Sase SC8E User manual

SASE Company, Inc.
Phone [phone] or Fax [phone]
www.SASECompany.com
SC8E Scarifier Manual
SASE

Congratulations on your decision to get the Power of SASE behind you! SASE is committed to excellence,
excellence in the quality of products we sell and excellence in service and support after the sale. It is im-
portant to us that your business continues to succeed and grow, and we know that the right products, ser-
vice and support can have a great impact on your bottom line.
SASE has made great strides in the concrete preparation and polishing industry over the years. With a
40,000 square foot distribution and service facility in Seattle, a 22,000 square foot distribution and service
facility in Knoxville, and local sales and technical support representatives throughout the United States,
SASE is able to provide unsurpassed service and technical support for the contractor.
At SASE we engineer and manufacture our own equipment, which allows us to be in control of the quality
of the equipment we sell. SASE offers a complete line of concrete preparation and polishing equipment,
our newest introduction being our new line of PDG planetary diamond grinders, which is setting a new
standard for the concrete grinding and polishing industry. SASE is also the leader in diamond tooling tech-
nology.
We look forward to a long and prosperous partnership with you! Thank you again for choosing SASE.
You won’t regret having the Power of SASE behind your company!
Sincerely,
SASE Company, Inc.
Jim Weder
President
Corporate Office
26423 79th Ave South
Kent, WA 98032-7321
1.800.522.2606 (P)
1.877.762.0748 (F)
www.SASECompany.com
[email protected]
SASE

SASE Company Inc. Equipment Safety Policy Statement
SASE Company, Inc. is adamant that safety is one of the highest priorities for both our employees
and customers. When considering set-up and operation of any piece of equipment supplied,
manufactured, distributed, rented or serviced by SASE Company, Inc., the safety and protection of
people should always be a top priority.
All customers and employees should follow all OSHA and local safety standards, requirements and
regulations.
The use of the following safety equipments are both recommended and required when operating any
piece of equipment supplied, manufactured, distributed, rented or serviced by SASE Company, Inc.
OSHA approved/certified eye protection (safety glasses).
OSHA approved/certified hearing and ear protection.
OSHA approved/certified foot protection (steel toed boots).
OSHA approved/certified respirator or breathing device.
OSHA approved head protection (hard hat).
Proper protective work gloves.
Proper protective clothing limiting skin exposure.
(The list is not meant to be all inclusive. Please exercise sound judgments during operation.)
The work area must always have proper ventilation to minimize the health and safety risks of
propane and gasoline emissions and airborne dust.
All SASE Company Equipment is engineered, designed and provided with dust control shrouds and
vacuum ports. It is strongly recommended that an approved dust containment system be connected
to and used in conjunction with all SASE Company equipment during operational use. SASE
Company supplies, distributes, rents and services dust control systems with HEPA filtration.
Extreme caution must be exercised at all times when electrical power is considered. All SASE
employees are prohibited from working on or hard wiring our equipments to any power
source that has not been provided by SASE Company Inc. Any such work must be
performed by a certified electrical technician. No SASE employee is permitted or authorized
to work on, operate, or connect our equipment or equipment belonging to our customers to
an electrical source that does not meet OSHA approved specifications. There are no
exceptions to this policy! SASE Company, Inc. also strongly recommends that only certified
electricians be permitted to deal with or manipulate electrical power sources within our
customers’ facilities or on their job-sites.
Finally, we at SASE Company, Inc. cannot stress enough the importance of following general safety
practices, the utilization of appropriate safety equipment and the application of common sense when
operating equipment supplied, manufactured, distributed, rented or serviced by SASE Company, Inc.
both on the job-site and in the field.
(JJL 07/2010)
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
5

SASE Company Scarifier SC8E User Manual
Important Information
DO NOT OPERATE THIS EQUIPMENT WITHIN AN ENCLOSED AREA. The
exhaust from the internal combustion engine contains carbon monoxide, an odorless and
deadly poison. If using equipment indoors, proper and adequate ventilation is required. An
approved OSHA air-monitoring system must be in place at all times. Avoid inhalation of
exhaust gas.
Carbon monoxide gas is toxic. Breathing it can cause unconsciousness and may KILL you.
Avoid any areas or actions that expose you to carbon monoxide.
Do to the use of the equipment; suitable protective clothing must be worn or bodily harm
may occur. The machine operator must wear eye protection, gloves, earplugs and non-slip
safety shoes.
When doing work that causes dust, wear an appropriate respiratory mask that will protect
you from the type of dust you are working in.
Before operation please read about this topic and other important safety information that is
contained within the enclosed Engine Owners Manual.
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
7

SASE Company, Inc. Scarifier SC8E User Manual
____________________________________________________________________________________________________
5
Safety Communication
READ AND UNDERSTAND BEFORE
ATTEMPTING TO OPERATE THIS EQUIPMENT
Safety Instructions are preceded by a graphic alert symbol of
DANGER, WARNING, or CAUTION
Imminent hazard which, if not avoided, will result in death or serious injury.
Imminent hazard which, if not avoided, can result in death or serious injury.
Hazards which, if not avoided, could result in serious injury and or damage to the
equipment.
General Instructions
Maintain the machine in safe operating condition with all guards in place and secure all mechanical fasteners
tight.
Ensure all controls in working order and the machine is configured for the job application.
Be sure all safety decals can be clearly read and understood. Replace damaged or missing decals
immediately.
Equipment should only be operated by trained personnel in good physical condition and mental health.
Never operate this machine while under the influence of drugs, alcohol or when taking medications that impair
the senses or reactions, or when excessively tired or under stress.
Avoid deck inserts, pipes, columns, openings, electrical outlets, or any objects protruding from slab surface.
Maintain a safe operating distance to other personnel. It is the operators’ responsibility to keep other people
(workers, pedestrians, bystanders, etc.) at a safe distance during operation.
Block off the work area in all directions. Failure to do so may result in others being injured by flying debris or
exposing them to harmful dust and noise.
For the operator’s safety and the safety of others, always keep all guards in place during operation.
Never let equipment run unattended.

SASE Company, Inc. Scarifier SC8E User Manual
____________________________________________________________________________________________________
6
(PPE) Personal Protection Equipment
Proper safety attire must be worn when operating this machinery. The operator must wear approved
safety equipment appropriate for the job such as hard hat and safety shoes when conditions require.
Ear protection must be worn at all times when this machine is in use. During normal use, sound
levels exceed 92dB.
Eye protection must be worn at all times when this machine is in use. Use only ANSI approved
safety glasses to help prevent eye injury.
Operator must wear appropriate clothing and footwear. Steel toe safety shoes should be worn.
Do not wear loose clothing or jewelry that can get tangled or caught in moving parts. Keep body parts and
loose clothing away from moving parts. Failure to do so could result in dismemberment or death.
General Operation
Stop motor/engine when adjusting or servicing this equipment. Maintain a safe operating distance from
flammable materials.
Sparks from the cutting-action of this machine can ignite flammable materials or vapors.
Check motor rotation.
DO NOT use if drum rotation is incorrect - have a qualified electrician make the necessary change in the main
control panel or motor connection box.

SASE Company, Inc. Scarifier SC8E User Manual
____________________________________________________________________________________________________
7
Before Starting the Machine
Perform a visual inspection of the entire machine and all daily maintenance according to the Maintenance
Schedule.
Locate and be familiar with all engine/motor and operating controls.
For Gasoline models, obtain the Engine Manufacturer’s Owner’s Manual. Read it and understand it before
continuing. Follow the engine manual for break-in instructions.
Use the correct cutters for the job. Be sure cutter drum is balanced, the number, size and type of cutter wheels
are correct.
Be sure all fasteners are tight and secure, check for signs of metal cracking or fatigue, inspect for damage to
electrical wiring, damage to fuel lines, check bearings, etc.
Be sure all guards are in place.
Inspect work area to determine the presence and location of deck inserts, pipes, columns and objects
protruding from the slab surface so that they may be avoided during operation.
Safety warnings and guidelines do not by themselves eliminate danger.
They are not given as substitutes for proper accident prevention and good judgment.
Electrical Powered Equipment
For Electric Models - Electric motors must be properly grounded at all times. Check the outlet
box to be sure the electrical service is properly grounded. Be sure adequate power is available.
Insufficient power will cause a motor to overheat and burn out.
Use only grounded extension cords correctly sized for the current draw and voltage drop (amp rating and
length). Never use frayed, damaged, taped or under rated extension cords.
Electrical shock could result in death or serious injury to the operator and damage to the
equipment.
Extreme care must be taken when operating electric models with water present: Ensure power cord is properly
grounded, is attached to a Ground-Fault-Interrupter (GFI) outlet, and is undamaged.
Check all electrical cables - be sure connections are tight and cable is continuous and in good condition. Be
sure cable is correctly rated for both the operating current and voltage of this equipment.
Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with
qualified electrician or service person if there is any doubt as to whether the outlet is properly grounded.
Adhere to all local codes and ordinances.
NOTE: In the event of a malfunction or breakdown, grounding provides a path of least resistance for the
electric current to dissipate. The motor is equipped with a grounded plug and must be connected to an outlet
that is properly installed and properly grounded. DO NOT modify the plug provided on the motor. If the plug
does not fit the outlet have a qualified electrician install the proper receptacle.

SASE Company, Inc. Scarifier SC8E User Manual
____________________________________________________________________________________________________
8
Switch motor OFF before disconnecting power.
Do not disconnect power by pulling cord. To disconnect, grasp the plug, not the cord.
Unplug power cord at the machine when not in use and before servicing.
Starting the Engine/Motor for Electric Models
Be sure the “OFF” button is depressed on the motor starter box.
Hook up the correct voltage/phase electrical power source by plugging into the connector provided. If the cord
does not mate with the connector, consult a qualified licensed electrician before continuing.
Verify that the electrical current being supplied is the proper voltage and phase required to run the equipment.
POISONOUS EXHAUST
Gasoline Powered Models
DO NOT operate any gasoline powered equipment without adequate ventilation. Carbon monoxide is an
invisible, odorless gas that can kill.
NEVER REFUEL A HOT ENGINE OR AN ENGINE WHILE IT IS RUNNING.
Only refuel a cool “stopped” engine in a well-ventilated area. Properly clean any spilled fuel before starting the
engine.
Gasoline is extremely flammable and poisonous. It should only be dispensed in well ventilated
areas, and with a cool engine..
Engine exhaust from this product contains chemicals known to cause cancer, birth defects or other
reproductive harm.
Small gasoline engines produce high concentrations of carbon monoxide (CO). Gasoline or
propane powered equipment should not be used in enclosed or partially enclosed areas.
Symptoms of CO poisoning include, headache, nausea, weakness, dizziness, visual problems
and loss of consciousness. If symptoms occur get into fresh air and seek medical attention
immediately.
Gasoline Models - Consult the Engine Manufacturer’s Owner’s Manual and follow the directions for starting
the engine and allow the engine to warm up.
Refer to the Engine/Motor Manufacturer’s Owner’s Manual for maintenance information specific to the
engine/motor used.

SASE Company, Inc. Scarifier SC8E User Manual
____________________________________________________________________________________________________
9
Dust Warning
Some dust created by grinding and other construction activities contains chemicals known
to cause cancer, birth defects, or other reproductive harm.
Some examples of these chemicals are:
Lead from lead-based paints
Crystalline silica from concrete and other masonry products.
Your risk of exposure to these chemicals varies depending on how often you do this type of work.
To reduce your risk work in a well ventilated area, use a dust control system, such as an industrial-
style vacuum, and wear approved personal safety equipment, such as a dust/particle respirator
designed to filter out microscopic particles.
Dry Grinding
Dry Grinding creates a large volume of airborne dust. For health reasons, the operator should wear an
applicable respirator. The dust may contain chemicals known to cause serious illnesses, including Silicosis - a
fatal disease of the lungs.
Check the chemical properties of the material to be removed and follow all EPA/OSHA regulations.
An Industrial vacuum, capable of handling high volume of fine dust, should be used when dry grinding with this
machine. If the material being used is hazardous or contains Silica - the vacuum unit should be capable of
removing Silica and hazardous particles of less than 3 microns and if necessary, have the capability to be
equipped with a HEPA filter.
Most standard drum type units use a paper bag filter. The dust created during grinding is extremely fine and
will clog the filter bag of these units and eventually damage the vacuums motor. In addition, damage to the
engine could occur.
The collected debris and filters should be disposed of according to procedures that comply with current
EPA/OSHA standards
Serious injury or death could occur if this machine is used improperly

SASE Company, Inc. Scarifier SC8E User Manual
____________________________________________________________________________________________________
10
Maintenance
Proper belt tension must be maintained to transmit the engine/motor power to the cutting drum. An over
tensioned belt will shorten belt and bearing life.
A damaged, stretched or excessively worn belt should be replaced.
Check oil level before operation. Change engine oil and filter according to engine manufacturers
recommendations.
Engine Air Filter
Important! Clean air filter element daily
Inspect the air filter for excess dust, dirt or damage before the engine is operated. More often if operating in an
extremely dusty environment.
Operating the engine with a damaged or dirty air filter, or without an air filter, will allow dirt to enter the engine
causing premature engine wear which is not covered under the engine manufacturer’s warranty.
Follow the engine manufacturer’s procedures for keeping filters in good condition.
Never work on or under equipment without first securing the equipment to prevent it from moving or falling.
Always work on a flat and level surface.
Remove spark plug lead on gasoline engine models or disconnect the supply voltage connector on electric
models before performing any maintenance.
Disconnect the power cord at the machine.
Operating Procedures for SC8E (GAS)
Start-Up
Add oil and gasoline to the machine.
Move the fuel valve lever to the ON position.
Move the choke lever to the CLOSED position (cold engine).
Move the throttle lever 1/3 of the way toward the FAST position.
Turn the engine switch to the ON position.
Operate the starter by lightly pulling the starter grip until you feel resistance, then pull briskly.
Gently return the starter grip.
Lower drum and begin grinding.
Read the following additional information before operating your scarifier.
Caution: Never tilt the unit back on the handle. Oil will flow into the cylinder head and could severely
damage the motor and void the warranty.

SASE Company, Inc. Scarifier SC8E User Manual
____________________________________________________________________________________________________
11
Drive Motor/Engine:
The internal combustion engines are supplied without fuel or motor oil. Therefore, be sure to fill them as
instructed in the manufacturer’s manual. If the motor suddenly stops, the oil could be to low or it may have
been overfilled.
Caution: Start the motor ONLY when the cutter drum assembly is in the raised position and the parking brake on.
Cutter/Drum Configuration
Check to make sure that the drum is configured with the cutters we recommend for the application in question.
When working with special milling cutters, be extra careful about the correct direction of drum rotation and
correct cutter installation. Never tip the machine on its back to look at the cutters. This can be done quickly and
easily by removing the endplate. When putting the endplate back on the machine, make certain to check the
tightening torque of cover nuts.
Caution: To avoid bearing damage, repeat this check of the cover nuts from time to time.
Working with the Scarifier:
To engage the drum, lift the black handle up and proceed in forward motion with the lever. Once the drum
engages, you can go lower for more aggressive cutting or back up for lighter scarifying. For fine-tuning of the
adjustment depth, turn the black dial clockwise until the desired adjustment is reached.
Caution: Do not lower the black handle too deep. This will NOT increase productivity. When the depth is set
correctly, the machine will run smoothly.
To stop scarifying, lift the black handle up and proceed in a backward motion until the lever is in the uppermost
position
Changing the cutter drum:
Always be sure to switch off the machine before removing the endplate. This will prevent any flying debris from
injuring the worker. Remove the cover nuts from the endplate, and then remove the endplate to expose the
cutter drum assembly.
Dust Control:
Should dust control be of concern, please contact SASE to inquire about our powerful dust control vacuums.
The SC8E can be used with an optional 2” vacuum connection.
If you need further assistance, please call our toll free number .800.522.2606.

Cutter and Flail Shaft Recommendations
- The above flail shafts are s fts should have been
replaced much earlier.
howing excessive wear. These sha
To a great extent, economical use of cutter drums depends upon proper maintenance. Changing flail
shafts before they become excessively worn and begin to oval out the shaft holes can significantly
increase the life of the drum. If you run a machine with badly worn flail shafts you can easily
destroy a drum in just a few hours. These shafts are only surface hardened in order to maintain their
internal strength. This is why it is important to replace them as soon as the grooves are 1/5 of an
inch or 5mm deep.
Changing the shafts early provides the following advantages:
•The drum shaft holes will not wear as fast thus increasing drum life.
•Breakage of shafts can be avoided, thus saving a great deal of downtime refitting the
machine.
Recommendations:
•When working with five or eight point Tungsten Carbide tipped cutters or special milling
cutters, replace the shafts every fifteen to twenty hours of operation.
•When working with steel cutters change the shafts every time new cutters are installed.
•Change the entire cutter/drum assembly after 3 sets of cutters have been used up, if not
sooner.
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
17


SASE Company, Inc.
800.522.2606
www.SASECompany.com
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
18

8
7
6
5
4
3
2
1
Dead Man’s
Switch & Wiring
SC8E Gas
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
19

Item No Part No Description Quantity
1SC.08.000 Black SC8E Chassis 1
2HON.GX160 5.5 HP GX160 FR 200 Engine 1
3NB.10.250 5/16 -24 X 3/4 Hex Screw 1
4NB.30.401 5/16 X 30 Fender Washer 1
5HON.2026227 Muffler Deflector (comes with HON.GX160) 1
16 SC.08.115 Upper Toothed Pulley FR200 SC8E Gas 1
Emergency Stop Bracket
6NB.19.101 8-32 X 3/4 Pan Head Screw 2
7NB.20.133 8-32 Nyloc Nut 2
8795.00.76 Mounting Emergency Stop Bracket FR200 1
Dead Man's Switch & Wiring
9795.00.12 11" X 0.125" Black Zip Tie 2
10 795.00.19 Emergency Stop Switch Tether with Cord 1
11 795.00.20 16-14 AWG Bullet Connector Blue Nylon 1
12 795.00.21 22-18 AWG Ring-1/4" Stud Red Nylon 1
13 795.00.22 22-18 AWG Butt Connector Red Vinyl 2
14 795.00.23 3/8" Heat Shrink Tubing Black 4 in
15 AIW.16X2CRD Power Cord 16/2 6 ft
*Honda engine
*Orient the upper pulley nipple toward motor
SC8E Gas
SC.08.020
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
20

Dead Man’s
Switch & Wiring
3
4
6
5
7
8
2
1
9
10
11
SC8E 110V
Single Phase
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
21

Item No Part No Description Quantity
1 NB.10.114 M8 X 20 Hex Head Screw 1
2 NB.30.403 M8 X 30 Fender Washer 1
3 SC.08.000 Black SC8E Chassis 1
4 SC.08.113 Upper Toothed Pulley FR200 1
5 SC.08.117 T-BOLT Short FR 200 SC8E 8
6 SC.08.120 Mounting Pair Rail FR 200 SC8E 1
7 SC.08.121 Electric Mounting Plate FR 200 SC8E 2
8 ZZ.03500T Electric Motor 1 PH 110V FR200 SC8E 1
Emergency Bracket
9 NB.19.101 8-32 X 3/4 Pan Head Screw 2
10 NB.20.133 8-32 Nyloc Nut 2
11 795.00.76 Mounting Emergency Stop Bracket FR200 1
Dead Man's Switch & Wiring
12 795.00.04 3/4" Liquidtight Flexible Conduit 4 ft
13 795.00.05 3/4" L/T Bullet Connector LT75P 2
14 795.00.06 3/4" W/R Black SLRN21 1
15 795.00.08 3/4-IN 45 Bullet L/T Connector 1
16 795.00.10 18 Gauge Wire Nut Yellow 3
17 795.00.12 Zip Tie Black 11" X 0.125" 2
18 795.00.19 Emergency Stop Switch Tether with Cord 1
19 795.00.20 16-14 AWG Bullet Connector Blue Nylon 1
20 795.00.21 22-18 AWG Ring-1/4" Stud Red Nylon 1
21 795.00.22 22-18 AWG Butt Connector Red Vinyl 2
22 795.00.23 3/8" Heat Shrink Tubing Black 4 in
23 AIW.10X3CRD Power Cord 10/3 6 ft
24 AIW.16X2CRD Power Cord 16/2 1 ft
25 ELE.33031 Twistlock Male Plug L5-15P 1
26 MCC.27AA110 Shunt Relay Module 110V for 25A Switch 1
27 MCC.27.25A 25 Amp Switch 1
28 MCC.27.KAZ Switch Enclosure Box for 25 Amp 1
29 NB.19.101 8-32 X 3/4 Pan Head Screw 2
30 NB.20.133 8-32 Nyloc Nut 2
*Orient the upper pulley nipple outward motor
*Align bolts through Motor Slots
SC8E 110V Single Phase
SC.08.040
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
22

9
10
11
Dead Man’s
Switch & Wiring
3
4
2
16
5
7
8
SC8E 230V
Single Phase
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
23

Item No Part No Description Quantity
1 NB.10.114 M8 X 20 Hex Screw 1
2 NB.30.403 M8 X 30 Fender Washer 1
3 SC.08.000 Black SC8E Scarifier Chassis 1
4 SC.08.113 Upper Toothed Electric Pulley FR200 1
5 SC.08.117 Short T-bolt FR 200 8
6 SC.08.120 Mounting Pair Rail FR200 1
7 SC.08.121 Electric Mounting Plate FR200 2
8 ZZ.L3515T Electric Motor 1 Phase 230V FR200 SC8E 1
Emergency Bracket
9NB.19.101 8-32 X 3/4 Pan Head Screw 2
10 NB.20.133 8-32 Nyloc Nut 2
11 795.00.76 Mounting Emergency Stop Bracket FR200 1
Dead Man's Switch & Wiring
12 795.00.04 3/4" Liquidtight Flexible Non-metallic Conduit 4 ft
13 795.00.05 3/4" L/T Bullet Connector LT75P 1
14 795.00.06 3/4" W/R Black SLRN21 1
15 795.00.08 3/4-IN 45 L/T Bullet Connector 3
16 795.00.10 18 Yellow Gauge Wire Nut 1
17 795.00.12 Black Zip Tie 11" X 0.125" 1
18 795.00.19 Emergency Stop Switch Tether with Cord 1
19 795.00.22 22-18 AWG Butt Connector Red Vinyl 2
20 795.00.23 3/8" Heat Shrink Tubing Black 4 in
21 AIW.10X3CRD Power Cord 10/3 6 ft
22 AIW.16X2CRD Power Cord 16/2 1 ft
23 MCC.27.16A 16 Amp Switch 1
24 MCC.27.25AA220 Shunt Relay Module for 220 V 1
25 MCC.27.KAZ Switch Enclosure Box for 25A Switch 1
26 NB.19.101 8-32 X 3/4 Pan Head Screw 2
27 NB.20.133 8-32 Nyloc Nut 2
*drill and tap
*Black = 1+5 White = 4+8
SC8E 230V Single Phase
SC.08.042
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
24

9
10
11
Dead Man’s
Switch & Wiring
3
4
2
16
5
7
8
SC8E 230V
Three Phase
SASE Company Inc.
Scarifier SC8E User Manual
SASE Company, Inc © 2006 All Rights Reserved
25
