Sangamo CHOICE PR1 User manual

CHOICE PR1
1 Channel Programmer
User Instructions
Introduction
What is a central heating programmer...?
Central Heating programmers allow you to set ‘On’
and ‘Off’ time periods for your heating and/or hot
water. One Channel models switch your central heating
and domestic hot water on and off at the same time,
while the two and three channel versions control your
domestic hot water and heating to come on and go
off at different times. Three channel programmers
are often used to provide separate control for two
heating zones (perhaps upstairs and downstairs)
as well as the separate control for your hot water.
Sangamo Choice programmers make it easy to set the
‘On’ and ‘Off’ time periods to suit your own lifestyle, with
options for; 7 day, 5/2 day, and 24 hour programming.
You can also choose to have your heating and hot water on
continuously or be permanently off. Choice programmers
also adjust automatically between Greenwich Mean Time
and British Summer Time. The Choice programmers even
have a default set of programmes, so you can decide
not to adjust the programming at all! And to improve
your comfort, you can temporarily adjust the heating
programme, with the Choice; ‘Advance’ or ‘Boost’ buttons.
Programmer Summary
This programmer can automatically switch your central
heating or hot water ON and OFF up to 3 times a
day, at whatever times you choose. Timekeeping is
maintained through power interruptions by a non-
replaceable battery designed to last for the lifetime
of the programmer. The clock is automatically put
forward 1 hour at 1:00am on the last Sunday of March
and back 1 hour at 2:00am on the last Sunday of
October. The clock is factory pre-set to UK time and date,
but you can alter the time setting if you wish.
During installation, the installer selects 24 hour, or 5 day/
2day, or 7 day programming and 2 or 3 on/off periods per
day, via a 4 position DIP switch on the back of the unit
(see installation instructions).
IMPORTANT: These settings should only be changed
by a qualied person. Contact your installer.
IMPORTANT: This programmer is not suitable for
the switching of devices greater than 6Amp rated.
(e.g. Not suitable for use as an immersion timer)
The large, easy to read display makes programming easy
and the unit is designed to eliminate the possibility of ac-
cidental changes to your programme. Buttons normally
visible only affect your set programme temporarily. All
buttons which can permanently change your programme
are located behind the ip-over fascia.
• The 24 hour programmer option runs the same
programme every day.
• The 5 day/2 day programmer option allows differ-
ent ON/OFF times at week ends.
• The 7 day programmer option allows different ON/
OFF times for each day of the week
Conguration
When setting time, date or changing programme times
the rst screen displayed indicates the conguration as
set up by the installer. (See SETTING THE TIME section)
Conguration Display
2 ON/OFF Pumped System 2PU
3 ON/OFF Pumped System 3PU
The 24 hour, or 5 day/2day, or 7 day programming option
as set up by the installer can also be veried at this stage
by how the Monday to Sunday indicators are displayed.
Programming
Option
Mon to Sun Indicators
ash
7 DAY Mon to Sun individually shown
5/2 DAY Mon to Fri together then Sat
& Sun together
24 HOUR Mon to Sun together shown
Now press any button to move to Setting the Time and
Day.
Built In Programme
For convenience, the programmer has a built in
programme which will be satisfactory for many people, but
which can be changed very easily (see section CHANGING
PROGRAMME TIMES). Once the unit is powered up this
built in programme will run.
If the user changes from the built in programme and
wishes to return to it, then pressing the reset button with
a non metallic pointed tool will return the unit to the built
in / default programme. NOTE: Every time the reset is
pressed, the time and date must be set again. See
the sections SETTING THE TIME & SETTING THE DATE
Factory Programme Settings
2Pu 3Pu Mon-Fri Sat-Sun
1st ON 1st ON 6:00am 7:00am
1st OFF 1st OFF 8:30am 9:00am
- 2nd ON 12:00 noon 12:00 noon
- 2nd OFF 12:00 noon 12:00 noon
2nd ON 3rd ON 4:30pm 4:30pm
2nd OFF 3rd OFF 10:30pm 11:00pm
If the unit is installed as a 24 hour programmer the built
in programme will be the same for each day (i.e. Sat-Sun
be same as Mon-Fri above).
Selecting Operating Mode
MODE
ON Central Heating and Hot Water is ON
continuously
AUTO Central Heating and Hot Water will be
switched ON or OFF as programmed
ALL DAY Central Heating and Hot Water will be
switched ON only once each day between
the rst ON time and last OFF time
OFF Central Heating and Hot Water is OFF
continuously
• Press the SET button once. The conguration setting
will appear on the screen.
• Press the SET button again. The clock icon [1] on the
screen will ash.
• Press the +/- buttons to adjust the time. Time will
change quicker if pressed continually.
• Press SET once to move on to setting the DATE or press
multiple times to return to RUN mode.
Setting The Time
[2]
[4]
[1]
[3]
[5]
• Press the SET button until the Y:XX icon (year) ap-
pears and the D (DATE) icon [2] ashes.
• Press the +/- button to set the year.
• Press NEXT button. M:XX appears (month).
• Press +/- button to set month.
• Press NEXT button. D:XX appears (Day).
• Press +/- button to set day.
You can review or edit the date you have set just by
pressing NEXT button again and repeating the sequence
above. To conrm the date and move on to PROGRAM
mode press SET button once or press SET button multiple
times to return to RUN mode.
Setting The Date
Changing Programme Times
The built in programmes can easily be changed to better
suit your lifestyle.
To change the times:
• Press SET button until PROGRAM [3] ashes in the
display and 1 ON [4] appears. This indicates the time
shown on the display is the rst ON time.
• By pressing the +/- buttons you can alter the ON time
[6]
Fit & forget...

If the unit is installed as a 24 hour programmer, the built
in programme will be the same for each day. The COPY
& DAY buttons have no affect if installed as a 24 hour
programmer.
SERVICE AND WARRANTY
Your product is not user serviceable. PLEASE DO NOT TRY TO DISMANTLE THE UNIT.
This product is guaranteed by your supplier for 5 years from the date of manufacture. If it should become
defective please contact your installer or supplier for a replacement unit or visit www.sangamo.co.uk/returns
This product must meet Waste Electronic and Electrical Equipment Regulations (WEEE) for suitable environmental
recycling, recovery and/or disposal. End of life products should be handled in line with local regulations.
Alternatively return end of life product to Sangamo for correct disposal.
CUSTOMER CARE POLICY
As part of Sangamo’s continuous improvement program, the company operates a Customer Care policy. This
means we welcome your comments and complaints, as it can help us to improve our services to you, our
customer.
Due to our policy of continuous product improvement and development, the specications in this guide may be
subject to change without prior notice.
Sangamo Limited
Industrial Estate, Port Glasgow,
Renfrewshire, PA14 5XG
Tel 01475 745131
Fax: 01475 744567
Email: [email protected]
Web: www.sangamo.co.uk
WEE/JH0069TY143701 Issue B
24 Hour Programmer Option
Programming Notes
The unit will automatically return to RUN mode if a period
of 5 minutes passes without any buttons being pressed.
For convenience, to allow for programmes to go past
midnight, the programme day is from 03:00am to
02:50am the next day.
If a programme is required to run from 1.00 am to
8.00 am then 2 programmes must be used because it
is not possible to programme through 2.50 am. (The
programme should be split up into two sections; 3.00
am > 8.00 am and 1.00 am > 2.50 am).
Reset
Press the reset button with a non-metallic pointed tool to
restore the built in programme. As well as restoring the built
in programme, it also resets the time to 12:00pm and the date
to 01/01/2000. Initially the display shows all segments lit for a
few seconds, but then will show the current conguration. See
SETTING THE TIME section to continue.
As a safety feature after reset the unit will be in OFF operating
mode. Reselect your required operating mode,
7 Day Programmer Option
If the unit is installed as a 7 day programmer, the initial
programme displayed will be for
Monday.
You can go to any date of the week by pressing the DAY
button repeatedly.
The ON/OFF times can be changed for each day as
described above in the section “CHANGING PROGRAMME
TIMES”.
If you press the COPY button, the current programme
will be copied onto the next day.
NOTE: it is not possible to copy Sunday to Monday.
5/2 Day Programmer Option
If the unit is installed as a 5 day/2 day programmer, the
initial programme displayed will be for Monday to Friday.
Pressing the DAY button will take you to the programme
for Saturday and Sunday.
The ON/OFF times can be changed for each day group as
described above in the section “CHANGING PROGRAMME
TIMES”.
If you press COPY button, the current programme will be
copied onto the next day group.
Using Advance
The ADVANCE function allows the user to move to the
next ON or OFF programme for a “one off” event, without
having to change the programme or use the ON or OFF
buttons.
Warning: The ADVANCE function is only available when
programme is in AUTO or ALL DAY operating modes.
To advance Central Heating
Press the ADV button. This will turn the Central heating
ON if it is in an OFF period and OFF if it is in an ON
period. It will stay in this state until either ADV button
is pressed again, or until a programmed ON/OFF period
commences. The word ADV [5] will appear in the top left
hand corner of the LCD.
Using +HR Boost
Press the +HR button to make the desired selection with
one, two or three hours extra heating [6] and cancel
options offered.
Warning: The +HOUR function is only available when
programme is in AUTO , ALL DAY or OFF operating
modes.
If the Central heating operating mode is OFF, then it will
switch on for the extra hours selected. If the Central
heating mode is AUTO or ALL DAY, then during an OFF
period, it will switch on for the extra hours selected. If
during an ON period, then it will temporarily extend that
programme by the number of hours selected, this is
displayed on the right of the LCD display [6].
NOTE: If the programmer is in the OFF mode and then
+HR button is pressed (+1 HR, + 2 HR, or + 3 HR)
and the resulting time of the boost overlaps a START /
ON time in the AUTO mode programme memory then
Power Interruption
In the event of a mains supply failure the screen will
go blank but the back-up battery ensures that the
programmer continues to keep the time and retain your
stored programme. When power is restored, if there has
been no change to the rear DIP switch, the programmer
then goes to RUN mode.
If the conguration setting on the rear DIP switch has
been altered during the power interruption the screen
will initially show the new conguration. And the
appropriate factory default programme (see BUILT IN
PROGRAMME section) will be installed.
Press SET button to return to RUN mode.
to the time you want.
• Press NEXT button, display will now show 1 OFF [4].
• By pressing the +/- buttons you can alter the OFF
time to the time you want.
• Press NEXT button to access remaining ON/OFF
periods and alter in same manner as above.
• To return to RUN mode, press the SET button until the
display indicates RUN on the display
NOTE: Programming is in 10 minute segments.
NOTE: Use of excessive force may result in the reset button
sticking behind the front cover of the programmer. If this happens
the unit will “freeze” - and the button can only be released by a
qualied installer
the boost will disengage. If this happens simply press
+HR button again and the boost will activate for the time
period chosen.
[2]
[4]
[1]
[3]
[5] [6]
If you have a problem or require
any further information please
contact our technical team on:
01475 745131
Popular Network Router manuals by other brands

Frymaster
Frymaster 3000 Operation manual

RouterBOARD
RouterBOARD OmniTik UPA-5HnD Quick setup guide and warranty information

D-Link
D-Link DSL-2642B user manual

Zte
Zte ZXR10 ZSR Hardware installation manual

Bicom Systems
Bicom Systems officeBOX M1000 installation guide

D-Link
D-Link DIR-615 - Wireless N Router Quick install guide
