SC&T AA002 User manual

Smart Cabling & Transmission Corp.
V1.0
Audio Microphone Series
User Manual
Model : AA002
Audio Pick up Box with 45cm power/audio cable

1
User Manual
AA002
Introduction
AA002 is a CCTV microphone designed to record the sound for a CCTV camera with sensitivity at -65dB..
Features
Records audio for a CCTV camera.
Supports sensitivity at -65dB.
Built-in a 45cm DC plug/ audio cable..
Installation View
Remark: Since Hi sensitivity microphone, AA002 audio pick up box must be put at 5 meters away from
monitor to avoid any audio reverberation.

2
User Manual
AA002
Specification
ITEM NO.
AA002
Support
Sensitivity
-65dB (±3dB@ 1 KHz)
Frequency Response
30Hz to 16KHz
Ports & Interfaces
Audio Output
1 x RCA Female Jack (2.2KΩ, 2V p-p)
Power Interface
1 x DC Jack
Power
Power Supply
DC 12V (±0.5V)
Power Consumption
10 mA
Ambient Temperature
Operation
-10 to 45℃
Storage
-30 to 60℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
50 x 14 x 14mm & 450mm Cable
Weight
35g
