Sanyo UPF323456L User manual

Aug
．
．．
．
2002
0 100 200 300 400 500
Number of Cycle
0
200
400
600
Discharge Capacity / mAh
Te mp . : 20 ℃
Charge:CC-CV:0.50A-4.2V(3hrs. cut)
Discharge:CC:0.50A(E.V.:2.75V)
0 60 120 180 240
Charge Time / min
2.0
2.5
3.0
3.5
4.0
4.5
Cell Voltage / V
0
200
400
600
800
1000
Current / mA
200
400
600
800
Capacity / mAh
Charge:CC-CV:0.50A-4.2V(3hrs. cut)
Cell Voltage
Capaci ty
40℃
20℃
0℃
Cur rent
0 100 200 300 400 500 600 700
Discharge Capacity / mAh
2.0
2.5
3.0
3.5
4.0
4.5
Cell Voltage / V
Charge:CC-CV:0.50A-4.2V(3hrs. cut)
Discharge:CC:0.50A(E.V.:2.75V)
60℃
20℃
0℃
-10℃
-20℃
0 100 200 300 400 500 600 700
Discharge Capacity / mAh
2.0
2.5
3.0
3.5
4.0
4.5
Cell Voltage / V
Temp.:20℃
Charge:CC-CV:0.50A-4.2V(3hrs. cut)
Discharge:CC:Vari able Current(E.V.:2.75V)
0. 2CA(=0.100A)
1. 0CA(=0.500A)
2. 0CA(=1.000A)
500mAh
3.7V
Constant Current
-Constant Voltage
4.2V
Std. 500mA
3.0hrs.
Charge 0
～
+40
℃
Discharge -20
～
+60
℃
Storage -20
～
+50
℃
13.3g
(T) 3.35mm
(W) 34.00mm
(H) 56.00mm
290Wh/l
139Wh/kg
Dimensions
(Max.)
Volumetric Energy Density
Gravimetric Energy Density
Charging Current
Charging Time
Ambient Temperature
Weight (Approx.)
Nominal Capacity
Nominal Voltage
Charging Method
Charging Voltage
Cell Type UPF323456L
Specifications
T3.15mm
W 34.0mm
H 55.5mm
Dimensions(Typ.)
of
Bare Cell
Typical Characteristics
Discharge rate characteristics Discharge temperature characteristics
Charge characteristics Cycle characteristics
H
T
W
W
T
H
