Sapphire Audio PE-AM2RS740G2 Installation instructions

Phenom II X4 Deneb HDX810WFK4FGI 810 200 2600 2M 4M C2 95
Phenom II X4 Deneb HDX925WFK4DGI 925 200 2800 2M 6M C2 95
Phenom II X4 Deneb HDX910WFK4DGI 910 200 2600 2M 6M C2 95
Phenom II X4 Deneb HDX805WFK4FGI 805 200 2500 2M 4M C2 95
Phenom II X4 Deneb HD900EOCK4DGI 900e 200 2400 2M 6M C2 65
Phenom II X4 Deneb HD905EOCK4DGI 905e 200 2500 2M 6M C2 65
Phenom II X4 Deneb HDX945WFK4DGI x945 200 3000 2M 6M C2 95
Phenom II X4 Deneb HDX820WFK4FGI x820 200 2800 2M 4M C2 95
Phenom II X4 Deneb HD910EOCK4DGM 910e 200 2600 2M 6M C3 65
Phenom II X4 Deneb HDX925WFK4DGM x925 200 2800 2M 6M C3 95
Phenom II X4 Deneb HDX945WFK4DGM x945 200 3000 2M 6M C3 95
Phenom II X3 Heka HDZ720WFK3DGI 720 200 2800 1.5M 6M C2 95
Phenom II X3 Heka HDX710WFK3DGI 710 200 2600 1.5M 6M C2 95
Phenom II X3 Heka HD700EOCK3DGI 700e 200 2400 1.5M 6M C2 65
Phenom II X3 Heka HD705EOCK3DGI 705e 200 2500 1.5M 6M C2 65
Phenom II X3 Heka HDZ740WFK3DGI z740 200 3000 1.5M 6M C2 95
Phenom II X3 Heka HDZ715WCJ3DGI z715 200 2800 1.5M 6M C2 95
Phenom II X3 Heka HDX720WFK3DGI x720 200 2800 1.5M 6M C2 95
Phenom II X2 Callisto HDX545WFK2DGI x545 200 3000 1M 6M C2 80
Phenom II X2 Callisto HDZ550WFK2DGI z550 200 3100 1M 6M C2 80
Phenom II X2 Callisto HDX545WFK2DGM x545 200 3000 1M 6M C3 80
Phenom II X2 Callisto HDX550WFK2DGM x550 200 3100 1M 6M C3 80
Phenom II X2 Callisto HDZ555WFK2DGM z555 200 3200 1M 6M C3 80
Phenom X4 Agena HD9500WCJ4BGD 9500 200 2200 2M 2M B2 95
Phenom X4 Agena HD9600WCJ4BGD 9600 200 2300 2M 2M B2 95
Phenom X4 Agena HD9100OBJ4BGD 9100e 200 1800 2M 2M B2 65
Phenom X4 Agena HD960ZWCJ4BGD 9600 200 2300 2M 2M B2 95
Phenom X4 Agena HD9650WCJ4BGH 9650 200 2300 2M 2M B3 95
Phenom X4 Agena HD9550WCJ4BGH 9550 200 2200 2M 2M B3 95
Phenom X4 Agena HD9750WCJ4BGH 9750 200 2400 2M 2M B3 95
Phenom X4 Agena HD960BWCJ4BGH 9600B 200 2300 2M 2M B3 95
Phenom X4 Agena HD960BWCJ4BGD 9600B 200 2300 2M 2M B2 95
Phenom X4 Agena HD9150ODJ4BGH 9150e 200 1800 2M 2M B3 65
Phenom X4 Agena HD9350ODJ4BGH 9350e 200 2000 2M 2M B3 65
Phenom X4 Agena HD9450ODJ4BGH 9450 200 2100 2M 2M B3 65
Phenom X4 Agena HD9850WCJ4BGH 9850 200 2500 2M 2M B3 95
Phenom X3 Toliman HD8400WCJ3BGD 8400 200 2100 1.5M 2M B2 95
Phenom X3 Toliman HD8600WCJ3BGD 8600 200 2300 1.5M 2M B2 95
Phenom X3 Toliman HD8450WCJ3BGH 8450 200 2100 1.5M 2M B3 95
Phenom X3 Toliman HD8650WCJ3BGH 8650 200 2300 1.5M 2M B3 95
Phenom X3 Toliman HD8750WCJ3BGH 8750 200 2400 1.5M 2M B3 95
Phenom X3 Toliman HD860BWCJ3BGH 8600B 200 2300 2M 2M B3 95
Phenom X3 Toliman HD860BWCJ3BGD 8600B 200 2300 2M 2M B2 95
Phenom X3 Toliman HD8250ODJ3BGH 8250 200 1900 1.5M 2M B3 65
Phenom X3 Toliman HD8450ODJ3BGH 8450 200 2100 1.5M 2M B3 65
Phenom X3 Toliman HD8550WCJ3BGH 8550 200 2200 1.5M 2M B3 95
Phenom X3 Toliman HD875ZWCJ3BGH 8750 200 2400 1.5M 2M B3 95
Phenom X3 Toliman HD8850WCJ3BGH 8850 200 2500 1.5M N/A B3 95
Wattage
AMD CPU Support List
Testing Environment:
Memory : Kingston DDR2 800/1G * 2 Pcs
VGA Card : on board 256MB, default clock 400MHz
1. Check BIOS CPU ID/Name/Vcore
2. Power On/Off and Reset on different CPU(5 times) Model: PE-AM2RS740G2
updated: 2009/11/23
Processor
Core Name
CPU Code
CPU No
FSB
Frequency
L2 Cache
L3 Cache
Stepping
1

Athlon II X4 Propus AD600EHDK42GI 600e 200 2200 2M N/A C2 45
Athlon II X4 Propus AD605EHDK42GI 605e 200 2300 2M N/A C2 45
Athlon II X4 Propus ADX620WFK42GI x620 200 2600 2M N/A C2 95
Athlon II X4 Propus ADX630WFK42GI x630 200 2800 2M N/A C2 95
Athlon II X4 Propus ADX635WFK42GI x635 200 2900 2M N/A C2 95
Athlon II X3 Rana AD400EHDK32GI 400e 200 2200 1.5M N/A C2 45
Athlon II X3 Rana AD405EHDK32GI 405e 200 2300 1.5M N/A C2 45
Athlon II X3 Rana ADX435WFK32GI x435 200 2900 1.5M N/A C2 95
Athlon II X3 Rana ADX425WFK32GI x425 200 2700 1.5M N/A C2 95
Athlon II X3 Rana ADX440WFK32GI x440 200 3000 1.5M N/A C2 95
Athlon II X2 Regor ADX250OCK23GQ x250 200 3000 2M N/A C2 65
Athlon II X2 Regor ADX245OCK23GQ x245 200 2900 2M N/A C2 65
Athlon II X2 Regor ADX240OCK23GQ x240 200 2800 2M N/A C2 65
Athlon II X2 Regor AD235EHDK23GQ 235e 200 2700 2M N/A C2 45
Athlon II X2 Regor AD240EHDK23GQ 240e 200 2800 2M N/A C2 45
Athlon II X2 Regor ADX215OCK22GQ x215 200 2700 1M N/A C2 65
Athlon II X2 Regor ADX255OCK23GQ x255 200 3100 2M N/A C2 65
Athlon X2 Windsor ADO3600IAA4CU 3600+ 200 2000 512K N/A F2 65
Athlon X2 Windsor ADA3800IAA5CU 3800+ 200 2000 1M N/A F2 89
Athlon X2 Windsor ADD3800IAA5CU 3800+ 200 2000 1M N/A F2 35
Athlon X2 Windsor ADO3800IAA5CU 3800+ 200 2000 1M N/A F2 65
Athlon X2 Windsor ADA4200IAA5CU 4200+ 200 2200 1M N/A F2 89
Athlon X2 Windsor ADO4200IAA5CU 4200+ 200 2200 1M N/A F2 65
Athlon X2 Windsor ADA4600IAA5CU 4600+ 200 2400 1M N/A F2 89
Athlon X2 Windsor ADO4600IAA5CU 4600+ 200 2400 1M N/A F2 65
Athlon X2 Windsor ADA5000IAA5CU 5000+ 200 2600 1M N/A F2 89
Athlon X2 Windsor ADA4000IAA6CS 4000+ 200 2000 2M N/A F2 89
Athlon X2 Windsor ADO4000IAA6CS 4000+ 200 2000 2M N/A F2 65
Athlon X2 Windsor ADA4400IAA6CS 4400+ 200 2200 2M N/A F2 89
Athlon X2 Windsor ADO4400IAA6CS 4400+ 200 2200 2M N/A F2 65
Athlon X2 Windsor ADA4800IAA6CS 4800+ 200 2400 2M N/A F2 89
Athlon X2 Windsor ADO4800IAA6CS 4800+ 200 2400 2M N/A F2 65
Athlon X2 Windsor ADA5200IAA6CS 5200+ 200 2600 2M N/A F2 89
Athlon X2 Windsor ADA5000IAA5CS 5000+ 200 2600 1M N/A F2 89
Athlon X2 Windsor ADO3800IAA5CS 3800+ 200 2000 1M N/A F2 65
Athlon X2 Brisbane ADO3600IAA5DD 3600+ 200 1900 1M N/A G1 65
Athlon X2 Brisbane ADO4000IAA5DD 4000+ 200 2100 1M N/A G1 65
Athlon X2 Brisbane ADO4400IAA5DD 4400+ 200 2300 1M N/A G1 65
Athlon X2 Brisbane ADO4800IAA5DD 4800+ 200 2500 1M N/A G1 65
Athlon X2 Brisbane ADO5000IAA5DD 5000+ 200 2600 1M N/A G1 65
Athlon X2 Windsor ADO4600IAA5CS 4600+ 200 2400 1M N/A F2 65
Athlon X2 Windsor ADA5000IAA5CZ 5000+ 200 2600 1M N/A F3 89
Athlon X2 Windsor ADA5200IAA6CZ 5200+ 200 2600 2M N/A F3 89
Athlon X2 Windsor ADA5400IAA5CZ 5400+ 200 2800 1M N/A F3 89
Athlon X2 Windsor ADA5600IAA6CZ 5600+ 200 2800 2M N/A F3 89
Athlon X2 Windsor ADO3800IAA5CZ 3800+ 200 2000 1M N/A F3 65
Athlon X2 Windsor ADO4600IAA5CZ 4600+ 200 2400 1M N/A F3 65
Athlon X2 Windsor ADO5200IAA6CZ 5200+ 200 2600 2M N/A F3 65
Stepping
Wattage
AMD CPU Support List
Testing Environment:
Memory : Kingston DDR2 800/1G * 2 Pcs
VGA Card : on board 256MB, default clock 400MHz
1. Check BIOS CPU ID/Name/Vcore
2. Power On/Off and Reset on different CPU(5 times) Model: PE-AM2RS740G2
updated: 2009/11/23
Processor
Core Name
CPU Code
CPU No
FSB
Frequency
L2 Cache
L3 Cache
2

Athlon X2 Brisbane ADH2300IAA5DD BE-2300 200 1900 1M N/A G1 45
Athlon X2 Brisbane ADH2350IAA5DD BE-2350 200 2100 1M N/A G1 45
Athlon X2 Brisbane ADO5200IAA5DD 5200+ 200 2700 1M N/A G1 65
Athlon X2 Windsor ADA6000IAA6CZ 6000+ 200 3000 2M N/A F3 89
Athlon X2 Windsor ADO5000IAA5CZ 5000+ 200 2600 1M N/A F3 65
Athlon X2 Brisbane ADO4200IAA5DD 4200+ 200 2200 1M N/A G1 65
Athlon X2 Brisbane ADO4400IAA5DO 4400+ 200 2300 1M N/A G2 65
Athlon X2 Brisbane ADO4800IAA5DO 4800+ 200 2500 1M N/A G2 65
Athlon X2 Brisbane ADO5000IAA5DO 5000+ 200 2600 1M N/A G2 65
Athlon X2 Brisbane ADO5200IAA5DO 5200+ 200 2700 1M N/A G2 65
Athlon X2 Brisbane ADH2300IAA5DO BE-2300 200 1900 1M N/A G2 45
Athlon X2 Brisbane ADH2350IAA5DO BE-2350 200 2100 1M N/A G2 45
Athlon X2 Brisbane ADH2400IAA5DO BE-2400 200 2300 1M N/A G2 45
Athlon X2 Brisbane ADO5000IAA5DS 5000+ 200 2600 1M N/A G2 65
Athlon X2 Brisbane ADO4200IAA5DO 4200+ 200 2200 1M N/A G2 65
Athlon X2 Brisbane ADO5400IAA5DO 5400+ 200 2800 1M N/A G2 65
Athlon X2 Brisbane ADO4600IAA5DO 4600+ 200 2400 1M N/A G2 65
Athlon X2 Brisbane ADA5600IAA5DO 5600+ 200 2900 1M N/A G2 76
Athlon X2 Brisbane ADH4050IAA5DO 4050e 200 2100 1M N/A G2 45
Athlon X2 Brisbane ADH4450IAA5DO 4450e 200 2300 1M N/A G2 45
Athlon X2 Brisbane ADH4850IAA5DO 4850e 200 2500 1M N/A G2 45
Athlon X2 Brisbane ADO5600IAA5DO 5600+ 200 2900 1M N/A G2 65
Athlon X2 Brisbane ADA5800IAA5DO 5800+ 200 3000 1M N/A G2 76
Athlon X2 Brisbane ADO540BIAA5DO 5400B 200 2800 1M N/A G2 65
Athlon X2 Brisbane ADO520BIAA5DO 5200B 200 2700 1M N/A G2 65
Athlon X2 Brisbane ADO500BIAA5DO 5000B 200 2600 1M N/A G2 65
Athlon X2 Brisbane ADH445BIAA5DO 4450B 200 2300 1M N/A G2 65
Athlon X2 Brisbane ADO4400IAA5DU 4400+ 200 2300 1M N/A G2 65
Athlon X2 Brisbane ADO5000IAA5DU 5000+ 200 2600 1M N/A G2 65
Athlon X2 Brisbane ADV6000IAA5DO 6000+ 200 3100 1M N/A G2 89
Athlon X2 Brisbane ADO5400IAA5DS 5400+ 200 2800 1M N/A G2 65
Athlon X2 kuma AD6500WCJ2BGH 6500 200 2300 1M 2M B3 95
Athlon X2 Brisbane ADH5050IAA5DO 5050e 200 2600 1M N/A G2 45
Athlon X2 kuma AD7450WCJ2BGH 7450 200 2400 1M 2M B3 95
Athlon X2 kuma AD7550WCJ2BGH 7550 200 2500 1M 2M B3 95
Athlon X2 kuma AD775ZWCJ2BGH 7750 200 2700 1M 2M B3 95
Athlon X2 kuma AD785ZWCJ2BGH 7850 200 2800 1M 2M B3 95
Athlon X2 kuma AD7750WCJ2BGH 7750 200 2700 1M 2M B3 95
Athlon X2 Brisbane AD5000ODJ22GI 5000 200 2200 1M N/A C2 65
Athlon X2 Brisbane AD5000OGJ22GI 5000 200 2200 1M N/A C2 65
Athlon Orleans ADA3000IAA4CN 3000+ 200 1800 512K N/A F2 62
Athlon Orleans ADA3200IAA4CN 3200+ 200 2000 512K N/A F2 62
Athlon Orleans ADA3500IAA4CN 3500+ 200 2200 512K N/A F2 62
Athlon Orleans ADD3500IAA4CN 3500+ 200 2200 512K N/A F2 35
Athlon Orleans ADA3500IAA4CW 3500+ 200 2200 512K N/A F2 62
Athlon Orleans ADA3800IAA4CN 3800+ 200 2400 512K N/A F2 62
Athlon Orleans ADA3800IAA4CW 3800+ 200 2400 512K N/A F2 62
Athlon Orleans ADA3200IAA4CW 3200+ 200 2000 512K N/A F2 62
L3 Cache
Stepping
Wattage
AMD CPU Support List
Testing Environment:
Memory : Kingston DDR2 800/1G * 2 Pcs
VGA Card : on board 256MB, default clock 400MHz
1. Check BIOS CPU ID/Name/Vcore
2. Power On/Off and Reset on different CPU(5 times) Model: PE-AM2RS740G2
updated: 2009/11/23
Processor
Core Name
CPU Code
CPU No
FSB
Frequency
L2 Cache
3

Athlon Orleans ADA3000IAA4CW 3000+ 200 1800 512K N/A F2 62
Athlon Orleans ADA4000IAA4DH 4000+ 200 2600 512K N/A F3 62
Athlon Orleans ADA3800IAA4DH 3800+ 200 2400 512K N/A F3 62
Athlon Orleans ADA3500IAA4DH 3500+ 200 2200 512K N/A F3 62
Athlon Orleans ADA4000IAA4CW 4000+ 200 2600 512K N/A F2 62
Athlon Lima ADH3200IAA4DE 3200+ 200 2000 512K N/A G1 45
Athlon Lima ADH3500IAA4DE 3500+ 200 2200 512K N/A G1 45
Athlon Lima ADH3800IAA4DE 3800+ 200 2400 512K N/A G1 45
Athlon Orleans ADH1600IAA5DH LE-1600 200 2200 1M N/A F3 45
Athlon Orleans ADH1620IAA5DH LE-1620 200 2400 1M N/A F3 45
Athlon Orleans ADH1640IAA5DH LE-1640 200 2600 1M N/A F3 45
Athlon Sparta ADH1640IAA4DP LE-1640 200 2700 512K N/A G2 45
Athlon Sparta ADH1660IAA4DP LE-1660 200 2800 512K N/A G2 45
Sempron Manila SDA2800IAA2CN 2800+ 200 1600 128K N/A F2 62
Sempron Manila SDA3200IAA2CN 3200+ 200 1800 128K N/A F2 62
Sempron Manila SDD3200IAA2CN 3200+ 200 1800 128K N/A F2 35
Sempron Manila SDA3200IAA2CW 3200+ 200 1800 128K N/A F2 62
Sempron Manila SDA3500IAA2CN 3500+ 200 2000 128K N/A F2 62
Sempron Manila SDA3000IAA3CN 3000+ 200 1600 256K N/A F2 62
Sempron Manila SDD3000IAA3CN 3000+ 200 1600 256K N/A F2 35
Sempron Manila SDA3400IAA3CN 3400+ 200 1800 256K N/A F2 62
Sempron Manila SDD3400IAA3CN 3400+ 200 1800 256K N/A F2 35
Sempron Manila SDA3600IAA3CN 3600+ 200 2000 256K N/A F2 62
Sempron Manila SDA3400IAA3CW 3400+ 200 1800 256K N/A F2 62
Sempron Manila SDA3800IAA3CN 3800+ 200 2200 256K N/A F2 62
Sempron Manila SDA3600IAA3CW 3600+ 200 2000 256K N/A F2 62
Sempron Lima SDH1100IAA3DE LE-1100 200 1900 256K N/A G1 45
Sempron Lima SDH1150IAA3DE LE-1150 200 2000 256K N/A G1 45
Sempron Sparta SDH1300IAA4DP LE-1300 200 2300 512K N/A G2 45
Sempron Sparta SDH1250IAA4DP LE-1250 200 2200 512K N/A G2 45
Sempron Lima SDH1200IAA4DE LE-1200 200 2100 512K N/A G1 45
Sempron Brisbane SDO2100IAA4DD 2100+ 200 1800 512K N/A G1 65
Sempron Brisbane SDO2100IAA4DO 2100+ 200 1800 512K N/A G2 65
Sempron Brisbane SDO2200IAA4DO 2200+ 200 2000 512K N/A G2 65
Sempron Brisbane SDO2300IAA4DO 2300+ 200 2200 512K N/A G2 65
Sempron Sparta SDH1200IAA4DP LE-1200 200 2100 512K N/A G2 45
Sempron Sparta SDH1250IAA4DW LE-1250 200 2200 512K N/A G2 45
Sempron Sargas SDX140HBK13GQ x140 200 2700 1M N/A C2 45
L2 Cache
L3 Cache
Stepping
Wattage
AMD CPU Support List
Testing Environment:
Memory : Kingston DDR2 800/1G * 2 Pcs
VGA Card : on board 256MB, default clock 400MHz
1. Check BIOS CPU ID/Name/Vcore
2. Power On/Off and Reset on different CPU(5 times) Model: PE-AM2RS740G2
updated: 2009/11/23
Processor
Core Name
CPU Code
CPU No
FSB
Frequency
4
