Important information
_ This symbol indicates that this product incorporates
,_ i _] _ _ double insulation between hazardous main voltage
RISK OF ELECTRIC SHOCK. and user accessible parts. When servicing, use only
DO NOT OPEN. identical replacement parts.
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside.
Refer servicing to qualified service personnel.
,_ This symbol indicates "dangerous voltage"
inside the product that presents a risk of
electric shock or personal injury. This symbol indicates important
instructions accompanying the product.
WARNING
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. This product should
not be exposed to dripping or splashing. No objects filled with liquids, such as vases, should be placed on the
apparatus.
WARNING
The TV is unstable if it is not properly attached to the base or mounted to the wall. Please follow the base or
wall mounting instructions provided in the User's Guide to ensure your safety.
WARNING The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
WARNING
The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
NeedHelp? www.sanyoctv.com ;,,, 1-800-877-5032
1

important Safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean onlywith dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacture's
instructions.
8,
g,
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has
two blades with one wider than the other. Agrounding plug has two blades and a third
grounding prong. The wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart or rack is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified personnel. Servicing is required when the apparatus has
been damaged in any way, such as power supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15. WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instruction.
16. If an outside antenna or cable system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection against voltage surges and built-up
static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70-1984 (Section
54 of Canadian Electrical Code, Part 1) provides information with respect to proper grounding of
the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size
of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode. See following example:
NeedHelp? www.sanyoctv.com +++ 1-800-877-5032
2

Important Safety Instructions
17. An outside antenna system should not be located in the vicinity of overhead power lines or other
electrical light or power circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
18. Wall or Ceiling Mounting - The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
19. Apparatus shall not be exposed to dripping or splashing, and no object filled with liquids, such as
vases, shall be placed on it.
20. When the MAINS plug is used as the disconnect device, the disconnect device shall remain
readily operable.
EXAMPLE OF ANTENNA GROUNDING ACCORDING
TO NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEADiN
WiRE GROUND
CLAMP
jANTENNA
I_i&R-_[_J /J_ DISCHARGEUNiT
I E_ENT _/_k-_/(NECSECTION810-20)
GROUND ROUNDINGCONDUCTORS
POWERSERVICEGROUNDING (NEC SECTION 810=21)
ELECTRODESYSTEM
(NEC ART 250, PART H) NEC =NATIONALELECTRICALCODE
Note to CATV system installer:
This reminder is provided to call CATV system installer's attention to Article 820-40 of the NEC that
provides guideline for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical."
Need Help? www.sanyoctv.com 1-800-877-5032
3

Table of Contents
Important Information ........................................................................................................................... 1
Important Safety Insructions ................................................................................................................ 2
Chapter 1: Connections and Setup
Before initial Setup .............................................................................................................................. 5
Check Supplied Parts ........................................................................................................................... 5
Attaching Your TV to the Stand Base .................................................................................................. 6
Mounting Your TV to the Wall ............................................................................................................. 7
Buttons on the TV ................................................................................................................................ 8
Explanation of jacks on TV .................................................................................................................. 8
Choose Your Connections ................................................................................................................... .10
MHL .................................................................................................................................................... 10
Remote Control Functions .................................................................................................................. 12
Obtain the Signal ................................................................................................................................ 13
Switching On ....................................................................................................................................... 13
Switching Off ....................................................................................................................................... 13
Setup Wizard ....................................................................................................................................... 14
input List .............................................................................................................................................. 16
Chapter 2: Menu Operation
Menu ..................................................................................................................................................... 16
Picture .................................................................................................................................................. 16
Sound ................................................................................................................................................... 17
Channel ................................................................................................................................................ 18
Setup .................................................................................................................................................... 19
Lock ..................................................................................................................................................... 20
Help ...................................................................................................................................................... 21
PC ........................................................................................................................................................ 22
ViDEO/HDMI ...................................................................................................................................... 23
USB ...................................................................................................................................................... 23
Photo .................................................................................................................................................... 23
Roku ..................................................................................................................................................... 24
Chapter 3:Other Information
Frequently Asked Questions (FAQS) ................................................................................................... 25
Troubleshooting .................................................................................................................................... 26
Care and Cleaning ............................................................................................................................... 28
Television Specifications ....................................................................................................................... 28
Specification ......................................................................................................................................... 28
Limited Warranty ................................................................................................................................... 29
NeedHelp? www.sanyoctv.com ,,, 1-800-877-5032
4

Chapter 1 Connections and Setup
Before Initial Setup
Protect Aaainst Power Suraes
• Connect all components before you plug any power cords into the wall outlet or power strip.
• NEVER plug your TV into an outlet that is controlled by a wall switch.
• Turn off the TV before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safety
Instructions.
Safety Information
• Protect components from overheating.
• Don't block ventilation holes on any of the components. Arrange the components so that air can
circulate freely.
• Don't stack components.
• If you place the component in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from it won't
harm other components.
Avoid Audio Interference
• Position cables properly; insert each cable firmly into the designated jack.
• If you place components above the TV, route all cables down one side of the back of the TV instead
of straight down the middle.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables.
• Keep twin lead cables away from audio/video cables.
Avoid Direct Liqht
Don't place the TV where sunlight or room lighting is directed toward the screen. Use soft or indirect
lighting.
Check Supplied Parts
Check that the following parts were packed with your product.
• Remote Control
• User's Guide
• QUIK'N EASY Setup Guide
• Parts for Stand Base
Graphics contained within this publication are presentation only.
NeedHelp? www.sanyoctv.com 1-800-877-5032
5

Connections and Setup
Attaching Your TV to the Stand Base
Your TV comes with the stand base unassembled so you can choose to mount your TV either to its table
stand or to a wall (wall mount sold separately). If you want to mount your TV to the wall, skip the stand
assembly instructions and follow the Mounting Your TV to the Wall instructions.
First, remove the TV bag and place it on a large, flat surface such as a table or countertop. Remove the TV
from the carton and place it face down on the TV bag. Be sure that the TV is face down to avoid scratching
the screen.
Then follow the steps below:
Note:The picture of stand installation is just for the reference, please base on the material object for
the real sample.
For model DP58D34, please just follow A - 2, A - 3.
Model
DP39D14
DP42D24
DP50E44
DP55D44
DP58D34
DP65E34
Mounting screws measurements
(J)M5 (5mm) Diameter, Length-12mm (maximum)
(z_'M4(4mm) Diameter, Length-20mm (maximum) Note:Stand base screws
are located in the
literature package.
M5 (5mm) Diameter, Length-16mm (maximum)
(J)M5 (5mm) Diameter, Length-16mm (maximum) x 4 pcs
_z_'M5(5mm) Diameter, Length-16mm (maximum) x 4 pcs
NeedHelp? www.sanyoctv.com 1-800-877-5032
6

Connections and Setup
Mounting Your TV to the Wall
If you are mounting your TV to the wail, don't attach the table stand.
For DP39D14model Purchase a VESA 200 x 200, M6 screw
For DP42D24model Purchase a VESA 200 x 200, M6 screw
For DP50E44 model Purchase a VESA 400 x200, M6 screw
For DP55D44model Purchase a VESA 200 x200, M6 screw
For DP58D34model Purchase a VESA 400 x200, IVl6 screw
For DP65E34 model Purchase a VESA 400 x 400, IVl6 screw
The VESA number is the horizontal and vertical measurement of the mounting holes. For example,
400x200 refers to the fact that the mounting measurements are 400mm horizontally and 200ram vertically.
Recommendation to buy screws: DP39D14
DP42D24
DP50E44
DP55D44
DP58D34
DP65E34
M6X 18.max(20mm)
M6X 18.max(20mm)
M6X18.max(18mm)
M6X 18.max(20mm)
M6X 18.max(20mm)
M6Xl 5.max(15mm)
Notes: Follow the directions included with the wall mount to mount the TV to the wall.
For model DP58D34, please remove neck cover and stand neck before mounting.
Caution: Your wall mount must be able to bear a minimum of five times the TV's net weight to avoid causing damage.
IMPORTANT:
Wall moUntVEsAkitmust com- ....
_ ply with standard
hole pattern.
All four (4) screws must be
_ hreaded to the wall mount
and HDTV's back cabinet.
NeedHelp? www.sanyoctv.com ,,, 1-800-877-5032
7

Buttons on the TV
Take a certain model for an example:
Connections and Setup
If you cannot locate your remote, you can use the TV panel buttons on your TV to operate many TV
features.
O A/v </_ (arrows) Highlights different items in the TV menu and adjusts the menu controls.
ENTER When the TV is in the menu system, press to confirm your selection.
O CH/k/V Selects channels stored in the channel list or acts as the up/down arrow (A/v) through the
menu items.
O VOL+/- Increases/decreases the volume or acts as the right/left arrow (_,/,_) through the menu
items.VOL+ also acts as the ENTER button when in the menu system.
OINPUT Selects the signal source.
MENU Brings up the TV's main menu.
POWER Turns the TV on or to standby mode.
(Please base on the material objectfor the real sample,)
Explanation of Jacks on TV
This section describes the jacks on the backside of your TV. There are several ways to connect devices.
Audio Equipment
I
I
NeedHelp? www.sanyoctv.com ,,, 1-800-877-5032
8

Connections and Setup
AUDIO OUTPUT the socket provides composite audio connection. The TV can
support amplified high power audio equipment. Please adjust the volume directly on
the external audio equipment. Please do not connect headphones directly to the TV.
OPTICAL OUTPUT: It is possible to output audio through the digital audio terminal.
L/R AUDIO Provides left and right audio connection when using the component input.
Red and white jacks for R AUDIO and L AUDIO connection.
(Note: AUDIO/VIDEO IN and COMPONENT IN share the same L/R AUDIO input jacks.)
Y Pb Pr (Component Video) Provides good picture quality because the video is
separated into three signals. Use component video cables for the connection.
HDMI I/DVI IN (High-Definition Multimedia Interface/Digital Visual interface)
Provides an uncompressed digital connection that carries both video and audio data
by way of an integrated mini-plug cable. Since HDMI technology is based on Digital
Visual Interface (DVl), the jack on the side of your TV is also compatible with DVl
devices.
(For DVl input, it's audio input is shared with PC audio input)
Note: For the audio receiver control ARC, firstly you must have a device which supports
HDMI ARC, then connect it to the HDMI1 port. When the "ARC/CEC Setting" is enabled on
your TV, the TV set's speakers will mute automatically and the audio will be outputted on
your ARC sound device system.
USB Allows you to connect a compatible mass storage device for the display of JPEG
pictures on the TV.
ANTENNA/CABLE IN this socket can be used to connect the outside aerial
(including the analog signal and the digital signal)
DVI/PC AUDIO IN (used for DVI/PC only) Provides audio connection when using
HDMI/DVI INPUT 1 jack for DVI or when using PC VIDEO IN.
Note: if using a DVI device, remember to connect the audio cable because the DVt
cable carries only the picture signal, not the sound.
PC IN Connect your computer or other device with a VGA output to this jack using a
15-pin, D-sub cable.
HDMI 2PMHL(High-Definition Multimedia Interface/Mobile High-Definition Link)
Provides an uncompressed digital connection that carries both video and
audio data by way of an integrated mini-plug cable. Since HDMI technology is
based on Mobile High-Definition Link(MHL),the jack on the side of your TV is also
compatible with MHL Device. Connect the Roku Streaming Stick (sold separately)
to quickly enable Smart TV applications.
HDM| 3iN Lets you connect a Device, such as a Digital cable box, with an HDMI
output for the best picture quality.
Need Help? .... _ www.sanyoctv.com 1-800-877-5032
