Sapphire Audio FS-FP6 User manual

User’s Manual
AMD FP6 SOC SFF Mainboard
FS-FP6
TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 1.0
ovember 17, 2021

~ ii ~
Federal Communications Commission (FCC) Statement
This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules These limits are designed to
provide reasonable protection against harmful interference in a residential
installation This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with instructions contained
in this manual, may cause harmful interference to radio and television
communications However, there is no guarantee that interference will not occur
in a particular installation
If this product does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the product into an outlet on a circuit different from that to which
the receiver is connected
Consult the dealer or an experienced radio/TV technician for help

Note1: Connecting this device to peripheral devices that do not comply
with Class B requirements, or using an unshielded peripheral data
cable, could also result in harmful interference to radio or television
reception

Note2: The user is cautioned that any changes or modifications not
expressly approved by the party responsible for compliance could
void the user’s authority to operate this product

Note3: To ensure that the use of this product does not contribute to
interference, it is necessary to use shielded I/O cables
CE: Radiation of EN 55022 & Immunity of EN 55024

~ iii ~
aste Electrical and Electronic Equipment ( EEE) Statement
To protect the global environment, this product must be sent to separate collection
facilities for recovery and recycling.
DISPOSAL
Do not dispose of this product as unsorted municipal waste. Collect such
waste separately for special treatment.
Manufacturer
Sapphire Technology Limited
Unit 909- 9 9, 9/F., Tower 2 Grand Central Plaza
38 Shatin Rural Committee Road
Shatin, Hong Kong

~ iv ~
Table of Contents
Chapter 1 Introduction .............................................................................1
1-1 Mainboard Specifications ................................................................1
1-2 Mainboard Layout ...........................................................................4
1-3 Mainboard Dimension .....................................................................6
Chapter 2 Installaion ................................................................................8
2-1 Installing System Memory ...............................................................8
Memory Configuration .....................................................................8
Memory Installation .........................................................................8
2-2 Installing Expansion Cards .............................................................9
M.2 E-Key Slot ................................................................................9
M.2 M-Key Slot ..............................................................................10
2-3 Connecting Cables and Jumper Settings ......................................13
Front Panel Header .......................................................................13
SATA3 Connector ..........................................................................14
SATA Power Header ......................................................................14
COM Header .................................................................................15
GPIO Header ................................................................................15
USB2.0 Header .............................................................................15
Case Open Header .......................................................................15
SMBus Header ..............................................................................16
SPI Header ....................................................................................16
Fan Headers .................................................................................16
RS422/RS232/RS485 Mode Select Jumper ..................................17
Slew Speed Select Jumper ...........................................................17
Auto Power ON Jumper ................................................................17
Clear CMOS Jumper .....................................................................18
2-4 LED Status Indicators ...................................................................19
Chapter 3 Configuring the BIOS ............................................................20
3-1 Select Boot Device .......................................................................20
3-2 Enter BIOS Setup .........................................................................20
3-3 Main Menu ....................................................................................22
3-4 Advanced Menu ............................................................................23

~ v ~
Trusted Computing ........................................................................23
ACPI Settings ................................................................................25
F81803 Super IO Configuration ....................................................26
Hardware Monitor ..........................................................................27
RTC Wake Settings .......................................................................29
CPU Configuration ........................................................................30
SATA Configuration....................................................................... 31
PCI Subsystem Settings ................................................................32
USB Configuration ........................................................................33
Network Stack Configuration .........................................................34
CSM Configuration ........................................................................35
NVMe Configuration ......................................................................37
Onboard Devices ..........................................................................37
AMD CBS ......................................................................................39
AMD PBS ......................................................................................43
3-5 Chipset Menu ................................................................................44
South Bridge .................................................................................44
North Bridge ..................................................................................45
3-6 Security Menu ...............................................................................46
3-7 Boot Menu ....................................................................................48
3-8 Save & Exit Menu .........................................................................49
Chapter 4 Driver Installation ...............................................................50
4-1 Driver Install ..................................................................................50

~ ~
Chapter 1 Introduction
1-1 Mainboard Specifications
APU
AMD
®
V2000 series APU for FP6 package with Zen 2 core
Graphics
AMD
®
Radeon Vega graphics series
Supports four independent displays with DisplayPort
Port Supported resolution
DisplayPort 1.4 3840x2160@60Hz
System Memory
Two 260-pin DDR4 SDRAM SO-DIMM (ECC/Non ECC) sockets
Supports 1 2V DDR4-2133/2400/2666/2933/3200 DIMMs with dual channel
architecture
* The memory speed will be depend on CPU specification
Supports 4GB, 8GB, 16GB and 32GB DDR4 SO-DIMMs up to maximum 64GB
Expansion Slots
 One M 2 Slot E-key with 2230 type with PCIe x1 and USB2 0 for Wifi/BT
One M 2 Slot M-key with 2242/2280 storage type with PCIe x4 for SSD
USB Ports
Four USB 2 0 ports at rear panel and one 4-pin onboard headers supporting
transfer speed up to 480Mbps
One USB3 1 Type C port and one USB3 1 Gen 2 port at front panel supporting
transfer speed up to 10Gbps
- USB3 1 Type C port power delivery: Nominal voltage 5V; maximum current
1 5A
Supports wake-up from S3 and S4 modes

~ 2 ~
SATA Ports
One SATA3 port with 6Gb/s data transfer rate
Supports AHCI (Advanced Host Controller Interface)
Onboard LAN
Two Gigabit Ethernet from Realtek
®
RTL8111H Gigabit controller
Onboard TPM
Supports TPM2 0 from Infineon SLB9670
Onboard Audio
Supports 2-channel High-Definition audio from Realtek ALC262 codec
/O
Onboard Fintek F81803U LPC bus I/O controller
Supports Hardware Monitor for fan speed monitoring, CPU and system
temperature
Back Panel /O Ports
2 x RJ45 LAN ports
4 x USB2 0 ports
4 x DisplayPorts
1 x DC-in 12V~19V Jack, dimension: 5 5x2 5mm
Front Panel /O Ports
1 x USB3 1 Type C port
1 x USB3 1 Gen 2 port
1 x Line-Out port
1 x Mic-In port
nternal /O Connectors
1 x 4-pin 12V ATX Power connector
1 x SATA3 header
1 x SATA Power header, 2 50mm pitch
1 x Front Panel header, 2 00mm pitch

~ 3 ~
1 x COM header, 2 00mm pitch
1 x GPIO header, 2 00mm pitch
1 x Case Open header, 2 54mm pitch
1 x SMBus header, 2 54mm pitch
1 x SPI header, 1 27mm pitch
1 x USB2 0 4-pin header, 2 54mm pitch
1 x 4-pin CPU Fan header
1 x 3-pin SYSTEM Fan header
Onboard Jumper
RS232 / RS422 / RS485 mode select jumper, 2 54mm pitch
Slew Speed Select Jumper, 2 54mm pitch
Auto Power ON selection jumper, 2 54mm pitch
Clear CMOS jumper, 2 54mm pitch
B OS
128Mb SPI Flash with AMI based BIOS
Supports ACPI (Advanced Configuration and Power Interface)
Onboard jumper to clear the CMOS data
Dimensions
Size: 147 3mm×139 7mm
Operating systems
Supports Windows 10 (64bit), Ubuntu 20 04 1 (64-bit)
Environmental
Power Requirement: Power adapter of 12V~19V DC OUT, ~75W, 5 5/2 5mm
power jack, input voltage tolerance +/- 10%
Operating Temperature: 0°C~50°C (32°F~122°F)
Storage Temperature: -20°C~80°C (-4°F~176°F)
Relative Humidity: 10%~90%

~ 4 ~
1-2 Mainboard Layout
The following figure shows the location of components on the mainboard
See page 5 for component description
Note:
Picture is for reference only, actual board may be slightly different.
7
8
9
5
4
1
1
0
21
3
2
23
24
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
2
7
2
5
2
8
2
9
22
20
See next page for details.
6
30
2
6

~ 5 ~
Item Component description Item Component description
1 AMD FP6 APU 16 GPIO Header, 2.00mm pitch
2 DDR4 SO-DIMM *2 17 Front Panel Header, 2.00mm pitch
3 M.2 E-Key slot for Wifi/BT card 18 COM Header, 2.00mm pitch
4 M.2 M-key for SSD device 19 USB2.0 Header, 2.54mm pitch
4-pin 2V ATX Power
Connector
(Note)
20 CPU Fan Header, 2.54mm pitch
6 DC-in 2V ~ 9V Jack
(Note)
21 SYSTEM Fan Header, 2.54mm pitch
7 Display Port *4 22 RS232/422/485 Mode Select Jumper
for COM , 2.54mm pitch
8 USB2.0 Port *4 23 Slew Speed Select Jumper, 2.54mm
pitch
9 RJ45 LAN Port *2 24 Case Open Header, 2.54mm pitch
10 Line-Out Port 2 SMBus Header, 2.54mm pitch
11 USB3. Type C Port 26 SPI Header, .27mm pitch
12 USB3. Gen 2 Port 27 Auto Power ON Jumper, 2.54mm
pitch
13 Mic-In Port 28 Clear CMOS Jumper, 2.54mm pitch
14 SATA3 Connector 29 BIOS
1 SATA Power Header, 2.50mm
pitch 30
Battery Header
Note:
There are two ways to source power to the board: DC jack or 4-pin ATX power connector.
Two different physical ports that can only be used one at a time.
e.g. When DC-in 2V ~ 9V jack is being used, the 4-pin power connector (PW ) shouldn’t
be connected to any power source.
Warning:
On
e of the power inputs may be damaged when connecting both DC jack and ATX power at
the same time.

~ 6 ~
1-3 Mainboard Dimension
PCB size: 147 3 x 139 7mm

~ 7 ~
Cooler size: 98 x 71 x 36 5 mm (For V2748 / V2546)
Cooler size: 60 x 60 x 36 9 mm (For V2718 / V2516)

~ 8 ~
Chapter 2 Installation
2-1 Installing System Memory
This mainboard has two 260-pin SO-DIMM (ECC/Non ECC) sockets for DDR4
memory
Supports 4GB, 8GB, 16GB and 32GB DDR4 SO-DIMMs up to maximum 64GB
Supports 1 2v DDR4-2133/2400/2666/2933/3200 DIMMs with dual channel
architecture
* The memory speed will be depend on CPU specification
Make sure that you install memory modules of the same type and density in
different channel DIMM slots for Dual-Channel mode
Memory Configuration
To use 1 DIMM: Install into either DIMM slot 0 or slot 1
To use 2 DIMMs: Install into DIMM slot 0 and DIMM slot 1
Memory Installation
DDR4 and DDR3 memory modules are physically different Please only install
DDR4 DIMMs on this mainboard To make sure you have the correct DIMM,
check that all the notches line up with the DDR4 DIMM slot
To install the DIMM, follow these steps:
1 Pull both clips on either side of the slot outwards Align the DIMM module
with the slot
2 Press modules straight down until the plastic clips close and the module fits
tightly into the DIMM slot Push clips inwards to make sure they are in place
To remove DIMM from a socket, gently spread the socket’s retention arms to
disengage them from the DIMM
Note: To avoid damaging the DIMM, do not touch its contact edge
DIMM1
DIMM0

~ 9 ~
2-2 Installing Expansion Cards
The mainboard provides
One M 2 Slot E-key with 2230 type with PCIe x1 and USB2 0 for Wifi/BT
One M 2 Slot M-key with 2242/2280 storage type with PCIe x4 for SSD
M.2 E-Key Slot
To install the M 2 wifi/bluetooth card (type 2230) only:
1 Remove screw&standoff and align
the notch on the M 2 2230 edge
connector with the tab in the slot
2 Plug the M 2 2230 firmly into the slot at a
20-degree angle, and until it clicks into
place
3 Fasten M 2 2230 onto the nut with
screw&standoff
M :
M.2 E-key for
wifi/bluetooth card
M2:
M.2 M-key for M.2 SSD
device
LED :
When the M.2 SSD device
is functional, this Green
LED is blinking.
LED
2
:
When the M.2 slot is in
Wifi mode, this Green
LED is on.
LED
3
:
When the M.2 slot is in
bluetooth mode, this
Green LED is on.
Note:
Recommended torque for the M.2
hold down screws: ~ .5lbf.
Key E Slot
22
30
Key
E
12 contacts
12 pins
nit: mm
Note:
The mainboard in the picture is not
actual mainboard, just for reference.
Supported module type: 2230
1
2
20
o
3

~ 0 ~
M.2 M-Key Slot
To install the M 2 SSD device (type 2242/2280):
Please note: for different modules type, need to use corresponding standoff or
screw to fasten them
If have a M 2 wifi/bluetooth card (2230), need to install the M 2 2230 first
 Use M 2 2230 + M 2 2242:
1 Remove screw&standoff
2 Use standoff to fasten M 2 2230 first
Align the notch on the M 2 2242 edge
connector with the tab in the slot
Plug the M 2 2242 firmly into the slot at a
20-degree angle, and until it clicks into
place
3 Fasten M 2 2242 onto the standoff with
screw
 Use M 2 2230 + M 2 2280:
1 Remove all screws and standoff
2 Use screw to fasten M 2 2230 first
Align the notch on the M 2 2280 edge
connector with the tab in the slot
Plug the M 2 2280 firmly into the slot at a
20-degree angle, and until it clicks into
place
3 Fasten M 2 2280 onto the nut with screw
4 Please keep the remaining standoff for use
when needed
1
Screw&standoff standoff
screw
+
Split to
3
Screw&standoff standoff
screw
+
Split to
3
2
20
o
1
standoff
screw
screw
20
o
2

~ ~
 Use M 2 2242 only:
1 Remove screw and leave the standoff
on nut
2 Align the notch on the M 2 2242 edge
connector with the tab in the slot
Plug the M 2 2242 firmly into the slot at a
20-degree angle, and until it clicks into place
3 Fasten M 2 2242 onto the standoff with screw
 Use M 2 2280 only:
1 Remove all screws and standoff
2 Align the notch on the M 2 2280 edge
connector with the tab in the slot
Plug the M 2 2280 firmly into the slot at a
20-degree angle, and until it clicks into place
3 Fasten M 2 2280 onto the nut with screw
4 Please keep the remaining screw&standoff for
use when needed
Note:
The mainboard in the picture is not
actual mainboard, just for reference.
Supported module type:
2242 / 2280
Key M Slot
Key M
5 contacts
5 pins
nit: mm
22 22
80
42
1
Screw&standoff
standoff
screw
+
Split to
3
1
2
20
o
standoff
screw
3
20
o
2

~ 2 ~
Removing Device Caution
Remove the M.2 wifi/bluetooth card or M.2 SSD device at a 20-degree angle.
 Please DO NOT pull up the M.2 wifi/bluetooth card or M.2 SSD device to avoid
damage to the M.2 slot.
20
o
20
o

~ 3 ~
2-3 Connecting Cables and umper Settings
This section takes you through all the necessary connections on the mainboard
Front Panel Header
The front panel header (CFP, 2 00mm pitch) on this motherboard is used to
connect the front panel switches and LEDs
PWR_LED
Attach the front panel power LED cable to these two pins of the connector
The Power LED indicates the system’s status
System Status
Power LED indicates
S0
The LED is on
S
The LED is off
S3
The LED will blink
S4
The LED is off
PW_ON
Attach the power button cable from the case to these two pins Pressing the
power button on the front panel turns the system on and off rather than
using the onboard button
HD_LED
Attach the hard disk drive indicator LED cable to these two pins The HDD
indicator LED indicates the activity status of the hard disks
Note: The HDD indicator LED supports SATA HDD only
RESET
Attach the Reset switch cable from the front panel of the case to these two
pins The system restarts when the RESET switch is pressed
Header Pin Signal
HD_LED
HD_PWR
3
HD Active
PWRLED
2
PWR LED
+
4
PWR LED
-
RESET
5
Ground
7
RST BTN
PWRSW
6
PWR BTN
8
Ground
No Connect
9
+5V
Empty
0
Empty
1
P R_LED
+
_
2
9
10
P _ON
HD_LED
RST
+
_

~ 4 ~
4-pin 12V ATX Power Connector
The PW1 power connector is used to provide power to the system Align the
power plug to the connector and press firmly until seated
SATA3 Connector
The S1 is SATA3 connector and works at speeds of up to 6G/s Each cable can be
used to connect one SATA drive to the mainboard
SATA Power Header
The SATA Power header (2 50mm pitch) is used to provide 5V power to SATA3
connector
Pin Definition
GND
2 GND
3 2V
4 2V
Pin Definition
GND
2 TX+
3 TX-
4 GND
5 RX-
6 RX+
7 GND
Pin Definition
+ 2V
2 GND
3 GND
4 +5V
1
7
1
4
2
4
1 3
Note:
There are two ways to source power to the board: DC jack or
4-pin ATX power connector. Two different physical ports that
can only be used one at a time.
e.g. When DC-in 2V ~ 9V jack is being used, the 4-pin power
connector (PW ) shouldn’t be connected to any power source.
DC
-
in Jack
Warning:
One of the power inputs may be damaged when connecting
both DC jack and ATX power at the same time.

~ 5 ~
COM Header
The Serial port header (COM1, 2 00mm pitch) can provide one serial port via an
optional COM port cable
GP O Header
There is a GPIO (General-purpose input/output) header (2 00mm pitch) on the
motherboard It can connect a variety of simple one- or two-wire devices
USB2.0 Header
This mainboard contains one 4-pin onboard header (2 54mm pitch) that can be
used to connect to one (1) external USB 2 0 device
Case Open Header
This header (2 54mm pitch) is used to for a chassis open detect When set, the
warning message will appear during POST when the case is opened
Pin Definition
DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI#
0 Empty
Pin
Definition
Pin
Definition
SIO_GPIO0(+3.3V) 2 SIO_GPIO4(+3.3V_ALW)
3 SIO_GPIO (+3.3V) 4 SIO_GPIO5(+3.3V_ALW)
5 SIO_GPIO2(+3.3V_ALW) 6 SIO_GPIO6(+ .8V_ALW)
7 SIO_GPIO3(+3.3V_ALW) 8 SIO_GPIO7(+3.3V_ALW)
9 VCC (+3.3V_ALW) 0 GND
Pin Definition
VCC
2 USB0-
3 USB0+
4 GND
Pin Definition
Case Open
2 GND
1
2
Note:
The pin definition of
header and standard DB9
male pin out is different.
1
2
9
10
1
Note: +3.3V_ALW means +3.3V Standby Power.
1
4
