Scan Corporation SCWBS-1 User manual

Wire Less Bar Code Scanner
User Manual
Version：TS_UM_EN_V1.0.2
Jun.2011

WIRE LESS BAR CODE SCANNER
2
Notice
1. Please carefully read the User Manual before using the barcode the scanner.
2. All software, including firmware, furnished to the user is on a licensed basis.
2. The right is reserved to make changes to any software or product to improve reliability, function, or design.
3. The material in this manual is subject to change without notice.

WIRE LESS BAR CODE SCANNER
1
Contents
Notice.........................................................................................................................................................................2
Contents.....................................................................................................................................................................1
Parts of the scanner and Host.....................................................................................................................................3
Parts of the scanner.............................................................................................................................................3
Panels of Host .....................................................................................................................................................3
Introduction to installation.........................................................................................................................................4
Installation Host..................................................................................................................................................4
Charging....................................................................................................................................................................6
Scanning.....................................................................................................................................................................7
Programming instruction ...........................................................................................................................................8
Programming without Parameter .......................................................................................................................8
Programming with Parameter.............................................................................................................................8
Set Defaults And Information Display...................................................................................................................... 10
Set Factory Defaults.......................................................................................................................................... 10
Products Information Display........................................................................................................................... 10
Communication Information and Battery Power Display.................................................................................. 10
Interface selection..................................................................................................................................................... 11
Scanning Mode Setting............................................................................................................................................. 12
Keyboard wedge....................................................................................................................................................... 13
USB interface ........................................................................................................................................................... 17
RS-232 Interface....................................................................................................................................................... 20
Global Settings......................................................................................................................................................... 24
Indication................................................................................................................................................................. 27
Wire Less Communication Setting .......................................................................................................................... 28
EAN-13 and ISBN/ISSN........................................................................................................................................... 31
EAN-8 ...................................................................................................................................................................... 33
UPC-A...................................................................................................................................................................... 35
UPC-E...................................................................................................................................................................... 37
Code128 C................................................................................................................................................................ 39
Code 39 .................................................................................................................................................................... 43
Code 93 .................................................................................................................................................................... 46
Interleaved 2 of 5...................................................................................................................................................... 48
Industrial 2 of 5........................................................................................................................................................ 50
Matrix 2 of 5............................................................................................................................................................. 52
Codabar................................................................................................................................................................... 54
Code 11 .................................................................................................................................................................... 56
MSI/Plessey.............................................................................................................................................................. 58
UK/Plessey ............................................................................................................................................................... 60
GS1 DataBar (GS1 DataBar Truncated) .................................................................................................................. 62
GS1 DataBar Limited............................................................................................................................................... 63

WIRE LESS BAR CODE SCANNER
2
GS1 DataBar Expanded ........................................................................................................................................... 64
Advanced Bar Code Data Formatting ...................................................................................................................... 66
Prefix................................................................................................................................................................ 66
Suffix ................................................................................................................................................................ 66
Preamble........................................................................................................................................................... 67
Postamble.......................................................................................................................................................... 67
Code ID............................................................................................................................................................. 67
Code ID position ............................................................................................................................................... 67
Code name transmission ................................................................................................................................... 68
Code length transmission.................................................................................................................................. 68
Case conversion: ............................................................................................................................................... 68
Insert String G1 Setting .................................................................................................................................... 68
Insert String G2 Setting .................................................................................................................................... 69
Insert String G3 Setting .................................................................................................................................... 69
Insert String G4 Setting .................................................................................................................................... 69
FN1 substitution string setting .......................................................................................................................... 69
Truncate leading G5 String setting.................................................................................................................... 69
Truncate ending G6 string setting..................................................................................................................... 70
Replace String Setting....................................................................................................................................... 70
Test Bar Code................................................................................................................................................... 71
Appendix 2 Default setting for each barcode ............................................................................................................ 72
Appendix 4 Decode zone........................................................................................................................................... 73
Appendix 6 ASCII Table.......................................................................................................................................... 74
Appendix 10 Parameter bar code ............................................................................................................................. 75

WIRE LESS BAR CODE SCANNER
3
Parts of the scanner and Host
Parts of the scanner
①Exit window
②LED
③Trigger
④Cable interface port / charging port
⑤Release-hole of the cable
Panels of Host
1．Host Port
2．Power Port
（Reserved）
3．Charging Port
4．Channel Settings
button
5．Pairing Button
6．LED

WIRE LESS BAR CODE SCANNER
4
Introduction to installation
Installation Host
1. Switch off the host;
2. Refer to the below pictures, connect the PC with the scanner based on different cables;
3. Ensure that all connections are secure.
4. Switch on the host system. If installation is successful, the beeper will beep and LED will light.
USB cable
PS2 cable

WIRE LESS BAR CODE SCANNER
5
RS232 cable

WIRE LESS BAR CODE SCANNER
6
Charging
When the green LED keeps flashing or the Scanner shut down immediately after powered up, these mean the
battery of Scanner runs out, and need Charging.
Connect the scanner to the Host with the Charging Cable to charge Scanner. The green LED keeps flashing when
the Scanner is charging until this operation is finished.
Charging

WIRE LESS BAR CODE SCANNER
7
Scanning
When the scanner is scanning, ensure the scan line crosses every bar and space of the bar code.
RIGHT RIGHT
WRONG WRONG
the Scan Line on the bar code

WIRE LESS BAR CODE SCANNER
8
Programming instruction
The scanner is programmed by scanning the setting barcode in the Manual. There are two kinds of Programming
instructions. One of them programmed with Parameter and the other one of them without Parameter.
Programming without Parameter
When programming without parameter, only one setting barcode is need to be scanned. For example, shut down the
beeper of the scanner just scan the bar code directly.
When it is programmed successful, the scanner issue a “beep beep”sound, but issue a “beep beep beep”sounds
when programmed fails.
Mute
NOTE: the factory default settings are indicated with asterisks (*).
Programming with Parameter
It is need to scan more than one setting barcode to program the scanner with parameter.
Program Parameters
The steps of programming are:
1. Scan the Function Setting Barcode. The Scanner will issue a "beep” sound, and the Red LED is on until the
program is finished.
2. Scan the parameters bar code. The parameters may be one or more than one digits.
3. Scan the setting barcode “Finish Setting”. If it is programmed successful , the scanner will issue a “beep beep”
sound, but issue a “beep beep beep”sound when fails.
e.g.：Set min. code length of Code 128 to 5 chars ：
1：Open the manual and turn chapter "code128 ". Scan the setting bar code “Scan Min. Code Length”.
Scan Min. Code Length（2 Digits；00~99，1*）

WIRE LESS BAR CODE SCANNER
9
2：Turn to the last page of this Manual Appendix 10 Parameter bar code, scan the parameter bar code “0”and
“5”：
0
5
3：Scan “Finish Setting”, finish the setting。
Finish Setting

WIRE LESS BAR CODE SCANNER
10
Set Defaults And Information Display
Set Factory Defaults
If you wish to return the base unit to the entire factory default settings (radio communication setting is not
included), scan the barcode ”Set Defaults”.
Set Defaults
Products Information Display
If you wish to display the firmware version or Serial number of the scanner, scan the barcode below.
Scanner Information Display
Scanner Serial number Display
If you wish to display the firmware version or Serial number of the Host, scan the barcode below.
Host Information Display
Host Serial number Display
Communication Information and Battery Power Display
Battery Power Display
Communication Channel and ID Number or Scanner Display

WIRE LESS BAR CODE SCANNER
11
Interface selection
This scanner supports interfaces such as keyboard wedge, RS-232 serial wedge, and USB interface.
Typically, host is able to identify the host port type automatically. In extreme cases, host port may need setting
manually if the host fails to identify it.
Automatic Identification*
USB
PS/2 Key Board
RS232

WIRE LESS BAR CODE SCANNER
12
Scanning Mode Setting
Good-read off scanning Mode: The trigger button must be pressed once to activate scanning. The light source of
scanner stops scanning when there is a successful reading or no code is decoded after the Stand-by duration
elapsed. Select Good-read off scanning Mode *
Auto-detection scanning Mode: The scanner will start scan Automatically if any object enter the scan area. The
laser light of scanner stops scanning when there is a successful reading or no code is decoded after the Stand-by
duration elapsed. Once the laser light stops scanning, the present object must be remove away from the scan area to
enable Auto-detect sensor. Select Auto-detection scan
Press Scanning Mode：It can continue scan barcode when the button is continuing pressed.
Press Scanning Mode
Click Scanning Mode: When the button is click, the scanner will keep scanning the barcode until the barcode is
reader or the Stand-by duration elapsed. Click Scanning Mode
Continuous Scanning mode: the scan engine is always scanning and decoding. The module will read the
barcode which gets into the scanning area automatically. Only when the barcode that has been read gets out of the
scanning area, the module can read the next barcode.
Select Continuous Scanning mode
Auto Continue mode: The scanner will start continuous scan Automatically if any object enter the scan area.
When there is no bar code is read for half a minute, the scanner shutdown the laser line and exit continuous
scanning mode. Auto Continue mode

WIRE LESS BAR CODE SCANNER
13
Keyboard wedge
Keyboard type
IBM AT，PS/2 *
Other（Reserved）
Keyboard layout
USA *
Italian
French
Turkish F
Turkish Q
Clock period
According to the PS2 protocol, the clock is provided by the device, e.g. keyboard or scanner, with the period
between 60us to 200us.
60 uS
80 uS*
100 uS
200 uS

WIRE LESS BAR CODE SCANNER
14
Delay-after-compound-key
In some rare occasions, machine with low speed PS2 communication portwould require a free time gap following
the press/release of the compound key (Shift, Ctrl or Alt).
0 mS*
10 mS
20 mS
40 mS
80 mS
Numeric key:
Alphabetic key *
Numeric keypad
Alt+ keypad
Power-on simulation
All of the PCs check the keyboard status during power-on self test. It simulates keyboard timing and passes
keyboard present status to the PC during power-on.
Enable
Disable *
Inter-character delay
This delay is inserted after each data character transmitted.
0 mS*

WIRE LESS BAR CODE SCANNER
15
5 mS
10 mS
20 mS
40 mS
80 mS
Inter-byte delay:
This delay is inserted after each byte transmitted. Normally a character is comprised of three or above bytes.
1 mS*
2 mS
4 mS
8 mS
Caps Lock reversion
By setting enable, the status of Caps Lock key (i.e. being pressed ON or OFF) on the keyboard is simulated in a
reversion status. Enable Caps Lock *
Disable Caps Lock
Caps Lock override

WIRE LESS BAR CODE SCANNER
16
If this function is enabled, on AT or AT notebook hosts, the keyboard ignores the state of the Caps Lock key.
Therefore, an „A‟ in the bar code is sent as an „A‟ no matter what the state of the keyboard‟s Caps Lock key
Enable
Disable*

WIRE LESS BAR CODE SCANNER
17
USB interface
USB device type
HID Keyboard*
Virtual RS232 Port（reserved）
IBM Table Top USB
IBM Hand-Held USB
USB OPOS Hand-Held
USB Keyboard layout
USA*
German
French
Other
USB Keystroke Delay
No Delay*
20mS
40mS

WIRE LESS BAR CODE SCANNER
18
USB CAPS Lock Override
Enable*
Disable
USB Ignore Unknown Characters
Enable
Disable*
Emulate Keypad
Enable this to send all characters as ASCII sequences over the numeric keypad. For example, ASCII A transmits as
“ALT make” 0 6 5 “ALT Break Enable
Disable*
Simulated Caps Lock
Enable this to invert the upper and lower case characters on the scanned bar code as if the Caps Lock state is
enabled on the keyboard. This inversion occurs regardless of the keyboard‟s Caps Lock state
Enable
Disable*
USB Keyboard FN 1 Substitution
This option applies only to the USB HID Keyboard Emulation device. When enabled, this allows replacing any FN
1 characters in an EAN 128 bar code with a Key Category and value chosen by the user.
Enable
