SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
1. User Manual ............................................................................................ p. 2
2. Legal Regulations................................................................................... p. 2
3. Safety Instructions ................................................................................. p. 3
4. Technical Information............................................................................. p. 4
5. Functional Principle ............................................................................... p. 4
6. Technical Data......................................................................................... p. 5
7. Performance Graph ................................................................................ p. 6
8. Mounting.................................................................................................. p. 7
9. Cutout Dimensions................................................................................. p. 8
10. Dimensions (H x W x D) ......................................................................... p. 9
11. Electrical Connection ............................................................................. p. 10
12. Wiring Diagram ....................................................................................... p. 11
13. Taking Into Operation............................................................................. p. 12
14. Repair....................................................................................................... p. 12
15. Maintenance & Cleaning ........................................................................ p. 12
16. Maintenance ............................................................................................ p. 13
17. Transportation & Storage....................................................................... p. 14
18. Parts Supplied......................................................................................... p. 14
19. Warranty / Limits of Liability ................................................................. p. 15
User Manual SCE-TE340B24VSS

B
2
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
1. User Manual
This instruction manual contains information and instructions to enable the user to work safely, correctly and economically
on the unit. Understanding and adhering to the manual can help one:
• Avoid any dangers
• Reduce repair costs and stoppages
• Extend and improve the reliability and working life of the unit
PLEASE ENSURE TO USE THE RIGHT VERSION OF THE INSTRUCTION MANUAL SUITABLE FOR YOUR UNIT
Conditions of Use
The unit is to be used exclusively for the dissipation of heat from control cabinets and enclosures in order to protect
temperature sensitive components in an industrial environment. To meet the conditions of use, all the information and
instructions in the instruction manual must be adhered to.
General Danger
Indicates compulsory safety regulations which are not covered by a specic
pictogram such as one of the following.
High Electric Voltage
Indicates electric shock danger.
Important Safety Instruction
Indicates instructions for safe maintenance and operation of the unit.
Attention
Indicates possible burns from hot components.
Attention
Indicates possible damage to the unit.
Instruction
Indicates possible danger to the environment.
2. Legal Regulations
Liability
The information, data and instructions contained in this instruction manual are current at the time of going to press. We
reserve the right to make technical changes to the unit in the course of its development. Therefore, no claims can be
accepted for previously delivered units based on the information, diagrams or descriptions contained in this manual. No
liability can be accepted for damage and production caused by:
• Disregarding the instruction manual
• Operation error
• Inappropriate work on or with the unit
• The use of non-specied spare parts and accessories
• Unauthorized modications or changes to the unit by the user or his personnel
Saginaw Control & Engineering is only liable for errors and omissions as outlined in the guarantee conditions contained in
the main contractual agreement. Claims for damages on any grounds are excluded.

B
3
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
3. Safety Instructions
Upon delivery the unit is already meeting current technical standards, therefore it can be safely taken into operation. Only
trained specialists are allowed to work on the unit. Unauthorized personnel must be prohibited from working on the unit.
Operating personnel must inform their superiors immediately if any malfunction of the unit becomes apparent.
Please note that before starting to work on or with the unit, a procedure must be carried out inside the cabinet on which the
unit is to be mounted.
Before commencing work inside the cabinet, the control cabinet manufacturer’s instruction must be read with regards to:
• Safety instructions
• Instructions on taking the cabinet out of operation
• Instructions on the prevention of unauthorized cabinet reconnection
The electric equipment meets the valid safety regulations. One can nd dangerous voltage (above 50V AC or above 100V
DC):
• Behind the control cabinet doors
• On the power supply in the unit housing
The units have to be fused according to the type plate and the wiring diagram. Switch the unit o immediately if the electric
power supply is interrupted.
Danger Through Incorrect Work on the Unit
Only specialized personnel are allowed to maintain and clean the unit. Regular maintenance
and cleaning must be kept in order to ensure that the unit remains in perfect working condition
and has a long working life.
Danger from Electric Voltage
Only specialized personnel are allowed to maintain and clean the unit. The personnel must
ensure that for the duration of the maintenance and cleaning, the unit is disconnected from
the electrical supply.
Attention
Damage to the unit through the use of inappropriate cleaning materials. Please do not use
aggressive cleaning material.
Instruction
Damage to the environment through unauthorized disposal. All spare parts and associated
material must be disposed of according to the environmental laws.

B
4
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
4. Technical Information
Peltier cooling units are intended to be used as a complementary accessory to larger industrial equipment. They are used
where heat needs to be dissipated from electrical control cabinets or similar enclosures in order to protect heat sensitive
components.
Peltier cooling units can dissipate heat from sealed enclosures such as control cabinets. At the same time they can reduce
the cabinet internal temperature to below the ambient air temperature. They are available in powder-coated sheet steel or
stainless steel housings. Peltier units have additional heating function by changing the supply polarity of the thermoelectric
elements. This is possible by using a combination of thermostats or having a specific polarity controller.
Peltier cooling units are resistant to extreme ambient conditions and can operate effectively even in environments which are
dusty and oily and where temperatures may vary from -4°F to 149°F. For the cooling capacities and environmental ratings
please refer to the type plate data.
5. Functional Principle
Functional Principle
The thermoelectric elements create a temperature difference between the internal and ambient heat sinks, making internal
air cooler while dissipating heat into the external environment. Fans help the transfer of convective heat from the heat
sinks, which are optimized for maximum flow. Peltier units can be mounted in any position because these units don’t have
a compressor or any moving parts. Depending on the mounting situation, the condensation management may need to be
considered and possibly adjusted.
1. Ambient Fans
2. Ambient Heat Sinks
3. Thermoelectric Elements
4. Insulation
5. Internal Heat Sink
6. Internal Fan

B
5
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
6. Technical Data
Part Number SCE-TE340B24VSS
Cooling Capacity @ 95°F / 95°F 340 BTU (100 Watts)
Operating Temperature Range -4°F - 149°F
Air Volume Flow Ambient Air Circuit: 75 cfm
Cabinet Air Circuit: 27 cfm
Mounting Recessed
Housing Material Stainless Steel AISI 304
Dimensions (H x W x D) 7.9 x 12.0 x 5.4 inch
Cutout Dimensions 10.24 x 6.30 inch
Weight 13 lbs
Rated Operating Voltage 24V DC
Rated Current 4.8 A
Starting Current 7.4 A
Max Current 5.6 A
Nominal Power @ 95°F / 95°F 115 W
Max Power 132 W
Fuse Rating 8A (T) - Time Delayed [Slow Acting]
Circuit Breaker - MCB Type D or K Slow Acting 8A Slow Acting
Connection Connection Terminal Block
NEMA Protection Class NEMA 3, 3R, 4, 4X & 12
Approvals CE / cURus
Industry Standards IS20

B
6
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
7. Performance Graph
Thermoelectric Cooler 340 BTU/HR (100 Watts)
Performance Curve
Ambient Temperature (°C)
Cooling Capacity
(BTU)
SCE-TE340B24VSS
Enclosure Air Temp
149°F/65°C 122°F/50°C 95°F/35°C 68°F/20°C
Cooling Capacity
(Watt)
Ambient Temperature (°F)
-4 6 16 26 36 46 56 66 76 86 96 106 116 126 136 146
1300
1200
1100
1000
900
800
700
600
500
400
300
200
100
0
-20 -14 -9 -3 2 8 13 19 24 30 36 41 47 52 58 63
381
352
322
293
264
234
205
176
146
117
88
59
29
0
Thermoelectric Cooler 340 BTU/HR (100 Watts)
Heating - Performance Curve
SCE-TE340B24VSS
Enclosure Air Temp
Ambient Temperature (°C)
Watt
Ambient Temperature (°F)
0 10 20 30 40 50 60 70 80 90 100 110
-18 -12 -7 -1 4 10 16 21 27 32 38 43
381
352
322
293
264
234
205
176
146
117
88
59
29
0

B
7
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
8. Mounting
Always switch o power supply before starting any work on the unit.
Installation
Ensure that ows of air leaving and entering the cooling unit, internal and external, are not obstructed. Before drilling the
enclosure, ensure the xing elements and couplings will not interfere with the equipment inside the enclosure itself. When
all mounting preparations are complete, the actual mounting operation can commence. Only use the enclosed material to
mount the unit on the cabinet.
Proceed as follows to mount the unit on the enclosure:
• Set the unit up on the enclosure.
• Ensure that the electrical connection is above the internal fan.
• Unit without duct: screw the M6 locknuts & washers into the M6 set screws in the unit.
• Unit with duct: screw the M6 screws & washers into the M6 threaded rivets in the unit.
The resistance of the earth connection between cabinet and cooling unit must be <0.1 Ω.

B
8
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
9. Cutout Dimensions
Note:
Primary dimensions in millimeters.
Secondary dimensions in inches.
160 [6.30]
260 [10.24]
304 [11.97]
200 [7.87]
Ø8 [Ø0.31]
185 [7.28]
285 [11.22]
160 [6.30]
TOP

B
9
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
10. Dimensions (H x W x D)

B
10
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
11. Electrical Connection
High electric voltage present.
Installation, maintenance, cleaning and any other work must be carried out by
qualied personnel only. The personnel must ensure that for the duration of this work
the unit and the cabinet are disconnected from the electrical supply and protected
against unauthorized/accidental reconnection.
Instruction
Check that the available voltage, frequency and fuse rating are the same as those stated on the data label.
Connection to the main electricity supply
The mains connection is made via a cable. To connect the unit to the mains supply proceed as follows:
• Disconnect the control cabinet from the mains.
• See the connection details on the circuit diagram.
• Note the connections on the four pole terminal block from the following table:
Terminal 24 V DC
1Ambient Fan +
2 Ambient Fan –
3 Internal Fan +
4 Internal Fan –
5 Thermoelectric Elements +
6 Thermoelectric Elements –
Ensure that the correct polarity is maintained. The fans should have a clockwise
rotation.
• Connect the unit to the mains.
• Take the control cabinet back into operation in the prescribed manner.
Power consumption and start-up current are stated on the data label and under technical data.

B
11
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
12. Wiring Diagram
Part List
TE Thermoelectric Elements (Peltier)
IF Internal Fan
AF Ambient Fan
24 VDC
Thermostat
0 VDC
1 + 2 - 3 + 4 - 5 + 6 -
TE
AF IF
Ambient
Fan
1 +
2 -
3 +
4 -
5 +
6 -
Internal
Fan
Thermoelectric
Elements +24 VDC
-
Thermostat SCE-TEMEVDC
Thermostat SCE-TEMNO

B
12
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
13. Taking Into Operation
The power supply rating on the rating plate must comply with mains supply.
Always disconnect the power supply before opening the unit.
Heat load to be dissipated from enclosure should not exceed specic cooling output of the unit at any condition. While
selecting a cooling unit always cater for a safety margin of at least 15% extra cooling output.
The Peltier - elements should be controlled by a suitable thermostat. We recommend the SCE-TEMEVDC Thermostat.
14. Repair
In case of fault Contact Saginaw Control & Engineering - Customer service department at 1-800-234-6871 or E-Mail
[email protected]
15. Maintenance & Cleaning
Always switch o power before starting any work on the unit. Only qualied
personnel may conduct any maintenance work on the cooling unit.
All Peltier units are virtually maintenance-free with no lters that need to be cleaned or replaced. Check the ambient heat
sinks from time to time. In case they are dirty proceed as following:
• Disconnect the enclosure from the mains.
• Clean the heat sink prole as required by blowing it out with compressed air.
• In cases of extreme pollution wet cleaning is required.
The unit must be removed from the control cabinet for wet cleaning.
Should a wet cleaning be necessary proceed as following:
• Disconnect the whole plant from the mains.
• Remove the unit from the cabinet.
• Ensure that the seals are not damaged.
• Wash the heat sink with an environmentally safe cleaning uid.
Danger to the environment through unauthorized disposal.
Disposal
Dispose of cooling unit and used parts with due regard for the environment and in accordance with environmental laws and
regulations.

B
13
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
16. Maintenance
Note: Only use original replacement parts when repairing the unit. This ensures that the unit functions perfectly and
remains safe.
Fan replacement: The average working life of the fan is ca. 40,000 hours under normal conditions. Should a fan
replacement be necessary proceed as following:
Danger from Electrical Voltage
Ensure that for the duration of the work the unit and the cabinet are disconnected from
the electrical supply and protected against unauthorized reconnection.
• Disconnect the unit from the mains.
• Remove the unit cover.
• Remove the screws from the relevant fan.
• Mount the new fan.
Danger Through Incorrect Work
Make sure that the cabinet fan or the ambient fan are not misplaced in the unit as
they are dierent. Ensure that the correct polarity is maintained. The fans must rotate
clockwise!
• Remove the 4 fan xing screws
• Close the unit and take it back into operation.

B
14
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
17. Transportation & Storage
Malfunction Due to Transport Damage
On delivery the carton containing the unit must be examined for signs of transport
damage. Any transport damage to the carton could indicate that the unit itself has
been damaged in transit, which in the worst case could mean that the unit will not
function.
During transport and storage the cooling unit must be kept in the position marked on the box and at a temperature between
-40˚F and 158˚F and a relative humidity of max. 95% (at 77°F). In case of damaged packaging after transport or in-house
handling, we recommend controlling the unit for any internal damages.
18. Parts Supplied
1 x Peltier Cooling Unit
1 x Instruction Manual
1 x CE Conformity Declaration
6 x M6 Nuts
6 x Washers
Saginaw Control and Engineering
95 Midland Road
Saginaw, MI 48638-5770
Phone: [phone]
Fax: [phone]
[email protected]

B
15
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
back to top
19. Warranty / Limits of Liability
All goods manufactured by SCE shall be warranted to be free of defects in material or workmanship for a period of two years
from the date of shipment. Should the product be proven to SCE to be defective, we shall option to repair or replace the
product. At no time will SCE reimburse purchaser for unauthorized rework on any product.
Air Conditioners & Heat Exchangers are warranted on parts and service for a period of two years from the date of shipment
by Saginaw Control and subject to the following conditions and exclusions:
All Goods must be installed and operated according to the following specications: Maximum voltage variation no
greater than plus or minus 10% of nominal rating; Maximum frequency variation no greater than plus or minus 3
Hz. from nominal rating; Must not exceed minimum and maximum rated temperatures; Must not exceed (BTU/Hr)
rating; Filters must be cleaned regularly; Must be installed and grounded in accordance with all relevant electrical
and safety codes, as well as the National Electric Code and OSHA rules and regulations; Must be installed in a
stationery application, free of vibration.
Our warranty does not warranty product that has been modied, subjected to abuse, negligence in operation or
maintenance, or if product is used in a manner that exceeds its designed capabilities and rating.
Warranty related claims will be returned to the factory for evaluation and nal disposition of the claim, any replacement parts
will be invoiced at standard pricing and credit issued for the returned product. If the product has been found to have been
modied, subjected to abuse, negligence in operation or maintenance, or if product has been used in a manner that exceeds
its designed capabilities and rating, credit may be reduced, denied or additional cost may be assessed and passed on to the
purchaser, such as return freight.
