Sanyo VCC-6584E - 1/3" Color CCD DSP High-Resolution... User manual

Lens not supplied with camera.
VCC-6584
1/3” Color CCD DSP
High-Resolution Camera
• Super high horizontal resolution of 520 TV lines
• High sensitivity — minimum illumination of 0.5 lx
• Built-in DSP (digital signal processing) circuitry
• Two types of backlight compensation
• 24V AC and 12 to 15V DC, dual power operation
The product introduced here is manufactured in Japan
utilizing advanced technologies and quality control.
Color
NTSC

VCC-6584
Caution: Please consult the instruction manual to ensure safe and proper operation of the product.
Distributed by:
SANYO Electric Co., Ltd.
www.sanyosecurity.com
©2004 SANYO Printed in Japan ’04.6.MA.
NOTE: Specifications subject to change without notice.
Main Features
• 1/3-inch CCD image sensor with approx. 410,000 picture elements.
• Super high horizontal resolution of 520 TV lines for maximum detail
and a noticeably sharper, clearer picture.
• High sensitivity for monitoring at a minimum required illumination of
0.5 lx with F1.2 lens at high gain.
• Built-in DSP (digital signal processing) circuitry delivers superior
color reproduction and reduced noise.
• Two types of backlight compensation selectable.
Multi-spot photometry system:
Luminance is measured in 64 separate areas for optimum backlight compen-
sation even for peripheral and moving objects; features selectable normal
and high modes.
Center-zone photometry system:
Luminance measured at center and automatic lens aperture adjustment
enable a clear image even when backlit.
Other Features
• Auto-tracing or manual white balance selectable.
• Electronic iris for indoor use with manual or fixed iris lens.
• Runs on 24V AC or 12 to 15V DC power sources.
Model No.
Scanning system
Image sensor
Effective picture elements
Resolution
Minimum illumination
Video output level
Video S/N ratio
Backlight compensation
White balance
Gain control
Light control
Lens mount
Flange back
Auto iris lens
Auto iris output
Lens iris level
Electronic iris
Electronic iris range
Synchronizing system
V phase adjustment
Sockets Video signal
Auto iris lens
Power supply
Operating
Storage
Power requirement
Power consumption
(approx.)
Camera mount
Dimensions (approx.)
Weight (approx.)
Specifications
[Unit: mm (inch)]
Dimensions
VCC-6584
NTSC Standard 525 Lines, 30 frames/sec.
1/3” (approx. 4.8 x 3.6 mm) interline transfer method CCD
768 (H) x 494 (V)
520 TV lines (horizontal), 350 TV lines (vertical)
0.5 lx (GAIN HI) / 1.0 lx (GAIN NORM) at F1.2
1.0 V (p-p) / 75 ohms, composite
More than 50 dB (AGC off)
ON / OFF — Slide SW (side)
ON = Multi-spot photometry (64-section) / Center-zone photometry system
— Slide SW (side) (activated when auto iris lens used)
Auto / Manual — Slide SW (side)
Normal / High — Slide SW (side)
Auto iris / Electronic iris
CS mount (top/bottom selectable)
12.5 mm ±0.5 mm adjustment
DC type
DC: Drive coil (+, –), Blake (Damp) coil (+, –)
LEVEL: L to H — VR (side)
ON (EI) / OFF (AI) — Slide SW (side)
1.0 to 50,000 lx (with F1.2 lens)
Internal sync / Line lock — Slide SW (side)
LINE PHASE — VR (rear)
VIDEO OUT — BNC (rear)
LENS — 4-pin (side)
24 V AC, GND — 3-pin terminal (rear)
12 to 15 V DC, GND — 2-pin terminal (rear)
Temperature: –10˚C to 50˚C [14˚F to 122˚F], Humidity: within 90% RH
Temperature: –20˚C to 70˚C [– 4˚F to 158˚F], Humidity: within 70% RH
24 V AC, 60 Hz / 12 to 15 V DC
3.6 W
1/4” – 20 UNC (top/bottom selectable)
56 (W) x 45 (H) x 99 (D) mm
[2.21 (W) x 1.77 (H) x 3.9 (D) in.] (excluding protrusions)
280 g [9.88 oz] (without lens)
SMS000
Operating
conditions
DI Solutions Company of Sanyo Electric Co., Ltd.
obtained Quality Management System ISO9001
and Environmental Management System ISO14001
certifications.
Multi-spot photometry
520 TVL Cameras for Greater Peace of Mind
VCC-6594/5984
1/3" Color CCD DSP
High-sensitivity/
resolution Camera
VCC-4594
1/3" Color CCD DSP
High-resolution
Day/Night Camera
VCC-9400
1/4" Color CCD DSP
High-resolution Day/Night
Speed Dome Camera
VCC-9300
1/4" Color CCD DSP
High-resolution
Speed Dome Camera
VCC-ZM400
1/4" Color CCD DSP
High-resolution Day/Night
AF Zoom Camera
VCC-ZM300
1/4" Color CCD DSP
High-resolution
AF Zoom Camera
VCC-XV400
1/4" Color CCD DSP
High-resolution Weatherproof
Day/Night Camera
VDC-D2184VA
1/4" Color CCD DSP High-resolution
Day/Night Vandal Proof Dome Camera
Day
Night
Day
Night
Day
Night
Day
Night
VDC-D1184VA
1/4" Color CCD DSP High-resolution
Day/Night Vandal Proof Dome Camera
Day
Night
Day
Night
56 (2.21)
28 (1.10)
45 (1.77)
1/4"–20UNC
threaded hole
(top / bottom selectable)
25.8
(10.20)
10.7
(0.42)
16
(0.63)
1.4
(0.06)
9
(0.35)
108 (4.25)
99 (3.90)
COLOR CCD C AMERA
LENS
LENS 4-pin
POWERVIDEO OUT
GND AC24V
DC12V
CLASS 2
WIRING
~~
+-
Rear panel
