Samsung SP-65W3HF User manual

COLOUR
TELEVISION
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ENG
REMOTE CONTROL
ON-SCREEN MENUS
PERFECT FOCUS
PICTURE IN PICTURE
100Hz
ELECT
01772A-03_AUS 7/10/06 2:27 PM Page 1

2
ENG
Important Warranty Information Regarding Television
Format Viewing
Standard screen format televisions (4:3, the aspect ratio of the screen width to height) are
primarily designed to view standard format full-motion video. The images displayed on them
should primarily be in the standard 4:3 ratio format and constantly moving. Displaying stationary
graphics and images on screen, such as the dark top and bottom letterbox bars (wide screen
pictures), should be limited to no more than 15% of the total television viewing per week.
Wide screen format televisions (16:9, the aspect ratio of the screen width to height) are
primarily designed to view wide screen format full-motion video. The images displayed on them
should primarily be in the wide screen 16:9 ratio format, or expanded to fill the screen if your
model offers this feature, and constantly moving. Displaying stationary graphics and images on
screen, such as the dark side-bars on non-expanded standard format television video and
programming, should be limited to no more than 15% of the total television viewing per week.
Additionally, viewing other stationary images and text such as stock market reports, video
game displays, station logos, web sites or computer graphics and patterns, should be limited as
described above for all televisions. Displaying any stationary images that exceed the above
guidelines can cause uneven aging of picture tubes (CRTs) that leave subtle, but permanent
burned-in ghost images in the television picture. To avoid this, vary the programming and
images, and primarily display full screen moving images, not stationary patterns or dark bars.
On television models that offer picture sizing features, use these controls to view the different
formats as a full screen picture.
Be careful in the selection and duration of television formats used for viewing. Uneven CRT
aging as a result of format selection and use, as well as other burned-in images, is not covered by
your Samsung limited warranty.
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
W
R
A
01772A-03_AUS 7/10/06 2:27 PM Page 2

3
ENG
Safety Instructions
◆Do not expose the television to extreme temperature conditions or to extreme humidity conditions.
◆Do not expose the television to direct sunlight and other sources of heat.
◆Do not expose the television to any liquids.
◆Never put objects of any kind into the television, and do not place a water-containing vessel on the
television.
◆During a storm conditions (especially when there is lightning) unplug the television from the mains
socket and aerial.
◆Do not step on or twist the power cord.
◆Do not overload wall outlets or extension cords as this can result in a risk of fire or electric shock.
◆Please use a soft and dry cloth (not containing volatile matter) when you clean the TV.
◆If the television is broken, do not try to repair it yourself. Contact qualified service personnel.
◆If the remote control is not used for a long period of time, remove the batteries and store it in a cool,
dry place.
◆Do not drop the remote control.
☛
This device is not for use in industrial environments.
Caution
CAUTION: TO PREVENT ELECTRICAL SHOCK,
DO NOT REMOVE REAR COVER, NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
CAUTION
WARNING: TO PREVENT DAMAGE WHICH MAY
RESULT IN FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
The lightning flash and arrow head
within the triangle is a warning
sign alerting you of “dangerous
voltage” inside the product.
The exclamation point within the
triangle is a warning sign alerting
you of important instructions
accompanying the product.
☛The main voltage is indicated on the
rear of the TV set and the frequency is
50 or 60Hz.
!
01772A-03_AUS 7/10/06 2:28 PM Page 3

4
ENG
Contents (continued)
◆PREPARING YOUR TELEVISION
■Safety Instructions ......................................................................................... 3
■Caution .......................................................................................................... 3
■Front Control Panel ....................................................................................... 6
■Front or Side Connection Panel .................................................................... 7
■Rear Connection Panel ................................................................................. 8
■Infrared Remote Control ................................................................................ 9
■Inserting the Batteries in the Remote Control................................................ 10
■Connecting the Aerial (or Cable Television Network).................................... 11
■Switching Your Television On and Off........................................................... 12
■Placing Your Television in Standby mode..................................................... 12
■Plug & Play Feature....................................................................................... 13
■Adjusting Basic Convergence........................................................................ 14
■Using the Perfect Focus Feature................................................................... 15
■Choosing Your Language.............................................................................. 16
◆SETTING UP THE CHANNELS
■Storing the Channels Automatically............................................................... 17
■Storing the Channels Manually...................................................................... 18
■Skipping Unwanted Channels ....................................................................... 19
■Fine tuning Channel Reception ..................................................................... 20
■Sorting the Stored Channels ......................................................................... 21
◆USING THE TELEVISION (continued)
■Changing the Picture Standard ..................................................................... 22
■Selecting the Picture Format ......................................................................... 22
■Adjusting the Picture Settings........................................................................ 23
■Activation/Deactivation the Digital Noise Reduction Feature ........................ 24
■Setting the Blue Screen Mode....................................................................... 24
■Using the Natural Scan Feature .................................................................... 25
■Using the LNA (Low Noise Amplifier) Feature............................................... 25
■Adjusting the Volume..................................................................................... 26
01772A-03_AUS 7/10/06 2:28 PM Page 4

5
ENG
Contents
◆USING THE TELEVISION
■Changing the Sound Standard ...................................................................... 26
■Adjusting the Sound Settings ........................................................................ 27
■Extra Sound Settings (Auto volume/Melody)................................................. 28
■Setting the Dolby ProLogic............................................................................ 29
■Selecting the Sound Mode ............................................................................ 30
■Switching the Sound Off Temporarily ............................................................ 30
■Setting the Sleep Timer ................................................................................. 31
■Setting and Displaying the Current Time....................................................... 31
■Switching the Television On and Off Automatically ....................................... 32
■Setting up your Remote Control .................................................................... 33
■Picture In Picture ........................................................................................... 34
■Setting up your PC (depending on the model) .............................................. 36
■Changing the Screen Size or Position of your PC
(depending on the model).............................................................................. 37
◆INFORMATION ON CONNECTIONS AND RECOMMENDATIONS FOR USE
■Connecting to the PC Input (depending on the model) ................................. 37
■Connecting to the AV Input/Outputs.............................................................. 38
■Connecting to the AV Input............................................................................ 38
■Connecting to the DVD Input......................................................................... 39
■Connecting to the S-Video Input.................................................................... 39
■Connecting to the Audio Output .................................................................... 40
■Viewing Picture From External Sources ........................................................ 40
■Automatic Degaussing to Remove Colour Patches....................................... 41
■Trouble Shooting: Before Contacting Service Personnel .............................. 41
☛➢
Symbols
Press Important Note
01772A-03_AUS 7/10/06 2:28 PM Page 5

6
ENG
Front Control Panel
➣The actual configuration on your TV may be different, depending on
your model.
➣
a) Temporary Sound Switch-Off
b) Source Selection
c) Menu Display
d) Volume Decrease
e) Volume Increase
f) Previous Channel Selection
g) Next Channel Selection
h) Power
i) Remote Control Sensor
j) Standby & Timer Indicator
01772A-03_AUS 7/10/06 2:28 PM Page 6

7
ENG
Front or Side Connection Panels
➣The actual configuration on your TV may be different, depending on
your model.
a
a) Perfect Focus
b) Video Input
c) Audio Inputs (L, R)
d) S-Video Input
e) PC Input (Option)
01772A-03_AUS 7/10/06 2:28 PM Page 7

8
ENG
Rear Connection Panel
☛The actual configuration on your TV may be different, depending on
the model.
R L
a) VHF/UHF
Connect to an antenna or to a cable TV
system.
b) SUPER VIDEO INPUT
S-Video signal from an S-VHS, VCR or
Laser Disc Player (The Audio signal,
however, must be connected to AV
INPUT3).
c) VIDEO INPUTS
Video signals from a VCR, Laser Disc
Player and similar devices (Two sets are
available: Video2 and Video3).
d) AUDIO INPUTS
Audio signals from a VCR, Laser Disc
Player and similar devices.
e) AUDIO-VIDEO MONITOR OUTPUTS
These Audio/Video signals are identical to
A/V signals being displayed on the big
screen (Typically used as the input signals
for a recording VCR).
f) DVD INPUTS
Connect video from a DVD player.
g) DVD AUDIO INPUTS
Connect to the audio output jacks of a
DVD player.
h, i, j) AUDIO OUTPUTS (Dolby Pro logic)
Connect to a rear-surround amp;
Surround Left and Right .
Option
➣
01772A-03_AUS 7/10/06 2:28 PM Page 8

9
ENG
Infrared Remote Control
➣Buttons and markings are subject to change.
Power
NEXT CHANNEL
PERFECT FOCUS
VCR/DVD FUNCTIONS;
(STOP/REWIND/PLAY/PAUSE/
FAST-FORWARD)
TELEVISION STANDBY
NUMERIC BUTTONS
TUNER/CABLE NETWORK SELECTION
VOLUME DECREASE
EXTERNAL INPUT SELECTION
DOLBY PRO LOGIC MENU DISPLAY
TEMPORARY SOUND SWITCH-OFF
ON-SCREEN DISPLAY
PICTURE SIZE SELECTION PICTURE EFFECT SELECTION
AUTOMATIC SWITCH-OFF
SOUND MODE SELECTION
SOUND EFFECT SELECTION
PREVIOUS CHANNEL
VOLUME INCREASE
CONTROL THE CURSOR IN THE MENU
MENU DISPLAY OR EXIT
ONE/TWO-DIGIT CHANNEL SELECTION
MAKE THE REMOTE CONTROL WORKS
FOR TV, PC, CABLE, VCR/DVD PLAYER
REMOTE CONTROL SETUP
THREE-DIGIT CHANNEL SELECTION
➢It is possible that the work of the transmitter is dull or not operated normally
if the light of the Bulb is on around the TV set.
PIP FUNCTIONS;
PIP ON/SWAP/LOCATE/SIZE SETTING/
SOURCE SELECTION (TV/VIDEO)/
SCAN/CHANNEL SELECTION (P▲/▼)
➢If the “PIP” is “Off”, the STILL
button used to freeze the main
picture.
CHANGE CONFIRMATION
PC DISPLAY CONTROL; OPTION
(CHANGE THE POSITION OR SIZE
OF SCREEN)
01772A-03_AUS 7/10/06 2:28 PM Page 9

10
ENG
Inserting the Batteries in the Remote Control
You must insert or replace the batteries in the remote control when
you :
◆Purchase the television.
◆Find that the remote control is no longer operating
correctly.
1Remove the cover of the remote control by pressing the symbol
()and pulling the cover in the direction of the arrow.
2Insert batteries, taking care to respect the polarities:
◆+on the battery with +on the remote control
◆ - on the battery with - on the remote control
3Replace the cover by pushing it in the direction of the arrow.
PRESS
T
th
01772A-03_AUS 7/10/06 2:28 PM Page 10
