Sanyo CE19LD08-B User manual

INSTRUCTION MANUAL

Colour television

ENGLISH

1 - 32

CE19LD08-B

Please read this Instruction book before using your television.

We wish you many hours of pleasure from your new television.

Problems with set-up?

Call 0844 335 2230

English - 1 -

Contents

Feature Menu ................................................... 22

Install Menu ...................................................... 22

Source Menu .................................................... 24

PC Mode Menu System........................................ 24

PC Position Menu............................................. 24

Displaying TV Information .................................... 25

Mute Function....................................................... 25

Picture Mode Selection......................................... 25

Freezing Picture ................................................... 25

Zoom Modes......................................................... 26

Auto .................................................................. 26

16:9................................................................... 26

4:3..................................................................... 26

Panoramic......................................................... 26

14:9................................................................... 26

Cinema ............................................................. 26

Subtitle.............................................................. 26

Zoom................................................................. 26

Teletext ................................................................. 27

Tips....................................................................... 27

Image Persistence............................................ 27

No Power.......................................................... 27

Poor Picture...................................................... 27

No Picture......................................................... 27

Sound ............................................................... 27

Remote Control................................................. 27

Input Sources.................................................... 27

Appendix A: PC Input Typical Display Modes....... 28

Appendix B: AV and HDMI Signal

Compatibility (Input Signal Types) ........................ 29

Appendix C: Supported File Formats

for USB Mode....................................................... 30

Speciﬁcations ....................................................... 31

Important Instruction............................................. 32

MAINS (AC) OPERATION ................................ 32

IMPORTANT..................................................... 32

CAUTION.......................................................... 32

SAFETY PRECAUTION ................................... 32

Accessories ............................................................ 2

Features ................................................................. 2

Introduction............................................................. 2

Preparation............................................................. 3

Safety Precautions ................................................. 3

Power Source ..................................................... 3

Power Cord......................................................... 3

Moisture and Water ............................................ 3

Cleaning.............................................................. 3

Heat and Flames ................................................ 3

Lightning ............................................................. 3

Replacement Parts ............................................. 3

Servicing............................................................. 3

Waste Disposal................................................... 3

FOR EU USERS................................................. 4

Disconnecting the Device ................................... 4

Headphone Volume ............................................ 4

Installation........................................................... 4

LCD Screen ........................................................ 4

Warning .............................................................. 4

Overview of the Remote Control ............................ 5

LCD TV and Operating Buttons.............................. 6

Viewing the Connections- Back Connectors .......... 6

Viewing the Connections - Side Connectors .......... 7

Power Connection .................................................. 7

Aerial Connection ................................................... 7

Using Side USB Input............................................. 8

USB Memory Connection ................................... 8

Connecting the LCD TV to a PC............................. 8

Connecting to a DVD Player................................... 9

Using Side AV Connectors ..................................... 9

Connecting Other Equipment via Scart .................. 9

Inserting Batteries into the Remote Control.......... 10

Switching the TV On/Off ....................................... 10

To Switch the TV Off ......................................... 10

Input Selection...................................................... 10

Basic Operations .................................................. 10

Operation with the Buttons of the TV................ 10

Initial Settings ........................................................11

General Operation.................................................11

Electronic Programme Guide (EPG) .................... 12

Displaying Subtitles .......................................... 12

Digital Teletext (** for UK only) ......................... 12

Analogue Teletext ............................................. 12

Widescreen....................................................... 12

IDTV Menu System .............................................. 13

Channel List...................................................... 13

Programme Guide ............................................ 14

Timers............................................................... 14

Conditional Access ........................................... 15

TV Setup........................................................... 15

Setup ................................................................ 15

Media Browser.................................................. 19

Analogue TV Menu System.................................. 20

Picture Menu..................................................... 20

Sound Menu ..................................................... 21

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 101_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 1 20.07.2010 10:36:1920.07.2010 10:36:19

English - 2 -

Please read the corresponding instructions

of this handbook prior to the ﬁrst usage of

the device, even when the usage of electronic

devices is familiar to you. Notice especially

the chapter SAFETY PRECAUTIONS.

Carefully keep the handbook as future

reference. When selling the device or giving

it away, absolutely give these direction for

use.

Accessories

SCREEN

LANG

SUBTTL

PIP

1 2 3

4 65

97 8

RETURN

EPG

FAV

SOURCE

PRESETS

SLEEP

INFO/?

Remote Control

Batteries: 2 X AAA

Instruction Book

Note: You should check the accessories after purchasing.

Make sure that each accessory is included.

Features

• Remote controlled colour LCD TV.

• Fully integrated digital TV (DVB-T).

• HDMI connector for digital video and audio. This

connection is also designed to accept high deﬁnition

signals.

• USB input.

•200 programmes from VHF, UHF(analogue).

• 500 programmes for digital mode (IDTV).

• OSD menu system.

• Scart socket for external devices (such as video,

video games, audio set, etc.).

• Stereo sound system.

• Teletext, fastext, TOP text.

• Headphone connection.

• Automatic programming system.

• Forward or backward manual tuning.

• Sleep timer.

• Child lock.

• Automatic sound mute when no transmission.

• NTSC playback.

• AVL (Automatic Volume Limiting).

• When no valid signal is detected, after 5 minutes the

TV switches automatically to standby mode.

• PLL (Frequency Search).

• PC input.

• Plug&Play for Windows 98, ME, 2000, XP, Vista,

Windows 7.

• Game Mode.

Introduction

Thank you for choosing this product. This manual will

guide you for the proper operation of your

TV. Before operating the TV, please read

this manual thoroughly.

Please do keep this manual in a safe place

for future references.

This device is intended to receive and display TV

programs. The different connection options make

an additional expansion of the reception and display

sources possible (receiver, DVD player, DVD recorder,

VCR, PC etc.). This device is only suitable for the

operation in dry interiors.

This appliance is intended solely for private domestic

use and may not be used for industrial and commercial

purposes. We exclude liability in principle, if the device

is not used as intended, or unauthorized modiﬁcations

have been made. To operate your LCD-TV in extreme

ambient conditions may cause the damage of the

device.

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 201_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 2 20.07.2010 10:36:1920.07.2010 10:36:19

English - 3 -

Cleaning

Before cleaning, unplug the TV set

from the wall outlet. Do not use liquid or

aerosol cleaners. Use soft and dry cloth.

Ventilation

The slots and openings on the TV set

are intended for ventilation and to ensure reliable

operation. To prevent overheating, these openings

must not be blocked or covered in anyway.

Heat and Flames

The set should not be placed near to

open ﬂames and sources of intense

heat such as an electric heater. Ensure

that no open ﬂame sources, such as

lighted candles, are placed on top

of the TV. Batteries should not be

exposed to excessive heat such as sunshine, ﬁre

or the like.

Lightning

In case of storm and lightning or when

going on holiday, disconnect the power

cord from the wall outlet.

Replacement Parts

When replacement parts are required, make sure that

the service technician has used replacement parts,

which are speciﬁed by the manufacturer or have the

same speciﬁcations as the original one. Unauthorized

substitutions may result in ﬁre, electrical shock or

other hazards.

Servicing

Please refer all servicing to qualiﬁed

personnel. Do not remove the cover

yourself as this may result in an electric

shock.

Waste Disposal

Instructions for waste disposal:

• Packaging and packaging aids are recyclable and

should principally be recycled. Packaging materials,

such as foil bag, must be kept away from children.

• Batteries, including those which are heavy metal-

free, should not be disposed of with household

waste. Please dispose of used battery in an

environment friendly manner. Find out about the

legal regulations which apply in your area.

• Cold cathode fluorescent lamp in LCD PANEL

contains a small amount of mercury; please follow

the local laws or regulations for disposal. Don’t try

to recharge batteries. Danger of explosion. Replace

batteries only with the same or equivalent type.

Preparation

For ventilation, leave a free space of at least 10 cm

all around the set. To prevent any fault and unsafe

situations, please do not place any objects on top

of the set.

Use this device in moderate climates.

10 cm

Safety Precautions

Read the following recommended safety

precautions carefully for your safety.

Power Source

The TV set should be operated only from a 220-240

V AC, 50 Hz outlet. Ensure that you select the correct

voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the

power cord (mains lead) or pinch the cord. Handle the

power cord by the plug. Do not unplug the appliance

by pulling from the power cord and never touch the

power cord with wet hands as this could cause a short

circuit or electric shock. Never make a knot in the cord

or tie it with other cords. The power cords should be

placed in such a way that they are not likely to be

stepped on. A damaged power cord can cause ﬁre or

give you an electric shock. When it is damaged and

needs to be replaced, it should be done by qualiﬁed

personnel.

Moisture and Water

Do not use this device in a humid

and damp place (avoid the bathroom,

the sink in the kitchen, and near the

washing machine). Do not expose this

device to rain or water, as this may be

dangerous and do not place objects

filled with liquids, such as flower

vases, on top. Avoid from dripping or

splashing.

If any solid object or liquid falls into the cabinet, unplug

the TV and have it checked by qualiﬁed personnel

before operating it any further.

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 301_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 3 20.07.2010 10:36:2020.07.2010 10:36:20

English - 4 -

FOR EU USERS

The symbol mark and recycling

systems described below apply to EU

countries and do not apply to countries

in other areas of the world.

Your SANYO product is designed and

manufactured with high quality materials

and components which can be recycled

and/or reused.

The symbol mark means that electrical and electronic

equipment, batteries and accumulators, at their end-

of-life, should be disposed of separately from your

household waste.

Note:

If a chemical symbol is printed beneath the symbol

mark, this chemical symbol means that the battery

or accumulator contains a heavy metal at a certain

concentration. This will be indicated as follows: Hg:

mercury, Cd: cadmium, Pb: lead

In the European Union there are separate collection

systems for used electrical and electronic equipment,

batteries and accumulators.

Please, dispose of them correctly at your local

community waste collection/recycling centre.

Please, help us to conserve the environment we

live in!

Disconnecting the Device

The mains plug is used to disconnect TV set from

the mains and therefore it must remain readily

operable.

Headphone Volume

Excessive sound pressure from earphones

and headphones can cause hearing loss.

Installation

To prevent injury, this device must be securely

attached to the wall in accordance with the installation

instructions when mounted to the wall (if the option

is available).

LCD Screen

The LCD panel is a very high technology product with

about a million thin ﬁlm transistors, giving you ﬁne

picture details. Occasionally, a few non-active pixels

may appear on the screen as a ﬁxed blue, green or

red point. Please note that this does not affect the

performance of your product.

Warning

Do not leave your TV in standby or operating mode

when you leave your house.

The Standby / On button doesn´t separate this

device completely from mains. Moreover the device

consumes power in the standby operation. In order to

separate the device completely from mains, the mains

plug has to be pulled from the mains socket. Because

of that the device should be set up in a way, that an

unobstructed access to mains socket is guaranteed,

so that in case of emergency the mains plug can be

pulled immediately. To exclude the danger of ﬁre, the

power cord should principally be separated from the

mains socket prior to a longer period of non-usage,

i.e. during vacations.

Electrical device not in the hands of children Never let

children use electrical device unsupervised.

Children can´t always recognize properly the possible

dangers.

Batteries / accumulators can be life threatening when

swallowed. Store batteries unreachable for small

children. In case of swallowing a battery medical

aid has to be sought immediately. Also keep the

packaging foils away from children. There is danger

of suffocation.

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 401_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 4 20.07.2010 10:36:2020.07.2010 10:36:20

English - 5 -

Overview of the Remote Control

Mono/Stereo - Dual I-II / Current language (in1.

DTV mode) (*)

Expand (in TXT mode)/ Image size2.

Electronic programme guide (in DTV mode)3.

Favourite Mode Selection (*) (in DTV mode)4.

Red (Sound Menu) /Channel List (*) (in DTV5.

mode)

Green / Picture Menu / Subtitle on-off (*) (in6.

DTV mode)

Direct Programme7.

Teletext / Mix / PAT (in TXT mode)8.

Volume Down9.

Programme Down / Page up (in DTV mode)10.

Mute11.

Navigation Buttons12.

Exit / Return (in DTV mode) / Index Page (in13.

TXT mode)

Menu14.

Info / Reveal (in TXT mode)15.

Okay (Store) / Select / Channel list (in DTV16.

mode) / Hold (in TXT mode)

External Source17.

Programme Up / Page down (in DTV mode)18.

Volume Up19.

Programme Previous20.

Yellow / Feature Menu / Currrent Language (*)21.

(in DTV mode)

Blue (Install Menu) / Favourite Mode Selection22.

(*) (in DTV mode)

Picture Mode Selection23.

Sleep Timer24.

No Function25.

Subtitle on-off / TXT Subtitle26.

Standby27.

(*) available for EU countries.

SCREEN

LANG

SUBTTL

PIP

1 2 3

4 65

97 8

RETURN

EPG

EPG FAV

SOURCE

PRESETS

SLEEP

INFO/?

1/ABC

2/DEF

3/GHI

4/JKL

5/MNO

6/PQR

7/STU

8/VWX

9/YZ

You can use numeric buttons on the remote control

to input letters when necessary. Pressing the numeric

buttons ‘0...9’ inputs letters assigned to that button.

Letters are present one by one as the button is

pressed. Table below shows the assigned letters:

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 501_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 5 20.07.2010 10:36:2120.07.2010 10:36:21

English - 6 -

LCD TV and Operating Buttons

FRONT and REAR VIEW SIDE VIEW Control Buttons

Up button1.

Down button2.

Programme/Volume / AV3.

selection button

Standby/On button4.

Note 1:You can use “+/-” buttons to

change volume. If you want to change

channels, press P/V/AV button once

and then use “+/-” buttons. If you hold

the P/V/AV button about a few seconds,

source OSD will be displayed. Main

menu OSD cannot be displayed via

control buttons.

Note 2: In source menu, + button

functions as cursor down, - button

functions as cursor up.

Viewing the Connections- Back Connectors

SCART socket inputs or outputs for external devices.1.

Connect the SCART cable between SCART socket on TV and

SCART socket on your external device (such as a decoder, a VCR

or a DVD player).

Note: If an external device is connected via the SCART socket,

the TV will automatically switch to AV mode.

PC Input is for connecting a personal computer to the TV set.2.

Connect the PC cable between the PC INPUT on the TV and the

PC output on your PC. Component Video Inputs (YpBPr) are used

for connecting component video.

You can use PC input to enable YPbPr signal connection with

a device that has component output. Connect the YPbPr to PC

cable between the PC INPUT on the TV and the component video

outputs of your device. (YPbPr cable is not supplied)

HDMI3. : HDMI input

HDMI Input is for connecting a device that has an HDMI socket.

Your LCD Television is capable of displaying High Deﬁnition pictures from devices such as a High

Deﬁnition Satellite Receiver or DVD Player. These devices must be connected via the HDMI sockets

or Component Socket. These sockets can accept either 480i, 480p, 576p, 576i, 720p, 1080i, 1080p

signals. No sound connection is needed for an HDMI to HDMI connection.

RF Input connects to an antenna or a cable system.4.

Note that if you use a decoder or a media recorder, you should connect the aerial cable through the

device to the television with an appropriate antenna cable, as shown in the illustration in the following

pages.

HDMI

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 601_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 6 20.07.2010 10:36:2120.07.2010 10:36:21

English - 7 -

Viewing the Connections - Side Connectors

CI Slot is used for inserting a CI card. A CI card allows you to view all the1.

channels that you subscribe to. For more information, see “Conditional

Access” section.

USB Input (functional in DTV mode only).2.

Video Input is used for connecting video signals of external devices.Connect3.

the video cable between the VIDEO IN socket on the TV and the VIDEO

OUT jack on your device.

Audio Inputs are used for connecting audio signals of external devices.4.

Connect the audio cable between the AUDIO INPUTS on the TV and the

AUDIO OUTPUT jacks on your device.

Also to enable PC/YPbPr sound connection in such a case, use an

appropriate audio cable between the connected device’s audio outputs and

the TV’s audio inputs

Note: If you connect a device to the TV via the VIDEO or PC/YPbPr cable

(YPbPr cable is not supplied) you should also connect your device with an

audio cable to the AUDIO INPUTS of the TV to enable audio.

Headphone jack is used for connecting an external headphone to the5.

system. Connect to the HEADPHONE jack to use headphones.

6. , switch is used for turning the TV on or off.

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

• After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the

mains.

• Plug the power cable to the mains socket outlet.

Aerial Connection

• Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.

HDMI

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 701_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 7 20.07.2010 10:36:2320.07.2010 10:36:23

English - 8 -

Using Side USB Input

• You can connect USB devices to your TV by using

the USB input of the TV. This feature allows you to

display/play music,photo or video ﬁles stored in a

USB stick.

• It is possible that certain types of USB devices (e.g.

MP3 Players) may not be compatible with this TV.

• You may back up your ﬁles before making any

connections to the TV set in order to avoid any

possible data loss. Note that manufacturer will not

be responsible for any ﬁle damage or data loss.

• The TV supports only FAT32 disk formatting. NTFS

format is not supported. If you connect a USB disk

with NTFS format, “usb is unformatted” osd will

be displayed.

• Do not pull out USB module while playing a ﬁle.

CAUTION: Quickly plugging and unplugging USB devices,

is a very hazardous operation. Especially, do not repeatedly

quickly plug and unplug the drive. This may cause physical

damage to the USB player and especially the USB device

itself.

SIDE VIEW USB MEMORY

USB Memory Connection

• Plug your USB device to the USB input of the TV.

IMPORTANT: The TV supports only FAT32 disk

formatting. NTFS format is not supported.

Connecting the LCD TV to a

For displaying your computer’s screen image on

your LCD TV, you can connect your computer to the

TV set.

• Power off both computer and display before making

any connections.

• Use 15-pin D-sub display cable to connect a PC

to the LCD TV.Use an audio cable between audio

inputs of the TV (side) and audio output of your PC

to enable sound connection.

• When the connection is made, switch to PC source.

See “Input selection” section.

• Set the resolution that suits your viewing requirements.

Resolution information can be found in the appendix

parts.

HDMI

PC audio cable

(not supplied)

to AUDIO INPUTS

on the TV

PC RGB cable

(not supplied)

to PC input

Audio

Inputs

PC Input

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 801_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 8 20.07.2010 10:36:2420.07.2010 10:36:24

English - 9 -

Connecting to a DVD Player

If you want to connect a DVD player to your LCD

TV, you can use connectors of the TV set. DVD

players may have different connectors. Please refer

to your DVD player’s instruction book for additional

information. Power off both the TV and the device

before making any connections.

Note: Cables shown in the illustration are not supplied.

• If your DVD player has an HDMI socket, you can

connect via HDMI. When you connect to DVD player

as illustrated below, switch to HDMI source. See,

“Input Selection” section.

• Most DVD players are connected through

COMPONENT SOCKETS. YPbPr can be use only

when you connect a device that has a YPbPr output

through the PC input with YPbPr to PC cable. To

enable sound connection, use AUDIO IN located

side of the TV (YPbPr cable is not supplied).

. When the connection is made, switch to YPbPr

source. See, “Input selection” section.

• You may also connect through the SCART socket.

Use a SCART cable as shown below.

HDMI

input

Scart socket YPbPr to PC

cable (optional)

Component

audio

inputs

DVD Player

Note: These methods of connection perform the same

function but in different levels of quality. It is not necessary

to connect by all three methods.

Using Side AV Connectors

You can connect a range of optional equipment

to your LCD TV. Possible connections are shown

below. Note that cables shown in the illustration are

not supplied.

• For connecting a camcorder, connect to the VIDEO

IN socket and the AUDIO SOCKETS. For selecting

the related source, see the section “Input selection”

in the following parts.

• To listen the TV sound from headphones, connect

to the HEADPHONE jack of theTV

Headphone

Connecting Other Equipment

via Scart

Most devices support SCART connection. You can

connect a; DVD recorder, a VCR or a decoder to

your LCD TV by using the SCART socket. Note that

cables shown in the illustration are not supplied.

Power off both the TV and the devices before making

any connections.

For more information, refer to your device’s own

instruction book.

SCART socket

Decoder

DVD Recorder Video Recorder

01_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 901_MB45_[GB]_3920UK_UKIDTV_NICKEL9_19908W_10068907_50168569.indd 9 20.07.2010 10:36:2620.07.2010 10:36:26
