ILLUSTRATED
PARTS
MANUAL
Part No. 06196 Rev 2
Printed 9/09
Printed in USA
© 2009
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
ModelSTC
TigerCat
IPL
30
31
32
33
34
29
33
36
37
40
39
38
41
35
18 18
THIS MANUAL CONTAINSTHE ILLUSTRATED PARTS LIST FOR MODELS:
STC48V-19KAI with a serial number of E4600001 to E4699999
STC48V-23CV with a serial number of E4700001 to E4799999
STC48V-25CV with a serial number of E9000001 to E9099999
STC48V-26BS with a serial number of E4800001 to E4899999
STC52V-25CV with a serial number of E4900001 to E4999999
STC52V-27CV-SS with a serial number of E8900001 to E8999999
STC61V-25CV with a serial number of E5000001 to E5099999
SMTC-48V with a serial number of D9100001 to D9199999
SMWC-52V with a serial number of D9200001 to D9299999
SMWC-61V with a serial number of D9300001 to D9399999

I
R
Table of Contents
Table of Contents
48V & 52V CUTTER DECKS .............................................................................................................................2
61V CUTTER DECK...........................................................................................................................................4
CUTTER DECK CONTROLS.............................................................................................................................6
SHEET METAL COMPONENTS ........................................................................................................................8
STC FOLDABLE ROLL-OVER PROTECTION SYSTEM ................................................................................10
STC SUSPENSION SEAT................................................................................................................................12
NOTES..............................................................................................................................................................13
DRIVE SYSTEM COMPONENTS ....................................................................................................................14
ENGINE & ATTACHING PARTS.......................................................................................................................16
STEERING COMPONENTS.............................................................................................................................18
BRAKE COMPONENTS ..................................................................................................................................20
WHEEL MOTOR PART NUMBER IDENTIFICATION ......................................................................................22
NOTES..............................................................................................................................................................23
FUEL AND HYDRAULIC SYSTEM..................................................................................................................24
ELECTRICAL SYSTEM ...................................................................................................................................26
BDP-10A HYDRAULIC PUMP ASSEMBLY.....................................................................................................28
REPLACEMENT DECALS AND INFORMATION PLATES .............................................................................30
ELECTRICAL SCHEMATIC .............................................................................................................................32

2
R
Section 8
48V & 52V CUTTER DECKS
STC 2006 CD4852 Rev.1
52,
52A
4
18
67
13
12
13
11
6 7 8
5 25
10
57
9
16
47
35
36
37
38
40
41
42
37
43
44
45
34
66
27
68 69
29
64 60 62 61
59 58 66 63
23
15
17
13
66
71
*
* 52" cutter deck has a notch for anti-scalp roller
24
30
65
46
29
21
70
26
22
19
1
33
70
26
55 55
55
14
14
14
53 53
53
56
56
72
73
29
21
49
49 49
49
3
3
3
33
29
80
48
84
54
81
83
3183
83
51
87
50
20
28
32
2
382 75
7776 84
79
78
13
74
88
89
85
86

3
R
Section 8
48V & 52V CUTTER DECKS
Ref.
No. Part No. Description 48 52 Ref. No. Part No. Description 48 52
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
461854
461858
43686
04019-04
481625-01
481632
04003-26
422478
04017-27
04043-06
04021-05
461844
461845
04001-11
04001-12
04021-10
04020-09
45944
04001-41
48038
04001-154
04063-08
483246
04043-04
04001-176
04019-03
04001-51
48100-15
04030-03
04040-15
04001-136
04021-09
04001-31
483247
424369
424409
04110-03
461663
43589
481024
481022
48114-04
48677
43644
43312
43296
481025
43297
481035
43590
482877
482878
483210
48224
461940
Cutter DeckVelocity Plus
Cutter DeckVelocity Plus
Boss, Spring Anchor
Nut, 3/8-16 Serrated Flange
Wing Nut, 3/8-16
Anti-Scalp Wheel
Bolt, Carriage 3/8-16 x 4”
Bracket, Anti-Scalp Wheel
Bolt, Serrated Flange 3/8-16 x 1”
Flatwasher, 5/8” Hardened
Locknut, 3/8-16 Center Lock
Discharge Chute
Discharge Chute
Bolt, Hex Head 5/16-18 x 1-1/2”, Rear
Bolt, Hex Head 5/16-18 x 1-3/4”, Front
Nut, Elastic Stop 5/16-18
Nut, 5/8-11 UNC
Shaft, Roller
Bolt, Hex Head 5/8-11 x 9-1/2”
Roller, Rear
Bolt, Hex Head 5/16-18 x 4-3/4”
Key, 1/4 x 1/4 x 2"
Spring, Idler LH
Flatwasher, 3/8”
Bolt, Hex Head 5/16-18 x 1-3/4”Gr. 8
Nut, Serrated Flange 5/16-18
Bolt, Hex Head 3/8-16 x 3-3/4”
Bushing, .376 ID Oilite
Lockwasher 5/16”
Flatwasher 5/16”
Bolt, Hex Head 3/8-16 x 1-1/2”Gr. 8
Nut, Elastic Stop 3/8-16
Bolt, Hex Head 3/8-16 x 2-1/2”
Spring, Idler RH
Bracket, Spring Anchor LH 48V
Bracket, Spring Anchor LH 52V
U-Nut, 3/8-16
Spindle Assembly
Shaft, Spindle
Seal Upper
Bearing Assembly
Grease Fitting
Valve, Grease Relief
Housing, Spindle
Spacer, Outside
Spacer, Inside
Seal, Lower
Bushing, Bottom
Nut, Special 1-1/16 - 18
Spacer, Spindle
Cutter Blade 16.5”
Cutter Blade 18”
Pulley, Idler 5” Dia.
Bearing
Idler Arm Assy.
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
43689
424322
424323
48926
461946
04001-172
483282
483284
424208
451240
461516
04020-16
04021-13
48763
04001-79
48114-04
483241
483242
04001-09
483378
424839
424840
04003-23
04021-22
04043-04
483239
483240
48181
483283
483285
483167
461929
04003-40
04040-11
04021-11
424367
04030-03
424376
424377
04001-136
04001-19
04021-04
483176
43689
04003-12
04040-04
Idler Pivot
Belt Cover (48V)
Belt Cover (52V)
Hub, Tapered 1-1/8” Bore
Idler Arm
Bolt, Hex Head 1/4-20 x 1”Grade 8
Pulley 4.75”
Pulley 5.35”
Turbo Baffle, Bolt On
Push Arm Shaft
Push Arm (Includes 64,60,62)
Nut, 5/8-18 UNF
Nut, Elastic Stop 5/8-11
Rod End, 5/8 Male RH Thread
Bolt, Hex Head 5/8-11 x 4-1/2”
Grease Fitting, 90 Degree
Belt, Cutter Deck Drive (48V)
Belt, Cutter Deck Drive (52V)
Bolt, Hex Head 5/16-18 x 1”
Spring, Discharge Chute
Baffle Custom-Cut, 48V (7-Position)
Baffle Custom-Cut, 52V (7-Position)
Bolt, Carriage 3/8-16 x 1”
Nut, Elastic Stop 5/16-18 Grade 8
Flatwasher 3/8”
Belt, RH Cutter Deck
Belt, RH Cutter Deck
Pulley, Idler 5” Dia.
Pulley, Double Groove
Pulley, Double Groove
Bolt, Special
Lever Assy., Deck Level
Bolt, Carriage 7/16-14 x 1-1/4”
Flatwasher, 7/16-.500 x 1.25 x .083"
Nut, Elastic Stop 7/16-14
Dust Shield
Lockwasher 3/8”
Bracket, Spring Anchor RH
Bracket, Spring Anchor RH
Bolt, Hex Head 3/8-16 x 1-1/2”Gr. 8
Bolt, Hex Head 3/8-16 x 1”
Nut, Center Lock 5/16-18
Wear Pad
Idler Pivot
Bolt, Carriage 5/16-18 x 3/4”
Flatwasher, 5/16”
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X

4
R
Section 8
61V CUTTER DECK
STWC 2006 CD61
52
4
18
67
13
64 60 62 61
59 58 66 63
23
15
12
13
11
6 7 8
5 25
10
57 22,
22A
46
9
16
19
1
47
35
36
37
38
40
41
42
37
43
44
45
34
6627
68 69
70
29
13
29
21
73 74
12
13
66
17
13
33
71
26
"A"
"A"
21
29
24 14
53 72 4951
32
54
56
56
56
56
31
79
81
55
65
50
32
53
30
82 20
280 80
78
3
28
78
80
80
7675
77
83 84
85
86
80
87
80
80 88
88
90 89
91
92
93
79
2
81
94

5
R
Section 8
61V CUTTER DECK
Ref.
No. Part No. Description Ref. No. Part No. Description
1 461862 Cutter DeckVelocity Plus
2 43687 Boss, Spring Anchor
3 424371 Bracket, LH Spring Anchor 61V
4 481625-01 Wing Nut, 3/8-16
5 481632 Anti-Scalp Wheel
6 04003-26 Bolt, Carriage 3/8-16 x 4”
7 422478 Bracket, Anti-Scalp Wheel
8 04017-27 Bolt, Serrated Flange 3/8-16 x 1”
9 04043-06 Flatwasher, 5/8” Hardened
10 04021-05 Locknut, 3/8-16 Center Lock
11 461846 Discharge Chute
12 04001-11 Bolt, Hex Head 5/16-18 x 1-1/2”, Rear
04001-12 Bolt, Hex Head 5/16-18 x 1-3/4”, Front
13 04021-10 Nut, Elastic Stop 5/16-18
14 04020-09 Nut, 5/8-11 UNC
15 45944 Shaft, Roller
16 04001-41 Bolt, Hex Head 5/8-11 x 9-1/2”
17 48038 Roller, Rear
18 04001-154 Bolt, Hex Head 5/16-18 x 4-3/4”
19 04063-08 Key, 1/4 x 1/4 x 2”
20 483246 Spring, LH Deck Drive
21 04043-04 Flatwasher, 3/8” - .938 x .391 x .105"
22 04001-176 Bolt, Hex Head 5/16-18 x 1-3/4” Grade 8
23 04019-03 Nut, Serrated Flange 5/16-18
24 04001-172 Bolt, Hex Head 1/4-20 x 1” Grade 8
25 48100-15 Bushing, .376 ID Oilite
26 04030-03 Lockwasher 5/16”
27 04040-15 Flatwasher 5/16”
28 483703 Spring, RH Deck Drive
29 04021-09 Nut, Elastic Stop 3/8-16
30 461940 Idler Arm Assembly, LH Drive
31 461946 lder Arm Assembly, RH Drive
32 483286 Pulley,Tapered Bore 6.33” Dia.
33 04110-03 U-Nut, 3/8-16
34 461663 Spindle Assembly
35 43589 Shaft, Spindle
36 481024 Seal Upper
37 481022 Bearing Assembly
38 48114-04 Grease Fitting
39 48677 Valve, Grease Relief
40 43644 Housing, Spindle
41 43312 Spacer, Outside
42 43296 Spacer, Inside
43 481025 Seal, Lower
44 43297 Bushing, Bottom
45 481035 Nut, Special 1-1/16 - 18
46 43590 Spacer, Spindle
47 482879 Cutter Blade 21”
48 483287 Pulley, Double Groove 6.33” Dia.
49 424367 Dust Shield
50 483210 Idler Pulley, 5” Dia.
51 48181 Idler Pulley, 5” Dia.
52 424575 Belt Cover (61V)
53 48926 Hub, Tapered 1-1/8” Bore
54 483415 Idler Pulley, 3-1/2” Dia.
55 43689 Pivot, Idler
56 48224 Bearing
57 424209 Turbo Baffle, Bolt On
58 451240 Push Arm Shaft
59 461516 Push Arm (Includes 64,60,62)
60 04020-16 Nut, 5/8-18 UNF
61 04021-13 Nut, Elastic Stop 5/8-11
62 48763 Rod End, 5/8 Male RH Thread
63 04001-79 Bolt, Hex Head 5/8-11 x 4-1/2”
64 48114-04 Grease Fitting, 90 Degree
65 483243 Belt, Deck Drive 61V
66 04001-09 Bolt, Hex Head 5/16-18 x 1”
67 483185 Spring, Discharge Chute
68 424841 Baffle Custom-Cut, 61V (7-Position)
69 04003-23 Bolt, Carriage 3/8-16 x 1”
70 04041-07 Flatwasher, 3/8-.391 x .938 x .105"
71 04001-77 Bolt, Hex Head 3/8-16 X 3-1/2”
72 483157 Belt, Deck Drive RH
73 482295 Wheel, Anti Scalp
74 45944 Roller Shaft
75 483167 Bolt, Special
76 04003-40 Bolt, Carriage 7/16-14 x 1-1/4”
77 461929 Lever Assy., Deck Level
78 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2” Gr.8
79 04001-19 Bolt, Hex Head 3/8-16 x 1”
80 04019-04 Nut, Serrated Flange 3/8-16
81 04030-04 Lockwasher, 5/16”
82 43689 Pivot, Idler Short
83 04003-12 Bolt, Carr.5/16-18 x 3/4”
84 483176 Wear Pad
85 04040-04 Flatwasher, 5/16-.344 x .688 x .065"
86 04021-04 Nut, Center Lock 5/16”
87 04001-19 Bolt, Hex Head 3/8-16 x 1”
88 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2”
89 04021-11 Nut, Elastic Stop 7/16-14
90 04040-11 Flatwasher, 7/16-.500 x 1.250 x .083"
91 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4”
92 04001-54 Bolt, Hex Head 3/8-16 x 3”
93 04021-09 Nut, Elastic Stop 3/8-16
94 483287 Pulley, Double Groove 6.33" Dia.

6
R
Section 8
CUTTER DECK CONTROLS
STC 2006 CDC
CUTTER DECK
10
11
89
1
2345
6
12
13
14
15
16
17
18
19
20 21
38
26
27
33
19
23
24 25
28
29
29
24
24
24
28
25
23
25
30
31
22
32 24
34
35
43
40
36
37
41 42 7
44
45
46
46

7
R
Section 8
CUTTER DECK CONTROLS
Ref.
No. Part No. Description
1 482624 Rod, Deck Lift Linkage
2 04020-28 Nut, Jam 1/2-20 LH Thread
3 481766 Rod End, 1/2-20 Female Thread
4 04050-10 Retaining Ring, 1/2” External “E”
5 483062 Slide, Deck Height Adjust
6 43487 Pin, Deck Lift
7 423463 Bracket, Cutting Height Adjustment
8 04001-22 Bolt, Hex Head 3/8-16 x 2-3/4”
9 43668 Bushing .502" OD
10 04021-09 Nut, Elastic Stop 3/8-16
11 461874 Lever, Deck Latch
12 422346 Slide, Cutting Height
13 04014-03 Screw, Cap 5/16-18 x 3” FHHS
14 422381 Guide, Short
15 04003-04 Bolt, Carriage 5/16-18 x 1”
16 422380 Guide, Long
17 483177 Spring, Helper
18 04021-05 Nut, 3/8-16 Center Lock
19 04040-09 Flatwasher, 5/8-.656 x 1.312 x .095"
20 04019-04 Nut, 3/8-16 Serr. Flange
21 04001-32 Bolt, Hex Head 3/8-16 x 1-1/4”
22 43678 Swivel Joint LH
23 04061-07 Cotter Pin, 3/16 x 1”
24 04019-04 Nut, Serr. Flange 3/8-16
25 04001-20 Bolt, Hex Head 3/8-16 x 1-1/2”
26 04019-04 Nut, Serr. Flange 3/8-16
27 04021-09 Nut, Elastic Stop 3/8-16
28 48540 Chain
29 48114-04 Grease Fitting, 1/4-28 Self Tap
30 483181 Torsion Spring
31 461929 Lever Assy., Deck Level
32 04004-45 Stud, 1/2-13 x 20”
33 04067-09 Pin
481547 Lanyard
34 04020-09 Nut, 5/8-11 UNC
35 43679 Swivel Joint RH
36 04001-155 Bolt, Hex Head 1/2-13 x 5”
37 481765 Rod End, 1/2-20 Female RH Thread
38 04001-77 Bolt, Hex Head 3/8-16 x 3-1/2”
39 43572 Spacer
40 04021-02 Locknut, 1/4-20
41 43630 Spacer
42 04020-27 Nut, 1/2-20 UNF-2B
43 04021-10 Nut, Elastic Stop 5/16-18
44 45904 Lift Bellcrank Weldment, LH Rear
45905 Lift Bellcrank Weldment, RH Rear
04041-14 Flatwasher, 1.0-1.062 x 1.5 x .048"
04050-08 Retaining Ring, 1” ext.
45 04062-04 Hair Pin Cotter, .177 x 3-1/4”
46 481477 Grip, Deck Latch Lever

8
R
Section 8
SHEET METAL COMPONENTS
STC 2008 BSMC
43
18 19
19 55
28
47
26
29
17
13
15
4
11 7 8 20
10
9
15
30
16 21
27
14
A
15
12
51
50
52
15
53
54
56
41
57 58 59
60
38
30 45
44
31
32
33
34
33
35
36
39
37
49
40
42
44
42 61
62
46
12
47
12
1
25
6A
24
322
25
23
67
A
65
Seat Assy. With Black Arm Rest
63
64
66
66
67

9
R
Section 8
SHEET METAL COMPONENTS
Ref.
No. Part No. Description Ref. No. Part No. Description
1 461918 Main Frame Assembly w/decals
2 04001-73 Bolt, Hex Head 5/16-18 x 3-3/4”
3 482632 Cushion, Back
4 04019-04 Nut, Serr. Flange 3/8-16
5 461989 Plate, Seat Mounting w/decals
6 482111 Cushion, Lower Seat
7 43462 Pin Retainer, Spring
8 481389 Spring
9 ** Battery (not available through Scag)
10 423571 Battery Cover
11 482553 Battery Hold Down Pad
12 04003-12 Bolt, Carr.5/16-18 x 3/4”
13 423556 Battery Box
14 04060-01 Roll Pin, Spring 5/32 x 3/4”
15 04019-03 Nut, Serr.Flange 5/16-18
16 04001-19 Bolt, Hex Head 3/8-16 x 1”
17 482552 Pad, Rubber
18 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4”
19 04019-02 Nut, Serr.Flange 1/4-20
20 451896 Seat Base Support
21 04021-10 Nut, Elastic Stop 5/16-18
22 483385 Seat Assembly w/ adj. rails
23 482108 Arm Pad, RH
482110 Bracket, Armrest RH
24 482107 Arm Pad, LH
482109 Bracket, Armrest LH
25 482183 Channel, Armrest
26 423557 Footplate
27 04021-09 Nut, Elastic Stop 3/8-16
28 04001-19 Bolt, Hex Head 3/8-16 x 1”
29 48566 Cable, Seat Stop
30 451826 Weldment, Caster Support (48” & 52”)
451827 Weldment, Caster Support (61”)
31 481559 Cap, Grease
32 04021-20 Nut, Elastic Stop 1.0"-14
33 48668 Bearing Set
34 482028-01 Plug, 1/4-28
35 481025 Seal, 2.0” OD x 1.625” ID
36 04021-07 Nut, Elastic Stop 1/2-13
37 451471 Yoke, Front Caster Wheel
451658 Yoke, Front Caster Wheel (61”)
38 04001-134 Bolt, Hex Head 1/2-13 x 7-1/2”
04001-167 Bolt, Hex Head 1/2-13 x 9-1/2”(61”)
39 43581 Sleeve - 48”& 52”
43583 Sleeve - 61”
40 482503 Caster Wheel Assembly
482504 Caster Wheel Assembly (61”)
41 424112 Bracket, Hour Meter
42 482622 Seal
43 04001-32 Bolt, Hex Head 3/8-16 x 1-1/4”
44 482621 Roller Bearing
45 48114-04 Fitting, Grease
46 423575 Mounting Bracket, OilTank
47 423764 Mounting Bracket, FuelTank
48 482633 Seat Pan
49 43584 Spacer, Caster Wheel
50 04001-28 Bolt, Hex Head 7/16-14 x 1-1/4”
51 04021-11 Nut, Elastic Stop 7/16-14
52 04030-05 Lockwasher, 7/16"
53 04030-04 Lockwasher. 3/8" Spring
54 04110-03 U-Nut, 3/8-16
55 04003-04 Bolt, Carriage 5/16-18 x 1”
56 423912 Bracket, Fuel Valve
57 04021-05 Locknut, 3/8-16 Center Lock
58 483371 Spring, Seat Latch
59 451897 Seat Latch Weldment
60 04001-100 Bolt, Hex Head 3/8-16 x 6”
61 482625 Rim 48” & 52” (Includes Item 45)
482620 Rim 61” (Includes Item 45)
62 481613 Tire, 13 x 5.0-6 Smooth (48” & 52”)
482619 Tire, 13 x 6.5-6 Smooth (61”)
63 483736 Seat Assembly w/Adjustable Rails
64 483544 Cushion, Back
65 483545 Cushion, Lower Seat
66 483549 Armrest Kit
67 482635 Seat Adjustment Track Set

10
R
Section 8
STC FOLDABLE ROLL-OVER PROTECTION SYSTEM
1
2
3
2
5
3
3
5
5
5
STC 2008 FOLDING ROPS
1
1
6
7
8
910 11
4
4
12
12
12
13
12
12
12
14
14
Seat Assy. With Black Arm Rest

11
R
Section 8
STC FOLDABLE ROLL-OVER PROTECTION SYSTEM
Ref.
No. Part No. Description
1 9512 STC Foldable ROPS Accessory (incl. all items listed)
2 04001-145 Bolt, Hex Head 1/2-13 x 3-1/2”
3 04021-19 Nut, Center Lock 1/2-13
4 483412 Retractable Seat Belt
5 04040-13 Flatwasher, 1/2-.562 x 1.375 x .109"
6 481625-03 Thumb Screw, 5/16-18 NC x 3/4”
7 04062-06 Hair Pin, Cotter
8 483262 Pin
9 04021-19 Nut, Center Lock 1/2-13
10 424407 Bracket, Stop
11 04001-145 Bolt, Hex Head 1/2-13 x 3-1/2”
12 461990 Seat Hardware Kit, STC
13 483451 Bracket
14 483412 Retractable Seat Belt (Seat with Black Armrest)
461990 Hardware Package, Seat Belt Mounting

12
R
Section 8
Ref.
No. Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
9292
04001-178
04040-11
483594
482950
482945
482946
482940
482943
482948
482942
482952
482944
482948
482941
04001-12
43572
483440
Suspension Seat Assembly w/seat belt
Bolt, Hex Head 7/16-20 x 1”
Flatwasher, 7/16-.500 x 1.25 x .083
Retractable Seat Belt
Armrest Only
Armrest Assembly Kit, LH
Armrest Assembly Kit, RH
Back Cushion Kit
Lumbar Kit
Knob Kit
Shock Absorber Kit
Seat Adjustment, Track Set
Weight Adjustment Kit
Knob Kit
Seat Cushion Kit
Seat Drain Kit (Included with Seat Cushion)
Bolt, Hex Head 5/16-18 x 1-3/4"
Spacer
Wire Harness Adapter
34
7
6
5
11
10
9
8
431
2
2
13
13
13
13
12
12
12
12
14
STC SUSPENSION SEAT

13
R
Section 8
NOTES

14
R
Section 8
DRIVE SYSTEM COMPONENTS
STC 2005 DSC
21
22 23 24
25
20
1
27
28
3
1
1
26
19
8
9
10
1
11
7
11
7
12
16 10
13 12
16
18
32
4
6
5
14
10
17
2
2
29
15
28
30
31

15
R
Section 8
DRIVE SYSTEM COMPONENTS
Ref.
No. Part No. Description
1 04021-09 Nut, Elastic Stop 3/8-16
2 04019-04 Nut, Serrated Flange 3/8-16
3 483087 Spring, Pump Idler
4 43286 Spacer
5 04001-22 Bolt, Hex Head 3/8-16 x 2-3/4”
6 461603 Idler Arm Assy., Pump Drive
7 04063-14 Key, 5 x 5 x 25mm
8 483172 Belt, Transmission
9 483415 Pulley, 3-1/2” Dia. Idler
10 04043-04 Flatwasher, 3/8-.391 x .938 x .105"
11 482744 Pulley, 5.75" OD Taper Bore
12 482085 Hub, Tapered, 15mm Bore
13 04001-45 Bolt, 3/8-16 x 2”
14 43503 Pivot, Idler
15 48224 Bearing
16 04001-172 Bolt, Hex Head 1/4-20 x 1” Grade 8
17 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2”
18 04001-20 Bolt, Hex Head 3/8-16 x 1-1/2”
19 483081 Pulley, 5.75" Dia. - 1.125” Bore
20 421203 Clamp Plate
21 04017-05 Hex Head Capscrew, 1/4-20 x 3/4”
22 422969 Control Lever, Pump
23 04017-05 Hex Head Capscrew, 1/4-20 x 3/4”
24 04030-02 Lockwasher, 1/4”
25 48829 Block, Pump Control
26 04060-06 Roll Pin
27 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2” Grade 8
28 04019-04 Nut, Serr. Flange 3/8-16
29 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2” Grade 8
30 424137 Bracket
31 04001-19 Bolt, Hex Head 3/8-16 x 1”
32 483215 Pulley, 5” Dia. Idler

16
R
Section 8
ENGINE & ATTACHING PARTS
2008 STC EAPBS
1
11
5
2
4
4
3
15
8
12
7
9
14
13
4
10
6
16
4
17

17
R
Section 8
Ref. No. Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
482932
483875
483281
483685
482900
423770
424107
41031
04019-04
482510
482349
04003-23
04104-01
483288
483266
483102
424133
423555
04001-11
04001-19
04011-12
483280-01
04003-31
04019-03
424415
Engine, Kawasaki 19hp KAI
Engine, Briggs & Stratton 26hp ELS
Engine, Kohler Command 23hp
Engine, Kohler Command 25hp
Engine, Kohler Command 27hp
Bumper, Rear
Shield, Rear (48” & 52”)
Weight, Rear Shield ( 61” Only)
Nut, Serr. Flange 3/8-16
Extension, Oil Drain 3.3”
Extension, Oil Drain 4" (Kohler)
Bolt, Carr. 3/8-16 x 1”
Bolt, 3/8-16 x 1”Torx
Muffler (Briggs & Stratton)
Muffler (Kohler)
Muffler (Kawasaki)
Bracket, Muffler
Plate, Skid
Bolt, Hex Head 5/16-18 x 1-1/2”
Bolt, Hex Head 3/8-16 x 1”
Screw, Hex Head 5/16-18 x 3/4” SelfTap
Tubing, Oil Drain 1/2” x 8”
Bolt, Carr. 3/8-16 x 3/4”
Nut, Serr. Flange 5/16-18
Guard, Carb Inlet (STC48V-26BS Only)
ENGINE & ATTACHING PARTS

18
R
Section 8
STEERING COMPONENTS
STC 2002 SSC
1
2
345
7
8
38
39
19 20
32
40
41
42
15
25
27
28
45
35
35
34
9
34
29, 29A
22
37
16
10 11
12 13 14
18 18
30
21
617
31
17
33,
33A
26
23
To Pump
24
