SAS BIO SOLID 19 User manual

2
TABLE OF CONTENTS
page
Declaration of Conformity CE 3
Fact Sheet 4
Test certificate for the SAS BIO SOLID water boiler 5-6
EcoDesign certificate for the SAS BIO SOLID 14kW boiler 7
EURO TOPTEN award 8
1. Preface 9
2. Purpose, boiler operational conditions 9
3. Boiler design and operation 10
4. SAS BIO SOLID boiler equipment 17
5. Technical and operational parameters 18
6. Fuel 23
7. Boiler installation guidelines 24
7.1 Boiler room requirements 25
7.2 Noise and noise reduction methods 26
7.3 Boiler placement 26
7.4. Boiler stack connection 27
7.5. Boiler connection to a heating system 28
7.5.1. Open vented system 29
7.5.2. Sealed system 31
7.6. Boiler connection to a power supply system 37
8. Guidelines for use and operation 38
8.1. Filling with water 38
8.2. Boiler firing and operation 39
8.3. Boiler cleaning 41
8.4. End of burning 43
9. Conditions for safe operation 44
10. Operation and maintenance of the feeder and burner 45
11. Statuses of incorrect boiler work 46
12. Protective devices 48
13. Delivery terms and conditions 51
14. Boiler disposal 52
15. Warranty terms and conditions 55
Warranty card 55
LIST OF FIGURES AND TABLES
Table
. 1 SAS BIO SOLID boiler equipment
18
Table
. 2 Technical and operational parameters for the SAS BIO SOLID 14-f 48 kW boiler
19
Table
. 3 Basic parameters of pellets intended for SAS BIO SOLID boilers
23
Figure
. 1 Moving grate positioning sensor (hall effect sensor)
12
Figure
. 2 Connection terminal strip supplying control equipment
13
Figure
. 3 Module controlling burner operation
14
Figure
. 4 The flue gas temperature sensor mounted in flue pipe
15
Figure
. 5 Location of the temperature sensor with a capillary tube
– thermal protection sensor
17
Figure
. 6 Diagram of SAS BIO SOLID boiler design with heat output of 14 -f 48 kW
20
Figure
. 7 Diagram of SAS MULTI FLAME burner design - side view, sectional view
21
Figure
. 8 Diagram of SAS MULTI FLAME burner design - upper view
22
Figure
. 9 Installation of adjustment feet in SAS BIO SOLID boiler
27
Figure
. 10 General connection diagram - an open vented system with a four-way valve
32
Figure
. 11 General connection diagram - an open vented system with a plate exchanger
33
Figure
. 12 General connection diagram - sealed system
34
Figure
. 13 Flue gas turbulator
42
Figure
. 14 The location of the STB safety temperature limiter and temperature sensor
49

Zakład Metalowo-Kotlarski „SAS”
Owczary, ul. Przemysłowa 3
28-100 Busko-Zdrój
tel. [phone] fax [phone]
www.sas.busko.pl e-mail: [email protected]
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SAS BIO SOLID / DZ/01/2015 Busko-Zdrój, 9 February 2015
EC DECLARATION OF
CONFORMITY
Zakład Metalowo-Kotlarski SAS
Mieczysław Sas
28-100 Busko-Zdrój, Owczary, ul. Przemysłowa 3
declares with full responsibility that the product:
Automatic central heating boiler type SAS BIO SOLID
with the heat output 14 to 48 kW
equipped with SAS MULTI FLAME burner
complies with the provisions of:
Directive 2006/42/EC
The Ordinance Of The Minister Of
The Economy
(Official Journal No 199/2008, item 1228)
(MD) Machinery Directive
Directive 2004/108/EC
(Official Journal No. 82/2007, item 556)
(EMC) Electromagnetic
Compatibility Directive
and harmonized standards:
PN-EN ISO 12100: 2012
PN-EN 303-5:2012
PN-EN 61000-6-2:2008P
PN-EN 61000-6-3:2008P
This is confirmed by the sign placed on the device
This Declaration of Conformity is invalidated if any design changes are made to the product without
the consent of the manufacturer.
If the product is resold to another owner, this Declaration of Conformity must be enclosed with the
product.
The manufacturer's official stamp Owner: Mieczysław SAS

4
Fact Sheet in accordance with the European Commission (EU) Regulation No. 2015/1187 of April 27, 2015
Model ID
BIO
SOLID 14
BIO
SOLID 19
BIO
SOLID 25
BIO
SOLID 36
BIO
SOLID 48
Energy efficiency class
A
+
A
+
A
+
A
+
A
+
Rated boiler output
15 kW 19 kW 26 kW 36 kW 49 kW
Energy Efficiency Index (EEI)
116 116 118 118 119
Room seasonal heating
energy efficiency ( h
s
)
79% 79% 80% 80% 81%
Special precautions:
1.
The boiler should be installed and operated solely by adults only in conditions meeting those
specified in the operation and maintenance manual delivered with the equipment!
2.
Any changes in the design aiming at adapting the boiler to perform functions not intended by
its manufacturer are strictly forbidden and shall void the warranty!
3. Only recommended fuel must be used!
4. The boiler is not designed to heat water above the maximum working temperature declared,
i.e. > 85°C.
5.
Flue gases emitted from an obstructed stack are hazardous. The stack and the connector
should be kept clean; they should be cleaned according to the instruction provided by the
manufacturer. The boiler flue gas ducts should be kept clean.
6.
All activities related to the boiler installation and operation should be performed with
caution. Personal protective equipment should be used, and health and safety regulations
should be observed. Some boiler surfaces are hot and protective gloves must be worn before
touching them! Safety goggles should also be used!
7.
Before maintenance, the boiler must be disconnected from the mains supply, and the
manufacturer's instructions must be observed.
All connections to the power supply system can only be made by a person holding relevant
qualifications — SEP (Polish Electricians Association) licence up to 1 kV. Any attempt to
perform unauthorised repairs/changes in the control system may lead to electrocution and
shall void the warranty.

5

6

7

8

9
Dear Buyer and User of the low-temperature SAS BIO SOLID boiler. This ope-
rating and maintenance manual contains all necessary information for energy-effi-
cient, safe and long operation of your boiler. The device is delivered together with
a set of operating and maintenance manuals for operation of the boiler, burner and
controller.
Before installation and operation of this device you must read and understand
contents of this operating and maintenance manual. After acquainting with this ma-
nual you will be able to use this device in an optimum way. By becoming thoroughly
acquainted with this manual you will be able to operate the boiler in an effective and
safe way.
Boilers manufactured by the Zakład Metalowo-Kotlarski “SAS” meet the requ-
irements of relevant EU directives and are CE-marked, and this is confirmed in the
enclosed EC DECLARATION OF CONFORMITY.
THIS DOCUMENTATION SHOULD BE KEPT FOR FUTURE USE, IT IS ALSO
A WARRANTY CARD FOR THE BOILER.
SAS BIO SOLID boilers with a fuel tank and SAS MULTI FLAME burner are
designed for installation in water central heating systems, open/close system*
with gravitational or forced water flow, secured according to current local or EU
regulations (PN-EN 12828+A1:2014-05 Heating installations in buildings. De-
sign of water-based heating systems). They are recommended, in particular, for
heating of residential flats in one- and multi-family houses, and for commercial,
services, catering and workshop facilities, etc., in which maximum acceptable
working temperature of supplied water does not exceed 85°C, and a maximum
working pressure in the system does not exceed 1.5 bar. Required minimum
flue gas pass downstream the boiler od 0,20-0,30 mbar, depending on the no-
minal thermal power (according to PN-EN 13384-1:20152008 Chimneys. Me-
thods for thermal and flow-through calculations. Part 1: Chimneys serving one
heating appliance).
1. PREFACE
2. PURPOSE, BOILER OPERATIONAL CONDITIONS
* The installed system must meet specific requirements of standards in force in a country of destination con-
cerning safety devices for water-based heating equipment in open vented systems,and expansion vessels in
an open vented or sealed systems together with accessories: diaphragm expansion vessel, pressure relief
valve, equipment for control and measurements, or devices for removing excess heat.

10
These boilers may also work with domestic hot water systems through a heat
exchanger (domestic hot water) of any producer that meets current standards.
The boiler cannot be used as a continuous flow water heater. The SAS BIO SOLID
boiler is also not intended to be used as an air heater.
A boiler for heating a building should be selected on a basis of an energy heat
balance of that building, developed in accordance with specific current national
or EU regulations (PN-EN 12831:2006 Heating systems and water based cooling
systems in buildings - Method for calculation of the design heat load).
NOTE 1: The boiler should be installed and operated only in conditions me-
eting those specified in the operation and maintenance manual (ma-
nufacturer documentation delivered together with the device)!
NOTE 2: Any changes in the design aiming at adapting the boiler to perform func-
tions not intended by its manufacturer are strictly forbidden and result in
a loss of warranty rights and documents associated with the product!
SAS BIO SOLID bolier is a low-temperature CH boiler with automatic fuel sup-
ply to the furnace. SAS BIO SOLID with power of 14÷48 kW is designed and
programmed for combustion of the solid fuel in automatic mode. The fuel is bio-
mass in the form of wood granules wood (pellets) with parameters defined by EN
14961-2 or PN-EN ISO 17225-2:2014-07p
Basic boiler components are specified in a figure 6.
The SAS MULTI FLAME burner elements are shown in fig. 7 and 8.
NOTICE: The SAS MULTI FLAME burner is affected by Protective Law no
67681 – provided by the Polish Patent Office for the utility model, entitled
“Water boiler burner suitable for combustion of biomass”.
The boiler consists of a water body made of welded steel plates. The boiler
water shell forms a double-walled cuboid divided with water chambers. Internal
partitions of the heat exchanger is made of boiler-grade steel P265GH with a
thickness of 6 mm, external water shell is made of design steel with grade S235JR
with a thickness of 4 mm. The boiler exchanger contains a permanently fixed
system of stud bolts bracing its covers (strengthening components in form of
“seams”). Covers are tested for their strength and tightness under a test pressure
of 3 bar during the production of each boiler. Water compartments of the boiler
and its parts are designed in such way that during its normal operation according
to this operating manual and following correct installation all air will be removed
and no local boiling of water will occur.
3. BOILER DESIGN AND OPERATION

11
OPERATION PRINCIPLE FOR AUTOMATIC FUEL DELIVERY SYSTEM:
The boiler operates using a set consisting of:
• a fuel feeder with dual auger and transfer duct,
• blow furnace equipped with the moving grate,
• fan supplying air to the furnace;
• and an electronic temperature regulator – controller.
The fuel is transported from the fuel reservoir into the furnace chamber using
the feed fuel mechanism fuel with two distribution pipes (two transport augers dri-
ven by an electric motor) separated with a transfer duct providing distance betwe-
en. This solution provides secure transport of biomass, eliminating the need for
additional protection against uncontrolled retraction of fire into the fuel reservoir.
For safety reasons the gate closing the fuel reservoir during the combustion of
biomass in the burner must be sealed. The feeding mechanism consists of gear
motor that drivers the fuel feeding system by means of sprockets and a chain. The
feeder drive is under the safety cover. The fuel feeding mechanism – transport au-
gers are located in the closed isolating-and-guiding pipe. The biomass furnace is
installed in the combustion chamber. It is possible to remove the feed mechanism
to periodic cleaning (Fig. 8) – mounting screws, sealing cord.
Biomass is supplied to the furnace chamber, where the automatic combustion
process is performed using the heater (electrical burner). The device is cooled by
a stream of air coming from the air duct. After reaching the preset temperature,
the automatic fuel ignition and fire support system enables the boiler the possibi-
lity of efficient operation even with low power thermal demand (possibility of con-
tinuous operation with domestic hot water reservoir during the summer period).
A characteristic feature of the SAS MULTI FLAME burner is an automatic, highly-
-effective and self-cleaning furnace burning exactly the portion of fuel necessary
to obtain the value set by the user on the temperature controller.
The burner is provided with a self cleaning furnace fitted with moving grates,
whose cyclic movement enables dropping the biomass ash and slag, ensuring
furnace purity over a long period of time.
The furnace elements (housing, moving grate, furnace grate, mounting plate)
exposed to high temperatures are made of stainless steel heat-proof sheet. Over
the furnace chamber there is a ceramic shape, which further protects the furnace
housing and causes reburning of unburned parts of flammable fuel. The burner
mounting plate is lined with a thermal insulation protecting fuel feeding mecha-
nism from heat.
Air for combustion is supplied by the fan driven by the electric motor and
connected to the furnace using an air-blowing duct. Part of the air is led under the
furnace grate, and the rest is blown directly into the combustion zone through the
distribution holes located on the sides of the furnace. The proper – depending on
the type of fuel burned – air flow is delivered by the blowing fan controlled by the
boiler controller.

12
The furnace grate was divided into a fixed part and the moving section. Cyc-
lically actuated moving grates driven by a eccentric mechanism enables evacu-
ation of fuel combustion residues from the furnace into the boiler chamber, i.e. the
ash in the form of slag. This solution is used to maintain the continuation furnace
in “clean” condition without interrupting the continuity of the combustion process.
After the furnace cleaning cycle, the moving grates take position in the slots of the
lower part of the furnace. The grate is positioned with a position control sensor
(hall effect sensor, see Fig.1 and Fig. 6). A small part of non-combustible fuel –
ash – remaining after combustion of biomass in the final stage of combustion is
transferred to the ash-box in which a drawer is situated. It must be cleaned perio-
dically (the ash resulting from the combustion process can be used as a fertilizer).
The frequency of drawer emptying depends on the quality of the pellet.
NOTICE:
Correct operation of the moving grate mechanism requires a correct setting
of the Hall effect sensor. A distance between the position sensor and the moving
grate drive string should be 3 to 5 mm, these components should be aligned
axially.
The controller (temperature regulator) located in the upper boiler cover uses
the readings from the temperature sensors to control all regulating devices, en-
suring the efficient and economic use of available power in order to maintain the
operating conditions of the installation. An efficiently working boiler furnace burns
the amount of fuel necessary to maintain the temperature set on the regulator by
the user. Thus, the controller continuously measures a temperature of water in
the boiler, and on this basis appropriately controls operation of the boiler and the
fan. At the same time the controller controls operation of pumps: central heating,
domestic hot water, floor and circulating (if the heating system is equipped with
pumps). The boiler can also be used outside the heating season in a system with
an exchanger, for domestic hot water. In a system equipped with a mixing valve
Figure 1 Moving grate positioning sensor (hall effect sensor).

13
with a cylinder, the mixer can be controlled directly from the boiler controlled.
Connection points for circulatory pumps, temperature sensors and the mixer are
located on the boiler side wall (see Fig. 2 and Fig. 6).
The control unit (see Fig. 3, Fig. 6) of the burner automatically controls the
heater and the mechanism of furnace cleaning with the positioning sensor (hall
effect sensor). The temperature regulator mounted on the boiler controls the blo-
wing fan, fuel feeding mechanism and the feeder temperature sensor. The co-
operation between the controller (Fig. 6 item 39) of the feeder SAS MULTI FLAME
type, the master boiler controller (Fig. 6 item 28) is possible thanks to the wired
RS communication system. The control unit has the power cord, main switch and
a fuse. If there is no power supply to the control unit, the regulator displays “No
communication with M1” message and emits the audible alarm. An efficiently
working boiler furnace burns the amount of fuel necessary to maintain the tempe-
rature set on the controller by the user.
Figure 2 Connection terminal strip supplying control equipment
(An example of the power strip depending on the model of the controller mounted on the boiler)

14
An advantage of a boiler is its simple operation in form of periodic replenish-
ment of fuel in the tank and removing ash from the ash drawer without a need to
put the furnace off. After firing, the boiler does not require a continuous operation,
and it can be used, generally, in a continuous mode during the heating season
(excluding breaks for periodical cleaning and repairs). Systematically performed
maintenance and cleaning ensures long and trouble-free operation of the boiler.
A boiler room with a solid fuel boiler is not maintenance-free and requ-
ires periodic monitoring. During boiler operation certain daily control activi-
ties must be performed, to prevent emergency situations.
BOILER DESIGN:
With the boiler structure based on three-pass layout of a flue gas duct in the
exchanger with ceramic panels, flue gas heat is fully recovered and used in a
water-based central heating system. Also the upper part of the furnace chamber
is closed with a water jacket.
Flue gases are directed to a stack through a flue located in the back part of
the boiler. A flue gas damper is installed in the flue, which can reduce the flue gas
flow when it becomes too strong (regulation). A clean out openings are located
on the side of the flue pipe. The flue pipe is fitted with the exhaust gas temperatu-
Figure 3 Module controlling burner operation.
(An example of the power strip depending on the model of the controller mounted on the boiler)

15
re sensor (solid state, PT1000), which regulates the combustion process and re-
duces the stack loss (blowing air adjustment). The adapter cube allows for quick
and simple exchange, when necessary (see Fig. 4).
NOTICE:
For correct operation of the regulator controlling the combustion process –
operation of the automatic fuel feeder – we encourage you to periodically clean
the sensor surface from dust/soot.
Clean out door, furnace door and ash-box door are located on the front wall of
the boiler. The furnace door enables the access to periodic cleaning of the boiler
and burner.
Front clean out door and top clean out (located under the cover) enables easy
access to cleaning of heat exchanger cartridges and gas turbulator. Side clean
out and ash-box door are used to remove dust settling in the flue gas duct.
Due to an overpressure in the whole inner space of the boiler, it is provided
with fire doors and inspection hatches with circumferential sealing (ceramic rope,
gaskets) and screwed connection, ensuring for its tight closing. Furthermore, it
is also provided with adjustment systems for hinges, and for closing systems for
doors and a fuel tank cover.
Non-flammable insulating materials were installed to reduce heat losses and
secure against excessive increase in a temperature of external boiler surfaces.
The heat exchanger surface is insulated from the environment with external
cladding of powder-coated steel sheets, under which a thermal insulation layer
of asbestos-free non-flammable mineral wool is installed. The insulating mate-
rial tightly fills space between the exchanger and the boiler casing (external,
powder painted insulating sheet). The boiler door and the top clean out have
a multi-layer construction made of stainless steel and insulating material which
restricts heat loss (temperature of the external surface of the boiler on a safe
level). And additional insulating partition made of stainless steel and insulating
material in the furnace door was implemented, as well as a stainless steel par-
tition in the clean out door. The boiler has an additional layer on front door in
the form of an opening external cover, protecting from an accidental contact
with surfaces susceptible to excessive heat. Door, clean out hatch, and flue gas
damper handles are made of non-flammable components significantly reducing
Figure 4 The flue gas temperature sensor mounted in the flue pipe

16
heat transfer, In addition, for safety reasons a pictogram and a message on the
nameplate was used that informs the user about uninsulated hot elements –
(flue pipe).
The moving parts (gear motor, sprocket mechanism and chain driving the
fuel feeder, moving grate drive, blowing fan) located underneath the hopper was
secured against direct access with detachable shields. Furthermore, for safety
reasons, a pictogram informing a user about presence of the mobile components
was used.
The fuel tank is provided with a loading opening with sealing and a closing
system. The design of the tank equipped with the hopper ensures free transport
of fuel (gravitational discharge). In addition it is fitted with a limit switch that stops
the blowing fan operation and fuel feeder after opening the cover! (See fig. 6) A
message appears on the display: „Cover Open” and an audible alarm is heard
(reminder and signal appear cyclically for a few seconds). When the fuel reservoir
cover is closed, the operation is resumed. Inside the cover there is an information
for the user about the presence and operation of the limit switch (reservoir cover
opening sensor).
NOTE:
Due to the installation of the limit switch, the fuel reservoir cover must al-
ways be sealed (during normal operation of the boiler)!
Directly above the furnace and on the side wall of the boiler opposite the SAS
MULTI FLAME burner the heat exchanger chamber has horizontal/vertical parti-
tions made of refractory ceramic material increasing the combustion temperature
and reducing the emission of harmful gases into the atmosphere. The number
and layout of horizontal ceramic partitions over the furnace is dependent on the
power of the boiler.
Additionally, the exchanger is equipped with a gas turbulator which forces hot
flue gas whirl and enhanced transmission of heat to the heat exchanger. The flue
gas impacts the turbulator walls, causing the dust fall to the bottom of the boiler.
The dust can be removed by side clean outs of the heat exchanger chamber.
HOT
SURFACE NOTE!
MOVING PARTS

17
A supply water connector is welded to the upper part of the heat exchan-
ger, while a return water connector is welded at the bottom, on the back wall. A
discharge connector (G ¾”) is located on a side wall in the bottom part of the
boiler. It is also used for connection of cooling water (from a water system) when
overheat thermal protection – a thermostat valve (a device removing excess heat,
according to Fig. 11 and Fig. 12) is installed. On the side wall of the top of the
boiler there is a connector (G ½”) for connecting the temperature sensor with a
capillary L=150 mm from thermal protection valve (see fig. 5).
Adjustment feet (does not apply to boilers with power over 25 kW) with the
adjustment range of 30 mm ensure the boiler final alignment versus the floor.
The user is responsible for possible installation of adjustment feet, according to
guidelines provided in this instruction (Fig. 9).
SAS BIO SOLID automatic boiler with control is delivered with a controller,
blowing fan, pellet burner (SAS MULTI FLAME), fuel reservoir, ash-box doors,
furnace doors, clean out doors, partitions with refractory ceramic panels. Addi-
tional isolation partitions made of stainless steel protect the furnace door and
clean out door. The boiler body has a thermal insulation made of mineral wool
that has the form of the shell made of powder painted steel sheets with high
resistance to corrosion. The SAS BIO SOLID boiler is equipped with the pellet
burner and fuel reservoir installed on the left (L) or the right (R) side. The burner
and fuel reservoir location should be clearly stated (in the order), as it is not
possible to move them to the other side afterwards.
The digital equipment (control systems) for the SAS BIO SOLID boiler is spe-
cified in the attached operating manual for the temperature controller.
4. SAS BIO SOLID BOILER EQUIPMENT
Figure 5 Location of a temperature sensor with a capillary tube– thermal protection
sensor

18
Table 1. SAS BIO SOLID boiler equipment
BOILER STANDARD EQUIPMENT
1Boiler operating and maintenance documentation (manual + warranty card)
pieces
1
2Operating manual + warranty card for a temperature regulator (controller)
pieces
1
3 Warranty card for a blower fan
pieces
1
4
Temperature regulator (controller operating two mixing valves, Ethernet module) with a set of cables and
sensors for the system operation (details in the controller operation and maintenance documentation)
pieces
1
5 STB safety temperature limiter
pieces
1
6 Flue gas temperature sensor
pieces
1
7 Analogue thermometer
pieces
1
8
SAS MULTI FLAME pellet burner
- control unit for the burner, power strip
- blower fan
- fuel feeder with a gearmotor
- moving grate with drive motor, biomass furnace
- heater (electric burner)
- shape made of refractory ceramic material
- grate positioning sensor (hallotron), feeder sensor temperature
set
1
9 Moving parts guard (fuel tank casing)
set
1
10
Partition made of stainless steel, thermally insulated, protecting the furnace door
pieces
1
11 Partition made of stainless steel protecting the cleanout door
pieces
1
12 The set of refractory ceramic panels: rear front, sides, horizontal partitions***
pieces
1
13
The set of refractory ceramic panels - boiler side wall opposite the biomass furnace
set
1
14 Flue gas turbulator
pieces
1
15 Fuel tank
pieces
1
16 Feeder flap opening sensor
pieces
1
17 Ash drawer
pieces
1
18 Pressure relief valve (2.5 bar)
pieces
1
19 A set of tools for boiler operation (poker, cleaning rod, scraper, and ash shovel)
set
1
20 Adjustment feet for boiler levelling (excluding boilers above 25 kW)
pieces
4
21 Connector (G
½ )of the overheating protection
pieces
1
***
the number of horizontal ceramic partitions over the furnace is dependent on the power of the boiler
OPTIONAL BOILER EQUIPMENT
1 Room regulator
pieces
1
2 Module controlling an additional mixing valve
*)
pieces
1
3 GSM module
*)
pieces
1
4
Thermostat valve with a capillary tube (G
½ ”) protecting against overheating:
- open vented system with a plate exchanger (e.g. Regulus, type BVTS)
- sealed system (e.g. SYR 5067)
pieces
1
*)
applies to boilers with a TECH controller
5. TECHNICAL AND OPERATIONAL PARAMETERS
Basic power parameters together with technical and operational parameters
for SAS BIO SOLID boilers are listed in Tab. 2, and Fig. 6.

19
Table 2. TECHNICAL AND OPERATIONAL PARAMETERS
SAS BIO SOLID 14-48 kW BOILER
No. Parameter Unit. SAS BIO SOLID
1. Nominal boiler power/type kW 14 19 25 36 48
2. Exchanger heating surface m21.2 1.7 2.2 3.0 4.0
3. Power range kW 4,2 ÷14 5,7 ÷19 7,5 ÷25 10,8 ÷36 14,4 ÷48
4. Energy efficiency class A+ A+ A+ A+ A+ A+
4. Thermal efficiency % 92,1 ÷ 92,4
5. Boiler class (according to PN-EN 303-5:2012)
efficiency/flue gas emissions - class 5 (the highest)
6. Fuel - pellets
7. Fuel grade (EN 14961-2) - biogenic fuel – class „C1”
8. Zużycie paliwa * kg/h 1,6 2,1 2,8 4,1 5,5
9. Fuel reservoir capacity dm3
kg
150
~95÷105
200
~130÷140
210
~140÷150
270
~175÷185
305
~200÷210
10. Boiler water holding capacity l 68 82 102 120 168
11. Boiler weight (without water) kg 550 600 660 730 860
12. Required min. hot gas pass mbar ~ 0,20 ~ 0,25 ~ 0,30
13a. The flow of the exhaust
gases at the
nominal g/s 8,8÷9,0 10,2÷11,7 12,7÷15,0 19,2÷20,1 23,8÷25,6
13b. minimum g/s 2,6÷4,3 3,1÷5,3 3,8÷6,8 5,8÷9,3 7,7÷12,1
14a. Flue gas temperature at the nominal °C 130 ÷ 160
14b. minimum °C 50 ÷ 80
15a. Water flow resistances
through the boiler for rated
power
at T=10K mbar 2,3 ÷ 4,1
15b. at T=20K mbar 0,6 ÷ 1,9
16. Recommended
operational temperature of heating °C 60 ÷ 80
17. Max. acceptable operating temperature °C 85
18. Max. acceptable operating pressure bar 1,5
19. Required return water temperature ** °C 50
20. Power supply V/Hz ~230V/50Hz
21. Power consumption *** W up to 220 (600 on ignition)
22. Noise level (by PN-EN 15036-1:2006) dB < 65 dB(A)
23. Basic boiler
dimensions
Amps mm 1230 1270 1270 1290 1410
A1 mm 290 290 290 305 330
B mm 950 1050 1175 1250 1250
B1 mm 450 450 535 605 605
H **) mm 1560 1520 1520 1560 1730
H1 **) mm 1270 1360 1360 1420 1520
H2 **) mm 930 1000 1000 1050 1120
H3 **) mm 180 180 180 180 180
24. Flue diameter mm Ø160 Ø180 Ø180 Ø200 Ø220
25. Spigot thread (feed/return) „
G 1¼ G 1¼ G 1½ G 1½ G 2
26. Drain spigot diameter „
G ¾ G ¾ G ¾ G ¾ G ¾
27. Pressure relief valve (2.5 bar) „
G ½ G ½ G ½ G ½ G ½
28. Min. stack height m 6 7 8 9
29. Min. flue pipe diameter cmxcm
mm
17x17
Ø200
18x18
Ø210
20x20
Ø220
22x22
Ø250
25x25
Ø280
*when working with medium load (50% of rated power) for the fuel dedicated referred to in chapter 6. In the actual conditions the fuel consumption
may differ from the one given in the table. The fuel consumption is impacted the quality of the fuel, type of heating installation, operating
parameters of the boiler, chimney, degree exchanger contamination, inside and outside temperature of the heated building, building insulation.
** when recommendations concerning maintaining of a specified range of heating water temperatures are not followed, the boiler must be obligatorily
connected to the heating system equipped with a four-way valve protecting against so-called „low-temperature corrosion”
*** temporary power consumption depends on the equipment operating mode
**) when adjustment feet are used (excluding boilers of the power exceeding 25 kW), the dimension increases from min. 29 mm to max. 56 mm

20
Figure 6. BOILER DESIGN DIAGRAM
SAS BIO SOLID 14-48 KW BOILER
* thermal protection against overheating (e.g., Regulus BVTS for an open vented system with a plate exchanger
or SYR 5067 for a sealed system) is not included in the boiler standard equipment.
** the number and layout of ceramic partitions over the furnace is dependent on the power of the boiler
**) when adjustment feet are used (excluding 25 kW), the dimension increases from min. 29 mm to max. 56 mm
1. Boiler housing 2. Thermal insulation 3. Water jacket 4. Ash drawer 5. Water connector - return 6. Air chamber clean out hatch 7. Furnace space 8. Ash box door with “explosion proof” ap 9. Insulated partition (heat) 10. Ceramic panels - side 11. Ceramic panels - rear/front 12. Ceramic shelves ** 13. Furnace doors 14. Protective partition 15. Clean out hatch door
16. STB safety temperature limiter 17. Power strip 18. Flue gas turbulator 19. Flue gas chamber ap 20. Upper clean out cover 21. Flue gas temperature sensor 22. Flue pipe clean out 23. Flue gas damper 24. Flue 25. Fuel tank 26. Limit switch in the feeder cover 27. Pressure relief valve 28. Driver 29. Water connector - power 30. Analogue thermometer
31. Housing of the front door 32. Ceramic partition - furnaces 33. Furnace housing 34. Side clean out 35. Connector for a thermal protection
with a capillary tube *
36. Guard for moving parts 37. Housing of the drive mechanism 38. SAS MULTI FLAME pellet burner 39. Module controlling burner operation 40. Burner power strip 41. Feeder temperature sensor 42. Discharge connector 43. Adjusting feet (does not apply to
boilers over 25 kW)
