MuxLab 500464 User manual

© MuxLab Inc. 2017 94-000869-A/ SE-000869-A
HDMI 2.0 Fiber
Extender Kit
Installation Guide
500464

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 2
SAFETY PRECAUTIONS
To insure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
Do not dismantle the housing or modify the module. It may result in electrical shock
or may burn.
To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this
product near water. Keep the product away from liquids.
Spillage into the housing may result in fire, electrical shock, or equipment damage. If
an object or liquid falls or spills on to the housing, unplug the module immediately.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
Using supplies or parts not meeting the product’s specifications may cause damage,
deterioration or malfunction.
Refer all servicing to qualified service personnel.
Install the device in a place with good ventilation to avoid damage caused by
overheating.
Unplug the power cord when left unused for a long period of time.
Do not put any heavy items on the unit.
Do not remove the housing of the device as you may be exposed to dangerous
voltage or other hazards.
Do not twist or pull with force ends of the optical cable attached to the unit, as it may
cause damage.
Information on disposal of devices: do not burn or mix with general household waste,
please treat this device as normal electrical wastes.
Unpack the equipment carefully and save the original box and packing material for
possible future shipment
NOTICE:
Please read this user manual carefully before using the product.

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 3
Contents
1. Introduction.................................................................................................................4
1.1 Introduction to the 500464.................................................................................4
1.2 Features ............................................................................................................4
1.3 Package Contents.............................................................................................4
2. Specifications..............................................................................................................5
3. System Requirement for Installation...........................................................................5
3.1 Hardware requirements.....................................................................................5
3.2 Software requirements ......................................................................................6
3.3 AC/DC Power Adapter (Technical Advisory) ......................................................6
4. System Connection.....................................................................................................6
4.1 Safety Precautions ............................................................................................6
4.2 System Diagram................................................................................................6
4.3 Connection Procedure.......................................................................................7
5. Troubleshooting & Maintenance .................................................................................9
Maintenance..........................................................................................................10
Technical Support and Service..............................................................................10
Certification of Eye Safety.....................................................................................10
Regulatory Compliance ................................................................................................11

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 4
1. Introduction
1.1 Introduction to the 500464
The HDMI 2.0 Fiber Extender Kit, 500464 enables the user to transmit 4K (4096x2160)
video at 60Hz signal up to 330ft (100m), with any form of scaling or data compression
being applied to the signal. This device supports a total data throughput of 18Gbps
(6Gbps per lane).
The unit supports two (2) LC connectors and may be connected with OM3 multi-mode
fiber between the Transmitter and Receiver, providing a clean, secure and easy
installation with ideal electrical isolation, and immune to electrical hazard and
interference. The 500464 Transmitter may be powered via USB power (with the
included power supply), or from the 5V supplied from pin #18 of the HDMI connector of
the source side only. Note that if the source does not adequately supply this power on its
HDMI connector, then the included power supply must be used.
1.2 Features
Supports the HDMI 2.0 standard
Up to 330ft (100m) over 50/125m multi-mode fiber (OM3) at 4K (4096x2160)
resolution, @ 60Hz refresh rate
Bandwidth of 18Gbps, supporting up to 4K (4096X2160) @ 60Hz
Supports CEC, EDID & HDCP 2.2
High retention HDMI connector to prevent accidental disconnection
Compact Metal Enclosure for a robust and easy installation
1.3 Package Contents
One (1) HDMI 2.0 Fiber Transmitter
One (1) HDMI 2.0 Fiber Receiver
Two (2) Power Supplies, 5VDC @ 1A with interchangeable US, UK & Euro
Blades
Two (2) USB type A to micro USB cables
One (1) User Manual
Notes：Confirm that the product and accessories are all included, if not please contact
your dealer.

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 5
2. Specifications
Environment
HDMI 2.0
Devices
Plasma, projectors, monitors, Television, PC, laptops, and
servers supporting HDMI.
Transmission
Transparent to the user
Video Bandwidth
18 Gbps (6 Gbps per lane)
Video Resolution
Up to 4096x2160 @ 60Hz
Signals
HDMI 2.0
Connectors per
unit
One (1) HDMI Male Connector
Two (2) LC Optical Connectors
One (1) Micro USB connector for external power
Maximum Distance
330ft (100 m) over 50/125m multi-mode fiber (OM3)
Cable
Two (2) LC multi-mode fibers, having a 50/125m core
Power Supply
Two (2) 110-240V to 5VDC, 1Apower supply with
interchangeable blades for US, UK & Euro
Temperature
Operating: 0° to 50°C Storage: -30° to 70°C
Humidity: Up to 85% non-condensing
Enclosure
Metal
Dimensions
1.02” x 2.83” x 0.57” (26 x 72 x 15 mm)
Weight
1.0 lbs (0.45 kg)
Compliance
Regulatory: FCC, CE, RoHS
Warranty
2 years
Order Information
500464 HDMI 2.0 Fiber Extender Kit
3. System Requirement for Installation
3.1 Hardware requirements
1) A HDMI source and display is required, supporting the graphic resolution of the
HDMI 2.0 Fiber Extender Kit.
2) No special requirements for memory size, CPU speed and chipsets are needed,
assuming the HDMI graphic controllers or cards have already been properly
installed.

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 6
3.2 Software requirements
No special restrictions, considering that the HDMI graphic controller and OS have
already been properly installed.
3.3 AC/DC Power Adapter (Technical Advisory)
The included power supply adaptors and USB cables can provide power to both the
Transmitter and Receiver. Although the HDMI interface of the source typically provides
5VDC on pin #18 of the HDMI connector, the USB power supply option is recommended
as a more stable power source for the Transmitter.
4. System Connection
4.1 Safety Precautions
This system should be installed in a clean environment with temperature and
humidity within the specified operating levels (see the specifications table).
4.2 System Diagram

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 7
4.3 Connection Procedure
a) Connect the Transmitter to the source equipment (such as a Blu-Ray Player), and
connect the Receiver to the sink equipment (such as a display). Connect the USB
Power Supply to the Receiver. Power on the HDMI source and display. The
Transmitter will be turned on due to the 5V supplied by pin #18 of HDMI interface
of the source. Even though the units are being powered, it is recommended that
the USB Power Supply be used as well for a more stable power source for the
Transmitter, since some sources may not be capable of providing sufficient power.
b) The Power LED will illuminate when the 500464 is connected to the HDMI
interface of the source and display, and the Status LED will blink three (3) times.
After which the Status LED will blink again once a reliable link is established with
the end equipment.
c) Connect an LC terminated duplex optical fiber between the Transmitter and
Receiver, where each of the individual fibers are connected as (A) to (A) and (B) to
(B). Ensure the duplex connectors are fully inserted and the top LED will begin to
blink.
Position of the LEDs

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 8
Note1: DO NOT look directly into the LC receptacles of the Transmitter, while it is
powered on, even though this product is strictly regulated to operate under
LASER Class I, classified by CDRH/FDA for eye safety.
Note2: Units support an extension distance up to 100m using OM3 multimode fiber.
Note3: Do not make use of any intermediate cable or adapter between these units or
between these units and the end equipment to avoid any undesirable
performance degradation.
a) Connect the Transmitter directly to the HDMI connector of the source.
b) Connect the Receiver directly to the HDMI connector of the display.
c) These units should be connected together with a single length of duplex
multimode fiber cable meeting the spec herein, while ensuring that the
optical LC connector end-faces are clean.
d) To ensure proper connectivity, confirm that the Status LEDs on both the
Transmitter and Receiver are ON.

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 9
5. Troubleshooting & Maintenance
The following section describes some of the symptoms, probable causes and possible
solutions in regard to the installation of the 500464 HDMI 2.0 Fiber Extender Kit.
The display only shows a blank (black) screen.
- Ensure that the USB power supplies are firmly connected and that both Transmitter
and Receiver Power LEDs are ON.
- Ensure that the HDMI connectors are firmly plugged into the HDMI connector of the
source and display.
- Ensure that the Transmitter and Receiver modules are plugged in the correct order
to the source and display, respectively (reversing the order will not work).
- Check if the source and display are powered on.
- Ensure that the duplex fiber is properly inserted into both the Transmitter and
Receiver.
- Reset the system by disconnecting and reconnecting the Transmitter HDMI or
Receiver HDMI side units, or by disconnecting and reconnecting the USB power
cables that are plugged in the Transmitter and Receiver modules.
- If necessary try to re-boot the system and re-connect the HDMI 2.0 Fiber Extender
Kit.
Screen is distorted or the display is noisy.
- Check if the graphic resolution is properly set. Go to the display properties and
confirm the settings.
- Ensure that the resolution is set to a maximum of 4K (4096x2160) at 60Hz refresh
ratio.
- Reset the system.
- Disconnect and reconnect the HDMI Fiber Extender Kit units or their power supply
adapters.
If you still cannot diagnose the problem, please call MuxLab Customer Technical
Support at 877-689-5228 (toll-free in North America) or ([phone]
(International).

HDMI 2.0 Fiber Extender Kit Installation Guide
© MuxLab Inc. 2017 10
Maintenance
No special maintenance is required for the HDMI 2.0 Fiber Extender Kit and power
adapters. Ensure that the HDMI modules and power adapters are stored or used in an
environment free from high humidity or dust/dirt contamination.
There are no user serviceable parts inside these units. Refer all service and repair
issues to MuxLab.
Technical Support and Service
For commercial or general product support, contact your reseller. For technical service,
contact MuxLab by email [email protected] or visit MuxLab’s website at
www.muxlab.com
Certification of Eye Safety
This laser component is using the following wavelength: 825, 850, 930, 980, 990nm LD
Transceivers, which are all certified by CDRH/FDA referred as classified in Laser Class
1 (IEC60825-1).
Caution –Use of controls, adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
