INSTALLATION MANUAL
Color CCD Camera
THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED
SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL
CODES.
Please read this manual before installing and using this unit, and always follow the instructions
in it for proper use. Please also read the separate INSTRUCTION MANUAL before using the unit
for proper use.
This unit can be installed on the ceiling or wall.
bWhen routing the cables on ceiling or wall
surfaces:
Twist off the knockout piece (B) above the rib
mark (A) with a pair of pliers, etc. and pass the
connection cables through the hole.
bReplacement timing of major parts
If the unit is used continuously, parts will become worn
and deteriorated depending on the environment of use.
It is recommended that parts be replaced
approximately every 2 years (approximately 1,200,000
times) in order to maintain unit performance.
• Motor, cables used in mechanical parts, gears, etc.
Ceiling Installed (see page 5)
Wall Installed (see page 7)
(In-ceiling routing)
(Surface routing)
(In-wall routing) (Surface routing)
Important
• Be careful when opening holes for installing
the unit. Work with the power and video
cables pulled out for easy installation.
• Make sure to properly perform waterproofing
for the ceiling or wall where you are installing
the unit.
• Make sure that the surface in the installation
location has no unevenness and is strong
enough to bear the total weight of the unit.
• Install this unit in an environment where the
temperature range stays between -10°C
and +40°C (no condensation allowed).
• As a precaution against static electricity
damage, touch a nearby metal object (door
knob, etc.) to dissipate static electricity in
your body before touching this unit.
A
B
VCC-PN9575P
EnglishFrançaisDeutsch中文简体
L5BQ2_XE(INSTALLATION).book 0 ページ ２００６年８月２８日 月曜日 午後４時１分

1
Cautions and Examples of PoE Power Supply Connection
bCautions when Connecting PoE (Power over Ethernet) Power Supply
and/or Microphone/Speakers for Bi-directional Voice Communication
●Do not use the power supply of the camera when using PoE power
supply.
●PoE cannot be used for supplying power to the heater board.
When using the heater, use a camera with AC 24V.
●When connecting PoE, do not supply power to the PoE hub or PoE power
adapter until the camera installation is finished.
●Howling may occur if microphone and speakers are put too close. Move
them apart or change the speakers orientation to prevent howling. Also
adjust the microphone sensitivity as well as the speaker volume.
●For speakers on the camera side, use speakers with built-in amplifier.
bConnection when Using PoE (Power over Ethernet) Power Supply - 1
Connect the camera to the LAN through a power adapter and switching hub using LAN cables
(straight type).
Video output
(BNC connector)
Voice output (black)
3.5 φ mini jack
External
microphone input
(white)
3.5 φ mini jack
Microphone
Speaker
TV monitor
Switching hub
PC
Power adapter
LAN cable (straight type)
Max. 100 m
LAN cable
(straight type)
Video/voice data + Power supply
Max. 100 m
Microphone
Speaker
Voice signal transmission to camera
Voice signal check at PC
MEMO: You may extend the transmission distance by using multiple switching hubs with PoE support.
For details on the extendable distance, please refer to the hub performance in the
specifications, etc.
L5BQ2_XE(INSTALLATION).book 1 ページ ２００６年８月２８日 月曜日 午後４時１分

2
bConnection when Using PoE (Power over Ethernet) Power Supply - 2
Connect the camera to the LAN through a switching hub with PoE support using LAN cables
(straight type).
Video output
(BNC connector)
Voice output (black)
3.5 φ mini jack
External
microphone input
(white)
3.5 φ mini jack
Microphone
Speaker
TV monitor
PC
LAN cable
(straight type)
Max. 100 m
Video/voice data + Power supply
Microphone
Speaker
Voice signal transmission to camera
Voice signal check at PC
LAN cable (straight type)
Max. 100 m
Switching hub
with PoE support
L5BQ2_XE(INSTALLATION).book 2 ページ ２００６年８月２８日 月曜日 午後４時１分

Cautions and Examples of PoE Power Supply Connection
3
bConnection when Not Using PoE Power Supply
(when using AC 24 V or DC 12 V) (see page 9)
●Direct connection
Connect the camera to your PC using a LAN
cable (crossover type).
●LAN connection
Connect the camera to the LAN through a
switching hub using LAN cables (straight
type).
LAN cable
(crossover type)
PC
LAN cable
(straight type)
Switching hub
LAN
●Internet connection
Connect the camera to a router or ADSL
modem with LAN interface using LAN cables.
bAbout the internet connection
Port forwarding must be set on two of the
broadband router ports (camera side).
For details on how to set port forwarding, please
refer to your router's instruction manual.
• Video port number
Conduct the following port forwarding settings with
respect to the router:
IP address on the LAN side:
Camera IP address (default: 192.168.0.2)
Port number on the LAN side:
Camera video port number (default: 80)
Port number on the WAN side:
Optional
For communication, use TCP/IP.
• Voice port number
Conduct the following port forwarding settings with
respect to the router:
IP address on the LAN side:
Camera IP address (default: 192.168.0.2)
Port number on the LAN side:
Camera voice port number (default: 34341)
Port number on the WAN side:
Camera voice port number (default: 34341)
For communication, use UDP.
When installing multiple cameras on the LAN side,
change the voice port number for the second
camera onwards accordingly (default: 34341), and
make the port forwarding setting for the
corresponding router.
When connecting to a router, use the
straight type LAN cable.
When connecting to an ADSL modem or
other devices, refer to the instruction
manual for the device.
Router or
ADSL modem
Internet
L5BQ2_XE(INSTALLATION).book 3 ページ ２００６年８月２８日 月曜日 午後４時１分

4
bTo prevent electromagnetic interference
●With AC 24 V/DC 12 V
Attach the 1 supplied core (small) to the
voice input/output cables as shown in the
figure.
Attach the 1 supplied core (small) to the
power cable as shown in the figure.
Attach the 1 supplied core (small) to the
video output cable as shown in the figure.
Attach the 1 supplied core (small) to the
control input/output cables as shown in
the figure.
Attach the 1 supplied core (large) to the
LAN cable as shown in the figure.
●With PoE
Attach the 1 supplied core (small) to the
voice input/output cables as shown in the
figure.
Attach the 1 supplied core (small) to the
video output cable as shown in the figure.
Attach the 1 supplied core (small) to the
control input/output cables as shown in
the figure.
Attach the 1 supplied core (large) to the
LAN cable as shown in the figure.
Power
cable LAN cable
Voice
input/output
cables
Video output cable
Control input/output
cables
LAN cable
Voice
input/output
cables
Video output cable
Control input/output
cables
L5BQ2_XE(INSTALLATION).book 4 ページ ２００６年８月２８日 月曜日 午後４時１分

5
Installing on the Ceiling
Pushing the base plate lock (A), open the
base plate in the arrowed direction.
1Pass the connection cables through the
cable hole on the base plate.
2Position the arrow (2) on the base plate
in the direction of the lens.
3Set the base plate on the ceiling and
tighten it securely using suitable screws
and washers (B).
[Screws]
•Length: 35 mm or more
•Diameter: 3.5 to 5.0 mm
•Height of screw head: 5 mm or less
(washer included)
Push the excess of connected cables into
the ceiling. For details on the connections,
see page 9.
Pass the LAN cable through the camera in order
to plug it into the LAN port on the network board
after removing the dome cover.
See step 3under "5. Remove the dome
cover" on page 6.
Aligning the ribs (C) and hook (D) on the
camera unit with the slot on the base plate,
push the camera unit until it clicks.
1. Remove the base plate from the
camera unit
2. Install the base plate
Make sure to tighten the screws properly.
Using screws of sizes other than
specified may cause the unit to fall.
A
B
B
2
1
3. Connect the cables from the ceiling
4. Mount the camera unit to the base
plate
Make sure that the camera unit and base
plate fit perfectly.
C
D
Unplug the PoE power supply hub.
L5BQ2_XE(INSTALLATION).book 5 ページ ２００６年８月２８日 月曜日 午後４時１分

6
1While pressing down the cabinet section
(F) on the opposite side of the rib mark
(E), open the dome cover in the arrowed
direction.
2Tighten the camera unit securely using
the supplied screw (G).
3Plug the LAN cable into the LAN port on
the network board.
bSet up the camera remotely (see page 11).
bCheck the settings screen or camera
angle on a portable monitor (see page 11).
Align the rib marks (A) and push the dome
cover until it clicks.
Plug the PoE hub into a power outlet.
5. Remove the dome cover
6. Adjust/Check the video image from
the camera
E
F
Push
G
LAN port
7. Install the dome cover
8. Power on
A
L5BQ2_XE(INSTALLATION).book 6 ページ ２００６年８月２８日 月曜日 午後４時１分

7
Installing on the Wall
See “Installing on the Ceiling”.
1Pass the connection cables through the
cable hole on the base plate.
2Set the base plate on the wall with the
arrow (↑) pointing upward. Then, secure
the base plate using the screws and
washers (B) (4 places).
[Screws]
•Length: 35 mm or more
•Diameter: 3.5 to 5.0 mm
•Height of screw head: 5 mm or less
(washer included)
For details on the cable connections,
see “3. Connect the cables from the
ceiling” on page 5.
While pressing down the cabinet section (F)
on the opposite side of the rib mark (E), open
the dome cover in the arrowed direction.
1
Push the spring (A) and set free the hooks
from the base chassis. Lift and turn the
camera in the arrowed directions so that
the back of the camera becomes visible.
2Rotate the camera so that the position of
the locks (B) is upside down.
3Align the locks (B) with the slots (C) on
the base chassis, push the spring (A),
and mount the camera.
Keep the flat cable away from the chassis.
1. Remove the base plate from the
camera unit
2. Install the base plate
Make sure to tighten the screws properly.
Using screws of sizes other than
specified may cause the unit to fall.
3. Remove the dome cover
B
B
2
1
F
E
Push
4. Change the camera position
A
B
A
C
B
Unplug the PoE power supply hub.
L5BQ2_XE(INSTALLATION).book 7 ページ ２００６年８月２８日 月曜日 午後４時１分

8
4Peel off the release-coated paper of the
cover sheet and cover the back of the
camera completely with the sheet,
aligning the hole with the central shaft.
1Aligning the ribs (C) and hook (D) on the
camera unit with the slot on the base
plate, push the camera unit until it
clicks.
2Tighten the camera unit securely using
the supplied screw (E).
bSet up the camera remotely (see page 11).
bCheck the settings screen or camera
angle on a portable monitor (see page 11).
See “7. Install the dome cover” under
“Installing on the Ceiling” (see page 6).
Plug the PoE hub into a power outlet.
5. Mount the camera unit to the base
plate
6. Adjust/Check the video image from
the camera
7. Install the dome cover
D
C
E
8. Power on
When Moving the Camera from
Wall to Ceiling
1Remove the cover sheet, being careful not
to distort it.
2Free the locks (G) on the base chassis.
3Push the spring and release the camera.
4Mount the camera by following the
opposite procedure from that indicated in
“4. Change the camera position” (see
page 7).
• Check that the flat cable is not
caught between the chassis.
• When removing the cover sheet, be
careful not to deform the sheet.
Deformation of the sheet (such as
large wrinkle or bend on the sheet)
may cause the sheet to contact
inside the dome cover when it is
re-attached, which may prevent
normal operation of the camera.
G
L5BQ2_XE(INSTALLATION).book 8 ページ ２００６年８月２８日 月曜日 午後４時１分

9
Connections
RG-6U, 500 m max.
For the connection, use a RG-6U coaxial
cable.
Monitor Connection
• Using different cables from those
specified here may attenuate the
video and/or sync signals and
interfere with correct transmission.
• RG-59U coaxial cables can be
used when distance between
devices is short, but not in duct or
aerial routing.
Cable type Length
RG-59U (3C-2V) 250 m max.
RG-6U (5C-2V) 500 m max.
RG-11U (7C-2V) 600 m max.
<AL OUT>
<COMMON>
<AL IN1>
<AL IN2>
<AC 24 V/DC 12 V (+)>
<GND>
<AC 24 V/DC 12 V (–)>
Do not connect the power cord until all other connections have been completed.
Speaker connection Microphone connection
Black:
Speaker cable
White:
Microphone cable
LAN cable (Non-PoE power supply)
<COMMON>
<COMMON>
L5BQ2_XE(INSTALLATION).book 9 ページ ２００６年８月２８日 月曜日 午後４時１分
