Sapir SP-1001-AM User manual

_English_
VACUUM CLEANER
SP-1001-AM
INSTRUCTION MANUAL
BRIEF INTRODUCTION
The vacuum cleaner features exquisite appearance, graceful in color, reasonable in
internal structure. This is multi-cyclone with plastic filter vacuum cleaner with foot
operated switch and automatic wire rolling button on it, and also have many suction
attachments. Its suction power is controlled by electronics and it features low noise
and high efficiency. It makes your life comfortable.

_English_
IMPORTANT SAFEGUARDS
1. Do not clean the machine with a cloth full of water. Do not let the water flow into
the vacuum cleaner.
2. Use only as described in the instruction manual. Use only manufacturers
recommended attachments.
3. This appliance is intended for normal household use.
4. This appliance is not intended for to be used by young children or infirm persons
without supervision. Young children should be supervised to ensure that they do
not play with the appliance.
5. If the supply cord of vacuum cleaner is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in order to avoid a
hazard.
6. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
7. Children should be supervised to ensure that they do not play with the appliance.
8. After using, do not pull the power cable while unplugging the appliance from the
power outlet.
9. Do not run the appliance over the power cable when operating.
10. Do not vacuum burning cigarettes or other burning materials.
11. Do not vacuum water or other liquid.
12. Do not vacuum sharp things or too heavy things.
13. Do not place the vacuum cleaner near heat sources.

_English_
MAIN PARTS IDENTIFICATION
A. Floor brush
B. Tube
C. Airflow control
D. Bend tube
E. Hose
F. Hose connector
G. Handle
H. ON/OFF switch
I. Cord button
J. Dust cup clip
K. Multi-cyclonic plastic filter
HOW TO USE
PREPARATION
1. Insert the end of the hose into the air intake socket until it clicks into position.
2. After using, push the button on the hose and pull the end out.

_English_
3. Connect one of the extension tubes to the bend tube. Then connect the second
extension tube to the other tube. At last connect the floor brush to the second
extension tube.
USING THE MACHINE
Pull out the wire to suitable length. Insert the plug into a power socket. Then press the
switch to run the machine. The vacuum cleaner begins to work. Use the airflow
control on the bend tube to adjust the suction power.
ATTENTION: Do not extend the cable beyond the RED mark.
USING THE FLOORACCESSORIES
1. For hard floor use the floor brush with extended bristles.
2. For carpets use the floor brush with retracted bristles.
Hose Handle
Handle
Tube
Tube
Tube
Tube
Floor brush
RED
YELLOW

_English_
AFTER USING
Press the ON/OFF switch to stop the vacuum cleaner, and press the cord-rewinder
button to roll back the power cord.
ATTENTION: If the power cord cannot be rewound completely, please pull it out a
little bit and press the cord-rewinder button again. You can repeat the rewinding steps
until the cable is rewound completely.
REPLACING THE DUST-CUP
1. When the dust reach to the 1/4 level in the dust-cup, it means that the dust-cup is
full. At this moment, dust-cup should be emptied and the filter should be washed.
2. Open the dust-cup as showing in the picture.
MAINTENANCE
1. The filter should be washed often when it is dirty.
2. When the plastic filter is full of dust, it should be washed.
FULL
