INSTRUCTION MANUAL
Network Camera
VCC-WB4000P
About this manual
Before installing and using this unit, please read this manual carefully. Be sure to keep it
handy for later reference.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 20

Contents
Precautions....................................................... 3
Features/Operating Environment ................... 4
Accessories...................................................... 4
Name and Function of Each Part.................... 5
Attaching the Lens........................................... 7
Flange Back Adjustment ................................. 8
Connections ..................................................... 9
Basic Connections .................................. 9
Connecting to a LAN............................. 10
Connecting to Alarm Terminals ........... 10
Connecting to the Internet.................... 10
Connecting to the PPP (Dial up) .......... 10
Network Camera (Wired LAN) Settings........ 11
1Installation of Plug-in Software
(JPEG2000) to the Computer................ 12
2Browser Settings................................... 14
3Cookie Settings ..................................... 14
4Wired LAN Settings............................... 15
Live View ................................................ 16
5NETWORK SET Settings....................... 20
Access Level Settings (Table 1)........... 21
Changing a Password........................... 23
Viewing Live Images Without
Typing In a Username or
Password................................................ 23
Changing the Access Level.................. 24
CLOCK SET Settings ..................................... 25
Description of the CLOCK SET
Screen..................................................... 25
NTP Server Settings .............................. 27
CAMERA Settings .......................................... 28
Description of the CAMERA SET
Screen..................................................... 28
Setting the Camera Title ....................... 30
DAY/NIGHT Settings.............................. 31
AAUTO Mode Settings............................. 31
BCOLOR Mode Settings.......................... 32
CB/W Mode Settings................................ 33
DTIMER Mode Settings............................ 34
Alarm Settings................................................ 35
Flow of Operations from Alarm
Detection to Recording ......................... 35
Description of the ALARM SET
Screen..................................................... 36
Detecting Intruders................................ 38
ADetecting Intruders Using an
External Sensor ..................................... 38
BDetecting Intruders Using Motion
Detector Settings................................... 40
CDetecting Intruders Using Both an
External Sensor and Motion
Detector Settings................................... 42
Remote Alarm Operations .................... 43
AAlarm Output for a Specified
Period ..................................................... 43
BContinuous Alarm Output..................... 44
Recording and Deleting Alarm Images ........ 45
Saving into the Camera’s Internal
Memory................................................... 45
ARecording Post-alarm Images
Only......................................................... 46
BRecording both Pre-alarm and
Post-alarm Images................................. 46
Transmitting Alarm Images Via
E-mail...................................................... 48
Description of the ALARM
NOTICE (SMTP) SET Screen................. 48
Setting E-mail Message
Transmissions ....................................... 50
Saving to an Expansion Memory
Card ........................................................ 51
Recording New Alarm Data .................. 51
Viewing Live Images ...................................... 52
Viewing Live Images ............................. 52
Viewing the Full Screen Window.......... 52
Playing Back and Deleting Alarm Data ........ 53
Playing Back Alarm Data in the
Camera’s Internal Memory.................... 53
Descriptions of Alarm Operation
Buttons................................................... 53
Playing Back Expansion Memory
Card Images........................................... 54
Playing Back Alarm Images
Stored in a Computer ............................ 55
Alarm Data Deleting .............................. 56
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English – 1 –

Contents
Saving Live Images and Alarm Images........ 57
Saving Live Images onto a
Computer................................................ 57
Saving Alarm Images onto a
Computer as Still Images...................... 57
Saving All of a Single Alarm Event
into a Computer ..................................... 58
WIRELESS LAN SET Settings....................... 59
Flow of Setup......................................... 59
Camera Wireless LAN Settings ............ 60
Description of WIRELESS LAN
SET Screen............................................. 61
Encipherment Settings ......................... 61
PPP Settings................................................... 62
APPP Connection to an Internet
Service Provider
(Dial-up connection).............................. 62
BPPP Connection from a Computer
(Dial-in connection) ............................... 65
Communication Speed Setting
(RS-232C)........................................................ 67
LANGUAGE Selection.................................... 67
STATUS Checking.......................................... 68
Glossary of Terms.......................................... 69
Troubleshooting............................................. 73
If the camera cannot be connected ..... 73
If you forget the IP Address.................. 73
ACheck Using the Communication
Setting Switch at the Rear of the
Camera. .................................................. 73
BChecking Using a Memory Card .......... 74
Specifications................................................. 75
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–2 –English

Precautions
In case of problem
Do not use the camera if smoke or a strange
odour comes from the unit, or if it seems not to
function correctly. Disconnect the power cord
immediately, and consult your dealer (or a
Sanyo Authorized Service Centre).
Do not open or modify
Do not open the cabinet, as it may be dangerous
and cause damage to the unit. For internal
settings and repairs, consult your dealer (or a
Sanyo Authorized Service Centre).
Do not put objects inside the unit
Make sure that no metal objects or flammable
substance get inside the camera. If used with a
foreign object inside, it could cause a fire,
short-circuits or damages.
If water or a liquid gets inside the camera,
disconnect the power cord immediately, and
consult your dealer (or a Sanyo Authorized
Service Centre). Be careful to protect the
camera from rain, sea water, etc.
Be careful when handling the unit
To prevent damages, do not drop the camera or
subject it to strong shock or vibration.
Install away from electric or magnetic
fields
If installed close to a TV, radio transmitter,
magnet, electric motor, transformer, audio
speakers the magnetic field they generate will
distort the image.
Protect from humidity and dust
To prevent damages to the camera, do not
install it where there is greasy smoke or steam,
where the dampness may get too high, or where
there is a lot of dust.
Protect from high temperatures
Do not install close to stoves, or other heat
generating devices, such as spotlights, etc., or
where it could be subject to direct sunlight, as
that could cause deformation, discoloration or
other damages.
Be careful when installing close to the ceiling, in
a kitchen or boiler room, as the temperature may
raise to high levels.
Install where the temperature range will stay
between –10°C and 50°C. (no condensation)
Cleaning
•Dirt can be removed from the cabinet by
wiping it with a soft cloth. To remove stains,
wipe with a soft cloth moistened with a soft
detergent solution and wrung dry, then wipe
dry with dry soft cloth.
•Do not use benzine, thinner or other
chemical product on the cabinet, as that may
cause deformation and paint peeling. Before
using a chemical cloth, make sure to read all
accompanying instructions. Make sure that
no plastic or rubber material comes in contact
with the cabinet for a long period of time, as
that may cause damage or paint peeling.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –3 –

Features/Operating Environment
Web Server Function
This camera is equipped with a web server
function. The camera can be accessed using a
computer’s web browser in order to view the
camera images. In addition, up to a maximum of
16 users can simultaneously access a single
camera on the network.
Network Connections
This camera is equipped with both an Ethernet
connector and an RS-232C connector, allowing
it to be connected to a variety of different
network environments, such as LANs and the
Internet.
Wireless LAN Compatibility
The camera can also be used in a wireless LAN
environment by installing the specified wireless
LAN card.
Adoption of JPEG2000
The images captured by the camera are
compressed using the JPEG2000 format before
transmission. In comparison to conventional
JPEG formats, this format produces very little
image deterioration and allows large volumes of
data to be transmitted quickly (maximum 30 fps).
Note: The transmission rate will vary depending
on individual network conditions.
A network environment that can transmit
data at high speeds is required in order to
transmit data at 30 fps.
Alarm Recording and Playback Functions
The built-in motion sensor detects movement,
and the camera can also be connected to an
external alarm sensor (such as a switch) that is
set to detect abnormalities, so that images can
be recorded and played back when an alarm
occurs.
Day/Night Function
The day/night function allows the camera to
adapt to a variety of different luminance
conditions so that color images are monitored
during daytime, but under conditions of low
illumination such as nighttime, it switches
automatically to black & white.
Alarm Image Transfer Function
The alarm image can be transferred by E-mail.
(Compatible with POP before SMTP and SMTP
authentication.)
The camera requires the following conditions to
operate.
•OS: In this manual, the Microsoft®Windows®
98 operating system, the Microsoft®
Windows®Millennium Edition operating
system, the Microsoft®Windows®2000
operating system and the Microsoft®
Windows®XP operating system are all
referred to as Windows.
Microsoft and Windows are trademarks, or
registered trademarks of Microsoft
Corporation in the United States and/or other
countries.
•CPU: Intel®Pentium®III 800 MHz or higher
or similar with equivalent speed capacity
(Pentium®4, 2 GHz recommended)
Intel and Pentium are trademarks or
registered trademarks of Intel Corporation or
its subsidiaries in the United States and other
countries.
•Memory: 128 MB or more (256 MB or more
recommended)
•Drive: CD-ROM drive
•Network card: 10Base-T / 100Base-TX
•Protocols: TCP/IP, PPP, FTP, HTTP,
SMTP, NTP
•Browser: Microsoft Internet Explorer 5.5
SP2 or later
•Computer monitor display size of 1024 x
768 pixels or greater
Accessories
1JPEG2000 setup CD-ROM . . . . . . . . . . 1 pc.
2Lens iris plug (4-pin). . . . . . . . . . . . . . . . 1 pc.
3Ferrite core. . . . . . . . . . . . . . . . . . . . . . . 2 pc.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–4 –English

Name and Function of Each Part
PC CARD
RS-232C
ALARM IN OUT
MODEM
PC
COMD/N IN AC24V
DC12V
GND
1 2
ETHERNET
POWER
MONITOR
OUT
5
6
7
1
2
3
3
CLASS 2 WIRING
4
1Lens mount cap
Attach this cap to protect the lens mounting
section. When using the camera, remove the
cap and attach the automatic iris-type lens
(sold separately).
2Camera mounting bracket
This bracket can be installed to either the top
or bottom of the camera as desired. When
changing the position of the camera
mounting bracket, you should always reuse
the screws that have been removed.
Note: If using a camera mounting bracket (sold
separately), select a location that is strong
enough to bear the full weight of the
camera and the mounting bracket for long
periods, and install the camera and
mounting bracket securely.
3Flange back locking screws (p. 8)
4Flange back adjustment dial (p. 8)
5PC card slot (PC CARD)
Use this slot to insert a memory card or
wireless LAN card.
Note: Make sure that the camera’s power is
turned off before inserting the card.
6MONITOR OUT connector
When setting up the camera, use this
connector to connect the camera to the video
connector (VIDEO IN) of a monitor for
adjusting the angle of view and focus.
7POWER indicator
This indicator illuminates when 24 V AC or
12 V DC is being supplied to the power input
terminals of the camera.
8Link indicator
This indicator illuminates when the camera is
connected to a network. It flashes while data
transmission is in progress.
The indicator switches off when the camera
is connected to a wireless LAN.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –5 –

Name and Function of Each Part
CLASS 2 WIRING
PC CARD
RS-232C
ALARM IN OUT
MODEM
PC
AC24V
DC12V
GND
1 2
ETHERNET
POWER
MONITOR
OUT
8
H
G
JF
I
9
COMD/N IN
9Alarm, Day/Night terminals
AALARM IN terminal (IN)
Connect this terminal to an infrared
sensor or similar use in external detection
of intruders.
BD/N IN terminal (D/N IN)
This can only be used when COLOR
mode is set. A device such as an infrared
sensor can be used to automatically
switch between color images and black &
white images.
CALARM OUT terminal (OUT)
Connect this terminal to a buzzer or lamp
that is used to warn when an alarm is
detected by means of motion sensor or
alarm input. In addition, when the day/night
function (COLOR mode or TIMER mode) is
being used, an IR lamp or other device can
be made to illuminate when monitoring
switches to black & white images. (Output
rating: 18 V, 25 mA)
DGround terminal (COM)
FPower supply input terminals
(AC24V, DC12V, GND)
GRS-232C connector
Use this connector to connect the camera to
a modem for transmission of data along
telephone lines, or for connecting the camera
to a computer.
HETHERNET connector
Use this connector to connect the camera
directly to a computer or to a network. Use a
10Base-T or 100Base-TX (Category 5, UTP)
cable to make the connection.
ILens iris output connector
Connect this connector (4-pin socket) to the
lens iris plug of the automatic iris-type lens
(sold separately).
JCommunication setting switches
Switch 1: Communication setting
(PC/MODEM)
•PC: Use this switch to set the function of
the RS-232C connector when connecting
the camera directly to either a modem or
computer.
•MODEM: With a PPP connection the
data transfer is switched.
Switch 2: This switch has no function.
Note: Make sure that the camera’s power is
turned off before setting the function of
the RS-232C connector.
ALARM IN OUT
A
BC
D
COMD/N IN
MODEM
PC
1 2
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–6 –English

Attaching the Lens
Use a DC-type automatic iris-type lens (sold separately).
1Remove the lens mount cap.
2Attach the CS mount-type lens.
Note:
The “L”part of the lens
should be 5 mm or less in
length. If a lens that does not
conform to this standard is
used, it will not be possible to
attach the lens correctly.
Gently screw the lens into the camera.
For C mount type
In order to allow correct adjustment of the flange
back, attach the C mount adapter ring (option) to
the lens before attaching the lens to the camera.
3Connect the lens iris plug to the lens iris
output connector of the camera.
1(–) control coil 3(+) drive coil
2(+) control coil 4(–) drive coil
(Connecting to the lens iris plug)
Lenses from other manufacturers may have
different plug shapes and specifications. In such
cases, you may need to rewire the lens iris plug.
1Cut off the plug of the lens cable, cut off
approximately 8 mm of the insulation, and
then strip the ends of the cable sheaths
leaving approximately 6 mm of sheath intact.
2Solder the ends of the cable wires to the
ends of the pins, and then attach the cover of
the lens iris plug.
L
32
C mount-type lens
CS mount-type lens
1
1
2
3
4
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –7 –

Flange Back Adjustment
The flange back is taken from the distance between the lens (sold separately) and the image capturing
surface of the camera. It is adjusted at the time of shipment from the factory to accommodate the types
of lenses that are generally assumed to be in use.
Accordingly, the flange back does not normally need to be adjusted. However, if attaching a zoom lens
and changing from wide angle to telephoto, the images may not be captured in proper focus, and so in
such cases the flange back should always be adjusted by following the procedure given below.
1Connect a coaxial cable between the
camera output connector (MONITOR OUT)
of the camera and the monitor’s video
connector (VIDEO IN).
Turn on the camera’s power.
Adjust the flange back while viewing the
camera images on the monitor.
2Use a Phillips screwdriver to loosen the
flange back locking screws.
3Move the zoom lens to the telephoto
setting, and then use the lens focus ring
to adjust the focus.
4Move the zoom lens to the wide angle
setting, and then use the flange back
adjustment dial to adjust the focus.
5Move the zoom lens from wide angle to
telephoto (repeating steps 3 and 4) and
check that the images are properly
focused. Then tighten the flange back
locking screws.
D/N IN COM
PC CARD
RS-232C
ALARM IN OUT
MODEM
PC
AC24V
DC12V
GND
1 2
ETHERNET
POWER
MONITOR
OUT
Power supply
connector
Flange back
locking screw
Flange back
locking screw
TV monitor
(sold separately)
2, 5
3
4
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–8 –English

Connections
Turn off the power for all equipment before making any connections.
Basic Connections
1Connect the camera to a computer.
Connect a cable between the ETHERNET connectors of the camera and the computer.
Use a crossed wire-type Ethernet cable.
2Connect the power supply.
After connecting the power supply, install the supplied ferrite core Ato the power cord.
•If using a commercially-available 24 V AC adapter, always be sure to connect the ground wire
(18AWG or higher) to the ground terminal. (Figure 1)
•If using a 12 V DC power supply (sold separately: DSA-0151CD-12J), make the connections as
shown in Figure 2.
Note:
•In order to avoid any problems with the camera and the power supply, take sufficient care to
ensure that the polarities are correct when connecting the power supply.
•When the accessory ferrite cores are attached, they will increase the load on the cable, so after
doing the installation, adjust the cable accordingly.
3Insert the power cord plug into a wall outlet.
The POWER indicator will illuminate.
PC CARD
RS-232C
ALARM IN OUT
MODEM
PC
COM AC24V
DC12V
GND
1 2
ETHERNET
POWER
MONITOR
OUT
24 V AC connection
Figure 1 Figure 2
12 V DC connection
Computer
Ethernet cable
(crossed wire-type cable)
AC24V
DC12V
GND AC24V
DC12V
GND
A
CLASS 2 WIRING
1
322
3
3
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –9 –

Connections
Connecting to a LAN
Use an Ethernet cable to connect the
ETHERNET connector of the camera to the
LAN’s Ethernet switching hub.
☞Use a straight-type Ethernet cable.
Connecting to Alarm Terminals
1Connect an infrared sensor or similar to
the ALARM IN terminal at the rear of the
camera.
2Connect a buzzer or lamp to the ALARM
OUT terminal.
Once the connections are complete, install
the supplied ferrite core Ato the power cord.
Connecting to the Internet
Use an Ethernet cable to connect the
ETHERNET connector of the camera to a device
such as a router or ADSL modem that is
connected to the Internet.
☞If connecting to a router, use a straight-type
Ethernet cable. If connecting to an ADSL
modem or to some other type of device, refer
to the documentation provided with the
device for details on what type of connection
method should be used.
Connecting to the PPP (Dial up)
Connect as follows if connecting to the provider
by means of a telephone line.
PC CARD
RS-232C
ALARM IN OUT
MODEM
PC
COM AC24V
DC12V
GND
1 2
ETHERNET
POWER
MONITOR
OUT
Ethernet cable
(straight type)
Ethernet switching hub
LAN
CLASS 2 WIRING
PC CARD
RS-232C
ALARM IN OUT
MODEM
PC
COMD/N IN AC24V
DC12V
GND
1 2
ETHERNET
POWER
MONITOR
OUT
Infrared sensor or similar
Buzzer or lamp
CLASS 2 WIRING
A
PC CARD
RS-232C
ALARM IN OUT
MODEM
PC
COM AC24V
DC12V
GND
1 2
ETHERNET
POWER
MONITOR
OUT
Internet
Ethernet cable
(straight type)
Device such as router or ADSL modem
CLASS 2 WIRING
CLASS 2 WIRING
PC CARD
RS-232C
ALARM IN OUT
MODEM
PC
COMD/N IN AC24V
DC12V
GND
1 2
ETHERNET
POWER
MONITOR
OUT
MODEM
PC
1 2
Internet
Serial cable
Set switch 1 to “MODEM”
Modem
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–10 –English

Network Camera (Wired LAN) Settings
In order to use the camera as a network camera, you must make the following settings in the order
given.
1Installation of Plug-in Software
(JPEG2000) to the Computer (p. 12)
Insert the contents of the supplied setup
CD-ROM to the computer.
Note: The same setup CD-ROM is
supplied with both the network
camera and the network video
server. You can use either CD-ROM
to carry out the installation.
2Browser Settings (p. 14)
Set up the Internet Explorer browser.
3Cookie Settings (p. 14)
Set the cookies.
4Wired LAN Settings (p. 15)
Connect an Ethernet cable between the
camera and the computer and then make
the required initial settings such as the
computer IP address, user name, password
and language.
When these settings are completed, the
initial camera screen will be displayed. This
section gives descriptions of the various
parts of the initial screen for you to refer to.
5NETWORK SET Settings (p. 20)
This screen lets you make general network
settings.
This screen lets you carry out operations
such as setting access levels
(Administrator, Operator or User) and
changing passwords.
Computer
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –11 –

Network Camera (Wired LAN) Settings
1 Installation of Plug-in Software (JPEG2000) to the Computer
Install the plug-in software (on the setup CD-ROM) onto the computer that is to be used. Installing the
plug-in software makes it possible to view live images from network cameras using the computer’s web
browser.
1Turn on the power for the computer.
After Windows has loaded, continue to the
next step.
2Insert the setup CD-ROM into the CD-ROM
drive of the computer.
3Click “Start”and then click “Run”.
4Type “d:\setup.exe”.
Type the drive letter for the CD-ROM drive of
the computer in place of “d:”.
5Click the [OK] button.
After a short time, the installation window will
appear.
Note: Simply answer the prompts that
appear on the screen in order to
continue installing the software. The
installation program has been set up
beforehand to install the software
correctly.
6Click the [Next] button.
7Read the license agreement, and select “I
accept the terms in the license
agreement”if you agree to the terms of
the license. Then click the [Next] button.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–12 –English

Network Camera (Wired LAN) Settings
8Type in your username and organization
name, and then click the [Next] button.
9Click the [Install] button.
Installation of the software will start and the
window display will change to show the
installation progress.
10 Click the [Finish] button.
This completes the installation of the
plug-in software.
(Uninstalling the plug-in software)
To uninstall the plug-in software, select
“Add/Remove Programs”from the Windows
Control Panel, and delete “J2KCORE”.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –13 –

Network Camera (Wired LAN) Settings
2 Browser Settings
Check that the Security settings for Microsoft
Internet Explorer are set as described below.
Select Internet Options from the Tools menu,
click the Security tab and then click the Custom
Level button to display the settings.
1Click “Enable”for “Run ActiveX controls
and plug-ins”in the “ActiveX controls and
plug-ins”section.
2Click “Enable”for “Active scripting”in
the “Scripting”section and then click the
[OK] button.
3 Cookie Settings
The camera uses cookies.
If using Internet Explorer Version 6.0 as the web
browser, select Internet Options from the Tools
menu, click the Privacy tab, move the slide bar
to the “Medium”or lower position and then click
the [OK] button.
Note: If using Internet Explorer Version 5.5 SP2,
click the Security tab.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–14 –English

Network Camera (Wired LAN) Settings
4 Wired LAN Settings
Once the plug-in software has been installed, use the computer’s web browser to access the camera.
Note: The network camera handles large volumes of image data that has been compressed into
JPEG2000 format. In order to provide smooth access to the camera, you should close any other
applications that you do not need to have open.
1Use an Ethernet cable to connect the
camera and the computer.
Refer to “Basic connections”in the
“Connections”section.
2Click on the Network Connections icon in
the computer’s Control panel, and then
make the Internet protocol settings (IP
address and Subnet mask) for the
computer.
•IP address setting:
The camera’s default IP address is set to
“192.168.0.2”, so type in a spare number
that is 3 or higher for the IP address.
Example: “192.168.0.101”
•Subnet mask setting:
Type in “255.255.255.0”.
3Start the web browser on the computer,
type “http://192.168.0.2/”into the location
bar and then press the [Enter] key.
The password entry window will be displayed.
4Type in the username (ID3) and the
password (3333), and then click the [OK]
button.
The language selection window will be
displayed.
Note: The username and password settings in
this screen are initially set to the
Administrator level settings (ID: “ID3”;
password: “3333”) so that all required
settings can be made. There are separate
passwords for each of the three access
levels (Administrator, Operator and User),
and the passwords can be changed.
Refer to “Access Level Settings”for
further details. (p. 21)
Language selection window
The initial screen will be displayed.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –15 –

Network Camera (Wired LAN) Settings
Live View
The initial screen is displayed once the network camera and the computer have been set. This screen
is mainly used for monitoring live images and for making various settings such as image quality and
image size.
1Image quality mode select buttons
Selects the quality for the live images that are
being transmitted.
Available settings:
•SPEED: (default setting)
The quality of the live images being
transmitted is automatically adjusted in
accordance with the performance of the
computer. The quality will change depending
on the performance of the computer, so if the
quality of images may be a problem, select
the “QUALITY”setting instead.
•QUALITY:
The live images being transmitted are
displayed at their highest quality regardless
of the computer’s performance. However, the
time required for image transmission will
become longer.
7
8
1
2
3
4
5
6
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–16 –English

Network Camera (Wired LAN) Settings
2Menu select buttons
The live image display area and setting area
changes when you click on one of these buttons.
•[LIVE VIEW] button (p. 52)
Live images can be monitored.
•[FULL SCREEN] button (p. 52)
Sets the live image display area to a fixed
image size (720x480).
•[NETWORK] button (p. 20)
Used when making network settings.
•[WIRELESS LAN] button (p. 60)
Used when making wireless LAN settings.
•[PPP] button (p. 62)
Used when setting up an Internet connection
using a modem.
•[CAMERA] button (p. 28)
Used when making settings for the camera
such as camera title, image quality and
day/night mode.
•[ALARM] button (p. 36)
Used when making general alarm settings
such as alarm recording settings and alarm
image transmission settings.
•[CLOCK] button (p. 25)
Used when setting the camera’s clock.
•[RS-232C] button (p. 67)
Used when setting the communication speed
when the camera is connected directly to the
computer.
•[LANGUAGE] button (p. 67)
Click this button if you would like to change
the language. The language selection screen
will be displayed.
•[STATUS] button (p. 68)
Used when checking firmware versions and
information relating to the camera.
3Network disconnect button
Click this button to shut down operation of the
network camera. The following message will be
displayed when this button is clicked. To
reconnect the camera, click the (Refresh)
button in the title bar.
Note: If you have closed the browser without
using the network disconnect button
because of a problem such as a browser
error, wait for 90 seconds or more to pass
before accessing the camera again.
4[Get JPEG2000 PLUG-IN] button
If you need to install the JPEG2000 plug-in
software, click this button to point the browser to
a website page for downloading the software.
Select “JPEG2000 Plug-in Software”and then
start the download. You will need an Internet
connection in order to download the software.
5Live image display area
Live images are displayed here when you click
the [LIVE VIEW] or [FULL SCREEN] button.
6[SET] button
Click this button to accept the settings that have
been made using the drop-down list boxes.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –17 –

Network Camera (Wired LAN) Settings
7Indicators
ALARM indicator
Camera title
•Off: No alarm data, or recording of images is complete.
•Lit red: Post-alarm recording in progress.
•Lit orange: Pre-alarm recording in progress.
The display for the camera title indicator changes when the camera title itself is
changed.
ALARM DATA indicator •Off: Alarm images are not being recorded.
•Lit red: (alarm recording image playback is possible)
Internal memory or expanded memory (installed in the PC card slot) is filled
by alarm recording images.
•Lit green: (alarm recording image playback is possible)
Alarm data can still be recorded into the expanded memory.
•Lit orange: (alarm recording image playback is not possible)
Alarm recording images are currently being transferred from internal memory
to expanded memory, alarm recording is in progress, or and expanded
memory error has occurred.
Note: Refer to “Alarm Settings”for further details on alarm recording. (p. 36)
CLOCK UNSET indicator This appears when the clock has not yet been set.
Refer to “CLOCK SET Settings”for details on setting the clock.
REMOTE ALARM
indicator (p. 43)
If “ALARM OUT MODE”is set to “REMOTE CONTROL”(remote alarm
operation indicator display: black), the output status from the alarm output
connector can be set to continuous output or timed output.
•Black indicator: No output status when “ALARM OUT TIME”has been
set.
•Red indicator: Output status when “ALARM OUT TIME”has been
selected. When the set time is exceeded, the indicator changes to black,
but if you click the indicator once more to select it, the indicator illuminates.
•Grey indicator: No output status when “ALARM OUT TIME”is set to
“REMOTE”.
•Orange indicator: Output status when “ALARM OUT TIME”is set to
“REMOTE”. The output status can be turned on and off repeatedly by
clicking the indicator.
Note: If an IR lamp has been connected to the alarm output terminal in the
“DAY/NIGHT SET”settings, this indicator will not illuminate. (p. 32, 34)
BEEP OFF indicator
(p. 37)
If “ALARM SOUND MODE”is set to “USE”, this display appears at the same
time as the buzzer sounds when an alarm is detected. Click the indicator to
stop the alarm buzzer from sounding.
The alarm buzzer will stop automatically when alarm recording is complete.
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
–18 –English

Network Camera (Wired LAN) Settings
8Detailed settings (Drop-down list boxes)
FRAME RATE setting Set the image transmission speed from the drop-down list box. Images can be
transmitted at maximum speed depending on the network environment that the
camera is connected to.
For example, if the maximum transmission speed for the network being
connected to is 15 fps, then the images can only be transmitted at a maximum
speed of 15 fps, even if the frame rate is set to “MID 3”or higher.
Available settings: BASIC (5 fps), MID 1 (10), MID 2 (15),
MID 3 (20: Default setting), HIGH (30)
PICTURE QUALITY
setting
Use the drop-down list box to select the image quality (image compression
ratio). If a higher compression ratio is used (BASIC), the volume of image data
becomes smaller (the amount of image deterioration becomes greater) and the
transmission speed becomes faster.
Available settings: BASIC, MID 1, MID 2 (Default setting), MID 3, HIGH
Note: Alarm recording is carried out at the picture quality that is specified in the
alarm recording settings, not at the setting that is made here. (p. 47)
RESOLUTION and
EXPANSION settings
(Selection screen
example)
160x120
320x240
640x480
720x480 (720x240)
•Select the image resolution from the drop-down list box. The volume of data
transmitted will be larger when a higher resolution is selected.
•Use the drop-down list box to set the enlargement ratio to x2 or x4 (when
the image size is 160x120) or x2 (when the image size is 320x240). The
image will appear coarser when a greater enlargement ratio is selected.
Note:
•When images that are compressed using JPEG2000 are played back, the
image refresh rate will vary depending on the performance specifications of
the computer being used. In addition, if other applications besides the web
browser are running, this may also cause the image refresh rate to become
slower or may result in unstable operation. You should avoid running other
applications at the same time as much as possible.
•Set the FRAME RATE, PICTURE QUALITY and RESOLUTION settings to
levels that will not interfere with the operation of the network. If the amount
of data being transferred is too large for the network environment, it may
have an adverse effect on other network operations.
•The picture quality and image resolution cannot be changed when
pre-alarm recording has been set.
Mode selection This lets you select the DAY/NIGHT mode.
Refer to “DAY/NIGHT Settings”for details on the DAY/NIGHT modes. (p. 31)
L5AM2/XE (VCC-WB4000P) GB 2004, 2, 17
English –19 –
