Sauber SC-171 User manual

Para su seguridad y uso correcto, antes de instalar y utilizar el aparato por
primera vez, lea este manual cuidadosamente. Para evitar errores y
accidentes innecesarios, es importante asegurar que todas las personas que
utilizan el aparato se familiaricen con sus características de operación y
seguridad. Guarde estas instrucciones.
Para que el aparato funcione correctamente, recuerde las precauciones de
estas instrucciones .
INSTALACIÓN
-La temperatura ambiental repercute fuertemente en el consumo de corriente
eléctrica, por lo tanto el aparato no debe estar expuesto directamente a los
rayos solares , ni situado al lado de fuentes de calor
como radiadores, estufas, cocinas,.....
- Este aparato no se debe instalar al aire libre, ni siquiera en caso de que el
espacio esté protegido por una marquesina; es muy peligroso dejarlo
expuesto a lluvia, tormentas o intemperie.
- El aparato és pesado. Se deberá tener cuidado al moverlo.
- Aconsejamos esperar por lo menos una hora antes de conectar el aparato
para que el aceite del circuito refrigerante tenga el tiempo necesario para ser
perfectamente eficiente.
-Si el cable de la corriente está dañado, éste debe ser reemplazado por
personal técnico qualificado. Asegurarse de que el aparato no esté apoyado
en el cable de alimentación.
- Se aconseja no utilizar prolongaciones ni enchufes múltiples para
conectarlo a la red de alimentación.
-El enchufe debe ser accesible.
-La falta de circulación adecuada de aire, puede causar sobrecalentamiento.
- Prestar atención para no causar daños a las tuberías del circuito de
enfriamiento mientras se coloca, instala o limpia.
- Comprobar que en proximidad de las aberturas de ventilación no se hayan
instalado aparatos o componentes eléctricos. (p. ej. ventiladores,
interruptores, enchufes, etc.).
- No coloque objetos sobre su frigorífico. Si se coloca junto a armarios de
cocina, ponga atención para dejar un espacio libre de 2 cm entre ellos.

SEGURIDAD PARA NIÑOS Y OTRAS PERSONAS
VULNERABLES
-Este aparato puede ser utilizado por los niños desde los 8 años y personas
con capacidades reducidas físicas, sensoriales o mentales o falta de
experiencia y conocimiento si ellos han sido dados la supervisión o
instrucción sobre el uso del aparato en una manera segura y entienden los
peligros involucrados. Los niños no deberán jugar con el aparato.
La limpieza y el mantenimiento del usuario, no deben ser llevados a cabo por
los niños sin supervisión.
- No permitir que los niños jueguen con el aparato. Por ejemplo si se sientan
en las cestas, se columpian o se agarran a la tapa, el congelador podría
volcarse o bien podrían caer los objetos colocados encima de él
SEGURIDAD
- Este aparato está destinado a uso no comercial.
- El aparato debe usarse exclusivamente para conservar y/o congelar
alimentos o bebidas.
- Este aparato está diseñado para ser utilizado en el hogar y aplicaciones
similares tales como:
Áreas de cocina de personal en tiendas, oficinas y otros entornos de
trabajo..
Casas de la granja y por los clientes en hoteles, moteles y otros
entornos de tipo residencial
Entornos de tipo cama y desayuno
Catering y aplicaciones similares no comerciales.
- No dañe el circuito refrigerante
- No usar aparatos eléctricos dentro del frigorífico.
- Para evitar situaciones de peligro debido a la inestabilidad del aparato, debe
instalarse en una superficie estable y plana, regulando los pies de nivelación.
- Para evitar la caída de objetos o causar lesión o daño al aparato, no
sobrecargue los estantes en la puerta ni coloque demasiados alimentos en los
cajones de verdura.
- Nunca se mantenga de pie sobre la base, los cajones, las puertas… ni los
utilice como soportes.
- No almacene sustancias gases o líquidos inflamables tales como latas de

aerosol, sprays .., . Hay riesgo de explosion.
- El refrigerante y el gas de soplo de aislamiento son inflamables. Al
desechar el aparato, sólo hágalo en un centro autorizado de desecho de
basuras. No lo exponga a la llama.
- No utilice dispositivos mecánicos u otros medios para acelerar el proceso
de descongelación.
- Mantenga todos los embalajes apartados de los niños ya que hay riesgo de
asfixia.
- Si va a desechar el aparato, quite la puerta para evitar que los niños jueguen
con ella
- Durante el desenchufe, siempre tire del enchufe macho desde la toma
corriente, no tire del cable.
- Antes de llevar a cabo cualquier operación de limpieza o mantenimiento,
desenchufar el aparato o apagar el interruptor principal de la red de
alimentación.
- Al descongelar el aparato no utilizar nunca objetos metálicos para acelerar
el proceso. El incumplimiento de dicha advertencia podría causar daños
irreparables al circuito refrigerante.
NOTA: Cualquier mantenimiento, incluido la eventual substitución del cable
de alimentación debe ser efectuado por el servicio de asistencia técnica o por
personal calificado. De lo contrario, el usuario puede correr serio peligro
USO EFICIENTE DEL APARATO
Consejos Para minimizar el consumo de energía
-No coloque el aparato junto a radiadores, calefactores, estufas o bajo la luz
solar directa.
-Asegúrese de que las salidas de aire no están cubiertas y limpiar el polvo de
una o dos veces al año.
-Seleccione la temperatura adecuada: 6 a 8 ° C en el frigorífico y -18 ° C en
el congelador es suficiente.
-En sus vacaciones, suba la temperatura en su refrigerador.
-Sólo abrir la nevera o en el congelador cuando sea necesario. Sirve de ayuda
si usted sabe qué alimentos contienen cada uno y dónde se encuentra. Volver
comida a la nevera o en el congelador tan pronto como sea posible después
de haber utilizado de modo que no se calienta demasiado.
-Limpie el interior de su refrigerador con un paño empapado en un
detergente suave. Los aparatos que no están de descongelación automática
requerirán descongelación regular. No permita que las capas heladas de
mayor espesor de 10 mm a la forma.
-Mantenga el sello alrededor de la puerta de limpieza, de lo contrario no se

cierra correctamente. Siempre vuelva a colocar sellos rotos.
Comprensión de las estrellas
*La temperatura es al menos -6 ° C; suficiente para almacenar los alimentos
congelados durante aproximadamente una semana.
** La comida puede ser almacenado a -12 ° C o menos durante 1-2 semanas
sin perder su sabor. No es apto para la congelación de alimentos.
*** Esta calificación se utiliza principalmente para almacenar los alimentos
a -18 ° C o menos. También puede ser utilizado para congelar hasta 1
kilogramo de alimentos frescos.
**** Este aparato es adecuado para el almacenamiento de alimentos a -18 °
C o menos y congelar grandes cantidades de alimentos frescos.
Zonas de frío
*Zonas de almacenamiento en el refrigerador
-Debido a la circulación natural del aire en el aparato, existen diferentes
zonas de temperatura en la cámara de refrigerador.
a)La zona más fría es justo encima de los cajones de verduras. Utilice
esta área para todos los alimentos, por ejemplo:
El pescado, la carne, las aves de corral
Salchicha
Comidas preparadas
Los platos o productos horneados que contienen huevos o crema
Pasta fresca,
Verduras y otros alimentos frescos preenvasados con una etiqueta
que indique que debe mantenerse a una temperatura de 4 ° C
aprox.
b)El área más caliente está en la sección superior de la puerta. Utilice
esto para almacenar la mantequilla y el queso.
NOTA: Alimentos que no se deben almacenar en un refrigerador:
-Las frutas y verduras que son sensibles al frío, como los plátanos,
aguacate, papaya, maracuyá, berenjenas, pimientos, tomates y
pepinos.
- La fruta que aún no está maduro
- Patatas
*Zonas de almacenamiento en el congelador:
a)Congelar preferentemente grandes cantidades de alimentos frescos
en el compartimento superior. De este modo los alimentos se congelan
de modo especialmente rápido.
Colocar los alimentos distribuyéndolos uniformemente en los cajones de
congelación.

Los productos ya congelados no deberían entrar en contacto con los
alimentos frescos que se desean congelar.
NOTA: cerciorarse que el cajón de congelación esté introducido a tope
USO DIARIO
- No tocar ni manejar nunca el aparato con los pies descalzos ni con manos o
pies mojados.
- Almacene los alimentos congelados pre-empaquetados de acuerdo con las
instrucciones del fabricante de alimentos congelados.
- No mueva ni toque los productos del compartimento congelador si sus
manos están mojadas, ya que puede causar abrasiones en la piel.
- Los alimentos congelados pueden causar quemaduras por congelación si
son consumidos directamente desde el compartimento congelador.
- No consuma los helados o cubitos de hielo directamente desde el
congelador ya que eso puede causar quemadura a la boca y los labios por el
congelador.
- Los alimentos congelados no deben ser recongelados una vez que hayan
sido descongelados
- No coloque las bebidas carbonatadas o gaseosas en el compartimento de
congelación ya que crea presión en el contenedor, que puede causar su
explosión, resultando dañado el aparato.
- No meter en la sección de baja temperatura botellas o contenedores de
cristal, porque podrían agrietarse o romperse cuando el contenido se congela.
- No consumir alimentos cuya fecha de conservación esté caducada puesto
que podrían ser causa de intoxicación.
R600a (ISOBUTANO)
El isobutano está dentro del circuito de refrigerante. Es un gas natural
que no tiene repercusiones para el medioambiente pero es inflamable.
Resulta por lo tanto indispensable, antes de conectar el aparato a la red de
alimentación, asegurarse de que no esté dañado ninguno de los tubos del
circuito refrigerante. La cantidad de refrigerante consta en la tarjeta de datos
técnicos situada en la parte posterior del aparato.
En caso de pérdida del refrigerante:
-Evite llamas y fuentes de encendido.
-Ventile la habitación donde se ubica el aparato.
INFORMACIONES INHERENTES AL
MEDIOAMBIENTE

Este aparato se ha marcado de acuerdo con la Directiva Europea
2002/96/CE referente a la eliminación de los Desperdicios de Aparatos
Eléctricos y Electrónicos
(RAEE). El símbolo del cajón tachado que consta en el aparato indica que
el producto al final de su vida útil no se debe tratar como basura doméstica
normal, sino que se debe llevar a los centros de recogida diferenciada de
desperdicios eléctricos y electrotécnicos o bien entregar al revendedor en el
momento de comprar un nuevo aparente de tipo equivalente. La adecuada
recogida diferenciada de este aparato contribuye a evitar posibles
repercusiones negativas para el ambiente o la salud de las personas, que
podrían producirse a causa de un incorrecto tratamiento de este producto. La
eliminación debe hacerse respetando los reglamentes medioambientales
locales vigentes. Para informaciones más detalladas inherentes al tratamiento,
la eliminación o el reciclado de este producto, rogamos contacten el servicio
local de eliminación de desechos o a la tienda en que compró el aparato. No
tirar el embalaje del aparato a la
basura sino seleccionar los diversos materiales como poliestireno, cartón,
bolsas de plástico, etc. De acuerdo con las normas locales sobre la
eliminación de basuras y las normas vigentes. Este aparato
carece de HFC (el circuito refrigerante contiene R600a -ISOBUTANO.)
Descripción general del producto
La capacidad neta del congelador (litros) ha sido testado sin los cajones del congelador.
1-Termostato

2-Luz interna
3-Estantes
4-Botellero
5-Verdulero
6-Bandeja para huevos.
7-Cajones congelador
8-Patas ajustables
UTILIZACIÓN
-Limpiar con agua tibia con un poco de detergente neutro y secar bien con un trapo. Las partes
eléctricas solo se pueden secar con un trapo seco.
-Conectar el aparato a la toma de corriente no antes de 4 horas, después de haberlo movido.
-Gire el termostato a la posición “3”. El compresor empieza a funcionar.
-No coloque comida antes de 24 horas.
-Ajuste la temperatura mediante el termostato que va desde la posición “0” (OFF) a la “7” que és la
temperature más fria possible. Probablemente la posición más habitual sea “4”
-Congelación rápida. Gire el termostato a la posición “7” antes de añadir la comida. Posteriormente
vuelva a la posición “4”.
Instrucciones generales Mantenimiento
El frigorífico debe ser limpiado cada mes, teniendo en cuenta de desconectarlo de la
corriente antes de hacerlo.
Limpiar el interior y exterior del aparato con un trapo seco.
Si está demasiado sucio, limpiar con un trapo humedecido con detergente neutral y agua
limpia, después secarlo con un trapo seco.
Si usted no va utilizar el aparato durante un periodo largo de tiempo, proceder como sigue:
*Desconectar el frigorífico de la corriente eléctrica.
*Quitar la comida.

*Limpiar el interior del aparato.
*Dejar las puertas abiertas para prevenir malas olores
DESCONGELACIÓN
Después de un periodo largo de utilización, aparece hielo en las superficies del evaporador. Esto reduce
el efecto frigorifico e incrementa el consumo de energía. En este caso, se debe descongelador el
frigorifico. Nunca se debe usar materiales punzantes para agilizar el proceso de descongelación::
1. Desconecte el aparato de la corriente, quite la comida y deje la puerta abierta.
2. Limpie el aparato.
3. Vuelva a conectar el aparato a la corriente eléctrica
ANTES DE LLAMAR A UN TÉCNICO (comprobar)
No funciona
-El aparato no está correctamente conectacdo a la corriente eléctrica..
Demasiado frio o demasiado calor
-El termostato no está en la posición correcta.
Aparece condensación en el exterior del aparato.
-Puede ser debido a un cambio en la temperature de la habitación. Si el problema continua,
póngase en contacto con un técnico cualificado.
Ruido
-Comprobar que el aparato está nivelado y que no está en contacto con la pared.
No enfría
-La puerta se ha quedado abierta demasiado tiempo.
-Hay demasiada comida en el frigorífico
-La temperatura no está correctamente regulada.
NOTA: los siguientes síntomas no son fallos del frigorífico:
-El refrigerante circulando por los tubos hacen un ligero ruido
-El compressor se calienta en verano durante la operación de congelación
*Si su aparato ofrece otros síntomas no descritos anteriormente, debe llamar a un técnico cualificado.
CAMBIO BOMBILLA INTERNA
1. Gire el termostato a la posición “0”. Desconecte el aparato de la corriente eléctrica.
2. Quite la cubierta de la bombilla.
3. Quite la bombilla.
4. Coloque la nueva bombilla (10W)
5. Coloque la tapa y vuelva a conectar el aparato a la corriente eléctrica.
.

Este aparato está diseñado y fabricado con materiales y
compenentes de alta calidad,
que pueden ser reciclados y
reutilizados.
Este símbolo significa que el equipo electrico y electrónico, al
final de su ciclo de vida, no se debe desechar con el resto de
residuos domésticos.
Por favor, deposite su Viejo electrodoméstico en el punto de
recogida de residuos o contacte con su administrador local.
En la Unión Europea existen sistemas de recogida
especificos para residuo
s de aparatos eléctricos y
electrónicos.

SAFETY
WARNING!
It is hazardous for anyone other than authorized service personnel to carry out servicing or repairs which involves the
removal of covers. To avoid the risk of an electric shock do not attempt to repair this appliance yourself.
WARNING!
Risk of fire / flammable materials.
Safety tips
Do not use electrical appliances such as a hair dryer or heater to defrost your Fridge/Freezer.
Containers with flammable gases or liquids can leak at low temperatures.
Do not store any containers with flammable materials, such as spray cans, fire extinguisher refill cartridges etc. in the
Fridge/Freezer.
Do not place carbonated or fizzy drinks in the Freezer compartment. Ice lollies can cause “Frost/Freeze burns”. If
consumed straight from the Fridge/Freezer.
Do not remove items from the Fridge/Freezer compartment if your hands are damp/wet, as this could cause skin
abrasions or “Frost/Freezer burns”. Bottles and cans must not be placed in the Freezer compartment as they can burst
when the contents freeze.
Manufacturer’s recommended storage times should be adhered to. Refer to relevant instructions.
Do not allow children to tamper with the controls or play with the Fridge/Freezer. The Fridge/Freezer is heavy. Care
should be taken when moving it. It is dangerous to alter the specification or attempt to modify this product in any way.
Do not store inflammable gases or liquids inside your Fridge/Freezer.
If the power cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
This appliance is intended to be used in household and similar applications such as
·staff kitchen areas in shops, offices and other working environments;
·farm houses and by clients in hotels, motels and other residential type environments;
·bed and breakfast type environments;
·catering and similar non-retail applications.
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by
the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of type
recommended by the manufacturer.
Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play
with the appliance.
– WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
– WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
– WARNING: Do not damage the refrigerant circuit.
– WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of
the type recommended by the manufacturer.
– WARNING: Refrigerating appliances – in particular a refrigerator-freezer Type I – might not operate consistently
(possibility of defrosting of contents or temperature becoming too warm in the frozen food compartment) when sited for an
extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed;
– WARNING: The necessity that, for doors or lids fitted with locks and keys, the keys be kept out of the reach of children
and not in the vicinity of the refrigerating appliance, in order to prevent children from being locked inside.
– WARNING: The refrigerant used in your appliance and insulation materials requires special disposal procedures.
– WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
– WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
To avoid contamination of food, please respect the following instructions:
– Opening the door for long periods can cause a significant increase of the temperature in the
compartments of the appliance.
–Clean regularly surfaces that can come in contact with food and accessible drainage systems.
– Clean water tanks if they have not been used for 48 h; flush the water system connected to a water supply if water has
not been drawn for 5 days.
– Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or
drip onto other food.
– Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice-
cream and making ice cubes.
– One-, two- and three-star compartments are not suitable for the freezing of fresh food.
– If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.
Locks
If your Freezer is fitted with a lock, to prevent children being entrapped keep the key out of reach and not in the vicinity of
the appliance. If disposing of an old Freezer break off any old locks or latches as a safeguard.
INTRODUCTION
BCD-230
INSTALLATION
Location
When selecting a position for your Fridge/Freezer you should make sure the floor is flat and firm, and the room is well
ventilated. Avoid locating your Fridge/Freezer near a heat source, eg, cooker, boiler or radiator. Also avoid direct sunlight
in out-buildings or sun lounges. If you are placing your Fridge/Freezer in an out-building such as a garage or annex
ensure that the Fridge/Freezer is placed above the damp course, otherwise condensation will occur on the Fridge/Freezer
cabinet. When working, the refrigerator gives off heat to surroundings. Therefore, at least 300mm of free space should be
spared at the top side, more than 100mm on both sides, and above 50mm at the back side of the refrigerator.
Leveling the Freezer
If the Freezer is not level, the door and magnetic seal alignment will be affected and may cause you Freezer to work
incorrectly. Once the Freezer is placed in its final location, adjust the leveling feet at the front by turning them.
No Description
1 Thermostat control dial
2 Internal light
3 Refrigerator Shelf
4 Salad Crisper
5 Egg tray
6 Bottle storage
7 Freezer draws
8 Adjustable Foot

Cleaning before use
Wipe the inside of the Freezer with a weak solution of bicarbonate of soda. Then rinse with warm water
using a damp sponge or cloth. Wash the baskets and shelves in warm soapy water and dry completely
before replacing in the Freezer. The external parts of the Freezer can be cleaned with wax polish.
Before plugging in YOUMUST
Check that you have a socket which is compatible with the plug supplied with the Freezer. Before
switching on!
DO NOT SWITCH ON UNTIL FOUR HOURS AFTER MOVING THE FREEZER.
The coolant fluid needs time to settle. If the appliance is switched off at any time, wait 30 minutes before
switching back on to allow the coolant fluid to settle.
Before filling your Freezer
Before storing foods in your Freezer, turn the Freezer on and wait for 24 hours, to make sure it is working
properly and to allow the Freezer to fail to the correct temperature.
Switching on your Fridge/Freezer
1 Before connecting the Fridge/Freezer to the mains supply position. TheThermostat control dial is
located inside the Fridge compartment.
2 Turn the thermostat knob to the“3”position and turn on electricity. Thecompressor and the light inside
the refrigerator will begin to work.
3 Wait 24 hours before placing food into the Fridge/Freezer, thetemperature inside your Fridge/Freezer
will then be cool enough to chill and freeze foods sufficiently.
Adjusting the temperature
The temperature in the refrigerator and freezer compartment is controlled by the temperature controller
installed on the inside wall of the refrigerator compartment. We strongly recommend you use a freezer
thermostat to check that the temperature is below -18 centigrade before loading any food. This can take 2
- 3 hours.
2. The marks on the knob are the temperature grades, NOT the exact degrees of temperature. “0”is
“OFF”and “7”represents the lowest
temperature.
3. Please start with the knob set to position“4”. Use a suitable thermometer to check the temperature
after two hours. The
refrigerator temperature should be set between +2ºC and +5ºand the freezer will vary between -18 and
-25 degrees centigrade over a typical cycle. To reduce the refrigerator temperature turns the knob
towards“7”and check after one hour.
NOTE: The Fridge/Freezer may not operate at the correct temperature if it is in a particularly hot or cold
room or if you open the Fridge/Freezer door too often.
Fast Freeze
1. Fast freezing makes water in the food form into fine ice crystal, so as to prevent the cell membrane
from being damaged and the cytoplasm from being lost when thawing, thus preserving the original
freshness and nutrition of food.
2. Fresh food and fish to be preserved for a long time should be frozen in a fast manner. To realize fast
freezing, please adjust the knob switch to mode "7" before adding the food.
3. After fast freezing, turn the knob back to its original mode (In general, the fast freezing time shall not
exceed 4 hours).
IN USE
1. The appliance might not operate consistently (possibility of defrosting of contents or temperature
becoming too warm in the frozen food compartment) when sited for an extended period of time below the
cold end of the range of temperatures for which the refrigerating appliance is designed
2. The fact that the internal temperatures could be affected by such factors as the location of the
refrigerating appliance, ambient temperature and the frequency of door opening, and, if appropriate, a
warning that the setting of any temperature control device might have to be varied to allow for these
factors
3. The fact that effervescent drinks should not be stored in food freezer compartments or cabinets or in
low-temperature compartments or cabinets, and that some products such as water ices should not be
consumed too cold
4.The need to not exceed the storage time(s) recommended by the food manufacturers for any kind of
food
5. The fact that a rise in temperature of the frozen food during manual defrosting, maintenance or
cleaning could shorten the storage life
6. It is better wrapping the frozen food in several layers of the glass shelves.
7. the care required with regard to frozen food in storage in the event of an extended non-running of the
refrigerating appliance (interruption of power supply or failure of the refrigerating system)
Tips for keeping food perfect in the Fridge

Take extra care with meat and fish
Cooked meats should always be stored on a shelf above raw meats to avoid bacterial transfer. Keep
raw meats on a plate which is large enough to collect juices and cover it with cling film or foil.
Leave space around food
This allows cold air to circulate around the Fridge, ensuring all parts of the Fridge are kept cool.
Wrap up food!
To prevent transfer of flavors and drying out, food should be separately packed or covered. Fruit and
vegetables need not be wrapped.
Pre-cooked food should be cooled properly
Allow pre-cooked food to cool down before placing in the Fridge. This will help to stop the internal
temperature of the Fridge from rising.
Shut the door!
To prevent cold air escaping, try to limit the number of times you open the door. When returning from
shopping, sort foods to be kept in your Fridge before opening the door. Only open the door to put food in
or take it out.
Recommended storage periods
For recommended food storage time, refer to the information given on your food packaging.
Tips for shopping for frozen foods
Your Freezer is 4 star
When you are buying frozen food, look at the Storage Guidelines on the packaging. You will be able to
store each item of frozen food for the period shown against the 4 star rating. This is usually the period
stated as “Best, Before”, found on the front of the packaging.
Check the Fridge/Freezer temperature
Check the temperature of the frozen food cabinet in the shop where you buy your frozen foods. It should
show a temperature lower than -18℃.
Choose packs carefully
Make sure the frozen food package is in perfect condition.
Purchase frozen food last Always buy frozen products last on your shopping trip or visit to the
supermarket.
Keep frozen foods together
Try to keep frozen food together whilst shopping, and on the journey home as this will help to keep the
food cooler.
Store food straight away
Don’t buy frozen food unless you can freeze it straight away. Special insulated bags can be bought from
most supermarkets and hardware shops. These keep frozen food cold for longer.
Thawing frozen foodFor some foods, thawing before cooking is unnecessary. Vegetables and pasta can
be added directly to boiling water or steam cooked. Frozen sauces and soups can be put into a
saucepan and heated gently until thawed.
Freezing fresh foods, useful tips
Use quality food and handle it as little as possible. Freeze food in small quantities, it freezes faster,
takes less time to thaw and enables you to eat it in the quantity you need.
Freezing fresh foods
First, estimate the amount of food you will be freezing. If you are freezing large amounts of fresh food,
remember to turn the control dial to Max. This will lower the temperature in the Freezer (approx -30℃),
freezing your food quicker and helping to keep the goodness in. However you should do this sparingly to
conserve energy.
Preparations for freezing
·Leave cooked food to cool completely.
·Chill food in a Fridge before freezing if possible.
·Consider how you want to cook the food before freezing it.
·Don’t freeze food in metal containers as you may want to microwave it straight from the Freezer.
·Use special Freezer bags available from supermarkets, Freezer film, polythene bags, plastic containers,
aluminum foil for acidic foods(such as citrus fruits).
Do not use thin cling film or glass. Do not use used food containers (unless cleaned thoroughly first).
·Exclude as much air from the container as possible. You could buy a special vacuum pump which sucks
excessive air out of the packaging.
·Leave a small amount of “air space” when freezing liquids, to allow for expansion.
·You can use the space in the Freezer most efficiently if you freeze liquids(or solids with liquids,
such as stew) in square blocks.
This is known as “performing” Pour the liquid into a polythene bag which is inside a square
sided container. Freeze it like this, then remove it from the container and seal the bag.
Where to store your foods in the fridge
Cool area：
This is where to store foods which will keep longer if they are kept cool. Milk, eggs, yogurt, fruit

juices, hard cheeses eg. Cheddar. Opened jars and bottles of salad dressings, sauces and jams. Fats, eg.
Butter, margarine, low-fat spreads, cooking fats and lard.
Coldest area:
This is where foods which must be cold to keep them safe should be kept:
·Raw and uncooked foods should always be wrapped.
·Pre-cooked chilled foods, eg. Ready meals, meat pies, soft cheeses.
·Pre-cooked meats eg. Ham,
·Prepared salads(including pre-packed mixed green salads, rice, potato salad etc).
·Desserts, eg. Fromage frais, home-prepared food and leftovers or cream cakes.
NOTE：Always wrap and store raw meat, poultry and fish on the lowest shelf at the bottom of the fridge.
This will stop them dripping onto, or touching other foods. Do not store inflammable gasses or liquids in
the fridge.
Recommended storage periods
For recommended food storage time, refer to the information given on your food packaging.
Defrosting
After a period of time frost will build up in certain areas in the Fridge/Freezer compartment. As a
temporary measure, this frost should be scraped away using a plastic scraper. NEVER use a metal or
sharp instrument. Complete defrosting will however become necessary approximately once per year, or
if the frost layer exceeds 5mm to maintain the efficiency of the Fridge/Freezer. This should be carried
out if the frost build-up cannot be scraped away, or if it begins to interfere with the food storage. Chose a
time when the stock of frozen food is low and proceed as follow:
4. Take out the frozen food, turn the Fridge/Freezer off at the mains supply and leave the doors open.
Ideally the frozen food should be put into another Fridge/Freezer or refrigerator. If this is not possible
wrap the food, firstly in several sheets of newspaper or large towels and then in a thick rug or
blanket and keep it in a cool place.
5. Scrape away as much frost build-up as possible using the plastic scraper. To accelerate the thawing
process place bowls of hot water inside the Fridge/Freezer cabinet. As the solid frost loosens, prize
it away with the plastic scraper and remove.
6. When defrosting is completed, clean your Fridge/Freezer as described.
Cleaning inside the Fridge/Freezer
After defrosting you should clean the Fridge/Freezer internally with a weak solution of bicarbonate of
soda. Then rinse with warm water using a damp sponge or cloth and wipe dry. Wash the baskets in
warm soapy water and ensure they are completely dry before replacing in the Fridge/Freezer.
Condensation will form on the back wall of the Fridge; however it will normally run down the back wall
and into the drain hole behind the salad bin.
The drain hole will have a “cleaning spike” inserted into it. This ensures that small pieces off food can not
enter the drain. After you have cleaned the inside of your Fridge and removed any food residues from
around the whole, use the “cleaning spike” to make sure that there are no blockages.
Cleaning outside the Fridge/Freezer
Use standard furniture polish to clean the Freezer exterior. Make sure that the doors are closed to
prevent polish getting on the magnetic door seal or inside.
The grille of the condenser at the back of the Freezer and the adjacent components can be vacuumed
using a soft brush attachment.
Do not use harsh cleaners, scouring pads or solvents to clean any part of the Freezer.
Vacation Time
Turn off the refrigerator first and then unplug the unit from the wall outlet.
Remove all the food.
Clean the refrigerator.
Leave the lid open slightly to avoid possible formation of condensation, mold, or odors.
Use extreme caution in the case of children. The unit should not be accessible to child’s play.
Short vacations: Leave the refrigerator operating during vacations of less than three weeks.
Long vacations: If the appliance will not be used for several months, remove all food and unplug the
power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door
open slightly: blocking it open if necessary or have the door removed.
TROUBLESHOOTING AND MAINTENANCE
Trouble Shooting
Power cut
If the internal temperature of the Freezer compartment is -18℃or less when the power returns, your
food is safe. The food in your Freezer will remain frozen for approx 16 hours with the door closed. Do not
open the Freezer door more than necessary.
The Freezer is exceptionally cold
You may have accidentally adjusted the thermostat control dial to a higher position.
The Freezer is exceptionally warm
The compressor may not be working. Turn the thermostat control dial to the maximum setting and wait a

few minutes. If there is no humming noise, it is not working. Contact the local store where your purchase
was made.
The Freezer is not working
Check it is plugged in and switched on. Check that the fuse in the plug has not blown. Plug
In another appliance, such as a lamp, to see if the socket is working. Leave the Freezer for 30 minutes.
Condensation appears on the outside of the Freezer
This may be due to a change in the room temperature. Wipe off any residue of moisture. If the problem
continues contact the local store where your purchase was made.
Noises inside the Freezer
If you have not owned a Freezer before, you may notice that it makes some rather unusual noises. Most
noises are perfectly normal; however you should be aware of them!
GURGLING, WHOOSHING
These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has become
more pronounced since the introduction of CFC free gases. This is not a fault and will not affect the
performance of your Freezer.
HUMMING, PURRING OR PULSATING
This is the compressor motor working, as it pumps the refrigerant around the system.
Moving the Freezer
Location
Do not place your Freezer near a heat source, eg. Cooker, boiler or radiator. Also avoid direct sunlight in
out-buildings or sun lounges.
Leveling the Freezer
Make sure the Freezer is level. Use the rotating leveling feet at the front. If the Freezer is not level, the
doors and magnetic seal alignments will be affected and may cause your Freezer to work incorrectly.
Do not turn on the Freezer for 4 hours
After the Freezer is in place it needs to be left for 4 hours. This allows time for the coolant to settle.
Installation
Don’t cover or block the vents or grilles of your appliance.
m your local electrical sore and then fit it. Carefully dispose of the burnt-out light bulb immediately.
Vacation Time
•Turn off the refrigerator first and then unplug the unit from the wall outlet.
•Remove all the food.
•Clean the refrigerator.
•Leave the lid open slightly to avoid possible formation of condensation, mold, or odors.
•Use extreme caution in the case of children. The unit should not be accessible to child’s play.
•Short vacations: Leave the refrigerator operating during vacations of less than three weeks.
•Long vacations: If the appliance will not be used for several months, remove all food and unplug the
power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the
door open slightly: blocking it open if necessary or have the door removed.
How to save energy
•Install the refrigerator in the coolest part of the room, out of direct sunlight and away from heating
ducts or registers. Do not place the refrigerator next to heat-producing appliances such as a range,
oven or dishwasher.
•The refrigerator door should remain open only as long as necessary; do not place hot food inside the
refrigerator.
•Organize the refrigerator to reduce door openings .Remove as many items as needed at one time
and close the door as soon as possible.
•The refrigerator door should be properly closed to avoid increased energy consumption, and the
formation of excess ice and / or condensation inside.
•Constantly circulating cold air keeps the temperature homogenous inside the refrigerator. For this
reason, it is important to properly distribute the food, to facilitate the flow of air.
•Cover foods and wipe containers dry before placing them in the refrigerator. This cuts down on
moisture build-up inside the unit.
•Do not overcrowd the refrigerator or block cold airvents. Doing so causes the refrigerator to run
longer and use more energy. Shelves should not be lined with aluminum foil, wax paper or paper
toweling. Liners interfere with cold air circulation, making the refrigerator less efficient, which could
cause food spoilage.
•During prolonged absences (example: vacations), it is advisable to disconnect the refrigerator,
remove all the food, and clean it . The door should be left slightly open to avoid mold and unpleasant
odors. This will not affect the refrigerator when it is reconnected.
•During short absences (example: holidays), the refrigerator can remain on. However, remember that
prolonged power outages may occur while you are gone.
Servicing

•This product should be serviced by an authorized engineer and only genuine spare parts should be
used.
•Under no circumstances should you attempt to repair the appliance yourself.
•Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact
the local store where your purchase was made.
•When the appliance is not in use for long periods, disconnect from the electricity supply, empty all
foods and clean the appliance, leaving the door ajar to prevent unpleasant smells.
ELECTRICAL INFORMATION
THIS APPLIANCE MUST BE EARTHED.
6. This appliance is fitted with a plug which will be suitable for use in all houses fitted with sockets to
current specifications.
7. If the fitted plug is not suitable for your socket outlets, it should be cut off and carefully disposed of.
To avoid a possible shock hazard, do not insert the discarded plug into a socket.
Changing the internal light
1. Before carrying out the bulb replacement always press and turn the thermostat control to dial to
position “OFF”, then disconnecting the mains supply.
2. Hold and lift up the light bulb cover.
3. Remove the old bulb by unscrewing it in an anti-clockwise direction.
4. Replace with a new bulb (Max.10W) by screwing it in a clockwise direction marking sure that it is
secure in the bulb holder.
Refit the light cover and re-connect your Fridge/Freezer to the mains supply and switch on.
THIS APPLIANCE MUST BE EARTHED.
This appliance is fitted with a plug which will be suitable for use in all houses fitted with sockets to
current specifications.
If the fitted plug is not suitable for your socket outlets, it should be cut off and carefully disposed of. To
avoid a possible shock hazard, do not insert the discarded plug into a socket.
This appliance complies with the EEC Directives.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental safe recycling.
Imported by Elec. Sauber España S.L. Paseo de la Castellana 93.
planta 1ª, 28046, Madrid, Spain
