Samsung VR9180 User manual

VIDEO CASSETTE RECORDER
Chassis : Scorpio
VR9180/9160/8160/5160
VR9180C/9160C/VR8170C/VR8160C/VR8140C
VR5160C/5140C
SERVICE
1. Precautions
2. Alignment and Adjustment
3. Exploded View and Parts List
4. Electrical Parts List
5. Schematic Diagrams
Manual
VIDEO CASSETTE RECORDER CONTENTS
For mechanical disassembly and adjustment, refer to the “Mechanical Manual” (TS-10 AC68-01405A).
VIDEO L AUDIO R
LINE IN
POWER EJECT
TV/VCR MENU
CHANNEL
TRACKING
REC
INPUT
TAPE SPEED
PLAY P/S STOP
J
O
G
/
S
H
U
T
T
L
E
VIDEO L AUDIO R
LINE IN
POWER EJECT
TV/VCR MENU
CHANNEL
TRACKING
REC
INPUT
TAPE SPEED
P/S STOP
REW F.F
VR9180/9180C
VR9160/9160C
EJECT POWER
VIDEO L AUDIO R
LINE IN 2
CHANNEL REC STOP
MENU
PLAY
REW F.F
VR8160/5160/8160C/5160C
VR8170C
VR8140C/5140C
POWER EJECT
POWER REC
REW
PLAY
F.F STO P
EJECT
POWER
CHANNEL REC STOP
MENU
REW PLAY F.F
LINE IN 2
VIDEO L AUDIO R
SERVICE MANUAL VR9180/9160/9180C/9160C/5160/5160C
ELECTRONICS
© Samsung Electronics Co., Ltd. FEB. 2001
Printed in Korea
AC68-01467A

IMPORTANT SERVICE GUIDE
♦MODE SWITCH (PROGRAM SWITCH) ASSEMBLY POINT
1) When installing the ass’y deck on the Main PCB, be sure to align the assembly point of mode switch.
ASSEMBLY POINT
(ALIGN TWO ARROWS)
Fig. 1
♦HOW TO EJECT THE CASSETTE TAPE
(If the unit does not operate on condition that tape is inserted into housing ass’y)
1) Turn the Gear Worm Œclockwise in the direction of arrow with screw driver. (See Fig. 2)
(Other method ; Remove the screw of Motor Load Ass’y, Separate the Motor Load Ass’y)
2) When Slider S, T are approached in the position of unloading, rotate holder Clutch counterclockwise after inserting screw driver in the
hole of frame’s bottom in order to wind the unwiunded tape. (Refer to Fig. 3)
(If you rotate Gear Worm Œcontinuously when tape is in state of unwinding, you may cause a tape contamination by grease and
tape damage. Be sure to wind the unwiunded tape in the state of set horizontally.)
3) Rotate Gear Worm ˇclockwise using screw driver again up to the state of eject mode and then pick out the tape. (Refer to Fig. 2)
Fig. 2 Fig. 3
ŒGEAR WORM
FRAME

Samsung Electronics 1-1
1. Precautions
1. Be sure that all of the built-in protective devices are
replaced. Restore any missing protective shields.
2. When reinstalling the chassis and its assemblies, be
sure to restore all protective devices, including :
control knobs and compartment covers.
3. Make sure that there are no cabinet openings
through which people--particularly children
--might insert fingers and contact dangerous
voltages. Such openings include the spacing
between the picture tube and the cabinet mask,
excessively wide cabinet ventilation slots, and
improperly fitted back covers.
If the measured resistance is less than 1.0 megohm
or greater than 5.2 megohms, an abnormality exists
that must be corrected before the unit is returned
to the customer.
4. Leakage Current Hot Check (See Fig. 1-1) :
Warning : Do not use an isolation transformer
during this test. Use a leakage current tester or a
metering system that complies with American
National Standards Institute (ANSI C101.1,
Leakage Current for Appliances), and Underwriters
Laboratories (UL Publication UL1410, 59.7).
5. With the unit completely reassembled, plug the AC
line cord directly the power outlet. With the unit’s
AC switch first in the ON position and then OFF,
measure the current between a known earth
ground (metal water pipe, conduit, etc.) and all
exposed metal parts, including : antennas, handle
brackets, metal cabinets, screwheads and control
shafts. The current measured should not exceed
0.5 milliamp. Reverse the power-plug prongs in the
AC outlet and repeat the test.
6. X-ray Limits :
The picture tube is designed to prohibit X-ray
emissions. To ensure continued X-ray protection,
replace the picture tube only with one that is the
same type as the original.
Fig. 1-1 AC Leakage Test
7. Antenna Cold Check :
With the unit’s AC plug disconnected from the
AC source, connect an electrical jumper across the
two AC prongs. Connect one lead of the ohmmeter
to an AC prong.
Connect the other lead to the coaxial connector.
8. High Voltage Limit :
High voltage must be measured each time
servicing is done on the B+, horizontal deflection
or high voltage circuits.
Heed the high voltage limits. These include the
X-ray protection Specifications Label, and the
Product Safety and X-ray Warning Note on the
service data schematic.
9. Some semiconductor (“solid state”) devices are
easily damaged by static electricity.
Such components are called Electrostatically
Sensitive Devices (ESDs); examples include
integrated circuits and some field-effect transistors.
The following techniques will reduce the
occurrence of component damage caused by static
electricity.
10. Immediately before handling any semiconductor
components or assemblies, drain the electrostatic
charge from your body by touching a known
earth ground. Alternatively, wear a discharging
Wrist-strap device. (Be sure to remove it prior to
applying power--this is an electric shock
precaution.)
DEVICE
UNDER
TEST
(READING SHOULD
NOT BE ABOVE
0.5mA)
LEAKAGE
CURRENT
TESTER
EARTH
GROUND
TEST ALL
EXPOSED METER
SURFACES
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
2-WIRE CORD

Precautions
1-2 Samsung Electronics
11. High voltage is maintained within specified limits
by close-tolerance, safety-related components and
adjustments. If the high voltage exceeds the
specified limits, check each of the special
components.
12. Design Alteration Warning :
Never alter or add to the mechanical or electrical
design of this unit. Example : Do not add
auxiliary audio or video connectors.
Such alterations might create a safety hazard.
Also, any design changes or additions will void
the manufacturer’s warranty.
13. Hot Chassis Warning :
Some TV receiver chassis are electrically
connected directly to one conductor of the AC
power cord. If an isolation transformer is not
used, these units may be safely serviced only if
the AC power plug is inserted so that the chassis
is connected to the ground side of the AC source.
To confirm that the AC power plug is inserted
correctly, do the following : Using an AC
voltmeter, measure the voltage between the
chassis and a known earth ground. If the reading
is greater than 1.0V, remove the AC power plug,
reverse its polarity and reinsert. Re-measure the
voltage between the chassis and ground.
14. Some TV chassis are designed to operate with 85
volts AC between chassis and ground, regardless
of the AC plug polarity. These units can be safely
serviced only if an isolation transformer inserted
between the receiver and the power source.
15. Never defeat any of the B+ voltage interlocks.
Do not apply AC power to the unit (or any of its
assemblies) unless all solid-state heat sinks are
correctly installed.
16. Always connect a test instrument’s ground lead to
the instrument chassis ground before connecting
the positive lead; always remove the instrument’s
ground lead last.
17. Observe the original lead dress, especially near
the following areas : Antenna wiring, sharp
edges, and especially the AC and high voltage
power supplies. Always inspect for pinched, out-
of-place, or frayed wiring. Do not change the
spacing between components and the printed
circuit board. Check the AC power cord for
damage. Make sure that leads and components
do not touch thermally hot parts.
18. Picture Tube Implosion Warning :
The picture tube in this receiver employs
“integral implosion” protection. To ensure
continued implosion protection, make sure that
the replacement picture tube is the same as the
original.
19. Do not remove, install or handle the picture tube
without first putting on shatterproof goggles
equipped with side shields. Never handle the
picture tube by its neck. Some “in-line” picture
tubes are equipped with a permanently attached
deflection yoke; do not try to remove such
“permanently attached” yokes from the picture
tube.
20. Product Safety Notice :
Some electrical and mechanical parts have special
safety-related characteristics which might not be
obvious from visual inspection. These safety
features and the protection they give might be
lost if the replacement component differs from the
original--even if the replacement is rated for
higher voltage, wattage, etc.
Components that are critical for safety are
indicated in the circuit diagram by shading,
( or ).
Use replacement components that have the same
ratings, especially for flame resistance and
dielectric strength specifications. A replacement
part that does not have the same safety
characteristics as the original might create shock,
fire or other hazards.

Samsung Electronics 2-1
2. Alignment and Adjustment
2-1 Reference
1) X-Point (Tracking center) adjustment, “Head switching adjustment” and “NVRAM option setting” can be adjusted with remote control.
2) When replacing the Micom (IC601) and NVRAM (IC603 ; EEPROM) be sure to adjust the “Head switching adjustment” and
“NVRAM option setting”.
3) When replacing the cylinder ass’y, be sure to adjust the “X-Point” and “Head switching adjustment”.
4) Among Samsung VCR remote control used for adjustment as a accessory, only the remote control that has figures buttons (0 ~ 9) is
available for all adjustment regardless of chassis.
5) How to adjustment.
- Momently short-circuit the test point on Main PCB with pincers to set the adjustment mode.
- If the corresponding adjustment button is pressed, the adjustment is performed automatically.
- If the adjustment is completed, be sure to turn the power off.
2-1-1 Location of adjustment button of remote control
Fig. 2-1
SHUTTLE
V-LOCK
REPLAY F.ADV/SKIP
TV/VCR PREV.CH
R
E
C
R
E
C
.
S
P
E
E
D
L
I
N
E
I
N
A
U
D
I
O
S
E
A
R
C
H
/
E
X
I
T
C
L
E
A
R
D
I
S
P
L
A
Y
POWER EJECT
CH/TRK
VCR
TV
A.TRK
ENTER
MENU
SLOW
VOL
100
Remote Control for adjustment is not supplied as a Service Jig.
VCR POWER TV POWER
EJECT TV/VCR
SLOW
A.TRK
100
TV VCR TRACKING
SELECT
AUDIO
VOL CH
PREV.CH
DISPLAY
SEARCH/EXIT
REC P/STILL
MENU
REC.SPEED LINE IN CLEAR F.ADV
REPLAY 30S-SKIP
REV
FWD
X-Point (Tracking Center)
Adjustment
Head Switching Adjustment
NVRAM Option Setting

2-2
Alignment and Adjustment
Samsung Electronics
2-1-2 Test point location for adjustment mode setting
Fig. 2-2 Main PCB (Top View)
Short-Circuit for a second and release.
Application Models ; VR9180/9160/9180C/9160C/8160/5160/8170C/8160C/5160C

Alignment and Adjustment
2-3
Samsung Electronics
Fig. 2-3 Main PCB (Top View)
Short-Circuit for a second and release.
Application Models ; VR8140C/5140C

2-4
Alignment and Adjustment
Samsung Electronics
2-2 Mechanical Adjustment
Note : Refer to the Mechanical Manual “TS-10 (AC68-01405A)” for the adjustment and confirmation of ass’y deck.
2-2-1 The number and position of test point
Test point : TP601 (Control Pulse)
TP602 (H’D S/W -Trigger)
TP301 (Envelope)
TP302 (Audio output)
TP303 (Video output)
Fig. 2-4 Location of Test point (Main PCB-Top View)
AUDIO OUTPUT
HEAD SWITCHING
ENVELOPE
2-2-2 ACE Head Position (X-Point) Adjustment
(See the 2-2-1(d) ACE Head Position (X-Point) Adjustment
on page 2-2 of the Mechanical Manual)
1) Playback the alignment tape (Color bar).
2) Momently short-circuit the test point on Main
PCB with pincers to set the adjustment mode.
(See Fig. 2-2 and 2-3)
3) Press the “5” button of remote control then adjust-
ment is operated automatically. (See Fig. 2-1)
4) Connect the CH-1 probe to TP301 (Envelope) the
CH-2 probe to TP602 (H’D switching pulse) and
then trigger to CH-1.
5) Insert the (-) driver into the X-Point adjustment
hole and adjust it so that envelope waveform is
maximum.
6) Turn the Power off.

Alignment and Adjustment
2-5
Samsung Electronics
2-3 Head Switching Point Adjustment
1) Playback the alignment tape.
2) Momently short-circuit the test point on Main PCB with pincers to set the adjustment mode.
(See Fig. 2-2 and 2-3)
3) Press the “REC.SPEED” button of remote control then adjustment is operated automatically. (See Fig. 2-1)
4) Turn the Power off.
2-4 NVRAM Option Setting
1) Momently short-circuit the test point on Main PCB with pincers to set the adjustment mode.
(See Fig. 2-2 and 2-3)
2) Press the “MENU” button on the remote control about 5 seconds then option setting display is appeared.
(See Fig. 2-5)
3) Select the option number (See Table 2-1) of corresponding model with “FF” and “REW” button on the
remote control.
4) If selecting the option number is completed, press the “STOP” button of remote control.
(If “STOP” button is pressed, the selected number is changes reversed color. ; See Fig. 2-5)
5) Press the “MENU” button of remote control again to store the option number.
(“COMPLETE” is displayed for a second as shown Fig. 2-6 and the setting is completed.)
6) Turn the Power off.
1) NVRAM Option is adjusted at production line basically.
2) In case Micom (IC601) and NVRAM (IC603 ; EEPROM) is replaced, be sure to set the corresponding option number of the repaired
model. (If the option is not set, the unit is not operated.)
MOVE : SAVE : MENU
01 02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32
33 34 35 36 37 38 39 40
Fig. 2-5
MOVE : COMPLETE
01 02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32
33 34 35 36 37 38 39 40
Fig. 2-6
<Table 2-1>
MODELS OPTION NUMBER
VR9180 2, 4, 5, 6, 7, 10, 13, 14, 15, 24, 31, 32, 34, 37
VR9160 2, 4, 5, 6, 7, 10, 13, 15, 18, 31, 32, 34, 37
VR8160 2, 4, 5, 6, 7, 10, 15, 18, 25, 31, 34, 37
VR5160 4, 5, 6, 7, 15, 18, 25, 31, 34, 37
VR9180C 2, 4, 5, 6, 7, 10, 13, 14, 15, 24, 31, 32, 34, 37
VR9160C 2, 4, 5, 6, 7, 10, 13, 15, 18, 31, 32, 34, 37
VR8170C 2, 4, 5, 6, 7, 10, 15, 18, 25, 31, 34, 37
VR8160C 2, 4, 6, 7, 10, 15, 18, 25, 31, 34, 37
VR8140C 2, 4, 6, 7, 10, 12, 15, 20, 28, 30, 31, 37
VR5160C 4, 6, 7, 15, 18, 25, 31, 34, 37
VR5140C 4, 6, 7, 12, 15, 20, 28, 30, 31, 37

2-6
Alignment and Adjustment
Samsung Electronics
MEMO

Samsung Electronics 3-1
3. Exploded View and Parts List
3-1 Cabinet Assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
3-2 Mechanical Parts (Top Side) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
3-3 Mechanical Parts (Bottom Side) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Page
3-2
3-4
3-6

Exploded View and Parts List
3-2 Samsung Electronics
3-1 Cabinet Assembly
S.N.A : Service Not Available
FULL DECK (S.N.A)
BRACKET-FRAME
(S.N.A)
BOTTOM-COVER (S.N.A)
MAIN-PCB (S.N.A)
153
157
101
155
TM401B
CN605B
CN303B
200
S602A
S601A
LD601A
21 21
22 22
1 1
ASSY-PANEL FRONT
VR9180/9180C
VR8170C VR8140C/5140CVR8160/5160/8160C/5160C
VR9160/9160C
REMOTE-CONTROL
VR9180/9180C
VR9160/8160/5160/9160C/8170C/8160C/5160C
VR8410C/5410C
SHUTTLE
V-LOCK
REPLAY F.ADV/SKIP
TV/VCR PREV.CH
R
E
C
R
E
C
.
S
P
E
E
D
L
I
N
E
I
N
A
U
D
I
O
S
E
A
R
C
H
/
E
X
I
T
C
L
E
A
R
D
I
S
P
L
A
Y
POWER EJECT
CH/TRK
VCR
TV
A.TRK
ENTER
MENU
SLOW
VOL
100
VCR POWER TVPOWER
EJECT TV/VCR
SLOW
A.TRK
100
TV VCR TRACKING
SELECT
AUDIO
VOL CH
PREV.CH
DISPLAY SEARCH/EXIT
REC P/STILL
MENU
REC.SPEED LINEIN CLEAR F.ADV
REPLAY 30S-SKIP
REV
FWD
FUNCTION PCB (S.N.A)
FUNCTION PCB
(S.N.A)
21
22
1
11
21 21
22 22
51
52

Exploded View and Parts List
Samsung Electronics 3-3
Loc. No Parts No. Description ; Specification Remark
1 Refer to table below ASSY-PANEL FRONT;HIPS94V2,VR9180,BLK
21 Refer to table below DOOR-CASSETTE;VR9180,ABS94HBBLK,-,-,-,-,
22 AC61-62032A SPRING-MASK;X-9,-,SUS,-,4.4,-,SV-C130
51 AC64-00616A KNOB-JOG;01T,ABS,-,-,-,- VR9180/9180C ONLY
52 AC64-00617A KNOB-SHUTTLE;01T,ABS,-,-,-,-,-,- VR9180/9180C ONLY
101 Refer to table below CABINET TOP;VR9160,-,PCM(SECC),-,TM6524
153 AC60-12126A SCREW-BH;-,BH,-,4*12,FE,FZY,-,-,-
155 AC60-12134A SCREW-TAP BH;-,BH,-,2-4X16,-,FE
157 AC60-10063A SCREW-TAPTITE;BH,+,-,M3,L12,ZPC3,SWRCH18
200 AC39-10200N POWER-CORD;EP2,SPT-2,AWG#18,1.8MT,WAFER,
CN303B 3809-001206 CABLE-FLAT;30V,-20to+80C,140mm,6P,1.25mm
CN605B 3809-001131 CABLE-FLAT;30V,80C,110MM,7P,1.25MM,UL289
LD601A AC61-21009A HOLDER-LED;-,POM(M90-44),-,BLK,-,X-9
S601A AC61-21008A HOLDER-SENSOR;-,POM(M90-44),-,BLK,-,X-9
S602A AC61-21008A HOLDER-SENSOR;-,POM(M90-44),-,BLK,-,X-9
TM401B Refer to table below CONNECTOR-BOARD-ASSY;-,HIPS,-,T2,61,-,BL
UT01 Refer to table below REMOCON-ASSY
MODELS 1 21 101 TM401B UT01
VR9180 AC97-01273B AC64-00606C AC64-00124D AC61-00058A AC59-00025C
VR9160 AC97-01273A AC64-00606A AC64-00124D AC61-00058A AC59-00024D
VR8160 AC97-01287A AC64-00636A AC64-00293A AC61-00058A AC59-00024C
VR5160 AC97-01287B AC64-00636B AC64-00293A AC61-11054A AC59-00024C
VR9180C AC97-01237E AC64-00606E AC64-00124B AC61-00058A AC59-00025D
VR9160C AC97-01273F AC64-00606F AC64-00124D AC61-00058A AC59-00024D
VR8170C AC97-01278A AC64-00637A AC64-00293A AC61-00058A AC59-00024D
VR8160C AC97-01287C AC64-00636C AC64-00293A AC61-00058A AC59-00024C
VR8140C AC97-01245F AC64-00535F AC64-00292A AC61-00002A AC59-10420H
VR5160C AC97-01287D AC64-00636N AC64-00293A AC61-11054A AC59-00024C
VR5140C AC97-01245G AC64-00535G AC64-00292A AC61-00050A AC59-10420H

Exploded View and Parts List
3-4 Samsung Electronics
3-2 Mechanical Parts (Top Side)
G001
G555
G510
G480 K546
G680
G681
B410
B575
B440
B448
B452
G546
G060
G520
G527
K188
K182
K110
K240
K248
K350
K330
K140
K340
G070
K470
B474
B473
K250
K530
K490
G530
G420
G450
K502
(OPTIONAL)
(OPTIONAL)

Exploded View and Parts List
Samsung Electronics 3-5
Loc. No Parts No. Description ; Specification Remark
B410 AC31-00012A MOTOR-LOADING ASSY;-,TS-10,-,-,-,-,-,-,-
B440 AC60-10515A SCREW-MACHINE;-,PH,+,-,M3,L3,ZPC,-,YEL
B448 AC66-00008A GEAR-WORM WHEEL;TS-10,POM,0.8,40,-,NAT,3
B452 AC66-00011A GEAR-FL CAM;TS-10,POM,0.8,59,-,BLK,48.48
B473 AC61-00105A SPRING-PINCH DRIVE;TS-10,SUS304-WPB,-,-,
B474 AC61-30180A PLATE-JOINT;-,SECC20/20,T0.8,-,X-9
B575 AC47-00002A DAMPER-CAPSTAN;TS-10,POM,-,-,BLACK
G001 AC97-01204A ASSY-CYLINDER;NTSC,CTS10,6HD-JUST HI-FI MODEL
AC97-01202A ASSY-CYLINDER;NTSC,CTS10,4HD-JUST MONO MODEL
G060 6006-001092 SCREW-ASS’Y MACH;WS,PH,+,M3.0,L6.0,ZPC(Y
G070 AC61-00161A PLATE-GROUND DECK;TS-10,SPTE,T0.3,-
G420 AC66-80142A SLIDER-SUPPLY ASSY;-,X-9(TS),-,-,-,X-9
G450 AC66-80141A SLIDER-TAKE UP ASSY;-,X-9(TS),-,-,-,X-9
G480 AC33-00009A HEAD-ACE ASS’Y;-,PPS,TS-10,-,-
G510 6006-001075 SCREW-ASS’Y TAPT;WSP,PH,+,M2.6,L5.0,ZPC(
G520 AC66-00033A LEVER-#9 GUIDE ASS’Y;TS-10,-,-,-,-,-,-,-
G527 AC61-60553A SPRING-#9 GUIDE;-,ES,SUS304-WPB,OD3.1,0.
G530 AC33-00007A HEAD-FE;-,-,HVFHPOO43A,-,-
G546 AC66-00005A LEVER-FL DOOR;TS-10,POM,-,-,-,-,NAT,-
G555 AC66-00032A LEVER-UNIT PINCH ASS’Y;TS-10,-,-,-,-,-,-
G680 AC66-00046A LEVER-HEAD CLEANER ASS’Y;TS-10,POM+URETH (OPTIONAL)
G681 AC61-50686A SLEEVE-HEAD CLEANER;-,POM,-,-,-,-,-,-,TS (OPTIONAL)
K110 AC66-10267A REEL-DISK S;X-9,POM,-,-,-,-,-,-
K140 AC66-10268A REEL-DISK T;X-9,POM,-,-,-,-,-,-
K182 AC66-30524A LEVER-IDLER;-,POM,-,-,-,-,-,-
K188 AC66-00039A GEAR-IDLE;TS-10,PET K3372,0.5,-,-,NTR,28
K240 AC66-00035A LEVER-TENSION ASS’Y;TS-10,SECC E20/20+SU
K248 AC61-00107A SPRING-TENSION LEVER;TS-10,SUS304-WPB,-,
K250 AC69-00104A BAND-BRAKE ASS’Y;TS-10,-,-,-,-,-,-
K330 AC66-30550A LEVER-S.BRAKE ASSY;-,POM+SUS,-,-,-,X-9
K340 AC66-30549A LEVER-T.BRAKE ASSY;-,POM+SUS,-,-,-,X-9
K350 AC61-00106A SPRING-BRAKE;TS-10,SUS304-WPB,-,-,-,-,-,
K470 AC66-00020A SLIDER-FL DRIVE;TS-10,SECC E20/20,1.0,-,
K490 AC61-00120A HOLDER-FL CASS. ASS’Y;TS-10,-,-,-,-,-
K502 AC61-60561A SPRING-FL.LEVER-LR;-,ES,SUS304 WPB,PI2.7
K530 AC66-00034A LEVER-FL ARM ASS’Y;TS-10,-,-,-,-,-,-,-
K546 AC61-50658A GUIDE-CASS. DOOR;X-9,POM,-,NTR,-,-

Exploded View and Parts List
3-6 Samsung Electronics
3-3 Mechanical Parts (Bottom Side)
G542
B462
B560
B501
B484
B488
B500
B456
B458
B464
B468
K222
K200
K225
K221
B478
B570
B460
B489

Exploded View and Parts List
Samsung Electronics 3-7
Loc. No Parts No. Description ; Specification Remark
B456 AC66-00009A GEAR-JOINT 1;TS-10,POM,1.5,17.5(22),-,NA
B458 AC66-00012A GEAR-JOINT 2;TS-10,POM,1.0,23,-,BLK,24.6
B460 AC61-00090A BRACKET-GEAR;TS-10,0.8,-,-
B462 AC60-10517A SCREW-TAP TITE;-,PH,+,-,M2.6,L5,ZPC,-,YE
B464 AC66-00019A SLIDER-CAM;TS-10,SECC E20/20,1.2,-,-,-,-
B468 AC66-00017A LEVER-PINCH DRIVE;TS-10,SECC E20/20,1.0
B478 AC66-00016A LEVER-TENSION DRIVE;TS-10,SECC E20/20,1
B484 AC66-00030A GEAR-LOADING DR. ASS’Y;TS-10,POM+SWPB,-,
B488 AC66-00023A LEVER-S LOADING;TS-10,POM,-,-,-,-,NAT,-
B489 AC66-00021A LINK-LOADING S;TS-10,SECC E20/20,0.8,-,-
B500 AC66-00024A LEVER-T LOADING;TS-10,POM,-,-,-,-,NAT,-
B501 AC66-00022A LINK-LOADING T;TS-10,SECC E20/20,0.8,-,-
B560 AC31-00010A MOTOR-CAPSTAN;-,SANKYO,-,-
B570 AC60-10514A SCREW-CAPSTAN;-,PH,+,M2.6,L6,-
G542 AC66-60051A BELT-PULLEY;-,5CM-70,2 * 2,-,71.3,-,X-9
K200 AC61-21012A HOLDER-CLUTCH ASSY;-,-,-,-,-,X-9
K221 AC66-20581A GEAR-CENTER ASSY;-,POM,M=O.5,-,HIGHT T.,
K222 AC60-30306A WASHER-SLIT;-,-,ID2.1,OD5.0,T0.5,-,POLYS
K225 AC66-00006A LEVER-UP DOWN;TS-10,POM,-,-,-,-,NAT,-

Exploded View and Parts List
3-8 Samsung Electronics
MEMO

Loc.No Part No Description ; Specification Remark Loc.No Part No Description ; Specification Remark
Samsung Electronics 4-1
- - ASSY PCB-MAIN S.N.A.
S.M.P.S. PARTS
BD1SR1 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
BD1SS1 AC27-92001M INDUCTOR;70UH-M RT BFS3565R2F,-,-,-,-
BD1SS2 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
C1SD01 2201-000828 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,15x
C1SD05 2201-000930 C-CERAMIC,DISC;0.22nF,10%,500V,Y5P,TP,5.
C1SD06 2301-000423 C-FILM,PEF;3.3nF,5%,100V,TP,7x10x4.5mm,5
C1SR01 2401-001681 C-AL;82uF,20%,200V,GP,TP,16x26,7.5m
C1SR02 2401-000905 C-AL;22uF,20%,16V,BP,-,6x11,2.5mm
C1SR03 2401-001235 C-AL;4.7uF,20%,250V,WT,TP,10x12.5,5
C1SR04 2301-000417 C-FILM,PEF;24nF,5%,50V,TP,6.5x10.5x4mm,5
C1SR05 2301-000180 C-FILM,PEF;18nF,0.05,100V,TP,7.2x4.5x8.0
C1SR07 2305-001021 C-FILM,MPEF;100nF,20%,275V,TP,17.5x7x13.
C1SS01 2401-003137 C-AL;330UF,20%,50V,WT,TP,10X16MM,5
C1SS03 2201-000812 C-CERAMIC,DISC;2.2nF,20%,400V,Y5U,BK,12.
C1SS04 2201-000916 C-CERAMIC,DISC;100pF,10%,400V,Y5U,TP,10x
C1SS06 2401-000385 C-AL;10uF,20%,100V,GP,TP,6.3x11,5
C1SS07 2401-002162 C-AL;1000uF,20%,25V,WT,TP,10x20,5mm
C1SS08 2401-001126 C-AL;330uF,20%,25V,WT,TP,10x12.5,5
C1SS10 2401-001479 C-AL;470uF,20%,10V,GP,TP,-,-
C1SS11 2301-000129 C-FILM,PEF;100nF,5%,50V,TP,10X9X4.3X5,5m
C1SS35 2401-003059 C-AL;1000UF,20%,16V,WT,TP,10X16,5
CN1SS1 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
D1SD01 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D1SD02 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D1SR01 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D1SR02 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D1SS01 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS02 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS03 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS04 0402-001196 DIODE-RECTIFIER;1T5,600V,1A,TS-1,TP
D1SS05 0402-000012 DIODE-RECTIFIER;UF4007,1KV,1A,DO-41,TP
D1SS06 0402-001194 DIODE-RECTIFIER;UG2D,200V,2A,DO-204AC,TP
D1SS07 0402-000431 DIODE-RECTIFIER;FML-M02S,200V,2.5A,TO-22 HIFI ONLY
D1SS08 0402-001195 DIODE-RECTIFIER;F1T4,400V,1.0A,TS-1,TP
F1SD01 3601-001122 FUSE-CARTRIDGE;250V,1.6A,FAST-ACTING,GLA
IC1SS1 0604-001028 PHOTO-COUPLER;TR,50-600%,250mW,DIP-4,ST
IC1SS2 AC14-12006D IC;KA431Z,TO-92,TAPING
L1SS01 AC29-00003A FILTER LINE NOISE;-,20mH MIN,-,-,-
L1SS02 AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,-
L1SS03 AC27-12001N COIL-CHOKE;10UH-15%,RA,K-30,Q80,150KHZ,-
PT1SD1 AC26-00002B TRANS SWITCHING;-,-,EE2621,-,UL/CSA/DEMK
Q1SR01 0501-000442 TR-SMALL SIGNAL;KTC3203-Y,NPN,400MW,T0-9
Q1SR02 0502-001123 TR-POWER;KTC4419,NPN,30W,TO-220,ST,10-4
R1SD01 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SD02 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SD03 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SR01 2002-000320 R-COMPOSITION;1.8Mohm,10%,1/2W,AA,TP,3.5
R1SR02 2003-002117 R-METAL OXIDE(S);330Kohm,5%,1W,AA,TP,3.3
R1SR03 2003-000314 R-METAL OXIDE;47ohm,5%,2W,AE,TP,6x16mm
R1SR04 2003-000314 R-METAL OXIDE;47ohm,5%,2W,AE,TP,6x16mm
R1SR05 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R1SR06 2003-000119 R-METAL OXIDE;0.68ohm,5%,2W,AE,TP,6x16mm
R1SR07 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1SS01 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x
R1SS02 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x
R1SS04 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R1SS05 2004-000869 R-METAL;3Kohm,1%,1/8W,AA,TP,1.8x3.2mm HIFI ONLY
R1SS06 2004-000459 R-METAL;2.2Kohm,1%,1/8W,AA,TP,1.8x3.2m
VA1SS1 1405-001026 VARISTOR;470V,600A,9x7mm,TP
ZD1SR1 0403-000571 DIODE-ZENER;UZP43B,43V,40-46V,1W,DO-41,T
POWER PARTS
C1P101 2401-001730 C-AL;10uF,20%,50V,GP,TP,5x11,2.5
C1P103 2401-001254 C-AL;4.7uF,20%,35V,GP,TP,4x7,5
C1P104 2401-001254 C-AL;4.7uF,20%,35V,GP,TP,4x7,5
C1P105 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C1P106 2401-002008 C-AL;100uF,20%,16V,GP,TP,6.3x11,2.5 HIFI ONLY
C1P108 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5 MONO ONLY
C1P112 2401-001254 C-AL;4.7uF,20%,35V,GP,TP,4x7,5 HIFI ONLY
D1P101 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP MONO ONLY
D1P102 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D1P106 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D1P108 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, HIFI ONLY
D1P109 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
L1P101 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm
Q1P101 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
Q1P102 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
Q1P104 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T HIFI ONLY
Q1P107 0501-000616 TR-SMALL SIGNAL;KSC2328A-Y,NPN,1W,TO-92L
Q1P108 0504-000142 TR-DIGITAL;KSR2001,PNP,300MW,4.7K/4.7K,T
Q1P109 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
R1P101 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
R1P102 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
R1P103 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM HIFI ONLY
R1P104 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM HIFI ONLY
R1P104 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3.2MM MONO ONLY
R1P105 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM MONO ONLY
R1P110 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
ZD1P01 0403-000390 DIODE-ZENER;UZP33B,33V,31.4-34.6V,1W,DO-
ZD1P02 0403-000717 DIODE-ZENER;MTZJ5.1B,5.1V,4.94-5.2V,500m
ZD1P03 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500
ZD1P05 0403-001211 DIODE-ZENER;MTZJ12B,11.44-12.03V,500MW,D
LOGIC PARTS
C601 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C602 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C603 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C604 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C605 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11.5,5
C606 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C607 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C608 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C609 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
C610 2203-000989 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
C612 2203-000361 C-CERAMIC,CHIP;0.15nF,5%,50V,NP0,TP,2012
C613 2401-001545 C-AL;47uF,20%,25V,GP,TP,6.3x7mm,2.5
C615 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C616 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C617 2401-002095 C-AL;47uF,20%,25V,GP,TP,6.3x5,5
C618 2203-000634 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,201
C619 2203-000683 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,201
C620 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
C622 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
4. Electrical Parts List
4-1 VR9180/9160/8160/5160/9180C/9160C/8170C/8160C/5160C Only

Loc.No Part No Description ; Specification RemarkLoc.No Part No Description ; Specification Remark
4-2 Samsung Electronics
Electrical Parts List
C623 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C624 2401-002165 C-AL;100uF,20%,16V,GP,TP,6.3x7,5
C625 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C626 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C627 2203-001245 C-CERAMIC,CHIP;0.082nF,5%,50V,NP0,TP,201
C628 2401-002068 C-AL;33uF,20%,16V,GP,TP,5x11,5
C629 2203-001579 C-CERAMIC,CHIP;15nF,10%,50V,NP0,TP,2012
C630 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C631 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C632 2203-001077 C-CERAMIC,CHIP;0.056nF,5%,50V,NP0,TP,201
C633 2203-000716 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,TP,2012
C634 2203-001077 C-CERAMIC,CHIP;0.056nF,5%,50V,NP0,TP,201
C635 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C636 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C637 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
C638 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
C639 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
C640 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C643 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C644 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C646 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C647 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C648 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C649 2203-000444 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,-
C650 2203-000727 C-CERAMIC,CHIP;3.9nF,10%,50V,X7R,TP,2012
C651 2203-000727 C-CERAMIC,CHIP;3.9nF,10%,50V,X7R,TP,2012
C652 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C653 2203-000575 C-CERAMIC,CHIP;220NF,10%,25V,X7R,TP,2012
C655 2202-000797 C-CERAMIC,MLC-AXIAL;10NF,30%,16V,Y5S,TP,
C656 2203-000844 C-CERAMIC,CHIP;39nF,10%,50V,X7R,TP,2012,
CN601 AC39-20817S LEAD CONNECTOR-ASSY;DP,SMH200-02,YBH200-
CN604 3711-003749 CONNECTOR-HEADER;BOX,8P,2R,2mm,STRAIGHT,
CN605 3708-001302 CONNECTOR-FPC/FC/PIC;7P,1.25mm,STRAIGHT,
D601 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D603 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D604 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D605 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
D606 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
D607 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
IC601 AC09-00197A IC MICOM;MN101D02D-CP1,VR8170,100P,5V,1
IC602 1003-001318 IC-MOTOR DRIVER;LB11880,DIP,30P,417MIL,-
IC603 1103-001148 IC-EEPROM;24C021,2KBIT,DIP,8P,300MIL,10M
IC6B1 AC14-12006C IC;KA7533,DIP,-
L601 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
L602 2701-000002 INDUCTOR-AXIAL;100uH,10%,4.2x9.8mm
L802 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,
LD601 0601-000517 LED-IR;RECTANGULA,4x6.0mm,75mW,6V,950
PT601 0604-001122 PHOTO-INTERRUPTER;TR,0.065%,150mW,DIP-4,
PT602 0604-001122 PHOTO-INTERRUPTER;TR,0.065%,150mW,DIP-4,
R601 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
R602 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
R603 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
R604 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
R605 2001-000111 R-CARBON;150OHM,5%,1/4W,AA,TP,2.4X6.4MM
R606 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R607 2007-000738 R-CHIP;30KOHM,5%,1/10W,DA,TP,2012
R608 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R610 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R613 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R614 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R615 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
R616 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R617 2007-000221 R-CHIP;1.2KOHM,5%,1/10W,DA,TP,2012
R618 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R619 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R620 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R621 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012
R622 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012
R623 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R624 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R630 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R631 2001-000864 R-CARBON;56KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R632 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R634 2007-000068 R-CHIP;470KOHM,5%,1/10W,DA,TP,2012
R635 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R637 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R638 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
R639 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
R641 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R642 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R643 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R644 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R645 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R646 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
R647 2007-000766 R-CHIP;330OHM,5%,1/10W,DA,TP,2012
R648 2007-000766 R-CHIP;330OHM,5%,1/10W,DA,TP,2012
R649 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
R650 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
R651 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
R652 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R653 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R656 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R660 2007-000001 R-CHIP;68KOHM,5%,1/10W,DA,TP,2012
R664 2007-000703 R-CHIP;3.6KOHM,5%,1/10W,DA,TP,2012
R665 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
R668 2003-000111 R-METAL OXIDE;0.47ohm,5%,1W,AD,TP,4.3x12
R669 2007-001024 R-CHIP;560KOHM,5%,1/10W,DA,TP,2012
R690 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R691 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R692 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R6A01 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
F-A/V(AUTO) ONLY
R6F2 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM HIFI ONY
R6F3 2007-001141 R-CHIP;7.5KOHM,5%,1/10W,DA,TP,2012 HIFI ONY
R6F4 2007-001141 R-CHIP;7.5KOHM,5%,1/10W,DA,TP,2012 HIFI ONY
R6JS01 2007-000546 R-CHIP;20KOHM,5%,1/10W,DA,TP,2012 VR9180/9180C ONLY
R6JS02 2007-000546 R-CHIP;20KOHM,5%,1/10W,DA,TP,2012 VR9180/9180C ONLY
R6JS03 2007-000546 R-CHIP;20KOHM,5%,1/10W,DA,TP,2012 VR9180/9180C ONLY
R6JS04 2007-000546 R-CHIP;20KOHM,5%,1/10W,DA,TP,2012 VR9180/9180C ONLY
R6JS07 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
VR9180/9180C ONLY
R6JS08 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M VR9180/9180C ONLY
R6JS09 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM VR9180/9180C ONLY
R6JS10 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM VR9180/9180C ONLY
S601 0603-001011 PHOTO-TR;NPN,35V,6V,50mA,75mW,BK
S602 0603-001011 PHOTO-TR;NPN,35V,6V,50mA,75mW,BK
SW602 AC34-20100B SWITCH-REC;-,-,X-9,-
SW603 AC34-20100A SWITCH-MODE;-,-,X-9,-
XT601 2801-001384 CRYSTAL-UNIT;14.31818MHz,30ppm,28-AAA,16
AUDIO/VIDEO PARTS
C301 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C302 2203-001721 C-CERAMIC,CHIP;360pF,5%,50V,NPO,TP,2012,
C303 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP, SQPB ONLY
C304 2202-000164 C-CERAMIC,MLC-AXIAL;0.18nF,10%,50V,Y5P,T
C305 2401-000598 C-AL;1uF,20%,50V,GP,TP,4x7,5
C306 2203-000192 C-CERAMIC,CHIP;100nF,+80-20%,50V,Y5V,TP,
C307 2401-003107 C-AL;47uF,20%,16V,GP,TP,5x7,5
C308 2401-000918 C-AL;22uF,20%,16V,GP,-,6.3x7,5
C309 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5
C310 2401-001915 C-AL;1uF,20%,50V,GP,TP,3x5,5
C311 2401-000414 C-AL;10uF,20%,16V,GP,TP,4x7,5 F-A/V ONLY
C312 2202-002037 C-CERAMIC,MLC-AXIAL;100nF,80-20%,50V,Y5V
