USER GUIDE
mITX-SKL-S-C236
Doc. Rev. 1.6
Doc-ID: 1061-1791

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 2
This page has been intentionally left blank

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 3

MITX
-SKL-S-C236 - USER GUIDE
Disclaimer
Kontron would like to point out that the information contained in this manual may be subject to alteration,
particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee
on the part of Kontron with respect to technical processes described in the manual or any product characteristics
set out in the manual. Kontron assumes no responsibility or liability for the use of the described product(s), conveys
no license or title under any patent, copyright or mask work rights to these products and makes no representations
or warranties that these products are free from patent, copyright or mask work right infringement unless otherwise
specified. Applications that are described in this manual are for illustration purposes only. Kontron makes no
representation or warranty that such application will be suitable for the specified use without further testing or
modification. Kontron expressly informs the user that this manual only contains a general description of processes
and instructions which may not be applicable in every individual case. In cases of doubt, please contact Kontron.
This manual is protected by copyright. All rights are reserved by Kontron. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the
express written permission of Kontron. Kontron points out that the information contained in this manual is
constantly being updated in line with the technical alterations and improvements made by Kontron to the products
and thus this manual only reflects the technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
©2019 by Kontron S&T AG
Kontron S&T AG
Lise-Meitner-Str. 3-5
86156 Augsburg
Germany
www.kontron.com

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 4
Intended Use
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE OR RESALE
FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR COMMUNICATION SYSTEMS FOR
AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE SUPPORT OR LIFE SUSTAINING APPLICATIONS,
WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE
PERFORMANCE, OR IN WHICH THE FAILURE OF PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR
SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK APPLICATIONS").
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at
your risk. To minimize the risks associated with your products and applications, you should provide adequate design
and operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security
related requirements concerning your products. You are responsible to ensure that your systems (and any Kontron
hardware or software components incorporated in your systems) meet all applicable requirements. Unless
otherwise stated in the product documentation, the Kontron device is not provided with error-tolerance capabilities
and cannot therefore be deemed as being engineered, manufactured or setup to be compliant for implementation or
for resale as device in High Risk Applications. All application and safety related information in this document
(including application descriptions, suggested safety measures, suggested Kontron products, and other materials) is
provided for reference only.
Handling and operation of the product is permitted only for trained personnel within a work
place that is access controlled. Please follow the “General Safety Instructions for IT
Equipment” supplied with the system.

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 5
Revision History
Revision Brief Description of Changes Date of Issue Author
1.0 Basic draft 2017-Sept-14 hjs
1.1 BIOS chapter added 2017-Sept-21 hjs
1.2 Typos corrected, block diagram modified 2018-Janu-12 hjs
1.3 Note ATX 12V specification, SPK entry removed, Audio in technical
data changed
2019-May-06 hjs
1.4 Added Caution for Limited Power Source 2020-Jun-17 CW
1.5 Added product variants in Chapter 2.1 and DP connector information 2020-Jul-24 CW
1.6 Modified title photo 2020-Nov-04 hjs
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about
warranty compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-
and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order
Terms & Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit
our website CONTACT US.
Customer Support
Find Kontron contacts by visiting: http://www.kontron.com/support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths
into a services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product
expertise coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace
of mind to build and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron
training academy, and more visit http://www.kontron.com/support-and-services/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the
revised user guide on our website.

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 6
Symbols
The following symbols may be used in this manual
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE indicates a property damage message.
Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60 V) when touching
products or parts of them. Failure to observe the precautions indicated and/or prescribed by
the law may endanger your life/health and/or result in damage to your material.
Please refer also to the "High-Voltage Safety Instructions" portion below in this section.
ESD Sensitive Device!
This symbol and title inform that the electronic boards and their components are sensitive
to static electricity. Care must therefore be taken during all handling operations and
inspections of this product in order to ensure product integrity at all times.
HOT Surface!
Do NOT touch! Allow to cool before servicing.
This symbol indicates general information about the product and the user manual.
This symbol also indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 7
Table of Contents
Symbols .................................................................................................................................................................................................................6
Table of Contents ...............................................................................................................................................................................................7
List of Tables....................................................................................................................................................................................................... 8
List of Figures ..................................................................................................................................................................................................... 8
1/ Introduction..........................................................................................................................................................................................10
2/ Description.............................................................................................................................................................................................11
2.1. Product Variants.........................................................................................................................................................................................11
3/ Installation procedure ......................................................................................................................................................................12
3.1. Packing Check List.....................................................................................................................................................................................12
3.2. Installing the Board .................................................................................................................................................................................12
3.3. Requirements IEC60950-1.....................................................................................................................................................................13
3.4. Lithium battery precautions.................................................................................................................................................................14
4/ System specifications.......................................................................................................................................................................15
4.1. Functional Block Diagram ......................................................................................................................................................................15
4.2. Component Main Data............................................................................................................................................................................16
5/ Jumpers and Connectors .................................................................................................................................................................19
5.1. Hardware Configuration Setting ..........................................................................................................................................................19
5.1.1. Jumpers and Connectors......................................................................................................................................................................19
5.2. Mainboard Placement and Rear I/O locations...............................................................................................................................20
5.3. Rear Side.....................................................................................................................................................................................................22
6/ Pin Definitions.....................................................................................................................................................................................23
6.1. Processor Support...................................................................................................................................................................................24
6.2. System Memory Support......................................................................................................................................................................24
6.3. Ethernet Connectors (I/O area).......................................................................................................................................................... 25
6.4. USB Connectors (I/O area)...................................................................................................................................................................26
6.5. Display Port (DP) V1.2 Connectors (I/O area)................................................................................................................................. 27
6.6. Audio Jack Connectors (I/O area).......................................................................................................................................................28
6.7. Fan Connectors (Internal).....................................................................................................................................................................29
6.8. Front Panel Connector (Internal).......................................................................................................................................................30
6.9. USB1, USB2 (Internal, option) ..............................................................................................................................................................30
6.10. COM1/COM2 external............................................................................................................................................................................31
6.11. Kontron Feature Connector GPIO (Internal) ..................................................................................................................................32
6.12. CMOS1 Jumper (Internal)..................................................................................................................................................................... 33
6.13. Always ON Jumper (Internal).............................................................................................................................................................33
6.14. LCD_PWR1 (Internal) ............................................................................................................................................................................34
6.15. LVDS (internal)........................................................................................................................................................................................34
6.16. SATA (Serial ATA) Disk Interfaces (Internal) ................................................................................................................................ 35
7/ Features and Power Supply...........................................................................................................................................................36
7.1. Onboard Power Supply...........................................................................................................................................................................36
7.2. External Power Supply ..........................................................................................................................................................................36
7.3. Power Management ...............................................................................................................................................................................38
7.4. Real-Time Clock .......................................................................................................................................................................................38
7.5. Trusted Platform Module (TPM) ........................................................................................................................................................38
8/ BIOS Setup structure........................................................................................................................................................................39
8.1. Main Setup Menu .....................................................................................................................................................................................39
8.2. Advanced Setup Menu...........................................................................................................................................................................39
8.3. Chipset Setup Menu................................................................................................................................................................................ 53

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 8
8.4. Security Setup Menu.............................................................................................................................................................................. 78
8.5. Boot Setup Menu.....................................................................................................................................................................................80
8.6. Save & Exit Setup Menu........................................................................................................................................................................80
9/ Technical Support ..............................................................................................................................................................................81
9.1. Warranty......................................................................................................................................................................................................81
9.2. Returning Defective Merchandise ......................................................................................................................................................81
List of Acronyms..............................................................................................................................................................................................83
About Kontron ..................................................................................................................................................................................................84
List of Tables
Table 1: Component Main Data ....................................................................................................................................................................16
Table 2: Environmental Conditions ............................................................................................................................................................18
Table 3: Certification and Compliance Information ..............................................................................................................................18
Table 4: Connector Definitions....................................................................................................................................................................23
Table 5: Processor Support..........................................................................................................................................................................24
Table 6: Memory Support.............................................................................................................................................................................24
Table 7: Ethernet Connector Pin Assignment ........................................................................................................................................ 25
Table 8: Signal Description........................................................................................................................................................................... 25
Table 9: USB 2.0 and 3.0 Connector Pin Assignment........................................................................................................................... 26
Table 10: Signal Description.........................................................................................................................................................................26
Table 11: DP 1.2 Connector Pin Assignment............................................................................................................................................. 27
Table 12: Signal Description.........................................................................................................................................................................28
Table 13: Pin Assignment (Line Out, green) ............................................................................................................................................28
Table 14: Pin Assignment (Line In, blue) ..................................................................................................................................................28
Table 15: Pin Assignment (Mic In, pink) ....................................................................................................................................................28
Table 16: Signal Description.........................................................................................................................................................................28
Table 17: 4-pin Mode Pin Assignment ......................................................................................................................................................29
Table 18: Signal Description.........................................................................................................................................................................29
Table 19: FP Connector Pin Assignment...................................................................................................................................................30
Table 20: USB Internal Connection Pin Assignment ............................................................................................................................30
Table 21: COM1/2 External Connection Pin Assignment .....................................................................................................................31
Table 22: Signal Description .........................................................................................................................................................................31
Table 23: GPIO Pin Assignment...................................................................................................................................................................32
Table 24: CMOS1 Internal Connection Pin Assignment....................................................................................................................... 33
Table 25: Always ON Jumper Pin Assignment........................................................................................................................................ 33
Table 26: LCD_PWR1 Internal Connection Pin Assignment ...............................................................................................................34
Table 27: LVDS Pin Assignment ..................................................................................................................................................................34
Table 28: SATA Pin Assignment.................................................................................................................................................................. 35
Table 29: Signal Description ........................................................................................................................................................................ 35
Table 30: Power States..................................................................................................................................................................................38
Table 31: Main Setup Menu Sub-Screens Functions............................................................................................................................ 39
Table 32: Advanced Setup Menu Sub-Screens and Functions......................................................................................................... 39
Table 33: Chipset Setup Menu Functions ................................................................................................................................................ 53
Table 34: Security Setup Menu Functions...............................................................................................................................................78
Table 35: Boot Priority Order .......................................................................................................................................................................80
Table 36: Save & Exit Setup Menu Functions.........................................................................................................................................80
List of Figures
Figure 1: Functional Block Diagram ............................................................................................................................................................15
Figure 2: Front Side and Interfaces............................................................................................................................................................20
Figure 3: Rear View with Interfaces ...........................................................................................................................................................21
Figure 4: Bottom Side....................................................................................................................................................................................22

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 9
Figure 5: Ethernet Connector....................................................................................................................................................................... 25
Figure 6: USB 2.0 / 3.0 socket......................................................................................................................................................................26
Figure 7: USB 2.0 High Speed Cable...........................................................................................................................................................26
Figure 8: USB 3.0 High Speed Cable........................................................................................................................................................... 27
Figure 9: DP 1.2 Connector ............................................................................................................................................................................ 27
Figure 10: Audio Jack.......................................................................................................................................................................................28
Figure 11: 4-pin Fan Connector....................................................................................................................................................................29
Figure 12: FP Connector .................................................................................................................................................................................30
Figure 13: USB Internal Connector .............................................................................................................................................................30
Figure 14: COM1/2 External Connector .....................................................................................................................................................31
Figure 15: Available Cable Kit (DB9 adapter cables) .............................................................................................................................31
Figure 16: GPIO Internal Connector ............................................................................................................................................................ 32
Figure 17: CMOS1 Jumper............................................................................................................................................................................... 33
Figure 18: Always ON Jumper ...................................................................................................................................................................... 33
Figure 19: LCD_PWR1 Internal Connector ................................................................................................................................................34
Figure 20: LVDS Connector...........................................................................................................................................................................34
Figure 21: SATA Connector............................................................................................................................................................................ 35
Figure 22: Available Cable Kit ...................................................................................................................................................................... 35

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 10
1/ Introduction
This manual describes the Mini ITX Skylake S/C236 board. This board will also be denoted mITX-SKL-S-C236 within
this Users Guide.
The use of this Users Guide implies a basic knowledge of PC hard- and software. This manual is focussed on
describing the mITX-SKL-S-C236 board’s special features and is not intended to be a standard PC textbook.
New users are recommended to study the short installation procedure stated in the following chapter before
switching-on the power.
All configuration and setup of the CPU board is either done automatically or manually by the user via the BIOS setup
menus.
Latest revision of this manual, datasheet, thermal simulations, BIOS, drivers, BSP’s (Board Support Packages) can be
downloaded from Kontron Web Page.

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 11
2/ Description
The mainboard mITX-SKL-S-C236 is based on the Skylake processor family. It uses the Intel Platform Controller Hub
(PCH) C236. This powerful hardware with efficient graphic and network capabilities offers a broad range of
application areas. The processor, graphics and memory controller is built on 22 nm die.
Main characteristics are:
Support Skylake Family Processors LGA1151 CPU Socket (37.5 mm x 37.5 mm)
Range from 35 to 65W TDP
Intel®SKL C236 PCH chipset
2x ECC/NON ECC SODIMM Memory Architecture
Max. three independent displays by Display Port (3x DP) or LVDS
Three Gigabit Ethernet ports
ECC memory optional
Four SATA 3.0 Ports
M.2 and PCIe minicard
Built with these functions, mITX-SKL-S-C236 motherboard is ideal for ATM, automation, Kiosk applications, medical
equipment, industrial automation, financial automation, process control, semiconductor equipment, and network
security markets.
2.1. Product Variants
The mITX-SKL-S-C236 has two product variants depending on the display requirements:

mITX-SKL-S-C236 with 2x DP + 1x LVDS (part number: 810685-4500)

mITX-SKL-S-C236 with 3x DP (part number: 810686-4500)

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 12
3/ Installation procedure
3.1. Packing Check List
The mITX-SKL-S-C236 package includes the following basic items accompany with this manual.
One main board
One IO shield
If any of these items is damaged or missed, please contact your vendor and save all packing materials for future
replacement and maintenance.
The above packing list is for standard single box packing only.
3.2. Installing the Board
ESD Sensitive Device!
Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry.
•Wear ESD-protective clothing and shoes
•Wear an ESD-preventive wrist strap attached to a good earth ground
•Check the resistance value of the wrist strap periodically (OK: 1 MΩto 10 MΩ)
•Transport and store the board in its antistatic bag
•Handle the board at an approved ESD workstation
•Handle the board only by the edges
To get the board running follow these steps. If the board shipped from Kontron has already components like RAM
and CPU cooler mounted, then relevant steps below can be skipped.
Only connect to a power supply delivering the specified input rating and complying with the
requirements of Safety Extra Low Voltage (SELV) and Limited Power Source (L.P.S.) of IEC
60950-1 and the Energy sources (ES1) of IEC 62368-1.
1.
Turn off the PSU (Power Supply Unit)
Turn off PSU (Power Supply Unit) completely (no mains power connected to the PSU)
or leave the Power Connectors unconnected while configuring the board. Otherwise
components (RAM, LAN cards etc.) might get damaged. Make sure to use +12V single supply
only. Alternatively use a standard ATX PSU with suitable cable kit and PS_ON# active.
2.
Insert the DDR4 SO-DIMM 260 pin module(s)
Be careful to push it in the slot(s) before locking the tabs. For a list of approved SO-DIMMs contact your
Distributor or FAE. See also chapter “System Memory Support”. Use SO-DIMM with the same memory density in
both sockets!
3.
Processor installation
Install the processor in the processor connector. Follow the steps in the delivered manual from the processor
manufacturer.
4.
Cooler Installation
You can connect the cooler fan electrically to the FANCPU connector.

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 13
5.
Connecting Interface
s
Insert all external cables for hard disk, keyboard etc. A monitor must be connected in order to change BIOS
settings.
6.
Connect and turn on PSU
Connect PSU to the board by the External Power of ATXPWR (20 poles power plug) and Internal Power of ATX4p
(4 poles power plug) to the I/O Power jack.
7.
Power Button
If the board does not start by itself when switching on the ATX/DC PSU AC mains, then follow these instructions
to start the board. I
8.
BIOS Setup
Enter the BIOS setup by pressing the <F2> key during boot up.
Enter “Exit Menu” and Load Setup Defaults.
Refer to the “BIOS Configuration / Setup“ section of this manual for details on BIOS setup.
To clear all BIOS settings, including Password protection, activate “Load Default BIOS
Settings” Jumper for > 10 sec (without power connected).
9. 156BMounting the board in chassis
When fixing the Motherboard on a chassis it is recommended to use screws with integrated washer and a
diameter of >7 mm. Do not use washers with teeth, as they can damage the PCB and cause short circuits.
When mounting the board to chassis etc. please notice that the board contains components
on both sides of the PCB which can easily be damaged if board is handled without
reasonable care. A damaged component can result in malfunction or no function at all.
Vibration may cause damage to boards
When setting up boards within a system, steps must be taken to reduce the level of
vibration within the system. It is the user’s responsibility to ensure that boards can function
properly in their system.
3.3. Requirements IEC60950-1
Take care when designing chassis interface connectors in order to fulfil the IEC60950-1 standard.
Users of mITX-SKL-S-C236 must evaluate the end product to ensure compliance the requirements of the IEC60950-1
safety standard are met:

The motherboard must be installed in a suitable mechanical, electrical and fire enclosure.

The system in its enclosure must be evaluated for temperature and air flow considerations.

The motherboard must be powered by a CSA or UL approved power supply that limits the maximum input
current to 10 A via external barrel-type 12-24 VDC connector, and to 16 A via internal square 12 VDC ATX
connector.

For interfaces having a power pin such as external power or fan, ensure that the connectors and wires are
suitably rated. All connections from/to the product shall be with SELV circuits only.

Wires have suitable rating to withstand the maximum available power.

The enclosure of the peripheral device fulfils the fire protecting requirements of IEC60950-1.

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 14
3.4. Lithium battery precautions
Danger of explosion if the lithium battery is incorrectly replaced.
•Replace only with the same or equivalent type recommended by the manufacturer
•Dispose of used batteries according to the manufacturer’s instructions
VORSICHT! Explosionsgefahr bei unsachgemäßem Austausch der Batterie.
•Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleichwertigen
Typ
•Entsorgung gebrauchter Batterien nach Angaben des Herstellers
ATTENTION! Risque d'explosion avec l'échange inadéquat de la batterie.
•Remplacement seulement par le même ou un type équivalent recommandé par le
producteur
•L'évacuation des batteries usagées conformément à des indications du fabricant
PRECAUCION! Peligro de explosión si la batería se sustituye incorrectamente.
•Sustituya solamente por el mismo o tipo equivalente recomendado por el fabricante
•Disponga las baterías usadas según las instrucciones del fabricante
ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig håndtering.
•Udskiftning må kun ske med batteri af samme fabrikat og type
•Levér det brugte batteri tilbage til leverandøren.
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri.
•Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten.
•Brukte batterier kasseres i henhold til fabrikantens instruksjoner
VARNING! Explosionsfara vid felaktigt batteribyte.
•Använd samma batterityp eller en ekvivalent typ som rekommenderas av
apparattillverkaren.
•Kassera använt batteri enligt fabrikantens instruktion.
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu.
•Vaihda paristo ainoastaan lalteval- mistajan suosittelemaan tyyppiln
•Hävitä käytetty paristo valmistajan ohjeiden mukaisesti

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 15
4/ System specifications
4.1. Functional Block Diagram
Figure 1: Functional Block Diagram

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 16
4.2. Component Main Data
The table below summarizes the features of the mITX-SKL-S-C236 embedded motherboard.
Table 1: Component Main Data
Motherboard mITX-SKL-S/C236
Form factor Mini ITX (170.18 mm by 170.18 mm)
Processor Onboard CPU variants
Intel® Skylake-S Processor line, LGA1151 CPU Socket (37.5 mm x 37.5 mm)
Range from 68 to 80 W TDP, Core™ i7-6700, Core™ i5-6500, Core™ i3-6100, Xeon®
Processor E3-1225 v5
BIOS AMI UEFI BIOS with128Mb SPI Flash ROM support AMT11.0
PCH Intel®SKL PCH 236 series
I/O Control ITE IT8528E/FX (Kontron EC)
Memory 2x Dual-Channel DDR4 SO-DIMM with ECC, Support DDR4 (1.2 V) 2133 MT/s (PC4-2133),
max. up to 32
GB memory using 2x16 GB modules
Storage 4 x SATA 3.0
Watchdog Timer Reset; 1 sec.~255 min. and 1 sec. or 1 min./step
Wake On Wake on LAN, USB, Power button
Hardware Status
Monitor
Monitoring CPU and system temperature, voltage status and fan speed
TPM Kontron TPM 2.0 support via SPI / USB interface
Power
management
Support S5, S4, S3, S0
Battery CR2032, 220 mAh
See Safety Instructions below this table!
Expansion One PCIe x16 slot (PCIe Gen3), MiniPCIe, M.2
Operating System
Support
Windows Embedded 7,Windows 7, 8.1, 10
Linux Fedora/Yocto
Board support packages in different flavors, downloadable from the web page
External I/O
LAN, USB 3.0/2.0 3x RJ-45 LAN Port (with two LED indicators) + dual USB3.0 + dual USB2.0 (4 x USB)
Audio 3 x Audio Jacks for MIC-input, Line-out and Line-input
Display Port (DP) 3 x Display Port connector Version 1.2
Internal I/O
SATA 4 x SATA3.0 (6
Gb/s)
PC Buzzer Standard PC buzzer on board
USB 2.0 2 x Front Panel Internal Header, supports 2 x USB 2.0
Serial Peripheral
Interface (SPI)
For optional fast General Purpose IO (GPIO) on component side
LVDS 1 x ( 2 x 20 ) 1.25
mm pin-header for 24-bit dual channel with brightness control
Mini PCIe 1 x for half size
Audio 1x 3-pin SPDF and 1x 3-pin Headphone Out
Serial 1 x RS232, 1 x RS485, 2 pairs RS422
Internal Header
Fan Power 2 x (1 x 4 ) 2.54
mm pin-header for CPU & System fan with PWM function

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 17
CMOS Clear 1 x (1 x 3 ) 2
mm pin-header
Front Panel 1 x 24 pin connector
Power COM pin 9 2 x ( 2 x 3 ) 2.0
mm pin-header;
PS/2 1x(2x3) 2.0
mm pin-header (for installing Windows)
Display
Graphics Controller
Intel®Gen 9 LP (generation 9 Low Power) graphics core with three pipes and 72 Execution
Units
Supports DirectX 11,Direct3D* 2015, Direct3D 11.2, Direct3D 11.1, Direct3D 9, Direct3D
10, Direct2D, OpenGL* 5.0,OpenCL* 2.1, OpenCL 2.0, OpenCL 1.2.
Supports full HW accelerated video decoding for AVC/H.264, MPEG2, VC1/WMV9,
VP8, JPEG/MJPEG, HEVC/H265, VP9
Supports full HW accelerated video encoding for H.264, MPEG2, VP8, JPEG,
HEVC/H265m VP9
4k x 2k HDMI and two DisplayPorts (optional 3), LVDS optional
DP to LVDS
Controller
NXP PTN3460
Display Interface 3x Display port 1.2 or
2x Display Ports + 1 x LVDS
Note: Three (3) Independent Displays Max.
Resolution DP/LVDS 4096x2304 @ 60
Hz, 24 bpp (one panel display)
Ethernet
Controller LAN1: Intel® I219LM 10/100/1000 Gigabit Ethernet PHY with AMT11.0
LAN2 and LAN3: Intel® I211AT 10/100/1000 Gigabit Ethernet Controller
Interface IEEE 802.3 10BASE-T / 100BASE-TX / 1000BASE-T compliant
Audio
HDAC Realtek®ALC269Q High Definition Audio Codec
Power Supply
Power Type 4-pin ATX 12V power connector
and :
20-pin ATX Power connector
Danger of explosion if the lithium battery is incorrectly replaced.
•Replace only with the same or equivalent type recommended by the manufacturer
•Dispose of used batteries according to the manufacturer’s instructions

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 18
Table 2: Environmental Conditions
Operating 0°C to +60°C (32°F~140°F) operating temperature (forced cooling).
It is the customer’s responsibility to provide sufficient airflow around each of the
components to keep them within allowed temperature range. Please refer to the thermal
simulation report for information about airflow.
10% to 90% relative humidity (non-condensing)
Storage -20°C~70°C (-4°F~176°F); lower limit of storage temperature is defined by specification
restriction of on-board CR2032 battery.
Board with battery has been verified for storage temperature down to -40 C by Kontron.
Up to 95 % relative humidity (temperature 25°C to 30°C)
Radiated Emissions
(EMI)
All Peripheral interfaces intended for connection to external equipment are EMI protected.
EN 61000-6-4:2007 (EMC) Generic emission standard Part 6-4: Emission standard for
industrial environments
Safety EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011:
Safety for information technology equipment including electrical business equipment
Shock IAW IEC 60068-2-27, Half-sine wave, Acceleration: 2g, Pulse duration: 11ms, number of
shocks: 600 shocks (100 shocks for each face)
Vibration AW IEC 60068-2-64, test Fh, Random Vibration, 90 min per axis, 3 axes at 1.9 grms, with
PSD: 10-20Hz: 0.05 g²/Hz and 20-500Hz:- 3dB/octave.
Restriction of
Hazardous
Substances (RoHS)
All boards in the mITX-SKL family are RoHS compliant
MTBF 15 years
Altitude 2000 m max., optionally 3000m
Table 3: Certification and Compliance Information
UL E147705-A96-UL: Equipment Including Electrical Business Equipment
CE EMC Directive 2014/30/EU
EN55032/EN55024
Low Voltage
Directive
2014/35/EU
FCC FCC 47 CFR Part 15 Subpart B
ANSI C63.4:2014
ISED ICES-003 (Issue 6)
CE EMC EN 55032:2012/AC:2013, Class B
CISPR 32:2012
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 55024:2010 + A1:2015
FCC DoC FCC 47 CFR Part 15 Subpart B
ICES-003 Issue 6-2016
ANSI C63.4-2014

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 19
5/ Jumpers and Connectors
5.1. Hardware Configuration Setting
This chapter gives the definitions and shows the positions of jumpers, headers and connectors. All of the
configuration jumpers on the board are in the proper position. The default settings shipped from factory are marked
with an asterisk (*).
In general, jumpers on the board are used to select options for certain features. Some of the jumpers are designed to
be user-configurable, allowing for system enhancement. The others are for testing purpose only and should not be
altered. To select any option, cover the jumper cap over (SHORT) or remove (NC) it from the jumper pins according to
the following instructions. Here, NC stands for “Not Connect”.
5.1.1. Jumpers and Connectors
Jumpers Function Remark
CLR_CMOS1 Clear CMOS 1 x 3 header
PWRBTN_N Power On Button 1 x 3 header
Connectors Function Remark
CPU_FAN1 CPU FAN Connector 1 x 4 wafer
SYS_FAN1 SYS FAN Connector 1 x 4 wafer
FP1 Front Panel Connector 2 x 12 header
USB2_P1 USB 2.0 Connector 2 x 5 header
USB2_P3 USB 2.0 Connector 2 x 5 header
USB2_P4 USB 2.0 Connector 2 x 5 header
USB2_P5 USB 2.0 Connector 2 x 5 header
USB2_P6 USB 2.0 Connector 2 x 5 header
USB3_P1 USB 3.0 Connector 2 x 5 header
USB3_P3 USB 3.0 Connector 2 x 5 header
USB3_P4 USB 3.0 Connector 2 x 5 header
SPKR Speaker Connector 1 x 4 wafer
GPIO GPIO Port Connector 2 x 5 box header
LCD_BKL LCD Backlight Connector 1 x 5 wafer
LVDS LVDS Connector 2 x 20 connector
ATX ATX Power Connector 2 x 10 Connector
PWR_CPU1 CPU Power Connector 2 x 2 Connector
MINI-PCIE Mini PCIe Connector 2 x 26 Connector
PCIEx16X PCIe x16 Connector 1 x
SPI_SOCKET Bios Socket 2 x 12 connector
SATA1 SATA3.0 Connector Standard
SATA2 SATA3.0 Connector Standard
SATA3 SATA3.0 Connector Standard
SATA4 SATA3.0 Connector Standard
BAT54 Battery Socket CR2032 compatible
DIMM1 Memory Socket Slot
DIMM2 Memory Socket Slot

mITX-SKL-S-C236 Doc. Rev. 1.6
www.kontron.com // 20
5.2. Mainboard Placement and Rear I/O locations
Figure 2: Front Side and Interfaces
Figure 2 shows the mITX-SKL-S-C236 variant with three display ports
1ATX 12 V power interface
2SATA connector
3Battery holder
4Memory socket
5CPU socket
6Buzzer
7PCIe x16 connector
8LVDS Connector
9 ATX-4-pin Power connector
10 LPC1 Bus
11 Sys-Fan
12 Com1
13 Com2
14 PCH chip heatsink
15 GPIO feature connector
16 Front Panel Connector
10
9
8
7
15
14
13
11
12
654
3
2
1
16
