SERVICE MANUAL Colour Television
Specifications
Power Source . . . . . . . .AC220 - 240V, 50/60Hz.
Colour System . . . . . . . .PAL, NTSC4.43, NTSC, PAL 60Hz
Television System . . . . .B/G, D/KK’, I, M/M
Channel Coverage . . . . .VHF: E2-E12, R1-R12, K1-K9, J1-J12, A2-A13
0-11, 5A (Aus.), 1-11 (NZ)
UHF: 21-69, A14-A69, J13-J62, 28-69 (Aus.)
CATV: S1-S41, X, Y, Z, Z+1, Z+2
Video IF . . . . . . . . . . . . . .38.0 MHz
Aerial Input Impedance .75Ω
Ext. Terminals
Video inputs: Phono jack 2 (1.0Vp
- p, impedance 75Ω)
Audio inputs: Phono jack 2 (436mVrms, impedance more than 40KΩ)
Video monitor output: Phono jack 1 (1.0Vp
- p, 75Ω)
Audio monitor outputs: Phono jack 1(436mVrms, Impedance less than
600Ω)
Speaker . . . . . . . . . . . . . . 5 cm  9 cm  2 pcs.
Sound Output . . . . . . . . . 2.5W + 2.5W (RMS)
Dimensions . . . . . . . . . . . 580 (W) 460 (H) 465 (D)mm
Weight . . . . . . . . . . . . . . . approx. 19.5 Kg
Specifications subject to change without notice
Original Version
Chassis Series: AC6-A
C8VV
FILE NO.
Model No. CP21CE1
Service Ref. No. CP21CE1-00
(Australia)
Give complete “SERVICE REF. NO.” for parts
order or servicing. It is shown on the rating plate
at the cabinet back of the unit.
This T.V. receiver will not work properly in
foreign countries where the television
transmission system and power source dif-
fer from the design specifications. Refer to
the specification table.
Product Code:113002116
REFERENCE NO. SM3010159
VIDEO AUDIO
TV/AV MENU - + CH
POWER
123
456
789
0
TV/AV
TIMER
x
-/--
SWAP
CH SCAN
MENU
BASS
SOUND
S. SYS
SURROUND
CH
CH
A B
.
PP
JXPSC
SM_21-C8VV(AC6-A)AUS 2/8/06 3:32 PM Page 1

Contents
-2-
Safety Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chassis Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
IC Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
CPU Port Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Service Adjustment with Replacing Memory IC(IC801) . . . . . . . . . . . . 8-11
Service Mode Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Service Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Special Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Purity and Convergence Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Mechanical Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Protection Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cabinet Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Chassis Electrical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-25
Component Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26-27
Voltages and Waveforms Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-28
Safety Notice
SAFETY PRECAUTIONS
1: An isolation transformer should be connected in the
power line between the receiver and the AC line
when a service is performed on the primary of the
converter transformer of the set.
2: Comply with all caution and safety-related notes pro-
vided on the cabinet back, inside the cabinet, on the
chassis or the picture tube.
3: When replacing a chassis in the cabinet, always be
certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers
or shields, barriers, isolation resistor-capacitor net-
works etc.. Before returning any television to the
customer, the service technician must be sure that
it is completely safe to operate without danger of
electrical shock.
X-RADIATION PRECAUTION
The primary source of X-RADIATION in television receiver is the picture tube. The picture tube is specially con-
structed to limit X-RADIATION emissions. For continued X-RADIATION protection, the replacement tube must be
the same type as the original including suffix letter. Excessive high voltage may produce potentially hazardous X
- RADIATION. To avoid such hazards, the high voltage must be maintained within specified limit. Refer to this
service manual, high voltage adjustment for specific high voltage limit. If high voltage exceeds specified limits,
take necessary corrective action. Carefully follow the instructions for + B1 volt power supply adjustment, and high
voltage check to maintain the high voltage within the specified limits.
PRODUCT SAFETY NOTICE
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by mark in the parts list and the schematic diagram designate components in which
safety can be of special significance. It is particularly recommended that only parts designated on the parts list
in this manual be used for component replacement designated by mark . No deviations from resistance
wattage or voltage ratings may be made for replacement items designated by mark .
SM_21-C8VV(AC6-A)AUS 2/8/06 3:32 PM Page 2

IC001
AUDIO AMP.
A101
TUNER
IC801
MEMORY
IC201
CPU/CHROMA/
IF/VIDEO/DEF.
RC
RECEIVER
LED
FRONT
KEYS
AUDIO (L)-IN
AUDIO (L)-IN
AUDIO (L)-OUT
V-IN
V-OUT
SP901
SP902 IC501
VERTICAL
Q431
T431
H-DRIVE
TRANS Q432
STB
10
R-OUT
G-OUT
B-OUT
V-OUT
H-OUT
KEY-IN
RC-IN
ON-TIMER
VIDEO-IN
L-OUT
R-OUT
IF OUT
X161
SAW
FILTER IF-IN
IF-IN
VIDEO-OUT
T471
FBT
SDA/SCL
T611
CONVERTER
TRANS
5V-1
5VRC
9V
24V 14V
130V
IC202
IC651
PRIMARY
CIRCUIT
D610
HV
FOCUS
SCREEN
Q901
CRT
L902
DY
AC
(Power ON=High)
17
1
12
13 14
21
54
52 29
26
39
31/32
5/6
4
8
12
63
64
5
CPU, TUNER, MEMORY
VERTICAL
AUDIO AMP.
FBT, TUNER
AUDIO CONTROL CPU, VERTICAL
11
14
12 13
ABL
10 FEED BACK
V-IN
AV-FRONT
AV-REAR
+
VIDEO-IN 46
AUDIO-OUT 6
5
FM-OUT
EXT. AUDIO-IN 9
-3-
Chassis Block Diagrams
