SC&T VKM03 User manual

VGA & USB, AUDIO, RS232, IR CAT5 Extender
ITEM NO.: VKM03 VGA & USB with Stereo Audio, RS232, IR CAT5 Extender
The VKM03 VGA, USB with Stereo Audio, RS232, and IR CAT5 extender design for extends all signals
over one CAT5 up to 140 meters, with local VGA monitor output. It provides superior video quality up
to 1920 x 1080 resolutions, and using cost effective Cat5e cable, instead of VGA, audio, RS232 cables,
for an easy, neater and reliable installation. It is optimized for applications at digital signage, home
network integration, and industrial control, security, and KVM extension.
Features:
Extend VGA, stereo audio, RS232, IR and USB signals over one CAT5E/CAT6 cable.
USB port support USB 2.0, USB 1.0 & USB 1.1
Full Duplex data communication.
Transmitter unit built in VGA loop output.
Receiver unit with 4 ports USB devices, to extend USB 2.0 peripheral devices, such as flash disk,
hard disk, keyboard, mouse, etc.
Supports up to 1920 x 1080.
Transmission range up to 140 meters.
Plug and play for easy operation.
Perfect for control remote machines and security monitoring systems, digital signage application.
Optional model: SR01 signal repeater for longer distance application.
Panel View:
Transmitter
Receiver
Installation View:

2
Optional Model: SR01 Signal Repeater (order separately)
Extend data signal for an additional 120meters.
Application for VKM03 signals for extra long range transmission.
Ability to cascade connection with multiple SR01 for long range transmission
Built in LED status indication.
External power required.
Plug and play for easy installation.
Work with VKM03 CAT5 Extender:
RJ45 Define:
Link Cable ( TIA/EIA-568-B )
1. Orange-white Data 1 +
2. Orange Data 1 -
3. Green-white Data 2 +
4. Blue Data 3 +
5. Blue-white Data 3 -
6. Green Data 2 -
7. Brown-white Data 4 +
8. Brown Data 4 -
LED Indication Status:
Power On (power )
Link Flash ( under linking )
On ( linking )
RJ45 Green Flash (Data transmission )
Orange On (linking)
Note: IR receiving angle ±55degree, emitting angle 30degree，distance reach to 3-5 meters.
Video Link cable using high quality CAT5E UTP/STP/FTP or CAT6 UTP cable.
Specification:
ITEM NO. VKM03T VKM03R
Support Resolution Up to 1920 x 1080 @ 85 Hz
Transmission Distance Up to 140 (Max)
Video Input Signals RGB Analog (75Ω, 0.7Vp-p) Sync Signal H/V Separated (TTL)
VGA Connector DB15 Female x 2 DB15 Female x 1
USB Connector
USB B-Type x 1
USB A-Type x 4
RS232 Connector
DB9(Female) x 1
DB9(Male) x 1
Audio Connector
3.5 mm Phone Jack x1
IR Connector
3.5 mm Phone Jack x1
Built-in
Link Connector RJ45 x 1
Power Supply
DC 5V 2 Amp
Power Consumption 1.1Amp
Temperature Operation: 0 to 55℃, Storage: -20 TO 85℃, Humidity: up to 95%
Dimensions mm 125 x 120.5 x 30
Weight g
335
330
Rev. B
