Sanyo VSP-9000 User manual

INSTRUCTION MANUAL
System Controller
VSP-9000
About this manual
• Before installing and using this unit, please read this manual carefully. Be sure to keep it handy for
later reference.
• This manual gives basic connections and operating instructions.

English
1Introduction
Table of Contents
Precautions (For UL) ...................................2
Safety Cautions............................................3
Major Characteristics ..................................8
Accessories..................................................8
Part Names...................................................9
Menu Display..............................................11
System Information ...................................12
Sample System Connection .....................13
Connection and Communication
Setup 1 (VIDEO) .........................................15
Connection and Communication
Setup 2 (VIDEO) .........................................18
Connection and Communication
Setup 3 (VIDEO/TELEMETRY A)...............21
Connection and Communication
Setup 4 (VIDEO/TELEMETRY B)...............24
Connection and Communication
Setup 5 (VIDEO/TELEMETRY A/B) ...........27
Communication Lines and
Number of Connected Units .....................30
Hard Disk Digital Recorder (DVR)
Operation....................................................32
Multiplexer (MUX) operation .....................36
Dome Camera/Zoom Camera Operation..38
System Setup Overview............................41
Language Selection...................................42
Communication Setup...............................43
bSelect a communication item
(COMMUNICATIONS)...................................... 43
bUnit Address Setup........................................... 44
Control Setup.............................................47
bSelect a Control Item
(ACCEPTED VALUES)..................................... 47
Password Setup (PASSWORD) ................50
bAT SWITCHING ON (Power ON password)..... 51
Setup (CONFIGURATION).........................52
bInitialize (RESTORE BASIS VALUES)............. 53
bBuzzer and menu display setup
(BUZZER/DISPLAY) ........................................ 53
bJoystick Setup (JOYSTICK) ............................. 54
bTouch screen adjustment
(TOUCH SCREEN SETTING).......................... 55
bTouch Screen Initialization and Reset.............. 56
bTouch screen test (TOUCH TEST) .................. 57
Software Configuration.............................59
bOperating Environment .................................... 59
Connection and Software Installation .....60
bInstall the Software........................................... 60
bMaking Connections......................................... 60
System Setup (Setup) ...............................61
AGeneral (General Settings) .............................. 62
BCameras (Camera communication setup)........ 64
CMonitor/Local Mux
(Valid/Invalid setup for hard disk digital recorder
with multiplexer) ............................................... 66
DEnabling (stopping or starting settings) ............ 67
Language Setup (Language) ....................68
bCreating Two Different English Tabs................ 69
Graphics Environment Setup (Maps) ......71
bDisplay Telephone Number on
Opening Screen ............................................... 72
bMap Screen Explanation .................................. 73
bSample Equipment Allocation .......................... 76
bProtocol Chart (Autopan).................................. 79
bProtocol Chart (Patrol)...................................... 80
bChanging the Opening screen to “SANYO”...... 81
bCreate a map using the graphics tool
and display on opening screen......................... 82
bBasic Graphics ................................................. 84
Specifications ............................................85
bOuter Dimensions (Units: mm) ......................... 85
Appendix ....................................................86
bCommunications Chart..................................... 86
bMessage Chart ................................................. 88
bSpecial Code Chart .......................................... 89
Introduction
Preparation
Operation
System Setup
Software
Others
