SBT 12-500 User manual

SBT 12-500 Cart Assembly
Instructions
Tools needed for Assembly:
(1) 19 mm wrench
(1) 18 mm wrench
(2) 17 mm wrenches
1) Lay out all parts neatly before assembly. As
you assemble, leave all nuts and bolts semi
loose. You will snug up everything upon
completion of the cart.
2) Lay out main frame members and bunks.
v 1.0 © 2012 SBT Inc.
1
3) With supplied hardware assemble the main
frame using the supplied gusset plates.
4) The cart should resemble the below picture.
The brackets you see under the carpeted bunks can be
positioned in two different locations depending on the
width of ski’s hull.

SBT 12-500 Cart Assembly
Instructions
5) When installing the wheels, use the supplied
metal reinforcement plates inside the square
tube and tighten the nuts.
v 1.0 © 2012 SBT Inc.
2
6) Tap the plastic caps in to cover up the wheel
nuts.

SBT 12-500 Cart Assembly
Instructions
7) Install the Z braces to connect the lower frame
to the upright frames, brackets mount on the
underside of the end uprights and on top of
the lower frame tubes.
8) The cart starts to take shape, use the below
picture as reference.
v 1.0 © 2012 SBT Inc.
*Now that everything is assembled, go back and
tighten all of the hardware.
3
