Samsung CS29M6 User manual

COLOUR
TELEVISION
CS29M6/CS29M20/CS29M16/
CS29K3/CS29K5/CS29K10/
CS29A11/CS25M6/CS25M20/
CS25K10/CS25A11/CS21T10/
CS21T20/CS21A11/CS21M7/
CS21M20/CS21S8
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
PICTURE IN PICTURE
DNIe Jr
(Digital Natural Image engine Junior)
TELETEXT (OPTION)
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 1

3
ENG
Contents
◆CONNECTING AND PREPARING YOUR TELEVISION
■Control Panels (depending on the model)..................................................... 5
■Connection Panels (depending on the model) .............................................. 6
■Infrared Remote Control ................................................................................ 8
■Inserting the Batteries in the Remote Control................................................ 9
■Connecting to an Aerial or Cable elevision Network ................................... 10
■Switching Your elevision On and Off........................................................... 11
■Placing Your elevision in Standby Mode..................................................... 11
■Becoming Familiar with the Remote Control ................................................. 12
■Plug & Play Feature (depending on the model)............................................. 13
■Viewing the Demonstration............................................................................ 14
■Choosing Your Language.............................................................................. 14
◆SETTING THE CHANNELS
■Storing Channels Automatically..................................................................... 15
■Storing Channels Manually............................................................................ 16
■Skipping Unwanted Channels ....................................................................... 18
■Sorting the Stored Channels ......................................................................... 19
◆USING YOUR TELEVISION
■Changing the Picture Standard ..................................................................... 20
■Adjusting the Picture Settings........................................................................ 21
■Selecting the Picture Size.............................................................................. 22
■Extra Picture Settings .................................................................................... 23
■Using the ilt Control Feature (depending on the model).............................. 24
■Setting the Blue Screen................................................................................. 24
■Changing the Sound Standard ...................................................................... 25
■Adjusting the Sound Settings ........................................................................ 26
■Extra Sound Settings (depending on the model)........................................... 27
■Selecting the Melody ..................................................................................... 28
■Selecting the Sound Mode (depending on the model) .................................. 29
■Setting and Displaying the Current ime....................................................... 30
■Setting the Sleep imer................................................................................. 31
■Switching the elevision On and Off Automatically....................................... 32
■Setting the Preferred Volume Level............................................................... 33
■Using the LNA (Low Noise Amplifier) feature (depending on the model) ...... 34
■Activating the Child Lock ............................................................................... 35
■Viewing an External Signal Source (depending on the model) ..................... 36
■Viewing the Picture In Picture (PIP) (depending on the model) .................... 37
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 3

4
ENG
Contents (continued)
◆USING THE TELETEXT FEATURE (depending on the model)
■eletext Feature (depending on the model) .................................................. 40
■Displaying the eletext Information (depending on the model) ..................... 40
■Selecting a Page by Number (depending on the model)............................... 41
■Using FLOF to Select a Page (depending on the model).............................. 42
■Storing eletext Pages (depending on the model) ........................................ 42
◆ADDITIONAL INFORMATION ON CONNECTIONS
■Connecting to the AV-1 or 2 Input/Outputs.................................................... 43
■Connecting to the S-VIDEO Input (depending on the model)........................ 43
■Connecting to the DVD Input (depending on the model)............................... 44
■Connecting to the RCA Input (depending on the model)............................... 44
■Connecting to the Audio Output (depending on the model) .......................... 44
■Connecting Headphones (depending on the model)..................................... 45
■Viewing Pictures From External Sources (depending on the model) ............ 45
◆RECOMMENDATIONS FOR USE
■Automatic Degaussing to Remove Colour Patches....................................... 46
■roubleshooting: Before Contacting Service Personnel................................ 46
☛➢
Press Important Note
Symbols
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 4

5
ENG
➢The actual configuration on your TV may be different, depending on
your model.
Control Panels (depending on the model)
1) Input source selection
2) Menu display
3) Volume adjustment
4) Channel selection
5) Remote control sensor
6) Standby indicator
7) Power On/Off
➢Using the Buttons on the Panel
If the remote control no longer works or you have lost it, you can use controls on the panel of
the TV to:
◆ Switch on the TV when it is in Standby mode and select channels ( ▼CH ▲ or CH ).
◆ Access the menu ( MENU ).
◆ Adjust the volume ( - VOL + ).
◆ Switch among Video input modes ( TV/VIDEO ).
Front of the TV
CS2
CS2
CS2
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 5

6
ENG
Connection Panels (depending on the model)
Side of TV Front of TV
ŒCONNECTING EXTERNAL A/V DEVICES (INPUT)
The RCA (VIDEO + AUDIO-L and R) connectors are used for equipment such as camcorders, video disc
players and some video game devices.
➢◆When both the side (or front) and rear connectors are connected to external equipment,
the side (or front) AV has the priority.
◆When using the mono equipment such as camcorders, video disc players and some video
game devices, connect to the “AUDIO-L” input connector.
´CONNECTING EXTERNAL S-VIDEO DEVICES (INPUT) (Option)
- Video and audio inputs for external devices with an S-Video output, such as a camcorder or VCR.
ˇCONNECTING HEADPHONES (Option)
- You can connect a set of headphones to your television if you wish to watch a television programme
without disturbing the other people in the room.
- Prolonged use of headphones at a high volume may damage your hearing.
☛Whenever you connect an audio or video system to your
television, ensure that all elements are switched off.
Refer to the documentation supplied with your equipment for
detailed connection instructions and associated safety
precautions.
➢This figure shows the Standard Connector-jack panel.
The actual configuration on your TV may be different, depending on
the model.
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 6

7
ENG
Connection Panels (depending on the model) (continued)
ΠMONITOR OUT (VIDEO / L-AUDIO-R)
Outputs for external devices.
´AV 1 (VCR) -VIDEO/AUDIO(L/R)
AV 2 (VCR) -VIDEO/L-AUDIO-R
Inputs or outputs for external devices,
such as VCR,DVD, video game device or
video disc players.
ˇCOMPONENT (DVD)
VIDEO (Y/Pb/Pr) and AUDIO (L/R) inputs
for Component.
¨VHF/UHF (75Ω)
75ΩCoaxial connector for Aerial/
Cable Network.
ˆ/ (SCART)
Inputs or outputs for external devices,
such as VCR, DVD, video game device or
video disc players.
Rear of TV
➢Available format for Component Inputs : 480i
➢When using the mono equipment such as camcorders, video disc players and some video
game device, connect to the “AUDIO-L”input connector.
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 7

8
Infrared Remote Control
ENG
TELEVISION STAND-BY
DIRECT CHANNEL SELECTION
VOLUME INCREASE
TEMPORARY SOUND SWITCH-OFF
MENU DISPLAY/
PROGRAMME SELECTION BY NAME
MOVE TO THE REQUIRED MENU
OPTION/
AD UST AN OPTION VALUE
RESPECTIVELY
TURBO SOUND
EXTERNAL INPUT SELECTION/
TELETEXT MODE SELECTION
(LIST/FLOF)
AUTOMATIC SWITCH-OFF/
TELETEXT STORE
PICTURE SIZE/
TELETEXT SIZE SELECTION
EXIT FROM ANY DISPLAY
PREVIOUS CHANNEL/
TELETEXT PREVIOUS PAGE
CHANGE CONFIRMATION
INFORMATION DISPLAY/
TELETEXT REVEAL
PIP FUNCTIONS (OPTION);
- PIP ON/OFF
- STILL
- INTERCHANGE THE MAIN AND
SUB PICTURE (SWAP)
- SOURCE SELECTION (TV/VIDEO)
- SIZE SELECTION (SIZE)
- LOCATION SELECTION (POSITION)
- CHANNEL SELECTION (P / )
PICTURE EFFECT SELECTION
ONE/TWO-DIGIT CHANNEL
SELECTION/
TELETEXT PAGE HOLD
TUNER/CABLE NETWORK
SELECTION
SWITCH REPEATEDLY
BETWEEN THE LAST TWO
CHANNELS DISPLAYED
SOUND EFFECT SELECTION
VOLUME DECREASE
NEXT CHANNEL/
TELETEXT NEXT PAGE
SOUND MENU DISPLAY
FASTEXT TOPIC SELECTION
TELETEXT DISPLAY/
MIX BOTH TELETEXT INFORMATION
AND THE NORMAL BROADCAST
SOUND MODE SELECTION/
TELETEXT SUB-PAGE
➢The performance of the remote control may be affected by bright light.
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 8

9
Inserting the Batteries in the Remote Control
ENG
You must insert or replace the batteries in the remote control when
you:
◆Purchase the television
◆Find that the remote control is no longer operating
correctly
1Remove the cover on the rear of the remote control by pressing
the symbol
() downwards and then pulling firmly to remove it.
2Insert two R03, UM4, “AAA” 1.5V or equivalent batteries taking
care to respect the polarities:
◆ - on the battery against - on the remote control
◆ + on the battery against + on the remote control
3Replace the cover by aligning it with the base of the remote
control and pressing it back into place.
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 9

10
Connecting to an Aerial or Cable Television Network
ENG
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
◆A satellite network
1In the first three cases, connect the aerial or network input cable to
the 75Ω coaxial socket on the rear of the television.
2If you are using an indoor aerial, you may need to turn it when
tuning your television until you obtain a picture that is both sharp
and clear.
For further details, refer to:
◆“Storing Channels Automatically” on page 15.
◆“Storing Channels Manually” on page 16.
➢Signal Strength( ) display (Option)
The “”(Signal Strength) symbol is displayed by
pressing the “INFO ( )”button. This symbol displays
signal strength for your watching TV channel. The more
signal bar is the better TV gets sensitivity on current
channel.
Rear of the TV
Cable elevision
Network
or
P 4 Mono
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 10

11
ENG
Switching Your Television On and Off
The mains lead is attached to the rear of your television.
1Plug the mains lead into an appropriate socket.
➢
he main voltage is indicated on the rear of the television
and the frequency is 50 or 60Hz.
2Press the “ ” button (On/Off) on the front of the television.
Result: he Standby indicator on the front of the television
lights up.
3Press the POWER ( ) button on the remote control to switch the
television on.
Result: he programme that you were watching last is re-
selected automatically.
➢
If you have not yet stored any channels, No clear picture
appears. Refer to “Storing Channels Automatically” on page
15 or “Storing Channels Manually” on page 16.
4o switch your television off, press the “ ” button (On/Off) again.
Placing Your Television in Standby Mode
Your television can be placed in Standby mode, in order to reduce:
◆Power consumption
◆Wear of the cathode ray tube
The Standby mode can be useful when you wish to interrupt
viewing temporarily (during a meal, for example).
1Press the POWER ( ) button on the remote control.
Result: he screen is turned off and the Standby indicator on
the front of the television lights up in red.
2o switch the television back on, simply press the POWER ()
button again.
➢
You can also switch on by pressing the Por button.
☛Do not leave your television in Standby mode for long
periods of time (when you are away on holiday, for
example). Turn your television off by pressing the “”
button (On/Off) on the front of the television. It is best to
unplug the set from the mains and aerial.
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 11

12
ENG
The remote control is used mainly to:
◆Change channels and adjust the volume
◆Set up the television using the on-screen menu system
The following table presents the most frequently used buttons and
their functions.
Button Viewing Function Menu Function
Used to display the next -
stored channel.
Used to display the previous
-
stored channel.
to Used to display the corresponding channels.
-/-- Used to select a channel numbered ten or over.
Press this button, and the “
-- ” symbol is displayed.
Enter the two-digit channel number.
PRE-CH Press the PRE-CH button. he V will switch to the last
channel viewed.
o quickly switch between two channels that are far apart,
tune to one channel, then use the number button to select
second channel. hen, use the PRE-CH button to quickly
alternate between them.
Used to increase the volume. -
Used to decrease the volume. -
MUTE Used to switch the sound off temporarily.
➢
o turn the sound back on, press this button again, or
press the or button.
MENU Used to display the Used to return to the previous
on-screen menu system. menu or normal viewing.
- Used to:
◆Display a submenu
containing selections for
the current menu option
◆Increase/decrease a
menu option value
- Used to confirm your choice.
EXIT - Used to exit from the menu
system and return to normal
viewing directly.
TV ◆Used to return the V -
mode when it is in external
input mode.
Becoming Familiar with the Remote Control
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 12

13
ENG
When the television is initially powered on, three basic customer
settings proceed automatically and subsequently: setting the
language, channel and clock.
1If the television is in Standby mode, press the POWER ( ) button
on the remote control.
Result: he message Plug & Play is displayed. It flickers for
a little while and then Language menu is automatically
displayed.
2Select the appropriate language by pressing the ▼or ▲ button.
Press the ENTER ( ) button to enter the language.
Result: he message Check antenna input. is displayed.
➢
If any language is not selected on the Language menu, the
Language menu will disappear about 30 seconds later.
3Make sure that the antenna is connected to the V.
Press the ENTER ( ) button.
Result: he Auto Store menu is displayed with Area is
selected.
4Press the ENTER ( ) button again. Select your area by pressing
the ▼or ▲button, and then Press the ENTER ( ) button.
o search the channels, select Search by pressing the ▼or ▲
button, and then press the ENTER ( ) button.
Press the ENTER ( ) button again to start search the channels.
Press the MENU ( ) button to stop the search.
Result: he Time menu is displayed with Clock is selected.
➢
Refer to “Storing Channels Automatically” on page 15.
5Press the œor √button to move to the hour or minute. Set the
hour or minute by pressing the ▼or ▲ button.
➢
Refer to “Setting and Displaying the Current ime” on page
30.
6When you have finished, press the MENU ( ) button.
Result: he message Enjoy your watching is displayed,
and then the channel which has been stored will be
activated.
7If you want to reset this feature...
1Press the MENU ( ) button.
2Press the ▼or ▲ button to select Setup, and then press the
ENTER ( ) button.
Result: he Plug & Play is selected.
3Press the ENTER ( ) button again.
Result: his feature starts with the message Plug & Play
is displayed.
Plug & Play Feature (depending on the model)
Plug & Play
Enjoy your watching
Move Enter Return
Setup
Plug & Play √√
Language : English
Time √√
Child Lock √√
Blue Screen : Off √√
Melody : On √√
Demonstration √√
TV
Move Enter Return
Auto Store
Area : ASIA W/EUROPE √√
Search √√
TV
Move Enter Return
Time
Clock -- : -- am
Sleep Timer : Off
On Timer -- : -- am Off
Off Timer -- : -- am Off
On Timer Volume : 10
TV
Check antenna input.
Enter Exit
Search
Enter Return
Start
Language
English
Français
Türkçe
Move Enter
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 13

14
ENG
To become familiar with the various menus provided by your
television, you can view the in built demonstration.
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Setup.
Result: he options available in the Setup group are
displayed.
3Press the ENTER ( ) button.
4Press the ▼or ▲ button to select Demonstration.
5Press the ENTER ( ) button.
Result: Each of the menu options is displayed in turn.
➢
When you wish to exit from the demonstration, press the
EXIT ( ) button on the remote control.
Viewing the Demonstration
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Setup.
Result: he options available in the Setup group are
displayed.
3Press the ENTER ( ) button.
4Press the ▼or ▲button to select Language.
5Select the appropriate language by pressing the ENTER ()
button repeatedly.
Choosing Your Language
Move Enter Return
Setup
Plug & Play √√
Language : English
Time √√
Child Lock √√
Blue screen : Off √√
Melody : On √√
Demonstration √√
TV
Move Enter Return
Setup
Plug & Play √√
Language : English
Time √√
Child Lock √√
Blue screen : Off √√
Melody : On √√
Demonstration √√
TV
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 14

15
You can scan for the frequency ranges available to you (and
availability depends on your country). Automatically allocated
programme numbers may not correspond to actual or desired
programme numbers. However you can sort numbers manually and
clear any channels you do not wish to watch.
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Channel.
Result: he options available in the Channel group are
displayed.
3Press the ENTER ( ) button.
Result: he Auto Store is selected.
4Press the ENTER ( ) button again.
Result: he options available in the Auto Store group are
displayed with Area is selected.
5Press the ENTER ( ) button again.
6Select your area by pressing the ▼or ▲button, then press the
ENTER ( ) button.
he areas are displayed in the following order:
ASIA W/EUROPE - CIS E/EUROPE - CHINA - HONGKONG U/K -
AUSTRALIA - NZ/INDONESIA - SOUTH AFRICA - AMERICA
7Press the ▼or ▲ button to select Search, then press the ENTER
( ) button.
8Press the ENTER ( ) button to start the search.
Result: he horizontal bar is displayed, and then channels are
stored in an order which reflects their positions in the
frequency range. Finally, the search will end
automatically.
➢
o stop the search before it has finished, press the MENU
( ) button.
9When searching and storing are complete, the Sort menu is
displayed.
◆ o sort the stored channels into the desired numerical order,
go to Step 6of the “Sorting the Stored Channels” procedure
on page 19.
◆ o exit from the channel store function without sorting the
channels, press the MENU ( ) button repeatedly until the
menus disappear.
10 When the channels have been stored, you can:
◆ Sort them in the order required (refer to page 19)
◆ Clear a channel (refer to page 18)
◆ Activate the Digital Noise Reduction feature (refer to page 23)
Storing Channels Automatically
ENG
Move Enter Return
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
LNA : Off √√
TV
Move Enter Return
Auto Store
Area : ASIA W/EUROPE √√
Search √√
TV
Move Enter Return
Auto Store
Area : ASIA W/EUROPE √√
Search √√
TV
Move Adjust Return
Sort
From : P 1
To : P--
Store : ?
TV
ASIA W/EUROPE
CIS E/EUROPE
CHINA
HONGKONG U/K
AUSTRALIA
NZ/INDONESIA
SOUTH AFRICA
AMERICA
Search
Enter Return
Start
Search
Enter Return
Stop
P1 102 MHZ
7%
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 15

16
ENG
You can store the channels, including those received via cable
networks.
When storing channels manually, you can choose:
◆Whether or not to store each of the channels found
◆The programme number of each stored channel which
you wish to identify
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Channel.
3Press the ENTER ( ) button.
Result: he options available in the Channel group are
displayed.
4Press the ▼or ▲ button to select Manual Store.
5Press the ENTER ( ) button.
6o assign a programme number to a channel, press the œor √
button.
7Press the ▼or ▲ button to select Color system.
8Press the ENTER ( ) button.
9Press the ▼or ▲ button to select the broadcasting standards.
Result: he color standards are displayed in the following
order:
AUTO - PAL - SECAM - NT4.43 - NT3.58.
10 Press the ENTER ( ) button.
11 Press the ▼or ▲ button to select Sound System.
12 Press the ENTER ( ) button.
13 Press the ▼or ▲ button to select the sound standards.
Result: he sound standards are displayed in the following
order:
BG - DK - I - M.
14 Press the ENTER ( ) button.
Storing Channels Manually
Move Enter Return
Manual Store
Programme : P 3
Color System : AUTO √√
Sound System : BG √√
Search : 46MHz
Channel : C 1
Store : ?
TV
Move Enter Return
Manual Store
Programme : P 3
Color System : Auto √√
Sound System : BG √√
Search : 46MHz
Channel : P 1
Store : ?
TV
Move Enter Return
Manual Store
Programme : P 3
Color System : AUTO √√
Sound System : BG √√
Search : 46MHz
Channel : C 1
Store : ?
TV
Move Enter Return
Manual Store
Programme : P 3
Color System : AUTO √√
Sound System : BG √√
Search : 46MHz
Channel : C 1
Store : ?
TV
Move Enter Return
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
LNA : Off √√
TV
AUTO
PAL
SECAM
NT4.43
NT3.58
BG
DK
I
M
Move Adjust Return
Manual Store
Programme : P 3
Color System : AUTO √√
Sound System : BG √√
Search : 46MHz
Channel : C 1
Store : ?
TV
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 16

17
ENG
15 If you do not know the channel numbers, select Search by
pressing the ▼or ▲ button. Press the œor √ button to start the
search.
Result: he tuner scans the frequency range until the first
channel or the channel that you selected is received
on your screen.
16 If you know the number of the channel to be stored, see the
following steps.
◆ Press the ▼or ▲ button to select Channel.
◆ Press the √button.
◆ Press the ▼or ▲ button to select C(Air channel) or S(Cable
channel).
◆ Press the √button.
◆ Press the ▼or ▲ button to select indicate the required
number.
➢
You can also select the channel number directly by
pressing the numeric buttons (0~9).
◆ Press the ENTER ( ) button to select the required number.
➢
If no sound or abnormal sound, re-select the sound standard
required.
17 o store the channel and associated programme number, select
Store by pressing the ▼or ▲ button. Press the ENTER ()
button to select OK.
18 Repeat Steps 16 to 17 for each channel to be stored.
☛Channel mode
◆P(Programme mode): When completing tuning, the
broadcasting stations in your area have been assigned to
position numbers from P00 to max P99. You can select a
channel by entering the position number in this mode.
◆C(Real channel mode): You can select a channel by
entering the assigned number to each air broadcasting station
in this mode.
◆S(Cable channel mode): You can select a channel by
entering the assigned number for each cable channel in this
mode.
Storing Channels Manually (continued)
Move Enter Return
Manual Store
Programme : P 3
Color System : AUTO √√
Sound System : BG √√
Search : 46MHz
Channel : C1
Store : ?
TV
Move Enter Return
Manual Store
Programme : P 3
Color System : AUTO √√
Sound System : BG √√
Search : 46MHz
Channel : C 1
Store : ?
TV
Move Search Return
Manual Store
Programme : P 3
Color System : AUTO √√
Sound System : BG √√
Search : 46MHz
Channel : C 1
Store : ?
TV
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 17

18
ENG
You can exclude the channels you chosen from the channels you
scanned. When you scan through the stored channels, those you
have chosen to skip are not displayed.
All of the channels that you do not specifically choose to skip are
displayed during scanning.
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Channel.
Result: he options available in the Channel group are
displayed.
3Press the ENTER ( ) button.
4Press the ▼or ▲ button to select Add/Delete.
5Press the ENTER ( ) button.
Result:
he stored channels are displayed.
6Press the ▼or ▲ button to select the channel to add or erase.
If necessary, select Added or Deleted by pressing the ENTER
( ) button.
7Repeat Step 6for each channel to be added or erased.
Skipping Unwanted Channels
Move Enter Return
Add/Delete
P 1 : Added
P 2 : Added
P 3 : Added
P 4 : Added
TV
Move Enter Return
Add/Delete
P 1 : Deleted
P 2 : Added
P 3 : Added
P 4 : Added
TV
Move Enter Return
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
LNA : Off √√
TV
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 18

19
ENG
This operation allows you to change the programme numbers of
stored channels. This operation may be necessary after using auto
store. You can delete the channels you do not want to keep.
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Channel.
Result: he options available in the Channel group are
displayed.
3Press the ENTER ( ) button.
4Press the ▼or ▲ button to select Sort.
5Press the ENTER ( ) button.
Result: he options available in the Sort group are displayed
with From is selected.
6Select the channel number that you wish to change by pressing
the œor √button repeatedly.
7Press the ▼or ▲ button to select To. Select the new channel
number which you wish to identify by pressing the œor √button
repeatedly.
➢
You can also select the channel number directly by pressing
the numeric buttons (0~9).
8Press the ▼or ▲ button to select Store. Select OK to confirm the
exchange of channel numbers by pressing the ENTER ()
button.
Result:
he selected channel is exchanged with the one
previously stored to the chosen number.
9For all the channels to move to the required channel numbers,
repeat steps 6to 8after selecting the From by pressing the ▼or ▲
button.
Sorting the Stored Channels
Move Adjust Return
Sort
From : P 1
To : P--
Store : ?
TV
Move Adjust Return
Sort
From : P 1
To : P 3
Store : ?
TV
Move Enter Return
Sort
From : P 3
To : P 1
Store : OK
TV
Move Enter Return
Channel
Auto Store √√
Manual Store √√
Add/Delete √√
Sort √√
LNA : Off √√
TV
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 19

20
ENG
You can select the type of picture which best corresponds to your
viewing requirements.
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Picture.
Result: he options available in the Picture group are
displayed.
3Press the ENTER ( ) button.
4Press the ENTER ( ) button again to select Mode.
Result: he options available in the Mode group are displayed.
5Press the ▼or ▲button to select picture mode.
Result: he following picture effects are available:
Dynamic - Standard - Movie - Custom.
6Press the ENTER ( ) button.
➢You can also set these options simply by pressing the
P.MODE ( : Picture Mode) button.
Changing the Picture Standard
Move Enter Return
Mode : Dynamic √√
Custom √√
Color Tone : Normal √√
Size : Normal √√
Digital NR : Off √√
DNIe Jr : On √√
††More
TV
Move Enter Return
Mode : Dynamic √√
Custom √√
Color Tone : Normal √√
Size : Normal √√
Digital NR : Off √√
DNIe Jr : On √√
††More
TV
Dynamic
Standard
Movie
Custom
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 20

21
ENG
Your television has several settings which allow you to control
picture quality.
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Picture.
Result: he options available in the Picture group are
displayed.
3Press the ENTER ( ) button.
4Press the ▼or ▲ button to select Custom.
5Press the ENTER ( ) button.
Result: he options available in the Custom group are
displayed.
6Press the ▼or ▲ button to select the option (Contrast,
Brightness, Sharpness, Color or Tint-N SC only) to be adjusted.
Press the ENTER ( ) button.
Result: he horizontal bar is displayed. Move the horizontal
bar’s cursor left or right by pressing the œor √
button.
7Press the EXIT ( ) button.
Selecting the Color Tone
1Press the MENU ( ) button.
Result: he main menu is displayed.
2Press the ▼or ▲ button to select Picture.
Result: he options available in the Picture group are
displayed.
3Press the ENTER ( ) button.
4Press the ▼or ▲ button to select Color Tone.
5Press the ENTER ( ) button.
6Press the ▼or ▲ button to select the required option (Cool2,
Cool1, Normal , Warm1 or Warm2).
7Press the ENTER ( ) button.
➢◆If you make any changes to these settings, the picture
standard is automatically switched to Custom.
◆The television has an “automatic degaussing”system
that is activated if magnetic interference is present.
To degauss the television screen, switch power off by
pressing the “”(On/Off) button on the front panel.
(Refer to “Automatic Degaussing to Remove Colour
Patches”on page 46.)
Adjusting the Picture Settings
Contrast 100
Move Enter Return
Custom
Contrast : 100
Brightness : 45
Sharpness : 50
Color : 55
TV
Move Enter Return
Mode : Dynamic √√
Custom √√
Color Tone : Normal √√
Size : Normal √√
Digital NR : Off √√
DNIe Jr : On √√
††More
TV
Move Enter Return
Mode : Dynamic √√
Custom √√
Color Tone : Normal √√
Size : Normal √√
Digital NR : Off √√
DNIe Jr : On √√
††More
TV
Move Enter Return
Mode : Dynamic √√
Custom √√
Color Tone : Normal √√
Size : Normal √√
Digital NR : Off √√
DNIe Jr : On √√
††More
TV
Cool2
Cool1
Normal
Warm1
Warm2
AA68-03418A-00Eng_UMG_TM76 6/2/04 11:48 AM Page 21
