Operator’s Manual
Original Operating Instructions
Splitz-it 5-tON
electric lOg Splitter
ENGLISH
Genuine part # AC02585
sbI hEATING AccEssoRIEs
250 rue de copenhague | saint-augustin-de-desmaures
québec, canada g3a 2h3
01-11-2012
2
Splitz-it 5-tON electric lOg Spliter
THANK YOU AND CONGRATULATIONS...
for purchasing an SBI Heating Accessories, Splitz-it 5-Ton Electric Log Splitter. We have worked to ensure that the splitter meets high stan-
dards for usability and durability. With proper care, your log splitter will provide many years of service. Please take the time to read this
manual carefully to learn how to correctly operate and maintain your log splitter. Congratulations on your investment in quality.
CONTENTS
Registration ........................................................................................................................................................................................................................................2
Safety & Safety Rules..................................................................................................................................................................................................................3-4
Specications & Electrical Requirements ...............................................................................................................................................................................5
Set-Up and Pre-Operation ...........................................................................................................................................................................................................6
Assembly ............................................................................................................................................................................................................................................7
Operation...........................................................................................................................................................................................................................................8
Maintenance .....................................................................................................................................................................................................................................9
Service, Troubleshooting, and Repair ....................................................................................................................................................................................10
Parts Explosion Breakdown and Parts List..................................................................................................................................................................... 11-12
Warranty ...........................................................................................................................................................................................................................................13
REGISTRATION
Record your model number and serial number in the space provided for easy reference. Fill out and mail the registration card .
Model Number *
Serial Number *
Date of Purchase *
Place of Purchase *
ABOUT YOU
First name *
Last name *
Gender (Optional) Male Female
Addess *
City * Country *
Province / State * Zip Code *
Phone * Email *
SBI Heating Accessories
250 Rue-de-Copenhague | Saint-Augustin-de-Desmaures
Québec, Canada G3A 2H3
Fax number: 418 878-3001
Fields marked with an asterisk (*) are required
Splitz-it 5-tON electric lOg Spliter
3
SAFETY AND SAFETY RULES
OWNER’S RESPONSIBILITY
Safe and eective use of the 5-ton electric log splitter is
the owner’s responsibility.
schedule, included in this Operator’s Manual.
place and in working order. Replace damaged, missing or
failed parts before using it.
with all controls and safety precautions.
SPECIAL MESSAGES
Your manual contains special messages to bring attention to
potential safety concerns, machine damage, as well as helpful
operating and servicing information. Please read all the
information carefully to avoid injury and machine damage.
IMPORTANT SAFETY PRECAUTIONS
Please read this section carefully. Operate the electric
log splitter according to the safety instructions and
recommendations outlined here, and stated throughout
the text. Anyone who uses this log splitter must read the
instructions carefully and be familiar with the controls.
This symbol signies important safety
instructions, which, if not followed could
endanger your personal safety. Read and
follow all instructions in this manual before
attempting to operate this equipment.
wear sturdy footwear. Do not wear sandals, sneakers, or
open toed shoes, and never operate the log splitter with
bare feet. Do not wear loose clothing or jewelry that may
get caught in moving parts. Always wear safety goggles for
eye protection. Everyday glasses have only impact resistant
lenses and are not eective safety glasses.
WARNING
WARNING INDICATES A HAZARD WHICH, IF NOT AVOIDED,
COULD RESULT IN DEATH OR SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
CAUTION
CAUTION INDICATES YOU CAN BE HURT OR YOUR EQUIP
MENT DAMAGED IF THE SAFETY INSTRUCTIONS THAT FOL
LOW THIS SIGNAL WORD ARE NOT OBEYED.
IMPORTANT
INDICATES HELPFUL INFORMATION FOR PROPER ASSEMBLY,
OPERATION, OR MAINTENANCE OF YOUR EQUIPMENT.
NOTE: General information is given throughout the
manual that may help the operator perform the operation
or service of the machine.
pusher. Do not attempt to load the log onto the log splitter
until the log pusher has come to a complete stop. Always
keep hands, feet, hair and loose clothing away from any
moving parts on the log splitter.
should not operate the log splitter without proper
instruction.
of drugs, alcohol, or any medication that could aect your
ability to use the equipment properly.
objects. The ends of the logs must be cut square. Branches
times. Never stand on the log splitter. Do not use the log
splitter as a step.
splitter at a comfortable height (24-32 inches), on a stable,
for handling material. Bolt the log splitter to the work
surface if it tends to slip, walk, or slide.
4
Splitz-it 5-tON electric lOg Spliter
it to rain.
specications table. Failure to do so may damage the
machine. Do not use the log splitter for anything other
than splitting logs. Do not force log through splitter.
use. The cord should not be longer than 30 feet. The cord
should be of a heavy-duty construction (12-10 AWG).
that it corresponds with the power, voltage and frequency
of the motor. Check that there is a ground connection and
a regulation dierential switch upstream. Ground the log
splitter. Prevent body contact with ground surfaces: pipes,
radiatiors, ranges, refrigerator enclosures, etc. Never open
the pushbutton box on the motor. Make sure your ngers
do not touch the plug’s metal prongs when plugging in or
unplugging the log splitter.
becomes lodged in the ram, unplug electric motor before
attempting to remove the foreign object.
explosion hazard.
bolts.
use, before making adjustments, changing parts, cleaning,
or working on the log splitter.
most safe performance.
SAFETY DECAL
The Splitz-it 5-Ton Electric Log Splitter has been designed and
manufactured to provide you with the safety and reliability
you would expect from an industry leader in outdoor power
equipment manufacturing.
Reading this manual, and the safety instructions it contains,
will provide you with the necessary knowledge to operate this
equipment safely and eectively. We have placed a safety de-
cal on the log splitter to remind you of some of the important
information while you are operating the unit.
This important safety decal is illustrated below, and is shown
here to help familiarize you with the location and content of
the safety messages you will see as you perform normal log
splitting operations. Please review this decal now, and if you
have any questions regarding its meaning or complying with
these instructions, reread the complete safety instruction text
in this manual, or contact your local dealer.
The decal below is located on the side panel of the log cradle
above the main power switch. Should this decal become un-
readable, because of being worn, faded, or otherwise damaged
during the use of your log splitter, please use the part number
information provided to order a replacement label from your
local authorized dealer. These decals are easily applied, and will
act as a constant visual reminder to you, and others who may
use the equipment, to follow the safety instructions necessary
for safe, eective operation of your log splitter.
Warning Decal
12345
67 8 9 10 11
STEPS FOR WORKING ON ELECTRIC LOG SPLITTER
1. Turn o motor switch. Unplug motor.
2. Replace or repair the part on the log splitter.
3. Check all parts that were repaired, or removed during
repair, to ensure they are secure and t correctly.
NOTE: All repair parts must come from the factory. Never
replace parts that are not specically designed for this log
splitter.
1. Crush hazard - hand
2. Take care when removing jammed logs from wedge
3. Clean up any spills
4. Read owners manual be fore using
5. Use protective eyeware
7. Unplug before servicing
8. Maintain a safe distance from bystanders when operating
9. Do not operate without guards
10. Use protective footware
11. Use protective gloves.
Splitz-it 5-tON electric lOg Spliter
5
SPECIFICATIONS AND ELECTRICAL REQUIREMENTS
APPLICATION CONDITIONS
The Splitz-it 5-Ton Electric Log Splitter has been designed as a
home use model only. It is designed for operating at ambient
temperatures between 40° F. and 105° F. The log splitter can
be stored or transported under ambient temperatures be-
tween -10° F. and 130° F.
SPECIFICATIONS
Model Number AC02585
Motor 120V~60Hz
1500W IP54
Circuit Protection
Requirements
20 Amps
(Amperes)
Log Capacity Diameter * 2 - 10 inches
Length 20 inches
Splitting Force 5 ton
Hydraulic Pressure 2,300 psi
Hydraulic Oil Capacity 3.75 quarts
Overall Size
Length 37 inches
Width 11 inches
Height 20 inches
Weight 105 lb
*The diameter of the log is not indicative - a small log can be dicult
to split when it contains knobs or a particularly tough ber. On the
other hand, it may not be dicult to split logs with regular bers
even if its diameter exceeds the maximum diameter described in the
specications chart.
ELECTRICAL REQUIREMENTS
Connect the main leads to a standard 110V ±10% electrical
supply which has protection devices under-voltage, over-volt-
age, over-current, as well as a ground fault circuit interrupter
(GFCI) or a ground fault interrupter (GFI) with a maximum
residual current of 0.03A.
6
Splitz-it 5-tON electric lOg Spliter
oil drain plug
dipstick
bleed screw
Figure 2
PARTS TO BE FREE OF
BURRS AND SHARP EDGES
THIS DRAWING AND ALL INFORMATION CONTAINED HEREIN IS AND REMAINS THE PROPERTY OF ARDISAM INC.
AND IS CONFIDENTIAL. IT IS SUBMITTED AND MAY BE USED ONLY IN CONNECTION WITH ARDISAMS' PROPOSALS
AND/OR ITS CUSTOMERS' ORDERS. IT SHALL NOT BE DISCLOSED TO OTHERS OR COPIED
WITHOUT ARDISAMS'
SPECIFIC WRITTEN CONSENT AND SHALL BE IMMEDIATELY RETURNED UPON REQUEST.
MATERIAL
TOLERANCE UNLESS
OTHERWISE NOTED:
0.0 ±.100 INCH ± 2.54 MM
0.00 ±.030 INCH ± 0.76 MM
0.000 ±.010 INCH ± 0.25 MM
ANGLES:
0 ± 2°
0.0 ± 1.0°
THREADS CLASS 2
PRIMARY DIMENSIONS ARE IN INCHES
SECONDARY DIMEMSION ARE IN MM
ALL ANGLES ARE DECIMAL DEGREES
UNLESS OTHERWISE SPECIFIED
NAME
TREATMENT
DR BY APPD PRT NO
W1200
PT WEIGHT
SURFACE AREA DATE
REVISION
THIRD ANGLE PROJECTION
SEE BILL OF MATERIALS
NONE
32121.68
3451644.89
W1200 5 TON ELECTRIC
LOG SPLITTER
1
MATT OLSEN
MDO 9/17/2010
09/17/2010
SHEET: 6 OF 8
SET-UP AND PRE-OPERATION
Before attempting to use, familiarize yourself with all the
operating features and safety requirements of your log splitter.
(SEE FIGURE 1)
1. Wedge 8. 2-hand operating
2. Oil tank hydraulic control lever
3. Carrying handle 9. Safety guard for 2-hand
4. Supporting leg operating hydraulic
5. Motor w/push switch control lever
& circuit breaker 10. Log pusher
6. Rubber feet 11. Log cradle
7. Rolling wheel
WARNING
FOR YOUR OWN SAFETY, DO NOT CONNECT THE LOG
SPLITTER TO THE POWER SOURCE UNTILTHE MACHINE
IS COMPLETELY ASSEMBLED AND YOU READ AND
UNDERSTAND THE ENTIRE INSTRUCTION MANUAL.
FOR YOUR OWN SAFETY, NEVER FORGET TO BOLT THE
WHEEL BRACKET TOTHE LOG SPLITTER, LIFT THE LOG
SPLITTER BYTHE HANDLES AT BOTH ENDS AND PLACE
IT ON A 6075CM HIGH,STABLE, FLAT AND LEVELWORK
SURFACE.
NEVER USE THE LOG SPLITTER IF IT IS NOT IN PERFECT
ORDER OR IF IT NEEDS SERVICING. BEFORE STARTING
WORK, CHECK CORRECT FUNCTIONING OF ALL THE
CONTROLS HYDRAULIC LEVER, PUSH BUTTON.
IMPORTANT
BEFORE OPERATING THE LOG SPLITTER, THE BLEED
SCREW SHOULD BE LOOSENED BY 34 ROTATIONS SO
AIR CAN GO IN AND OUT OF THE OIL TANK SMOOTH
LY. AIR FLOW THRU THE BLEED SCREW HOLE SHOULD
BE DETECTABLE DURING LOG SPLITTER OPERATION.
BEFORE MOVING THE LOG SPLITTER, MAKE SURE
THE BLEED SCREW IS TIGHTENED TO AVOID OIL
LEAKAGE FROM THIS POINT. See Figure 2)
CAUTION
FAILURETO LOOSEN THE BLEED SCREWWILL RESULT IN
AIR BEING COMPRESSED AND DECOMPRESSED INTHE
HYDRAULIC SYSTEM. CONTINUOUS AIR COMPRESSION
AND DECOMPRESSION WILL BLOW OUTTHE SEALS OF
THE HYDRAULIC SYSTEM AND CAUSE PERMANENT
DAMAGE TO THE LOG SPLITTER.
CAUTION
DO NOT ADJUST THE MAXIMUM PRESSURE LIMITING
SCREW. THE PRESSURE LIMITING SCREW HAS BEEN
SEALED ATTHE FACTORYTO PREVENT UNAUTHORIZED
ADJUSTING. RESETTING THE SCREW WILL CAUSE
THE HYDRAULIC PUMP TO FAIL TO OUTPUT ENOUGH
SPLITTING PRESSURE OR CAUSETOO MUCH PRESSURE,
WHICH MAY RESULT IN SERIOUS INJURY, AS WELL AS
DAMAGE TO THE MACHINE.
1
3
2
4
7
56
10
9
11
8
Figure 1
Splitz-it 5-tON electric lOg Spliter
7
ASSEMBLY
1. Attach the control lever assembly by screwing the knob to the end of the lever. (SEE FIGURE 3)
2. Bolt the rolling wheel bracket to the log splitter beam and log cradles using the four M6-1 x 12 bolts and corresponding lock
(SEE FIGURE 3)
3. Attach safety guard lever to the top of the rolling wheel bracket with M6-1 x 12 bolts provided. (SEE FIGURE 3)
4. Assemble the handle bars to the handle, then attache the completed handle bar assembly to the log splitter beam using the
M6 x 12 bolts, the M6 x 1.5 washer, and the M6 x 13 x 1.75 washers provided. (SEE FIGURE 4)
Figure 3
log cradle
log cradle
rolling wheel bracket
control lever assembly
safety guard lever
rolling wheel bracket
M6 bolts
M6 x 13 washer
M6 x 1.5
washer
log splitter beam
Figure 4
4
3
5
completed
handle bar
assembly
M6 x 13 washer
M6 x 1.5
washer
M6 bolts
8
Splitz-it 5-tON electric lOg Spliter
LOG SPLITTER OPERATION
The Splitz-it 5-Ton Electric Log Splitter requires the use of
both hands to operate. The user’s left hand controls the
hydraulic control lever, while the right hand controls the
push button switch. The log splitter will freeze upon absence
of either hand. The log pusher will return back to the starting
position only after both hands release the controls.
(SEE FIGURE 5)
Split the log in the direction of its grain. Placing logs across the
log splitter for splitting is dangerous and may seriously damage
the machine. Do not attempt to split two logs at the same time.
FREEING A JAMMED LOG
1. Release both controls.
2. Once the log pusher completely stops at its starting
position, insert a wood wedge under the jammed log.
(SEE FIGURE 7)
3. Start the log splitter to push the wood wedge under the
jammed log.
4. Repeat above procedure with sharper sloped wood
wedges until the log is completely freed.
hydraulic
contol lever
push button
switch
Figure 6
Figure 7
Figure 8
CAUTION
NEVER FORCE PRESSURE ON THE LOG SPLITTER
FOR MORE THAN 5 SECONDS IN ORDER TO SPLIT
EXCESSIVELY HARD WOOD.
CAUTION
ALWAYS SET LOGS FIRMLY ON THE LOG CRADLE AND
WORK TABLE. MAKE SURE LOGS WILL NOT TWIST,
ROCK OR SLIP WHILE BEING SPLIT. DO NOT FORCE
THE BLADE BY SPLITTING THE UPPER PART OF THE
LOG. THIS WILL BREAK THE BLADE OR DAMAGE THE
MACHINE. SEE FIGURE 6
CAUTION
DO NOT TRY TO KNOCK THE JAMMED LOG OFF THE
WEDGE USING A HAMMER OR OTHER DEVICE. SEE
FIGURE 8
Figure 5
Splitz-it 5-tON electric lOg Spliter
9
MAINTENANCE
REPLACING HYDRAULIC OIL
Replace the hydraulic oil in the log splitter after every 150
hours of use. Take the following steps to replace the oil.
1. Make sure all moving parts are stopped and the log
splitter is unplugged.
2. Remove oil drain bolt and dipstick. Make sure bleed screw
is closed tight. (SEE FIGURE 9)
3. Turn the log splitter on the support leg side over using
a one gallon or larger capacity container to drain the
hydraulic oil. (SEE FIGURE 10)
4. Turn the log splitter on the motor side.
(SEE FIGURE 11)
5. Rell with 3.75 quarts of fresh hydraulic oil.
6. While keeping the log splitter vertical, clean the surface
of dipstick on the oil drain bolt and put it back into the oil
tank.
7. Make sure the level of the relled oil is between the two
grooves around the dipstick.
8. Clean the oil drain bolt before re-threading it back in.
Make sure the bolt is tightened to avoid leakage before
placing the log splitter horizontally.
IMPORTANT: LOOSEN BLEED SCREW 34 TURNS BEFORE
OPERATION.
Periodically check oil level to ensure it is between the two
grooves around the dipstick. If the level is below the lower
limit, ll until level is correct.
The following hydraulic oils, or equivalent, are recommended
for the log splitter’s hydraulic pump:
SHELL Tellus 22
MOBIL DTE 11
ARA Vitam GF 22
BP Energol HLP-HM 22
SHARPENING WEDGE
When the log splitter wedge becomes dull and/or worn,
sharpen the wedge using a ne-toothed le and smooth any
burrs or crushed areas along the cutting edge.
oil drain container
Figure 10
Figure 11
oil drain
plug
dipstick
bleed screw
Figure 9
full mark
10
Splitz-it 5-tON electric lOg Spliter
ORDERING REPAIR PARTS
Parts can be obtained from the store where your mini log
splitter was purchased.
Please include the following information with your order:
1. Part numbers
2. Part description
3. Quantity
4. Model number and serial number
SERVICE INFORMATION
In the event you experience trouble operating your log splitter,
follow the suggestions in the troubleshooting guide in this
section.
The guide will help you pinpoint the causes of common
problems and identify remedies.
We will always be glad to answer any questions you have,
or help you nd suitable assistance. To order parts or inquire
about warranty, see the section ordering repair parts.
SERVICE, TROUBLESHOOTING AND REPAIR
TROUBLESHOOTING
IMPORTANT
IN CASE OF A SERVICE PROBLEM, DO NOT SEND UNIT
BACK TO RETAILER.
CONTACT SBI HEATING ACCESSORIES,
TELEPHONE: 1 418 8783040
EMAIL: tech@sbi-international.com
PROBLEM POSSIBLE CAUSE REMEDY/ACTION
Fails to split logs 1. Log is improperly positioned 1. Refer to Log Splitter Operation Section for log
loading
2. The size or hardness of the log exceeds
the capacity of the machine
2. Reduce the log size before splitting on the log
splitter
3. Wedge cutting edge is blunt 3. Refer to Sharpening Wedge Section to sharpen
the cutting edge
4. Oil leaks 4. Locate leak(s) and contact the dealer
5. Unauthorized adjustment was made onto
the maximum pressure limiting screw
5. Contact the dealer
The log pusher moves with
a jerking motion, makes an
unfamiliar noise or vibrates
excessively
1. Lack of hydraulic oil and excessive air in
the hydraulic system
1. Check oil level for possible oil relling. Contact
the dealer.
Oil leak occurs around cylinder
ram or from other points
1. Air sealed in hydraulic system while
operating
1. Loosen bleed screw 3-4 rotations before
operating the log splitter
2. Bleed screw is not tightened before
moving the log splitter
2. Tighten the bleed screw before moving the
log splitter
3. Oil drain bolt with dipstick is not tight 3. Tighten the oil drain bolt with dipstick
4. Hydraulic control valve assembly and/
or seal(s) worn
4. Contact the retailer
Contact service provider if above remedies fail.
Splitz-it 5-tON electric lOg Spliter
11
SPLITZ-IT 5-TON ELECTRIC LOG SPLITTER BREAKDOWN
17
18
9
10 11
12
27
25
26
29
13
8
7
14
15
16
6
5
4
3
12
28
20
19
22
23
21
24
30
31
12
Splitz-it 5-tON electric lOg Spliter
SPLITZ-IT 5-TON ELECTRIC LOG SPLITTER PARTS LIST
KEY
NO. PART NO. DESCRIPTION QT Y.
1 W120075 BLEED SCREW 1
2 W1200245 O RING 7.5 X 4 X 1.75 W1200 1
3 W120083 OIL DRAIN PLUG W1200 1
4 W120082 O RING 17.5 X 12 X 2.75 W1200 1
5 W120081 1
6 W120067 HANDLE ASSY W1200 1
7 W120066 FRONT LEG WELDMENT W1200 1
8 W120006 FOOT RUBBER W1200 4
9 W1200115 BOLT M61 X 12 HH GR5 ZN FT 20
10 W1200116
COLLAR
16
11 W1200117 WASHER M6 X 13 X 1.75 FLAT ZN 16
12 W120063 LOG CRADLE A W1200 1
13 W120062 LOG CRADLE B W1200 1
14 W1200248 CONTROL LEVER ASSY W1200 1
15 W1200122
COLLAR
2
16 W1200123
OX FT
1
17 W120001 MOTOR ASSEMBLY W1200 1
18 W1200207 FORWARD FOOT W1200 MOTOR 1
19 W120014 O RING PUMP CASTING W1200 2
20 W1200247 PUMP W1200 1
21 400024 WASHER FLAT M8 8.4 X 16 X 1.6
9
22 W1200118
OX FT
3
23 W1200114
HIGH COLLAR
9
24 W1200130
OX FT
6
25 W1200126 WASHER M10 X 28 X 2.8 ZN 2
26 W1265V0903
ZN
2
27 W120021 WHEEL ASSEMBLY W1200 2
28 W120022 1
29 W120087 SAFETY GUARD LEVER W1200 1
30 W1200128 NUT M5 X 4 H GR8.8 ZN 1
31 W120003 VIBRATION DAMPENER W1200 1
Splitz-it 5-tON electric lOg Spliter
13
SPLITZ-IT 5-TON ELECTRIC LOG SPLITTER
Warranty Terms and Conditions
PRODUCT WARRANTY: 1YEAR LIMITED WARRANTY
SBI Heating Accessories, warrants this SPLITZ-IT 5-TON ELECTRIC LOG SPLITTER to be free from defects in the material
or workmanship for a period of one year from the date of purchase. During the one-year warranty of this product, SBI Heating
Accessories, will furnish, at their discretion, parts and labor to correct any defect caused by faulty material or workmanship. Any
unit used in a commercial application is covered for a period of 90 days after purchase. This warranty applies to the original
owner with a proof of purchase and is not transferable.
For replacement parts, phone 418 878-3040
These warranties apply only to products which have not been subjected to negligent use, misuse, alteration, accident,
unauthorized parts, failure to use proper fuel and oil, or if repairs have been performed at non-authorized service centers.
These warranties supersede all other warranties either expressed or implied and all other obligations or liabilities on our part.
SBI Heating Accessories, does not assume, and does not authorize any other person to assume for us, any liability in connection
with the sale of our products. To be at "No Charge," warranty work must be sent directly to SBI Heating Accessories, or one of
our authorized service centers and performed by them.To obtain warranty service and/or replacement instructions, contact our
customer service department at 418 878-3040 Monday through Friday from 8 a.m. to 5 p.m. If you choose to ship your product
to SBI Heating Accessories for warranty repair, you must rst have prior approval from SBI Heating Accessories, calling our
customer service department at 418 878-3040 for a return material authorization number (RMA#). Under these circumstances,
all items must be shipped prepaid. SBI Heating Accessories, will at no charge, repair or replace, at their discretion, any defective
part which falls under the conditions stated above. SBI Heating Accessories, retains the right to change models, specications
and price without notice.
Distributed under SBI Heating Accessories.
Manufactured by Ardisam, Inc.
14
Splitz-it 5-tON electric lOg Spliter
NOTES
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
Splitz-it 5-tON electric lOg Spliter
15
NOTES
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
_______________________________________________________________________________________________________
sbI hEATING AccEssoRIEs
250 rue de copenhague
saint-augustin-de-desmaures
québec, canada g3a 2h3
tel: 418 878-3040
Fax: 418 878-3001
email:inFo@sbi-international.com
This manual suits for next models
1
Table of contents
