SINGLE
Technical
Data Book
Wind-Free 4Way Cassette for Europe
(R410A, HP)
Model : AC∗∗∗MN∗∗KH/EU (Indoor Unit), AC∗∗∗MXAD∗H/EU (Outdoor Unit)

2
History
Version Modification Date Remark
Ver.1.0 Released CAC Wind-Free 4Way Cassette for Europe (R410A, HP) ''17. 12. 14

3
CAC - World-class energy efficiency
Maintain optimal comfort and control with energy and
cost-efficient technologies
Featuring a suite of energy-optimizing technologies, Samsung
CAC Single delivers top-class energy efficiency to support
business in saving costs and the environment. Plus, CAC Single
with its smart technologies fully complies with new European
Union (EU) regulations for more efficient performance.
Small package, big performance
The Samsung Ceiling Type air conditioner boasts a slim,
compact design—half the size of conventional products—
with cooling power comparable to larger units.
as per EU Directive 2011/626/EU
Quick, efficient heating and cooling
Smart inverter technology offers powerful, quick cooling
and heating with minimal electricity consumption, which
means real cost savings and less energy waste. The EU has
established new regulations to drastically cut the power
consumption of air conditioners. Inefficient units will be
gradually withdrawn from the market starting in 2013.
To further support this initiative, the EU is introducing an
improved energy labeling system to provide consumers a
better idea of how much electricity their units consume.
Up to 50 percent less energy use
After reaching changes its operation mode to economical.
By avoiding inefficient and frequent switching on and off of
the compressor, the digital inverter saves up to 50 percent in
energy consumption compared to non-inverter air conditioners.
200
300
400
500
600
(Wh/h)
Saving
302Wh/h
621.4
Wh/h
Non-inverter
Wind-Free Cooling with Micro holes
•The Wind-Free Air conditioner pushes air out
through 13,000 micro holes in the panel, producing
a dispersed and gentle flow of air actually defined as
“still air” and the key here is all of those holes create
a still, cooled air flow that infiltrates the room gently
and softly.
※ Still Air condition : According to ASHRAE, If velocity
of wind is lower than 0.15m/s, People can not detect
wind. And they define that condition is “Still Air”
※Wind-Free 4Way(600x600) : 9,000 Micro Holes
15,000 Micro Holes
[ Comparision of Room Temp.]
ASHRAE Comfort Zone(23℃~26℃)
Normal
Cooling
Set Off
Wind -Free Cooling
20
34
32
30
28
26
24
22
0 20 4060 80 100 120 140 160
Room Temp.(℃)
Time (Min)
“ Maintain comfort condtion
with Wind-Free cooling ”
※ Interanal Test (14.0kW Model @ 122㎡)
Features & Benefits

4
Features & Benefits
CAC Single - Superior performance
Stabilize the atmosphere with broad temperature
allowance and control
Samsung is dedicated to supporting comfortable living
and working environments based on the strength of
its technologies. With a single unit, CAC Single delivers
reliable comfort and control over multiple areas to ensure
a pleasant atmosphere in any climate.
Wide temperature performance
No matter how extreme the temperature, the high-
performing CAC Single can handle the condition-
without the need for an additional unit. Featuring a wide
temperature allowance, it can cool in heat of up to 50 and
provide warmth in the freezing cold of -20℃ to ensure a
constant and comfortable home environment.
Ideal comfort in minutes
The CAC Single digital inverter air conditioner works at
maximum capacity at startup. As soon as the temperature
reaches the desired or set temperature, CAC Single
performs fine adjustments to cope with any changes. This
means less temperature fluctuation and ideal comfort in a
matter of minutes.
Uncomfortable
(Energy Loss)
Comfortable
Uncomfortable
(Energy Loss)
25 C
24 C
23 C
Non-inverter
Steady Temperature Fluctuation
High Temperature Fluctuation
Versatile piping installation
CAC Single outdoor units offer a selection of pipe
directions. The internal pipe connection ports allow
four different pipe directions, supporting a neater, more
organized-looking unit upon installation.

5
(1) Classification
AC CAC
(2) Capacity
x 1/10 kW (3 digits)
(3) Version
H2014
J2015
K2016
M2017
N2018
(4) Product Type
NIndoor Unit
XOutdoor Unit
(5) Product Notation
11 Way Cassette
N4 Way Cassette (600x600)
Wind-Free 4 Way Cassette (600x600)
44 Way Cassette, 360 Cassette
Wind-Free 4 Way Cassette
LLSP Duct
MMSP Duct
CCeiling
JConsole
AA3050 (Wall Mounted)
(6) Feature
FFlagship
SStandard
DDeluxe
PPremium
(7) Rating Voltage
K1Ф, 220~240V, 50/60Hz
(8) Mode
HHeat Pump
Installation
Nomenclature
Indoor Unit
Model Name
AC
(1)
026
(2)
N
(3)
N
(4)
N
(5)
D
(6)
K
(7)
H
(8)
EU
Buyer

6
Nomenclature
Outdoor Unit
Model Name
AC
(1)
026
(2)
M
(3)
X
(4)
A
(5)
D
(6)
K
(7)
H
(8)
EU
Buyer
(1) Classification
AC CAC
(2) Capacity
X 1/10 kW (3 digits)
(3) Version
H2014
J2015
K2016
M2017
(4) Product Type
NIndoor Unit
XOutdoor Unit
(5) Product Notation
AInv+Side+General Temp
(6) Feature
FFlagship
SStandard
DDeluxe
PPremium
(7) Rating Voltage
K1Ф, 220~240V, 50/60Hz
N3Ф, 380~415V, 50/60Hz
(8) Mode
HHeat Pump

7
Line-up
Indoor unit
Model
Capacity (kW)
2.6 3.5 5.2 6.0 7.1 9.0 10.0 12.0 14.0
Wind-Free 4Way
CST (600x600)
Wind-Free
4Way CST
Outdoor Unit
Model
Capacity (kW)
2.6 3.5 5.2 6.0 7.1 9.0 10.0 12.0 14.0
1Phase
3Phase

8
Contents
Wind-Free 4Way Cassette (600x600) 9
Wind-Free 4Way Cassette 34
Outdoor Units 68

9
1. Specification 11
2. Summary Table 17
3. Capacity Table 18
4. Dimensional Drawing 23
5. Center of Gravity 24
6. Electrical Wiring Diagram 25
7. Sound Data 26
8. Temperature and air flow distribution 29
Wind-Free 4Way Cassette (600x600)
Wind-Free 4Way Cassette (600x600)

Wind-Free 4Way Cassette (600x600)
10
Features & Benefits
Add chic flairto yourinterior design with a stylish yet
powerful AC system
Samsung’s advanced Wind-Free 4Way Cassette
(600 x 600) builds on the aesthetic appeal and
performance of the standard Wind-Free 4Way Cassette
with an enhanced design. The Wind-Free 4Way Cassette
(600 x 600) comes in a variety of patterns to
complement any interior. The stylish cassette unit
visually harmonizes with the indoor space, while efficient
cooling and heating performance make it a dependable
and practical air conditioning solution.
The Wind-Free 4Way Cassette (600 x 600) indoor
air conditioning system provides high-performance
heating and cooling in an elegant design with features
such as:
•Tasteful design and compact, lightweight build.
Create a polished ambiance with a discreetly sized
design and a choice of attractive panel patterns.
•Enhanced comfort control. Optimize comfort and
save energy with optional motion detection.
•Low maintenance and powerful airflow. Ease
installation and maintenance and maximize airflow
with an efficient design and robust performance.
Wind-Free 4Way Cassette (600 x 600) - Tasteful design, Compact, Lightweight build
Refine the interiorwith an elegant, compact design
The enhanced Samsung Wind-Free 4Way Cassette
(600 x 600) indoor air conditioner features a selection
of simple panel patterns to blend seamlessly into any
interior design. Its uniquely lightweight frame blends
effortlessly and beautifully into any décor, while clever
blade construction keeps the unit clean for a tidy
appearance.
Attractive panel and display
The Wind-Free 4Way Cassette (600 x 600) features a
fashionable panel with a simple, beveled corner design.
The rounded panel frame promotes a neat, tidy look
for an aesthetic flair that blends perfectly with any
ambience.
Ultra-compact size
Samsung's Wind-Free 4Way Cassette (600 x 600) air conditioner
can be installed on a single standard ceiling tile (600W x 600D)
which helps minimize installation time and effort.
Light, robust design
The Samsung Wind-Free 4Way Cassette (600 x 600) indoor unit
is now lighter in weight at 11kg. It is the lightest indoor unit in the
industry, about 35 percent lighter than our conventional products.
11kg
17kg11kg
17kg
Wind-Free 4Way Casseette (Interior)
Conventional
*Based on 3.5kW

Wind-Free 4Way Cassette (600x600)
11
1. Specification1. Specification
Model Name Indoor Unit AC026NNNDKH/EU AC035NNNDKH/EU AC052NNNDKH/EU
Outdoor Unit AC026MXADKH/EU AC035MXADKH/EU AC052MXADKH/EU
System
Mode - HEAT PUMP HEAT PUMP HEAT PUMP
Performance Capacity
Cooling
(Min/Std/Max)
kW 1.00 / 2.60 / 3.40 1.00 / 3.50 / 4.00 1.30 / 5.00 / 5.90
Btu/h 3,400 / 8,900 / 11,600 3,400 / 11,900 / 13,600 4,400 / 17,100 / 20,100
Heating
(Min/Std/Max)
kW 0.98 / 3.40 / 4.10 1.00 / 4.00 / 4.80 1.30 / 5.50 / 7.50
Btu/h 3,300 / 11,600 / 14,000 3,400 / 13,600 / 16,400 4,400 / 18,800 / 25,600
Power
Power Input
Cooling (Min/Std/Max) kW 0.24 / 0.68 / 1.20 0.24 / 1.09 / 1.50 0.31 / 1.53 / 2.10
Heating (Min/Std/Max) kW 0.20 / 0.90 / 1.45 0.19 / 1.20 / 1.80 0.35 / 1.52 / 2.40
Current Input
Cooling (Min/Std/Max) A 1.60 / 3.80 / 5.50 1.60 / 5.60 / 7.50 2.60 / 6.90 / 9.50
Heating (Min/Std/Max) A 1.30 / 4.80 / 7.00 1.30 / 5.80 / 10.50 2.90 / 6.90 / 11.00
Current MCA A 11 11 21
MFA A12.5 12.5 25
Efficiency
EER Cooling W/W 3.82 3.21 3.27
COP Heating W/W 3.78 3.33 3.62
SEER (Cooling Energy Grade) W/W 6.9 (A++) 6.8 (A++) 6.5 (A++)
SCOP (Heating Energy Grade) W/W 4.3 (A+) 4.3 (A+) 4.1 (A+)
Pdesignh kW 2.1 2.1 2.6
Piping
Connections
Liquid Pipe
Type Flare connection Flare connection Flare connection
Φ, mm 6.35 6.35 6.35
Φ, inch 1/4 1/4 1/4
Gas Pipe
Type Flare connection Flare connection Flare connection
Φ, mm 9.52 9.52 12.7
Φ, inch 3/8 3/8 1/2
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Piping length
(ODU-IDU)
Standard m 5 5 5
Max. m 20 20 30
Elevation m 15 15 20
Chargeless m 20 20 5
Wiring
connections
Power Source Wire mm2---
Transmission Cable mm2Min. 0.75 Min. 0.75 Min. 0.75
Remark -F1, F2 F1, F2 F1, F2
Power supply intake -
Both indoor and outdoor unit Both indoor and outdoor unit Both indoor and outdoor unit
Refrigerant Type - R410A R410A R410A
Factory Charging kg / tCO₂e 1.05 / 2.19 1.05 / 2.19 1.3 / 2.71

Wind-Free 4Way Cassette (600x600)
1. Specification
12
Model Name Indoor Unit AC026NNNDKH/EU AC035NNNDKH/EU AC052NNNDKH/EU
Outdoor Unit AC026MXADKH/EU AC035MXADKH/EU AC052MXADKH/EU
Indoor
Unit
Power Supply Ø, #, V, Hz 1, 2, 220-240, 50 1, 2, 220-240, 50 1, 2, 220-240, 50
Heat
Exchanger
Type - Fin & Tube Fin & Tube Fin & Tube
Material Fin -Al Al Al
Tube - Cu Cu Cu
Fan
Type - Turbo Fan Turbo Fan Turbo Fan
Quantity EA 1 1 1
Air Flow Rate High/Mid/Low CMM 8.0 / 7.0 / 6.0 9.2 / 8.0 / 6.4 10.5 / 9.5 / 8.5
l/s 133.3 / 116.7 / 100.0 153.3 / 133.3 / 106.7 175.0 / 158.3 / 141.7
External Static
Pressure Min/Std/Max mmAq ---
Pa ---
Fan Motor Output W x n 65 x 1 65 x 1 65 x 1
Drain Drain Pipe Φ, mm VP-25(OD32, ID25) VP-25(OD32, ID25) VP-25(OD32, ID25)
Sound
Sound Pressure Level High/Mid/Low/(Silent) dB(A) 31 / 28 / 25 34 / 30 / 25 39 / 34 / 29
Sound Power Level dB(A) 48 50 56
External
Dimension
Net Weight kg 11.4 11.4 11.6
Shipping Weight kg 13.7 13.7 14
Net Dimensions (WxHxD) mm 575 x 250 x 575 575 x 250 x 575 575 x 250 x 575
Shipping Dimensions (WxHxD) mm 623 x 298 x 653 623 x 298 x 653 623 x 298 x 653
Casing Material - Polypropylene Polypropylene Polypropylene
Panel
Model Name - PC4SUFMAN PC4SUFMAN PC4SUFMAN
Type - Wind-Free Type Wind-Free Type Wind-Free Type
Material - HIPS HIPS HIPS
Color -DA White DA White DA White
Net Weight kg 2.7 2.7 2.7
Shipping Weight kg 4.0 4.0 4.0
Net Dimensions (WxHxD) mm 620 x 57 x 620 620 x 57 x 620 620 x 57 x 620
Shipping Dimensions (WxHxD) mm 670x120x660 670x120x660 670x120x660
Control System Infrared remote control - AR-EH03E AR-EH03E AR-EH03E
Control System Wired remote control - MWR-WE13N MWR-WE13N MWR-WE13N
Drain Pump Drain Pump - Included Included Included
Max. lifting Height / Displacement mm / Liter/h 750/24 750/24 750/24
Additional
Accessories
Drain Pump
External Model - - - -
Internal Model - - - -
Max. lifting Height /
Displacement
mm / Liter/h ---
Air Filter -Removable / Washable Removable / Washable Removable / Washable
Virus Doctor - Option Option Option

Wind-Free 4Way Cassette (600x600)
13
1. Specification
Model Name Indoor Unit AC026NNNDKH/EU AC035NNNDKH/EU AC052NNNDKH/EU
Outdoor Unit AC026MXADKH/EU AC035MXADKH/EU AC052MXADKH/EU
Outdoor
Unit
Power Supply Ø, #, V, Hz 1, 2, 220-240, 50 1, 2, 220-240, 50 1, 2, 220-240, 50
Heat
Exchanger
Type - Fin & Tube Fin & Tube FMC
Material Fin -Al Al Al
Tube - Cu Cu Al
Fin Treatment - Anti-Corrosion Anti-Corrosion Hybrid Coating
Compressor
Model Name UG9AJ3090FER UG9AJ3090FER UG9TK3150FE4
Output kW 0.83 0.83 1.42
Oil Type - POE POE POE
Initial charge cc 320 320 500
Fan
Type - Propeller Propeller Propeller
Discharge direction - Front Front Front
Quantity EA 1 1 1
Air Flow Rate CMM 29 30 40
l/s 483 500 667
Fan Motor Type - BLDC Motor BLDC Motor BLDC Motor
Output W x n 68 x 1 68 x 1 125 x 1
Sound
Sound Pressure
Level
Cooling dB(A) 46 48 48
Heating dB(A) 47 48 48
Sound Power Level dB(A) 59 61 62
External
Dimension
Net Weight kg 32.8 32.8 43.8
Shipping Weight kg 35.8 35.8 4 7. 5
Net Dimensions (WxHxD) mm 790 x 548 x 285 790 x 548 x 285 880 x 638 x 310
Shipping Dimensions (WxHxD) mm 926 x 640 x 384 926 x 640 x 384 1023 x 730 x 413
Casing Material Body - EGI Steel Plate EGI Steel Plate EGI Steel Plate
Operating
Temp. Range
Cooling ℃ -15 ~ 50 -15 ~ 50 -15 ~ 50
Heating ℃ -20 ~ 24 -20 ~ 24 -20 ~ 24
NOTE
•Specification may be subject to change without prior notice.
Specification comply with EN14511.
1) Capacities are based on (Equivalent refrigerant piping 5m, Level differences 0m);
- Cooling : Indoor temperature 27°C DB, 19°C WB / Outdoor temperature 35°C DB, 24°C WB
- Heating : Indoor temperature 20°C DB, 15°C WB / Outdoor temperature 7°C DB, 6°C WB
2) Sound power level is an absolute value that a sound source generates.
Sound power level is based on cooling operation.
Sound pressure level is a relative value, depending on the distance and acoustic environment.
Sound values are obtained in an anechoic room.
Sound values of multi combination are theoretical values based on sound results of individual installed units.
3) These products contain R410A(GWP=2,088) which is fluorinated greenhouse gas.
•In case you want to know more information regarding capacity and correction, please refer to capacity table
TDB on pvi.samsung.com site.

Wind-Free 4Way Cassette (600x600)
1. Specification
14
Model Name Indoor Unit AC060NNNDKH/EU AC071NNNDKH/EU
Outdoor Unit AC060MXADKH/EU AC071MXADKH/EU
System
Mode - HEAT PUMP HEAT PUMP
Performance Capacity
Cooling
(Min/Std/Max)
kW 1.80 / 5.80 / 6.50 2.20 / 6.80 / 8.00
Btu/h 6,100 / 19,800 / 22,200 7,500 / 23,200 / 27,300
Heating
(Min/Std/Max)
kW 1.60 / 7.00 / 9.00 1.90 / 7.50 / 9.00
Btu/h 5,500 / 23,900 / 30,700 6,500 / 25,600 / 30,700
Power
Power Input
Cooling (Min/Std/Max) kW 0.38 / 2.15 / 2.60 0.35 / 2.72 / 3.95
Heating (Min/Std/Max) kW 0.35 / 2.32 / 3.60 0.35 / 2.80 / 3.95
Current Input
Cooling (Min/Std/Max) A 1.90 / 9.30 / 11.50 2.00 / 11.80 / 17.00
Heating (Min/Std/Max) A1.70 / 10.00 / 17.30 2.00 / 12.30 / 17.00
Current MCA A 21 21
MFA A 25 25
Efficiency
EER Cooling W/W 2.70 2.50
COP Heating W/W 3.02 2.68
SEER (Cooling Energy Grade) W/W 6.2 (A++) 6.0 (A+)
SCOP (Heating Energy Grade) W/W 4.0 (A+) 3.8 (A)
Pdesignh kW 2.6 4
Piping
Connections
Liquid Pipe
Type Flare connection Flare connection
Φ, mm 6.35 6.35
Φ, inch 1/4 1/4
Gas Pipe
Type Flare connection Flare connection
Φ, mm 12.7 15.88
Φ, inch 1/2 5/8
Heat Insulation - Both liquid and gas pipes Both liquid and gas pipes
Piping length
(ODU-IDU)
Standard m 5 5
Max. m 30 50
Elevation m 20 30
Chargeless m 5 5
Wiring
connections
Power Source Wire mm2- -
Transmission Cable mm2Min. 0.75 Min. 0.75
Remark -F1, F2 F1, F2
Power supply intake -
Both indoor and outdoor unit Both indoor and outdoor unit
Refrigerant Type - R410A R410A
Factory Charging kg / tCO₂e 1.3 / 2.71 1.5 / 3.13

Wind-Free 4Way Cassette (600x600)
15
1. Specification
Model Name Indoor Unit AC060NNNDKH/EU AC071NNNDKH/EU
Outdoor Unit AC060MXADKH/EU AC071MXADKH/EU
Indoor
Unit
Power Supply Ø, #, V, Hz 1, 2, 220-240, 50 1, 2, 220-240, 50
Heat
Exchanger
Type - Fin & Tube Fin & Tube
Material Fin -Al Al
Tube - Cu Cu
Fan
Type - Turbo Fan Turbo Fan
Quantity EA 1 1
Air Flow Rate High/Mid/Low CMM 11.0 / 10.0 / 9.0 11.5 / 10.5 / 9.5
l/s 183.3 / 166.7 / 150.0 191.7 / 175.0 / 158.3
External Static
Pressure Min/Std/Max mmAq - -
Pa - -
Fan Motor Output W x n 65 x 1 65 x 1
Drain Drain Pipe Φ, mm VP-25(OD32, ID25) VP-25(OD32, ID25)
Sound
Sound Pressure Level High/Mid/Low/(Silent) dB(A) 41 / 37 / 32 42 / 39 / 36
Sound Power Level dB(A) 56 58
External
Dimension
Net Weight kg 11.6 11.8
Shipping Weight kg 14 14.2
Net Dimensions (WxHxD) mm 575 x 250 x 575 575 x 250 x 575
Shipping Dimensions (WxHxD) mm 623 x 298 x 653 623 x 298 x 653
Casing Material - Polypropylene Polypropylene
Panel
Model Name - PC4SUFMAN PC4SUFMAN
Type - Wind-Free Type Wind-Free Type
Material - HIPS HIPS
Color -DA White DA White
Net Weight kg 2.7 2.7
Shipping Weight kg 4.0 4.0
Net Dimensions (WxHxD) mm 620 x 57 x 620 620 x 57 x 620
Shipping Dimensions (WxHxD) mm 670x120x660 670x120x660
Control System Infrared remote control - AR-EH03E AR-EH03E
Control System Wired remote control - MWR-WE13N MWR-WE13N
Drain Pump Drain Pump - Included Included
Max. lifting Height / Displacement mm / Liter/h 750/24 750/24
Additional
Accessories
Drain Pump
External Model - - -
Internal Model - - -
Max. lifting Height /
Displacement
mm / Liter/h - -
Air Filter -Removable / Washable Removable / Washable
Virus Doctor - Option Option

Wind-Free 4Way Cassette (600x600)
1. Specification
16
Model Name Indoor Unit AC060NNNDKH/EU AC071NNNDKH/EU
Outdoor Unit AC060MXADKH/EU AC071MXADKH/EU
Outdoor
Unit
Power Supply Ø, #, V, Hz 1, 2, 220-240, 50 1, 2, 220-240, 50
Heat
Exchanger
Type - FMC FMC
Material Fin -Al Al
Tube -Al Al
Fin Treatment - Hybrid Coating Hybrid Coating
Compressor
Model Name UG9TK3150FE4 UG4T200FUAE4
Output kW 1.42 1.79
Oil Type - POE POE
Initial charge cc 500 650
Fan
Type - Propeller Propeller
Discharge direction - Front Front
Quantity EA 1 1
Air Flow Rate CMM 40 51
l/s 667 850
Fan Motor Type - BLDC Motor BLDC Motor
Output W x n 125 x 1 125 x 1
Sound
Sound Pressure
Level
Cooling dB(A) 49 49
Heating dB(A) 49 51
Sound Power Level dB(A) 62 65
External
Dimension
Net Weight kg 43.8 53
Shipping Weight kg 4 7. 5 5 7. 2
Net Dimensions (WxHxD) mm 880 x 638 x 310 880 x 798 x 310
Shipping Dimensions (WxHxD) mm 1023 x 730 x 413 1023 x 911 x 413
Casing Material Body - EGI Steel Plate EGI Steel Plate
Operating
Temp. Range
Cooling ℃ -15 ~ 50 -15 ~ 50
Heating ℃ -20 ~ 24 -20 ~ 24
NOTE
•Specification may be subject to change without prior notice.
Specification comply with EN14511.
1) Capacities are based on (Equivalent refrigerant piping 5m, Level differences 0m);
- Cooling : Indoor temperature 27°C DB, 19°C WB / Outdoor temperature 35°C DB, 24°C WB
- Heating : Indoor temperature 20°C DB, 15°C WB / Outdoor temperature 7°C DB, 6°C WB
2) Sound power level is an absolute value that a sound source generates.
Sound power level is based on cooling operation.
Sound pressure level is a relative value, depending on the distance and acoustic environment.
Sound values are obtained in an anechoic room.
Sound values of multi combination are theoretical values based on sound results of individual installed units.
3) These products contain R410A(GWP=2,088) which is fluorinated greenhouse gas.
•In case you want to know more information regarding capacity and correction, please refer to capacity table
TDB on pvi.samsung.com site.

Wind-Free 4Way Cassette (600x600)
17
2. Summary Table2. Summary Table
Performance Characteristics
Model Code Net Weight
(kg)
Capacity
Fan Speed
Airflow
(Cooling/Heating)
(CMM)
Sound Pressure Level
(dBA)
Sound Power Level
(dBA)
Cooling
(kW)
Heating
(kW)
AC026NNNDKH/EU 11.4
Max. 3.4 4.1 High 8.0 / 10.0 31 48
Std. 2.6 3.4 Mid 7.0 / 9.0 28 -
Min. 1.0 0.98 Low 6.0 / 8.0 25 -
AC035NNNDKH/EU 11.4
Max. 4.0 4.8 High 9.2 / 10.4 34 50
Std. 3.5 4.0 Mid 8.0 / 9.0 30 -
Min. 1.0 1.0 Low 6.4 / 7.8 25 -
AC052NNNDKH/EU 11.6
Max. 5.9 7. 5 High 10.5 / 10.5 39 56
Std. 5.0 5.5 Mid 9.5 / 9.5 34 -
Min. 1.3 1.3 Low 8.5 / 8.5 29 -
AC060NNNDKH/EU 11.6
Max. 6.5 9.0 High 11.0 / 11.0 41 56
Std. 5.8 7.0 Mid 10.0 / 10.0 37 -
Min. 1.8 1.6 Low 9.0 / 9.0 32 -
AC071NNNDKH/EU 11.8
Max. 8.0 9.0 High 11.5 / 11.5 42 58
Std. 6.8 7. 5 Mid 10.5 / 10.5 39 -
Min. 2.2 1.9 Low 9.5 / 9.5 36 -
NOTE
•Sound data is based on cooling operation.
Electric Characteristics
Model Outdoor Unit Input Current (Amperes) Power Supply
Indoor Unit Outdoor Unit Rated Voltage range Outdoor Unit Indoor Unit Total MCA(A) MFA(A)
Hz Volts Min. Max. Cooling Heating
AC026NNNDKH/EU AC026MXADKH/EU 50 220 to 240 198 264 10 10 1 11 11 12.5
AC035NNNDKH/EU AC035MXADKH/EU 50 220 to 240 198 264 10 10 1 11 11 12.5
AC052NNNDKH/EU AC052MXADKH/EU 50 220 to 240 198 264 20 20 1 21 21 25
AC060NNNDKH/EU AC060MXADKH/EU 50 220 to 240 198 264 20 20 1 21 21 25
AC071NNNDKH/EU AC071MXADKH/EU 50 220 to 240 198 264 20 20 1 21 21 25
NOTE
• MCA : Minimum circuit amperes
• MFA : Maximum fuse amperes
•Select wire size based on the value of MCA

Wind-Free 4Way Cassette (600x600)
3. Capacity Table
18
3. Capacity Table
(1) AC026NNNDKH/EU + AC026MXADKH/EU
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB / WB)
20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
-15 2.54 2.15 0.49 2.67 2.21 0.50 2.78 2.28 0.51 2.87 2.35 0.52 2.92 2.33 0.52 3.07 2.30 0.53 3.22 2.26 0.54
21 2.42 2.04 0.51 2.54 2.11 0.52 2.65 2.17 0.53 2.73 2.24 0.54 2.78 2.22 0.55 2.92 2.19 0.55 3.07 2.15 0.57
35 2.30 1.95 0.64 2.42 2.01 0.65 2.52 2.07 0.67 2.60 2.13 0.68 2.65 2.11 0.69 2.78 2.09 0.69 2.92 2.05 0.71
46 1.96 1.80 0.58 2.06 1.86 0.59 2.14 1.92 0.60 2.21 1.97 0.61 2.25 1.95 0.62 2.37 1.93 0.62 2.49 1.90 0.64
50 1.50 1.42 0.51 1.57 1.46 0.52 1.64 1.51 0.53 1.69 1.55 0.54 1.72 1.54 0.55 1.81 1.52 0.55 1.90 1.49 0.57
Heating
TC : Total Capacity, PI : Power Input
Outdoor Temperature
(℃, DB)
Indoor Temperature (℃, DB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-20 2.39 1.19 2.37 1.18 2.35 1.17 2.32 1.16 2.30 1.15 2.28 1.14
-15 3.02 1.38 2.99 1.36 2.96 1.35 2.93 1.34 2.90 1.32 2.87 1.31
-5 3.40 1.29 3.37 1.27 3.33 1.26 3.30 1.25 3.27 1.23 3.23 1.22
03.54 1.10 3.50 1.09 3.47 1.08 3.43 1.07 3.40 1.06 3.36 1.05
73.47 0.92 3.43 0.91 3.40 0.90 3.37 0.89 3.33 0.88 3.30 0.87
24 4.51 1.06 4.46 1.05 4.42 1.04 4.38 1.02 4.33 1.01 4.29 1.00
NOTE
•The performance table shows the average value of each conditions.

Wind-Free 4Way Cassette (600x600)
19
3. Capacity Table
(2) AC035NNNDKH/EU+ AC035MXADKH/EU
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB / WB)
20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
-15 3.41 2.68 0.78 3.59 2.76 0.80 3.74 2.84 0.81 3.86 2.93 0.83 3.94 2.90 0.84 4.13 2.87 0.84 4.34 2.82 0.86
21 3.25 2.55 0.82 3.42 2.63 0.84 3.56 2.71 0.85 3.68 2.79 0.87 3.75 2.77 0.88 3.94 2.74 0.89 4.13 2.68 0.91
35 3.10 2.43 1.03 3.26 2.50 1.05 3.40 2.58 1.07 3.50 2.66 1.09 3.57 2.63 1.10 3.75 2.61 1.11 3.94 2.55 1.13
46 2.63 2.26 0.92 2.77 2.33 0.94 2.89 2.40 0.96 2.98 2.48 0.98 3.03 2.45 0.99 3.19 2.43 1.00 3.35 2.38 1.02
50 2.01 1.79 0.82 2.12 1.84 0.84 2.21 1.90 0.85 2.28 1.96 0.87 2.32 1.94 0.88 2.44 1.92 0.89 2.56 1.88 0.91
Heating
TC : Total Capacity, PI : Power Input
Outdoor Temperature
(℃, DB)
Indoor Temperature (℃, DB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-20 2.82 1.59 2.79 1.58 2.76 1.56 2.73 1.54 2.71 1.53 2.68 1.51
-15 3.55 1.84 3.51 1.82 3.48 1.80 3.45 1.78 3.41 1.76 3.38 1.75
-5 4.00 1.71 3.96 1.70 3.92 1.68 3.88 1.66 3.84 1.65 3.80 1.63
04.16 1.47 4.12 1.45 4.08 1.44 4.04 1.43 4.00 1.41 3.96 1.40
74.08 1.22 4.04 1.21 4.00 1.20 3.96 1.19 3.92 1.18 3.88 1.16
24 5.30 1.41 5.25 1.39 5.20 1.38 5.15 1.37 5.10 1.35 5.05 1.34
NOTE
•The performance table shows the average value of each conditions.

Wind-Free 4Way Cassette (600x600)
3. Capacity Table
20
(3) AC052NNNDKH/EU + AC052MXADKH/EU
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
Outdoor
Temperature
(℃, DB)
Indoor Temperature (℃, DB / WB)
20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
-15
4.88 3.72 1.09 5.13 3.84 1.12 5.35 3.96 1.14 5.51 4.08 1.16 5.62 4.04 1.17 5.90 4.00 1.19 6.20 3.92 1.21
21 4.64 3.55 1.15 4.89 3.66 1.18 5.09 3.77 1.20 5.25 3.89 1.22 5.36 3.85 1.24 5.62 3.81 1.25 5.90 3.73 1.27
35 4.42 3.38 1.44 4.66 3.48 1.47 4.85 3.59 1.50 5.00 3.70 1.53 5.10 3.66 1.55 5.36 3.63 1.56 5.62 3.55 1.59
46 3.76 3.15 1.30 3.96 3.25 1.32 4.12 3.35 1.35 4.25 3.46 1.38 4.34 3.42 1.39 4.55 3.39 1.40 4.78 3.32 1.43
50 2.88 2.49 1.15 3.03 2.57 1.18 3.15 2.65 1.20 3.25 2.73 1.22 3.32 2.70 1.24 3.48 2.68 1.25 3.65 2.62 1.27
Heating
TC : Total Capacity, PI : Power Input
Outdoor Temperature
(℃, DB)
Indoor Temperature (℃, DB)
16 18 20 21 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-20 3.87 2.02 3.83 2.00 3.80 1.98 3.76 1.96 3.72 1.94 3.68 1.92
-15 4.88 2.33 4.83 2.30 4.79 2.28 4.74 2.26 4.69 2.23 4.64 2.21
-5 5.50 2.17 5.44 2.15 5.39 2.13 5.34 2.11 5.28 2.09 5.23 2.06
0 5.72 1.86 5.67 1.84 5.61 1.82 5.55 1.81 5.50 1.79 5.44 1.77
7 5.61 1.55 5.56 1.54 5.50 1.52 5.45 1.50 5.39 1.49 5.34 1.47
24 7. 2 9 1.78 7. 2 2 1.77 7.1 5 1.75 7.0 8 1.73 7.0 1 1.71 6.94 1.70
NOTE
•The performance table shows the average value of each conditions.
