S&C PureWave Installation guide

December 22, 2014 © S&C Electric Company Instruction Sheet 658-500
S&C PureWave® Community Energy Storage System
25 kW/25 kVA, 240/120 V
Operation and Maintenance
Table of Contents
Section Page Section Page
Introduction
Qualified Persons ..............................2
Read this Instruction Sheet ......................2
Retain this Instruction Sheet .....................2
Proper Application..............................2
Warranty .....................................2
Safety Information
Understanding Safety-Alert Messages .............3
Following Safety Instructions .....................3
Replacement Instructions and Labels...............3
Location of Safety Labels ........................4
Annual Inspections .............................4
Equipment Safety, Precautions and Practices ........6
Shield Protection...............................6
Visible Battery Disconnect Terminals ...............6
Controls and Indicators
Control Panel .................................7
Selector Switch ................................7
Indicator Lights ................................7
Reset Button ..................................8
Hot Start Button ...............................8
Discharge Connector ...........................8
States .......................................9
Resets...................................... 10
Alarms ..................................... 10
Operation
System Overview ............................. 16
System Design ............................... 16
Entering the System Enclosure................... 17
Energy Storage System ........................ 18
IntelliLink® Remote Setup Software Configuration.... 19
IntelliLink® Program ...........................20
Initial Power Up and Testing .....................21
PureWave CES Bypass Procedures ...............23
Outage Procedure.............................25
Specifications ................................26
Maintenance
Maintenance Checklist .........................27
PureWave CES Annual Maintenance Checklist ......27

2S&C Instruction Sheet 658-500
Qualified Persons WARNING
The equipment covered by this publication must be installed, operated, and maintained by
qualified persons who are knowledgeable in the installation, operation, and maintenance
of underground electric power distribution equipment along with the associated hazards.
A qualified person is one who is trained and competent in:
• The skills and techniques necessary to distinguish exposed live parts from non-live parts
of electrical equipment.
• The skills and techniques necessary to determine the proper approach distances cor-
responding to the voltages to which the qualified person will be exposed.
• The proper use of the special precautionary techniques, personal protective equipment,
insulating and shielding materials, and insulated tools for working on or near exposed
energized parts of electrical equipment.
These instructions are intended only for such qualified persons. They are not intended
to be a substitute for adequate training and experience in safety procedures for this type
of equipment.
Read this
Instruction Sheet
Thoroughly and carefully read this entire instruction sheet before operating and main-
taining the PureWave Community Energy Storage (CES) System. Familiarize yourself
with the safety information and precautions on pages 3 through 6. The latest version
of this instruction sheet is available online in PDF format at sandc.com/Support/
Product-Literature.asp
Retain this
Instruction Sheet
This instruction sheet is a permanent part of your PureWave CES. It does not include
instruction sheets from the original battery manufacturer and the IntelliLink® Remote
Setup Software. Designate a location where you can easily retrieve all information and
refer to it.
Proper Application CAUTION
The equipment in this publication must be selected for a specific application. The appli-
cation must be within the ratings furnished for the equipment. Refer to S&C Information
Sheet 658-450 for the PureWave CES guide specification.
Warranty The warranty and/or obligations described in S&C’s standard conditions of sale, as set
forth in Price Sheet 150, plus any special warranty provisions, as set forth in the appli-
cable product-line specification bulletin, are exclusive. The remedies provided in the
former for breach of these warranties shall constitute immediate purchaser’s or end
user’s exclusive remedy and a fulfillment of all seller’s liability. In no event shall seller’s
liability to immediate purchaser or end user exceed the price of the specific product
which gives rise to immediate purchaser’s or end user’s claim. All other warranties,
whether express or implied or arising by operation of law, course of dealing, usage of
trade or otherwise, are excluded. The only warranties are those stated in Price Sheet 150,
and THERE ARE NO EXPRESS OR IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. ANY EXPRESS WARRANTY OR OTHER
OBLIGATION PROVIDED IN PRICE SHEET 150 IS GRANTED ONLY TO THE IMMEDI-
ATE PURCHASER AND END USER, AS DEFINED THEREIN. OTHER THAN AN END
USER, NO REMOTE PURCHASER MAY RELY ON ANY AFFIRMATION OF FACT OR
PROMISE THAT RELATES TO THE GOODS DESCRIBED HEREIN, ANY DESCRIPTION
THAT RELATES TO THE GOODS, OR ANY REMEDIAL PROMISE INCLUDED IN PRICE
SHEET 150.
The seller’s warranties are contingent upon the installation and adjustment of the S&C
PureWave® Community Energy Storage System in accordance with S&C’s applicable
instruction sheets, data sheets, and/or data bulletins.
Introduction

S&C Instruction Sheet 658-500 3
Understanding
Safety-Alert
Messages
There are several types of safety-alert messages which may appear throughout this
instruction sheet as well as on labels attached to the PureWave CES System. Familiarize
yourself with these types of messages and the importance of the various signal words, as
explained below.
DANGER
“DANGER” identifies the most serious and immediate hazards which will likely result in
serious personal injury or death if instructions, including recommended precautions, are
not followed.
WARNING
“WARNING” identifies hazards or unsafe practices which can result in serious personal
injury or death if instructions, including recommended precautions, are not followed.
CAUTION
“CAUTION” identifies hazards or unsafe practices which can result in minor
personal injury or product or property damage if instructions, including recommended
precautions, are not followed.
NOTICE
“NOTICE” identifies important procedures or requirements that can result in product or
property damage if instructions are not followed.
Following
Safety Instructions
If you do not understand any portion of this instruction sheet and need assistance, contact
your nearest S&C Sales Ofce or S&C Authorized Distributor. Their telephone numbers
are listed on S&C’s website sandc.com. Or call S&C Headquarters at (773) 338-1000; in
Canada, call S&C Electric Canada Ltd. at (416) 249-9171.
NOTICE
Read this instruction sheet thoroughly and carefully before
installing or operating your S&C PureWave CES System.
Replacement
Instructions
and Labels
If you need additional copies of this instruction sheet, contact your nearest S&C Sales
Ofce, S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.
It is important that any missing, damaged, or faded labels on the equipment are replaced
immediately. Replacement labels are available by contacting your nearest S&C Sales Office,
S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.
Safety Information

4S&C Instruction Sheet 658-500
Safety Information
Location of Safety Labels
D
C
B
A
Reorder Information for Safety Labels
Location Safety Alert Message Description Number
AWARNING Risk of electrical shock. Discharge capacitors . . . PE-702170
rev. 001
BWARNING Risk of electrical shock. Bus is energized . . . PE-70420-1
rev. 000
CDANGER Risk of electrical shock. Hazardous voltage. . . . PE-70421-1
rev. 000
DWARNING KEEP OUT. RISK OF ELECTRICAL SHOCK. . . . PE-70314
Annual Inspections After the PureWave CES is commissioned and the unit is on-line, inspection and main-
tenance should be scheduled on an annual basis to ensure the proper operation of the
system. Schedules for maintenance should be reviewed by the customer based upon the
given site conditions and, if required, the frequency of the recommended maintenance
should increase to ensure the reliability of their PureWave CES.

S&C Instruction Sheet 658-500 5
Safety Information
1. QUALIFIED PERSONS. Access to PureWave CES must
be restricted only to qualified persons. See “Qualified
Persons” on page 2.
2. SAFETY PROCEDURES. Always follow safe
operating procedures and rules.
3. PERSONAL PROTECTIVE EQUIPMENT. Always use
suitable protective equipment such as rubber gloves,
rubber mats, hard hats, safety glasses, and flash
clothing in accordance with safe operating procedures
and rules.
4. SAFETY LABELS. Do not remove or obscure any of
the “DANGER,” “WARNING,” “CAUTION,” or “NOTICE”
labels.
5. ENCLOSURE. Do not open access doors unless the
system is offline or otherwise authorized by S&C Electric
Company.
6. MAINTAINING PROPER CLEARANCE. Always
maintain proper clearance from energized components.
Ensure that the shield protectors inside the PureWave
CES are in place. See Figures 1 and 2 on page 6.
7. HIGH VOLTAGES. High-voltage DC is present
even without utility power connected. Hazardous
voltages should also be expected in all interconnecting
components and lines.
To maintain safety, the user should use padlocks on
each door of the PureWave CES.The door and the use
of the padlock provide protection to inadvertent contact
with high-voltage circuits.
8. GROUNDING.
• The PureWave CES base must be connected to a
suitable earth ground for testing before energizing
the unit, and at all times when energized.
• The ground wire(s) must be bonded to the sys-
tem neutral, if present. If the system neutral is not
present, proper precautions must be taken to ensure
that the local earth ground, or building ground,
cannot be severed or removed.
• The overall ground system should be sufficient to limit
the Ground Potential Rise (GPR), step voltage, and
touch voltage to acceptable limits as determined by
the utility’s practices and the National Electric Safety
Code (NESC).
9. ENERGIZED COMPONENTS. Always consider all
parts live until de-energized, tested, and grounded. For
visible battery disconnection from the PureWave CES,
see Figure 3 on page 6 for location of terminals.
10. INSULATED HAND TOOLS.
• Insulated hand tools are required when working on or
around any energized equipment. Use only properly
rated tools for the energy present.
• Tool inventories should be kept to ensure that all tools
that enter the system enclosure are removed prior to
energizing the system.
11. EMERGENCY PROCEDURES AND EQUIPMENT.
• The owner should develop policies and procedures
for handling emergency situations.
• It is the responsibility of the owner to develop
site-specic emergency action plans for response
to such situations.
12. ADDITIONAL SAFETY INSTRUCTIONS. Consult the
battery supplier for additional safety instructions and
procedures regarding the battery used in the PureWave
CES.
DANGER
The PureWave CES operates at high voltage. Failure to observe the precautions
below will result in serious personal injury or death.
Some of these precautions may differ from your company’s operating procedures
and rules. Where a discrepancy exists, follow your company’s operating procedures
and rules.

6S&C Instruction Sheet 658-500
Safety Information
Equipment Safety
Precautions and
Practices
S&C PureWave CES and battery instruction sheets must be available to all operators and
other employees. If doors to the system enclosure must be opened, refer to the instruc-
tion sheet for procedures for guarding against electric shock. All enclosure doors must
be padlocked when authorized personnel are not present to prevent injury to persons
unaware of the risks associated with the system.
WARNING
For safety, the PureWave CES has been designed as an unmanned device.
No person should attempt to defeat any interlock or other safety device and open any
PureWave CES access panels while the unit is running, the isolation breakers are closed,
or there is greater than 50V on the DC link or the battery input.
The user should not attempt to connect any additional logic controls or power connec-
tions to the PureWave CES without having received written approval from S&C Electric
Company.
Shield Protection The PureWave CES contains protection for the end-user from exposure to potentially
dangerous components of the unit. Figure 1 shows the shielding protection from the line
connections (at the front of the unit). Figure 2 shows the protection from the DC wiring
(at the back of the unit).
Figure 1. Shield protection from wiring
(front of unit).
Figure 2. Shield protection from line
connections (back of unit).
Visible Battery
Disconnect Terminals
The PureWave CES provides a means to disconnect the battery from the unit. At the rear
of the unit, there are two non-load-break disconnect terminals (positive and negative). It
is here that the end-user can connect/break the connection between the unit and the bat-
tery. This ensures the operator has a visible means to proceed in taking steps to operate
the unit (when connected), or take the steps needed to service the unit (when discon-
nected). See Figure 3.
Figure 3.Visible battery non-load-break
disconnect terminals.

S&C Instruction Sheet 658-500 7
Control Panel The control panel contains the master controls and the associated circuitry needed to
support proper operation of the PureWave CES. See Figure 4.
24-VDC inputs Selector switch Reset button
Indicator
lights
Hot start
button
DC bus test
points
DC discharge connector
Figure 4. Control panel.
Selector Switch A three-position rotary switch selects between three control modes of the PureWave
CES unit:
1. SCADA ENABLE – Fully counter-clockwise position.
2. SCADA DISABLE – Center position.
3. REMOVE FROM SERVICE – Fully clockwise position.
In the “REMOVE FROM SERVICE” control mode, the AC and DC breakers are opened
(if not already open). The inverter is inhibited. The “IN SERVICE” LED is off. The unit
will not respond to local or SCADA real or reactive power commands. If the control is
powered up and communications are functioning, unit status is available through DNP
points to local and/or SCADA applications. The unit will save updates to local and SCADA
commands, but will not respond to them.
When the selector switch is moved from “REMOVE FROM SERVICE” to “SCADA DIS-
ABLE,” the “IN SERVICE” LED is lighted. The unit will respond to local energy dispatch
commands. The unit will save updates to SCADA commands, but will not respond to them.
When the selector switch is moved from “SCADA DISABLE” to “SCADA ENABLE,”
any previously stored SCADA command is initiated (real or reactive power flow in or
out). The “IN SERVICE” LED is lighted. The unit will respond to SCADA energy dispatch
commands. The unit will save updates to local commands, but will not respond to them.
Indicator Lights Five LEDs indicate the status of the PureWave CES unit:
1. SCADA ENABLE – A yellow LED that illuminates when rotary switch is in the “SCADA
ENABLE” position. The unit is in SCADA mode.
2. SCADA DISABLE – A yellow LED that illuminates when rotary switch is in the
“SCADA DISABLE” position. The unit can be operated via the IntelliLink program.
3. IN SERVICE – A green LED that illuminates whenever the rotary switch is not in the
“REMOVE FROM SERVICE” position.
4. ALARM – A red LED that illuminates whenever an alarm or warning is present.
5. DISCHARGE – A red LED that illuminates whenever the discharge connector is
installed.
Controls and Indicators

8S&C Instruction Sheet 658-500
Reset Button The reset button has two functions: resetting alarms and powering down the unit
controls.
The presence of alarms is indicated by the alarm LED. Pressing the reset button (black
push-button) will cause the unit to attempt to reset any active alarms. If all alarms are
successfully cleared, the alarm LED will turn off.
To power down all PureWave CES unit controls, remove the utility source and turn
the selector switch to “REMOVE FROM SERVICE.” Then press and hold the reset button
for 14 seconds.
Hot Start Button If the unit controls are shut down, they may be restarted without the presence of AC
power. The user can provide a “jump start” using a 24-VDC battery connected to the
24-VDC terminals that are located under the selector switch on the control panel (refer
back to Figure 5 for 24-VDC input locations). Then press the hot start button (red push-
button). This action only powers controls for investigation; the system will not power
the load without the utility source present.
Discharge Connector The DC test points and discharge connector are mounted below the selector switch on
the control panel. These are used to discharge the DC bus capacitors and to test to that
a safe voltage level has been reached so that the unit may be serviced. Refer to Figure 5
for location of components to discharge the PureWave CES.
To discharge the DC bus capacitors:
• Place the selector switch in the “REMOVE FROM SERVICE” position.
• Install the DC voltage meter leads in the test points.
• Install the discharge jumper into the discharge connector.
• Observe the DC voltage meters to ensure that the DC bus capacitors discharge below
50 VDC in approximately ve (5) minutes.
Discharge jumper
DC bus test
points
Figure 5. Discharging the PureWave CES.
DANGER
Keep the shorting jumper installed during any service operation. This will discharge the
energy from the electrolytic capacitors.
Failure to install the shorting jumper may result in electric shock from the DC bus.
Controls and Indicators

S&C Instruction Sheet 658-500 9
Controls and Indicators
The DC bus capacitor test points are red, white, and black.
• The black test point is connected to DC (-).
• The white test point is connected to the DC midpoint
• The red test point is connected to DC (+)
Capacitors are connected from DC (+) to midpoint and from DC (-) to midpoint. Use
these test points to monitor the DC bus voltage while the discharge jumper is installed
to verify that the voltage has been discharged to a safe level for entry and service.
Note the locations of the DC test points and the 24-VDC alternate supply points to
avoid confusion.
States Listed in Table 1 are the eight operating states of the PureWave CES. The IntelliLink
program will inform the user what state the system is currently in. Depending on the
alarm condition encountered, the community energy storage system can be in any of
these states. Below is the description of each state.
Table 1. Operating States of the PureWave CES
States Description
Program Reset This state indicates that the program is initialized. This state also only occurs at
power up.
Inhibit This state indicates that there is a problem that needs attention and will affect
the proper operation of the system. The system will stop operating when an
INHIBIT is being displayed on the IntelliLink program. The AC breaker will
remain closed during this state.
Trip Offline This state indicates that there is a severe problem that needs attention and will
affect the proper operation of the system. The system will stop operating when
a TRIP OFFLINE is being displayed on the IntelliLink program. The AC breaker
will be open in this state.
Ready The state indicates that the PureWave CES is ready to protect the load in the
event of a utility disturbance.
VS Run This state indicates that the master control has commanded the PureWave
CES to run. Here, the inverter controls the AC voltage and the PureWave CES
is the power source in the event of a utility power outage.
CS Run This state indicates that the master control has commanded the PureWave
CES to run. Here, the inverter controls the AC current and the PureWave CES
provides the required real or reactive power for power smoothing.
Conserve Energy This state indicates that the battery is reducing power usage to prolong
the ability to run on the battery. This state is entered if the battery energy is
depleted and the utility source voltage is not present.
System Shutdown This state indicates that the battery energy is depleted. The system enters
“shutdown,” which turns the system off. The system will return to the “Ready”
state when the utility source power is restored and the batteries are charged.

10 S&C Instruction Sheet 658-500
Resets In order to clear an alarm condition, the PureWave CES will require a “reset” to set
the unit to the “Ready” state. This enables the community energy storage system to be
ready for another event should one occur. Table 2 lists the three resets available for the
PureWave CES: Auto, Manual, and Self.
Table 2. Reset Types for the PureWave CES
Reset Type Description
Auto This type of reset will automatically be performed until a pre-determined reset
count has been reached.
The alarm is reset up to the limit defined by the Auto Reset TripCountMax
control parameter. When the number of Auto Reset attempts exceeds the
TripCountMax, the system goes to and remains in the ‘Trip Offline’ state until it
is reset manually by the operator.
Each alarm does not have its own Auto Reset Trip Counter. Rather, there
is only one counter, such that Auto Reset attempts from different alarms all
count against the same total. There is also an Auto Reset Trip Reset Timer that
starts counting down from five minutes every time an Auto Reset alarm occurs.
If the timer reaches zero before the maximum number of Auto Reset attempts
is exceeded, the Auto Reset Count is cleared. The Auto Reset Count is not
allowed to persist for more than five minutes.
Manual This type of reset will require a person to use the local user interface, a SCADA
connection, or push the RESET button on the control panel of the PureWave
CES to reset the system.
Self This type of reset will clear alarms when the alarm condition clears. No reset
counter is used.
Alarms The PureWave CES contains an extensive self-diagnosis system. If any abnormal condi-
tion occurs, the system will activate an alarm. Below is a list of alarms categorized by
alarm type. Alarm types are categorized as information, warning, inhibit, isolate, and
trip ofine.
CAUTION
All alarms should be handled by qualified personnel who are knowledgeable in
troubleshooting the PureWave CES. If there are any doubts about how to handle an
alarm event, please contact S&C Electric Company.
Information Statuses
This notication provides the status of the PureWave CES and will not affect the proper
operation of the system. See Table 3 for the listed information statuses.
Table 3. PureWave CES Information Statuses
Alarm Description Reset Type
AcBreakerOpenCmd Indicates that the AC breaker has been
commanded open.
SELF
AutoReset Indicates that the inverter is resetting the
problem.
SELF
BatteryAuxChargeActive Indicates that the battery auxiliary charger (if
present) is active.
SELF
BatteryInLowPowerMode Indicates that the battery is in low power
mode. Verify that the unit is not In Conserve
Energy mode.
SELF
BatteryModuleComms Indicates that the management system in the
battery lost communication with one or more
modules.
SELF
BatteryReqSocRecalcByCharge Indicates that the battery has requested a
recalculation of its state of charge by charging
the battery to the top of charge.
SELF
BatteryReqSocRecalcByDischarge Indicates that the battery has requested
a recalculation of its state of charge by
discharging the battery to the bottom of
charge.
SELF
TABLE CONTINUED ▶
Controls and Indicators

S&C Instruction Sheet 658-500 11
Controls and Indicators
Table 3. PureWave CES Information Statuses—continued
Alarm Description Reset Type
DcContactorOpenCmd Indicates that the DC breaker has been
commanded open.
SELF
EmergencyVoltageRegEnabled Indicates that the autonomous voltage
regulation using reactive power is enabled on
the unit. The PureWave CES may generate
reactive power based on the measured
voltage.
SELF
InverterLimitedByBatteryLimits Indicates that the inverter is limited by the
battery output.
SELF
InverterLimitedByLocalLoadControl Indicates that the inverter is controlled by the
local load.
SELF
InverterOutputLimited Indicates that the inverter output is limited.
Reduce the load.
SELF
IslandingInhibited Indicates that the PureWave CES been
inhibited to island.
SELF
IslandingRequested Indicates that the PureWave CES has been
requested to island.
SELF
LocalLoadControlEnabled Indicates that the PureWave CES is in SCADA
DISABLE mode.
SELF
ManualReset Indicates that the inverter has been reset
manually.
SELF
McuExecutionInterrupted Indicates an issue occurred in the execution
on the communication processor.
MANUAL
McuMediaStorageCapacity Indicates that the internal compact flash card
is at its capacity.
SELF
PowerOverVarsMode Indicates that the PureWave CES is
configured to give preference to power over
VARs, when approaching the system rating.
SELF
PowerScheduleMode Indicates that the PureWave CES is operating
in a power scheduling mode.
SELF
PowerSetpointRegulationMode Indicates that the PureWave CES is operating
in a power setpoint regulation mode.
SELF
PowerSmoothingMode Indicates that the PureWave CES is operating
in a power smoothing mode.
SELF
VarSetpointRegulationMode Indicates that the PureWave CES is operating
in a reactive power setpoint regulation mode.
SELF
VoltageSetpointRegulationMode Indicates that the PureWave CES is operating
in a voltage regulation mode.
SELF
VsReturnDelayActive Indicates that the PureWave CES is in the
process of returning to a grid connected mode
of operation.
SELF
Warning Alarms
This type of alarm indicates a problem that may need attention but will not affect the
proper operation of the system. The system will continue to operate when a “warning”
is being displayed. See Table 4 for the listed warning alarms.
Table 4. PureWave CES Warning Alarms
Alarm Description Reset Type
AutoResetLockout Indicates that the Auto Reset counter has
been exceeded.
MANUAL
BatteryCellOverTemperature Indicates that the battery cell has gotten too
hot.
SELF
BatteryCellOverVoltage Indicates that the battery cell has over-
charged.
SELF
TABLE CONTINUED ▶

12 S&C Instruction Sheet 658-500
Table 4. PureWave CES Warning Alarms—continued
Alarm Description Reset Type
BatteryCellUnderTemperature Indicates that the battery cell has gotten too
cold.
SELF
BatteryCellUnderVoltage Indicates that the battery cell has drained to a
very low level.
SELF
BatteryDetectedWater Indicates that the battery detected water in the
container.
SELF
BatteryMaintenanceRequired Indicates that the battery requires
maintenance. Please contact S&C Electric
Company.
SELF
BatteryOverCurrent Indicates that more current was flowing into or
out of the battery than the battery allowed.
SELF
BatteryRequestsShutdown Indicates that the battery is requesting to shut
down.
SELF
ConserveEnergyModeActive Indicates that the PureWave CES is in
conserve energy mode.
SELF
DcLinkDissipatorInstalled Indicates that the DC jumper is installed.
When safe to do so, remove it from the control
panel.
SELF
EmergencyVoltageRegulation Indicates that the inverter is generating
reactive power to correct the line voltage.
SELF
IgbtOverTempWarningLine1 Indicates that IGBT on line 1 is too hot. SELF
IgbtOverTempWarningLine2 Indicates that IGBT on line 2 is too hot. SELF
InverterCurrentLimitLine1 Indicates that the inverter is working at its limit
on line 1.
SELF
InverterCurrentLimitLine2 Indicates that the inverter is working at its limit
on line 2.
SELF
IoDeviceCommsLoss Indicates that the PureWave CES is
experiencing loss of communications.
SELF
MaintenanceChargeOrDischarge Indicates that the PureWave CES is providing
a maintenance charge or discharge to the
battery.
SELF
McuMediaInitFailure Indicates that the internal compact flash card
did not initialize properly. Please contact S&C
Electric Company.
SELF
McuMediaOperationFailure Indicates that the internal flash card had an
internal anomaly. Please contact S&C Electric
Company.
SELF
McuMediaUnavailable Indicates that the internal flash card is not
available for logging. Please contact S&C
Electric Company.
SELF
MisconfiguredSchedule Indicates that the PureWave CES has an
improper schedule configuration.
SELF
ScadaCommError Indicates that there is a problem with the radio
or hardwired SCADA communications.
SELF
TotalSystemShutdownImminent Indicates that the PureWave CES is about
to enter system shutdown after being in the
Conserve Energy state too long.
SELF
Controls and Indicators

S&C Instruction Sheet 658-500 13
Controls and Indicators
Inhibit Alarms
This type of alarm indicates a problem that needs attention and will affect the proper
operation of the system. The inverter will stop operating when an “inhibit” is being dis-
played. The DC breaker and AC breaker will remain closed. See Table 5 for the listed
inhibit alarms.
Table 5. PureWave CES Inhibit Alarms
Alarm Description Reset Type
AcBreakerUnsucccessfulClose Indicates that the AC breaker did not close as
expected.
MANUAL
AcBreakerUnsuccessfulOpen Indicates that the AC breaker did not open as
expected.
MANUAL
AllPhaseLegsTripped Indicates there is a serious alarm present on
both phases of the PureWave CES output.
SELF
AnyAppBoardPowerSupplyUV Indicates that the application board power
supply is below the required voltage value.
AUTO
DcBreakerUnsuccessfulOpen Indicates that the DC breaker did not open as
expected.
MANUAL
DischargeLimitInVsExceeded Indicates that there is too much load on the
PureWave CES.
SELF
DoorOpen Indicates that the access door to the unit is
open.
SELF
DownstreamFault Indicates there is a physical fault on the
network between the PureWave CES and the
load.
SELF
DspFpgaHeartbeatLost Indicates that there is a problem with the
control assembly that will require for it to be
replaced.
MANUAL
ExecutionTimeOverrun Indicates a serious issue with the control
processing of the PureWave CES.
MANUAL
IgbtGateDriveAlarmLine1 Indicates a physical issue with the power
electronics.
AUTO
IgbtGateDriveAlarmLine2 Indicates a physical issue with the power
electronics.
AUTO
IgbtOverTempTripLine1 Indicates that the IGBT on line 1 is too hot. SELF
IgbtOverTempTripLine2 Indicates that the IGBT on line 2 is too hot. SELF
IgbtThermistorBrokenLine1 Indicates that the IGBT on line 1 has a broken
thermistor(s).
SELF
IgbtThermistorBrokenLine2 Indicates that the IGBT on line 2 has a broken
thermistor(s).
SELF
IgbtThermistorShortedLine1 Indicates that the IGBT on line 1 has a
shorted thermistor(s).
SELF
IgbtThermistorShortedLine2 Indicates that the IGBT on line 2 has a
shorted thermistor(s).
SELF
InverterOverCurrentLine1 Indicates that the inverter is working over its
limit on line 1.
AUTO
InverterOverCurrentLine2 Indicates that the inverter is working over its
limit on line 2.
AUTO
TABLE CONTINUED ▶

14 S&C Instruction Sheet 658-500
Table 5. PureWave CES Inhibit Alarms—continued
Alarm Description Reset Type
InverterOverload Indicates that there is too much load on the
inverter.
AUTO
IslandDetectedInCs Indicates that an island was detected while the
PureWave CES was operating in the Current
Source state.
SELF
McuCommsError Indicates that an issue occurred in the
execution on the communication processor.
SELF
OutputFaultInVs Indicates that a fault on the output of the
PureWave CES was detected while operating
in the Voltage Source state.
SELF
OverFrequency Indicates that the PureWave CES is above the
‘over-frequency’ threshold.
SELF
OverVoltage Indicates that the AC connection is above the
‘over-voltage’ threshold.
SELF
ParamCalChangeActivation Indicates that either a configuration parameter
or analog calibration value is being saved and
activated.
SELF
ParamCalNvError Indicates that corrupt memory was found
in the inverter settings that can cause a
malfunction in the inverter.
SELF
SystemInhibit Indicates that the PureWave CES is in the
inhibit state due to user command.
SELF
UdmOverVoltage Indicates that the utility has a disturbance and
an island is needed to continue to supply the
load.
SELF
UdmUnderVoltage Indicates that the utility has a disturbance and
an island is needed to continue to supply the
load.
SELF
UnderFrequency Indicates that the PureWave CES is under the
‘under-frequency’ threshold.
SELF
UnderVoltage Indicates that the AC connection is below the
‘under-voltage’ threshold.
SELF
VeryOverVoltage Indicates that the inverter detects a very high
input voltage.
SELF
VeryUnderFrequency Indicates that the inverter detects a very low
input frequency.
SELF
VeryUnderVoltage Indicates that the inverter detects a very low
input voltage.
SELF
Controls and Indicators

S&C Instruction Sheet 658-500 15
Controls and Indicators
Isolate Alarms
This type of alarm indicates a problem that needs to be addressed and will affect the
proper operation of the system. The system will operate on a limited basis when “iso-
late” is displayed in the IntelliLink program. The inverter is capable of running reactive
power only. See Table 6 for the listed isolate alarms.
Table 6. PureWave CES Isolate Alarms
Alarm Description Reset Type
BatteryAnySystemAlarm Indicates the battery has entered into a
serious alarm state.
MANUAL
BatteryBmsComms Indicates that there is no longer good
communication between the PureWave CES
and the battery. This will cause the PureWave
CES to stop charging and discharging the
battery.
SELF
DcBreakerUnsuccessfulClose Indicates that the DC breaker did not close as
expected.
MANUAL
DcLinkMidpointUnbalanced Indicates the DC link between the PureWave
CES and the battery is no longer adequately
balanced around zero volts.
SELF
DcLinkOV Indicates that the internal DC bus voltage
exceeded the “over-voltage” threshold.
SELF
DcLinkUV Indicates that the internal DC bus voltage is
under the “under-voltage” threshold.
SELF
Trip Offline Alarms
This type of alarm indicates a problem that needs attention and will affect the proper
operation of the system. The system will not operate when a “trip ofine” is being dis-
played in the IntelliLink program. The DC breaker and AC breaker will also open. See
Table 7 for the listed trip ofine alarms.
Table 7. PureWave CES Trip Offline Alarms
Alarm Description Reset Type
ExcessGenerationInVs Indicates that excess power generated by
distributed generation while the PureWave
CES was operating in an island has charged
the battery to its maximum state of charge.
SELF
SystemDisconnect Indicates that the PureWave CES is not
configured for SCADA or local control.
SELF
WaterInPcs Indicates that water has been detected in the
PureWave CES.
AUTO

16 S&C Instruction Sheet 658-500
System Overview The PureWave CES shall function and operate as an intelligent distributed energy
storage system to help utilities meet their rapidly changing Smart Grid challenges. By
positioning discrete amounts of utility-controlled storage where needed throughout
their distribution system, the PureWave CES shall enable utilities to rapidly respond
to changing electricity-use patterns, integrate renewables, manage renewable resource
intermittency, manage peak loads including plug-in electric vehicle loads, and provide
reliable backup power within a fraction of a second for improved power quality. With
the PureWave CES system’s ability to provide high-speed transfer from the grid to bat-
tery power, outages are often barely perceptible to customers.
The PureWave CES is rated at 25 kW/25 kVA. Each PureWave CES unit shall consist of
1) a power conversion system (PCS) suitable for outdoor installation on a user-
furnished concrete pad or the user-furnished box pad, and
2) an energy storage unit consisting of either a select 25-kWh or 50-kWh lithium-
ion battery pack suitable for subsurface installation underneath the PCS, in a
user-furnished concrete vault. The PureWave CES shall be connected to the 120/
240 VAC split-phase secondary of a 25-kVA outdoor utility distribution transformer
(supplied by others) at a frequency either 50 Hz or 60 Hz.
The PCS shall consist of an inverter area housing an AC circuit breaker, an inverter,
user-accessible AC termination area, user-accessible DC termination area, and user-
accessible controls area.
System Design In normal operation, the PureWave CES shall operate in current-source mode, provid-
ing such functionality as voltage regulation, power factor correction, peak shaving, and
load following. If the utility power source is interrupted, the AC breaker in the unit shall
open, isolating and islanding the load from the utility source. The energy storage unit
and inverter shall then power the islanded load for up to either 1 hour with a 25-kWh
battery pack or 2 hours with a 50-kWh battery pack. The energy storage unit will sup-
port the load until utility service is resumed or the energy storage unit of the PureWave
CES is depleted. See Figure 6.
SOURCE LOAD
Source Line 1, 2 Load Line 1, 2
F3
F4
F1
F2
F
DC Contactor M
Battery
Line 1, 2 LD
CT 1, 2
CT 3, 4
CT 5, 6
Normal Control
Power
Battery Source or
Hot Start input
Surge
Arrester
CB 1
Terminal Bay
Inverter
Discharge
Jumper
Control
Power
Supply
PCS
Control
Battery Enclosure
PCS Enclosure
Battery
Management
System
AC
DC
25 kWh or 50 kWh
Figure 6. PureWave CES System one-line diagram.
Operation

S&C Instruction Sheet 658-500 17
Operation
Entering the System
Enclosure WARNING
Do not enter the system enclosure unless trained, certified, and authorized to do so.
Potentially lethal voltages are present inside the system enclosure. High-voltage DC is
present even without the utility power connected.
The enclosure is meant to provide access for field troubleshooting purposes only when
the unit is properly grounded. Never, under any circumstances, open the enclosure doors
on the PureWave CES while it is online or has not been fully discharged and grounded.
The PureWave CES enclosure houses the control, inverter, and cable termination
areas. These areas can be accessed by unlocking all padlocks and opening the doors of
the enclosure using a penta-socket wrench. Location of the door locks and components
are illustrated in the following Figures 7, 8, and 9.
Control
panel Inverter
(inside)
Lock
(front)
Breaker
panel
Figure 7. View of inside the enclosure at the front.
Lock
(back)
DC cable
termination
area
Figure 8. View of inside the enclosure at the back.

18 S&C Instruction Sheet 658-500
Lock
(side)
AC cable
termination
area
Figure 9. View of inside the enclosure at the side.
Energy Storage
System
The energy storage (batteries) component of the PureWave CES shall be designed and
constructed for installation underground in a vault, which shall be located directly
beneath the unit. The batteries shall be contained in a watertight NEMA Type 6P
enclosure, providing protection against water seepage and prolonged submersion at
installation depth. The battery pack shall include a battery monitoring system. See
Figure 10 for illustration. Please refer to the battery manufacturer manual for more
information.
Battery
Figure 10. View of battery enclosure (stored underground).
Operation

S&C Instruction Sheet 658-500 19
Operation
IntelliLink® Remote
Setup Software
Configuration
The operation, control, and monitoring of the PureWave CES is accomplished through
the IntelliLink Remote Setup Software. This program can be accessed via secure Wi-Fi
connection or wide-area network radio using a PC with the IntelliLink software. This
software also works in conjunction with the IntelliTeam Distributed Energy Manage-
ment (DEM) system for PureWave CES eet systems.
Configuring your PC for IntelliLink when onsite:
1. Connect the PC to the Ethernet port as shown in Figure 11.
Ethernet
connection
Ethernet
connection
Figure 11. Ethernet connection location.
2. Turn on the PC and set the computer to the xed IP on the same subnet as the Pure-
Wave CES add-on Ethernet port:
a. IP = 192.168.10.4
b. Mask = 255.255.255.0
c. No gateway
3. Find the IntelliLink icon and double-click on it to access the conguration screen.
The following are the conguration steps to the IntelliLink program. See Figure 12 on
page 20 for location of the elds to enter the data:
a. Destination DNP address = as congured in unit (default = 12)
b. Connection Type = UDP/IP
c. Peer IP = 192.168.10.2
d. Peer port = 20000
e. Our Port = 20001 (if SCADA is used on the same PC in the UDP channel denition,
the value must be different).
f. Click on the “IntelliLink” button to connect.
4. Once connected, the user will be required to enter a login and password for authorized
access to the program.
NOTICE
Login and password information for access to the IntelliLink program can be obtained
from your designated administrator.

20 S&C Instruction Sheet 658-500
Figure 12. Location of data fields for IntelliLink configuration.
IntelliLink Program Once connected and logged into the IntelliLink program, the Operation Status screen
will appear. See Figure 13. This is the default screen, which is found under the “Opera-
tion” menu and “Status” sub-menu.
Figure 13. IntelliLink operation status screen.
Operation
Other manuals for PureWave
2
Table of contents
Other S&C Storage manuals
Popular Storage manuals by other brands

SimpliPhi
SimpliPhi Sol-Ark AccESS installation manual

Seagate
Seagate IRONWOLF ST6000VN0033 product manual

Intellinet
Intellinet 524469 user manual

Cybernetics
Cybernetics V Series CY-miSAN-V Operator's manual

Philips
Philips FM01SW81 Specifications

Qsan Technology
Qsan Technology XCubeNAS XN7004R owner's manual

Sun Microsystems
Sun Microsystems StorEdge N8400 Upgrade guide

ActionTec
ActionTec WNS100 user manual

Overland Tandberg
Overland Tandberg LTO quick start guide

Stonesoft
Stonesoft StoneGate IPS-1205 Appliance installation guide

CD3
CD3 discgear browser 100 instructions

Fujitsu
Fujitsu ETERNUS CS800 Getting started guide
