Sanyo Twicell HF-A1U User manual

Size : A1
17.0 mm 1350mAh
1250mAh
1.2V
Fast Charge 2) 1350 mA x about 1.1h
Charge
Condition Fast Charge 2) 0°C - 40°C
0°C - 50°C
Less than
30days -20°C - 50°C
Less than
90days -20°C - 40°C
Less than
1year -20°C - 30°C
About 26 g
17.0(W) x 6.2(T) x 67.0(H) mm
T
y
pical Characteristics
Charge Discharge
Storage
Condition
Internal Impedance 3)
(after discharge to E.V.=1.0V)
Type : Nickel-Metal Hydride Battery
Capacity 1)
Typical
6.2 mm
Specifications
Cell T
y
pe HF-A1U
Nominal Voltage
Charging Current x Time
2)Use recommended charging system.
3)After a few charge and discharge cycles under the above 1) condition.
4)With tube.
Charge : 135mA×16h, Discharge : 270mA(E.V.=1.0V) at 20°C
Discharge Condition
Weight 4)
Size 4) : (Width) x (Thickness) x (Height)
Ambient Temp.
Minimum
Dimensions
(with tube)
Width
Thinckness
Height
67.0 mm
17.0 mm
6.2 mm
67.0 mm
1)Single cell capacity under the following condition.
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
0 250 500 750 1000 1250 1500
Discharge Capacity (mAh)
Cell Voltage (V)
Charge : 135mA×16h
Rest : 1h
Discharge : 270mA,1350mA,2700mA
(E.V.=1.0V)
Ambient Temp. : 20°C
270mA 1350mA 2700mA
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
0 1020304050607080
Charge Time (min)
Cell Voltage (V)
Charge : 1350mA (-∆V=4mV)
Ambient Temp. : 0°C,20°C,40°C
0
°
C
20°C
4
0
°
C
A
bout 20mΩ
(
at 1000Hz
)
