Sanyo SC-A127C - Upright Commerical Vacuum Cleaner User manual

FILE No.
Notice
CORRECTION
SERVICE FLASH
Please add this notice to the Manuals listed below.
Category :
Model :
The reason of change.
A : Misprint C : StandardizationB : Quality Reliabilitise
D : Design F :E : Supply Level
G :
Destination :
Date :
Effective from : Serial NO.
REF : No. Issue Number
PRODUCTION CHANGE
ADD INFORMATION
REFERENC No. PL2110043-02
Jul./2005 Printed in China
Vacuum Cleaner
SC-A127C
U.S.A. PL2110043-01
Jul 2003
1
Page &
Section Key No. Part No. Description
P.4
Reason
PRODUCT CODE NO. 1-326 734 57 (K)
Q'ty
663 007 2813 BRUSH BASE ASSEMBLY LEFT
70 2
2
70
71
Old Part
71
70
New Part
MISPRINT
663 007 2820
BRUSH BASE ASSEMBLY RIGHT
A
A
71
SANYO FISHER SERVICE CORPORATION.

- 1 -
FILE No.
PARTS LIST
Specifications
Wiring Diagram
Vacuum Cleaner
Carbon brush
Switch Fuse
(125V 12A)
A C
Stator
Stator
Rotor
Motor
Green
Black
White
Cord
SC-A127C (U.S.A.)
PRODUCT CODE NO.
1 - 326 734 57 ( K )
REFERENCE NO. PL2110043-01
Power source : AC 120 V 60 Hz
Power consumption : 12 A
Motor revolution : 35,500 r.p.m.
Vacuum : 22,000 Pa
Dimensions : 340 x 330 x 1,070 mm
L X W X H ( 13 - 3/8” x 12 - 31/32” x 42 - 1/8” )
Net weight : 6.9 Kg ( 15 lbs. 3 ozs. )
Attachment : Suction hose, 2 Wands,
Crevice tool, Upholstery tool
Separate sale : Paper bag(5pcs) 1-323-117-01 SC-PU1

1
52
4
33
1
13
2
12
1
3
36
1
42
8
41
40
21
15
38
27
24
23
39
45
47
26
25
22
34
26
43
22
50
17
18
21
23
51
16
1
1
20
19
48
49 12
32
27
32
27
28
35
5
6
7
910
1
11 114
37
31
30
29
46
44
- 2 -
Exploded View NOTE
: The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-A127C (U.S.A.)

58
82
59
57
84
53
56
54
60
83
64 (65 - 80)
65
65
66 67 68
68
69
70
71
72 73
74 75
76
77
77
78 79
80
61 62
35
63
81
89
85
86 87
88
82
55
86
85
- 3 -
Exploded View NOTE
: The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-A127C (U.S.A.)

- 4 -
For Parts or Service Contact
SANYO FISHER SERVICE CORPORATION.
21605 Plummer Street,
Chatsworth, CA 91311
Parts List NOTE
: The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-A127C (U.S.A.)
Jul./2003
Key
No. Key No.
Parts No. Description Q'ty Parts No. Description Q'ty
COLOR CODE:NN-B(BLACK),NW-13(GRAY), N3-99/N3-99T(SILVER), N1-251/NW-13(GRAY)
1 663 000 1998 SCREW (4X20) 18 50 663 000 2452 OUTLET FILTER INNER 1
2 663 005 0002 GRIP RIGHT (NN-B) 1 51 663 006 7765 CASE FRONT (NN-B) 1
3 663 005 0019 GRIP INSCRIPTION (NN-B) 1 52 663 000 2674 CAUTION LABEL 1
4 663 005 0026 GRIP LEFT (NN-B) 1 53 663 000 2476 CREVICETOOL (NN-B) 1
5 663 006 7666 CORD HOOK (NN-B) 1 54 663 000 2483 UPHOLSTERY BRUSH BASE 1
6 663 005 0057 GRIP PIPE 1 55 663 000 5279 DUSTING BRUSH (NN-B) 1
7 663 006 7673 SCREW (4X12) 2 56 663 000 2490 CONNECTION PIPE A (NN-B) 1
8 663 006 7680 GRIP UPPER (NN-B) 1 57 663 000 2506 CONNECTION PIPE B (NN-B) 1
9 663 000 2247 DUST BOX PACKING B (NN-B) 1 58 663 006 7772 LENS (NN-B) 1
10 663 006 7697 CASE COVER (NN-B) 1 59 663 006 7789 CASE UPPER (NN-B) 1
11 663 005 0088 GRIP PIPE FITTING (NN-B) 1 60 663 000 2537 BUMPER (NN-B) 1
12 663 000 0076 SCREW (4X16) 2 61 663 000 2544 AIR INLET (NN-B) 1
13 663 000 5620 SUCTION HOSE RETAINER 1 62 663 000 2551 LEAF SPRING 1
14 663 000 2063 HANDLE SCREW (M6) 1 63 663 000 2568 SCREW 1
15 663 006 7703 DUST BOX COVER (NN-B) 1 64 663 000 5743
ROTARY BRUSH COMP.(STEEL) KEYNO,65-80 1
16 663 000 5644 OUTLET FILTER OUTTER 1 65 663 007 2769 BEARING HOLDER CAP (NN-B) 2
17 663 000 2094 DUST BOX PACKING A (NN-B) 1 66 663 007 2776 NUT (LEFT) 1
18 663 006 4511 CLOTH FILTER ASSEMBLY 1 67 663 007 2783 WASHER (SPRING-LEFT) 1
19 663 000 2117 CRAMP LEVER (NW-13) 1 68 663 007 2790 BEARING HOLDER ASSEMBLY 2
20 663 000 2124 HELICAL SPRING A 1 69 663 007 2806 ROTARY HOLDER 1
21 663 000 2131 RING E6 2 70 663 007 2813 BRUSH BASE ASSEMBLY LEFT 2
22 663 000 2148 WHEEL REAR (NN-B) 2 71 663 007 2820 BRUSH BASE ASSEMBLY RIGHT 2
23 663 000 2155 WASHER Z (7.2X12X0.5) 2 72 663 007 2837 BRUSH HOLDER (NN-B) 1
24 663 000 2162 SHAFT 1 73 663 007 2844 SCREW (3X14) 1
25 663 000 2179 AIR INLET FILTER 1 74 663 007 2851 PULLEY 1
26 663 000 2186 SLEEVE (NN-B) 2 75 663 007 2868 WASHER (SPRING-RIGHT) 1
27 663 000 0700 WIRE CONNECTOR (CE-230) 3 76 663 000 2285 NUT (RIGHT) 1
28 663 006 7710 CASE REAR (NN-B) 1 77 663 000 1356 WASHER 5
29 663 000 2216 FUSE ASSEMBLY (125V 12A) 1 78 663 007 2875 ROTARY BRUSH BASE SHAFT 1
30 663 000 2223 CORD ASSEMBLY (BLACK) L=120 1 79 663 007 2882 ROTARY PIPE ASSEMBLY 1
31 663 000 2230 SWITCH 1 80 663 007 2899 PIN 1
32 663 000 2261 DUST BOX PACKING C (NN-B) 2 81 663 000 2582 BELT (NN-B) 1
33 663 000 2278 SCREW (4X17) 1 82 663 000 2605 AIR SPREADER B 2
34 663 000 2285 NUT (RIGHT) 1 83 663 000 2612 LEAF SPRING D 1
35 663 000 2292 SCREW (4X14) 2 84 663 005 1993 BOTTOM PLATE 1
36 663 000 2308 SHIELD PLATE B 1 85 663 000 2636 WHEEL FRONT (NN-B) 2
37 663 006 7727 POWER CORD (U2) 1 86 663 000 2643 SHAFT FRONT 2
38 663 000 2322 HOSE JOINT PIPE A (NN-B) 1 87 663 000 2650 LEVER (NN-B) 1
39 663 006 7734 SUCTION HOSE COMP. 1 88 663 005 0149 BOTTOM PLATE B 1
40 663 000 2346 ATTACHMENT SUPPORTER B 1 89 663 000 0847 SCREW (4X16) 2
41 663 000 2353 ATTACHMENT SUPPORTER D 1 663 006 7796 INSTRUCTION MANUAL 1
42 663 000 2360 ATTACHMENT SUPPORTER A 1
43 663 006 7741 NAME PLATE 1
44 663 006 7758 UL CSA SPT-2 CORD 1
45 663 000 2391 MOTOR CUSHION REAR 1
46 663 000 5699 MOTOR COMP. (AC 120V) 1
663 000 0298 CARBON BRUSH ASSEMBLY 2
47 663 000 2421 MOTOR CUSHION FRONT 1
48 663 000 2445 CAUTION LABEL 1
49 663 006 8045 LABEL (SC-CU1) 1
