Sanyo VPC HD700 - Xacti Camcorder - 720p User manual

Xacti Software DVD 1.2
For Digital Movie Camera
INSTRUCTION MANUAL
Please read these instructions carefully before using. Be sure to keep this manual
for later reference.

iEnglish
ATTENTION
Regarding permission to use the DVD-ROM
hThis DVD-ROM may not be reproduced without permission.
hWhen installing the software in this DVD-ROM, permission is granted for
its use only if the user agrees to the terms and conditions that are
displayed at the start of installation.
hRegarding products by other manufacturers that are specified on this
DVD-ROM, and for service, please inquire of the respective
manufacturer.
iIt is strictly forbidden to copy this manual, wholly or in part, without prior
written permission.
iThe contents of this manual are subject to change without prior notice.
iSanyo Electric shall not be held responsible for any problems resulting
from the use of this product.
iSanyo Electric declines all responsibility for damages due to improper use
of this product, failure to adhere to the instructions given in this manual, or
repairs or changes done by those other than a technician authorized by the
manufacturer.
iSanyo Electric shall not be held responsible for any damage caused by
optional devices or consumable items used with this product other than
those supplied with this product or those specified by Sanyo Electric.
iSanyo Electric shall not be held responsible for any losses or loss of
revenue resulting from the loss of data caused by the malfunction, or the
repairing of a malfunction, of this product.

1English
COPYRIGHTS
This manual and the software are copyrighted materials from Sanyo Electric
Co., Ltd.
Mac OS, QuickTime, iPod and iTunes are trademarks of Apple Inc., registered
in the U.S. and other countries.
Microsoft and Windows are registered trademarks of Microsoft Corporation in
the USA and other countries.
Intel and Pentium are registered trademarks of Intel Corporation (USA).
In this manual, the Microsoft®Windows®2000 operating system, Microsoft®
Windows®XP operating system, and Microsoft®Windows®Vista operating
system are collectively referred to as “Windows”.
All other brand or product names mentioned in this manual are trademarks or
registered trademarks of their respective companies.

English 2
CONTENTS
INTRODUCTION ....................................................................................3
About this manual ............................................................................3
The software ....................................................................................4
OPERATING ENVIRONMENT ...............................................................5
When using as a card reader ..........................................................5
SETTING THE CONNECTION MODE ...................................................6
USING AS A CARD READER ................................................................8
For Windows Vista/XP users ...........................................................8
For Windows 2000 users .................................................................9
For Mac OS X users ......................................................................10
ABOUT THE CONTENTS OF THE CARD ...........................................11
Configuration of directories in the card ..........................................11
File formats ....................................................................................11
Cautions when using as a card reader ..........................................12
CONNECTING IN THE MTP MODE ....................................................13
USING AS A PC CAMERA ...................................................................14
For Windows XP ............................................................................14
Using as a PC camera ..................................................................14
INSTALLING THE APPLICATION SOFTWARE ..................................15
Windows ........................................................................................16
Mac OS .........................................................................................17
ABOUT MovieFactory ...........................................................................18
Main features .................................................................................18
Additional features .........................................................................19
SCREEN CAPTURE .............................................................................20

3English
INTRODUCTION
This manual describes how to install and operate the Xacti Software DVD.
Please read this manual carefully, in order to use the images and audio
recordings captured with your camera in a wide range of applications.
About this manual
The explanations in this manual conform to the following conventions.
iThe examples given in this manual are generally based on a Windows
environment. For Macintosh users, while the menu names and screen
indications may be different, this is no impediment to understanding the
operation. In those places where the operations for Macintosh users and
Windows users differ, specific explanations are provided.
iIn this manual, the SD Memory Card is referred to as “card”.
hThis manual is designed for users with the following computer skills:
hKnowledge of basic computer operations
hKnowledge of basic mouse operations
hKnowledge of how to open, close, move, minimize and maximize
windows
hKnowledge of how to move from one folder to another folder
Detailed information about the operations listed above can be found in the
printed or online manuals accompanying the computer or operating system
software.
Symbols used in this manual
HINT Extra information about software or cautionary notes.
CAUTION Points requiring special attention.
(page xx) Refer to the page indicated for detailed information.

English 4
The software
The following software applications are in the Xacti Software DVD.
Please see page 14 for a summary of each software program.
iQuickTime 7.2
In this manual, referred to as QuickTime.
iiTunes 7.3
In this manual, referred to as iTunes.
iAdobe Premiere Elements 3.0 (Windows)
In this manual, referred to as Premiere Elements.
iAdobe Photoshop Album Starter Edition (Windows)
In this manual, referred to as Photoshop Album SE.
iXacti Screen Capture 1.1 (Windows)
In this manual, referred to as Screen Capture.
* Photoshop Album SE and Premiere Elements both support the MPEG-4
format. Installing these application software will allow you to view
MPEG-4 files.

5English
OPERATING ENVIRONMENT
*1Compatible with Windows 2000.
*2Limited to models with preinstalled OS.
When using as a card reader
Limited to models with the preinstalled OS.
kWindows
Windows 2000, XP, Vista
kMac OS
Mac OS X 10.3.6 or later
Windows®Mac OS
Software
QuickTime 7.2,
iTunes 7.3,
Xacti Screen
Capture 1.1*1
Adobe Premiere
Elements 3.0,
Adobe Photoshop
Album Starter
Edition
QuickTime 7.2,
iTunes 7.3
OS*2
Windows®XP
Windows®Vista
(provided with USB)
Mac OS X 10.3.9
Mac OS X 10.4.9 or
later
(provided with USB)
CPU
Pentium 4 3.6 GHz
Core Duo 1.66 GHz
or later
Pentium 4 3.2 GHz
or later
Core Duo 1.66 GHz
or later
Athlon 64 SSE2
Power PC G5 dual
2.3 GHz or later
Memory 1 GB (2 GB or more
recommended)
1 GB (2 GB if Vista)
(2 GB or more
recommended)
256 MB or more
HDD 4 GB or more unused disk space —
Drive DVD-ROM DVD-ROM
Other Direct X9.0 or above —

English 6
SETTING THE CONNECTION MODE
1Start your computer, and use the supplied USB interface cable to
connect the docking station to the computer.
hConnect the docking station’s USB terminal to the computer’s USB
connector.
2Set the camera in the docking station, and press the operation mode
button on the docking station.
hThe USB Connection Screen appears on the camera’s monitor.
OKCANCEL
USB CONNECTION
CANCEL
PRINTER
COMPUTER
To power outlet
To USB connector on the computer
Supplied dedicated USB interface cable
iInsert the plug with the [n] mark facing up.
To USB terminal on
the docking station

7English
3Select “COMPUTER”, and press
the SET button.
hThe screen to select the
computer connection mode
appears.
CARD READER:
Use the camera as an external
drive of the computer.
MTP:
Connect the camera in the MTP
mode to a Windows Vista
computer.
SCREEN CAPTURE:
Save an image of the computer
screen in your camera’s card.
PC CAMERA:
Use your camera as a PC camera.
4Select the desired connection mode, and press the SET button.
CAUTION
Insert and pull out the cable carefully
iWhen connecting the cables, make sure that the cable plugs are correctly
oriented and that they match the shapes of the terminal sockets on the
devices. Push the plugs in straight when connecting them. If undue force is
used to connect a cable, it may permanently damage the connector pins in
the terminal socket.
iDo not use excessive force when connecting and disconnecting cables.
iPlease connect the dedicated USB interface cable to your computer’s USB
connector. Do not connect it to the USB port on your monitor or keyboard,
or to the USB hub. Be especially careful when installing the driver
software. In some instances, it may not be possible to correctly install the
driver software.
Do not exchange data bi-directionally
iWhile copying data from the camera to the computer in the card reader
mode, do not perform any operation that would copy the computer data to
the camera.
USB CONNECTION
MTP
CARD READER
SCREEN CAPTURE
PC CAMERA
CANCEL
OK

English 8
USING AS A CARD READER
For Windows Vista/XP users
Mounting your camera
1Set the camera to the card reader mode (page 6).
hThe message [Found New Hardware] appears in the task tray,
showing that the camera is recognized as a drive.
hThe card is recognized (mounted) as a disk, and the [XACTI (E:)] icon
appears in the [My Computer] window.
* The drive name (E:) may be different on your computer.
2Select an action.
hIf the [XACTI (E:)] window appears automatically, select the desired
procedure from the window.
Dismounting the camera
CAUTION
iTo disconnect your camera, be sure to follow the procedure below. Failure
to follow this procedure may cause faulty operation of your computer or
loss of card data.
1Left-click on the icon for safely removing hardware in the task tray.
hA list appears showing the devices connected to the computer’s USB
connector.
<Windows Vista>
hClose the window.
2Left-click on the camera drive (E:).
hThe camera can now be disconnected.
* The drive name (E:) may be different on your computer.

9English
For Windows 2000 users
Mounting your camera
1Set the camera to the card reader mode (page 6).
hIf a message appears on the computer monitor instructing you to load
the Windows CD-ROM, follow the instructions and install the driver.
hThe camera is recognized as a drive, and [Removable disk (E:)]
appears in the [My Computer] window.
* The drive name (E:) may be different on your computer.
hThe card is recognized (mounted) as a disk.
hDouble-click on the [Removable disk (E:)] icon in [My Computer], and
you can process the contents of the card installed in your camera
exactly like you would the files in the other computer drives.
Dismounting the camera
CAUTION
iTo disconnect your camera, be sure to follow the procedure below. Failure
to follow this procedure may cause faulty operation of your computer or
loss of card data.
1Left-click on [Unplug or Eject Hardware] in the task tray.
hA list appears showing the devices connected to the computer’s USB
connector.
2Left-click on the camera drive (E:).
* The drive name (E:) may be different on your computer.
hThe [Safe to Remove Hardware] dialog box will open.
3Click on the [OK] button.
hYou can now disconnect the camera.

English 10
For Mac OS X users
Mounting your camera
1Set the camera to the card reader mode (page 6).
hThe camera is recognized as a drive and appears as an icon named
[XACTI] on the Desktop.
hDouble-click on the [XACTI] icon, and you can process the contents of
the files in your camera’s memory exactly like you would the files in
the other computer drives.
Dismounting the camera
CAUTION
iTo disconnect your camera, be sure to follow the procedure below. Failure
to follow this procedure may cause faulty operation of your computer or
loss of data in your camera.
1Drag the [XACTI] icon for your camera on the Desktop to the
trashcan.
hThe [XACTI] icon disappears from the Desktop.
hYou can now disconnect your camera.
CAUTION
When using in a Mac OS X Classic environment
iIt is not possible to save or load files directly to or from your camera. The
files must first be saved once to your hard disk.

11 English
ABOUT THE CONTENTS OF THE
CARD
Configuration of directories in the card
* Up to 9,999 files can be stored in folder 100SANYO. If more files are made,
a folder named 101SANYO is created, and they will be stored in there. New
folders will then be named in sequence, i.e., 102SANYO, 103SANYO, etc.
File formats
The format of the files saved and the method in which the file names are
determined are explained below.
* Consecutive numbers assigned in the order the files were saved.
Type of file File format File name structure
Still image
file JPEG
File name begins with SANY.
Extension is “.jpg”.
Video clip file MPEG-4
File name begins with SANY.
Extension is “.mp4”.
SANY****.mp4
Audio
recording file
MPEG-4 Audio
(AAC compression)
File name begins with SANY.
Extension is “.m4a”.
SANY****.m4a*
ROOT DCIM
MISC
100SANYO
101SANYO
SANY0003.mp4
SANY0004.m4a
102SANYO SANY0001.jpg
Folder number Image
number
Image or
audio
recording
number
(Location
of DPOF
files)

English 12
Cautions when using as a card reader
iDo not alter files or folders in your camera in any way. Doing so may result
in your camera not recognizing that data.
If you want to edit files, first copy them to your computer’s hard drive.
iCards formatted on your computer cannot be used by your camera. Format
all cards to be used by your camera with your camera.
HINT
About the volume name
iThe volume name will be [XACTI] for a card that was formatted with the
camera and [Removable disc] for a card that was formatted with a
computer.
About video clip files recorded with this camera
iYou can use Apple’s QuickTime to play back video clips on a computer.
Playback may be possible using other software that supports the ISO
standard MPEG-4 AVC/H.264 (AAC audio). QuickTime 7.2 is supplied with
the included DVD-ROM (Xacti Software DVD).
About audio files recorded with this camera
iIf you change the extension (.m4a) of audio files to “.mp4”, playback may
be possible using software that supports the ISO standard MPEG-4 (AAC
audio).
About file names when the card is replaced...
iIf the file number memory function is set to on, even when the card is
replaced, consecutive numbering of folder numbers and file names
continues from the previously installed card (see page 162 in the camera’s
instruction manual).
CAUTION
If you intend to view the images on the camera, do not use a computer
to rewrite the card files
iIf the folders, file names, or their configuration is modified using a personal
computer, it will be impossible to play back the files using the camera, and
the camera may not operate properly.

13 English
USING AS A PC CAMERA
When connected to a Windows XP or Windows Vista computer, the camera
can be used as a PC camera.
For Windows XP
Please perform the following upgrades before connecting the camera to a
computer.
iUpgrade Windows XP to SP2.
Install Windows XP SP2.
iInstall Windows Messenger 5.0 or later version.
Download Windows Messenger 5.0 or later version, and install it.
iIf using MSN Messenger, please install MSN Messenger 7.0 or later
version.
CAUTION
iThe PC camera function can be used only with computers in which
Windows XP or Windows Vista was preinstalled. Correct operation cannot
be guaranteed for models that have been upgraded to Windows XP.
iThe zoom cannot be used with the PC camera function. Moreover, only
images can be recorded; audio files cannot be recorded.
iAlthough your camera can shoot at a maximum rate of 15 frames per
second, the rate at which you can broadcast in the PC camera mode may
be less than this depending on the speed of your Internet connection.
Using as a PC camera
1 Set the camera to the PC CAMERA mode (page 6).

English 14
INSTALLING THE APPLICATION
SOFTWARE
The Xacti Software DVD contains the application software indicated below.
Installation of each application will serve to optimize your use of the data
recorded with your camera.
iPhotoshop Album SE
Organizing the data recorded with your camera is easy to understand
using the graphic screen.
iPremiere Elements
Use this integrated tool to edit various file types–such as video and music
files, photo files, data files, etc.–with your computer and store them on
discs.
iiTunes
With this music software, you can use your computer to play and organize
music and other audio files.
iScreen Capture
Save a window of your computer’s screen display as an image file in your
camera.
iQuickTime*
Play back video clips. The recorded audio is played back at the same time.
Be sure to install this application if you are going to view video clips that
were photographed with your camera (Windows). When installing iTunes,
QuickTime can be installed at the same time.
* By upgrading from QuickTime to QuickTime Pro, you will be able to edit
QuickTime movies, among other features. You can upgrade from Apple
Inc.’s web page at http://www.apple.com.

15 English
Windows
1Insert the DVD-ROM (Xacti Software DVD) in your computer’s DVD
drive.
hThe installation window soon appears.
hIf the installation window does not appear, double-click on the DVD-
ROM icon in the [My Computer] window, and double-click on [Autorun]
or [Autorun.exe] in the DVD-ROM window.
2Click on the name of the application software you wish to install.
hThe window for beginning the installation procedure for the specified
application will open.
hWhen you click on [Let’s shoot more movies!], your computer will
connect to our website, where you’ll find lots of hints for having fun
with your camera.
hThe installer program for each application is preset to properly install
the software. If you are unfamiliar with the computer, we recommend
clicking the [Next] button at each screen.
hIf a user registration dialog box appears, do not enter anything in the
[Enter your registration information] dialog box, and click on the [Next]
button.
hIf a dialog box prompting you to restart your computer appears, restart
your computer.
You can find more information about the respective applications at:
iTunes: http://www.apple.com
Premiere Elements/Photoshop Album SE: http://www.adobe.com/
3Click on [EXIT].
HINT
About Kodak online service
iWhen you complete the installation, a dialog box to connect to the website
introducing Kodak’s online service appears. To go to the website, select
the [Tell me more now !] option button. If you do not wish to go to the
website, select on the [No thanks !] option button. Click on the [OK] button.

English 16
Mac OS
1Insert the DVD-ROM (Xacti Software DVD) in your computer’s DVD
drive.
hThe DVD-ROM window will open after a few seconds.
hIf the window does not open, double-click on the DVD-ROM icon
[Xacti Disc] on the Desktop.
2Install the application.
1Double-click on [iTunes.dmg] in the [iTunes] folder.
hThe window opens.
2Double-click on [iTunes.mpkg].
hInstallation begins.
hFollow the instructions in the dialog box to complete the
installation.

17 English
ABOUT Photoshop Album SE
With Photoshop Album SE you can quickly and easily organize large numbers
of photos. It’s easy to find the photos you’re looking for and share them with
friends.
kImport data
When you connect your camera to a computer using the dedicated USB
interface cable, it is immediately detected by the system and the camera’s
internal data is imported by Photoshop Album SE and at the same time
copied to the computer. Data stored on the computer’s hard disk or on a CD-
ROM or DVD etc. can also be imported by Photoshop Album SE.
kSearch for files in the computer
Data that was copied to the computer is scattered over various locations
when it is saved. Photoshop Album SE can search through all the data in the
computer and find the specific data you’re looking for to easily import it.
Removable media (DVDs etc.) and data on the network drive (if the computer
is connected to a network) are not searched.
kData is displayed in a thumbnail area
Data imported to Photoshop Album SE is displayed in the thumbnail area as
thumbnail images. The thumbnail display mode can be adjusted by dragging
the slider that is below the thumbnail area. In addition, with Photoshop Album
SE, the thumbnail area catalog can be rearranged in a variety of ways.
kOrganize photos by their labels
Data in the Photoshop Album SE thumbnail area is automatically organized
based on the date and time it was recorded, but by using the “label” function,
you have access to advanced features to organize, sort, preview and search
the data. “Labels” are like keywords that you can assign to the data.
Assigning labels does not change the data itself in any way, but it provides
more flexibility and ease in searching and organizing your data.

English 18
kOrganize data into collections
A collection is like a container in which you put data. You can use the
thumbnail area to drag and drop data in the desired order into a collection.
The order is indicated by a number displayed for each data. Unlike with
labels, photos in a collection can be displayed in the order you specify.
kImage editing
Use Photoshop Album SE to edit your imported photos with functions such as
rotate, clipping, and brightness and sharpness adjustment.
kCreate PDF slideshows
In a PDF slideshow, photos are automatically displayed in a specified order.
Slideshows are ideal for sharing photos in your emails or for displaying photos
on your computer screen.
