Samsung UN40KU7000F User manual

UHD TV
SERVICEManual
UHD TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UN**KU7000F
Chassis : UWP60
Model : UN40KU7000F
UN43KU7000F
UN49KU7000F
UN55KU7000F
UN65KU7000F

Contents
1. Precautions...................................................................................................................1-1
1-1. Safety Precautions .............................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product information .............................................................................................................2-1
2-2. Product specication ...........................................................................................................2-3
2-2-1. Specications ...........................................................................................................2-3
2-2-2. Detailed Specications .............................................................................................2-4
2-3. Accessories ......................................................................................................................2-24
2-4. Viewing the Functions .......................................................................................................2-25
2-4-1. 2016' Smart Hub...........................................................................................2-25
2-4-2. Picture ....................................................................................................................2-28
2-4-3. Smart Things ..........................................................................................................2-29
2-4-4. Viewing the Panel...................................................................................................2-30
2-4-5. The Samsung Smart Control ..................................................................................2-33
2-4-6. Using Voice Interaction...........................................................................................2-34
2-4-7. Supported Resolutions for UHD Input Signals .......................................................2-35
2-4-8. Supported Formats.................................................................................................2-36
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
4. Troubleshooting ...........................................................................................................4-1
4-1. Previous Check ..................................................................................................................4-1
4-2. How to Check Fault Symptom.............................................................................................4-2
4-2-1. Power .......................................................................................................................4-2
4-2-2. Video.........................................................................................................................4-6
4-2-3. Audio.........................................................................................................................4-9
4-2-4. Network...................................................................................................................4-10
4-2-5. Smart Hub .............................................................................................................. 4-11
4-2-6. Bluetooth / WiFi Module .........................................................................................4-13
4-3. Factory Mode.....................................................................................................................4-14
4-4. Factory Mode Adjustments ................................................................................................4-18
4-4-1. Detail Factory Option..............................................................................................4-18
4-4-2. Factory Data ...........................................................................................................4-23

4-5. RS-232C............................................................................................................................4-36
4-6. AV Control Tabe.................................................................................................................4-37
4-7. Updating the TV’s Software...............................................................................................4-45
5. Wiring Diagram.............................................................................................................5-1
5-1. Wiring Diagram....................................................................................................................5-1
5-2. Connector............................................................................................................................5-3
ANNEX. Exploded View & Part List [UN40KU7000FXZA DA01] ........................ ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN43KU7000FXZA AA01] ........................ ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN49KU7000FXZA FA01]......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN55KU7000FXZA FA01]......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN65KU7000FXZA FA01]......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2016 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

1. Precautions
1-1. Safety Precautions
Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according to•
the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

ANNEX. Exploded View & Part List [UN55KU7000FXZA FA01]
1-1. Exploded View
1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-02655C PRODUCT LCD-SDC; CY-KK055HGLV3V/H,KU6400, 1 SA
2 BN44-00876A DC VSS-PD BOARD; L55E6_KHS,AC/DC,170W,100 1 SA
3 BN94-10781A ASSY PCB MAIN-SDC; LED 6K TV 1 SA
3-1 BN63-15236A COVER-TERMINAL SIDE; HIPS,MOLD,HB,BK0020, 1 SA
4 BN96-39802C ASSY BOARD P-FUNCTION TACT; KS7000/7500/K 1 SA
5 BN96-39965A ASSY SPEAKER P-FRONT; 6ohm,10 1 SA
6 BN59-01239A NETWORK-WLAN CLIENT; WCK730B,USB 2.0,16P, 1 SA
7 BN96-40124A ASSY COVER P-REAR; 55KU6400,PC+ABS+ED20%, 1 SA
8 BN96-40157A ASSY GUIDE P-STAND; 55KU6400,PC+GF20%,BLA 1 SA
9 BN96-40161B ASSY STAND P-BOTTOM; 55KU6400,PC+ABS,TITA 1 SA
ANNEX-1
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN55KU7000FXZA (FA01)
1 R001A BN90-08101B ASSY COVER REAR;LED TV 6K 1 SNA
0.2 R001A BN96-40124A ASSY COVER P-REAR;55KU6400,PC+ABS+ED20%, 1 SA
..3 BN60-00162H SPACER-FOAM;PE FOAM,ROLL,GRAY,T0.5,W5 1 SNA
..3 BN61-04692A ADHESIVE-AA;SHEET,CLEAR,C043 0 SNA
..3 R001 BN63-15234A COVER-REAR;55KU6400,PC+ABS+ED20%,MOLD,V- 1 SNA
..3 BN64-03529A INLAY-TERMINAL SIDE;55KU6500,PET,T0.125, 1 SNA
..3 BN68-07835A LABEL-STICKER LICENSE;40K5500,PET,0.125, 1 SNA
1 S001A BN90-08126B ASSY STAND;LED TV 6K 1 SNA
0.2 SG01A BN96-40157A ASSY GUIDE P-STAND;55KU6400,PC+GF20%,BLA 1 SA
..3 6902-002059 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W300,L40 1 SNA
..3 SG03 BN61-13610A GUIDE-STAND;55KU6400,PC+GF20%,MOLD,V-2,B 1 SNA
..3 BN63-07556S SHEET-PROTECTION COVER;TOC,PO,W150,ROLL, 1 SNA
..3 BN63-11875X SHEET-PROTECTION COVER;55KS7000,PO,T0.06 1 SNA
..3 BN63-15464A COVER-STAND NECK FRONT;55KU6400,PC+ABS,M 1 SNA
..3 BN63-15468A COVER-STAND NECK REAR;55KU6400,PC+ABS,MO 1 SNA
..3 BN63-15474A COVER-STAND DECORATION REAR;55KU6400,PC+ 1 SNA
..3 BN96-36261A ASSY ACCESSORY-SCREW;JU7000 75",6003-001 1 SNA
...4 SCREW 6003-001334 SCREW-TAPTYPE;BH,+,S,M4,L14,ZPC(BLK),SWR 4 SA
...4 6902-002476 BAG SCREW;LDPE,T0.05*,W70,L90,TRP,RECYCL 1 SNA
..3 BN96-40153A ASSY COVER P-STAND DECORATION;55KU6400,P 1 SNA
0.2 SB02A BN96-40161B ASSY STAND P-BOTTOM;55KU6400,PC+ABS,TITA 1 SA
..3 SCREW 6002-000126 SCREW-TAPPING;FH,+,-,2S,M3,L10,ZPC(BLK), 8 SA
..3 6902-002462 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W100,L50 2 SNA
..3 6902-002469 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W160,L30 1 SNA
..3 BN60-00162E SPACER-FOAM;PE FOAM,ROLL,GRAY,T0.5,W20 1 SNA
..3 BN61-13596A BRACKET-STAND BOTTOM;55KU6500,ALDC,MOLD, 1 SNA
..3 RF01 BN67-00398L FOOT-RUBBER;SILICONE,GRAY,T2 6 SNA
..3 BN68-05603A LABEL-E PASS;ART PAPER 90G,W/W 2 SNA
..3 BN95-02794B ASSY COVER STAND SMT-TOP;KU6500,55,TITAN 1 SNA
...4 BN63-11118P SHEET-PROTECTION COVER;55K6200,PET,T0.04 1 SNA
...4 BN63-15459A COVER-STAND TOP;55KU6400,PC+ABS,MOLD,V-0 1 SNA
..3 BN96-18013B ASSY ACCESSORY-SCREW;ALL MODEL,6002-0012 1 SNA
...4 SCREW 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 SA
...4 BN69-08203B BAG SCREW;LDPE,0.05,70,90,TRP,Vinyl pack 1 SNA
1 BN90-08332B ASSY W/I;UKU6400Q 1 SNA
0.2 BN81-08159Z A/S PART SET-ELEC W/I;LED TV ELEC spec-C 1 SNA
0.2 BN81-12184Y A/S PART SET-MECH W/I;UKU6400Q,U55KQ* 1 SNA
1 M0017 BN91-17257A ASSY CHASSIS;LED TV 6K 1 SNA
0.2 BN94-10781A ASSY PCB MAIN-SDC;LED 6K TV 1 SA
..3 BN62-00817A HEAT SINK-PS;55KU6000,A1050,T1.5,W115,L1 1 SNA
..3 BN63-15236A COVER-TERMINAL SIDE;HIPS,MOLD,HB,BK0020, 1 SA
..3 T0527 BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W 1 SNA
..3 BN97-10915A ASSY DRM;JAZZ-L,ATSC,NagSam, MAC, HDCP 1 SNA
ANNEX-2
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 BN46-00109H KEY CODE-CERTIFICATION;MAC,TV/AV,General 1 SNA
...4 BN46-00110P KEY CODE-CERTIFICATION;MIRACAST(HDCP2.2) 1 SNA
...4 BN46-00499A KEY CODE-CERTIFICATION;JAZZ-L,Nagra CSC 1 SNA
..3 BN97-10971A ASSY SMD;LED 6K 1 SNA
...4 0202-001976 SOLDER-CREAM;LST-309M-K21,20~38um,96.5Sn 4 SNA
...4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
...4 0403-001164 DIODE-ZENER;MMSZ5232B,5.32~5.88V,500mW,S 1 SA
...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8~6.6V,300mW,SO 3 SNA
...4 0403-001831 DIODE-ZENER;KDZ12B,12~13.5V,1000mW,SOD-1 1 SA
...4 0403-002014 DIODE-ZENER;KDZ16B,16.2~18.3V,1000mW,SOD 2 SNA
...4 0404-001307 DIODE-SCHOTTKY;SSC54,40V,5000mA,DO-214AB 1 SA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 5 SA
...4 0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000mA,SOD 1 SA
...4 0404-001881 DIODE-SCHOTTKY;SS3040-HE,40V,3000mA,SOD- 1 SA
...4 0404-001953 DIODE-SCHOTTKY;MBRA340F-HAF,40V,3000mA,S 3 SA
...4 0406-001200 DIODE-TVS;RClamp0504F,6V,1MAV,TP 2 SA
...4 0406-001628 DIODE-TVS;AOZ8804ADI,6V,1MAV,5A,TP 1 SA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V,6.7V,7V,200MAV,20 1 SA
...4 0406-001643 DIODE-TVS;1SMA33AT3G,36.7V,38.65V,40.6V, 1 SNA
...4 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, 1 SNA
...4 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 7 SC
...4 0504-000126 TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7K,S 1 SA
...4 0505-001844 FET-SILICON;SI4435DDY-T1-GE3,P,30V,-11.4 1 SA
...4 0505-002560 FET-SILICON;AO6415,P,20V,-3.3A,0.15ohm,1 1 SA
...4 0505-002598 FET-SILICON;AP2317GN,P,20V,-4.2A,0.052oh 1 SA
...4 0505-002660 FET-SILICON;Si2308BDS,N,60V,2.3A,0.156oh 1 SNA
...4 0505-002893 FET-SILICON;AO4801AS,P,30V,-5A,2W,SOIC-8 2 SA
...4 0505-003205 FET-SILICON;DMG4435SSS-13,P,30V,-7.3A,1. 1 SA
...4 0505-003391 FET-SILICON;AOD2922,N,100V,8A,140Mohm,18 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,0.38A,1.19ohm, 1 SA
...4 0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2 5 SA
...4 1001-001998 IC-ANALOG MULTIPLEX;NX3DV221GM,USB switc 2 SA
...4 1103-001564 IC-EEPROM;S-24C512CI-J800,512Kbit,64Kx8, 1 SA
...4 1105-002704 IC-DDR4 SDRAM;K4F8E304HB-MGCH,LPDDR4-SDR 1 SA
...4 1105-002751 IC-DDR4 SDRAM;K4F2E3S4HM-MGCJ,LPDDR4-SDR 1 SA
...4 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 SA
...4 1201-003690 IC-AUDIO AMP;TAS5747PHPR,QFP,48P,DUAL,PL 1 SA
...4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 SA
...4 1203-008102 IC-POSI.FIXED REG.;S-13A1D12-E800,HSOP,8 1 SNA
...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 1 SNA
...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E800,HSOP,8 1 SNA
...4 1203-008391 IC-DC/DC CONVERTER;AOZ1269QI-02,QFN-23L, 1 SA
...4 1203-008392 IC-VOL. DETECTOR;S-6414AAB-L800X,TSOT-23 1 SA
...4 1203-008454 IC-DC/DC CONVERTER;TPS56528,HSOP8,8,4,89 2 SA
...4 1203-008522 IC-DC/DC CONVERTER;SN1501019DDCR,SOT-23, 2 SNA
...4 1203-008551 IC-DC/DC CONVERTER;BM81244,QFN,40P,6x6mm 1 SNA
...4 1203-008655 IC-DC/DC CONVERTER;BM81249MWW,QFN,56,7x7 1 SA
ANNEX-3
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 1203-008732 IC-DC/DC CONVERTER;SYD104ADC,TSOT-23,6,3 1 SA
...4 1203-008733 IC-DC/DC CONVERTER;AOZ1236QI-02,QFN,23,4 2 SA
...4 1204-003697 IC-DECODER;SDP1531,FCPBGA,1046P,31x31,GL 1 SA
...4 1205-004822 IC-SWITCH;TPS22965DSGR,SON,8P,2x2x0.75mm 3 SNA
...4 1205-005325 IC-REPEATER;PS8409QFN48GTR2-A1,QFN,48P,6 1 SNA
...4 1205-005519 IC-SWITCH;ET20163,SOT23-5,5P,2.95x3.02mm 2 SA
...4 1404-001731 THERMISTOR-NTC;33Kohm,4050K,1mW/C,TP,1.6 2 SNA
...4 1405-001232 VARISTOR;6.4V,5.6Vdc,30A,1.6x0.8mm,TP,19 2 SNA
...4 1405-001271 VARISTOR;35V,20Vdc,5A,1.0x0.5mm,TP,100V, 15 SA
...4 1405-001381 VARISTOR;11V,8Vdc,30A,1.6x0.8mm,TP,25V,5 2 SA
...4 1405-001382 VARISTOR;24.5V,16VDC,120A,2.0x1.25mm,TP, 2 SA
...4 2007-000039 R-CHIP;0ohm,1%,1/10W,TP,1608 8 SA
...4 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 12 SA
...4 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 SA
...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 17 SA
...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 23 SA
...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 5 SA
...4 2007-000683 R-CHIP;3.3Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-000701 R-CHIP;3.6Kohm,1%,1/10W,TP,1608 1 SNA
...4 2007-000736 R-CHIP;30Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-000779 R-CHIP;33ohm,1%,1/10W,TP,1608 2 SA
...4 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 3 SA
...4 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-001288 R-CHIP;18ohm,5%,1/16W,TP,1005 4 SA
...4 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 25 SA
...4 2007-001298 R-CHIP;51ohm,5%,1/16W,TP,1005 10 SNA
...4 2007-002899 R-CHIP;10ohm,1%,1/10W,TP,1608 10 SA
...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 14 SNA
...4 2007-007131 R-CHIP;13Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 67 SNA
...4 2007-007137 R-CHIP;1.2Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005,T0.35 13 SA
...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 28 SA
...4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 25 SNA
...4 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005,T0.35 1 SA
...4 2007-007310 R-CHIP;8.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 11 SA
...4 2007-007313 R-CHIP;6.8Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 14 SA
...4 2007-007334 R-CHIP;200Kohm,1%,1/16W,TP,1005 5 SA
...4 2007-007488 R-CHIP;75Kohm,1%,1/16W,TP,1005 5 SNA
...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 6 SNA
...4 2007-007520 R-CHIP;20ohm,1%,1/10W,TP,1608 9 SA
...4 2007-007528 R-CHIP;1.5Kohm,1%,1/16W,TP,1005 5 SA
ANNEX-4
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2007-007720 R-CHIP;300Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-007723 R-CHIP;75Kohm,1%,1/10W,TP,1608 3 SA
...4 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 19 SA
...4 2007-007767 R-CHIP;200ohm,1%,1/16W,TP,1005 8 SA
...4 2007-007798 R-CHIP;10ohm,1%,1/16W,TP,1005 9 SA
...4 2007-007830 R-CHIP;14Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-007847 R-CHIP;16Kohm,1%,1/10W,TP,1608 5 SA
...4 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007981 R-CHIP;180Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 9 SA
...4 2007-008263 R-CHIP;3Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-008269 R-CHIP;51Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005 4 SA
...4 2007-008391 R-CHIP;6.34Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-008596 R-CHIP;0.1ohm,1%,1/4W,TP,3216 3 SC
...4 2007-008779 R-CHIP;0ohm,1%,1/16W,TP,1005 3 SA
...4 2007-009117 R-CHIP;49.9Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-009322 R-CHIP;1.3Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-009777 R-CHIP;4.99Kohm,1%,1/16W,TP,1005 2 SA
...4 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 8 SNA
...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 4 SA
...4 AD480 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,TP,1005 5 SA
...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 3 SA
...4 AD480 2203-000386 C-CER,CHIP;0.015nF,5%,50V,C0G,TP,1005 3 SA
...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 12 SA
...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 2 SA
...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 3 SA
...4 AD480 2203-000812 C-CER,CHIP;0.033nF,5%,50V,C0G,TP,1005 6 SA
...4 AD480 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 5 SNA
...4 AD480 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608 1 SNA
...4 AD480 2203-005054 C-CER,CHIP;0.0047nF,0.25pF,50V,NP0,TP,10 2 SA
...4 AD480 2203-005083 C-CER,CHIP;220nF,10%,50V,X7R,TP,1608,0.8 6 SA
...4 AD480 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 4 SA
...4 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 2 SNA
...4 AD480 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 8 SA
...4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,TP,1005 3 SNA
...4 AD480 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,TP,1005,T0. 106 SA
...4 AD480 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,TP,1608 16 SA
...4 AD480 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0. 1 SA
...4 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 28 SNA
...4 AD480 2203-006698 C-CER,CHIP;1000nF,10%,25V,X7R,TP,1608,0. 6 SA
...4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,TP,1608 5 SNA
...4 AD480 2203-006838 C-CER,CHIP;2200nF,10%,6.3V,X5R,TP,1005 9 SA
...4 AD480 2203-006844 C-CER,CHIP;470nF,10%,10V,X5R,TP,1005 2 SA
...4 AD480 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 30 SNA
ANNEX-5
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 19 SNA
...4 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 72 SA
...4 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 12 SA
...4 AD480 2203-007306 C-CER,CHIP;10000nF,10%,25V,X5R,TP,2012,1 42 SNA
...4 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 21 SA
...4 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 36 SA
...4 AD480 2203-008315 C-CER,CHIP;22000nF,20%,25V,X5R,TP,2012,1 4 SA
...4 2402-001268 C-AL,SMD;100uF,20%,25V,WT,TP,8x6.3mm 1 SA
...4 2409-001240 C-ORGANIC,SMD;33uF,20%,25V,LR,TP,7343(1. 1 SA
...4 2409-001338 C-POLYMER ,CHIP;47uF,20%,6.3V,TP,3.2x1.6 1 SA
...4 2703-000213 INDUCTOR-SMD;470nH,10%,1.35Ohm,35mA,15,M 1 SA
...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 3 SA
...4 2703-003149 INDUCTOR-SMD;2.2uH,20%,0.055Ohm,3000mA,W 1 SA
...4 2703-003747 INDUCTOR-SMD;22uH,20%,6060,0.135ohm,1300 2 SA
...4 2703-003862 INDUCTOR-SMD;10uH,20%,6060,0.065ohm,1900 3 SA
...4 2703-003913 INDUCTOR-SMD;2.2uH,20%,2520,1.2T,0.116Oh 1 SNA
...4 2703-003937 INDUCTOR-SMD;1uH,20%,7.0x6.47x3.0mm,0.00 3 SA
...4 2703-004630 INDUCTOR-SMD;2.2uH,20%,5.0T,0.0025Ohm,66 1 SNA
...4 2703-004724 INDUCTOR-SMD;8.2uH,20%,4T,0.072Ohm,2300m 4 SA
...4 2703-005191 INDUCTOR-SMD;1.5uH,20%,4.5,0.02Ohm,5300m 1 SA
...4 2703-005193 INDUCTOR-SMD;2.2uH,20%,4.5,0.024Ohm,5100 2 SA
...4 2703-005376 INDUCTOR-SMD;10uH,20%,10x10.7mm,4.0T,0.0 1 SA
...4 2801-004021 CRYSTAL-SMD;24.576MHz,20ppm,28-AAN,12pF, 1 SA
...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, 4 SNA
...4 3301-002039 BEAD-SMD;26ohm,1608,TP 33 SA
...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL 3 SA
...4 3601-001376 FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,Hi 2 SNA
...4 3701-001967 CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5mm,BLK 3 SA
...4 3707-001103 CONNECTOR-OPTICAL;ANGLE,SPDIF,2.5PI 1 SA
...4 3708-003241 CONNECTOR-FPC/FFC/PIC;96P,0.5mm,SMD-A,AU 2 SNA
...4 3711-002050 CONNECTOR-HEADER;BOX,10P,1R,1.25mm,SMD-A 1 SNA
...4 EH01 3711-007803 HEADER-BOARD TO CABLE;BOX,12P,1R,1.25mm, 1 SA
...4 EH01 3711-007814 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S 1 SA
...4 EH01 3711-008098 HEADER-BOARD TO CABLE;BOX,20P,1R,1.25mm, 1 SNA
...4 EH01 3711-008131 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 SA
...4 EH01 3711-008859 HEADER-BOARD TO CABLE;BOX,12P,2R,2mm,ANG 1 SA
...4 3711-009090 CONNECTOR-HEADER;BOX,16P,1R,1.25mm,SMD-A 1 SA
...4 3722-003199 JACK-MODULAR;8P/8C,Y,ANGLE,NONE,AU,1PORT 1 SA
...4 3722-003457 JACK-USB;4P/1C,NI,BLK,ANGLE,A,2.0,13.1x1 2 SA
...4 3722-003814 JACK-PHONE;1P/7C,NI/SN,YEL,ANGLE,3.5PI,1 1 SA
...4 JACK 3722-003873 JACK-PHONE;1P/7C,AU/SN,BLU,ANGLE,3.5PI,1 1 SA
...4 6302-001376 GASKET-SMD;,,CONDUCTIVE FABRIC,T14,W43,L 7 SNA
...4 BN13-00067B IC-PLD;MAXQ636V-2605+T,9,3.3,1.64,3.6,0t 1 SNA
...4 BN40-00321B TUNER-DTV AIR CABLE;GVTH-6A21,GVTH-6A21, 1 SA
...4 BN41-02528A PCB-MAIN;KU6000,FR-4,4L,1.6T,193x241mm,1 1 SNA
...4 CB07 BN61-13312B BRACKET-PCB;55KS8000,SK5,0.3,13.7,11.4,S 4 SNA
...4 BN68-04746A LABEL-SMD;all model,POLY*,polyester,comm 1 SNA
ANNEX-6
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 BN97-10863A ASSY MICOM-SUB;JMMICOM_TV,UWP60,W25Q40CL 1 SNA
....5 1107-002226 IC-NOR FLASH;W25Q40CLSSIP,4Mbit,SOIC,8P, 1 SA
...4 BN97-10920A ASSY MICOM;TCON,KU6k,55-SDC-Flat,W25Q80D 1 SNA
....5 1107-002339 IC-NOR FLASH;W25Q80DV,8Mbit,SOP,5.28x5.2 1 SNA
....5 BN46-00515A S/W MICOM;Jazz M-L,TCON F/W 1 SNA
....5 BN46-00518A S/W MICOM;K55A6U0F,SDC,55A6AU**K,Flat 1 SNA
...4 BN97-10946A ASSY MICOM;T-JZMAKUC,UWP60,THGBMHG6C1LBA 1 SNA
....5 1107-002422 IC-EMMC;8GB,64Gbx1,BGA,153P,11.50 x 13.0 1 SA
1 BN91-17331A ASSY SHIELD;LED TV 6K 1 SNA
0.2 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 2 SA
0.2 BN39-02217C LEAD CONNECTOR-POWER;40K5500,UL21016,12P 1 SA
0.2 BN39-02219D LEAD CONNECTOR-SUB ASSY;40KU6300, 43KU63 1 SA
0.2 BN39-02231D LEAD CONNECTOR-SUB ASSY;43KU6400,UL21016 1 SA
0.2 BN44-00876A DC VSS-PD BOARD;L55E6_KHS,AC/DC,170W,100 1 SA
0.2 WIFI BN59-01239A NETWORK-WLAN CLIENT;WCK730B,USB 2.0,16P, 1 SA
0.2 BN96-39802C ASSY BOARD P-FUNCTION TACT;KS7000/7500/K 1 SA
0.2 BN96-39820B FFC CABLE;43KS7500,Fold,L500,96P 1 SA
0.2 BN96-39821D FFC CABLE;55KU6400,Fold,L350,96P 1 SA
0.2 BN96-39965A ASSY SPEAKER P-FRONT;6ohm,10 1 SA
1 BN92-19771B ASSY LABEL;LED TV 6K 1 SNA
0.2 BN68-05050A LABEL-RATING;ALL MODEL,SS,PE,T0.05,W93,L 1 SNA
0.2 BN68-07841D LEAFLET-QUICK SETUP GUIDE;KU7000,ZA,W/P, 1 SNA
0.2 BN68-07854Q LABEL-ENERGY;UN55KU7000FXZA,PET,T0.1,38, 1 SNA
0.2 BN74-00053G TAPE-PAPER;PAPER,3M2307,0.14T,W10,60M,WH 0 SNA
1 BN92-19797A ASSY BOX;LED TV 6K 1 SNA
0.2 BH68-00697A LABEL BOX;ALL,ART,90g,W60,L100,WHT,NO SI 1 SNA
0.2 BN69-13567B BOX UNIT;55KU7000,CB,DW3,F1,L1410,W148,H 1 SNA
1 BN92-19821A ASSY P/MATERIAL;LED TV 6K 1 SNA
0.2 6902-001611 BAG ROLL;HDPE/PE FOAM,T0.5/T0.015,W1500, 2 SNA
0.2 6922-000013 BAND;PP,W18,L2300/L2900,TRP 1 SNA
0.2 BH69-00418A WRAP;762,1828M,SAMEX FACTORY 2 SNA
0.2 BN02-00319B TAPE-OPP;OPP,T0.05,W75,L800m,CLEAR 3 SNA
0.2 AS080 BN63-07229A SHEET-PROTECTION COVER;rose70",PET,T0.05 2 SNA
0.2 BN68-02422B LABEL-WARNING;ALL,ART,T0.05,W240,L100,Wh 1 SNA
0.2 BN69-12806A PACKING ANGLE;40J6400,PAPER 1 SNA
0.2 BN69-13063A CUSHION-SET SIDE;EPS,16.7g/l,WHT,0 1 SNA
0.2 BN69-13186A CUSHION-SET;EPS,16.7g/l,WHT,W/W,0 1 SNA
0.2 BN69-14199A PAD-CUSHION FRONT;55KU6400,CB,DW2+EPS,W6 1 SNA
1 ACCE1 BN92-20005A ASSY ACCESSORY;LED TV 6K 1 SNA
0.2 BN96-39497A ASSY ACCESSORY-MANUAL CABLE;UK6R 1 SNA
..3 T0268 3903-001117 CBF-POWER CORD;DT,USA,Angle,2P(C7),125V, 1 SA
..3 4301-000101 BATTERY-ALKALINE;1.5V,1650mAH,LR6,14.5x5 2 SNA
..3 6801-002215 CARD COUPON;7 Series and SUHD, SEA,PLAST 1 SNA
..3 6902-001962 BAG PE;LDPE,BIOBASED,T0.05,W400,L300,TRP 1 SNA
..3 EC03 BN39-02189A GENDER CABLE;DC to RCA Cable,3P,L100,UL2 1 SA
..3 EC03 BN39-02190A GENDER CABLE;DC to RCA Cable,2P,L100,UL2 1 SA
..3 BN59-01241A REMOCON-SMART CONTROL;2016 TV,Samsung,14 1 SA
ANNEX-7
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..3 BN68-04972E LEAFLET-REGULATORY GUIDE;ALL,SAMSUNG,W/W 1 SNA
..3 BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,T0.2,W20 1 SNA
..3 BN68-07920A MANUAL USERS;KU7000,ZA,W/P 1 SNA
..3 BN96-40152A ASSY HOLDER P-CABLE;65KS7500,ABS,BK0007, 1 SNA
...4 BN61-04692A ADHESIVE-AA;SHEET,CLEAR,C043 1 SNA
...4 BN61-05704A TAPE-DOUBLE FACE;T1.1,W8,Dark Gray,3M #4 0 SNA
...4 AH089 BN61-13777A HOLDER-CABLE;55KS7500,ABS,T15,BK0007,HB, 1 SNA
...4 AS080 BN63-07556W SHEET-PROTECTION COVER;F-LED,PO,W12,ROLL 0 SNA
..3 EH03A BN96-40460A ASSY HOLDER P-RING;55KS7500,ABS,BLACK,V- 1 SNA
...4 6902-001404 BAG PE;LDPE,T0.05,W80,L100,TRP,N 1 SNA
...4 BN61-13518A HOLDER-WALL RING;55KS7500,ABS,MOLD,BK000 4 SA
1 BN95-02655C PRODUCT LCD-SDC;CY-KK055HGLV3V/H,KU6400, 1 SA
0.2 BN68-05595A LABEL-STICKER;ART 100G,T0.2,W80X23,WHITE 1 SNA
0.2 BN90-08236A ASSY MISC-BLU;Y16,LCM 1 SNA
..3 6001-002912 SCREW-MACHINE;CH,+,M3,L3,ZPC(BLK),SWRCH1 12 SA
..3 BN61-13658A OPTICAL SHEET-COMPLEX;16Y_KU6400_COMPLEX 1 SNA
..3 BN61-13659A OPTICAL SHEET-DIFFUSER;16Y_KU6400_55INCH 1 SNA
..3 BN61-13660A OPTICAL SHEET-REFLECTOR;16Y_KU6400_REFLE 1 SNA
..3 BN61-13688A LGP;16Y_KS9000_55INCH_LGP,MS,MS Lenti (V 1 SNA
..3 BN61-14082A HOLDER-LGP;55KS7000,PC,MOLD,WT0044,V-2 1 SNA
..3 BN96-39601A ASSY LED BAR P;55 KU6400(SDC),Left,ALUMI 1 SNA
..3 BN96-39602A ASSY LED BAR P;55 KU6400(SDC),Right,ALUM 1 SNA
..3 BN96-39615C ASSY CHASSIS REAR P;55KU6400,EGI-SECC,NA 1 SNA
...4 SCREW 6001-002759 SCREW-MACHINE;CH,+,M3,L4,ZPC(BLK),SWRCH1 4 SA
...4 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 4 SA
...4 6041-001068 RIVET-PH;SWRCH10A,OD3.2,L4.3,ZPC(WHT) 10 SNA
...4 BN02-00040B TAPE DOUBLE FACE;NNB 32/40/46/55",PET,T0 1 SNA
...4 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 0 SNA
...4 BN02-00352B TAPE-OPP;PET,T0.05,W30,L50M,BLK,ULNO.E16 0 SNA
...4 BN02-00352H TAPE PET;49"MEGA 2,PET,T0.05,W15,L18,BLA 4 SNA
...4 BN02-00493A TAPE PET;55KS9000,PET,T0.05,W5,L50,BLACK 5 SNA
...4 BN02-00508A TAPE PET;65KS7000,PET,T0.05,W13,L70,BLAC 5 SNA
...4 BN39-02178A LEAD CONNECTOR-BLU;55KU6400,UL21016,12P, 1 SNA
...4 BN60-00988T SPACER-SILICONE;55KS9000,SI,L10,BLACK,T2 4 SNA
...4 BN60-00988V SPACER-SILICONE;55KU6400,Si,L10,GRAY,T3. 2 SNA
...4 BN61-05914A TAPE DOUBLE FACE;65LB650,ACRYL,T1.1,W20, 0 SNA
...4 BN61-08235A HOLDER-LGP;SNB,SWRCH10A,BLACK,PRESS 2 SNA
...4 BN61-08235F HOLDER-LGP;55KS7500,SWRCH10A,EXTRUSION,S 2 SNA
...4 BN61-11982B HOLDER-WALL RIVET;55KS7000,CR-SPCC,EXTRU 4 SNA
...4 BN61-13245B BRACKET-LED PCB;55KS7000,Al,T1.5,W200,L9 1 SNA
...4 BN61-13327A HOLDER-SHEET;55KS7500,ABS,BK0007,HB,COMM 5 SNA
...4 BN61-13557A BRACKET-WIRE;KS7000,SW-C,1,60,SILVER 4 SA
...4 BN61-13557G BRACKET-WIRE;KS7000,SW-C,1,490,SILVER,ZI 4 SA
...4 CB18 BN61-13606A BRACKET-STAND LINK;55KU6400,EGI-SECC,T1. 1 SNA
...4 CB18 BN61-13607A BRACKET-STAND LINK;55KU6400,EGI-SECC,T1. 1 SNA
....5 BN61-09605A STUD-PEM;LED TV F6100,SUM24L,L8 4 SNA
...4 AH358 BN61-13908A HOLDER-REAR;55KS9000,ABS,MOLD,BK0007,HB 4 SNA
ANNEX-8
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 BN63-15364A INSULATOR-SMPS;KS7000 49/55IN,PC,BLACK,L 1 SNA
...4 BN63-15367A INSULATOR-SOURCE PCB LEFT;55KS7000,PET,B 1 SNA
...4 BN63-15368A INSULATOR-SOURCE PCB RIGHT;55KS7000,PET, 1 SNA
...4 CC04 BN64-03330A CHASSIS-REAR;EGI-SECC,SECC-AG 1 SNA
...4 BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,T0.2,W20 1 SNA
..3 BN96-40327A ASSY FRAME P-MIDDLE TOP;55KU6400,PC+GF10 1 SNA
...4 BN60-00672X SPACER-SILICONE;Y14 VNB 55,Si,L602,GRAY, 4 SNA
...4 BN61-13513A FRAME-MIDDLE TOP;55KU6400,PC+GF10%,V-2,B 1 SNA
..3 BN96-40328A ASSY FRAME P-MIDDLE BOTTOM;55KU6400,PC+G 1 SNA
...4 BN60-01426D SPACER-FOAM;55KU6400,PU FOAM,L1218,WHITE 1 SNA
...4 BN61-13514A FRAME-MIDDLE BOTTOM;55KU6400,PC+GF10%,V- 1 SNA
..3 BN96-40329A ASSY FRAME P-MIDDLE LEFT RIGHT;55KU6400, 2 SNA
...4 BN60-00672Y SPACER-SILICONE;Y14 VNB 55,Si,L680,GRAY, 2 SNA
...4 BN61-13547A FRAME-MIDDLE LEFT RIGHT;55KU6400,PC+GF10 2 SNA
0.2 BN96-39045A ASSY OPEN CELL;LSF550FN08-L,16:9,UHD 60H 1 SNA
..3 BN81-12946A A/S-ADHESIVE ACF;ADHESIVE ACF,0201-00232 1 SNA
..3 BN81-12952A A/S-ADHESIVE SIL;ADHESIVE SIL,0201-00237 1 SNA
..3 BN81-12953A A/S-IC DRIVER SOURCE;IC DRIVER SOURCE,LJ 1 SNA
..3 BN81-12954A A/S-POLARIZER CF;POLARIZER CF,LJ01-09697 1 SNA
..3 BN81-12955A A/S-POLARIZER TFT;POLARIZER TFT,LJ01-096 1 SNA
..3 BN81-12956A A/S-SOURCE PCB LEFT;SOURCE PCB LEFT,LJ94 1 SNA
..3 BN81-12957A A/S-SOURCE PCB RIGHT;SOURCE PCB RIGHT,LJ 1 SNA
0.2 BN96-39574B ASSY COVER P-SOURCE PCB;55KS7000,EGI-SEC 1 SNA
..3 BN63-15311A INSULATOR-SOURCE PCB RIGHT;55KS8000,PET, 1 SNA
..3 BN63-15317A INSULATOR-SOURCE PCB LEFT;55KS8000,PET,B 1 SNA
..3 BN63-15647B COVER-SOURCE PCB;55KS7000,EGI-SECC,T0.6, 1 SNA
0.2 BN96-40330C ASSY CHASSIS FRONT P;55KU6400,Al,DARK TI 1 SNA
..3 BN60-00715A SPACER-CONDUCTIVE;Y13 Slim F-LED,CONDUCT 2 SNA
..3 BN60-00715D SPACER-CONDUCTIVE;LCM MNT 28,CONDUCTIVE 4 SNA
..3 BN60-01178J SPACER-CONDUCTIVE;55KU6500,CONDUCTIVE FA 2 SNA
..3 BN60-01178M SPACER-CONDUCTIVE;55KU6500,CONDUCTIVE FA 2 SNA
..3 BN61-09308A ADHESIVE-TP;F8K,GREEN,ACRYL 0 SNA
..3 BN63-14373A SHEET-PROTECTION COVER;PO,W25,ROLL,CLEAR 1 SNA
..3 BN64-03583A BADGE-INLET;55KU6500,Ni,0.06,W30,Silver 1 SNA
..3 CD01A BN95-02798B ASSY DECORATION SMT;KU6400,55,TITAN SILV 1 SNA
...4 0204-007315 COATING;CVM92000(VOC),CLEAR,1.06 10 SNA
...4 BN01-00160A TARGET-CHROMIUM CY;Chromium,99.95%,1800x 0 SNA
...4 FD01 BN63-15399A COVER-DECORATION;55KU6400,PC+ABS+MF17%,M 1 SNA
..3 BN96-40705C ASSY CHASSIS FRONT P;55KU6400,Al,SUB-ASS 1 SNA
...4 BN61-09308A ADHESIVE-TP;F8K,GREEN,ACRYL 0 SNA
...4 BN61-13545A BRACKET-CORNER;55KU6400,EGI-SECC,T0.5,NA 2 SNA
...4 BN63-15554A SHEET-PROTECTION COVER;49K6200,PO,T0.048 3 SNA
...4 BN63-15858A SHEET-PET;55KU6400,PET,T0.1,W2,L12.8,BLA 2 SNA
...4 AC155 BN64-03489C CHASSIS-FRONT;55KU6400,Al,-,EXTRUSION,NA 1 SNA
ANNEX-9
ANNEX. Exploded View & Part List

ANNEX. Exploded View & Part List [UN43KU7000FXZA AA01]
1-1. Exploded View
1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-02650C PRODUCT LCD-AUO; CY-KK043HGAV3V/H,KU6400, 1 SA
2 BN44-00875A DC VSS-PD BOARD; L40E6_KSM,AC/DC,138W,100 1 SA
3 BN94-10779A ASSY PCB MAIN; LED 6K TV 1 SA
3-1 BN63-15666A COVER-TERMINAL SIDE; 43KU6500,HIPS,MOLD,H 1 SNA
4 BN96-39802C ASSY BOARD P-FUNCTION TACT; KS7000/7500/K 1 SA
5 BN96-39964A ASSY SPEAKER P-FRONT; TV-SPK,KU6400,6ohm, 1 SA
6 BN59-01239A NETWORK-WLAN CLIENT; WCK730B,USB 2.0,16P, 1 SA
7 BN96-40122A ASSY COVER P-REAR; 43KU6400,PC+ABS+ED20%, 1 SA
8 BN96-40156A ASSY GUIDE P-STAND; 43KU6400,PC+GF20%,BLA 1 SA
9 BN96-40160B ASSY STAND P-BOTTOM; 43KU6400,PC+ABS,TITA 1 SA
ANNEX-1
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN43KU7000FXZA (AA01)
1 R001A BN90-08094A ASSY COVER REAR;LED TV 6K 1 SNA
0.2 R001A BN96-40122A ASSY COVER P-REAR;43KU6400,PC+ABS+ED20%, 1 SA
..3 R001 BN63-15232A COVER-REAR;43KU6400,PC+ABS+ED20%,MOLD,V- 1 SNA
..3 BN64-03571A INLAY-TERMINAL SIDE;43KU6500,PET,T0.125, 1 SNA
..3 BN68-07835A LABEL-STICKER LICENSE;40K5500,PET,0.125, 1 SNA
1 S001A BN90-08119B ASSY STAND;LED TV 6K 1 SNA
0.2 SG01A BN96-40156A ASSY GUIDE P-STAND;43KU6400,PC+GF20%,BLA 1 SA
..3 6902-002059 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W300,L40 1 SNA
..3 SG03 BN61-13609A GUIDE-STAND;43KU6400,PC+GF20%,MOLD,V-2,B 1 SNA
..3 BN63-11875X SHEET-PROTECTION COVER;55KS7000,PO,T0.06 1 SNA
..3 BN63-15463A COVER-STAND NECK FRONT;43KU6400,PC+ABS,M 1 SNA
..3 BN63-15467A COVER-STAND NECK REAR;43KU6400,PC+ABS,MO 1 SNA
..3 BN96-36261A ASSY ACCESSORY-SCREW;JU7000 75",6003-001 1 SNA
...4 SCREW 6003-001334 SCREW-TAPTYPE;BH,+,S,M4,L14,ZPC(BLK),SWR 4 SA
...4 6902-002476 BAG SCREW;LDPE,T0.05*,W70,L90,TRP,RECYCL 1 SNA
..3 BN96-40204A ASSY COVER P-STAND DECORATION;43KU6400,P 1 SNA
...4 BN61-13387A HOLDER-COVER;55KU6500,TPE,BK0007,V-2,NYL 4 SNA
...4 BN63-15473A COVER-STAND DECORATION REAR;43KU6400,PC+ 1 SNA
0.2 SB02A BN96-40160B ASSY STAND P-BOTTOM;43KU6400,PC+ABS,TITA 1 SA
..3 SCREW 6002-000126 SCREW-TAPPING;FH,+,-,2S,M3,L10,ZPC(BLK), 2 SA
..3 SCREW 6003-001001 SCREW-TAPTYPE;FH,+,-,B,M3,L8,ZPC(BLK),SW 6 SA
..3 6902-002463 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W100,L40 2 SNA
..3 6902-002469 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W160,L30 1 SNA
..3 BN60-00162E SPACER-FOAM;PE FOAM,ROLL,GRAY,T0.5,W20 0 SNA
..3 BN61-13595A BRACKET-STAND BOTTOM;43KU6500,ALDC,MOLD, 1 SNA
..3 RF01 BN67-00398L FOOT-RUBBER;SILICONE,GRAY,T2 6 SNA
..3 BN95-02793B ASSY COVER STAND SMT-TOP;KU6500,43,TITAN 1 SNA
...4 0204-007315 COATING;CVM92000(VOC),CLEAR,1.06 6 SNA
...4 0204-007390 COATING;CVM92000(VOC,Matt3%),CLEAR,1.06 6 SNA
...4 BN01-00160A TARGET-CHROMIUM CY;Chromium,99.95%,1800x 0 SNA
...4 BN63-11118P SHEET-PROTECTION COVER;55K6200,PET,T0.04 1 SNA
...4 BN63-15457A COVER-STAND TOP;43KU6400,PC+ABS,MOLD,V-0 1 SNA
..3 BN96-18013B ASSY ACCESSORY-SCREW;ALL MODEL,6002-0012 1 SNA
...4 SCREW 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 SA
...4 BN69-08203B BAG SCREW;LDPE,0.05,70,90,TRP,Vinyl pack 1 SNA
1 BN90-08332D ASSY W/I;UKU6400Q 1 SNA
0.2 BN81-08159Z A/S PART SET-ELEC W/I;LED TV ELEC spec-C 1 SNA
0.2 BN81-12851G A/S PART SET-MECH W/I;UKU6400Q,U43KQ* 1 SNA
1 M0017 BN91-17255A ASSY CHASSIS;LED TV 6K 1 SNA
0.2 M0014 BN94-10779A ASSY PCB MAIN;LED 6K TV 1 SA
..3 BN62-00817A HEAT SINK-PS;55KU6000,A1050,T1.5,W115,L1 1 SNA
..3 BN63-15666A COVER-TERMINAL SIDE;43KU6500,HIPS,MOLD,H 1 SNA
..3 T0527 BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W 1 SNA
ANNEX-2
ANNEX. Exploded View & Part List
2-1. Electrical Parts List
