Samsung POWERbot SR20K9350W Series User manual

POWERbot
User manual
SR20K9350WSeries
• Beforeoperatingthisunit,pleasereadtheinstructionscarefully.
• Forindooruseonly.
SR9300K_EN_DJ68-00743E-00_EU.indd 1 2016-02-03 오후 8:23:52

ENGLISH-02
Contents 03 Safety information
08 Installation
Accessories/Installationnote
10 Charging
Automaticcharging/Recharging/Low
battery(Lo)
12 Installing the Virtual guard
PartnameoftheVirtualguard/Inserting
batteries
14 Using POWERbot
Selectingcleaningmode
16 Using the remote control
Power/Recharging/Suctionpower/
Additionalfunction/Manualcleanmode&
Directioncontrol/Pointcleaning
18 Name of each part
Top/Bottom/Displaypanel
19 Setting time/schedule
Settingthetime/Settingtheschedule
20 Cleaning and maintaining
Cleaningthedustbin/Cleaningthesensorsand
thecamera/CleaningthePetbrush/Cleaningthe
Drivingwheel
22 Samsung Smart Home App
Preparingthenetwork/UsingtheSamsungSmart
Homeapp
30 Notes and cautions
Charging/Inuse/Cleaningandmaintenance/About
battery/AbouttheIrDAsensor
32 Information codes
33 Troubleshooting
35 Warnings about battery
36 Open Source Announcement
37 Specifications
SR9300K_EN_DJ68-00743E-00_EU.indd 2 2016-02-03 오후 8:23:52

ENGLISH-03
Safety information
SAFETY INFORMATION
WARNING
• Beforeoperatingtheappliance,pleasereadthismanualthoroughlyandretainit
foryourreference.
WARNING
• Becausethesefollowingoperatinginstructionscovervariousmodels,the
characteristicsofyourvacuumcleanermaydifferslightlyfromthosedescribedin
thismanual.
CAUTION/WARNING SYMBOLS USED
WARNING
Indicates that a danger of death or serious injury exists.
CAUTION
Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
NOTE
Indicates that the following text contains additional important
information.
This Smart Robot vacuum supports from Samsung Smart Home.
More detailed information, please visit Samsung.com/Smarthome.
Indicates that a detachable supply unit.
SR9300K_EN_DJ68-00743E-00_EU.indd 3 2016-02-03 오후 8:23:52

ENGLISH-04
Safety information
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should be observed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING YOUR POWERbot.
Unplug from outlet when not in use and before conducting maintenance.
WARNING: to reduce the risk of fire, electric shock, or injury:
GENERAL
•Useonlyasdescribedinthismanual.
•DonotoperatePOWERbotorCharger/dockingstationifithasbeendamagedinany
way.
•Ifthevacuumcleanerisnotworkingasitshould,hasbeendropped,damaged,left
outdoors,ordroppedinwater,returnittoacustomercarecenter.
•DonothandletheCharger/dockingstationorPOWERbotwithwethands.
•Useonlyondry,indoorsurfaces.
•Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswith
reducedphysical,sensoryormentalcapabilitiesorlackofexperienceandknowledge
iftheyhavebeengivensupervisionorinstructionconcerninguseoftheapplianceina
safewayandunderstandthehazardsinvolved.
•Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshallnotbe
madebychildrenwithoutsupervision.
BATTERY Charger / docking station
•Donotmodifythepolarizedplugtofitanon-polarizedoutletorextensioncord.
•Donotuseoutdoorsoronwetsurfaces.
•UnplugtheCharger/dockingstationfromtheoutletwhennotinuseandbefore
servicing.
•UseonlytheCharger/dockingstationsuppliedbythemanufacturertorecharge.
•Donotusewithadamagedcordorplugoraloosepoweroutlet.
•Donotpullorcarrybythecord,usethecordasahandle,closethedooronthecord,
orpullthecordaroundsharpedgesorcorners.Keepthecordawayfromheated
surfaces.
•Donotuseextensioncordsoroutletswithinadequatecurrentcarryingcapacity.
•Donotunplugbypullingonthecord.Tounplug,grasptheplug,notthecord.
•Donotmutilateorincineratebatteriesastheywillexplodeathightemperatures.
•DonotattempttoopentheCharger/dockingstation.Repairsshouldonlybecarried
outbyaqualifiedcustomercarecenter.
SR9300K_EN_DJ68-00743E-00_EU.indd 4 2016-02-03 오후 8:23:52

ENGLISH-05
•DonotexposetheCharger/dockingstationtohightemperaturesorallowmoistureor
humidityofanykindtocomeintocontactwiththecharger/dockingstation.
POWERbot
•Donotpickuphardorsharpobjectssuchasglass,nails,screws,coins,andetc.
•Donotusewithoutafilterinplace.Whenservicingtheunit,neverputfingersorother
objectsintothefanchamberincasetheunitaccidentallyturnson.
•Donotputanyobjectsintoopenings.Donotusewithanyopeningsblocked;keep
openingsfreeofdust,lint,hair,andanythingthatmayreduceairflow.
•Donotpickuptoxicmaterials(chlorinebleach,ammonia,draincleaner,etc.).
•Donotpickupanythingthatisburningorsmoke,suchascigarettes,matches,orhot
ashes.
•Donotusetopickupflammableorcombustibleliquidssuchasgasoline,noruseon
areaswheretheymaybepresent.
•Locationswithcandlesordesklampsonthefloor.
•Locationswithunattendedfires(fireorembers).
•Locationswithdistilledalcohol,thinner,ashtrayswithburningcigarettes,etc.
•DonotusePOWERbotinanenclosedspacefilledwithvapoursgivenoffbyoilbased
paint,paintthinner,mothproofingsubstances,flammabledust,orotherexplosiveor
toxicvapours.
•Leaksfrombatterycellscanoccurunderextremeusageortemperatureconditions.
Iftheliquidgetsonskin,washquicklywithwater.Iftheliquidgetsintotheeyes,
flushthemimmediatelywithcleanwaterforaminimumof10minutes.Seekmedical
attention.
•ForinformationonSamsung’senvironmentalcommitmentsandproductspecific
regulatoryobligationse.g.REACHvisit:samsung.com/uk/aboutsamsung/
samsungelectronics/corporatecitizenship/data_corner.html
SR9300K_EN_DJ68-00743E-00_EU.indd 5 2016-02-03 오후 8:23:52

ENGLISH-06
WARNING Power related
fPleasepreventanyriskofelectricshockor
fire.
–Donotdamagethepowercord.
–Donotpullthepowercordtoohardortouch
thepowerplugwithwethands.
–Donotuseapowersourceotherthan
100-240V~andalsodonotuseamultioutlet
tosupplypowertonumberofdevicesatthe
sametime.(Donotleavethecordcarelesslyon
thefloor.)
–Donotuseadamagedpowerplug,powercord
orloosepoweroutlet.
fCleandustoranyforeignmattersonthepin
andcontactpartofthepowerplug.
–Thereisariskofelectricshockormalfunction.
WARNING Before use
fDonotusePOWERbotnearcombustible
materials.
–Placenearcandle,desktoplamps,fireplaceor
nearcombustiblematerialssuchasgasoline,
alcohol,thinnersetc.
fThePOWERbotisintendedforhousehold
usethereforedonotuseitinanattic,
basement,storage,industrialbuilding,outof
indoorspace,placeswithmoisture(suchas
bathroom,laundry),onthetableorshelves.
–ThePOWERbotcanbedamagedor
malfunction.
fInstalltheVirtualguardinfrontofdangerous
areas(suchasstairsorrailings)toprevent
damagingtheproductorgettinginjured.
–Foryoursafety,alwayskeepthecliffsensor
clean.
fBesurePOWERbotdoesnotpassthroughor
touchanykindofliquids.
–ThePOWERbotcanbeseverelydamagedand
itmaycontaminateotherareasifthewheels
passthroughliquid.
fDonotspillanyliquidsonthedockingstation.
–Thereisariskoffireorelectricshock.
fDonotusethedockingstationforanything
otherthanitsintendedpurpose.
–Thereisariskoffireorseveredamagetothe
dockingstation.
fAlwayskeepthecliffsensorcleanforyour
safety.
WARNING In use
fIfanyabnormalsounds,smellsorsmoke
comefromPOWERbot,immediatelyshut
offtheemergencyswitchatthebottomof
POWERbotandcontactaservicecenter.
WARNING Cleaning and
maintenance
fWhenpowercordisdamaged,contacta
servicecentertogetitreplacedbycertified
repairman.
–Thereisariskoffireorelectricshock.
fPleasecheckwithaSamsungElectronics
servicecenterwhenexchangingbatteries.
–Usingbatteriesfromotherproductscancause
malfunction.
Safety information
SR9300K_EN_DJ68-00743E-00_EU.indd 6 2016-02-03 오후 8:23:52

ENGLISH-07
CAUTION Before use
fInsertthedustbinbeforeusingPOWERbot.
fOpenroomdoorsbeforecleaninginorder
tohaveallroomscleanedandinstalla
Virtualguardinfrontofentryway,balconies,
bathrooms,orotherareaswherePOWERbot
mayfall.
fBecarefulwiththefollowingsforproper
automaticrecharging.
–Alwaysturnonthepowerofthedocking
station.
–InstallthedockingstationwherePOWERbot
caneasilyfind.
–Donotleaveanyobjectinfrontofthedocking
station.
fWheninstallingthedockingstation,donot
leavethecordcarelesslyonthefloorsince
POWERbotmaygettangledbyit.
fDonotusePOWERbotonblackcolored
floors.
–ThePOWERbotmaynotbeabletooperate
normally.
fDonotpickupPOWERbotbythedustbin
holder.
fDonotplaceanyobjectswithin0.5mtoboth
sidesand1mtothefrontofthedocking
station.
fMakesurethedockingstation'scharging
contactisnotdamagedorhaveanyforeign
mattersonit.
fDonotinstallthedockingstationinanarea
withadarkfloor.
–Iftheflooraroundthedockingstationisdark,
rechargingishindered.
fMoveanyobstaclesthatmaydisturb
POWERbot'smovement(suchaschildren's
indoorswingorslides)beforecleaning.
CAUTION In use
fUsingPOWERbotonthickcarpetmay
damagebothPOWERbotandthecarpet.
–ThePOWERbotcannotpassovercarpetthatis
thickerthan1cm.
fDonotusePOWERbotontablesorother
highsurfaces.
–Thereisariskofdamageifitfalls.
fThePOWERbotmaybumpintochair,desk
legsthereforemovethemawayforfasterand
efficientcleaning.
fWhenPOWERbotisoperating,donotliftitup
orcarryittoanotherarea.
fDonotholdbydrivingwheelsofPOWERbot
whencarryingittoanotherarea.
fDonotputanyobjectsontopofPOWERbot
sinceitmaycausemalfunction.
fRemoveanylargepapersorplasticbags
immediatelywhenusingPOWERbotsince
theymayblocktheintake.
fDonotaimtheredpointerdirectlyatpeople
oranimals.
CAUTION Cleaning and
maintenance
fPreventanydamagetoPOWERbotby
complyingthefollowings.
–DonotcleanPOWERbotbysprayingwater
directlyontoitorusebenzene,thinner,acetone
oralcoholtocleanit.
fDonotdisassembleorrepairPOWERbot.
Thisshouldonlybedonebyacertified
repairman.
fAlwayskeeptheobstaclesensorandcliff
sensorclean.
–Ifforeignmatteraccumulates,sensorsmay
malfunction.
SR9300K_EN_DJ68-00743E-00_EU.indd 7 2016-02-03 오후 8:23:53

ENGLISH-08
1Connect the
adapter jack
to the docking
station
2Connect the
power cord to
the adapter
Whenusingtheadapter,
thesidewiththesticker
attachedmustfacedown.
3Connect the
power plug to
the outlet
Powerlamp(Red)willturn
on.
Installation
Power of the docking station must be on at all times.
DC-IN
DC-IN
Powerlamp(Red)
About1m
About0.5m
About0.5m
Installitinaplacewithoutobstacles
anddangeroffalling.
Do not install the docking station in a narrow
passage or near a door.
SR9300K_EN_DJ68-00743E-00_EU.indd 8 2016-02-03 오후 8:23:53

ENGLISH-09
Accessories
Remote control Batteries (AAA
type)
User manual Spare filter Cleaning brush
Docking station
Power cord
Adapter Virtual guard
Installation note
Note
fInstallthedockingstationinaplacewherethefloorandwallarelevel.
fItisbesttoinstallthedockingstationalongthegrainofwoodenfloors.
fIftheemergencyswitchisoff,POWERbotwillnotchargeevenifitisdockedonthedockingstation.
fAlwaysturnonthepowerofthedockingstation.
–Ifpowerisnotsuppliedtothedockingstation,POWERbotcannotfinditandcannotautomatically
recharge.
–IfPOWERbotisleftdetachedfromthedockingstation,thebatterywilldrainnaturally.
fIfPOWERbotisinenergy-savingmode,powerwillnotcomeoneveniftheemergencyswitchis
turnedoffandthenon.Pressandholdthe[Start/Stop]buttononPOWERbot.
SR9300K_EN_DJ68-00743E-00_EU.indd 9 2016-02-03 오후 8:23:53

ENGLISH-10
Charginglampduringcharging(green)
It takes approximately 240 minutes to
completely charge when charging for the
first time after purchase and can be used for
approximately 30 minutes in Max mode.
Charging
1Turn on the
emergency switch
on the bottom
Youmustturnonthe
emergencyswitchtoturnon
POWERbot.
2Manually charge
POWERbot by
placing it on the
docking station
Makesurechargepinsof
POWERbotandthedocking
stationisaligned.
3Check the
charging status
“”willturnon
accordingtocharging
progressand"FULL"will
turnonwhenchargingis
complete.
WARNING
• Ratedinputvoltageofthisproduct
is100-240V~.
SR9300K_EN_DJ68-00743E-00_EU.indd 10 2016-02-03 오후 8:23:54

ENGLISH-11
When the battery indicator blinks
during cleaning, POWERbot will
return to the docking station to
charge itself automatically.
Automatic charging
You may command POWERbot to
recharge at the docking station
while it is in cleaning process.
Recharging
Manually charge POWERbot by
placing it on the docking station.
Low battery (Lo)
Steps to take if recharging is not being executed
Check the installation status of the
docking station when:
fdockingstationislocatedinaplacewhere
POWERbotcannoteasilyaccess
fdistanceofthedockingstationandPOWERbotis
over5mapart
–ItmaytakealongtimeforPOWERbottoreturnto
thedockingstationforrecharging
Manually charge POWERbot when:
fdockingstationislocatedinacorner
fbatteryisfullyexhausted
fPOWERbotisstuckbyobstacles(furnitureetc.)
fPOWERbotcan'tclimbthresholdneardocking
station(HeightofthethresholdthatPOWERbotcan
climb:about2.0cmandbelow)
fBatteryindicatorblinksand"Lo"isdisplayed
fPOWERbotissetonSpotcleanorManualclean
mode
SR9300K_EN_DJ68-00743E-00_EU.indd 11 2016-02-03 오후 8:23:54

ENGLISH-12
Installing the Virtual guard
Infrared ray from the Virtual guard will restrict POWERbot from approaching certain
area.
Virtualguard
1Press the Power
button to turn it on
Powerlamp(Red)willblink.
2Install the Virtual guard
where you want to restrict
POWERbot's entrance
Makesurethatdistancesensorisfacing
atthedesireddirectionyouwantto
createainvisiblebarrier(whichwillrestrict
POWERbot'sapproach).
The distance of virtual wall is 2.5 m at minimum and may differ
depending on surroundings and movement status of POWERbot.
Minimum 2.5 m
SR9300K_EN_DJ68-00743E-00_EU.indd 12 2016-02-03 오후 8:23:54

ENGLISH-13
Part name of the Virtual guard
Power button
Distance detection sensor
(Infrared ray sensor)
Power lamp
Poweron:Redlampblinks
Poweroff:Lampisoff
POWERbot detection sensor
Battery cover
Inserting batteries
BatteriesforVirtualguardmustbepurchasedseparately.
1Open the battery cover
of the Virtual guard by
pressing the locking
tab and lift it up.
2Insert the alkaline
batteries (D type)
as shown in the
illustration (check the
+, - polarity).
3Insert the tip of the
cover into the slot and
push the other end to
close the battery cover.
 Specification:typeD(LR20)batteries
SR9300K_EN_DJ68-00743E-00_EU.indd 13 2016-02-03 오후 8:23:54

ENGLISH-14
Using POWERbot
You must turn on the emergency switch before using POWERbot.
Turning the power on/off
Press the button for more than
3 second
Using Auto clean mode
ThePOWERbotmovesandcleansautomatically
untilitcleansentirespaceonce.
 Stopcleaning:Pressthe button
Recharging
YoumaycommandPOWERbottorechargeatthe
dockingstationautomaticallywhileitisincleaning
process.
Using Spot clean mode
ThePOWERbotcleansalocalizedareaintensely.
WARNING
• WhenPOWERbotisnotusedfor
30minutes,itwillreturntothedocking
stationtochargeitselfautomatically.
Location recognizing function
fIfturningoffthePOWERbotandturningitback
on,thePOWERbotwillsearchthelocationthatit
stoppedpreviouslyandthencleantheareawhere
wasnotcleanedbefore.
–Whenthelocationrecognizingfunctionoperates,
thePOWERbotsearchesthecurrentlocation.
–Ifthesearchingisfailedmorethan3times,the
POWERbotwillstarttocleanfromthebeginning.
Note
fStartthecleaningagainattheareawithin1m
aroundwherethePOWERbotstopped.
–Ifyoustartthecleaningattheareamorethan
1mfromwherethePOWERbotstopped,
itisdifficulttosearchthelocationandthe
POWERbotmaycleantheareawhereitalready
cleaned.
SR9300K_EN_DJ68-00743E-00_EU.indd 14 2016-02-03 오후 8:23:55

ENGLISH-15
Cleaning mode How to select Displayed icon
Auto clean
Spot clean
 Spotcleanmodecanbeselectedonly
bypressingthisbuttononthemain
bodyofthePOWERbot.
Manual clean
 Manualcleanmodecanbeselected
bythedirectioncontrolbuttonsofthe
remotecontrol.
 Whencleaningisdonewithin15minutesinAutocleanmode,thePOWERbotwillrepeatcleaning
onemoretime.
 WhendustintakeisdetectedinSpot/Manualcleanmode,suctionofthePOWERbotwillbecome
stronger.
 IfthePOWERbotfailstoreturntothedockingstation,itwillbeturnedintotheenergy-savingmode.
Thenthedisplaypanelofthemainbodywillbeturnedoff.Press[Start/Stop]or[Power]buttonto
canceltheenergy-savingmode.
 Chargingandcleaningtimescandifferaccordingtoconditionsofuse.
Cleaning method for each modes
About1.5m
About1.5m
Auto clean
Cleansautomaticallyuntilentire
spaceiscleanedonce.
Spot clean
Cleansalocalizedarea
intensely.Itcanbeusedto
cleanbreadorcookiecrumbs.
Manual clean
YoucanmovePOWERbotwith
theremotecontroltocleanthe
desiredspot.
Selecting cleaning mode
SR9300K_EN_DJ68-00743E-00_EU.indd 15 2016-02-03 오후 8:23:55

ENGLISH-16
Using the remote control
1 Power / Recharging / Start/Stop
Power TurnPOWERbot'spoweron/off
Recharging SelecttorechargePOWERbotatthedockingstation
automatically
Start/Stop Selecttostartorstopcleaningprocess
2 Suction power
Max mode Selecttocleanwiththestrongestsuctionpower
Normal mode Selecttocleanwithmoderatesuctionpower
Quiet mode Selecttocleanwithloweroperationnoise
3 Additional function
Sound Eachtimeyoupressthisbutton,SoundEffectsMuteis
selectedinthissequence.
Smart control
Selecttoturnonoroffthesmartcontrol
 Press[Sound]buttonfor3seconds..
 Wi-Ficonnectionshouldbedonetocontrolthe
POWERbotusingSamsungSmartHomeapp.
 Thepreviouslyselectedsettingwillnotchangeeveniftheemergencyswitchisturnedoffandthenon.
Inserting batteries
Openthebatterycoverbyliftingitup
whilepressingthelockingtaband
insertthebatteriesasshowninthe
illustration.Then,closethecoveruntil
itclicksintoplace.
SR9300K_EN_DJ68-00743E-00_EU.indd 16 2016-02-03 오후 8:23:56

ENGLISH-17
You can use the remote control to point and clean
the desired spot while the POWERbot is in cleaning
process.
Point the red light on the floor within 1 m around POWERbot's
location.
PressandholdthePointcleaningbuttontomovetheredlightto
thedesiredspot.ThePOWERbotwillfollowthelightwhilecleaning.
1 m
 
Operating distance of the remote control
Heightoftheremote
control
Operatingdistance
Height of the remote
control 1m 1.5m
Operating distance About2m About2.5m
5 Point cleaning
4 Manual clean mode & Direction
control
Selecttomoveforward
Selecttoturnleft
Selecttoturnright
 Movingbackwardisnotavailable.
Referto
page19
1
1
2
4
3
5
SR9300K_EN_DJ68-00743E-00_EU.indd 17 2016-02-03 오후 8:23:56

ENGLISH-18
Name of each part
1
5
2
3
4
6
3
3
4
7
8
9
Top
1. Displaypanel
2. Dustbinholder
3. Remotecontrolsignalreceiver
4. Virtualguardsensor
5. Obstaclesensor
6. Dustbin
7. Camera
8. Dustbinhandle
9. Bumpersensor
1
4
2
6
5
5
4
7
4
8
9
3
Bottom
1. Chargepins
2. Petbrush
3. Petbrushcover
4. Cliffsensor
5. Roller
6. Batterycover
7. Petbrushcoverbutton
8. Drivingwheel
9. Emergencyswitch
13 149121110
6
16
17
3
4
5
8
1
7
2
15
Display panel
1. Mute
2. InformationIndicator
3. Filterinspection
4. SmartControlOff/Onindicator
5. Wi-Fi
6. Batteryindicator
7. One-time/Dailyschedule
8. Numberdisplay
9. Spotcleanmode
10. Manualcleanmode
11. Quietmode
12. Normalmode
13. Maxmode
14. Dustsensor
15. Spotcleaningbutton
16. Start/Stopbutton
17. Rechargingbutton
SR9300K_EN_DJ68-00743E-00_EU.indd 18 2016-02-03 오후 8:23:57

ENGLISH-19
Setting time/schedule
Only Auto clean mode can be scheduled.
Setting the time
YoumustsetthecurrenttimebeforeusingtheOne-time/dailyschedule.
Start setting Select "Hour" Select "Minute"
Select "AM/PM"Setting complete
Skip to previous, next setting
Setting the schedule
Setting/cancellingtheschedulecanonlybedonewhilePOWERbotisdockedonthedockingstation.
Start setting Select "One-time" or
"Daily" schedule
Select "Hour"
Select "Minute"Select "AM/PM"Setting complete
Skip to previous, next setting
Cancelling during setup fSettingwillbecanceledautomaticallywhenthere'snoinput
for7seconds
Cancelling One-time/Daily schedule
When both One-time/
Daily schedule is set or or
Pressfor3sec. Selecttheschedule Cancelcomplete
When either one of
One-time or Daily
schedule is set Pressfor3sec.
SR9300K_EN_DJ68-00743E-00_EU.indd 19 2016-02-03 오후 8:23:57

ENGLISH-20
Cleaning and maintaining
You must turn off the emergency switch before cleaning POWERbot.
Cleaning the dustbin
Cleanthedustbinwhenfilterinspectionindicator( )turnsonorifthere'stoomuchdustinthedustbin.
1Remove the dustbin 2Remove the dustbin
cover 3Remove dust in the dustbin and cyclone
unit
"Click"
4Detach the cyclone unit
from the dustbin cover
then wash the dustbin
and the filter
5Reassemble the
dustbin 6Reinsert the dustbin into the main body until
it clicks
Cleaning the sensors and the camera
Lightly wipe with soft cloth. Do not use water or cleaning solutions.
Camera
Frontsensor
window
Rearsensor
window
Cliffsensors
SR9300K_EN_DJ68-00743E-00_EU.indd 20 2016-02-03 오후 8:23:59
