Sandstrom SDABXCR13 User manual

Instruction Manual
DAB Clock Radio
SDABXCR13
SDABXCR13_IB_160929_will.indd 1 30/9/2016 2:37 PM

Safety Warnings........................................................................... 4
Introduction................................................................................. 7
Unpacking.................................................................................... 8
Controls and Connections........................................................... 9
Front View.................................................................................................................9
Rear View ...............................................................................................................10
Getting Started .......................................................................... 11
Aerial Cable...............................................................................................11
Mains Power .........................................................................................................12
Switching on for the First Time................................................. 13
Switching On........................................................................................................13
Initial Scan ............................................................................................................. 14
Altering the Screen Brightness................................................. 15
Basic Operation ......................................................................... 16
Mode Select .......................................................................................................... 16
Tuning a DAB Station .............................................................................. 16
Secondary Services ............................................................................................ 17
Volume Control....................................................................................................17
Presetting and Recalling a Station........................................... 18
Presetting a Station............................................................................................ 18
Recalling a Preset................................................................................................ 19
Displaying a Station Name ....................................................... 20
DAB Options in the Menu ......................................................... 21
Menu Navigation ................................................................................................22
Full Scan ................................................................................................................. 23
DRC ..........................................................................................................................23
Prune .......................................................................................................................24
Altering the Display Mode...............................................................................25
Contents
SDABXCR13_IB_160929_will.indd 2 30/9/2016 2:37 PM

Organising the Station Order................................................................. 27
FM Reception ............................................................................. 28
Tuning an FM Station ........................................................................................ 28
Manual and Auto Tuning.................................................................................. 28
Scan Option All (DX) or Strong (Local) Stations............................29
Stereo and Mono ................................................................................................30
Choosing and Recalling a Preset Station....................................................30
FM Options in the Menu............................................................ 31
Altering the Display Mode...............................................................................32
Product Settings ........................................................................ 33
Sleep Mode ........................................................................................................... 34
Setting the Alarm................................................................................................ 35
Activating the Alarm.......................................................................................... 38
Snooze ...................................................................................................................38
Disabling the Alarm ........................................................................................... 38
Setting the Time and Date............................................................................... 39
Other Menu Options.................................................................. 41
Language............................................................................................................... 41
Factory Reset ........................................................................................................ 41
Software Version .................................................................................................41
Earphone Listening ................................................................... 42
Connecting and Using Earphones................................................................42
Maintenance .............................................................................. 43
Cleaning the Radio............................................................................................. 43
Troubleshooting ........................................................................ 43
Specications............................................................................. 44
Contents
SDABXCR13_IB_160929_will.indd 3 30/9/2016 2:37 PM

Page 4
• Read all the instructions carefully before using the unit and keep
them for future reference.
• Retain the manual. If you pass the unit onto a third party make sure
to include this manual.
• Check that the voltage marked on the rating label matches your
mains voltage.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any doubt about
it working normally, or if it is damaged in any way - switch o,
withdraw the mains plug and consult your dealer.
Location of Unit
• The unit must be placed on a at, stable surface and should not be
subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces as the unit may
fall o or tip over.
• The mains socket must be located near the unit and should be easily
accessible.
Temperature
• Avoid extreme degrees of temperature, either hot or cold. Place the
unit well away from heat sources such as radiators or gas/electric res.
• Avoid exposure to direct sunlight and other sources of heat.
Naked Flames
• Never place any type of candle or naked ame on the top of or near
the unit.
Moisture
• To reduce the risk of re, electric shock or product damage, do not
expose this unit to rain, moisture, dripping or splashing. Do not
operate the unit with wet hands, near water or other liquid.
• If you spill any liquid into the unit, it can cause serious damage.
Switch it o at the mains immediately. Withdraw the mains plug and
consult your dealer.
Safety Warnings
SDABXCR13_IB_160929_will.indd 4 30/9/2016 2:37 PM

Page 5
Ventilation
• To prevent the risk of electric shock or re hazard due to overheating,
ensure that curtains and other materials do not obstruct the
ventilation vents.
• Do not install or place this unit in a bookcase, built-in cabinet or in
another conned space. Ensure the unit is well ventilated.
Safety
• Always disconnect the unit from the mains supply before
connecting/disconnecting other devices or moving the unit.
• Unplug the unit from the mains socket during a lightning storm.
Mains Adapter
• The mains adapter will continue to draw electricity from the mains
supply when plugged in the mains socket. In the interests of safety
and to avoid unnecessary energy consumption, never leave the
adapter plugged in the mains socket while unattended for long
periods of time. Disconnect the adapter from the power supply.
Use only power supplies listed in the user instructions.
Mains Adapter Cable
• Make sure the unit is not resting on top of the mains adapter cable,
as the weight of the unit may damage the cable and create a safety
hazard.
Interference
• Do not place the unit on or near appliances which may cause
electromagnetic interference. If you do, it may adversely aect the
operating performance of the unit, and cause distorted sound.
Earphones
• Listening to loud sounds for prolonged periods of time
may permanently damage your hearing.
• Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
Safety Warnings
SDABXCR13_IB_160929_will.indd 5 30/9/2016 2:37 PM

Page 6
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated“dangerous voltage” within the unit’s
enclosure that may be of sucient magnitude to constitute a
risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
manual accompanying the unit.
Supervision
• Children should be supervised to ensure that they do not play with
the unit.
• Never let anyone, especially children, push anything into the holes,
slots or any other openings in the case - this could result in a fatal
electric shock.
Service
• To reduce the risk of electric shock, do not remove screws. The
unit does not contain any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may expose dangerous voltages.
Maintenance
• Ensure to unplug the unit from the power supply before cleaning.
• Do not use any type of abrasive pad or abrasive cleaning solutions as
these may damage the unit’s surface.
• Do not use liquids to clean the unit.
Safety Warnings
SDABXCR13_IB_160929_will.indd 6 30/9/2016 2:37 PM

Page 7
Features
• Your radio features both DAB and DAB+ reception and an FM
band for areas that may not have DAB broadcasts.
• Two alarms with independent settings are available.
• The display brightness can be altered or even switched o to suit
your personal taste.
• A headphone jack is provided for personal listening.
Introduction
SDABXCR13_IB_160929_will.indd 7 30/9/2016 2:37 PM

Page 8
• Remove all packaging from the unit.
• Retain the packaging. If you dispose of it please do so according
to local regulations.
• These items are included:
• DAB/FM Clock Radio
• AC Adaptor
DAB/FM Clock Radio
AC Adaptor
Unpacking
SDABXCR13_IB_160929_will.indd 8 30/9/2016 2:37 PM

Page 9
STANDBY
1
2
3
4
1. MODE/MENU Control
Rotate to select DAB/FM mode.
Press to display the menu.
2. VOLUME/STANDBY Control
Rotate to alter the volume.
Press to switch the radio on and o.
3. DISPLAY SCREEN
4. TUNE/SELECT Control
Rotate to tune a station/select a menu item.
Press to conrm a selection.
Controls and Connections - Front View
SDABXCR13_IB_160929_will.indd 9 30/9/2016 2:37 PM

Page 10
5. SNOOZE/DIMMER Button
When the alarm comes on:
Press to delay the alarm (SNOOZE mode).
When the radio is playing or in Standby:
Press to alter screen brightness (high/low)
6. 6V DC Power input
7. Headphone Socket
Connect a pair of earphones for private listening.
8. Aerial Cable
Fully extend and adjust for best reception.
Controls and Connections - Rear View
5
6
7
8
SDABXCR13_IB_160929_will.indd 10 30/9/2016 2:37 PM

Page 11
Aerial Cable
Unwrap and fully extend the aerial cable to its full length.
Getting Started
When you rst tune the radio you may need to change the
aerial’s position to get the best results.
After tuning, if you wish you can x the aerial’s position by
securing the loop at the end of the cable with a suitable xing.
SDABXCR13_IB_160929_will.indd 11 30/9/2016 2:37 PM

Page 12
Mains Power
This unit is designed only to operate with the supplied AC adapter.
Connecting the radio to any other power source may damage it.
• Unwind the AC adapter cable to its full length.
• Connect the plug at the end of the cable to the DC: 6V socket on
the back of the radio.
• Plug the AC adapter into a mains socket and switch the socket
on (if necessary). The unit is now connected and ready to use.
To switch the unit o completely, always unplug the
mains adapter from the mains socket.
Getting Started
SDABXCR13_IB_160929_will.indd 12 30/9/2016 2:37 PM

Page 13
Switching On
• Press VOLUME/STANDBY control to activate the radio.
• Press again to switch the radio o and put it into
Standby mode.
Switching on for the First Time
WARNING- SNOOZE/DIMMER BUTTON
If you accidentally press the SNOOZE/
DIMMER button before you rst
activate the radio (or immediately
after a Factory Reset), you will see this
screen.
This is not a cause for concern. Press the VOLUME/STANDBY
control to activate the radio normally.
AFTER the radio has activated, you can press the
SNOOZE /DIMMER button to vary the screen brightness
level even when the radio is in Standby mode.
STANDBY
STANDBY
SDABXCR13_IB_160929_will.indd 13 30/9/2016 2:37 PM

Page 14
Initial Scan
When your radio is switched on from Standby for the rst time it
will scan the DAB band, searching for usable stations. These will be
stored alpha-numerically. The initial scan will take a few minutes.
During the scan the scan progress will be shown on a bargraph and
the number of stations found will be displayed.
Note: If no stations are found, switch the radio o and move it to
a location with a stronger signal. You may also move the aerial
around. When you switch the radio back on it will automatically
repeat the scan process.
When the scan has completed, the rst station found will play.
The lower line displays the station
name and messages (DLS Text). Other
information can be selected - see Page 24.
Scan
Progress Stations
Found
Signal
Strength/
Radio Mode
The clock time and date are set from DAB
station information. If there are no DAB
stations in your area you can set the clock
manually. Refer to the ‘Setting the Time and
Date’ section.
Switching On For The First Time
SDABXCR13_IB_160929_will.indd 14 30/9/2016 2:37 PM

Page 15
• Press the SNOOZE/DIMMER button to scroll the screen
brightness HIGH/LOW.
• You can alter the screen brightness whether the radio is
operational or in standby mode.
Altering the Screen Brightness
SDABXCR13_IB_160929_will.indd 15 30/9/2016 2:37 PM

Page 16
Mode Select
• Turning the MODE/MENU control switches the radio
between DAB and FM modes.
1. Switch the radio to DAB mode.
The radio will tune to the last station played. The station name will be
briey displayed followed by the station information.
The volume level will display briey at the bottom of the screen.
Tuning a DAB Station
1. Turn the MODE/MENU control to switch the radio to
DAB mode.
2. Turn the TUNE/SELECT dial to browse the DAB station list for the
station you want.
3. Press the TUNE/SELECT dial to select and play the station.
Basic Operation
STANDBY
STANDBY
STANDBY
STANDBY
SDABXCR13_IB_160929_will.indd 16 30/9/2016 2:37 PM

Page 17
Secondary Services
An X symbol after a station name indicates secondary services are
available. These secondary services are related to the primary station
and are inserted directly after the primary station in the station list.
Turn the TUNE/SELECT dial until you nd the service you want, then
press the dial to select it. When the secondary service ends, the unit
will play the content from the primary station.
Volume Control
• Turn the VOLUME/STANDBY control to adjust the volume level.
The volume level will display briey at the bottom of the screen.
STANDBY
Basic Operation
SDABXCR13_IB_160929_will.indd 17 30/9/2016 2:37 PM

Page 18
You can store up to 10 of your favourite stations as presets.
• Presetting a Station
• Tune to the station you want to save. Press MODE/MENU.
The display will show
“RECALL”
Rotate TUNE/SELECT one turn to the right to display “STORE”.
Press TUNE/SELECT to conrm.
The rst preset will
display. If no station
is stored in the preset
“Empty” will display.
If a station is already stored in the preset the station name will display.
Rotate TUNE/SELECT to select a preset location.
Presetting and Recalling a Station
STANDBY
STANDBY
STANDBY
X1
STANDBY
SDABXCR13_IB_160929_will.indd 18 30/9/2016 2:37 PM

Page 19
Press TUNE/SELECT to store the station in the preset location.
Recalling a Preset
1. Press MODE/MENU.
2. Press TUNE/SELECT to conrm. The rst preset will display.
3. Rotate TUNE/SELECT to select a preset station from the list of
stored stations.
4. When the wanted preset station displays, press TUNE/SELECT to
conrm and play the station.
Presetting and Recalling a Station
STANDBY
You can store a station in any preset location. If a station is
stored in a preset location, selecting this location and pressing
TUNE/SELECT will over-write the location with the new station.
The procedure for Presetting and Recalling a
Station is the same for DAB and FM operation.
STANDBY
STANDBY
SDABXCR13_IB_160929_will.indd 19 30/9/2016 2:37 PM

Page 20
The default operating mode shows only station information in a
scrolling line below the time display. Nowhere does the station
name display.
To display the Station Name: (also see Page 26)
• Rotate TUNE/SELECT one stop to the right.
The station will briey show before the display reverts to the previous
state.
Displaying a Station Name
STANDBY
X1
When a menu item is displayed, if you take
no action, the radio will revert to its previous
state after a few seconds without making any
changes.
If you select a menu item and you wish to
cancel, press the MODE/MENU button to exit
without making any changes.
SDABXCR13_IB_160929_will.indd 20 30/9/2016 2:37 PM
