from:
Samsung Electronics U.K. Ltd.
Samsung Customer Support Centre
Selectapost 38, Sheffield, S97 3FJ,
United Kingdom
United Kingdom: Tel. 0333 000 0333
www.samsung.com/uk/support
EIRE: Tel. 0818 717100
www.samsung.com/ie/support
WARRANTY CONDITIONS
1. The warranty is onlyvalid if, when warranty service is required, the warranty card is fully and properly completed and is presented
with the original invoice or sales slip or confirmation, and the serial number on the product has not been defaced.
2. Samsung’s obligations are limited to the repairor, at its discretion, replacement of the product orthe defective part. Repaired or
replaced products may include new and or refurbished components and equipment.
3. Warranty repairs must be carried out byAuthorised Samsung Dealers orAuthorised Service Centres. No re-imbursement will
be made forrepairs carried out by non-Samsung Dealers and, any such repairwork and damage to the products caused by such
repairwork will not be covered bythis warranty.
4. This product is not considered to be defective in materials norworkmanship by reason that it requires adaptation in orderto
conform to national or local technical orsafety standards in force in any Country other than the one forwhich the product was
originally designed and manufactured.
This warrantywill not cover, and no re-imbursement will be made for such adaptation nor any damage which may result.
5. This warranty covers none of the following:
a) Periodic check-ups, maintenance and repairor replacement of parts due to normal wearand tear.
b) Cost relating to transport, removal or installation of the product.
c) Misuse, including the failure to use this product forits normal purposes or incorrect installation.
d) Use of this product in a commercial/ business environment, which shall include, but is not limited to, the following: any use
forprofit orfinancial gain, public display or events such as clubs, bars and restaurants including continuous statistical or
graphical display, or any commercial use of continuous orintentional long term display of News reels (“tickers”), static or fixed
images such as timetables and 4:3 pictures or video content displaying permanent black bars.
e) Damage caused by Lightning, Water, Fire, Acts of God, War, Public Disturbances, incorrect mains voltage, improperventilation
or any other cause beyond the control of Samsung.
f) Spillage of food or liquid or use of any other hazardous substances, which may affect the product.
g) Performance due to differences in broadcasting method between countries.
6. This warranty is valid for any person who legally acquired possession of the product during the warranty period.
7. The consumers’ statutory rights in any applicable national legislation whether against the retailerarising from the purchase
contract orotherwise are not affected by this warranty. Unless there is national legislation to the contrary, the rights under
this warranty are the consumers’ sole rights and Samsung, its subsidiaries and distributors shall not be liable for indirect or
consequential loss orany damage to disc based media, removable memory orany otherrelated equipment ormaterial.
8. Some products may differfrom these guidelines. Please check with your dealer orthe local Samsung web-site.
9. Samsung shall honourwarranties forall EU specification products purchased by a consumerwithin the following European
countries listed.
–UK, Republic of Ireland, Germany, France, Italy, Malta, Spain, Portugal, The Netherlands, Belgium, Luxembourg, Denmark,
Sweden, Finland, Poland, Hungary, Czech Republic, Slovakia, Austria, Slovenia, Croatia, Estonia, Latvia, Lithuania, Greece,
Cyprus, Romania, Bulgaria, Switzerland, Norway, Lichtenstein and Iceland.
SAMSUNG ELECTRONICS CO LTD.
