Sanyo LCD-42K40TD User manual

SERVICE MANUAL LCD Television
FILE NO.
Original Version
Chassis Series: UE5-B
N7DE
Model No. LCD-42K40TD
Give complete “SERVICE REF. NO.” for
parts order or servicing. It is shown on the
rating plate at the cabinet back of the unit.
This T.V. receiver will not work properly in
foreign countries where the television
transmission system and power source dif-
fer from the design specifications. Refer to
the specification table.
Product Code: 1-130-184-04
Contents
Safety Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chassis Block Diagrams . . . . . . . . . . . . . . . . . . 4-5
IC Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . 6-8
On-screen Service Menu system . . . . . . . . . . . . 9-10
Service Adjustments . . . . . . . . . . . . . . . . . . . . . 11-13
Mechanical Disassembly . . . . . . . . . . . . . . . . . . 14-15
Chassis Electrical Parts List . . . . . . . . . . . . . . . 16-31
Cabinet Parts List . . . . . . . . . . . . . . . . . . . . . . . 32
PCB Assemble . . . . . . . . . . . . . . . . . . . . . . . . . . 33-34
Printed Wiring Board . . . . . . . . . . . . . . . . . . . . . 35-37
Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . 38-43
REFERENCE NO. SM3010465
Service Ref. No. LCD-42K40TD-00
COVER-SM-LCD-42K40TD 10/29/10 3:17 PM Page 1

2
Safety Notice
Safety Precautions
The following precautions must be observed.
1:Comply with all caution and safety-related notes provided on the cabinet back, cabinet bottom, inside the
cabinet or on the chassis.
2:When replacing a chassis in the cabinet, always be certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers or shields, barriers, etc..
DO NOT OPERATE THIS TELEVISION WITHOUT THE PROTECTIVE SHIELD IN POSITION AND
PROPERLY SECURED
3:Before replacing the cabinet cover, thoroughly inspect the inside of the cabinet to see that no stray parts or
tools have been left inside.
Before returning any televison to the customer, the service personnel must be sure that it is completely safe
to operate without danger of electrical shock.
Product Safety Notice
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by mark in the parts list and the schematic diagram designate components in

It is particularly recommended that only parts designated on the parts list in this manual be used for
component replacement designated by mark .
No deviations from resistance wattage or voltage ratings may be made for replacement items designated
by mark .

3

Model LCD-42K40TD
Maximum Visible Range 106cm
Picture Resolution 1920(H) x 1080(V)
Viewable Angle(L。/3) L/R:+/-89D, U/D:+/-89D
Brightness 500cd/m²

Mobile Trailer Time 5ms
Voltage AC110-242V 50/60Hz
Power Consumption 188W
Power Management VESA DPMS
Digital TV System DVB-T(2K/8K COFDM), Band Wide: 7MHZ
Video decoder:MPEG2 MP@HL
Audio decoder:MPEG1,MPEG2(Layer I/II),and DOLBY Digital(AC3)
Analog TV System Colour System:PAL,SECAM,NTSC/NTSC4.43(only AV)
Sound System:D/K,I,B/G,
Stereo System:NICAM,A2/IGR(German Stereo)
Channel Coverage - VHF: 0-12
- UHF: 27-69,
- MATV: UHF 20-27, UHF 70-75, S2-S44

Speaker Size Mains: 6cm x 12cm x 2pcs
Sound speciality Maximum Output Power is 10W+10W

Input terminals PC input terminal : RGB X 1 HDMI terminal: x3
Audio: Mini stereo jack x 1 (Audio input of PC)
Video: Composite video terminals x1 ()
S-VIDEO input: x 1 (DIN 4-pin, Y/C separate signal input)
DVD input: Component video input Y, CB/PB, CR/PRinput x 1
Audio input: (R/L) x 4 (400mVrms)
Output terminals Video Monitor Output: 
Audio Monitor Output: R/L x 2 (
S/P DIF (Coaxial) Output x 1
Headphone Jack : Mini stereo jack x1
Dimensions
(Width x Height x Depth) 1009.5mm X 674.8mm X 271.6mm (Including Stand)
Net Weight
(Including Stand ) 18 KG
Operating Environment
Operating Temperature 0ºC~40ºC（32ºF~104ºF）

Storage Temperature -10ºC~50ºC（14ºF~122ºF）


4
Chassis Block Diagrams
for HDCP
5V VA 5V STB
SPI FLASH
(option for air update)
TUNER TDTC-G501D
DVB-T DEMODULATOR CE6353
IF-PLL TDA9886
VGA
HDMI_2 HDMI_3
1/3
SWITCH
PS321
HDMI
PORTS
CVBS0P
SIF
TS
DDR
UART
DDR SDRAM
256Mb x2
UART I/F
SPI
DUAL LVDS
LG PANEL
LC420WUN-SCB1
MUX LINE
AUDIO
OUT
OP AMP
4558R
POWER AMPLIFIER TDA3124D2
IR
KEY BOARD
IR
USB
HEADER
EEPROM 24C32
DDCR
R/G/B 1
Y/Pb/Pr R/G/B 0
24C02CT
AV1
HDMI_1
AV OUT
H.PHONE
EEPROM 24C512
SPDIF SPDIFO
CVBS1P
CVBSO LINE OUT1
10W
10W
HEAD PHONE OUTPUT
CVBS/L/R
HP-L
R/G/B
JACK LINE IN2
L
/
R
L/R LINE IN1
L/R
Y/Pb/Pr
L/R LINE IN3
L/R
CVBS
MSD1
09CL- H
DVB LCD/PDP DTV PROCESSOR MCU VIDEO DEC MPEG2 MP@HL DEC MPEGI&II,AC3 DEC NICAM/A2 SCALER HDMI LVDS
Q24C02CT/ SN-P
QNJM4558M---P
SPI FLASH 32Mb
QRCLAMP0524PP
1LB4J
11B0580M
TS
IF-
IF+
IIC1
IF_AGC
IF_TV
TV-VID
SIF P/M
I2C
RF-AGC
RST
20.48M
12MHz
I2C
UAR
FOR SOFT DEBUG
L
R
RESET
QPS321TQFP80M
USB
ESD
ESD
ESD
4MH
IIC1
IIC2
IIC3
HPD3
HPD1
HPD2
DDCDA
I2C-DDC HOTPLUG
MUTE1
AU AMP TPA6110
MUTE2 QTPA6110A2--P
KEY
IIC2
SPDIF
HP-R
HP-L
HP
-
R
RS232_I UART1
RXD/TXD
QTDA9886TSV4P
S_VIDEO
MAX232
C YCVBS4P
CVBS6P
UAR
for external u
p
date
BUFFER

5
CPU Block Diagrams
MSD109CL-H

6
K4H560438H
K4H560838H
K4H561638H
256Mb TSOP-II Package Pinout
V DD
1
66Pin TSOP II
(400mil x 875mil)
DQ 0
2
V DDQ
3
NC
4
DQ 1
5
V SSQ
6
NC
7
DQ 2
8
V
DDQ
9
NC
10
DQ 3
11
V SSQ
12
BA 0
20
CS
19
RAS
18
CAS
17
WE
16
NC
15 V DDQ
14
NC
13
V DD
27
A 3
26
A 2
25
A
1
24
A
0
23
AP/A 10
22
BA 1
21
V
SS
54
DQ 7
53
V SSQ
52
NC
51
DQ 6
50
V
DDQ
49
NC
48
DQ 5
47
V SSQ
46
NC
45
DQ 4
44
V DDQ
43
A 11
35
36
CKE
37
CK
38
DM
39
V REF
40
V SSQ
41
NC
42
V SS
55
A 4
56
A 5
57
A 6
58
A 7
59
A 8
60
A 9
34
(0.65mm Pin Pitch)
33
32
31
30
29
28
61
62
63
64
65
66
NC
NC
NC
NC
NC
V
DD
NC
DQS
NC
V SS
CK
NC
A
12
V
SS
NC
V
SSQ
NC
DQ 3
V DDQ
NC
NC
V
SSQ
NC
DQ
2
V DDQ
A 11
CKE
CK
DM
V REF
V SSQ
NC
V
SS
A
4
A 5
A 6
A 7
A 8
A
9
NC
DQS
NC
V
SS
CK
NC
A 12
V DD
NC
V
DDQ
NC
DQ 0
V SSQ
NC
NC
V
DDQ
NC
DQ 1
V SSQ
BA
0
CS
RAS
CAS
WE
NC
V
DDQ
NC
V DD
A 3
A 2
A
1
A 0
AP/A 10
BA 1
NC
NC
NC
NC
NC
V DD
Bank Address
BA0~BA1
Auto Precharge
A10
64Mb x 4
32Mb x 8
V DD
DQ
0
V DDQ
DQ 1
DQ 2
V SSQ
DQ
3
DQ 4
V
DDQ
DQ
5
DQ
6
V
SSQ
BA
0
CS
RAS
CAS
WE
LDM
V
DDQ
DQ 7
V
DD
A 3
A 2
A
1
A
0
AP/A 10
BA
1
NC
LDQS
NC
NC
NC
V
DD
V SS
DQ 15
V SSQ
DQ 14
DQ
13
V DDQ
DQ 12
DQ 11
V SSQ
DQ 10
DQ 9
V
DDQ
A
11
CKE
CK
UDM
V REF
V SSQ
DQ
8
V SS
A 4
A 5
A
6
A 7
A
8
A 9
NC
UDQS
NC
V
SS
CK
NC
A 12
16Mb x 16
IC Block Diagrams
K4H561638H

7
IC Block Diagrams
CE6353(INTEL)
7

8
IC Block Diagrams
TPA3124D2PWPR
TDA9886
1
2
3
4
5
6
7
8
9
10
11
12
PVCCL
SD
PVCCL
MUTE
LIN
RIN
BYPASS
AGND
AGND
PVCCR
VCLAMP
PVCCR
24
23
22
21
20
19
18
17
16
15
14
13
PGNDL
PGNDL
LOUT
BSL
AVCC
AVCC
GAIN0
GAIN1
BSR
ROUT
PGNDR
PGNDR
TPA3124D2
PWP (TSSOP) PACKAGE
(TOP VIEW)
2Submit Documentation Feedback Copyright © 2008, Texas Instruments Incorporated
Product Folder Link(s): TPA3124D2

9
On-screen Service Menu System
General
This set has an On-screen Menu system included in the CPU that allows remote operation for most of the
service adjustments.
rHow to select the service item and adjust data:
On-screen Service Menu System
Quick operation is needed to enter Service Mode.
rHow to enter the Service Menu
1. Press and hold the MENU button on Side Controls.
2. Keep pressing the MENU button and press “1” button on the remote control, and the Service Mode will be
displayed.
       or button to navigate through the
options or adjust an option. Press OK button to confirm a selection or
enter a sub-menu.
rTo exit service mode
Press MENU button to exit service mode.
OK
Open or close the On-Screen Menu.
MENU button
Side Controls
[ Service Mode Menu ]
Service Mode
ADC ADJUST
PICTURE MODE
W/B ADJUST
WHITE PATTERN : OFF
RFAGC ADJUST : 16
SSC ADHYST
BACKLIGHT ADJUST
UE5B_V2.26_LG42_100301
ADC ADJUST

10
■ Service Adjustment Data Table
On-screen Service Menu System
ADC ADJUST SOURCE RGB
R-GAIN 97
G-GAIN 103
B-GAIN 101
R-OFFSET 133
G-OFFSET 123
B-OFFSET 131
AUTO ADC <FAIL/SUCCESS>
SOURCE YPbPr(SD)
R-GAIN 65
G-GAIN 61
B-GAIN 66
R-OFFSET 128
G-OFFSET 128
B-OFFSET 128
AUTO ADC <FAIL/SUCCESS>
SOURCE YPbPr(HD)
R-GAIN 63
G-GAIN 61
B-GAIN 66
R-OFFSET 128
G-OFFSET 128
B-OFFSET 128
AUTO ADC <FAIL/SUCCESS>
W/B ADJUST BASE R-GAIN 64
SOURCE ALL BASE G-GAIN 64
TEMPERTURE ALL BASE B-GAIN 64

11
Service Adjustments
CAUTION !
Do not attempt to adjust service adjustments not listed below otherwise it may cause loss of performance
and for correct operation.
rSetting the Initial data
This adjustment is controlled by the CPU (IC5500) through the IIC Bus Data Line in the chassis, and those
adjustment data are memorized the memory IC (IC5750). Therefore, Main board or the memory IC (IC5750)
is replaced, these data will be disappeared. Readjust should be made. Initial data is provided in the CPU
ROM, when the memory IC (IC5750) is replaced with new one. CPU ROM data is loaded into the memory.
Initial data is provided to operating the monitor basically. For operating the monitor quality performance,
further adjustment is required following chassis electrical adjustment.
1. Enter the Dealer Mode, and select RESET.
rHow to enter the Dealer Mode.
Press the MENU button on Side Controls, the screen menu will be displayed.
Press the INFO button on the Remote Control, you can enter the Dealer Mode as following.
 or OK button to select RESET and confirm to returns most setting
values to the factory default settings.
(Note: After executed reset function, ADC ADJUST and W/B ADJUST should be readjusted. Please
enter Service Mode to adjust data.)
2. Enter the Service Mode, and select ADC ADJUST / W/B ADJUST to adjust the data according
"Service Adjustment Data Table" on page 10.
rHow to enter the Service Mode. Please refer to page 9.

12
Service Adjustments
rADC ADJUST
1. Enter the Service Mode.
2. Select "ADC ADJUST" by pressing  button, then press OK button to enter ADC ADJUST menu.
3. Press  button to select "SOURCE" item, press or button to select RGB, YPbPr(SD) or
YPbPr(HD).
(1). Receive signal from PC input. And set ANSI pattern contrast in PC mode.Receive signal from PC input. And set ANSI pattern contrast in PC mode.
(2). Enter the ADC ADJUST menu. PressEnter the ADC ADJUST menu. PressPress  button to select "SOURCE" item
(3). Press or button to select RGB.
(4). Press  button to select AUTO ADC item, then press OK button.
(1).           
(2). Enter the ADC ADJUST menu. PressEnter the ADC ADJUST menu. PressPress  button to select "SOURCE" item.
(3). Press or button to select YPbPr (SD).
(4). Press  button to select AUTO ADC item, then press OK button.
(1).            
(2). Enter the ADC ADJUST menu. PressEnter the ADC ADJUST menu. PressPress  button to select "SOURCE" item.
(3). Press or button to select YPbPr (HD).
(4). Press  button to select AUTO ADC item, then press OK button.
4. Exit the Service Mode.
Wait for about several seconds until AUTO ADC adjust completed. Then press MENU button to exit.
Note: If you want to adjust any item, please consult qualified service personnel.
RGB
YPbPr (SD)
YPbPr (HD)
ADC ADJUST
SOURCE : RGB
R-GAIN : 117
G-GAIN : 121
B-GAIN : 123
R-OFFSET : 131
G-OFFSET : 145
B-OFFSET : 123
AUTO ADC FAIL
SOURCE : RGB

13
rW/B ADJUST
Pattern
 
Condition
Picture Mode: STANDARD
Color Temperature: NORMAL
Aging Time: More than 10 minutes
Adjustment
1. Enter the Service Mode.
2. Select "W/B ADJUST" by pressing  button, then press OK button to enter W/B ADJUST menu.
3. Exit the Service Mode.
After adjustment, confirm white balance again by normal picture.
Note: • Maybe BASE data for each TV set is different. And the items are for factory setting and
Service Centre.
• SOURCE items are for all input source gain. Usually the items can not be adjusted.
• USER items are just for user setting. Usually the items can not be adjusted.
•If you want to adjust any item, please consult qualified service personnel.
Service Adjustments
W/B ADJUST
BASE R-GAIN : 78
BASE G-GAIN : 78
BASE B-GAIN : 78
SOURCE : DTV
SOURCE R-GAIN : 25
SOURCE G-GAIN : 25
SOURCE B-GAIN : 25
TEMPERATURE : Normal
USER R-GAIN : 25
USER G-GAIN : 25
USER B-GAIN : 25
R-OFFSET : 128
G-OFFSET : 128
B-OFFSET : 128
COPY ALL
BASE R-GAIN : 78

14
Mechanical Disassembly
(一) Lid Back Removal
Remove screws A and B, Take the Lid Back off.
(A: 2pcs, B: 3pcs)
A
LID
BACK
Picture 1.
A
B
B
B
POWER BOARD
MAIN
BOARD
Picture 2.

15
Mechanical Disassembly
(三) Cabinet Back Removal
Picture 3.
MAIN BOARD
E
POWER BOARD
A
E
POWER BOARD HOLDER
F
GG
Picture 4.
C C C
C
C
C
C
D
DD
D
D
CC
C
C
C
CCCC
E
STAND BASE
Note: When remove Power Board and MAIN BOARD, please keep EARTH BRKT PWB.
And make sure of installing EARTH BRKT PWB if assemble the LCD TV set again.
EARTH BRKT
POWER PWB EARTH BRKT
MAIN PWB
(二) Chassis Board and Stand Base Removal
1. Remove Screw E, take Power Board Holder, then take Power Board off.
2. Remove Screw A and E, take Main Board off.
3. Remove Screw F and G, take Stand Base off.
(A: 3pcs, E: 12pcs, F: 2pcs, G: 4pcs)
Remove Screw C and D, take the Cabinet Back off.
(C: 16pcs, D: 5pcs)

16
N7DE
OUT OF CIRCUIT BOARD
LCD PANEL
EL901 6451024480 LCD(LC420WUN-SCB1)
MISCELLANEOUS
SP901 6520014473 SPEAKER,8
6520018327 SPEAKER,8
SP902 6520014473 SPEAKER,8
6520018327 SPEAKER,8
WCN1-660 6520026285 NON STANDARD WIRE ASSY
6520025233 NONSTANDARD WIRE ASSY
WSP9L 6520028623 NON STANDARD WIRE
6520023987 NONSTANDARD WIRE ASSY
WSP9R 6520028661 NON STANDARD WIRE ASSY
6520028401 NONSTANDARD WIRE ASSY
W2002-20 6103458076 STANDARD WIRE ASSY-JPN
6103453613 STANDARD WIRE
W662-001 6103458106 STANDARD WIRE ASSY-JPN
6103450728 STANDARD WIRE
W680-150 6103399980 STANDARD WIRE ASSY-JPN
6103391977 STANDARD WIRE
W7300 6520026513 CORD 51PIN (LVDS)
W8001-19 6520028647 NONSTANDARD WIRE ASSY
6520028425 NONSTANDARD WIRE ASSY
W8002-19 6103397085 STANDARD WIRE ASSY
6103508283 STANDARD WIRE ASSY-N5JV
6103352749 STANDARD WIRE
W901 6450956072 CORD,POWER-2.23MK-VAR-2
6103501529 ASSY,PWB,MAIN,N7DE
1AA0B10S286EA
TRANSISTOR
Q001 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q002 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q003 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
!
!
Chassis Electrical Parts List
Ref. No. Part No. Description Ref. No. Part No. Description
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following parts
list be used for components replacement pointed out by the mark.
!
Note: Parts order must contain Chassis No., Part No., and descriptions. The main PCB unit will be supplied without tuner and
flyback transformer. They should be ordered separately.
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
Less than 10pF
A : Not specified B : ±0.1pF C : ±0.25pF
D : ±0.5pF F : ±1PF G : ±2pF
R : ±0.25-0pF S : ±0-0.25pF E : +0-1pF
More than 10pF
A : Not specified B : ±0.1% C : ±0.25%
D : ±0.5% F : ±1% G : ±2%
H : ±3% J : ±5% K : ±10%
L : ±15% M : ±20% N : ±30%
P : +100-0% Q : +30-10% T : +50-10%
U : +75-10% V : +20-10% W : +100-10%
X : +40-20% Y : +150-10% Z : +80-20%
Rated value: P=pico farad, U=micro farad
Material:
CERAMIC........... Ceramic
MT-PAPER......... Metallized Paper
POLYESTER...... Polyester
MT-POLYEST.....Metallized Polyester
POLYPRO.......... Polypropylene
MT-POLYPRO....Metallized Polypropylene
COMPO FILM.....Composite film
MT-COMPO........Metallized Composite
STYRENE...........Styrene
TA-SOLID........... Tantalum Solid
AL-SOLID........... Aluminium Solid
ELECT................ Electrolytic
NP-ELECT..........Non-polarised Electrolytic
OS-SOLID.......... Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT.......... Double Layered Electrolytic
RESISTOR
CARBON 4.7K J A 1/4W
Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1% G: ±2% J: ±5% K: ±10%
M: ±20% P: +5-15%
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON........... Carbon
MT-FILM............ Metal Film
OXIDE-MT......... Oxide Metal Film
SOLID................ Composition
MT-GLAZE......... Metal Glaze
WIRE WOUND...Wire Wound
CERAMIC RES.. Ceramic
FUSIBLE RES....Fusible
NOTES:
P LIST (N7DE) UE5-B 10/29/10 1:33 PM Page 16

4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q004 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q006 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q007 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q101 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q1062 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q1063 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q1064 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q1065 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q5900 4052203115 TR ISA1235AC1E
4052203016 TR ISA1235AC1F
4060214308 TR MMBTSA1235F
4051345925 TR 2SA1037AK-T146-R
4051472215 TR 2SA1037AK-S-T146
4051739615 TR 2SA1235A1E
4051739714 TR 2SA1235A1F
Q6501 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q6502 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q6503 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q6801 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q6803 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q6805 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q6806 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q7207 4052203115 TR ISA1235AC1E
4052203016 TR ISA1235AC1F
4060214308 TR MMBTSA1235F
4051345925 TR 2SA1037AK-T146-R
17
N7DE
Ref. No. Part No. Description Ref. No. Part No. Description
P LIST (N7DE) UE5-B 10/29/10 1:33 PM Page 17

18
N7DE
4051472215 TR 2SA1037AK-S-T146
4051739615 TR 2SA1235A1E
4051739714 TR 2SA1235A1F
Q7208 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q8000 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
Q8001 4060214407 TR MMBTSC3928R
4050144519 TR 2SC2412K T146 R
4050144618 TR 2SC2412K T146 S
4050158724 TR 2SC2812-L6-TB
4050158922 TR 2SC2812-L7-TB
4051631612 TR 2SC2812N-L6-TB0
4051739813 TR 2SC3928A1R
4051739912 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC001 4096910413 IC TPA3123D2PWPR
4106847408 IC TPA3124D2PWPR
IC003 4096910314 IC TPA6110A2DGNR
IC1004 4096990514 IC FMS6141S5X
IC101 4095498219 IC TDA9886TS/V4
IC102 4106852303 IC WJCE6353SL9G5
IC1501 4094620324 IC 24LC21AT/SN
IC3100 4093870918 IC BA4558F-E2
IC5500 4106847507 IC MSD109CL-H-LF
IC5600 4106852402 IC K4H561638J-LCCC
IC5601 4106852402 IC K4H561638J-LCCC
IC5750 4107101905 IC W25X32VSSIG-N7DE
4107159807 IC AT25DF321A-SH-B-N7DE
IC5900 4106716308 IC XC6108N28AMR
IC6500 4096933818 IC PS321TQFP80G
IC6501 4096925714 IC RCLAMP0524P
IC6502 4096925714 IC RCLAMP0524P
IC6503 4096925714 IC RCLAMP0524P
IC6504 4096925714 IC RCLAMP0524P
IC6505 4096925714 IC RCLAMP0524P
IC6506 4096925714 IC RCLAMP0524P
IC6700 4096444017 IC AMS1117-1.8
4096836416 IC LM1117S-1.8
IC6701 4095599015 IC AMS1117-3.3
4096836515 IC LM1117S-3.3
IC6800 4095598919 IC AMS1117-2.5
4097014219 IC LM1117S-2.5
IC6801 4095599015 IC AMS1117-3.3
4096836515 IC LM1117S-3.3
IC6802 4095599015 IC AMS1117-3.3
4096836515 IC LM1117S-3.3
IC6803 4096941219 IC ST1S10PHR
IC6804 4052027711 TR TPC8109
4060221603 TR HAT1131R-EL-E
IC6901 4095599015 IC AMS1117-3.3
4096836515 IC LM1117S-3.3
IC8001 4106848405 IC AT24C512BN-SH-T
IC8002 4106256200 IC 24LC32AT-I/SNG—N3VP
IC8003 4096990415 IC FSA1156P6X
CAPACITOR
C001 4041084203 ELECT 470U M 35V
C002 4041044900 CERAMIC 0.1U K 50V
4040912606 CERAMIC 0.1U K 50V
4033670417 CERAMIC 0.1U K 50V
C003 4041167500 CERAMIC 1U K 16V
C004 4041167500 CERAMIC 1U K 16V
C005 4041167500 CERAMIC 1U K 16V
C006 4041167500 CERAMIC 1U K 16V
C007 4041044900 CERAMIC 0.1U K 50V
4040912606 CERAMIC 0.1U K 50V
4033670417 CERAMIC 0.1U K 50V
C008 4041084203 ELECT 470U M 35V
C009 4034502212 CERAMIC 0.22U K 25V
C010 4041081004 ELECT 100U M 35V
C011 4041044900 CERAMIC 0.1U K 50V
4040912606 CERAMIC 0.1U K 50V
4033670417 CERAMIC 0.1U K 50V
C012 4034502212 CERAMIC 0.22U K 25V
C013 4032569316 CERAMIC 0.47U Z 50V
C014 4032569316 CERAMIC 0.47U Z 50V
C015 4041064205 ELECT 1000U M 35V
C016 4041064205 ELECT 1000U M 35V
C017 4041167500 CERAMIC 1U K 16V
C018 4041044900 CERAMIC 0.1U K 50V
4040912606 CERAMIC 0.1U K 50V
4033670417 CERAMIC 0.1U K 50V
C029 4041032907 CERAMIC 0.01U K 50V
4040901204 CERAMIC 0.01U K 50V
4032152211 CERAMIC 0.01U K 50V
C030 4041036608 CERAMIC 0.22U K 16V
4032812412 CERAMIC 0.22U K 16V
C031 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C032 4041131402 ELECT 47U M 10V
4040988304 ELECT 47U M 10V
C033 4041125401 ELECT 100U M 10V
4040987901 ELECT 100U M 10V
C034 4041125401 ELECT 100U M 10V
4040987901 ELECT 100U M 10V
C035 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C037 4041044900 CERAMIC 0.1U K 50V
4040912606 CERAMIC 0.1U K 50V
4033670417 CERAMIC 0.1U K 50V
C055 4041079704 ELECT 100U M 50V
4040989608 ELECT 100U M 50V
C056 4041044900 CERAMIC 0.1U K 50V
4040912606 CERAMIC 0.1U K 50V
4033670417 CERAMIC 0.1U K 50V
C057 4041079704 ELECT 100U M 50V
4040989608 ELECT 100U M 50V
C058 4041044900 CERAMIC 0.1U K 50V
4040912606 CERAMIC 0.1U K 50V
4033670417 CERAMIC 0.1U K 50V
C100 4041047901 CERAMIC 22P J 50V
4040947608 CERAMIC 22P J 50V
4031459915 CERAMIC 22P J 50V
C1002 4041129201 ELECT 220U M 10V
4040988106 ELECT 220U M 10V
C1005 4041128600 ELECT 10U M 16V
4040969600 ELECT 10U M 16V
C1008 4041128600 ELECT 10U M 16V
4040969600 ELECT 10U M 16V
C101 4041047901 CERAMIC 22P J 50V
Ref. No. Part No. Description Ref. No. Part No. Description
P LIST (N7DE) UE5-B 10/29/10 1:33 PM Page 18

4040947608 CERAMIC 22P J 50V
4031459915 CERAMIC 22P J 50V
C102 4040944003 CERAMIC 0.1U Z 50V
C1021 4041038206 CERAMIC 10P J 50V
4040946304 CERAMIC 10P J 50V
C1024 4041038206 CERAMIC 10P J 50V
4040946304 CERAMIC 10P J 50V
C103 4041116102 ELECT 47U M 6.3V
4041102501 ELECT 47U M 6.3V
4040923602 ELECT 47U M 6.3V
C1035 4041123506 ELECT 4.7U M 50V
4040973409 ELECT 4.7U M 50V
C104 4040944003 CERAMIC 0.1U Z 50V
C105 4041128600 ELECT 10U M 16V
4040969600 ELECT 10U M 16V
C106 4040944003 CERAMIC 0.1U Z 50V
C1060 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C1061 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C1062 4041130801 ELECT 100U M 16V
4040971801 ELECT 100U M 16V
4041084104 ELECT 100U M 16V
C1063 4040944003 CERAMIC 0.1U Z 50V
C1064 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C1066 4040944003 CERAMIC 0.1U Z 50V
C1067 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C1068 4040944003 CERAMIC 0.1U Z 50V
C107 4041047901 CERAMIC 22P J 50V
4040947608 CERAMIC 22P J 50V
4031459915 CERAMIC 22P J 50V
C108 4041033904 CERAMIC 0.47U K 10V
4040950301 CERAMIC 0.47U K 10V
4033485823 CERAMIC 0.47U K 10V
C109 4041034109 CERAMIC 0.22U K 10V
4040950202 CERAMIC 0.22U K 10V
4033256314 CERAMIC 0.22U K 10V
C110 4041045204 CERAMIC 1500P K 50V
4040901303 CERAMIC 1500P K 50V
4031552111 CERAMIC 1500P K 50V
C112 4041032907 CERAMIC 0.01U K 50V
4040901204 CERAMIC 0.01U K 50V
4032152211 CERAMIC 0.01U K 50V
C113 4041032907 CERAMIC 0.01U K 50V
4040901204 CERAMIC 0.01U K 50V
4032152211 CERAMIC 0.01U K 50V
C114 4041032907 CERAMIC 0.01U K 50V
4040901204 CERAMIC 0.01U K 50V
4032152211 CERAMIC 0.01U K 50V
C115 4041037803 CERAMIC 390P J 50V
4040948506 CERAMIC 390P J 50V
4032150910 CERAMIC 390P J 50V
C116 4041034802 CERAMIC 0.01U K 16V
4041032907 CERAMIC 0.01U K 50V
4040950400 CERAMIC 0.01U K 16V
4040901204 CERAMIC 0.01U K 50V
C117 4041036707 CERAMIC 0.47U K 16V
4041109807 CERAMIC 0.47U K 16V
4033363517 CERAMIC 0.47U K 16V
C118 4041032402 CERAMIC 1000P K 50V
4040901105 CERAMIC 1000P K 50V
4031133815 CERAMIC 1000P K 50V
C123 4041034505 CERAMIC 0.1U K 16V
4040950509 CERAMIC 0.1U K 16V
4032989619 CERAMIC 0.1U K 16V
C124 4041038206 CERAMIC 10P J 50V
4040946304 CERAMIC 10P J 50V
4031669215 CERAMIC 10P J 50V
C125 4041038206 CERAMIC 10P J 50V
4040946304 CERAMIC 10P J 50V
4031669215 CERAMIC 10P J 50V
C126 4041034505 CERAMIC 0.1U K 16V
4040950509 CERAMIC 0.1U K 16V
4032989619 CERAMIC 0.1U K 16V
C127 4041034505 CERAMIC 0.1U K 16V
4040950509 CERAMIC 0.1U K 16V
4032989619 CERAMIC 0.1U K 16V
C130 4041125401 ELECT 100U M 10V
4040987901 ELECT 100U M 10V
C131 4041034505 CERAMIC 0.1U K 16V
4040950509 CERAMIC 0.1U K 16V
4032989619 CERAMIC 0.1U K 16V
C132 4040944003 CERAMIC 0.1U Z 50V
C133 4040954705 CERAMIC 0.022U Z 50V
C134 4041044207 CERAMIC 56P J 50V
4040948902 CERAMIC 56P J 50V
C135 4040944003 CERAMIC 0.1U Z 50V
C136 4040954200 CERAMIC 0.01U Z 50V
C1500 4041034505 CERAMIC 0.1U K 16V
4040950509 CERAMIC 0.1U K 16V
4032989619 CERAMIC 0.1U K 16V
C1501 4041040209 CERAMIC 100P J 50V
4040946403 CERAMIC 100P J 50V
C1502 4041040209 CERAMIC 100P J 50V
4040946403 CERAMIC 100P J 50V
C1505 4041047901 CERAMIC 22P J 50V
4040947608 CERAMIC 22P J 50V
4031459915 CERAMIC 22P J 50V
C1506 4041047901 CERAMIC 22P J 50V
4040947608 CERAMIC 22P J 50V
4031459915 CERAMIC 22P J 50V
C3100 4040947707 CERAMIC 220P J 50V
C3101 4041032402 CERAMIC 1000P K 50V
4040901105 CERAMIC 1000P K 50V
C3102 4033835212 CERAMIC 4.7U K 6.3V
C3103 4041032402 CERAMIC 1000P K 50V
4040901105 CERAMIC 1000P K 50V
C3104 4040947707 CERAMIC 220P J 50V
C3105 4033835212 CERAMIC 4.7U K 6.3V
C3106 4041130801 ELECT 100U M 16V
4040971801 ELECT 100U M 16V
C3107 4040944003 CERAMIC 0.1U Z 50V
C3108 4041130801 ELECT 100U M 16V
4040971801 ELECT 100U M 16V
C3112 4041045709 CERAMIC 2200U K 50V
4040913306 CERAMIC 2200P K 50V
4031134119 CERAMIC 2200P K 50V
C3113 4041045709 CERAMIC 2200U K 50V
4040913306 CERAMIC 2200P K 50V
4031134119 CERAMIC 2200P K 50V
C3114 4040913108 CERAMIC 0.018U K 50V
4040954606 CERAMIC 0.018U Z 50V
C3117 4040913108 CERAMIC 0.018U K 50V
4040954606 CERAMIC 0.018U Z 50V
C3119 4040944003 CERAMIC 0.1U Z 50V
C400 4041127900 ELECT 470U M 10V
4040988403 ELECT 470U M 10V
C402 4041034505 CERAMIC 0.1U K 16V
4040950509 CERAMIC 0.1U K 16V
4032989619 CERAMIC 0.1U K 16V
C403 4041129300 ELECT 470U M 16V
4040988700 ELECT 470U M 16V
19
N7DE
Ref. No. Part No. Description Ref. No. Part No. Description
P LIST (N7DE) UE5-B 10/29/10 1:33 PM Page 19

20
N7DE
C405 4041034505 CERAMIC 0.1U K 16V
4040950509 CERAMIC 0.1U K 16V
4032989619 CERAMIC 0.1U K 16V
C5500 4041038206 CERAMIC 10P J 50V
4040946304 CERAMIC 10P J 50V
4031669215 CERAMIC 10P J 50V
C5501 4041038206 CERAMIC 10P J 50V
4040946304 CERAMIC 10P J 50V
4031669215 CERAMIC 10P J 50V
C5502 4040944003 CERAMIC 0.1U Z 50V
C5503 4040944003 CERAMIC 0.1U Z 50V
C5504 4040944003 CERAMIC 0.1U Z 50V
C5505 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5506 4041047604 CERAMIC 8200U K 50V
4040915300 CERAMIC 8200P K 50V
4032152112 CERAMIC 8200P K 50V
C5507 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5508 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5509 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5510 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5511 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5512 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5513 4041047604 CERAMIC 8200U K 50V
4040915300 CERAMIC 8200P K 50V
4032152112 CERAMIC 8200P K 50V
C5514 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5515 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5519 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5520 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5521 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5522 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5523 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5524 4040944003 CERAMIC 0.1U Z 50V
C5525 4040944003 CERAMIC 0.1U Z 50V
C5528 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C5529 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C5530 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C5531 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C5532 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C5533 4041212903 CERAMIC 2.2U K 10V
4033827811 CERAMIC 2.2U K 10V
C5534 4040944003 CERAMIC 0.1U Z 50V
C5535 4041067909 CERAMIC 2.2U K 6.3V
C5536 4040944003 CERAMIC 0.1U Z 50V
C5537 4041067800 CERAMIC 1U K 10V
4040949701 CERAMIC 1U Z 10V
4033645811 CERAMIC 1U K 10V
C5538 4041067909 CERAMIC 2.2U K 6.3V
C5540 4041045501 CERAMIC 0.018U K 50V
4040913108 CERAMIC 0.018U K 50V
4032725811 CERAMIC 0.018U K 50V
C5541 4041045501 CERAMIC 0.018U K 50V
4040913108 CERAMIC 0.018U K 50V
4032725811 CERAMIC 0.018U K 50V
C5544 4040944003 CERAMIC 0.1U Z 50V
C5545 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5546 4041035809 CERAMIC 0.047U K 16V
4040952909 CERAMIC 0.047U K 16V
4032753012 CERAMIC 0.047U K 16V
C5600 4041067909 CERAMIC 2.2U K 6.3V
C5601 4040944003 CERAMIC 0.1U Z 50V
C5602 4040944003 CERAMIC 0.1U Z 50V
C5603 4041116300 ELECT 470U M 6.3V
4040987802 ELECT 470U M 6.3V
C5605 4040944003 CERAMIC 0.1U Z 50V
C5606 4041067909 CERAMIC 2.2U K 6.3V
C5607 4040944003 CERAMIC 0.1U Z 50V
C5608 4041067909 CERAMIC 2.2U K 6.3V
C5609 4041067909 CERAMIC 2.2U K 6.3V
C5610 4040944003 CERAMIC 0.1U Z 50V
C5611 4040944003 CERAMIC 0.1U Z 50V
C5612 4040944003 CERAMIC 0.1U Z 50V
C5613 4040944003 CERAMIC 0.1U Z 50V
C5614 4040944003 CERAMIC 0.1U Z 50V
C5615 4040944003 CERAMIC 0.1U Z 50V
C5616 4040944003 CERAMIC 0.1U Z 50V
C5617 4040944003 CERAMIC 0.1U Z 50V
C5618 4040944003 CERAMIC 0.1U Z 50V
C5619 4040944003 CERAMIC 0.1U Z 50V
C5620 4040944003 CERAMIC 0.1U Z 50V
C5621 4040944003 CERAMIC 0.1U Z 50V
C5622 4040944003 CERAMIC 0.1U Z 50V
C5623 4040944003 CERAMIC 0.1U Z 50V
C5624 4040944003 CERAMIC 0.1U Z 50V
C5625 4040944003 CERAMIC 0.1U Z 50V
C5650 4040954200 CERAMIC 0.01U Z 50V
C5651 4041032402 CERAMIC 1000P K 50V
4040901105 CERAMIC 1000P K 50V
4031133815 CERAMIC 1000P K 50V
C5750 4041116102 ELECT 47U M 6.3V
4041102501 ELECT 47U M 6.3V
4040923602 ELECT 47U M 6.3V
C5751 4040944003 CERAMIC 0.1U Z 50V
C5752 4040944003 CERAMIC 0.1U Z 50V
C5755 4040944003 CERAMIC 0.1U Z 50V
C5900 4041079407 ELECT 10U M 50V
4040970200 ELECT 10U M 50V
C5901 4033579611 CERAMIC 0.1U Z 50V
C5903 4034502212 CERAMIC 0.22U K 25V
Ref. No. Part No. Description Ref. No. Part No. Description
P LIST (N7DE) UE5-B 10/29/10 1:33 PM Page 20
