nThe appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
nChildren should be supervised to ensure that they do not play with
the appliance.
nThe device should only be used with the power supply supplied with
the device.
nThe appliance is only to be used with the recommended vaporizing
medium.The use of other substances may give rise to a toxic or fire risk.
---
nPlease leave 30 mm around the Hubble control unit to ensure normal
functioning of the product.
nDimensions of the Hubble control unit: H 94 mm x W 63 mm x D 32 mm.
nDimensions of the folded fan and capsule holder:
H 84 mm x W 44 mm x D 48 mm.
nProvide an air outlet of dimensions 100 mm x 20 mm or a hole of
diameter 50 mm for the supply of fresh air.
nProvide an outlet for fragranced air of 40 mm x 40 mm or a hole of
diameter 50 mm.
---
SAFETY INFORMATION
---
nDo not use the product if:
- it shows visible damage or malfunctions,
- a cord seems damaged.
nNever disassemble the device yourself.
nUse only in environment < 80% humidity and temperature between
10 and 30°C.
nDo not put any metallic object near the Hubble.
FOR EUROPEAN MARKETS ONLY
nThis appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
nChildren shall not play with the appliance.
nCleaning and user maintenance shall not be made by children without
supervision.
nKeep the appliance and its cord out of the reach of children aged less
than 8 years.
Let’s help to protect the environment!
Your appliance contains many materials that can be reused or recycled. Take it to a collection
point so it can be processed.
Information concerning the CE
The CE marking indicates that the product meets the main requirements of European Directives:
2014/35 / EU (Low Voltage), 2014/30 / EU (Electromagnetic Compatibility).

5/24
MKT/DOC/126/V2
4/24
MKT/DOC/126/V2
SUMMARY
nSafety information 2
nTechnical characteristics 7
nDimensions 8
nContent of Box 9
nFan and capsule holder 11
nIntegration of the Hubble 16
nConnectors 18
nConnecting the Hubble 19
nHow to trigger fragrances 20
nHow to position the fragrance air flow 20
nPlace of the capsule in the support 21
nWarranty 21

7/24
MKT/DOC/126/V2
6/24
MKT/DOC/126/V2
Thank you for purchasing the Hubble fragrance diffuser.
The Hubble is a system allowing you to provide contactless olfactory experiences to
your guests and customers.
Easy to install and to trigger, it offers a totally safe dry fragrance diffusion.
Please read this manual carefully so you can use your diffuser properly and safely.
For any inquiries about this diffuser, please contact us at "[email protected]".
HUBBLE FRAGRANCE DIFFUSER
Dimensions - Height 94 mm
- Width 63 mm
- Depth 32 mm
- Weight 0,253 kg
Power supply EU Plug 100-220V (5V output)
or
3 x LR6 AA Battery (not provided)
Power consumption 0,5 W
Type of diffusion Dry diffusion technology
TECHNICAL CHARACTERISTICS

9/24
MKT/DOC/126/V2
8/24
MKT/DOC/126/V2
2
4
5
6
CONTENT OF BOX
1/ Hubble control unit
2/ Capsule and Fan holder
3/ Fan with fan cable (1 m)
4/ Power supply
110-220V to 5V with EU plug
5/ Battery Holder (3 x AA LR6)
6/ Adhesive velcro band
1
DIMENSIONS (mm)
HUBBLE CONTROL UNIT
CAPSULE FAN
63 90
94
110
27.30 31.80
46.20
14.84
42.97
46
24
3
46
Air flow
20±
32±0.3
40±0.5
4-∅4.3±0.3
0.5
0

11/24
MKT/DOC/126/V2
10/24
MKT/DOC/126/V2
nTo hold the capsule (not provided) and the fan, the support has to be folded this way:
FAN AND CAPSULE HOLDER
Important:
Make sure that the fan air flow is directed toward the Scentys capsule.
The air flow direction is indicated by an arrow on the fan.
Air flow direction

13/24
MKT/DOC/126/V2
12/24
MKT/DOC/126/V2
4
5
1 I 2 I 3 I 4. Wrap the support around the fan.
5. Use double-sided tape to complete this step.
1
2
3

15/24
MKT/DOC/126/V2
14/24
MKT/DOC/126/V2
6 7 9
10 11
9. Fold the four bands.
10 I 11. Insert the last strip band into the opening in order to secure a Scentys capsule.
The support for the fan and capsule is now complete.
6 I 7 I 8. Push all the angles inside the holder to secure the fan position.
8

17/24
MKT/DOC/126/V2
16/24
MKT/DOC/126/V2
Important:
nThe system will need fresh air from outside your POS stand or your furniture.
nThe fragrance flow must not be obstructed.
nMake sure to have access to the capsule and fan holder to allow capsules
replacement.
nOdors and surrounding polluted air must be avoided at all cost.
nPlease read the Guideline before integrating the Hubble: LIB-DOC-20-Vx
General guidelines for installing Scentys capsule-based products.
Contact: [email protected]
nPlace the Hubble control unit under your furniture or POS, as indicated above. Use the
adhesive velcro band provided to fix the Hubble control unit.
Important:
nThe detection area must be as close as possible to the surface of your POS or your
furniture where your Guests will trigger the diffusion.
nAs the hand above the detection area triggers the fragrance diffusion, it is important
to indicate with a mark its precise location.
INTEGRATION OF THE HUBBLE
.'
DETECTION AREA OF THE HUBBLE CONTROL UNIT
Sample
of mark
Detection area
Surface
of the POS or the furniture
Detection area
Hubble control unit

19/24
MKT/DOC/126/V2
18/24
MKT/DOC/126/V2
CONNECTORS
INPUT OUTPUT
+
-
nFix the fan and the capsule inside your furniture or POS. The fan and capsule holder
can be fixed with screws or scotch tap to your support, or by any efficient solution.
nThe fan must be connected to the left connector of the Hubble control unit.
The right connector can be used for output and input commands.
Input: Receives a dry contact to trigger a diffusion.
(example: the diffusion can be triggered with a push button).
Output: Powers 5 VDC when a diffusion is running.
(example: a light signal during the fragrance diffusion).
The Male connector is not provided. Reference: Phoenix Contact 1881341
CONNECTING THE HUBBLE
nThe power plug or the battery holder must be connected to the Hubble.
The Hubble can either be powered by the power plug or battery holder (3 x LR6 AA).
Important:
When you connect the diffuser to the power, it will automatically scan
his new environment for 15 seconds. Meanwhile it will not respond to
any command.

21/24
MKT/DOC/126/V2
20/24
MKT/DOC/126/V2
PLACE OF THE CAPSULE IN THE SUPPORT
A hand will trigger the fragrance diffusion.
nThe hand must be at 5-10 cm range (depending on the thickness of the material).
The fragrance will be diffused for 30 seconds.
HOW TO TRIGGER FRAGRANCES
nMake sure the direction of the fragrance flow is directed toward the nose of the person
who will trigger the fragrance diffusion.
HOW TO POSITION THE FRAGRANCE AIR FLOW
nPlace the fragrance capsule (sold apart from the Hubble diffuser) into the support, as
indicated in the illustration.
.'
10 cm
Note: Even though the diffusion duration is 30 seconds, you may start to get the
smell 2 to 10 seconds after, depending on the layout, the fragrance power
and the surrounding environment.
Scentys warrants the Hubble diffuser starting from the purchase date.
The warranty covers manufacturing defects, not damage resulting from misuse.
If, during the warranty period, this product proves defective with normal use and care,
please contact us at [email protected].
Scentys is liable only for the cost of repairing and/or replacing the unit while under warranty.
WARRANTY
