Kontron mITX-CFL-S - Quick Installation Guide - Version 2.0 - P/N: 0D2MITXCLS020000 // 1

m
ITX-CFL-S - QUICK INSTALLATION GUIDE
Thank you for purchasing the Kontron mITX-CFL-S embedded board. This document provides information to allow you
to quickly install this product.
Packing Checklist
1. Take the mITX-CFL-S out of the packing box and check if the unit is properly secure in the plastic bag.
2. Check the contents of the carton box: (*: optional)
mITX-CFL-S main board
I/O Shield
Quick Installation Guide
USB 2.0 Cable*
COM Port Cable*
DIO Cable*
SATA Cable*
SATA Power Cable*
Audio Cable*
DC Jack Cable*

Kontron mITX-CFL-S - Quick Installation Guide - Version 2.0 - P/N: 0D2MITXCLS020000 // 2
Top Side Jumper and Internal Connector Locations
Jumper List
Item Designation Description
1 JP2 ME F/W Selection
2 JP4 Backlight Power Enable Selection for eDP1
3 JP5 AT / ATX Power Mode Selection
4 JP7 RTC Reset Selection
5 JP8 Pin-9 Selection for COM2
6 JP9 Panel & Backlight Power Selection for eDP1
7 JP10 Pin-9 Selection for COM1
8 JP11 PCIE Configuration Setting for PEG1
9 JP13 USB Power Selection
10 JP14 M.2 Key B Function Selection
1
4
3
5
6
7
2
9
10
11
12
14
13
15
16
17
8
18
19
20
21
22
23
25
26
27
24
28
29
30
31
32
33
34
35
36

Kontron mITX-CFL-S - Quick Installation Guide - Version 2.0 - P/N: 0D2MITXCLS020000 // 3
Internal Connector List
Item Designation Description
11 ATX1 2x4-pin ATX Power Supply Wafer
12 BAT1 CR2032 Battery Power Input Wafer
13 CN1 USB2.0 Port 13, 14 Pin Header
14 CN2 USB2.0 Port 7, 8 Pin Header
15 CN3 RS-232/422/485 Port 4 Wafer
16 CN4 RS-232/422/485 Port 3 Wafer
17 CN6 SPDIF-Out Pin Header
18 CN7 8-bit Digital Input / Output Pin Header
19 CN11 Front Panel Audio Pin Header
20 CN14 M.2 Key A Activity LED Indication Pin Header
21 CN15 M.2 Key B Activity LED Indication Pin Header
22 CN16 M.2 Key M Activity LED Indication Pin Header
23 M2A1 M.2 Key A Slot
24 M2B1 M.2 Key B Slot
25 M2M1 M.2 Key M Slot (only support PCIe)
26 FAN1 System FAN Wafer
27 FAN2 CPU FAN Wafer
28 FP1 Front Panel Pin Header 1
29 FP2 Front Panel Pin Header 2
30 PEG1 PCIEx16 Slot
31 CN17 HDD Power Wafer
32 SATA1 Serial ATA Port-0 Connector
33 SATA2 Serial ATA Port-1 Connector
34 DIMM1 DDR4 Memory U-DIMM Socket
35 DIMM2 DDR4 Memory U-DIMM Socket
36 SIM1 Micro SIM Interface Slot for M.2 Key B

Kontron mITX-CFL-S - Quick Installation Guide - Version 2.0 - P/N: 0D2MITXCLS020000 // 4
Bottom Side Internal Connector Locations
Internal Connector List
Item Designation Description
1 EDP1 eDP Connector
Jumper Settings
ME F/W Selection (JP2)
Jumper 1 Position Description
Pin 1-2 Pin 2-3
X - Security Measures Defined are Set (Default)
- X Security Measures Defined by BIOS are Over-written
“X” = Jumper set (short) and “-” = jumper not set (open)
2
3
1
1

Kontron mITX-CFL-S - Quick Installation Guide - Version 2.0 - P/N: 0D2MITXCLS020000 // 5
Backlight Power Enable Selection for eDP1 (JP4)
Jumper 1 Position Description
Pin 1-3 Pin 3-5
X - Backlight Enable Voltage = +3.3V
- X Backlight Enable Voltage = +5V
Jumper 2 Position Description
Pin 2-4 Pin 4-6
X - Active High
- X Active Low
“X” = Jumper set (short) and “-” = jumper not set (open)
AT / ATX Power Mode Selection (JP5)
Jumper 1 Position Description
Pin 1-2 Pin 2-3
X - ATX Mode
- X AT Mode
“X” = Jumper set (short) and “-” = jumper not set (open)
RTC Reset Selection (JP7)
Jumper 1 Position Description
Pin 1-2 Pin 2-3
X - Normal (default position)
- X Clear RTC CMOS (board does not boot with the jumper in this position)
“X” = Jumper set (short) and “-” = jumper not set (open)
2
1
65
2
3
1
2
3
1

Kontron mITX-CFL-S - Quick Installation Guide - Version 2.0 - P/N: 0D2MITXCLS020000 // 6
Pin-9 Selection for COM2 (JP8)
Jumper Position Description
Pin 1-2 Pin 2-3 Pin 3-4 Pin 4-5
X - - - COM2, Pin-9 = +12V
- X - - COM2, Pin-9 = +5V
- - X - COM2, Pin-9 = +5V
- - - X COM2, Pin-9 = RI
“X” = Jumper set (short) and “-” = jumper not set (open)
Panel & Backlight Power Selection for eDP1 (JP9)
Jumper 1 Position Description
Pin 1-3 Pin 3-5
X - Backlight Power = +12V
- X Backlight Power = +5V
Jumper 2 Position Description
Pin 2-4 Pin 4-6
X - Panel Power = +3.3V
- X Panel Power = +5V
“X” = Jumper set (short) and “-” = jumper not set (open)
2
1
65

Kontron mITX-CFL-S - Quick Installation Guide - Version 2.0 - P/N: 0D2MITXCLS020000 // 7
Pin-9 Selection for COM1 (JP10)
Jumper Position Description
Pin 1-2 Pin 2-3 Pin 3-4 Pin 4-5
X - - - COM1, Pin-9 = +12V
- X - - COM1, Pin-9 = +5V
- - X - COM1, Pin-9 = +5V
- - - X COM1, Pin-9 = RI
“X” = Jumper set (short) and “-” = jumper not set (open)
PCIE Configuration Setting for PEG1 (JP11)
Jumper 1 Position Jumper 2 Position Description
Pin 1-3 Pin 3-5 Pin 2-4 Pin 4-6
X - X - x16
X - - X N/A
- X X - x8 x8
- X - X X8 x4 x4
“X” = Jumper set (short) and “-” = jumper not set (open)
USB Power Selection (JP13)
Jumper 1 Position Description
Pin 1-2 Pin 2-3
X - USB Power is always support
- X USB Power is only S3 support
“X” = Jumper set (short) and “-” = jumper not set (open)
2
1
65
2
3
1

Kontron mITX-CFL-S - Quick Installation Guide - Version 2.0 - P/N: 0D2MITXCLS020000 // 8
M.2 Key B Function Selection (JP14)
Jumper 1 Position Description
Pin 1-2 Pin 2-3
X - SATA
- X PCIE
“X” = Jumper set (short) and “-” = jumper not set (open)
Real I/O Panel Connector Locations
Item Designation Description
1 CN8 GbE LAN1 & USB3.1 Port-1, 2 Connector
2 CN9 GbE LAN2 & USB3.1 Port-3, 4 Connector
3 CN10 GbE LAN3 & USB3.1 Port-5, 6 Connector
4 HDMI1 HDMI 1.4 Connector
5 CN13TOP RS-232/422/485 COM2 Connector
6 CN13BOT RS-232/422/485 COM1 Connector
7 CN12TOP Display Port A Connector
8 CN12BOT Display Port B Connector
2
3
1
6
1
4
8
5
7
2
3
