Saville Airshare Instruction manual

QUICK USER GUIDE
Saville
A
V/IT Solutions & Services
www.saville-av.com

Wireless Presentation-Screen Mirroring Receiver
Saville Airshare is a wireless presentation and screen mirroring receiver for computer and mobile
devices. It connects laptops, notebook, ultrabooks or mobile devices like iPad, iPhones, Android tablets
or Smartphones to any projector or LCD/Plasma display for presenting high quality presentations. It is
compatible with Windows, Mac OS, iOS and Android OS. With its unique Plug-and-Show token, split
screen Collaboration mode, Conference Control mode, free Mobile Apps and Remote Control-desktop
feature, Saville Airshare is an integral part of any conference room, meeting room, training or classroom.
Hardware Mounting
Saville Airshare can be placed horizontally on any flat stable surface like a shelf or counter top. The unit
can be mounted behind a wall mounted flat panel display using the provided bracket, alternatively Velcro
or adhesive tape can be used, but it is recommended to use cable ties as well.
Display Connection
Connect the HDMI output of the unit into the HDMI input of a flat screen display, projector or to an input
of an AV switcher. The default output is HDMI, however the unit can be connected to a VGA-XGA display
via the HD-15 VGA connector after reconfiguring the system via the admin webpage. When using the
analogue VGA connector, connect the 3.5mm audio output to the display speakers or mixer/amplifier input.
Network Connection / AP Client mode
Connect a network cable from a switch or router to the RJ-45 connector to access an existing wired
network via Ethernet.
The unit can be used on an existing wireless network by configuring the AP Client mode settings for SSID
and encryption key via the web admin page.
By default, internal access point Airshare is active at power on and it can be used for connection the device.
This enables the unit to be used wirelessly, without the need to be connected to an existing network.
Screen Mirroring via computers
There are three methods of connecting to the display through Airshare from any computer with
Windows or Mac OS:
Connect N Show:
Ideal for routine users .Install the WiD App on the computer and launch the App.
Click N Show:
Mirror/project screen with a single click via a direct connection to a specified Airshare device/display
after installing the WiD App and creating an association file.
Plug N Show:
Ideal for vsitors or guests without the need to install the App. The WiD App can be run from the
provided PNS Token (USB disk) or a designated network location.
www.saville-av.com

App Installation
Depending on your network connection, access the
Saville Airshare via the wireless or wired network in
the facility. Open up a web browser on your device
and type in the web-address shown on the display/
projector. (Omit the http:// www.) From the webpage
of the unit, click the Download button next to the
relevant OS of the connected computer. Run or Save
the WiD.exe for Windows OS or WiD.pkg file for Mac
OS. If downloaded files are saved, then open the
location and double-click to install.
Make sure the computer’s
firewall or Smartscreen filter
will allow the WID app to
pass through and then
complete the installation
by following on screen
instructions. After installing
the program, a WiD
shortcut will be placed
on desktop.
OPERATION: Client App & User Interface
Click the WiD shortcut icon on the desktop. Alternatively locate the WiD App from the program list or
search window via the Start button on Windows OS.
On Mac OS, locate the WiD app on desktop or in the dock. If not present, use finder to locate the
program in the Application list.
A new window / UI box labeled as Current Server will appear on screen.
When WiD UI box appears on screen, click Manual button first.
Enter Devicename or IP address seen on bottom of Projector/Display screen along with 4-digit login
code seen on top right corner. Click Connect button next.
A
V/IT Solutions & Services

In WiD user interface box press Play button in center to show full screen image. Press 1 through 4 to
show in respective corner for Collaboration mode.
Click the WiD shortcut icon on the desktop. Alternatively locate the WiD App from the program list or
search window via the Start button on Windows OS.
On Mac OS, locate the WiD app on desktop or in the dock. IF not present, use finder to locate the
program in the Application list.
A new window / UI box labeled as Current Server will appear on screen.
Configuration > UI Menu
Click the icon to open the Option menu to manage the following features
Main / Extended screen projection
Quality and aspect ratio of screen mirroring,
Graphics / Video mode,
Advanced screen capture of surface windows
Audio setup,
Produce a new Plug N Show token or obtain a copy of the application.
Configuration > Admin Web Page
The system status page provides information about
the current Airshare settings.
a) Network setup (Static / DHCP IP address, DHCP server, Wireless
access point, Security/Encryption, AP Client mode, Gateway setup)
b) Projection Setup (Output format selection between VGA /HDMI, video output resolution, Login code format)
c) Default OSD background screen setup
d) Change passwords for admin and trainer (Conference control mode) login
e) Reboot device
f) Firmware upgrade (Contact Tech support and upgrade only if advised)
The unit is pre-configured for default settings. The following
settings are allowed to be modified using administration web
page by entering IP address of the Saville Airshare device in any
standard web browser and selecting the admin menu. The
default admin login password is Admin&11. The admin
webpage can be accessed via the Option menu button of the
User interface.
www.saville-av.com

Troubleshooting
Saville Airshare is easy to operate, however if you are receiving error messages or connection problems
please see below:
A) The quality of the image is not sharp.
If connected wirelessly, check that the signal strength is Excellent or Good. This is verified by moving the
cursor over the Wireless Network Connection icon in the lower right-hand corner of the system tray. You
may be too far from the Wireless Receiver or there may be a object or wall obstructing the radio waves.
Click on Menu button on WID utility and select Better Quality instead of Normal.
B) The displayed image appears to be cropped.
If the displayed image appears to be cropped, change the resolution of the transmitting PC in order to
avoid this. The display resolution can be changed/verified by right-clicking on the desktop and selecting
properties. From the Settings tab the resolution can be changed/ verified.
C) The image or video displayed is slow.
The quality of transmission depends largely upon the transmitting PCs CPU performance. Avoid running
multiple applications simultaneously while streaming to maximize the CPUs performance.
If streaming wirelessly, check that the signal strength is Excellent or Good – see A) above.
Saville Airshare plays full motion video from a web browser, YouTube or Windows Media Player or QuickTime
in Speedy mode, so make sure to activate this by clicking on the Video option menu button in the User interface.
A
V/IT Solutions & Services

WiD Application and Firewall
There are three types of firewall that could stop the WiD application from playing video in Video Playback
mode or the computer screen in Presentation mode:
Network Equipment Firewall
Computer Operating System Firewall
Third-party software based firewall
1. Network equipment Firewall
Please open the below ports which the WiD application requires to operate correctly.
Inbound: UDP 1047, 1048, 1049 TCP:1041
Outbound: TCP 443, 389, 3286, 80, 21, 515
2. Windows Firewall
Please check the firewall in Control Panel->Windows Firewall
If Firewall is OFF then there would not be problem in
Video Playback.
If Firewall is ON then click on Exception tab. Check the
exceptions, to see if there is WiD present in the list. If
present then put a check-mark in front of it. When WiD
App is run from computer or provided Plug N Show Token
(USB-stick) is installed the firewall exception is added and
selected automatically unless there are group network
policies preventing that.
If WiD.exe is not present in the exception list, press the
“Add Program” button to add it to the list and follow
instructions.
3. Software Firewall
If any software based third-party firewall like Zonealarm,
Norton Systemworks, Norton 360, CA Internet Security
Suite or McAfee Firewall, then please follow that software
developer’s documentation about adding programs to a
safe list or adding exceptions to the firewall rules.
www.saville-av.com

2. Software Firewall
If any software based third-party firewall like Zonealarm, Norton Systemworks, Norton 360, CA Internet
Security Suite or McAfee Firewall, then please follow that software developer’s documentation about
adding programs to a safe list or adding exceptions to the firewall rules.
Specifications
Function Wireless Presentation, Speedy mode, Conference Control,
Collaboration 4 to 1 split-screen
Output HDMI port or HD-15 VGA Female connector with Audio on
3.5mm jack (audio on video playback)
PC/Laptop Resolution Support SVGA, XGA, SXGA, WXGA, UXGA
Output Resolution Support SVGA (800x600) XGA (1024x768) WXGA (1280x768)
WXGA+(1280x800 1400x900)
Hardware Support LAN, WAN (802.11b/g/n)
Wireless technology 802.11 b/g/N at 2.4 GHz
Transmission Range 150-ft Outdoor, 100-ft Indoor
Transmission Rate 54 Mbps wireless, 100 Mbps wired
Encryption WEP, WPA, WPA2-PSK 128 or 64-bit
Native OS Support Windows 8, 7, Vista, XP, 2000, Mac OS 10.5 above
Mobile OS Apps Windows 8 Pro, iOS, Android
Usability & Security Auto-redirect, Login Security, Access point
Power Supply 5V DC, 2.0A input with included power adapter
Dimensions (W x L X H) 5.50” x 2.5” x 1” (140 x 55 x 25 mm)
Weight 0.8 lbs. (0.5 kg.)
Specifications are subject to change without notice.
A
V/IT Solutions & Services

WiD Application and Firewall
• Connect N Show mode with easy to use and fast WiD app.
• Plug N Show - Convenient USB Token for hassle-free and fast presentation without installing any
software on connecting computer.
• Windows 8, 7, Vista, XP, or Mac OS compatible App downloaded from device and installed in
less than 10 seconds
• Built-in 802.11 n/g/b Access-point for wireless network client connection using 64/128-bit WEP/WPA
security making single device for presentation and networking.
• Built-in Ethernet 10/100 Mbps LAN port to make WiD510-ENT part of existing network infrastructure
• Conference control feature for moderating and streamlining presentations
• Collaboration mode allows screen of up to 4 participants wirelessly on same display
• Speedy mode for full-motion video playback with minimum lag.
• 720p HD output on HDMI connector or VGA-WXGA+ output on HD-15 connector
• Audio & Video transmitted from connected client PC or Mac
• Extended screen projection capability – ideal for PowerPoint presentations
• All-in-one presentation+ wireless access point device or part of existing wired/wireless network infrastructure.
Connect & Show For frequent users, install the WID utility (application specific to
OS) from the webpage of the Saville Airshare or from provided USB Plug & Show
Token. After initial installation of the WiD application it is easy to connect by
clicking on shortcut icon.
Plug & Show With the Plug & Show USB Token, wireless presentation becomes easy!
Just link your PC/Laptop to the Saville Airshare via WLAN or wired network Ethernet,
plug the token into a USB port, and in seconds, your screen will be wirelessly projected
to the connected display! There is no need to install drivers or download software.
Collaboration using 4-to-1 Split Screen Projection With this 4-to-1 split screen feature, up to four
PC/Mac screens can be shown on one display at the same time to collaborate, view side-by-side comparison,
teach or compare. It is easy to switch from Collaboration to show full screen, with a single click .
Conference control The moderator/instructor can control projection from connected PCs through a
web-based control page on the Saville Airshare. This function is especially useful in teaching
environments in schools, colleges and universities.
