Fast Track Troubleshooting
Model: WA40J3000
Publication #DR WA40J3000
Production date: 5-13-15
IMPORTANT SAFETY NOTICE –“For Technicians Only” This service data sheet is
intended for use by persons having electrical, electronic, and mechanical experience and knowledge
at a level generally considered acceptable in the appliance repair trade. Any attempt to repair a
major appliance may result in personal injury and property damage. The manufacturer or seller
cannot be responsible, nor assume any liability for injury or damage of any kind arising from the use
of this data sheet.
Bulletins:
Support Information:
HELP: 1-888-751-4086 (Tech Sup. –ASC/SSD) - 1-866-894-0637 (Tech Sup. - FE/ME)
GSPN: http://gspn3.samsungcsportal.com/main.jsp
PLUS ONE: http://my.plus1solutions.net/clientPortals/samsung
TEST MODE: WITH POWER OFF - PRESS: Load Size + POWER
* Entering Test mode will delete any stored errors
1. All LED’s light up and it sends out Beep Sound when it
enters into the Test Mode, and the memory will clear
EEPROM. ( including any errors that were saved)
2. Press the Start key to bypass LED light up, it would
displays software version after on normal mode.
3. Press the Temp key, test the Water Valve.
4. Press the Temp and Start key, test the Door Lock.
5. Press the Load Size and Start key, test the Pump.
6. Turn the Jog-Dial to
1) Normal course :Display the MCU SW version.
2) Heavy Duty Course : Display the Model Option.
3) Delicates course : Test the Motor On/Off.
4) Colors/Darks course : Test the Spin.
TEST FUNCTION test PRESS
1 Water Valve Test TEMP
2 Door Lock / Unlock TEMP + Start
3 Pump Test Load Size + Start
4 Motor On / Off Set to Delicates
5 Spin Test Set to Colors/Darks
6 SW Version Set to Normal
7 Model Option Set to Heavy Duty
Activating or disable the Child Lock function
Press and hold the Temp. and Load Size
buttons simultaneously for approximately 3
seconds.
• When you activate the Child Lock function,
the “Child Lock” lamp blinks
Error Code Check When power is on Hold TEMP 3
Seconds
Check Errors First before entering test mode

Error Codes
Unit keeps running non stop -
If you have this issue with this
unit replace the Main PCB,
software in the board has
changed it will correct this
symptom.
Error Code Check Hold TEMP 3 Seconds
ATC (Auto Temperature Control)
ATC is the control function that the washer controls water temperature with temperature sensor (thermistor).
Because there are numerous water temperatures depending on the customer’s environments (cold
areas, warm areas, various water temperatures, settings of heater temperature, etc.), ATC function in
our washer maintains the certain level of wash temperature to output the best washing performance at
each cycle.
If you select normal cycle, this cycle is the regulation and UL cycle. Since new washers must reduce
the amount of energy usage as a first priority, customers will notice more cold water entering the
washer. But, this is normal, not a problem.
In this regulation cycle, Hot temperature is similar to acceptable adult bath-water temperature and
warm temperature is similar to comfortable swimming-pool water temperature.
If customers want to wash clothes in specific water temperatures, customers should choose a different
cycle at each temperature (Hot/Warm).

CN9
CN12
CN6 CN1 CN8CN7CN10
CN2
CN3
CN801
White and black
may be switched
at this point.
Adjust
