1 Introduction
1.
The AX-8 Analog Expander is an instrument that enables Powermeters to interface
with other devices that require analog signals. The AX-8 can be connected to any
Powermeter equipped with an RS-422 communication port and analog expander
option.
The AX-8 provides up to 8 analog outputs. Two units can be connected in
sequence, providing as many as 16 analog outputs with use of one Powermeter1.
For information on analog output and analog expander setup and connections,
refer to the Installation and Operation Manual of the specific Powermeter.
Features
Accuracy -The AX-8 provides 8 or 9 bit resolution on each analog output. Output
values on all channels are updated continuously at a rate of 0.3 to 0.5 seconds,
depending on the speed of communication (baud rate).
Flexibility -The analog outputs are provided with current output options of 0-20
mA and 4-20 mA, 0-1 mA and ±1 mA , and voltage output options of 0-10V DC
and ±10V DC. Depending on the specific model of Powermeter, a wide range of
output values are user-selectable, from the Powermeter front panel or via
communications software.
Installation -DIN rail or wall mounting. No auxiliary power supply is required; an
internal switching power supply with a wide AC/DC range is provided.
Communications -The AX-8 is connected to the Powermeter using a twisted pair
cable via the RS-422 port, using ASCII, Modbus or DNP3.0 protocols. This allows
communication over a distance of up to 1000 meters at a baud rate of up to 19,200
bps. Installation of the AX-8 does not interfere with the inclusion of the Powermeter
in a communication network (RS-422 or RS-485) of up to 31 Powermeters.
Figure 1-1shows a typical communication network with two AX-8 expanders.
1If your Powermeter supports7 (14) channels, then the AX-8 will also provide 7 (14) channels.

2
Figure 1-1AX-8 Analog Expanders in a Typical Communication Network
INPUTS (PLC)
POWERMETER
POWERMETER
AX-8
POWERMETER
RS-422/RS-485
UP TO 31 POWERMETERS
00-02021
USER'SANALOG
CURRENT
CURRENT
CURRENT
L3
/L
31
KV
L
1/
L1
2
VOLTAGE
VOLTAGE
L 2/L2 3
V
KV
V
HARMONICANALYZER
VOLTAGE
KVV
RESET
SELECT
RESET
MAX
PAGING
ENERGY
KVARH/MVARH
KA
REACTIVEENERGY
MAX.AMP.DEMAND
290H
KVAR
MVAR
MAX.DEMAND
MAX.AMP.DEMAND
MAX.AMP.DEMAND
KA
A
A
ACTIVEPOWER
ACTIVEENERGY
REACTIVEPOWER
KA
A
POWER FACTOR
UNBALANCED CURRENT
FREQUENCY
MW
KW
KWH/MWH
MAX.DEMAND
SATEC
A
H
z
SYSTEM290
APPARENT POWER
MVA
KVA
CURRENT
CURRENT
CURRENT
L3
/L
31
KV
L
1/
L1
2
VOLTAGE
VOLTAGE
L 2/L2 3
V
KV
V
HARMONIC ANALYZER
VOLTAGE
KV
V
RESET
SELECT
RESET
MAX
PAGING
ENERGY
KVARH/MVARH
KA
REACTIVEENERGY
MAX.AMP.DEMAND
290H
KVAR
MVAR
MAX.DEMAND
MAX.AMP.DEMAND
MAX.AMP.DEMAND
KA
A
A
ACTIVE POWER
ACTIVE ENERGY
REACTIVEPOWER
KA
A
POWERFACTOR
UNBALANCEDCURRENT
FREQUENCY
MWKW
KWH/MWH
MAX.DEMAND
SATEC
A
Hz
SYSTEM 290
APPARENTPOWER
MVA
KVA
CURRENT
CURRENT
CURRENT
L3 /L3 1
KV
L 1/L1 2
VOLTAGE
VOLTAGE
L 2/L 23
V
KV
V
HARMONIC ANALYZER
VOLTAGE
KV
V
RESET
SELECT
RESET
MAX
PAGING
ENERGY
KVARH/MVARH
KA
REACTIVEENERGYMAX.AMP.DEMAND
290H
KVAR
MVAR
MAX.DEMAND
MAX.AMP.DEMAND
MAX.AMP.DEMAND
KAA
A
ACTIVEPOWER
ACTIVEENERGY
REACTIVEPOWER
KAA
POWERFACTOR
UNBALANCEDCURRENT
FREQUENCY
MW
KW
KWH/MWH
MAX.DEMAND
SATEC
A
Hz
SYSTEM290
APPARENTPOWER
MVA
KVA
AX-8
ADDRESS 1
ANALOG OUTPUT
OUT
IN
#2 #31
#1
ADDRESS 0
IN
ANALOG OUTPUT
ANALOG EXPANDER AX-8
ANALOGOUTPUTS
ON
POWERSUPPLY
DC
AC +
LN
_
NETWORK
RS-422/RS-485
RX
RS-422
POWER METER
TX TX RX
++ _ _
RX
+_
1 2 53 4 6 7 8
RX
TX
RX
TX
RX
TX
__
++ +_+_+_+_+_+_+_
POWER METER
RX
ON
TX
_
NL
+
AC
DC
POWER SUPPLY
ANALOG EXPANDER AX-8
RX
_
TX
RS-422/RS-485
NETWORK
+
TXTXRX
__
+ +
RXTX
RS-422 +
RX +
_
RX
1
_
+
ANALOG OUTPUTS
+
_
+
_
+
_432 5
_ _
+
_
+
_
+
876
RS
RS-422 ONLY

3
2 Field Setting
2.
2.1 Default Setting
The Analog Expander is set by the dip switches S1 and S2 on the PCB located
inside the AX-8 case. The default setting is as follows:
Expander address 0 1
Analog output range factory set as per order
Protocol ASCII
Data format 8N (8 bit, no parity)
Baud rate 9600 bps
If you require a change to this setting, open the case as per Sections 2.2 -2.4
below and change the setting.
2.2 ChangingtheCommunicationParameters (Firmware Version 0.10)
1. Disassemble the AX-8 case: remove the 8 screws from the outside of
the case and take off the rear cover.
2. Set the DIP switches on the PCB (see Figure 2-1) as shown in Tables 2-1
and 2-2below.
3. Re-assemble the case: put the rear cover back on, insert and tighten the 8
screws.
1This address allows use of up to 7 or 8 analog outputs, according to the analog output
setup in the Powermeter. Use of additional outputs from one Powermeter requires
installation of an additional AX-8 unit with address ‘1’.

4
Figure 2-1Location of Dip Switches on AX-8 PCB
Table 2-1 DIP Switch S1 * = default
AX-8 Option
SW1
Addr0 SW2
Addr1
SW3
Addr 2
SW4
N/A SW5
N/A SW6 SW7 SW8
Factory Set
Address 0 OFF OFF OFF
Address 1 ON OFF OFF
Address 2 OFF ON OFF
Address 3 ON ON OFF
Address 4 OFF OFF ON
Address 5 ON OFF ON
Address 6 OFF ON ON
Address 7 ON ON ON
Table 2-2DIP Switch S2 (Serial Port) * = default
AX-8 Option SW1
Mode SW2
Data SW3
Parity SW4
N/A SW5
Baud 0
SW6
Baud 1 SW7
Baud 2 SW8
Baud 3
ASCII mode OFF
Binary (transparent)
mode ON
7 bit/Even parity OFF ON
8 bit/No parity ON OFF
8 bit/Even parity ON ON
110 baud OFF OFF OFF OFF
300 baud ON OFF OFF OFF
600 baud OFF ON OFF OFF
1200 baud ON ON OFF OFF
2400 baud OFF OFF ON OFF
4800 baud ON OFF ON OFF
9600 baud OFF ON ON OFF
19200 baud ON ON ON OFF
CE5
R43
R27
R29
R28
C14
R30
1
1
C204
R204
R25
R35
R38
R36
+
+15V
C18
S1
R16
R18
R14
R26
R24
1
S2
+
C13 C12
D5
U6
L3
R42
R101
R109
U102
R103
R110
R107
R108
R104
R105
C101
C102
U101
R23
D7 CE4
+
CE7
R106
D8
+
TOP PC0117 REV.A1
1
1
431 2 765 8
00-03008
86 753 421
ONON

5
3 Installation
3.
3.1 Mechanical Installation
The AX-8 should be mounted in a dirt-free environment away from heat
sources and high electrical fields. Mounting may be either standard DIN
rail or wall mount. Only front access is required for wiring.
4.685"
(186.0)
5.118"
(130.0)
01-05001-1
2.992"
ANALOG EXPANDER AX-8
7.323"
(76.0)
PANEL
(36.3)
1.430"
(165.0)
6.496"
Figure 3-1Standard DIN Rail Mounting

6
ANALOG EXPANDER AX-8
PANEL
LOCK WASHER
SCREW
Figure 3-2Wall Mounting
3.2 Electrical Installation
For AX-8 connections to the power supply, communications and analog
outputs, see Figures 3-3 (RS-422 network) or 3-4(RS-485 network).
Power Supply
Use a dedicated breaker from a proper power source, from which the unit
can be turned off. All AX-8 analog outputs are provided with an internal
power supply; no external power supply for analog outputs is required.
Communications
The AX-8 is connected on one side to the Powermeter via the RS-422
input, and from the other side, to the multi-drop communication network
via the RS422 or RS-485 output, using the ASCII, Modbus or DNP3.0
protocol.
Communications may be over a distance of up to 1000 meters and at a
baud rate of up to 19,200 bps. A twisted pair cable of 0.33mm2/22AWG is
recommended.

7
Analog Output Options
Current output options Voltage output options
0-20mA, 4-20mA 0-10V DC and ±10V DC
0-1mA, ±1mA
Loads must be connected to analog outputs 1-8 according to their polarity.
Figure 3-3AX-8 Connections in RS-422 Network
FBe sure that all incoming AC power and other power sources
are turned OFF before performing any connections.
00-03020
+Rx
-Rx
+Tx
-Tx
COMMUN.
PORT
AX-8
#2
POWERMETER
RS-422
(IBM PC OR PLC)
MASTER
RS-422
COMMUN.
PORT
#2
RS-422
TERMINAL
POWERMETER
TERMINAL
RS-422
#31
POWERMETER
NETWORKPOWERMETER
ANALOG EXPANDER AX-8
ANALOG OUTPUTS
ON
POWER SUPPLY
DC
AC +
LN
_
NETWORK
RS-422/RS-485
RX
RS-422
POWER METER
TX TX RX
++ _ _
RX
+
_
1
2
RXTX RXTXRXTX __
++ +_+_+_+_+_+_+_
OR 48V DC
OR 24V DC
OR 12V DC
POWER SUPPLY
110-230VAC/DC
*
7
6
5
3
4
2
1
*
*
3
4
5
6
7
8
8
LOADS
R
1
#1
-Rx
-Tx
+Rx
+Tx
+Tx
+Rx
-Tx
-Rx
UP TO
2
R
+Tx
+Rx
-Tx
-Rx
-Rx
-Tx
+Rx
+Tx
-Rx
-Tx
+Rx
+Tx
TERMINATIONRESISTORS
R2
R1==200-500 OHM
0.5W
5A
*
as per customer order

8
Figure 3-4 AX-8 Connections in RS-485 Network
FBe sure that all incoming AC power and other power sources
are turned OFF before performing any connections.
*
as per customer order
00-03021
+Rx
-Rx
+Tx
-Tx
COMMUN.
PORT
AX-8
#2
POWERMETER
RS-422/485
(IBMPCORPLC)
MASTER
RS-422
COMMUN.
PORT
#2
TERMINAL
POWERMETER
TERMINAL
#31
POWERMETER
NETWORK
POWERMETER
ANALOG EXPANDER AX-8
ANALOG OUTPUTS
ON
POWER SUPPLY
DC
AC +
LN
_
NETWORK
RS-422/RS-485
RX
RS-422
POWER METER
TX
TX RX
++ _ _
RX
+
_
1
2
RXTX RXTXRXTX __
++ +_+_+_+_+_+_+_
OR 48V DC
OR 24V DC
OR 12V DC
POWER SUPPLY
110-230VAC/DC
*
7
6
5
3
4
2
1
*
*
3
4
5
6
7
8
8
LOADS
R
1
#1
-Rx
-Tx
+Rx
+Tx
+Tx
+Rx
-Tx
-Rx
UP TO
2
R
+Tx
+Rx
-Tx
-Rx
-Rx
-Tx
+Rx
+Tx
-Rx
-Tx
+Rx
+Tx
TERMINATION RESISTORS
R2R1==200-500 OHM
0.5W
RS-422/485
RS-422/485
5A

9
4 Operation
4.
Refer to the Installation and Operation Manual of the specific Powermeter for
instructions on Analog Expander and communication parameters setup.
4.1 Power Up
Close the power feed breaker; the ‘ON’ LED will light up.
4.2 Communication
When you program your powermeter to output data to external analog outputs, the
powermeter periodically updates the AX-8 analog outputs (each 300-500 ms) via
the pair of wires on the RS-422 communications link used for transmitting data. At
that time, the transmission (output) line of the AX-8 is disconnected from the
external network, while the receive line is directly connected to the powermeter
port so that the instrument is constantly ‘listening’ to the network.
When data is requested from the powermeter by a master computer (or controller),
the powermeter instructs the AX-8 to switch the transmission line to the external
network, and then sends the response. After the response message is sent out, the
transmission line is disconnected from the network and the powermeter continues
updating the AX-8 outputs.
The AX-8 can work with different ASCII and non-ASCII network protocols. If you
use an ASCII communications protocol, set the switch #1 on the DIP switch block
S2 to OFF in order to put the AX-8 into ASCII mode. The ASCII message frame
should be ended with two characters CR/LF (ASCII 13 and 10). If you are using
non-ASCII communications protocol such as Modbus or DNP 3.0, set the switch #1
on the DIP switch block S2 to ON to put the AX-8 into binary (transparent) mode. In
this event, the AX-8 will not decode the message frame and the transmission line is
disconnected in 3.5 character time after the response message is sent out.
Indicator LEDs
The AX-8 is provided with a single Rx LED (network indication) and a pair of Rx-Tx
LEDs (Powermeter indication) which operate as shown in Figure 4-1:

10
Transmission Status LED Indication
no transmission no LEDs lit up
Powermeter to AX-8single Rx LED (‘1’ in Figure 4-1) flashes
RS-422: master to Powermeter Powermeter Tx LED (‘2’) flashes
Powermeter to master Powermeter Rx LED (‘3’) flashes
RS-485: master to Powermeter
Powermeter to master Powermeter Rx and Tx LEDs flash
Figure 4-1Detail of Communication LEDs on AX-8
NETWORK
RS-422/RS-485
RX
RS-422
POWER METER
TX TX RX
++ _ _
RX
RXTX RXTXRXTX __
++
1
2
3

11
5 Technical Specifications
5.
Instrument serial
communications RS-422
Network serial communications
RS-422 / RS-485
Baud rate (bps) 110, 300, 600,1200, 2400, 4800, 9600, 19200
Inter-channel separation >95dB
Galvanic isolation:
Power Supply
Communication
2500V rms
1000V DC
Accuracy
Temperature coefficient
±0.5% of full scale for current output up to 2500Ω
±2.0% of full scale for current output from 2500Ω
to 10000Ω
±50ppm/°C
Resolution 8 bits
Current output Span (factory set) External resistance
Voltage output
4-20mA
±1mA
0-20mA
0-1mA
0-10V DC
±10V DC
up to 750Ω
up to 10000Ω
up to 750Ω
up to 10000Ω
from 1000Ω
from 1000Ω
Power supply ratings (factory set)
120&230 V AC
and 110&220 V DC
option 12 V DC
option 24 V DC
option 48 V DC
90-264V AC 50/60 Hz
and 110-290V DC burden 10 W
10 -16 VDC
18 -36 VDC
36 -72 VDC
Ambient temperature Operation: -20°C to +60°C
Storage: -25°C to +80°C
Humidity 95% max. non-condensing
Enclosure Aluminum, anodized
Mounting 35 mmDIN rail or wall mount
Weight 0.6 kg (1.32 lb.)
Dimensions 186 x 75 x 109 mm (7.33 x 2.95 x 4.3 inch)

12
Technical Specifications (continued)
Standards UL File # E129258
CE-EMC: 89/336/EEC as amended by 92/31/EEC and 93/68/EEC
CE-SAFETY: 72/23/EEC as amended by 93/68/EEC and
93/465/EEC
Harmonized standards to which conformity is declared:
EN55011:1991; EN50082-1:1992; EN61010-1:1993; A2/1995
ANSI C37.90.1 1989 Surge Withstand Capability (SWC)
ANSI C62.41-1991 Standard Surge
EN50081-2 Generic Emission Standard-Industrial Environment
EN50082-2 Generic Immunity Standard-Industrial Environment
EN55022: 1994 Class A
EN61000-4-2
ENV50140: 1983
ENV50204: 1995 (900MHz)
ENV50141: 1993
EN61000-4-4:1995
EN61000-4-8: 1993
Table of contents
