Sanyo 26TW72R User manual

System: 26TW72R Indoor/Outdoor: THW2672R/C2672R
Ceiling Suspended Air Conditioner
Power V/PH/Hz 230/208/1/60
Circuit Ampacity
Fuse Size, Max.
Compressor
No. used
R.L. Amps - L.R.
Crankcase Heater
Outdoor Unit
Fan type
Dia. (in.) - No. Speeds
Type Drive - No. Speeds
No. Poles
No. Motors
CFM
F.L. Amps
Coil Type
Fin Type - Pipe Type
Rows - F.P.I.
Face Area
Tube Size
Indoor Unit
Fan type
Dia. & Length (in.) - No. Speeds
No. Speeds
No. Poles
No. Motors
CFM
Indoor Sound Rating
F.L. Amps
Coil Type
Fin Type - Pipe Type
Rows - F.P.I.
Face Area
Tube Size
Drain Connection Size
Refrigerant
Lbs. - R410a (outdoor unit)
Control
Connection
Line Length, Max
Lift Difference, Max
Line Size
Line Size
Dimensions
Indoor Unit
Outdoor Unit
Weight
Net
Shipping
Shipping Volume
Performance Data @ ARI Standard Conditions (230/208V)
Cooling
Total Capacity
Sensible Capacity
Latent Capacity
SEER
Dehumidification
Amps
Power Inputs
Outdoor Sound Rating
(A) 15-30 Indoor-Outdoor
(A) 15-30 Indoor-Outdoor
General Data (at 230V)
1
(A) 12.9-17.5
(W) -
Propeller
18-7/64-1
Direct Inverter
(RPM) 8 - 800
(W) 1-90
14.5
(Pints/H) 7.7
(BTU/H) 24,000 (9,500-24,400)
(BTU/H) 14,330
(BTU/H) 10,070
(Uncrated) 7-17/32 x 51-3/16 x 26-3/8
(W) 2,880/2,880
Aluminum Fin & Copper Pipe
Slit Plate - Inner Rifled
(in.) 3/8”
4.19
Split System Submittal Data
Electric Expansion Valve
Job Name:
Location:
Engineer:
Submitted to:
Submitted by:
Reference:
Approval:
Date:
Construction:
Unit #:
Drawing #:
1-15.9
(sq.ft.) 7.25
(lbs.) 57 128
(A) 15.6/17.3
(in. O.D. Discharge) 3/8”
(in. O.D. Suction) 5/8”
DC Rotary Inverter
(High) 1765
(A) 13.8
R410A
(in.) H x W x D
(Crated) 9-7/16 x 54-19/32 x 31-1/16
Indoor Outdoor
(cu.ft.) 8.9 13
Indoor Outdoor
(lbs.) 68 148
(dB-A) 49
Centrifugal
5-1/8 - 4
3 & Auto
(RPM, High) 4-1179
(W) 1-31
Aluminum Fin & Copper Tube
Slit Plate - Inner Rifled
(in.) 9/32”
3-14.9
(sq.ft.) 1.81
(HI/Med/Lo) 550/490/460
(A) 0.5
(in.) (1-1/4)
(Hi) (dB-A) 39
Flare
165
50 (Outdoor lower), 100 (Outdoor higher)
(Uncrated) 30-23/32 x 37 x 13-3/8
(Crated) 34-31/32 x 39-31/32 x 16-3/32

Dimensions
Sanyo Commercial Solutions
A Division of SANYO North America
1300 Michael Drive
Wood Dale, IL 60191 USA
www.sanyohvac.com
Feature
Controls
Remote Controller
Temperature Control
Timer
Night Setback
Air Louver
Power Failure Automatic Restart
Self-Diagnosis
Air Filter
Option
Refrigerant Line Set
Fresh Air Intake
Condensate Drain Pump
Wireless Remote Controller
Non-Removeable Remo-con Bracket
Operating Range
Indoor Air Intake Temp. Outdoor Air Intake Temp.
Cooling Maximum 95F DB/71F WB 115F DB
Minimum 67F DB/57F WB 0F DB
Built-In
Built-In
Washable, Anti-Mold
Available
Knock-Out
Available
Available
Available
Microprocessor
LCD Wired Type, Temp. Sensor Built In
(Horizontal) Manual
72HR, ON/OFF
IC Thermostat
Built-In
(Vertical) Automatic
Dimensional Data for 36T72R
Indoor unit : TH3672R
Dimensional Data for 36T72R
Indoor unit : TH3672R
