INSTALLATION AND USERS GUIDE
2013 SAVI NOTE
IMPORTANT NOTICE - ATTENTION INSTALLER: This Installation and
Users Guide contains important information about the installation,
operation and safe use of this swimming pool/spa light. This Guide
should be given to the owner and/or operator of this equipment.
DANGER - SERIOUS BODILY INJURY OR DEATH CAN RESULT IF THESE
LIGHTS ARE NOT INSTALLED AND USED CORRECTLY
DANGER - INSTALLERS, POOL OPERATORS AND POOL OWNERS MUST
READ THESE WARNINGS AND ALL INSTRUCTIONS BEFORE USING
THESE LIGHTS
WARNING - Before installing this product, read and follow all warning
notices and instructions in this Guide. Failure to follow warnings and
instructions can result in severe injury, death or property damage. For
more information contact company at numbers contained within Guide.
WARNING - These underwater swimming pool lights MUST BE installed by a
licensed or certified electrician or a qualified pool professional in accordance with
the National Electric Code (NEC) or the Canadian Electric Code (CEC), CSA C22.1.
All applicable local installation codes and ordinances must also be adhered to.
Improper installation will create an electrical hazard which could result in death or
serious injury to pool users, installers or others due to electrical shock.
ALWAYS DISCONNECT THE POWER TO THE POOL LIGHT(S) BEFORE SERVICING.
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Products in this Guide are covered
under one or more of the following
patents: 6,827,464 7,244,037 6,971,760
5,617,496 5,617,497 5,789,471
5,528,714 5,33,228 6,200,012
6,48,952 6,422,730 6,367,100
6,398,397 6,393,192 6,375,342
7,204,602 7,229,027
The following are registered
trademarks and designs of
Next Step Products: Savi,
Endglow, Sideglow Oasis
9400 Southridge Park Ct #200 Orlando FL 32819
Tel: [phone] Fax: [phone]
nextstepproduct.com
IMPORTANT WARNING & SAFETY INSTRUCTIONS
CRITICAL - The 2013 Savi Note LED Light requires the use of a
M4 Controller and is not designed to operate independently

INSTALLATION INSTRUCTIONS
SAVI NOTE Underwater LED Light
READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
CAUTION! SAFETY PRECAUTIONS
TURN OFF MAIN POWER TO LIGHT BEFORE INSTALLATION
SAVI NOTE is a low voltage light and should NEVER be electrically connected to a power source other than a SAVI
M4 controller. Failure to comply will either damage or destroy SAVI NOTE and VOID the Warranty.
Product WATTS AMPS MINIMUM CONDUIT LENGTH
A Division of Next Step Products
9400 SOUTHRIDGE PARK COURT SUITE 200 ORLANDO, FLORIDA 32819 USA
Tel: [phone] Fax: [phone] nextstepproduct.com
STEP 1
The light must be installed in the wall of the pool (or
water feature) with the top of the lens opening not less than 4
inches (10.16cm) below the normal water level of the pool.
STEP 2
STEP 3
read the into the wall until it is
Using enclosed Lens Key, thread the light into the wall fitting until it is snug. Please
provide Pool Owner with minimum of 1 key upon job completion (see winterization
clause above)
NOTE: Requires the use of a 1-1/2” threaded wall
NOTE: Make sure all protective coverings have been removed.
4” MIN. FROM WATER
LEVEL TO TOP OF LENS
1.5” THREADED WALL FITTING
1.5” dia. Pipe1” min. Pipe
Sweeps ONLY
No 90 degree bends
4” MIN. FROM WATER
LEVEL TO TOP OF LENS
Allow 18” - 24”
slack for
Service Loop
Tighten
NOTE: All lights
must be directly
wired to M4 control
NOTE: Check with Local Building as to what conduit/pipe is acceptable for usage.
1.5” Pipe through bond beam for a minimum of 14” then 1” conduit min. beyond
with sweeps / no 90 degree bends. We highly recommend the use of 1.5" pipe
throughout the entire width of the bond beam. NOTE: Use of 1.5” pipe with 14”
min. length will accommodate all SAVI Lighting nicheless products. Minimum
1.5" conduit length is 7".
Winterization Clause
Pool Water Level must be drained down 12” below light(s) position in pool wall.
We also highly recommend that the lights be loosed from their wall to
allow drainage of water that might have accumulated within conduit. Consult
your local Swimming Pool Professional for proper local area winterization
processes. At NO TIME should there be water removed from the pool without
checking ground water tables.
Small Gasket
Large Gasket
Flat Gasket
NOTE: For Vinyl wall Fittings use both rubber gaskets.
For Gunite and Fiberglass remove the Small
gasket and use the Large one only.
4” MIN. FROM WATER
LEVEL TO TOP OF LENS
Vertical Installation for
Benches, Swimouts and
Fountains
SAVI M4 Controller
Conduit to M4
1. To prevent electrocution and/or death make sure power is off at the breaker.
2. Avoid touching/installing the M4 controller box during electrical storms. Death
or serious injury may result due to lightning surges through the system.
3. Be sure to check local electrical codes for grounding electrical boxes via
the approved method (internal conduit ground, external box ground wire to
grounding rod, etc.)
4. Use approved conduit routed by approved methods to conduit fittings on the
box.
5. For DMX based units, do not install data cables in the same conduit as power
cables to prevent communication problems.
6. Be sure the mounting surface is able to support the load of the controller. Use all
four mounting holes to secure the controller.
7. There are no customer serviceable components inside the M4 controller. Only
qualified electricians should open the box for installation of the power and LED
accessories connections. All connections should enter through an approved
conduit method.
8. LED accessories are low voltage and should never be electrically connected
to any power source other than the appropriate M4 controller connector (J5 to
J8). Wires must be connected properly to avoid permanently damaging the LED
accessory.
WARNING
2013 SERVICABLE
SAVI NOTE 14 1.2 7"
Products are available with 30,50,100 & 150ft cords
Pull the 4 conductor electric cord throught the conduit inlet of the wall
fitting, into the conduit and up to the location of the M4 controller. Cut
off the excessive cord after allowing for a service loop. Pull light snug
into the wall fitting. THIS PRODUCT DOES NOT ALLOW FOR THE
USE OF A JUNCTION BOX INSTALLATION. ALL LIGHTS MUST BE
DIRECTLY WIRED TO THE M4 COTNROLLER.

DESIGNER LENS SERIES OPTION:
Savi Pool & Spa has created a unique set of options for our LED Series of lights - designer lens. Each one has
the ability to create fantastic lighting effects within the pools interior. No other company can offer these lighting
effects. These are so unique that we have a Patent Pending on this series. Look below and see if any one fits
into your pool environment. Keep in mind that these lenses can be added on to any of our 2013 LED Lights -
even if they have already been installed.
HALF DOME - This escutcheon adds over the existing lens to allow you to
direct 1/2 the light in a direction you want. Downwards-to light a pools
interior without light shining upwards. Upwards to light a waterfeature or
sideways to put light where it might be needed but no where else
HALO LENS - This lens allows for gentle lighting in an area but knocks down
the center beam. This allows for installation on walls, etc where there might be
an opposite wall, etc where you want to eliminate generating a "hot" spot.
Great general lighting but softly.
SPOT LENS - Just the opposite of the Halo whereas we knock down the general
lighting and focus more of the light forwards. Great for illuminating that special
feature.
CATS EYE - This lens reduces the light eminating but for just a "slice" of light
that is broad but thin. An incredible effect for illuminating but without spilling
light all over.
DIAMOND - WOW want to really create something special? The Diamond lens
creates incredible points of light throughout the interior. The points will be
different the farther away from the light they are. Put the LED colored light on
DANCE PARTY MODE AND WATCH THE FUN BEGIN!
9400 SOUTHRIDGE PARK COURT, SUITE 200, ORLANDO, FL 32819 USA
TEL: [phone] FAX: [phone] nextstepproduct.com
M4 CONTROLLERS - The Savi Note can be hooked into 1 of 3 different M4 Controllers. SA - allows the
Savi Notes to operate and Synchronize with other Savi Pool LED lights such as the Savi Melody and or - with
our Savi X-Stream Color LED drivers which will allow for waterfeature lighting to match the Savi Note lights.
RB - stands for M4 Rainbow Controller which has all the basic LED color lighting features as the SA but adds
exciting additional color lighting effects such as Rainbow - which allows individual color lights such as BLUE to
literally look like it is moving from 1 light to another or in effect creates a "chasing" effect. There are multiple
preprogrammed rainbow features built into this controller.
DMX - DMX alllows for the ulitmate in color lighting control. With this M4 controller you can program any lighting
show, any lighting sequence - in fact any color or colors you want. Design your own custom light show.

OPERATION INSTRUCTIONS
Synchronization Process for LED Color Pool and Spa Lights
1. Turnthelightsonandwaitfor20seconds.Thelightswillfirst comeonwhitefor10-15secondsandthenreturntothe
colormodeitwasonpriortobeingturnedoff.(Ifthisistheinitialinstallation,thelightswillreturntowhatevermode
they were in when last receiving power).
2. Donotmovetothenextstepuntilsteponeiscomplete.
3. Tosynchronizelights,turnthelightsoff,wait6-9secondsandthenturnthembackon.Youshouldseethreequick
flashes (red,green&blue),andthenallthelightswillresettothefirstcolormode(TreasureIsland).
4. (A)Ifyoudonotseethreequickflashes thenthelightsdidnotreset.
(B)Ifyoudidnotwaitlongenough(shorterthan6seconds)thelightswilladvancetotheirnextcolormode.Theyare
not synched as each light could be in different color modes.
(C)Ifyouwaittoolong(longerthanthe9seconds)theyallwillgotowhitefor10-15seconds,lookinglikethey’re
synchedBUTAFTER15secondstheywillreturntotheirpreviouscolormode(whichatthispointthelightsare
stillunsynchronized).
5. Repeatstep1-3untilsynchronizationisaccomplished.
6. To confirmthelightshavebeensynchronized(TreasureIslandMode)-thebestwayisto:turnthelightsofffor1-2
seconds and turn back on – DO THIS TWICE. All the lights should be in the SAVI BLUE color mode. If they are all
fixedonBLUE–youhavenowsynchronizedyourlights.Ifnot–turnthelightsoffformorethan20seconds–Turn
back on and proceed to Step 1.
OPERATING THE LIGHT
7. Tomovetothenextcolormode,Turnthelights offfor1-2secondsandturnbackon.Repeatuntildesiredcolormode
is found.
Example:IfyoufollowedstepsixandarenowonSAVIBlueandwantthelightstobeWhite,thenthelightsmustbe
turnedoffandon(7)seventimestobringyoutoMoonlightWhite.
1. Treasure Island / Slow color change
2. MoonlightWhite/FixedWhite
3. SAVIBlue/FixedBlue
4. SargassoSea/FixedGreen
5. BlueLagoon/FixedLightBlue
6. PassionPink/FixedMagenta
7. CaribbeanHues/BlueandGreenSlowColorChange
8. Copacabana/Magenta,YellowandOrangeSlowColorChange
9. Danceparty/MultiColorStrobeEffect
8. Thelightshavememory.Ifthelightsareofffor10secondsormore,thenexttimethelightsareturnedon,theywill
gotowhiteforapproximately10-15secondsandthenreturntothelastcolormodetheywereonpriortobeingturned
off(Step1listedabove).Thisfunctionallowsyoutokeepyourlightsreturningtoyourfavoritecolormodeeverytime
the lights are turned back on.
Ifyouhaveinternetaccess,pleasegotowww.nextstepproduct.com/SAVI/support.html and click on the link under USER
GUIDES that says “synchronous process” for a video that demonstrates how this process works.
A Division of Next Step Products
9400SOUTHRIDGEPARKCOURTSUITE200  ORLANDO,FLORIDA32819USA
Tel:407.855.5630Fax:407.210.8679nextstepproduct.com
LIGHT SYNCHRONIZATION
Important Note: All xtures must be tied into the same transformer, circuit or switch for synchronization
SAVI NOTES REQUIRE ALL LIGHTS TO BE TERMINATED INTO A M4 CONTROLLER. IF
MULTIPLE M4'S ARE INSTALLED - ALL MUST BE CONNECT TO 1 MAIN POWER SOURCE

9400 SOUTHRIDGE PARK COURT, SUITE 200, ORLANDO, FL 32819 USA
TEL: [phone] FAX: [phone] nextstepproduct.com
BASIC TROUBLESHOOTING GUIDE - FOR ADDITIONAL INFORMATION CONTACT
TECHNICAL SERVICES AT TELEPHONE NUMBERS LISTED BELOW
ALL LIGHTS FAIL TO ILLUMINATE - Check 120V power supply into M4 controller - check or
reset GFCI. For further voltage checks - please refer to M4 Guide for specific testing procedures.
ONE OR MORE LIGHTS DIM - This is generally caused by a poor connection or improper wire
gauge. IF A JUNCTION BOX IS BEING USED (not recommended) - VERIFY THAT THE CORRECT WIRE
GAUGE IS BEING USED BETWEEN M4 AND JUNCTION BOX. Typically though the problem is located
in either the M4 or a poor connection between M4 and cord from light.
BLINKING, FLASHING, NON WORKING LIGHTS - This is generally caused by a poor
connection or improper wire gauge. IF A JUNCTION BOX IS BEING USED (not recommended) -
VERIFY THAT THE CORRECT WIRE GAUGE IS BEING USED BETWEEN M4 AND JUNCTION BOX.
Typically though the problem is located in either the M4 or a poor connection between M4 and cord
from light.
2013 SAVI LED LIGHTING PRODUCTS
COLORED LIGHTS OUT OF SYNCH - Follow Synchronization Instructions in this Guide. Be very
patient and read instruction carefully. If lights fail to synchronize - verify that proper wire
connections are being achieved for those lights that are out of step with others. Generally a lights
failure to sync with the rest is: improper voltage supply or poor connection to light.
NOTE: In most situations problems come down to main faults: improper voltage supply,
improper wiring gauge,improper/poor wiring connections, internal to M4 or the light itself.
2013 SAVI LED LIGHTS ARE FIELD SERVICABLE AND THE CORD AND LIGHT BODY
FIXTURE SHOULD NOT BE REMOVED COMPETELY FROM THE CONDUIT OR POOL. THERE SHOULD
BE ENOUGH CORD SUPPLIED IN THE SERVICE LOOP TO REMOVE LIGHT FROM WALL FITTING AND
LIFTED ABOVE WATER LEVEL FOR LED LIGHT CARTRIDGE REPLACEMENT. IF THERE IS NOT
ENOUGH CORD IN SERVICE LOOP OR IT CANNOT BE ACCESSED - POOL WATER CAN BE DRAINED
BELOW LIGHT TO ACCESS FRONT OF LIGHT.
DO NOT PULL LIGHT AND CORD ENTIRELY FROM CONDUIT UNLESS INSTRUCTED BY COMPANY.
SAVI POOL AND SPA WILL NOT ACCEPT ENTIRE LIGHTS BEING RETURNED FOR SERVICE
UNLESS INSTRUCTED BY COMPANIES TECHNICAL SERVICES DEPARTMENT
ONLY LED LIGHT CARTRIDGES SHOULD BE REPLACED OR EXCHANGED WITH THE
2013 PRODUCT
Refer to the Light Cartridge Replacement Instructions included in this Guide for light replacement.
WARNING: All servicing of Savi LED Lights should be done by a licensed or certified electrican or a
qualified pool professional in accordance with the National Electric Code (NEC) or Canadian Electric
Code (CEC)
For additional troubleshooting assistance or installation advice please contact Technical
Services at telephone number below.
If problem is suspected to be within the M4 Controller - please refer to Installation Guide
for the M4 Controller. Specific troubleshooting information is contained within that Guide.
For additional help in determining or identifying issue - please contact Technical Services.

TURN OFF MAIN POWER TO LIGHT BEFORE INSTALLATION
STEP 1
TURN OFF MAIN POWER TO LIGHT BEFORE
REPLACING LIGHT CARTRIDGE. Be sure the
light fixture is in a dry environment. Remove the (8)
eight screws from the lens with the tool provided.
Pull the lens from the fixture body. Remove and
discard the O-ring between the Lens and Fixture
Body.
STEP 2
Using the tool provided, insert and turn the thread-
ed portion into the extraction hole in the face of the
Light Cartridge. Pull the Light Cartridge from
the housing body.
STEP 3
Insert the replacement cartridge into the housing
body. Line up the TAB at the end of the circut board
with the receiving slot inside the housing body.
It may be necessary to slowly turn the Light
Cartridge until the TAB lines up with the SLOT.
STEP 4
Clean the Lens and the Enclosure of any remaining
old Silicone before applying new Silicone and replac-
ing the Lens. Replace the O-ring with the new one
provided. Attach the lens onto the fixture body.
Tightly secure the eight (8) screws indicated in the
diagram to the right. Once all screws are tight, slowly
submerse in water, checking for any air bubbles -
quickly remove from water bubbles appear as it
indicates the seal is not water tight. Retighten the
screws and test for bubbles again.
STEP 5
Reset the fixture into the wall fitting and turn the power ON.
Apply a new silicone bead to
the lens with tube provided
after cleaning the lens and
body of old silicone.
WINTERIZING
The water level should be lowered to approximately 12
inches below the pool lights, make certain the water is
drained out of the wall housing. Consult a Local Swimming
Pool Professional for proper winterization. Minimum
safeguard requires dropping the water level 2”-4” below
the light. At NO TIME should there be water removed from
the pool without checking ground water tables.
LIGHT CARTRIDGE REPLACEMENT
SAVI NOTE
9400 Southridge Park Court Suite 200 Orlando, Florida 32819 USA T. 407.855.5630 NextStepProduct.com
TAB
SCREW TIGHTENING DIAGRAM
SILICONE BEAD ON LENS
SLOT
O-Ring
New O-Ring
Lens
Extraction Tool /
Screw Driver
Light Cartridge
Replacement
Light Cartridge
Fixture Body
1
23
4
5
6
7
8
LC111912
NOTE-CARTRIDGE-KIT
SAVI NOTE IS A LOW VOLTAGE LIGHT AND SHOULD NEVER BE ELECTRICALLY
CONNECTED TO A POWER SOURCE OTHER THAN A SAVI M4 CONTROLLER.
FAILURE TO COMPLY WILL DAMAGE OR DESTROY THE SAVI NOTE
AND VOID WARRANTY
REPLACEMENT LIGHT CARTRIDGE KIT PART NUMBERS

LIMITED PRORATED WARRANTY
Next Step Products LLC and its wholly owned subsidiaries and divisions (herein referred to as “the Company”),
warranties its products, excluding lamps, to be free from defects in material and/or workmanship, under normal
condition,useandservice,foraperiodofFive(5)yearsfromtheoriginalinvoicedate. During the first two (2) years
100% coverage on all parts, 3rd (3) year all warranty parts will be replaced at
35%
of the then current List Price of such
part and in years Four & Five (4&5) all warranty parts wil be replaced at 50% of the then current List price of such part.
This specific warranty is for parts only and specifically excludes all labor charges associated with warranty items.
TERMS AND CONDITIONS:
ThiswarrantyonlyapplieswhentheCompany’sproductsareproperlywiredandinstalledtogetherasasystem;
andoperatedwithintheelectricalvaluesshownontheCompany’sspecification sheets;usedinlightingequipment
designedandapprovedfortheapplicationandenvironmentalconditions(temperature,humidity)withinthenormal
specified operatingrangeofthesystem.Thiswarrantydoesnotapplytoanyabnormaluseinviolationofanyapplicable
standard,codeorinstructionsforuseininstallationsincludingthosecontainedinthelatestNationalElectricalCode
(NEC),theStandardsforSafetyofUnderwritersLaboratory,Inc.(UL),StandardsfortheAmericanNational
StandardsInstitute(ANSI),inCanada,theCanadianStandardsAssociation(CSA),Europe(CE),Australia(C-
Tick).Thiswarrantywillnotapplyintheeventofconditionsdemonstratingabnormaluseorstress,including
under/overvoltageconditions, excessiveswitchingcycles,excessiveoperatinghours,alterations,accident,theft,
misuse,abuseanddamagedcausedbynegligentinstallation,impropermaintenanceorwhereadequatecarehasnot
beentakentopreventdamagetothelightingsystem.ReplacementoftheCompany’sproductcomponentswithany
othermanufacturerwillvoidtheentirewarranty.
WARRANTY SERVICE CLAIMS:
TheCompanymustissueaReturnMaterialAuthorization(RMA)numberforallrequestsforwarrantyreview.Toexpedite
service,pleasecontacttheCompany’sCustomerRepresentativewhereyoupurchasedtheproduct.Ifyouareunsure
whetherasituationexiststhatiscoveredbythiswarranty,pleasecontacttheCompany’scustomerservicedepartment
from the company or division where you purchased the product for assistance. In the event of a defect in material or
workmanshipduringthewarrantyperiod,theCompanywillrepairorreplace(atitsowndiscretion)itsproductsunder
the conditions of the warranty.
AcompletelistoftheCompany’sbrandsandtheirwarrantyservicecontactinformationcanbefoundattheendthe
warranty.
RETURN OF DEFECTIVE PRODUCT:
AftercontactingthepropercompanyordivisionandreceivingtheRMA#,thepurchaser/usershallpromptlyreturnthe
productafterreceivinginstructionsregardingif,whenandwheretoshipproduct.Productmustbereturnedwithin30
daysofreceivingRMA#.ShippingboxmustbeclearlymarkedwithRMA#.Failuretofollowthisprocedureshallvoidthis
warranty.Thecompanywillcoverexpensesformaterialbutwillnotcovershippingcosts.Productsreturnedwithoutan
RMA#willberefusedandreturnedtosenderatthesendersexpense.
REPLACEMENTOFPRODUCT,LIMITSOFLIABILITY:
TheforegoingshallconstitutetheexclusiveremedyofthepurchaserandthesoleliabilityofNextStepProductsLLC
and its wholly-owned subsidiaries and divisions regarding its products and component warranty. NO WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS MADE OR IS TO BE IMPLIED. In no event shall
NextStepProductsLLCoritswholly-ownedsubsidiariesordivisionsbeliableforanyothercostsordamagesincluding
laborcharges,lostprofits orrevenues,incidental,specialorconsequentialdamages.TheCompanyreservestheright
toexamineallfailedproductsandcomponentstodeterminethecauseoffailureandpatternsofusageandreserves
theright to be the sole judge as to whether any product or component is defective and covered under this warranty.
THIS WARRANTY IS ONLY TO THE ORIGNAL PURCHASER OF PRODUCT AND DOES NOT TRANSFER.
November1, 2012
A Division of Next Step Products
9400SOUTHRIDGEPARKCOURTSUITE200  ORLANDO,FLORIDA32819USA
Tel:407.855.5630Fax:407.210.8679nextstepproduct.com
