Samsung SP-42Q2HL Quick start guide

49
ENG
☛Whenever you connect an audio or video system to your
television, ensure that all elements are switched off.
Refer to the documentation supplied with your equipment
for detailed connection instructions and associated safety
precautions.
Connecting to the External Devices
Rear of the TV
(Input/Output)
① This end can be fitted with:
◆Three RCA connectors (VIDEO + AUDIO-L and R)
② If you have a second VCR and wish to copy cassettes tape, connect the source VCR to “IN 1” and the
target VCR to
“OUT” so that you can redirect the signal from source VCR to target VCR.
③ If you have a decoder, connect the decoder to the VCR and the VCR to the television.
➃ “OUT” is used for displaying the current picture to an external device. When you wish to record the
current picture, connect the VCR to
“OUT” .
①
Side of the TV
(Input)
(depending on the model)
Camcorder
Video disc player
Video game device
VCR
Decoder /
Video game device
Video disc player
Satellite receiver
③
➃
②
BP68-00303A(J60A_Asia_ENG) 4/2/04 12:15 AM Page 49

50
ENG
➢The AUDIO-L and R connectors are used for equipment, such as an audio system or external amplifier
(to take full advantage of the Surround sound effect).
Audio System/
External Amplifier
Connecting to the Audio Outputs
Rear of the TV
BP68-00303A(J60A_Asia_ENG) 4/2/04 12:15 AM Page 50

51
ENG
Connecting to the S-Video Input
➢The S-VIDEO (or S-VIDEO INPUT) and RCA (AUDIO3-L and R) connectors are used for
equipment with an S-Video output, such as a camcorder or VCR.
Camcorder
VCR
① To play pictures and sound, both the S-VIDEO (or S-VIDEO INPUT) and RCA connectors must be used.
and
①
and
①
Side of the TV
(depending on the model)
BP68-00303A(J60A_Asia_ENG) 4/2/04 12:15 AM Page 51

52
ENG
Connecting to the Component Input
➢The COMPONENT IN connectors are used for equipment with a DVD or DTV receiver output.
(480i, 480p, 576i,576p, 1080i)
DVD
Rear of the TV
DTV receiver
①
②
BP68-00303A(J60A_Asia_ENG) 4/2/04 12:15 AM Page 52
