Sanipex BAGNODESIGN BDB-DRE-830-WH User manual

www.sanipexgroup.com
BDB-DRE-830-WH
DREAM S CORNER INSET BATHTUB 1350X1350X520 MM

IMPORTANT PLEASE READ
 B 
 

 






 L  C 



 x 
           
          
 








 

 







Laguna Corner Bath Installation Instructions
Before you start
•Before fixing remove ALL protective covering and examine carefully. The
polythene film must be removed in full and the bath checked for any visible
damage.
• Unpack and check the product is complete and undamaged.
•Have the correct tools available.
•Please notify the retailer immediately of any damage or faults. The
manufacturer cannot be held responsible for any installation costs that may
arise from damaged or faulty product being installed. The guarantee does
not cover impact related damage. Please dispose of all packaging with due
regard to the environment.
Safety
•Handle the bath with care.
•This product is heavy and requires two persons to carry.
•When drilling walls, check first for hidden pipes and cables.
•Use safety eyewear when drilling.
•Keep small parts away from children.
Tools required
Spirit Level
Spanners (17mm &
19mm)
Drill
Pozi Screwdriver
Pencil
Appropriate Drill Bit
Tape Measure
Junior Hacksaw
Sealant Gun &
Sealant
•Tools shown not supplied
•Ensure drill bit used is suitable for wall surface!

Parts Provided
500mm
Channels x2
Wall Fixing Brackets x4
M10 x 250mm Centre
Foot x2
M12 x 65mm Plastic Foot x6
M12 x 120mm
Allthreads x 6
M10 Nuts x 2
1 2 3
4 5 6
789
M12 Nuts x 18
16mm Self Tapping
Screws x40
Panel Clips x8
10
400mm Jack Leg x2
11
C Channel Metal Foot
Bracket x2
•We have taken great care to ensure that this product reaches
you in perfect condition. However should any parts be damaged
or missing please contact your point of purchase. This does not
affect your statutory rights. In addition if you require replacement
parts your point of purchase will be happy to assist.
•You may have additional spare parts, please discard with due regard to the
environment.

5
10
3
2
1
10
5
10
3
2
1
1
0
7
9
8
22
2
6
Please Note:
•Baths should be set at supplied panel height.
•The baseboard is encapsulated into the bath.
•Half the panel clips supplied should be secured (if possible) to the floor
•Before the final fixing of the bath, fit tap and waste fittings using a suitable
sealing compound. When complete place the bath into position, re-check levels
and make any final adjustments necessary. Finally secure the feet to the floor
and the wall brackets to the wall. Movement may occur if not fitted correctly
•HECK THAT THE BATH RIM IS LEVEL.
2
4
2
4
2
4
5
10
10
2
2
3
5
10
10
2
2
3
7
9
8
22

Note:

INB-DRE-830-WH-11-23
