Sapphire Audio IPC-FP6 User manual

User’s Manual
AMD V2000 Mini-ITX Board
IPC-FP6
TRADEMARK
All products and company names are trademarks or registered
trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 1.0
eptember 24, 2021

~ ii ~
Federal Communications Commission (FCC) Statement
This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules These limits are designed to
provide reasonable protection against harmful interference in a residential
installation This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with instructions contained
in this manual, may cause harmful interference to radio and television
communications However, there is no guarantee that interference will not occur
in a particular installation
If this product does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the product into an outlet on a circuit different from that to which
the receiver is connected
Consult the dealer or an experienced radio/TV technician for help

Note1: Connecting this device to peripheral devices that do not comply
with Class B requirements, or using an unshielded peripheral data
cable, could also result in harmful interference to radio or television
reception

Note2: The user is cautioned that any changes or modifications not
expressly approved by the party responsible for compliance could
void the user’s authority to operate this product

Note3: To ensure that the use of this product does not contribute to
interference, it is necessary to use shielded I/O cables
CE: Radiation of EN 55022 & Immunity of EN 55024

~ iii ~
aste Electrical and Electronic Equipment ( EEE) Statement
To protect the global environment, this product must be sent to separate collection
facilities for recovery and recycling.
DISPOSAL
Do not dispose of this product as unsorted municipal waste. Collect such
waste separately for special treatment.
Manufacturer
Sapphire Technology Limited
Unit 909- 9 9, 9/F., Tower 2 Grand Central Plaza
38 Shatin Rural Committee Road
Shatin, Hong Kong

~ iv ~
Table of Contents
Chapter 1 Introduction .............................................................................1
1-1 Mainboard Specifications ................................................................1
1-2 Mainboard Layout ...........................................................................4
I/O Back Panel ................................................................................7
1-3 Mainboard Dimension ...................................................................11
Chapter 2 Installation .............................................................................13
2-1 Installing System Memory .............................................................13
Memory Configuration ...................................................................13
Memory Installation .......................................................................13
2-2 Installing Expansion Cards ...........................................................14
PCIe Slot .......................................................................................15
M.2 E-Key Slot ..............................................................................15
M.2 M-Key Slot ..............................................................................16
2-3 Connecting Cables and Jumper Settings ......................................17
Front Panel Header ............................................................................... 7
SATA Power Header ............................................................................. 9
eDP Connector ..............................................................................19
USB2.0 Header .............................................................................20
COM Header .......................................................................................... 20
Case Open Header .......................................................................20
GPIO Header ................................................................................21
SMBus Header ..............................................................................21
SPI Header ............................................................................................. 2
CFPA Header ................................................................................21
S/PDIF Header ..............................................................................22
Speaker Header ............................................................................22
Fan Headers .................................................................................22
JP1 eDP Select Jumper ................................................................22
JP2 LCD Backlight Power Jumper ................................................23
JP3 LCD VDD Power Jumper .......................................................23
JP4 Auto Power ON Jumper ...........................................................23
Clear CMOS Jumper .....................................................................23

~ v ~
2-4 System LED Status Indicators ......................................................24
Chapter 3 Configuring the BIOS ..............................................................25
3-1 Select Boot Device .......................................................................25
3-2 Enter BIOS Setup .........................................................................25
3-3 Main Menu ....................................................................................27
3-4 Advanced Menu ............................................................................28
Trusted Computing ........................................................................28
ACPI Settings ................................................................................30
Hardware Monitor ..........................................................................31
RTC Wake Settings .......................................................................33
CPU Configuration ........................................................................34
SATA Configuration .......................................................................35
SIO Configuration ..........................................................................36
PCI Subsystem Settings ................................................................36
USB Configuration ........................................................................37
Network Stack Configuration .........................................................38
CSM Configuration ........................................................................39
NVMe Configuration ......................................................................41
Onboard Devices ..........................................................................41
AMD CBS ......................................................................................43
AMD PBS ......................................................................................47
3-5 Chipset Menu ................................................................................48
South Bridge .................................................................................48
North Bridge ..................................................................................49
Memory Information ......................................................................49
3-6 Security Menu ...............................................................................50
3-7 Boot Menu ....................................................................................51
3-8 Save & Exit Menu .........................................................................52
4-1 Driver Install ......................................................................................53

~ ~
Chapter 1 Introduction
1-1 Mainboard Specifications
APU
AMD
®
V2000 series APU for FP6 package with Zen 2 core
Graphics
AMD
®
Radeon series graphics
Supports four independent displays with DisplayPort and one eDP connector
shared with DP1 DisplayPort
Port Supported resolution
DisplayPort 1.4 / eDP 1.3 3840x2160@60Hz
System Memory
Two 260-pin DDR4 SDRAM SO-DIMM (ECC/Non ECC) sockets
Supports 1 2V DDR4-2133/2400/2666/2933/3200 DIMMs with dual channel
architecture
Supports 4GB, 8GB, 16GB and 32GB DDR4 SO-DIMMs up to maximum 64GB
Expansion Slots
One PCI Express 3 0 x8 slot
 One M 2 Slot E-key with 2230 type with PCIe x1 and USB2 0 for Wifi/BT
One M 2 Slot M-key with 2242/2260/2280 storage type with PCIe x4 for SSD
USB Ports
Eight USB 2 0 ports (two at rear panel, six onboard headers), supporting
transfer speed up to 480Mbps (current limitations: 500mA)
Two USB3 1 Gen 2 ports at rear panel supporting transfer speed up to 10Gbps
(current limitations: 900mA)
Supports wake-up from S3 and S4 modes
SATA Ports
Two SATA3 ports with 6Gb/s data transfer rate (current limitations: 2A)

~ 2 ~
Supports AHCI (Advanced Host Controller Interface)
Onboard LAN
One Gigabit Ethernet from Realtek
®
RTL8111H Gigabit controller
One 10 Gigabit Ethernet from Marvell
®
AQC107 Gigabit controller
Onboard TPM
Supports TPM2 0 from Infineon SLB9670
Onboard Audio
Supports 5 1 channel High-Definition audio from Realtek ALC662 codec
/O
Onboard Fintek F81803U/F81216AD LPC bus I/O controller
Supports Hardware Monitor for fan speed monitoring, CPU and system
temperature
Back Panel /O Ports
1 x DC-in 12V~19V Jack, dimension: 5 6x2 6mm
4 x DisplayPorts
2 x COM ports
1 x RJ45 Gigabit LAN port
1 x RJ45 10 Gigabit LAN port
2 x USB2 0 ports
2 x USB3 1 Gen 2 ports
3 x audio jacks
nternal /O Connectors
1 x DC-in 4-pin 12V~19V +/- 5% Power connector
1 x eDP connector
2 x SATA3 connectors
1 x SATA Power header, 2 50mm pitch
3 x USB2 0 headers, 2 54mm pitch (supports 6 USB2 0 ports)
1 x Front Panel header, 2 54mm pitch

~ 3 ~
1 x S/PDIF header, 2 54mm pitch
1 x Front Panel Audio header, 2 54mm pitch
1 x Speaker header, 2 54mm pitch
2 x COM headers, 2 54mm pitch
1 x GPIO header, 2 54mm pitch
1 x SMBus header, 2 54mm pitch
1 x SPI header, 1 27mm pitch
1 x Case Open header, 2 54mm pitch
1 x 4-pin CPU Fan header, 2 54mm pitch
1 x 3-pin SYSTEM Fan header, 2 54mm pitch
1 x LCD Backlight Power jumper, 2 54mm pitch
1 x LCD VDD Power jumper, 2 54mm pitch
1 x Auto Power ON jumper, 2 54mm pitch\
1 x eDP select jumper, 2 54mm pitch
1 x Clear CMOS jumper, 2 54mm pitch
B OS
128Mb SPI Flash with AMI based BIOS
Supports ACPI (Advanced Configuration and Power Interface)
Onboard jumper to clear the CMOS data
Form Factor
Mini ITX form factor of 170mm×170mm
Operating systems
Supports Windows 10 64bit and Ubuntu 20 04 1 64bit
Environmental
Power Requirement: Power adapter of 12V~19V DC OUT, input voltage
tolerance +/- 5%, 150W, 5 5/2 5mm power jack
Operating Temperature: 0°C~50°C (32°F~122°F)
Storage Temperature: -20°C~80°C (-4°F~176°F)
Relative Humidity: 10%~90%

~ 4 ~
1-2 Mainboard Layout
The following figure shows the location of components on the mainboard
See page 6 for component description
Front view of mainboard:
1
1
0
3
2
4
24
25
5
6
8
9
1
2
1
3
1
4
1
5
1
7
1
8
1
8
1
9
21
2
8
7
22
1
1
1
6
2
0
23
2
6
2
7

~ 5 ~
Back view of mainboard:
See next page for details.
Note:
Picture is for reference only, actual board may be slightly different.
2
9
30

~ 6 ~
Item Component description
1
AMD FP6 APU
2
DDR4 SO-DIMM *2
3
PCIe 3 0 x8 Slot
4
M 2 M-key for SSD device
5
4-pin 12V~19V Power Connector
6
SATA3 Connector *2
USB 2 0 Header *3
(Note)
, 2 54mm pitch
8
SATA Power Header, 2 50mm pitch
9
Front Panel Audio Header, 2 54mm pitch
10
S/PDIF Header, 2 54mm pitch
11
Front Panel Header, 2 54mm pitch
12
COM3 Header for RS232 mode, 2 54mm pitch
13
COM4 Header for RS232 mode, 2 54mm pitch
14
Speaker Header, 2 54mm pitch
15
GPIO Header, 2 54mm pitch
16
SPI Header, 1 27mm pitch
1
CPU Fan Header, 2 54mm pitch
18
SYSTEM Fan Header, 2 54mm pitch
19
Case Open Header, 2 54mm pitch
20
SMBus Header, 2 54mm pitch
21
eDP Select Jumper, 2 54mm pitch
22
LCD Backlight Power Jumper, 2 54mm pitch
23
LCD VDD Power Jumper, 2 54mm pitch
24
Auto Power ON Jumper, 2 54mm pitch
25
Clear CMOS Jumper, 2 54mm pitch
26
BIOS
2
Battery
28
Back Panel Connectors (see next page for detail)
29
M 2 E-Key slot for Wifi/BT card
30
eDP Connector
Note: Each USB 2 0 Header can be used to connect 2 USB devices

~ 7 ~
I/O Back Panel
Item Description Item Description
1 DC-IN 12V~19V Jack 5 10G bps RJ45 LAN Port
2 Display Port *4 (Note) 6 USB2 0 Port *2
3 COM Port *2 (RS232/485/422) USB3 1 Gen 2 Port *2
4 1G bps RJ45 LAN Port
8
Audio Port *3
1 DC-IN Jack
The DC-IN Jack supports only 12V~19V Input
6
7
8
3
2
1
4
DP0
DP1 DP3
DP
2
COM1
COM2
Reference DC power adapter:
Output Power:
90W – Without installed PCIe graphic card
150W – With installed PCIe graphic card
Output Voltage: 12V~19V
5

~ 8 ~
2 DisplayPort (DP0/DP1/DP2/DP3)
The DisplayPort provides support for high resolution displays, digital
content protection With a suitable adapter, DisplayPort may be used to
drive displays with a VGA, DVI or HDMI interface
3 COM Port (COM1/COM2)
It is a serial communication physical interface through which information
transfers in or out one bit at a time The data was transferred through serial
ports to devices such as modems, terminals and various peripherals
These COM ports support RS232, RS485 and RS422 modes The RS232,
RS485 and RS422 mode configure in BIOS (Default is RS232)
Pin Definition Pin Definition
GND 2 Hot Plug Detect
3 ML_Lane 0 (p) 4 CONFIG
5 ML_Lane 0 (n) 6 CONFIG2
7 GND 8 GND
9 ML_Lane (p) 0 ML_Lane 3 (p)
ML_Lane (n) 2 ML_Lane 3 (n)
3 GND 4 GND
5 ML_Lane 2 (p) 6 AUX_CH(p)
7 ML_Lane 2 (n) 8 AUX_CH(n)
9 GND 20 DP_PWR
Pin Definition Pin Definition
DCD 6 DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 GND
19
3
1
20
3
2
Note:
DP1 is shared with eDP connector (The default is DP1, to use eDP connector,
please change the JP1 jumper from “1-2” to “2-3” position)

~ 9 ~
4 1G bps RJ45 LAN Port
The mainboard provides two standard RJ-45 jacks for connecting to Local
Area Network (LAN) Two LEDs are built into the RJ-45 LAN connector
These LEDs indicate the status of the LAN
5 10G bps RJ45 LAN Port
The mainboard provides two standard RJ-45 jacks for connecting to Local
Area Network (LAN) Two LEDs are built into the RJ-45 LAN connector
These LEDs indicate the status of the LAN
Pin Definition Pin Definition
TX+ 5 NC
2 TX- 6 RX-
3 RX+ 7 NC
4 NC 8 NC
LED LED Color LED state Indicates
A Green
Off LAN link is not established
On LAN link is established
Blinking LAN activity is occurring
B
N/A Off 10M bps data rate
Green On 100M bps data rate
Yellow On 1000M bps data rate
Pin Definition Pin Definition
TX+ 5 NC
2 TX- 6 RX-
3 RX+ 7 NC
4 NC 8 NC
LED LED Color LED state Indicates
A Green
Off LAN link is not established
On LAN link is established
Blinking LAN activity is occurring
B
N/A Off 10M bps data rate
Green On 100M/1G/2.5G/5G bps data rate
Yellow On 10G bps data rate
8
3
1
8
3
1
A
3
B
A
3
B

~ 0 ~
6 USB2 0 Ports (two)
The mainboard provides an OHCI/EHCI (Open Host Controller Interface/
Enhanced Host Controller Interface) Universal Serial Bus root for attaching
USB devices such as a keyboard, mouse or other USB-compatible devices
Supports data transfer rates up to 480Mb/s
7 USB3 1 Gen2 ports (two)
USB3 1 Gen2 ports are backward compatible with USB 3 0/2 0 devices
Supports data transfer rates up to 10Gpbs
8 Audio ports
This mainboard provides 2 or 6 channel audio It is easy to differentiate
between the audio functions by referring to the color of the jacks
Pin Definition
+5V
2 Data-
3 Data+
4 GND
Pin Definition Pin Definition
+5V 6 SSTX+
2 Data- 7 GND
3 Data+ 8 SSRX-
4 GND 9 SSRX+
5 SSTX-
1
2
3
4
1
3
4
9
6
5
Blue
Lime
Pink
Line
-
In
Line-In / Real Speaker Out
Line
-
Out
Front Speaker Out / Headphone
Mic
-
In
Mic-In / Center/Subwoofer

~ ~
1-3 Mainboard Dimension
PCB Size: 170 x 170mm

~ 2 ~
Cooler size: 98 x 71 x 36 5 mm (For V2748 / V2546)
Cooler size: 60 x 60 x 36 9 mm (For V2718 / V2516)

~ 3 ~
Chapter 2 Installation
2-1 Installing System Memory
This mainboard has two 260-pin SO-DIMM sockets (ECC/Non ECC) for DDR4
memory
Supports 4GB, 8GB, 16GB and 32GB DDR4 SO-DIMMs up to maximum 64GB
Supports 1 2V DDR4-2133/2400/2666/2933/3200 DIMMs with dual channel
architecture
Make sure that you install memory modules of the same type and density in
different channel DIMM slots for Dual-Channel mode
Memory Configuration
To use 1 DIMM: Install into either DIMM slot 0 or slot 1
To use 2 DIMMs: Install into DIMM slot 0 and DIMM slot 1
Memory Installation
DDR4 and DDR3 memory modules are physically different Please only install
DDR4 DIMMs on this mainboard To make sure you have the correct DIMM,
check that all the notches line up with the DDR4 DIMM slot
To install the DIMM, follow these steps:
1 Pull both clips on either side of the slot outwards Align the DIMM module
with the slot
2 Press modules straight down until the plastic clips close and the module fits
tightly into the DIMM slot Push clips inwards to make sure they are in place
To remove DIMM from a socket, gently spread the socket’s retention arms to
disengage them from the DIMM
Note: To avoid damaging the DIMM, do not touch its contact edge
DIMM1
DIMM
0

~ 4 ~
2-2 Installing Expansion Cards
The mainboard provides
One PCI Express 3 0 x8 slot
One M 2 Slot E-key with 2230 type with PCIe x1 and USB2 0 for Wifi/BT
One M 2 Slot M-key with 2242/2260/2280 storage type with PCIe x4 for SSD
In front side of mainboard:
In back side of mainboard:
M
2
:
M.2
E
-
key
for
wifi/bluetooth card
PE
:
PCI
e
3.0 x8 slot
LED :
When the M.2 SSD device
is functional, this
Green
LED
is
blinking
.
M : M.2 M-key for M.2 SSD device
Note:
Recommended torque for the M.2 hold down screws: ~ .5lbf.
LED2: When the M.2 slot is in Wifi mode, this Green LED is on.
LED
:
When the M.2 slot is in
bluetooth mode, this
Green LED is on.

~ 5 ~
PCIe Slot
The design of this motherboard supports PCIe interface expansion card
complying with the PCI Express specification
To install a PCI Express card:
1 Place the card in an available PCI Express slot and press down on the card
until it is completely seated in the slot If the card is not seated properly, it
could cause a short across the pins
2 Secure the card’s metal bracket to the chassis back panel with a screw
M.2 E-Key Slot
To install the M 2 wifi/bluetooth card:
1 Remove screws and align the notch on the
M 2 wifi/bluetooth card edge connector with
the tab in the slot
2 Plug the M 2 wifi/bluetooth card firmly into
the slot at a 20-degree angle, and until it
clicks into place
3 Fasten M 2 wifi/bluetooth card onto the nut
with accompanied screws
Key E Slot
22
30
Key
E
12 onta ts
12 pins
Unit: mm
1
3
Supported module type: 2230
2
20
o
