Sanyo VCC-WD8875P User manual

FILE NO.
REFERENCE No.SM5310778
L5CU2/XE, XE-C1F, US, US-C1F, C-Z, C-C1F (R)
NOTE: 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
Design and specifications are subject to change without notice.
SERVICE MANUAL
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the
part designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
PRODUCT SAFETY NOTICE
RoHS
This product does not contain any hazardous substances prohibited by the RoHS Directive.
WARNING
You are requested to use RoHS compliant parts for maintenance or repair.
You are requested to use lead-free solder.
(This product has been manufactured using lead-free solder. Be sure to follow the warning given on page 2 when carrying
out repair work.)
VCC-WD8875P
(Product Code : 117 177 00)
(Product Code : 117 247 00)
(Europe, U.K., Southeast Asia)
CONTENTS
1. SPECIFICATIONS .........................................3
2. DISASSEMBLY ..............................................4
3. ADJUSTMENT ...............................................7
4. PARTS LIST ................................................14
CIRCUIT DIAGRAMS &
PRINTED WIRING BOARDS ...........................C1
VCC-WD8874
(Product Code : 117 177 01)
(Product Code : 117 247 01)
(U.S.A., Canada, Taiwan, Brazil)
Wide Dynamic Range Camera
VCC-WD8878PC
(Product Code : 117 177 02)
(Product Code : 117 247 02)
(China)

-2 -
WARNING
Do not use solder containing lead.
This product has been manufactured using lead-free
solder in order to help preserve the environment.
Because of this, be sure to use lead-free solder when
carrying out repair work, and never use solder
containing lead.
Lead-free solder has a melting point that is 30 - 40°C (86 -
104°F) higher than solder containing lead, and moreover it
does not contain lead which attaches easily to other metals.
As a result, it does not melt as easily as solder containing
lead, and soldering will be more difficult even if the
temperature of the soldering iron is increased.
The extra difficulty in soldering means that soldering time
will increase and damage to the components or the circuit
board may easily occur.
Because of this, you should use a soldering iron and
solder that satisfy the following conditions when carrying out
repair work.
Soldering iron
Use a soldering iron which is 70 W or equivalent, and
which lets you adjust the tip temperature up to 450°C
(842°F). It should also have as good temperature recovery
characteristics as possible.
Set the temperature to 350°C (662°F) or less for chip
components, to 380°C (716°F) for lead wires and similar,
and to 420°C (788°F) when installing and removing shield
plates.
The tip of the soldering iron should have a C-cut shape or
a driver shape so that it can contact the circuit board as flat
or in a line as much as possible.
Solder
Use solder with the metal content and composition ratio by
weight given in the table below. Do not use solders which
do not meet these conditions.
Lead-free solder is available for purchase as a service tool.
Use the following part number when ordering:
Part name: Lead-free solder with resin (0.5 mm dia., 500 g)
Part number: VJ8-0270
Metal content Tin (Sn) Silver (Ag) Copper (Cu)
Composition
ratio by weight 96.5% 3.0% 0.5%
Note:
If replacing existing solder containing lead with lead-free
solder in the soldered parts of products that have been
manufactured up until now, remove all of the existing solder
at those parts before applying the lead-free solder.

-3 -
Scanning system : PAL standard 625 lines, 50 fields/sec. (VCC-WD8875P, VCC-WD8878PC)
Scanning system : NTSC standard 525 lines, 60 fields/sec. (VCC-WD8874)
Image sensor : 1/3” progressive CMOS
Number of effective pixels : 800 (H) x 600 (V)
Horizontal resolution : 550 TV lines, typical
Minimum illumination (approx.) : 0.8 lx (F1.2 color mode), 0.08 lx (F1.2 B/W mode)
Video output : 1.0 V (p-p)/75 ohms, composite, BNC
Video S/N ratio : More than 48 dB (AGC OFF:More than 50 dB)
Light control : Optical auto iris lens/Electronic iris (indoor use)
Auto iris lens drive : DC
Lens mount : CS mount
Flange back : 12.5 mm ± 0.5 mm/ 0.5 in. ± 0.02 in. adjustment
Menu : On screen display
Wide dynamic range : ON (65 dB typical)/OFF
Backlight compensation : OFF/ON (Center zone metering)
White balance : ATW/ Manual
Gain control : Normal/High/OFF
Electronic shutter : 1/50, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 sec. (VCC-WD8875P, VCC-WD8878PC)
Electronic shutter : 1/60, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 sec. (VCC-WD8874)
Aperture compensation : Normal/High/Low/OFF
Day/Night : AUTO/ COLOR/ B/W
Sync system : Internal sync/Line lock
Camera title : OFF/ON, Up to 16 characters, adjustable title position
Digital noise reduction : ON (1, 2)/OFF
Operating environment : Temperature -10°C - +50°C (14°F - 122°F)
Operating Environment : Humidity less than 90% RH max. (no condensation)
Power supply : 24 V AC ± 10% 50 Hz/12 - 15 V DC (VCC-WD8875P, VCC-WD8878PC)
Power supply : 24 V AC ± 10% 60 Hz/12 - 15 V DC (VCC-WD8874)
Power consumption (approx.) : 6.9 W (with auto-iris lens)
Weight (approx.) : 330 g/ 11.6 oz. (without lens)
Dimensions
1. SPECIFICATIONS
1/4” -20UNC
129 (5.1)
119.5 (4.7)
1
(0.04)
11 (0.4)
71 (2.8)
45 (1.8)
Unit: mm (inch)

-4 -
1
2
34
5
6
8
7
9
9
10
11
16
15
14
12
13
12
18
17
2. DISASSEMBLY
2-1. REMOVAL OF COVER AND CABINET
1. Screw 3 x 10
2. Two screws 3 x 6
3. Screw 3 x 6
4. Mounting
5. Cover mounting
6. Two screws 3 x 4
7. Screw 2 x 4
8. Dec side + Dec button
9. Four screws 2 x 4
10. Cover top
11. Cover bottom
12. Two hooks
13. Cabinet front
14. Two hooks
15. Cabinet back
16. Spacer heat transfer
17. Spacer cooler CMOS
18. Screw 2 x 5

-5 -
2
1
3
4
5
6
6
8
9
10
11
12
13
14
15
16
7
18
17
A
AB
B
2-2. REMOVAL OF CA-2 BOARD, CA-3 BOARD AND CA-4 BOARD
1. CN201 (Assy shield wire W1001)
2. Four screws 2 x 4
When assembling, attachment order.
A B
3. Connector
4. Assy wire W4001 (CN202 - CN421)
5. CA-2 board
6. Four screws 2 x 4
7. Connector (CN422)
8. Assy shield wire W1001 (CN101)
9. Screw 2 x 4
10. Two screws 2 x 4
11. Screw 2 x 4
12. CA-3 board
13. Screw 3 x 10
14. Screw 3 x 12
15. CA-4 board
16. Chassis
17. Spacer guide
18. Spacer stopper

-6 -
CA-1 BOARD
CA-2 BOARD
CA-4 BOARD
CA-3 BOARD
1. Two screws 2 x 2
2. Spring plate housing
3. Three screws 2 x 5
4. Three screws 2 x 4
When assembling, tighten the screws
order. A C
5. Holder CA-1
6. CA-1 board
7. Spacer filter
8. Optical filter
The direction of the arrow is long.
It installs it in the direction of figure.
9. Optical dummy glass
The direction of the arrow is long.
It installs it in the direction of figure.
10. Spacer filter
11. Two screws 1.4 x 4
12. Assy motor DN
13. Assy housing
14. Spacer guide
15. Screw 2 x 2
16. Spring plate fix cam
17. Three screws 2 x 4
When assembling, tighten the screws
order. A C
18. Spacer shade
19. Cam
20. Mounting lens
21. Chassis front
2-3. REMOVAL OF CA-1 BOARD AND BOARD LOCATION
3
1
2
1
2
11
12
4
5
6
7
9
10
13
14
16 17
15
A
B
C
18
20
19
21
8
A
B
C
BOARD LOCATION

-7 -
3. ADJUSTMENT
3-1. ADJUSTMENT CONDITION
1. Use the 5,100K viewer for the subject. (color temperature
: 5500 ± 100 k (or 4900 - 6000 k), luminosity : 1000 ± 100
cd/m²)
2. Set the trigger signal of oscilloscope to VIDEO OUT, and
apply H sync unless specified.
3. Adjustment is performed by the following function set-
tings.
4. In adjustments without direction to display charts, shield
light with a lens cap to provide dark condition.
5. Connect the video output to a video monitor with an input
impedance of 75 ohms.
6. This lens should be a VCL-CS8LY or an equality.
7. Power supply input is CN401.
SHUTTER : 50 (VCC-WD8875P, VCC-WD8878PC)
SHUTTER : 60 (VCC-WD8874)
3-2. TABLE FOR SERVICING TOOLS
1. Use an IR-303 as the radiation temperature gauge, and
set the radiating rate to 95E.
2. Adjust the temperature of the heated air from the spot
heater to 150 ± 10°C using an iron tip temperature
gauge.
3. Use the latest versions of the adjustment software and
the WDDL5CS software.
3-3. PREPARATION
1. Install the adjustment software and WDDL5CS software
in a computer running the Windows operating system.
2. If the CA-1 circuit board has been replaced, copy the
S1.txt and S2.txt files from the accessory CD-ROM to the
C:\CCTV\Data folder of the personal computer.
Record the input number contained in the INPUT NO.txt
file on the CD-ROM.
Ref. No. Name Part code
J-1
J-2
J-3
J-4
J-5
J-6
J-7
J-8
J-9
J-10
CA-2 BOARD SIDE A
FUNCTION SYNC WD BLC IRIS WB
POSITION INT OFF OFF AI ATW
FUNCTION AGC G SHUTTER APERTURE D/N
POSITION NORM 50 or 60 NORM AUTO
Record the CMOS (CCD) number which is written on the
CMOS protective sheet on the CA-1 circuit board.
3. Use the adjustment jig (VHJ-0127) to connect the camera
to be adjusted to the serial port (COM1) of the computer
with RS-232C cross cable (Inter link cross cable, VHJ-
0149), and then turn on the power for the computer .
4. Double-click the adjustment software which has been
installed into the computer.The main window will be
displayed.
5. Click “Co” in the main window menu (or click “Set” and
then click “Config”). The setting window will be displayed.
6. In the setting window, change the “COM” setting to
“COM1”. For a notebook computer, select “NOTE PC”.
Click “OK”. The main window will be displayed.
7. Click “CS” in the main window menu (or click
“Adjustment” and then click “L5CS”). The selection
window will be displayed.
8. In the selection window (Main dialog), click “SET UP”.
The setup window will be displayed.
9. In the setup window, change all other values to the
standard settings (setup window illustration).
10. Click “OK” to accept the settings. The selection window
will be displayed.
11. In the selection window, click “ADJUSTMENT”. The
adjustment window will be displayed.
12. In the adjustment window, click “START”. If “Version is
different” appears, return to the setup window and enter
the version.
3-3-1. Adjustment parts
TP251
CT251
CT231
TP231
CN261
ADJ
VJ8-0007
VJ8-0009
VJ8-0010
VHJ-0126
VHJ-0127
VHJ-0149
VHJ-0182
VHJ-0183
VHJ-0184
Color viewer
Color bar chart
Gray scale chart
Commander cable (spare)
Adjustment jig
Inter link cross cable
Calibration software
WDDL5CS software
Radiation temperature gauge
Spot heater
VHJ-0182 = DSPCCTV Ver. 1.54 or later
VHJ-0183 = WDDL5CS Ver. 1.07 or later

-8 -
3-3-2. Computer screen during adjustment
Main window
Setting window
Setup window
Adjustment window
Selection window (Main dialog)
CONFIG
COM
SERIAL PORT
BASE ADDRESS
PARALLEL PORT
WAIT COUNTER
GP/IB ADDRESS
STARTUP ENABLE
START UP
SPEED
COM1
38400
378
0
TDS-3012
R6441A
1
2
TR5822 3
ADJ. L5BU
NOTE PC
OK CANCEL
L5CS
MODEL
ADJUSTMENT ADD
SETUP COPY
DEL
CLOSE
R V X Z H W AF AG AX AY BC BG BH BU CS I Co
dspcctv - DSP Camera Control for Windows95/98/Me/2000 Ver.1.51
Exit Adjustment Set View Help
DSP
CAM
Ready
NUM
ADJ L5CS
START END
CLOSE
MODEL
STATUS
AUTO
M/WB2
R GAIN
R HUE
B GAIN
Y GAIN
SYNC
BURST
A IRIS
SENSOR HIGH NORMAL
M/WB1
B HUE
WDD
PHASE 0
TACK
Version(FRONT)
Version(BACK)
WHITECLIP
0
0
0
0
0
0
0
0
0
0
0
IRIS
CHECK WDD1 WDD2
FPGA
SECRET
AUTO
WDD2
SCROLL TIMER mS
SET L5CS
ADJ/CHK INIT DATA
MODEL
ADJUSTMENT
ROM CLEAR
SYNC
A.IRIS
M/WB1
BURST 29 50
15
SET VERSION(FRONT)
Set Version
Set Time
ROM CLEAR TIMER Sec
Option-Board ON
OK CANCEL
57
GAIN
M/WB2
CHROMA
0
Select
0x20
Day/Night Color Mode
Day/Night Mode
0x21 0x22
SENCER CHECK
64
112
214
67
32
58
Y GAIN
IRIS 208
142
201
WDD
127
SET VERSION(BACK)
10
LENS DATA
Lens Set
85
NORMAL HIGH S1 50
THRESHOLD
150
4
EXPOSURE
4
NORMAL HIGH S2
30
GAIN
20
WDD2
WHITE CLIP
NORMAL S1 50
THRESHOLD
80
EXPOSURE
HIGH S2
36
SHD
36
4
CHECK WDD
PHASE
FPGA VERSION
SECRET VERSION
RESET
END RESET
4
4
2
MATCH

-9 -
3-6. Sensor Gain Confirmation
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Oscilloscope
Subject: Color bar chart
Adjusting method:
1. Display the color bar chart at designated picture angle.
2. Click the adjustment software installed from the personal
computer, and the adjustment window will be displayed.
3. Click the START.
4. Use the “ ” button to be SENSOR in the adjustment
window.
5. HIGH and NORMAL are switched and a wave-like change
is checked. The level of HIGH is high.
3-7. SYNC and BURST Level Adjustment
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Oscilloscope
Subject:
Adjusting method:
1. Shield light with a lens cap to provide dark condition.
2. Use the “ ” button to be SYNC in the adjustment window.
3. Use the computer’s mouse to adjust the SYNC in the
adjustment window so that the video out terminal is 300 ±
5 mVp-p (VCC-WD8875P, VCC-WD8878PC) or 286 ± 5
mVp-p (VCC-WD8874).
4. Use the “ ” button to be BURST in the adjustment
window.
5. Use the computer’s mouse to adjust the BURST in the
adjustment window so that the video out terminal is 300 ±
5 mVp-p (VCC-WD8875P, VCC-WD8878PC) or 286 ± 5
mVp-p (VCC-WD8874).
3-3-3. Computer screen during adjustment (WDDL5CS)
Note:
Each operation corresponds to the keyboard.
H ADDRESS minus .........
H ADDRESS plus .........
V ADDRESS minus .........
V ADDRESS plus ........
DT SW .........D
WDD .........W
LUMINANCE .........L
[Start] or [End] .........Speac
Shift and ( ) .........Speed up
3-4. Sub Carrier Frequency Adjustment
Adjustment location: CT231 (CA-2)
Measuring location: TP231 (CA-2)
Measuring equipment: Frequency counter
Subject: No designation
Adjusting method:
1. Adjust with CT231 to 17734476 Hz ± 10 Hz (VCC-
WD8875P, VCC-WD8878PC) or 14318180 Hz ± 10 Hz
(VCC-WD8874).
3-5. 28 MHz VCO Voltage Adjustment
Adjustment location: CT251 (CA-2)
Measuring location: TP251 (CA-2)
Measuring equipment: Digital voltmeter
Subject: No designation
Adjusting method:
1. confirm an INT mode.
2. Adjust with CT251 to 5.0 ± 0.2 V.
sync
burst
300 mV ± 5 mV
or
286 mV ± 5 mV
300 mV ± 5 mV
or
286 mV ± 5 mV
VIDEO OUT

-10 -
3-8. White Balance Adjustment
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Oscilloscope, Vectorscope
Subject: Color bar chart
Adjusting method:
1. Use the “ ” button to be A. IRIS in the adjustment window.
2. Auto iris adjustment will be started automatically.
3. Use the “ ” button to be M/WB1 in the adjustment window.
4. Display the color bar chart at designated picture angle.
5. Select the M/WB1 and M/WB2 by using the “ ” and “ ”
button in the adjustment window. Adjust by operating level
scroll bar so that the luminescent spot representing white is
overlapping with the crosshair mark in the center of the
vectorscope.
R
YL
MG
Cy
G
B
75%
100%
cy
g
yl
mg
b
U
v
W
R
Y
L
M G
C Y
G
B
Q
100%
75%
W
45 µsec VCC-WD8875P
VCC-WD8878PC
45 µsec
VCC-WD8874
50 µsec
VCC-WD8874
50 µsec
VCC-WD8875P
VCC-WD8878PC
3-9. Hue and Chroma Adjustment
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Oscilloscope, vectorscope
Subject: Color bar chart
1. After the white balance adjustment, this adjustment is done.
2. Use the “ ” button to be R GAIN in the adjustment window.
3. Shield light with a lens cap to provide dark condition.
4. Display the color bar chart at designated picture angle.
5. Select the R GAIN and B GAIN by using the “ ” and “ ”
button in the adjustment window.Adjust by operating level
scroll bar so that the red and yellow luminescent spots are
the size and position which are designated in the vectorscope.
6. Select the R HUE and B HUE by using the “ ” and “ ”
button in the adjustment window. Adjust by operating level
scroll bar so that the red and yellow luminescent spots are
the size and position which are designated in the vectorscope.
R
YL
MG
Cy
G
B
75%
100%
cy
g
yl
mg
b
U
v
YL R
W
R
YL
MG
CY
G
B
Q
100%
75%
YL R
W
VCC-WD8875P
VCC-WD8878PC
R :630mV 107°
YL:470mV 160°
VCC-WD8874
R :600mV 107°
YL:450mV 160°
45 µsec
VCC-WD8875P
VCC-WD8878PC
45 µsec
VCC-WD8874
50 µsec
50 µsec

-11 -
3-12. Normal Temperature White point correction
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Monitor display
Adjustment method:
1. Shield light with a lens cap to provide dark condition.
2. Click the WDDL5CS software installed from the personal
computer, and the adjustment window will be displayed.
3. Click the Auto in MODE.
4. Click the “INPUT No.”, Input number is input.
5. Click the Color in FILTER.
6. CMOS number is input to CCD No. column.
7. Push the ENTER kye.
Adjustment starts and a result is displayed.
8. Click the Manual in MODE.
9. Click the START.
10. Please pile up a false white point and a white point.
3-10. Y-Gain Adjustment
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Oscilloscope
Subject: Gray scale chart
Adjusting method:
1. Display the gray scale chart at designated picture angle.
2. Use the “ ” button to be GAIN in the adjustment window.
3. Shield light with a lens cap to provide dark condition.
4. Use the computer’s mouse to adjust the Y GAIN in the ad-
justment window so that the video out terminal is 700 ± 10
mVp-p.
3-11. Iris Level Adjustment
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Oscilloscope
Subject: Gray scale chart
Adjusting method:
1. Use the “ ” button to be IRIS in the adjustment window.
2. Display the gray scale chart at designated picture angle.
3. Because adjustment is carried out from the open side of
the lens, use the scroll bar to momentarily set the
adjustment value to its maximum so that the white level is
saturated.
4. Use the scroll bar to gradually reduce the adjustment value
until the output reaches the level of 700 ± 10 mVp-p.
VIDEO OUTPUT
35 µsec
VIDEO OUTPUT
700 mV ± 10 mV
35 µsec
700 mV ± 10 mV
Please Input Serial No.
White Defect = ooo,ooo
************
*****

-12 -
0 ± 0.2 msec.
VIDEO OUT
24 V AC zero cross point
11. It checks that click DT SW and a white point disappears
completely.
12. Click WDD checks white point compensation being
performed and disappearing.
3-13. High Temperature White point correction
Adjustment location: Computer screen
Measuring location: VIDEO OUT
Measuring equipment: Monitor display, Spot heater,
Radiation temperature gauge
Adjustment method:
1. Shield light with a blackout curtain and the box to provide
dark condition.
2. Switch to the adjustment software and display the
adjustment screen.
3. Use the spot heater to evenly heat the underside of the
sensor to 75°C.
4. Press the “ ” key to move to WDD, and then click
“AUTO” in white spot correction mode. The correction will
be carried out and the results will be displayed.
5. Carry out white spot correction three times at “AUTO”.
6. Switch to the WDDL5CS software and display the
adjustment screen.
7. Click the Manual in MODE.
8. Click the START.
9. Please pile up a false white point and a white point.
10. It checks that click DT SW and a white point disappears
completely.
11. Click WDD checks white point compensation being
performed and disappearing.
Please Adjust...
12. Click the END button of WDDL5CS screen.
3-14. Line Phase Adjustment
Adjustment location: Computer screen
Measuring location: VIDEO OUT, 24 V AC/GND
Measuring equipment: Oscilloscope
Adjusting method:
1. Use the “ ” button to be PHASE in the adjustment window.
2. Connect the camera to a 24 V AC /50 Hz (VCC-WD8875P,
VCC-WD8878PC) or 60 Hz (VCC-WD8874) power source.
3. Connect the + (red) power supply lead to the HOT side of
the probe, and connect the – (black) power supply lead to
the COLD side of the probe.
4. Use the scroll bar to adjust the leading edge of the vertical
sync signal and zero-cross shift of the AC 24 power supply
to 0 ± 0.2 msec.
5. Click the END button.
NOTE:
1. If the CA-1 circuit board has been replaced, be sure to
carry out white spot correction.
2. If the CA-2 circuit board has been replaced, be sure to
also replace the CA-1 circuit board and carry out white
spot correction.
Please Adjust...
White Defect = oo,oo
***
***

-13 -
MEMO

14
4. PARTS LIST (R)
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
ACCESSORIES & PACKING MATERIALS
9110 613 217 4541 INST MANUAL, A6,Chinese (Simplified),
VCC-WD8878PC ONLY
9110 613 218 2164 INST MANUAL,GB/F A6, English,French,
EXCEPT VCC-WD8878PC
9111 613 218 2171 INST MANUAL,D/CS A6,German,
Chinese (Simplified),VCC-WD8875P ONLY
9111 613 218 4175 INST MANUAL,E A6,Spanish,
VCC-WD8874 ONLY
7001 613 212 0197 CARTON CASE INNER,
EXCEPT VCC-WD8878PC
7001 613 212 6366 CARTON CASE INNER,VCC-WD8878PC ONLY
7002 613 184 1659 CUSHION BAG
7007 613 218 1716 CUSHION BAG,SET (LENS SIDE),
VCC-WD8878PC ONLY
CABINET & CHASSIS PARTS
5008 613 203 9635 MOUNTING
5009 613 203 9628 COVER MOUNTING
5010 613 217 5746 CABINET,FRONT-L5CS2
5012 613 217 3766 COVER TOP-L5CS2
5014 613 217 3773 COVER BOTTOM-L5CS2
5016 613 217 7603 CABINET,BACK-L5CU2
5018 613 217 3803 DEC SIDE-L5CS2
5020 613 218 5950 DEC INDICATOR-L5CU2
5022 613 217 6927 DEC,BUTTON-L5CS2
6010 613 217 3780 CHASSIS-L5CS2 (N.S.P)
8000 613 218 4786 SPACER HEAT TRANSFER
NOTE :
If the CA-2 circuit board has been replaced, be sure to also
replace the CA-1 circuit board and carry out white spot correction.
CA2 613 217 6385 COMPL PWB,CA-2 F/W,VCC-WD8875P ONLY
CA2 613 217 6439 COMPL PWB,CA-2 F/W,VCC-WD8874 ONLY
CA2 613 218 9644 COMPL PWB,CA-2 F/W,
VCC-WD8878PC ONLY
CA3 613 217 1458 COMPL PWB,CA-3
CA4 613 217 7450 COMPL PWB,CA-4
NJ510 312 051 6000 SPECIAL SCREW-3X4
NJ512 411 126 4702 SCR PAN+SW+W 3X6
NJ514 411 023 3709 SCR S-TPG PAN 3X10
NJ516 411 098 1006 SCR S-TPG BIN 3X6
NJ518 411 097 9409 SCR PAN PCS 2X4
NJ520 411 097 9409 SCR PAN PCS 2X4
NJ610 411 030 5406 SCR BIN 2X4
NJ612 411 030 5406 SCR BIN 2X4
NJ614 411 030 5406 SCR BIN 2X4
NJ616 411 097 9409 SCR PAN PCS 2X4
NJ620 411 192 0301 SCR PAN+SW 3X10
NJ622 312 060 4103 SPECIAL SCREW-3X12
NJ623 411 194 9401 SCR PAN PCS 2.0X5.0
#1
6001 613 217 4398 ASSY,HOUSING L5CU
6002 613 218 5714 SPACER FILTER-L5CS
6004 613 217 4367 HOLDER CA1-L5CS
6005 613 217 4343 CAM-L5CS
6006 613 217 6293 MOUNTING,LENS
6007 613 217 5739 CHASSIS-FRONT-L5CS2 (N.S.P)
6008 613 217 6880 SPRING PLATE HOUSING
6009 613 217 6897 SPRING PLATE FIX CAM
6011 613 218 6018 SPACER FILTER
6013 613 218 5356 SPACER SHADE-L5CS
6014 613 218 5707 SPACER COOLER CMOS
6016 613 218 7046 SPACER GUIDE
6018 613 219 0640 SPACER STOPPER
6320 645 084 4027 ASSY,MOTOR DN
8001 645 098 5638 OPTICAL FILTER
8002 645 098 9285 OPTICAL,DUMMY GLASS
CA1 613 217 6408 COMPL PWB,CA-1
NJ601 411 030 5406 SCR BIN 2X4
NJ602 411 191 1903 SCR S-TPG BIN 2X5
NJ603 411 107 4509 SCR PAN PCS 2X2
NJ604 411 170 6509 SCR PAN PCS 2X4
NJ625 411 187 6509 SCR S-TPG PAN PCS 1.4X4

15
L5CU2/XE (MS)
NJ510
NJ518
5012
NJ610
CA3 5010
NJ616
6010
5014
NJ516
5018
5008
5009
NJ512
NJ520
NJ612
5016
NJ514
NJ614
NJ612
NJ622 NJ616
NJ623
NJ620
CA2
NJ614
5022
CA4
#1
6014
NJ604
6008
NJ603
6008
NJ603
NJ625
6320
CA1
NJ601
6004 NJ602
6002
6011
8002
6001
6016
NJ603
6009
6006
6005
6013
6007
#1
NJ518
5020
8000
6018
8001

16
ELECTRICAL PARTS
Note:
1. Materials of Capacitors and Resistors are abbreviated as follows ;
Resistors Capacitors
MT-FILM Metallized Film Resistor MT-POLYEST Metallized Polyester Capacitor
MT-GLAZE Metallized Glaze Resistor MT-COMPO Metallized Composite Capacitor
OXIDE-MT Oxide Metallized Film Resistor TA-SOLID Tantalum Solid Capacitor
AL-SOLID Aluminum Solid Capacitor
NP-ELECT Non-Polarized Electrolytic Capacitor
OS-SOLID Aluminum Solid Capacitors with Organic
Semiconductive Electrolytic Capacitor
DL-ELECT Double Layered Electrolytic Capacitor
POS-SOLID Polymerized Organic Semiconductor Capacitor
2. Tolerance of Capacitor (10pF over) and Resistor are noted with follow symboles.
F ............1% G ............2% J ............5% K ............10%
M ..........20% N ..........30% Z ..........+80% ~ -20%
3. Capacitors
U : µF P : pF
4. Inductors
UH : µH MH : mH
5. N.S.P. : Not available as service parts.
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
COMPL PWB,CA-1
613 217 6408
(SEMICONDUCTORS)
Q1501 405 222 0409 TR 2SA1532G0
OR 405 221 5207 TR 2SA1532GC
Q1552 405 222 0409 TR 2SA1532G0
OR 405 221 5207 TR 2SA1532GC
(INTEGRATED CIRCUITS)
IC101 409 699 8401 IC TC922S (N.S.P)
IC131 409 677 8409 IC NJM2877F3-05
IC132 409 677 8409 IC NJM2877F3-05
(INDUCTOR)
L1201 945 048 5757 IMPEDANCE,120 OHM P
(CAPACITORS)
C1001 303 155 1800 CERAMIC 0.01U K 25V
C1002 303 155 1800 CERAMIC 0.01U K 25V
C1003 303 155 1800 CERAMIC 0.01U K 25V
C1004 303 155 1800 CERAMIC 0.01U K 25V
C1005 303 452 9400 CERAMIC 10U K 10V
C1006 303 358 8309 CERAMIC 1U K 10V
C1007 303 452 9400 CERAMIC 10U K 10V
C1009 303 452 9400 CERAMIC 10U K 10V
C1010 303 155 1800 CERAMIC 0.01U K 25V
C1011 303 419 8903 CERAMIC 10U M 6.3V
C1012 303 419 8903 CERAMIC 10U M 6.3V
C1014 303 433 1102 CERAMIC 1U K 10V
C1015 303 433 1102 CERAMIC 1U K 10V
C1016 303 433 1102 CERAMIC 1U K 10V
C1201 303 419 8903 CERAMIC 10U M 6.3V
C1204 303 155 1800 CERAMIC 0.01U K 25V
C1205 303 155 1800 CERAMIC 0.01U K 25V
C1301 303 155 1800 CERAMIC 0.01U K 25V
C1302 303 155 1800 CERAMIC 0.01U K 25V
C1303 303 338 0309 CERAMIC 0.1U K 10V
C1304 303 408 5500 CERAMIC 2.2U K 16V
C1305 303 338 0309 CERAMIC 0.1U K 10V
C1307 303 383 5205 CERAMIC 4.7U K 6.3V
C1308 303 338 0309 CERAMIC 0.1U K 10V
C1309 303 338 0309 CERAMIC 0.1U K 10V
C1501 303 113 3808 CERAMIC 1000P K 50V
C1551 303 113 3808 CERAMIC 1000P K 50V
(RESISTORS)
R1002 301 105 1108 MT-GLAZE 12K JA 1/16W
R1003 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1005 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
R1006 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
R1007 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R1008 301 112 8008 MT-GLAZE 5.6 JA 1/16W
R1009 301 105 0507 MT-GLAZE 1K JA 1/16W
R1203 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1204 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1205 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1206 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1207 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1208 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1209 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1210 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1211 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1212 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1213 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1214 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1215 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1216 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1217 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1218 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1301 301 224 9306 MT-GLAZE 1K JA 1/16W
R1302 301 234 4902 MT-GLAZE 150K JA 1/16W
R1501 301 038 6300 MT-GLAZE 470 JA 1/10W
R1502 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R1551 301 038 6300 MT-GLAZE 470 JA 1/10W
R1552 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
(MISCELLANEOUS)
Y1001 613 212 5062 SPACER,SHAFT
(CONNECTOR)
CN101 645 097 6100 SOCKET,PWB-WIRE 2 (N.S.P)
COMPL PWB,CA-2
613 217 6378 VCC-WD8875P ONLY
613 217 6422 VCC-WD8874 ONLY
613 218 9637 VCC-WD8878PC ONLY
(VARISTORS)
VA287 308 050 1504 VARISTOR AVR-M1608C220KT
VA288 308 050 1504 VARISTOR AVR-M1608C220KT
(SEMICONDUCTORS)
Q2052 305 212 7503 TR RTL030P02
Q2101 305 168 3703 TR DTC144EM
Q2451 305 115 5705 TR DTA144EE
Q2501 305 115 5705 TR DTA144EE
Q2801 305 172 8800 TR 2SC5658-R
Q2802 305 172 8800 TR 2SC5658-R
Q2803 305 168 3901 TR EMZ1
Q2804 305 172 8800 TR 2SC5658-R
Q2821 305 168 4502 TR 2SA2029-R
Q2822 305 172 8800 TR 2SC5658-R
Q2872 305 172 8800 TR 2SC5658-R
Q2873 305 172 8800 TR 2SC5658-R
Q2901 305 172 8800 TR 2SC5658-R
(INTEGRATED CIRCUITS)
IC201 309 669 6904 IC AD9971BCPZ
IC205 309 669 6904 IC AD9971BCPZ
IC211 410 671 4007 IC XC3SD3400A-4CSG484C,BGA (N.S.P)

17
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
L2870 945 048 5757 IMPEDANCE,120 OHM P
L2872 945 020 1869 INDUCTOR,750 OHM
L2873 945 020 1869 INDUCTOR,750 OHM
L2876 945 020 1869 INDUCTOR,750 OHM
L2900 645 068 9024 INDUCTOR,47U K
L2901 645 068 9024 INDUCTOR,47U K
L2903 945 084 2635 INDUCTOR,1.2U J
L2904 645 069 4516 INDUCTOR,47U J
L2905 945 084 2635 INDUCTOR,1.2U J
L2906 645 068 9024 INDUCTOR,47U K
L3009 945 048 5757 IMPEDANCE,120 OHM P
(CAPACITORS)
C2001 303 338 0309 CERAMIC 0.1U K 10V
C2002 303 338 0309 CERAMIC 0.1U K 10V
C2003 303 372 7500 CERAMIC 2.2U K 6.3V
C2004 303 176 0202 CERAMIC 0.1U Z 25V
C2005 303 409 3406 CERAMIC 0.1U K 16V
C2006 303 338 0309 CERAMIC 0.1U K 10V
C2007 303 338 0309 CERAMIC 0.1U K 10V
C2008 303 338 0309 CERAMIC 0.1U K 10V
C2009 303 338 0309 CERAMIC 0.1U K 10V
C2010 303 338 0309 CERAMIC 0.1U K 10V
C2012 303 338 0309 CERAMIC 0.1U K 10V
C2013 303 409 3406 CERAMIC 0.1U K 16V
C2015 303 382 1109 TA-SOLID 4.7U M 10V
C2020 303 392 5005 CERAMIC 22U M 6.3V
C2024 303 338 0309 CERAMIC 0.1U K 10V
C2025 303 276 1307 CERAMIC 1000P K 50V
C2028 303 276 1307 CERAMIC 1000P K 50V
C2030 303 338 0309 CERAMIC 0.1U K 10V
C2031 303 338 0309 CERAMIC 0.1U K 10V
C2032 303 429 6005 POS-SOLID 47U M 6.3V
C2033 303 338 0309 CERAMIC 0.1U K 10V
C2035 303 338 0309 CERAMIC 0.1U K 10V
C2042 303 358 8309 CERAMIC 1U K 10V
C2044 303 358 8309 CERAMIC 1U K 10V
C2045 303 276 1307 CERAMIC 1000P K 50V
C2050 303 372 7500 CERAMIC 2.2U K 6.3V
C2051 303 338 0309 CERAMIC 0.1U K 10V
C2052 303 338 0309 CERAMIC 0.1U K 10V
C2053 303 338 0309 CERAMIC 0.1U K 10V
C2055 303 382 1109 TA-SOLID 4.7U M 10V
C2058 303 338 0309 CERAMIC 0.1U K 10V
C2059 303 338 0309 CERAMIC 0.1U K 10V
C2061 303 338 0309 CERAMIC 0.1U K 10V
C2062 303 338 0309 CERAMIC 0.1U K 10V
C2063 303 276 1307 CERAMIC 1000P K 50V
C2064 303 392 5005 CERAMIC 22U M 6.3V
C2066 303 276 1307 CERAMIC 1000P K 50V
C2067 303 338 0309 CERAMIC 0.1U K 10V
C2068 303 338 0309 CERAMIC 0.1U K 10V
C2069 303 338 0309 CERAMIC 0.1U K 10V
C2070 303 338 0309 CERAMIC 0.1U K 10V
C2071 303 429 6005 POS-SOLID 47U M 6.3V
C2080 303 358 8309 CERAMIC 1U K 10V
C2082 303 358 8309 CERAMIC 1U K 10V
C2083 303 276 1307 CERAMIC 1000P K 50V
C2101 303 419 8903 CERAMIC 10U M 6.3V
C2102 303 276 1307 CERAMIC 1000P K 50V
C2103 303 276 1307 CERAMIC 1000P K 50V
C2104 303 338 0309 CERAMIC 0.1U K 10V
C2105 303 276 1307 CERAMIC 1000P K 50V
C2106 303 338 0309 CERAMIC 0.1U K 10V
C2107 303 276 1307 CERAMIC 1000P K 50V
C2108 303 338 0309 CERAMIC 0.1U K 10V
C2109 303 338 0309 CERAMIC 0.1U K 10V
C2110 303 276 1307 CERAMIC 1000P K 50V
C2111 303 338 0309 CERAMIC 0.1U K 10V
C2112 303 276 1307 CERAMIC 1000P K 50V
C2114 303 429 3202 CERAMIC 22U M 6.3V
C2115 303 429 3202 CERAMIC 22U M 6.3V
C2116 303 338 0309 CERAMIC 0.1U K 10V
C2117 303 338 0309 CERAMIC 0.1U K 10V
C2118 303 338 0309 CERAMIC 0.1U K 10V
C2119 303 276 1307 CERAMIC 1000P K 50V
C2120 303 276 1307 CERAMIC 1000P K 50V
C2122 303 338 0309 CERAMIC 0.1U K 10V
C2123 303 338 0309 CERAMIC 0.1U K 10V
IC212 410 676 4101 IC AT45DB161D-SU-P01,
EXCEPT VCC-WD8874
IC212 410 676 4200 IC AT45DB161D-SU-N01,VCC-WD8874 ONLY
IC213 410 635 0106 IC UPD6467GR-580-A,
EXCEPT VCC-WD8878PC
IC213 410 658 6604 IC UPD6467GR-587-A,VCC-WD8878PC ONLY
IC214 409 694 6105 IC LTC3568EDD
IC216 309 301 5401 IC TC7S14FU(BRA)
IC235 410 665 1500 IC PL611S-02-B83TC,VCC-WD8874 ONLY
IC235 410 665 1708 IC PL611S-02-B84TC,EXCEPT VCC-WD8874
IC236 410 665 1906 IC PL611S-02-C19TC,VCC-WD8874 ONLY
IC241 409 678 8309 IC UPC358GR-9LG-A
IC251 309 320 9107 IC TC7SU04FU
IC252 309 323 9005 IC TC7S04FU
IC253 309 320 9107 IC TC7SU04FU
IC254 309 323 9005 IC TC7S04FU
IC261 410 668 5208 IC UPD70F3735GK(S)-GAK-AX (N.S.P)
IC262 410 649 0703 IC AT24C128B-TH-T
OR 410 670 4602 IC CAT24C128YI-GT3
OR 410 672 7106 IC M24128-BWDW6TP
OR 410 678 2303 IC M24128-BRDW6TP
IC263 309 505 9601 IC TK11133CS
IC264 409 698 4305 IC BD5228G
IC271 410 670 5500 IC DAC908E
IC272 410 670 5500 IC DAC908E
IC279 309 626 7401 IC TK11150CS-G
IC281 309 478 2203 IC NJM2274R
IC291 309 167 7205 IC NJM2406F
IC292 309 368 5802 IC TC7SH08FU
IC293 309 368 5802 IC TC7SH08FU
IC294 309 323 9005 IC TC7S04FU
IC295 309 305 3106 IC TC7W74FU
IC296 309 359 9000 IC BA7071F
IC298 309 368 5802 IC TC7SH08FU
(DIODES)
D2001 307 201 7600 LED SML-310MT
D2303 307 155 5509 VARACTOR DI HVU316
D2451 307 151 0409 VARACTOR DI HVU200A
D2821 307 206 5403 ZENER DIODE UDZS8.2B
D2822 307 206 5403 ZENER DIODE UDZS8.2B
D2823 307 017 2905 LED SEL2110R,
D2901 307 236 0904 DIODE DSH015-TLE
D2902 307 236 0904 DIODE DSH015-TLE
(OSCILLATORS)
X2351 645 098 5591 OSC,CRYSTAL 17.734475MHZ,
EXCEPT VCC-WD8874
X2351 645 098 5607 OSC,CRYSTAL 14.318180MHZ,
VCC-WD8874 ONLY
X2501 645 057 4566 OSC,CRYSTAL 28.375MHZ,
EXCEPT VCC-WD8874
X2501 645 057 4573 OSC,CRYSTAL 28.63636MHZ,
VCC-WD8874 ONLY
X2601 945 053 3878 OSC,CERAMIC 5.00MHZ
(TRIMMERS)
CT231 645 069 5131 TRIMMER,30PF
CT251 645 069 5131 TRIMMER,30PF
(INDUCTORS)
L2001 945 048 5757 IMPEDANCE,120 OHM P
L2050 945 048 5757 IMPEDANCE,120 OHM P
L2101 945 048 5757 IMPEDANCE,120 OHM P
L2102 945 048 5757 IMPEDANCE,120 OHM P
L2103 945 048 5757 IMPEDANCE,120 OHM P
L2202 645 098 2187 INDUCTOR,1.8U N
L2401 645 068 9024 INDUCTOR,47U K
L2402 645 068 9024 INDUCTOR,47U K
L2451 945 004 2615 INDUCTOR,2.2U J
L2601 945 048 5757 IMPEDANCE,120 OHM P
L2602 945 048 5757 IMPEDANCE,120 OHM P
L2701 945 048 5757 IMPEDANCE,120 OHM P
L2702 945 048 5757 IMPEDANCE,120 OHM P
L2721 945 048 5757 IMPEDANCE,120 OHM P
L2722 945 048 5757 IMPEDANCE,120 OHM P
L2791 945 048 5757 IMPEDANCE,120 OHM P
L2801 645 068 8997 INDUCTOR,33U J,EXCEPT VCC-WD8874
L2802 645 068 8898 INDUCTOR,22U J
L2803 645 068 8898 INDUCTOR,22U J
L2821 945 055 3135 INDUCTOR,68U J
L2824 645 068 9000 INDUCTOR,10U K

18
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C2124 303 276 1307 CERAMIC 1000P K 50V
C2125 303 276 1307 CERAMIC 1000P K 50V
C2126 303 338 0309 CERAMIC 0.1U K 10V
C2127 303 338 0309 CERAMIC 0.1U K 10V
C2128 303 276 1307 CERAMIC 1000P K 50V
C2129 303 276 1307 CERAMIC 1000P K 50V
C2130 303 338 0309 CERAMIC 0.1U K 10V
C2131 303 419 8903 CERAMIC 10U M 6.3V
C2132 303 338 0309 CERAMIC 0.1U K 10V
C2133 303 338 0309 CERAMIC 0.1U K 10V
C2134 303 276 1307 CERAMIC 1000P K 50V
C2135 303 276 1307 CERAMIC 1000P K 50V
C2136 303 338 0309 CERAMIC 0.1U K 10V
C2137 303 276 1307 CERAMIC 1000P K 50V
C2138 303 338 0309 CERAMIC 0.1U K 10V
C2139 303 338 0309 CERAMIC 0.1U K 10V
C2140 303 276 1307 CERAMIC 1000P K 50V
C2141 303 276 1307 CERAMIC 1000P K 50V
C2142 303 338 0309 CERAMIC 0.1U K 10V
C2143 303 276 1307 CERAMIC 1000P K 50V
C2144 303 157 3604 CERAMIC 100P J 50V
C2145 303 338 0309 CERAMIC 0.1U K 10V
C2146 303 276 1307 CERAMIC 1000P K 50V
C2147 303 338 0309 CERAMIC 0.1U K 10V
C2148 303 338 0309 CERAMIC 0.1U K 10V
C2149 303 276 1307 CERAMIC 1000P K 50V
C2150 303 338 0309 CERAMIC 0.1U K 10V
C2151 303 276 1307 CERAMIC 1000P K 50V
C2152 303 338 0309 CERAMIC 0.1U K 10V
C2153 303 276 1307 CERAMIC 1000P K 50V
C2154 303 338 0309 CERAMIC 0.1U K 10V
C2155 303 276 1307 CERAMIC 1000P K 50V
C2156 303 338 0309 CERAMIC 0.1U K 10V
C2157 303 276 1307 CERAMIC 1000P K 50V
C2201 303 113 3808 CERAMIC 1000P K 50V
C2202 303 421 0209 CERAMIC 47U M 6.3V
C2204 303 155 1800 CERAMIC 0.01U K 25V
C2205 303 421 0209 CERAMIC 47U M 6.3V
C2206 303 421 0209 CERAMIC 47U M 6.3V
C2207 303 157 2904 CERAMIC 47P J 50V
C2352 303 433 1102 CERAMIC 1U K 10V
C2353 303 276 1307 CERAMIC 1000P K 50V
C2355 303 419 8903 CERAMIC 10U M 6.3V
C2401 303 276 1000 CERAMIC 0.01U K 16V
C2402 303 378 6002 CERAMIC 4.7U K 16V
C2403 303 276 1307 CERAMIC 1000P K 50V
C2404 303 397 7608 CERAMIC 1U K 25V
C2405 303 207 0300 CERAMIC 1U Z 16V
C2406 303 276 1000 CERAMIC 0.01U K 16V
C2407 303 276 1000 CERAMIC 0.01U K 16V
C2410 303 383 5205 CERAMIC 4.7U K 6.3V
C2411 303 338 0309 CERAMIC 0.1U K 10V
C2412 303 338 0309 CERAMIC 0.1U K 10V
C2451 303 378 6002 CERAMIC 4.7U K 16V
C2453 303 276 1307 CERAMIC 1000P K 50V
C2454 303 276 2809 CERAMIC 18P J 50V,
EXCEPT VCC-WD8874
C2454 303 305 8505 CERAMIC 15P J 50V,
VCC-WD8874 ONLY
C2455 303 419 8903 CERAMIC 10U M 6.3V
C2456 303 276 1307 CERAMIC 1000P K 50V
C2457 303 276 1000 CERAMIC 0.01U K 16V
C2458 303 305 8505 CERAMIC 15P J 50V
C2460 303 433 1102 CERAMIC 1U K 10V
C2461 303 276 1307 CERAMIC 1000P K 50V
C2501 303 276 1307 CERAMIC 1000P K 50V
C2502 303 276 1307 CERAMIC 1000P K 50V
C2503 303 276 2106 CERAMIC 3P C 50V,
EXCEPT VCC-WD8874
C2503 303 313 3608 CERAMIC 4P C 50V,VCC-WD8874 ONLY
C2504 303 419 8903 CERAMIC 10U M 6.3V
C2505 303 276 1307 CERAMIC 1000P K 50V
C2507 303 433 1102 CERAMIC 1U K 10V
C2508 303 276 1307 CERAMIC 1000P K 50V
C2601 303 276 1000 CERAMIC 0.01U K 16V
C2602 303 408 5500 CERAMIC 2.2U K 16V
C2603 303 338 0309 CERAMIC 0.1U K 10V
C2604 303 338 0309 CERAMIC 0.1U K 10V
C2605 303 338 0309 CERAMIC 0.1U K 10V
C2606 303 294 6100 CERAMIC 100P J 50V
C2608 303 294 6100 CERAMIC 100P J 50V
C2609 303 294 6100 CERAMIC 100P J 50V
C2610 303 383 5205 CERAMIC 4.7U K 6.3V
C2611 303 338 0309 CERAMIC 0.1U K 10V
C2612 303 338 0309 CERAMIC 0.1U K 10V
C2613 303 338 0309 CERAMIC 0.1U K 10V
C2614 303 383 5205 CERAMIC 4.7U K 6.3V
C2615 303 338 0309 CERAMIC 0.1U K 10V
C2616 303 358 8309 CERAMIC 1U K 10V
C2617 303 383 5205 CERAMIC 4.7U K 6.3V
C2618 303 338 0309 CERAMIC 0.1U K 10V
C2619 303 276 1307 CERAMIC 1000P K 50V
C2620 303 276 1307 CERAMIC 1000P K 50V
C2621 303 358 8309 CERAMIC 1U K 10V
C2622 303 276 1307 CERAMIC 1000P K 50V
C2623 303 325 6307 CERAMIC 0.22U K 10V
C2624 303 324 6407 CERAMIC 0.022U K 16V
C2701 303 419 8903 CERAMIC 10U M 6.3V
C2702 303 298 9602 CERAMIC 0.1U K 16V
C2703 303 298 9602 CERAMIC 0.1U K 16V
C2704 303 338 0309 CERAMIC 0.1U K 10V
C2705 303 419 8903 CERAMIC 10U M 6.3V
C2706 303 298 9602 CERAMIC 0.1U K 16V
C2707 303 338 0309 CERAMIC 0.1U K 10V
C2721 303 419 8903 CERAMIC 10U M 6.3V
C2722 303 298 9602 CERAMIC 0.1U K 16V
C2723 303 298 9602 CERAMIC 0.1U K 16V
C2724 303 338 0309 CERAMIC 0.1U K 10V
C2725 303 419 8903 CERAMIC 10U M 6.3V
C2726 303 298 9602 CERAMIC 0.1U K 16V
C2727 303 338 0309 CERAMIC 0.1U K 10V
C2791 303 408 5500 CERAMIC 2.2U K 16V
C2792 303 338 0309 CERAMIC 0.1U K 10V
C2793 303 276 1000 CERAMIC 0.01U K 16V
C2801 303 384 8809 ELECT 22U M 6.3V
C2802 303 155 1602 CERAMIC 33P J 50V
C2803 303 383 5205 CERAMIC 4.7U K 6.3V
C2804 303 139 7507 CERAMIC 39P J 50V,
EXCEPT VCC-WD8874
C2805 303 145 9908 CERAMIC 22P J 50V
C2806 303 338 0309 CERAMIC 0.1U K 10V
C2808 303 146 0102 CERAMIC 47P J 50V
C2809 303 176 0202 CERAMIC 0.1U Z 25V
C2811 303 157 1907 CERAMIC 10P D 50V
C2812 303 145 9908 CERAMIC 22P J 50V
C2813 303 382 1109 TA-SOLID 4.7U M 10V
C2814 303 338 0309 CERAMIC 0.1U K 10V
C2821 303 338 0309 CERAMIC 0.1U K 10V
C2822 303 276 2809 CERAMIC 18P J 50V,
EXCEPT VCC-WD8874
C2822 303 309 2509 CERAMIC 27P J 50V,
VCC-WD8874 ONLY
C2824 303 155 1800 CERAMIC 0.01U K 25V
C2825 303 338 0309 CERAMIC 0.1U K 10V
C2827 303 338 0309 CERAMIC 0.1U K 10V
C2829 303 429 3202 CERAMIC 22U M 6.3V
C2830 303 338 0309 CERAMIC 0.1U K 10V
C2832 303 358 8309 CERAMIC 1U K 10V
C2835 303 429 3202 CERAMIC 22U M 6.3V
C2836 303 381 4804 ELECT 100U M 6.3V
C2871 303 276 1307 CERAMIC 1000P K 50V
C2872 303 276 1307 CERAMIC 1000P K 50V
C2875 303 338 0309 CERAMIC 0.1U K 10V
C2901 303 383 5205 CERAMIC 4.7U K 6.3V
C2902 303 319 3503 CERAMIC 220P K 50V
C2903 303 276 1307 CERAMIC 1000P K 50V
C2904 303 311 5802 CERAMIC 47P J 50V
C2905 303 338 0309 CERAMIC 0.1U K 10V
C2906 303 338 0309 CERAMIC 0.1U K 10V
C2907 303 276 1307 CERAMIC 1000P K 50V
C2908 303 338 0309 CERAMIC 0.1U K 10V
C2909 303 383 5205 CERAMIC 4.7U K 6.3V
C2910 303 276 1307 CERAMIC 1000P K 50V
C2911 303 338 0309 CERAMIC 0.1U K 10V
C2912 303 308 3408 CERAMIC 390P K 50V
C2913 303 324 6407 CERAMIC 0.022U K 16V

19
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
C2914 303 311 7806 CERAMIC 8P D 50V
C2915 303 308 3408 CERAMIC 390P K 50V
C2916 303 358 8309 CERAMIC 1U K 10V
C2917 303 279 3100 CERAMIC 150P C 50V
C2918 303 338 0309 CERAMIC 0.1U K 10V
C2919 303 276 1307 CERAMIC 1000P K 50V
C2920 303 358 8309 CERAMIC 1U K 10V
C2921 303 276 1307 CERAMIC 1000P K 50V
C2922 303 348 9101 CERAMIC 0.47U K 6.3V
C2926 303 338 0309 CERAMIC 0.1U K 10V
(RESISTOR PACK)
RB279 945 033 1443 R-NETWORK 4.7KX4 1/16W
(RESISTORS)
R2001 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
R2002 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
R2003 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
R2004 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
R2005 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
R2006 301 225 7905 MT-GLAZE 220 JA 1/16W
R2007 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2008 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2009 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2010 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2011 301 225 1101 MT-GLAZE 27 JA 1/16W
R2012 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2013 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2014 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2015 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2016 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2017 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2019 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2020 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2026 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2028 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2051 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2053 301 225 7905 MT-GLAZE 220 JA 1/16W
R2054 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2055 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2056 301 225 1101 MT-GLAZE 27 JA 1/16W
R2057 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2058 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2059 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2060 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2061 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2062 301 105 0606 MT-GLAZE 10K JA 1/16W
R2081 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2101 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2102 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2103 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2104 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2105 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2106 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2107 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2108 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2109 301 225 8001 MT-GLAZE 330 JA 1/16W
R2112 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2113 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2114 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2115 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2116 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2117 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2118 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2119 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2120 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2121 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2122 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2123 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2124 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2126 301 225 0302 MT-GLAZE 33 JA 1/16W
R2127 301 225 0302 MT-GLAZE 33 JA 1/16W
R2128 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2132 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2133 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2134 301 224 9009 MT-GLAZE 10K JA 1/16W
R2136 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2137 301 226 1506 MT-GLAZE 0.000 ZA 1/16W,
VCC-WD8874 ONLY
R2138 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2139 301 225 1200 MT-GLAZE 4.7K JA 1/16W
R2140 301 224 9009 MT-GLAZE 10K JA 1/16W
R2142 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2145 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2146 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2147 301 225 1200 MT-GLAZE 4.7K JA 1/16W
R2148 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2149 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2150 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2151 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2152 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2153 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2155 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2157 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2159 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2160 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2161 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2163 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2165 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2166 301 224 9009 MT-GLAZE 10K JA 1/16W,
VCC-WD8874 ONLY
R2166 301 226 1506 MT-GLAZE 0.000 ZA 1/16W,
EXCEPT VCC-WD8874
R2167 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2168 301 037 5007 MT-GLAZE 0.000 ZA 1/10W
R2169 301 224 8804 MT-GLAZE 100 JA 1/16W
R2170 301 224 8903 MT-GLAZE 100K JA 1/16W
R2171 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2172 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2174 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2175 301 225 0302 MT-GLAZE 33 JA 1/16W
R2176 301 225 0302 MT-GLAZE 33 JA 1/16W
R2177 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2178 301 225 0302 MT-GLAZE 33 JA 1/16W
R2180 301 225 0302 MT-GLAZE 33 JA 1/16W
R2182 301 225 1200 MT-GLAZE 4.7K JA 1/16W
R2185 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2187 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2188 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2189 301 224 9009 MT-GLAZE 10K JA 1/16W
R2191 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2192 301 225 0302 MT-GLAZE 33 JA 1/16W
R2193 301 225 0302 MT-GLAZE 33 JA 1/16W
R2196 301 225 0302 MT-GLAZE 33 JA 1/16W
R2198 301 224 9009 MT-GLAZE 10K JA 1/16W
R2199 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2200 301 283 7107 MT-GLAZE 100 DC 1/16W
R2201 301 283 7107 MT-GLAZE 100 DC 1/16W
R2202 301 283 7107 MT-GLAZE 100 DC 1/16W
R2203 301 283 7107 MT-GLAZE 100 DC 1/16W
R2204 301 283 7107 MT-GLAZE 100 DC 1/16W
R2205 301 283 7107 MT-GLAZE 100 DC 1/16W
R2206 301 225 0302 MT-GLAZE 33 JA 1/16W
R2207 301 225 0302 MT-GLAZE 33 JA 1/16W
R2208 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2209 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2211 301 225 0302 MT-GLAZE 33 JA 1/16W
R2213 301 225 0302 MT-GLAZE 33 JA 1/16W
R2214 301 225 0302 MT-GLAZE 33 JA 1/16W
R2215 301 225 0302 MT-GLAZE 33 JA 1/16W
R2217 301 225 0302 MT-GLAZE 33 JA 1/16W
R2218 301 225 0302 MT-GLAZE 33 JA 1/16W
R2219 301 225 0302 MT-GLAZE 33 JA 1/16W
R2221 301 224 9009 MT-GLAZE 10K JA 1/16W
R2229 301 105 1108 MT-GLAZE 12K JA 1/16W
R2230 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2231 301 224 9306 MT-GLAZE 1K JA 1/16W
R2234 301 105 0705 MT-GLAZE 100K JA 1/16W
R2236 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2237 301 105 8008 MT-GLAZE 1M JA 1/16W
R2238 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2241 301 105 8008 MT-GLAZE 1M JA 1/16W
R2243 301 105 4307 MT-GLAZE 330K JA 1/16W
R2244 301 105 3805 MT-GLAZE 30K JA 1/16W
R2245 301 250 5006 MT-GLAZE 100K DC 1/16W
R2246 301 258 9303 MT-GLAZE 220K DC 1/16W
R2247 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2251 301 226 1506 MT-GLAZE 0.000 ZA 1/16W

20
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
R2352 301 225 0302 MT-GLAZE 33 JA 1/16W
R2353 301 225 0302 MT-GLAZE 33 JA 1/16W,
VCC-WD8874 ONLY
R2354 301 224 9306 MT-GLAZE 1K JA 1/16W,
VCC-WD8874 ONLY
R2354 301 225 8001 MT-GLAZE 330 JA 1/16W,
EXCEPT VCC-WD8874
R2355 301 224 9009 MT-GLAZE 10K JA 1/16W,
VCC-WD8874 ONLY
R2355 301 224 9405 MT-GLAZE 1.0M JA 1/16W,
EXCEPT VCC-WD8874
R2356 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2357 301 226 1506 MT-GLAZE 0.000 ZA 1/16W,
VCC-WD8874 ONLY
R2359 301 225 0302 MT-GLAZE 33 JA 1/16W
R2401 301 225 1705 MT-GLAZE 39K JA 1/16W
R2402 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R2403 301 225 1705 MT-GLAZE 39K JA 1/16W
R2404 301 224 9207 MT-GLAZE 15K JA 1/16W
R2405 301 225 8704 MT-GLAZE 120K JA 1/16W
R2406 301 224 8903 MT-GLAZE 100K JA 1/16W
R2407 301 225 8704 MT-GLAZE 120K JA 1/16W
R2408 301 224 9801 MT-GLAZE 220K JA 1/16W
R2409 301 225 1200 MT-GLAZE 4.7K JA 1/16W
R2410 301 225 1200 MT-GLAZE 4.7K JA 1/16W
R2411 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2412 301 225 1200 MT-GLAZE 4.7K JA 1/16W
R2413 301 224 9009 MT-GLAZE 10K JA 1/16W
R2414 301 224 9009 MT-GLAZE 10K JA 1/16W
R2451 301 225 0500 MT-GLAZE 33K JA 1/16W
R2452 301 224 8903 MT-GLAZE 100K JA 1/16W
R2454 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R2455 301 225 1408 MT-GLAZE 47K JA 1/16W
R2501 301 224 9009 MT-GLAZE 10K JA 1/16W
R2503 301 224 8903 MT-GLAZE 100K JA 1/16W
R2505 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2506 301 224 9405 MT-GLAZE 1.0M JA 1/16W
R2507 301 224 9009 MT-GLAZE 10K JA 1/16W
R2508 301 158 4002 MT-GLAZE 3.3 JA 1/16W
R2509 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2513 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2601 301 224 9306 MT-GLAZE 1K JA 1/16W
R2602 301 258 6609 MT-GLAZE 10K DC 1/16W,
EXCEPT VCC-WD8874
R2603 301 224 9009 MT-GLAZE 10K JA 1/16W
R2604 301 224 8804 MT-GLAZE 100 JA 1/16W
R2605 301 224 8804 MT-GLAZE 100 JA 1/16W
R2606 301 224 8804 MT-GLAZE 100 JA 1/16W
R2607 301 224 8804 MT-GLAZE 100 JA 1/16W
R2608 301 224 8804 MT-GLAZE 100 JA 1/16W
R2610 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2611 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2612 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2613 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2614 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2615 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2616 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2617 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2619 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2620 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2621 301 224 9306 MT-GLAZE 1K JA 1/16W
R2622 301 224 9306 MT-GLAZE 1K JA 1/16W
R2623 301 224 9306 MT-GLAZE 1K JA 1/16W
R2624 301 224 9009 MT-GLAZE 10K JA 1/16W
R2625 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2627 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2628 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2629 301 224 8804 MT-GLAZE 100 JA 1/16W
R2630 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2634 301 224 8903 MT-GLAZE 100K JA 1/16W
R2635 301 224 9009 MT-GLAZE 10K JA 1/16W
R2636 301 224 9306 MT-GLAZE 1K JA 1/16W
R2637 301 224 9009 MT-GLAZE 10K JA 1/16W
R2638 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2639 301 224 9504 MT-GLAZE 2.2K JA 1/16W
R2640 301 224 9504 MT-GLAZE 2.2K JA 1/16W
R2641 301 224 9504 MT-GLAZE 2.2K JA 1/16W
R2642 301 224 9009 MT-GLAZE 10K JA 1/16W
R2645 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2646 301 224 9009 MT-GLAZE 10K JA 1/16W
R2647 301 224 9009 MT-GLAZE 10K JA 1/16W
R2650 301 224 9009 MT-GLAZE 10K JA 1/16W
R2651 301 224 9009 MT-GLAZE 10K JA 1/16W
R2652 301 224 9009 MT-GLAZE 10K JA 1/16W
R2653 301 224 9009 MT-GLAZE 10K JA 1/16W
R2654 301 224 9009 MT-GLAZE 10K JA 1/16W
R2655 301 105 7902 MT-GLAZE 0.000 ZA 1/16W,
VCC-WD8874 ONLY
R2656 301 105 7902 MT-GLAZE 0.000 ZA 1/16W,
VCC-WD8874 ONLY
R2657 301 224 9900 MT-GLAZE 22K JA 1/16W
R2701 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2702 301 224 9603 MT-GLAZE 2.7K JA 1/16W
R2703 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2704 301 113 4405 MT-GLAZE 75 JA 1/16W
R2705 301 113 4405 MT-GLAZE 75 JA 1/16W
R2721 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2722 301 224 9603 MT-GLAZE 2.7K JA 1/16W
R2723 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2724 301 113 4405 MT-GLAZE 75 JA 1/16W
R2725 301 113 4405 MT-GLAZE 75 JA 1/16W
R2791 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2792 301 224 9306 MT-GLAZE 1K JA 1/16W
R2801 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2802 301 235 1405 MT-GALZE 1.2K JA 1/16W
R2803 301 235 1405 MT-GALZE 1.2K JA 1/16W
R2804 301 224 9504 MT-GLAZE 2.2K JA 1/16W
R2805 301 224 9306 MT-GLAZE 1K JA 1/16W
R2806 301 224 9108 MT-GLAZE 150 JA 1/16W
R2807 301 225 8001 MT-GLAZE 330 JA 1/16W
R2808 301 105 5205 MT-GLAZE 470 JA 1/16W,
EXCEPT VCC-WD8874
R2810 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2811 301 224 9306 MT-GLAZE 1K JA 1/16W
R2812 301 224 9306 MT-GLAZE 1K JA 1/16W
R2813 301 226 2404 MT-GLAZE 560 JA 1/16W
R2815 301 224 9306 MT-GLAZE 1K JA 1/16W
R2816 301 225 7905 MT-GLAZE 220 JA 1/16W
R2817 301 224 9108 MT-GLAZE 150 JA 1/16W
R2818 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2819 301 177 2409 MT-GLAZE 10M JA 1/16W
R2821 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2822 301 105 4703 MT-GLAZE 39K JA 1/16W
R2823 301 105 4703 MT-GLAZE 39K JA 1/16W
R2824 301 105 0507 MT-GLAZE 1K JA 1/16W
R2825 301 105 0507 MT-GLAZE 1K JA 1/16W
R2826 301 105 0507 MT-GLAZE 1K JA 1/16W
R2827 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2832 301 225 1408 MT-GLAZE 47K JA 1/16W
R2833 301 105 0507 MT-GLAZE 1K JA 1/16W
R2834 301 105 5403 MT-GLAZE 47K JA 1/16W
R2835 301 105 0507 MT-GLAZE 1K JA 1/16W
R2836 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2837 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2838 301 224 9009 MT-GLAZE 10K JA 1/16W
R2839 301 226 1506 MT-GLAZE 0.000 ZA 1/16W
R2841 301 166 5305 MT-FILM 68 DC 1/16W
R2844 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2847 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2848 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2849 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2850 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2851 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2852 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2853 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2854 301 105 7902 MT-GLAZE 0.000 ZA 1/16W
R2873 301 224 9009 MT-GLAZE 10K JA 1/16W
R2874 301 224 9009 MT-GLAZE 10K JA 1/16W
R2876 301 037 5403 MT-GLAZE 1K JA 1/10W
R2877 301 224 9009 MT-GLAZE 10K JA 1/16W
R2878 301 224 9009 MT-GLAZE 10K JA 1/16W
R2880 301 037 5403 MT-GLAZE 1K JA 1/10W
R2882 301 224 9009 MT-GLAZE 10K JA 1/16W
R2883 301 224 9009 MT-GLAZE 10K JA 1/16W
R2884 301 224 9009 MT-GLAZE 10K JA 1/16W
R2885 301 224 9009 MT-GLAZE 10K JA 1/16W
