SanRex CALPOTE UF-1 Series User manual

Thyristor Type Power Adjusting Unit
INSTRUCTION MANUAL
In order to operate this product properly, operators and other persons concerned are all requested to
read the “Safety Precautions” in this INSTRUCTION MANUAL thoroughly before using the product.
Strictly forward this INSTRUCTION MANUAL to the end users.

TABLE OF CONTENTS
FORWARD ................................................................................................................1
SAFETY PRECAUTIONS..........................................................................................2
Safety precautions to be observed by operators................................................................................. 2
Limitations for working environments .................................................................................................. 3
Precautions in installation ..................................................................................................................... 3
Precautions in wiring.............................................................................................................................. 4
Precautions in operation........................................................................................................................ 4
Precautions in maintenance and inspection........................................................................................ 5
PRECAUTIONS BEFORE USE ................................................................................6
Confirmation of the product .................................................................................................................. 6
CONNECTION DIAGRAM OF UNIT .........................................................................7
EXTERNAL CONNECTION DIAGRAM OF UNIT.....................................................8
Connection diagram for each setting system ......................................................................................8
How to connect unit control cables ...................................................................................................... 9
HOW TO SET UNIT .................................................................................................10
setting of dip switch S1........................................................................................................................ 10
setting of dip switch S3........................................................................................................................ 11
FUNCTION CHARACTERISTICS ...........................................................................12
DETECTION OF ABNORMALITY ..........................................................................13
Detection and indication of abnormality ............................................................................................ 13
Self-diagnostic function ....................................................................................................................... 15
External warning circuit ....................................................................................................................... 16
EXTERNAL DIMENSIONS OF UNIT ......................................................................17
FUSE TO BE USED ................................................................................................18
OTHERS ..................................................................................................................19
Precautions in use................................................................................................................................ 19
Maintenance and inspection................................................................................................................ 20
Troubleshooting .................................................................................................................................... 20
Option .....................................................................................................................21
Display panel (Model UF-DP) ............................................................................................................... 21
Conversion board (Model UF-TB)........................................................................................................ 21
Communication function...................................................................................................................... 21
UNIT SPECIFICATIONS..........................................................................................22

1
FORWARD
Thank you very much for having purchased our “Thyristor Type Power Adjusting Unit UF1 Series”.
The Thyristor Type Power Adjusting Unit has been widely used in various fields for its operability, reliability, or
other superiorities.
Our company consistently developed and manufactured the power adjusting unit starting from Thyristor ele-
ments, and obtained user’s enjoyment and satisfaction on our various products.
Now we introduce our “Thyristor Type Power Adjusting Unit UF1 Series” that we have developed
with confidence based on actual records accumulated through many years.
In this UF1 series, an insulation-type Thyristor module is introduced in the main circuit, contributing to the min-
imizing of the unit’s size and weight, while an one-chip microprocessor is loaded on the control circuit,
enhancing functions and performance of the unit.

2
SAFETY PRECAUTIONS
Before installing, operating, maintaining, and inspecting this unit, be sure to read the present INSTRUCTION
MANUAL and all other documents attached therein carefully in order for you to operate this unit properly. You
and others concerned are requested to completely master all the know-how, safety instructions and precau-
tions on the unit before use.
In this INSTRUCTION MANUAL, the following safety precautions are ranked as “DANGER” and “CAUTION” .
Further, note that articles, even if noted in the , may cause a serious result depending on the situation.
Strictly observe the articles since they describe important matters.
Sign indications for the “prohibited” and “required” actions are explained hereunder.
Safety precautions to be observed by operators
To prevent serious injury to the operators and others, be sure to observe the following precautions.
If live parts (input and output terminals) are exposed, be sure to house them in a box or to enclose
them with a protective cover. Not doing so may cause electric shock, or fatal accidents resulting in
death or serious injury.
To secure safety, this unit must be installed, wired, maintained, inspected, and repaired by qualified
persons or persons who are familiar with this unit.
In the event of any failure of this equipment, off-flavor, and abnormal noise, cease its operation
immediately. Not doing so may cause fire.
To prevent electric shock, be sure to observe the following precautions.
Never touch any parts that are electrically “live” or “hot” .
Before wiring, maintaining, or inspecting this unit, turn off all the input power from a switch on the
distribution panel, and check to see that power is OFF.
When power is supplied to the unit, do not touch the cables connected to the power supply.
Doing so may cause electric shock or burns.
A procedure which, if not properly followed, may cause extremely hazardous
conditions, resulting in death or serious injury.
A procedure which, if not properly followed, may cause hazardous conditions,
resulting in medium or slight injury and/or only damage on physical assets.
This sign indicates the “prohibition” that you should not do.
For example, for “Use of Fire Strictly Prohibited” .
This sign indicates the “compulsion” that you should do without fail.
For example, for “Ground” .
DANGER
CAUTION
CAUTION
PROHIBITED
REQUIRED
DANGER
CAUTION

3
Limitations for working environments
Absolutely do not operate nor store this unit in the following environments. Doing so may cause any
failure in, damage to, or deterioration of the unit, resulting in fire.
In hot, cold, or damp areas which are not in compliance with the requirements for ambient environ-
ments specified in relevant catalogs and this INSTRUCTION MANUAL
In area where exposed to direct sunlight
In area where subjected to vibration or shock
In the vicinity of the equipment that produces sparks
In area where exposed to dust, conductive dust, corrosive gases, salinity, or flammable gases, and
Outdoors
Precautions in installation
Attach the unit vertically and perpendicularly in such a manner that a marking of its model is prop-
erly legible.
(Horizontal attaching of the unit will increase the temperature of it excessively.)
When use the unit in the environment that dust produces, please attach the unit in the installation.
In addition, please make measures so that dust does not enter in the installation.
Locate the unit at a well-ventilated and dust-free place to the extent possible.
Secure spaces necessary for discharging heat on the top and bottom and both sides of the main
body.
When stacking two or more units especially, give a sufficient space between units so that heat from
the lower unit does not affect the upper unit.
If you intend to install a communication function into the unit, attach a communication unit on the
left side of the unit body. Attach units in consideration of the size of communication unit sized to
24mm wide. Additionally, keep sufficient space so that its front door can be opened and closed for
maintenance and inspection.
The working ambient temperature of the unit is 50°C or below. Please do not use the unit at any
higher temperature.
The working ambient humidity of the unit is 90%Rh or below. Please do not use the unit at any
higher humidity.
CAUTION
CAUTION
Over 20mm
Over 20mmOver 20mm
Over from
200 to 400mm

4
Precautions in wiring
Ask a specialist contractor for wiring work.
Imperfect wiring work may cause electric shock or fire.
Precautions to be taken by a specialist contractor
Qualified specialists are required to turn off all the input power from a switch on the distribution
panel and to make sure that power is off before connecting the input and output cables.
The specialists must put a “Do not turn on this switch!” sign on the switch of the power distribution
panel in order to prevent others than the specialists from touching the switch. Not doing so may
cause electric shock or injury.
Be sure to insulate the conductive parts which are connected to the power supply with insulating
material (tube, tape, and others) . Exposure of such parts may cause electric shock or short-circuit-
ing to the power supply, resulting in fire.
Select the input and output cables of gauges suitable for this unit. Excessively small gauges of
cables may cause overheating or fire.
Use the cables of a dielectric strength suitable for the circuit voltage. The cables not having suffi-
cient dielectric strength may cause electric shock.
Be sure to use the crimp-type terminal for connections to the input and output terminals.
Improper connection may cause electric shock.
Precautions in operation
Do not remove a unit cover. Doing so may cause electric shock.
Do not insert fingers or metal rods into the opening. Doing so may cause electric shock.
In the event of any failure of this unit, off-flavor, and abnormal noise, stop its operation immediately.
Not doing so may cause fire.
Do not insert fingers or rods into the opening. Doing so may cause caught-in accident by a cooling
fan, resulting in injury.
Do not touch the input and output terminal portions of the unit with a metal rod or fingers. Doing so
may cause electric shock or injury.
CAUTION
DANGER
CAUTION
DANGER
CAUTION

5
Precautions in maintenance and inspection
Persons other than approved persons (specialists) must not maintain, inspect, or repair this unit.
Doing so may cause electric shock, injury, or fire.
To repair this unit or to replace defective parts, please contact the distributor of your purchase or
any service company.
Precautions to be taken by a specialist contractor
When performing maintenance, inspection, or repair, be sure to wear sufficiently safe clothing. Not
doing so may cause electric shock or injury.
When performing maintenance, inspection, or repair, turn off all the input power from a switch on
the distribution panel, and check to see that power is OFF. Not doing so may cause electric shock
or injury.
The workers must put a “Do not turn on this switch!” sign on the switch on the power distribution
panel in order to prevent others than the workers from touching the switch. Not doing so may cause
electric shock or injury.
Before maintaining, inspecting, or repairing this unit, read this INSTRUCTION MANUAL thoroughly to
perform proper work. Improper work may cause electric shock or fire.
Before performing work, remove metal objects such as watches. Wearing metal objects during
work may cause electric shock or injury.
When performing work, place a sign, “Keep out! Authorized personnel only!”, in the working area to
prevent other persons from entering the working area inadvertently. Not doing so may cause elec-
tric shock or injury.
Use insulated tools. Not doing so may cause electric shock.
Do not touch the high temperature parts such as transformers and heat discharging fin. Such parts
may cause injury even after turning off power.
Select replacement parts of same ratings and same type. Not doing so may cause fire.
PROHIBITED
CAUTION
DANGER
CAUTION

6
PRECAUTIONS BEFORE USE
Confirmation of the product
Check the following items before installation.
Check if correct products and optional items are provided as specified in the order.
[Main body]
[Option]
8 models of conversion boards, including 1A, 1V,
are available.
Refer to the “INSTRUCTION MANUAL for Con-
version Board” for details.
Check if necessary PT and CT are pro-
vided for the unit when equipped with an
optional conversion board (UF-TB ).
Check if the product has no damage due
to accident during transportation or other
causes.
No. Included items Q’ty
1 UF1 unit body 1 unit
2 Screws, nuts, and others for the connection of output wires
a: Screw (25A-250A only) 2 pcs
b: Bolt (350A and 450A only) 2 pcs
c: Washer (350A and 450A only) 4 pcs
d: Spring washer (350A and 450A only) 2 pcs
e: Nut (350A and 450A only) 2 pcs
3 Screw for the connection of a grounding terminal 1 pcs
4 Attachment volume set 1 set
a: Volume (1k B characteristic) 1 pcs
b: Knob 1 pcs
c: Insulation sheet 1 pcs
d: Nameplate (manual output adjustment, setting of the grade) 2 pcs
5 Easy lock 3 pcs
12 3
4ab c d
ab cde
5
Option name Model
Display panel UF-DP
Conversion board UF-TB
RS485 communication unit UF-RS485
DeviceNet
communication unit
UF-DN
CC-Link communication unit UF-CL
PROFIBUS
communication unit
UF-PB

7
CONNECTION DIAGRAM OF UNIT
For wiring of the external input terminals, refer to the Connection Diagram for Each Setting System.
Use a transformer to obtain a 200/220V of the control power when other value of the power supply voltage is
supplied for the main circuit. Align the polarities between the main and control circuits for wiring.
LK
K2 K1
G2K2 G1K1
V1
D1
I1
VE1
VL2
VH2
VF2
VE3
PH
GT
ST
AT
RT
PS
-
S
+
HC
HA
1C
1A
0
200
HL
F1
TF1
FAN1
PCB1
PCB2
PCB4
CT1
THS1
CN2
CN3
CN1
CN5
UF-DP
THY1 +
-
UF-TB
UF-RS485
UF-DN
UF-CL
UF-PR
PCB3
Abnormality
indication
circuit
Conversion
Board
Display
panel
Communication
unit
Control circuits
Power supply, Gate circuit
Snubber circuit
Major failure
output
External
input and
output
terminals
Conversion
board
(option)
Minor failure
output
Power
supply Load
THY1 Thyristor
FAN1 Cooling fan (forced air cooling only)
F1 Fuse
(only for models with the indication of F)
TF1 Fuse warning contact
(only for models with the indication of F)
CT1 Current transformer
PCB Printed circuit board
CN Connector
THS1 Thermal switch

8
EXTERNAL CONNECTION DIAGRAM OF UNIT
Connection diagram for each setting system
Connection diagrams for each setting system are shown below.
Short circuit between GT and PH terminals during operation. Open-circuiting between them during
operation forcibly stops output.
Short-circuiting between ST and PH terminals starts output, and open-circuiting between them
stops output.
GT and ST terminals function differently in stop movement as listed below.
AT and PT terminals become automatic adjustment when short-circuited, and become manual
adjustment when open-circuited.
HL and PH terminals start output in case that the setting of an upper limit at short-circuit or of a
lower limit at open-circuit is made.
When GT and PH terminals are open-circuited, the GT terminal immediately stops output regard-
less of the soft start period.
When ST and PH terminals are open-circuited, the ST terminal gradually reduces output during the
soft start period, and finally stops output.
When GT and ST terminals are short-circuited, both terminals gradually increase output to its set
value during the soft start period.
Manual adjustment
The setting of Grade, Manual, and Lower Point is selectively available. The setting of Ratio, Upper Limit, and Lower Limit is selectively available.
The setting of Grade and Lower Point is selectively available. The setting of Grade and Lower Point is selectively available.
Automatic adjustment
(DC 4 to 20mA / 1 to 5V)
Note 1
Note 2
Automatic adjustment
(DC 0 to 5V)
Two-position control
+
S
-
PS
RT
HL
AT
ST S1 1
1
2
2
3
3
1
2
3
1
2
3
4
ON
OFF
GT
PH
VE3
VF2
VH2
VL2
VE1
S1 1234
ON
OFF
1
2
3
1
2
3
1
2
3
+
S
-
PS
RT
HL
AT
ST
GT
PH
VE3
VF2
VH2
VL2
VE1
1
2
3
1
2
3
S1 1 2 3 4
ON
OFF
+
S
-
+
-
PS
RT
HL
AT
ST
GT
PH
VE3
VF2
VH2
VL2
VE1
S1 1 2 3 4
ON
OFF
1
2
3
1
2
3
+
-
+
S
-
PS
RT
HL
AT
ST
GT
PH
VE3
VF2
VH2
VL2
VE1
Grade
1k
Grade
1k
"+" and "S" are to be short-circuited in the case of a current signal.
"S" and "-" are to be short-circuited in the case of a voltage signal.
Note 1, Note 2
Adjust-
ment
meter
Adjust-
ment
meter
In the case that Ratio is not to be used, "VE3" and "VF2" are to be
short-circuited.
In the case that Grade is not to be used, "VE3" and "VF2" are to be
short-circuited.
In the case that Lower Point is not to be used, "VL2" and "VE1" are
to be short-circuited.
In the case that Lower Limit is not to be used, "VL2" and "VE1" are to
be short-circuited.
In the case that Grade is not to be used, "VE3" and "VF2" are to be
short-circuited.
In the case that Lower Point is not to be used, "VL2" and "VE1" are
to be short-circuited.
In the case that Grade is not to be used, "VE3" and "VF2"
are to be short-circuited.
In the case that Lower Point is not to be used, "VL2" and
"VE1" are to be short-circuited.
Grade
1k
Manual
1k
Lower
Point
1k
Lower
Point
1k
Lower
Point
1k
Grade
1k
Ratio
1k
Upper
Limit
1k
Lower
Limit
1k

9
How to connect unit control cables
Use an easy lock to bind up the control cables (for control power supply, major failure output, minor fail-
ure output, external input and output terminals, and conversion board) of the unit.
1Fix the easy locks on the unit.
2Bind the control cables with the easy locks.
Separate the cables for the control power sup-
ply and other cables to bind.
Other cables
Cables for the
control power
supply

10
HOW TO SET UNIT
Perform a setting of the unit with a good attention in that live parts are exposed when opening a
cover of the unit. Before setting, turn off power.
The standard initial setting of this unit is as listed below. If the unit is used under other conditions, open
a cover on the lower part of the unit to change the setting of dip switch S1 located on the printed circuit.
Setting of dip switch S1
Control system Phase control
Type of temperature control unit DC4-20mA or DC1-5V
Cycle control Intermittent type
Item Description 1 2 3 4
Control system Phase control OFF
Cycle control ON
Type of temperature control unit DC1-5V/4-20mA OFF OFF
DC0-5V OFF ON
Two-position control ON OFF
Not defined ON ON
Cycle control Intermittent type OFF
Continuous type ON
CAUTION
ON
OFF
12 3 4

11
Control system (S1-1)
[Function] This makes a selection of phase control or cycle control. The phase control is to control the
phase of half-cycle by means of its effective value.
The cycle control is to control the number of turning ON in one cycle during a certain con-
stant period by means of its effective value. Changeover between phase and cycle controls
is not possible during output operation. Changeover between phase and cycle controls is
possible only while the power is turned off.
Use the S1-4 switches to change the setting of intermittent type/continuous type for cycle
control. However, changeover of the control system is not made during output operation.
A system is provided to prevent the changeover of control system during its operation.
Type of temperature control unit (S1-2, 3)
[Function] This changes the signal levels sent from the temperature control unit, and selects the two-
position control. Changeover of the operating conditions of temperature control unit is pos-
sible only while the power is at a standstill, but such changeover is not possible during out-
put operation.
However, changeover of the type of the temperature control unit is not possible during out-
put operation. A system is provided to prevent the changeover of the type of temperature
control unit during operation.
Cycle control (S1-4)
[Function] This makes a selection of intermittent type or continuous type for cycle control.
Use the S1-1 switch to change the setting of phase control or cycle control.
However, changeover of the cycle control is not possible during output operation. A system
is provided to prevent the changeover of cycle control during output operation.
Setting of dip switch S3
S3 is a switch to change the setting of the unit address when an optional RS485 communication unit is
installed. Therefore, leave the setting of the switch as initially set.
25%
50%
75%
100%
25%
50%
75%
100%
(50%)
(70%)
(86%)
Phase control waveform
Output voltage
Cycle control waveform
Output cycles
(Effective value)
25%
50%
75%
100%
(50%)
(70%)
(86%)
25%
50%
75%
100%
(50%)
(70%)
(86%)
Continuous type waveformIntermittent type waveform
Output cycles
(Effective value)
Output cycles
(Effective value)
Period 1 second

12
FUNCTION CHARACTERISTICS
The standard unit has the linear characteristic between control signals and output level. It can be changed to
have the following characteristics.
Function characteristics No. Input and output characteristics
Characteristic 0 Linear characteristic
Characteristic 1 1.6th root characteristic
Characteristic 2 1.8th root characteristic
Characteristic 3 2.0th root characteristic
Characteristic 4 2.2th root characteristic
Characteristic 5 2.5th root characteristic
Characteristic 6 3.0th root characteristic
Characteristic 7 3.5th root characteristic
100.0%
100.0％
90.0%
80.0%
80.0%
70.0%
60.0%
60.0%
50.0%
40.0%
40.0%
30.0%
20.0%
20.0%
10.0%
0.0%
0.0%
Output voltage
(V)
Set value

13
DETECTION OF ABNORMALITY
Detection and indication of abnormality
In the event of any abnormality, check the Unit Abnormality lamp, stop operation of the unit, and
then turn off power.
When an abnormality detection circuit functions, an abnormality indication lamps lights up or flickers on
the right-hand side of the terminal block inside the front panel of the unit.
Abnormality indications, abnormality descriptions, operating status, and procedures to restart operation
are as listed below.
1 This abnormality is available only for an 100A unit or larger.
2 This abnormality is available only for an unit with fuse.
3 This abnormality is available only for an unit equipped with a conversion board for detection of
heater disconnection (optional).
OCR
This detects overcurrent when the current exceeding 150 percent of the unit’s rated current has flowed
over several cycles. On detection of overcurrent, an “OCR” indication lights up and operation stops. To
resume operation, turn off the control power supply.
TMP
This detects temperature rise abnormality when the temperature of a cooling fin has been increased
abnormally. On detection of temperature rise abnormality, a “TMP” indication lights up and operation
stops. To resume operation, turn off the control power supply.
Abnormality
indication
Abnormality
description
Operating status
after detection of
abnormality
Procedures to
restart
operation
Light-emitting
diode is lit.
OCR Detection of
overcurrent
Operation stops. Turn off power.
TMP Temperature rise
abnormality
Operation stops. Turn off power. 1
F Fuse disconnection Operation stops. Turn off power. 2
HET Heater disconnection
(optional)
Operation continues. 3
Light-emitting
diode flickers.
THY Thyristor short Operation stops. Turn off power.
Thyristor open Operation stops. Turn off power.
LOD Load short Operation stops. Turn off power.
Load open Operation continues.
FRQ Abnormal frequency Operation continues.
L. Vo Power supply
undervoltage
Operation stops. Operation is
automatically
recovered.
CAUTION

14
F
This detects fuse disconnection when a fuse built in the unit (optional) is disconnected. On detection of
fuse disconnection, an “F” indication lights up and operation stops. To resume operation, turn off the
control power supply.
HET
The optional function is provided to detect heater disconnection. On detection of heater disconnection,
an “HET” indication lights up and operation continues.
THY
The self-diagnostic function is provided to detect Thyristor open or short. On detection of Thyristor
open or short, a “THY” indication flickers and operation stops. To resume operation, turn off the control
power supply.
LOD
The self-diagnostic function is provided to detect load open or short. On detection of load open or
short, an “LOD” indication flickers. Operation continues in the event of load open. Operation stops in
the event of load short. To resume operation, turn off the control power supply.
FRQ
This detects abnormal frequency in the event of any abnormality with frequency of control power sup-
ply. On detection of abnormal frequency, an “FRQ” indication flickers and operation continues.
L. Vo
This detects power supply undervoltage when the voltage of control power supply falls below its appro-
priate value. On detection of power supply undervoltage, an “L. Vo” indication flickers. Operation is at a
standstill only while such abnormality is detected. When the detection of abnormality is released, oper-
ation is automatically resumed.

15
Self-diagnostic function
This function is provided somewhat differently depending on the combination with a conversion board
(optional).
Only when conversion boards 3 (U) and 3H (U) mounted.
The item marked with is judged to be load short even in the case of Thyristor open.
Starting the unit without turning on the power of main circuit for test operation may cause its self-diag-
nostic function to stop operation. In such a case, release the self-diagnostic function once to restart
operation.
To forcibly release the self-diagnostic function, use a thin bar-shaped item to press the SELF CHECK
switch located on the lower-right part after opening a terminal cover on the front of the unit. When the
switch for approximately one second is pressed, the abnormality indication lamps of “THY” and “LOD”
on the upper part simultaneously flicker for about 1 minute. If the control power supply is turned off and
then on during compulsory release of self-diagnostic function, the settings are stored during such com-
pulsory release. When the control power supply is turned on, the abnormality indication lamps of “THY”
and “LOD” flicker for about 1 minute simultaneously, indicating that the self diagnostic function is in
compulsory release.
To recover the self-diagnostic function, press the SELF CHECK switch again. Doing so causes such
abnormality indication lamps to go out in the case they are flickering simultaneously.
Without conversion
board
With conversion
board
Operating status after
detection of abnormality
In running In stopping In running In stopping
Thyristor open N/A Available N/A Operation stops.
Thyristor short N/A Available Available Available Operation stops.
Load short Available N/A Available N/A Operation stops.
Load open Available N/A Available N/A Operation continues.

16
External warning circuit
The abnormality detection circuit, when activates, causes an external warning relay in the unit to acti-
vate. Major and minor failure relays are provided as the external warning relay.
Major failure relay
The abnormalities described below, when detected, forcibly stops operation and at the same time
causes a major failure relay in the unit to activate.
Detection of overcurrent
Temperature rise abnormality
Fuse disconnection
Thyristor open/short and load short to be detected by self-diagnosis function
Use the output of the major failure relay contact to monitor any abnormality.
The output of the major failure relay contact informs multiple abnormalities detected. So, check the indi-
cation of abnormality detection to know what abnormality was detected as a cause of activating the
relay.
Minor failure relay
The abnormalities listed below, when detected, causes a minor failure relay in the unit to activate.
Power supply undervoltage
Abnormal frequency
Load open to be detected by self-diagnostic function
Detection of heater disconnection (optional)
There may be the cases that power supply undervoltage and abnormal frequency are detected when
the control power supply is turned on/off. Therefore, the relay does not activate for about 3 seconds
after detection of such abnormalities even when they are actually detected.
Use the output of the minor failure relay contact to monitor any abnormality.
The output of the minor failure relay contact informs multiple abnormalities detected. So, check the indi-
cation of abnormality detection to know what abnormality was detected as a cause of activating the
relay.
Normal Between 1A and 1C Opened
Abnormality Between 1A and 1C Closed
Specifications for
relay contact
AC 250V 0.1A-1A
DC 30V 0.1A-1A
Normal Between HA and HC Opened
Abnormality Between HA and HC Closed
Specifications for
relay contact
AC250V 0.1A-1A
DC30V 0.1A-1A

17
EXTERNAL DIMENSIONS OF UNIT
= 2 : 200V/220V/254V
= 4 : 380V/400V/440V/460V/480V
= None : without FUSE
= F : with FUSE
Model Rated
current
Cooling
system
External dimensions (mm) Weight
(kg)
Calorific
value (W)
Terminal
screw
A B C D E F
UF1- 025 25A Self-cooling 60 40 240 256 270 190 3 43 M5
UF1- 035 35A Self-cooling 60 40 240 256 270 190 3 57 M5
UF1- 050 50A Self-cooling 60 40 240 256 270 190 3 77 M5
UF1- 075 75A Self-cooling 60 40 240 256 270 230 3.5 113 M6
UF1- 100 100A Air-cooling 60 40 240 256 270 230 4 164 M6
UF1- 150 150A Air-cooling 118 98 240 256 270 230 5 224 M8
UF1- 250 250A Air-cooling 118 98 350 366 380 260 8 349 M10
UF1- 350 350A Air-cooling 118 98 425 437 455 260 12 395 M12
UF1- 450 450A Air-cooling 118 98 425 437 455 260 12 512 M12
A
B
A
B
A
B
A
B
F
C
FF
C
C
E
D
E
D
E
D
E
D
C
F
Fixing screw M4
Fixing screw M6
Fixing screw M4
Fixing screw M6
25A-100A
250A
150A
350A/450A

18
FUSE TO BE USED
Unit current Fuse
200V/400V
25A 660GH 50S-F
35A 660GH 63S-F
50A 660GH 100S-F
75A 660GH 125S-F
100A 660GH 160S-F
150A 660GH 250S-F
250A 660GH 350S-F
350A 660GH 500S-F
450A 660GH 710S-F
