Krossi
Fixed Height Desk
Installation Guide

Krossi
Fixed Height Desk Installation Guide (SI-P-22)
Page 2
Parts Included
You will need:
Worktop with beam pre-installed
Legs x 2
Phillips Head Screw Driver
(Star Tip)
M4 Screw (for the legs) x 8
M6 Screw (for the beams) x 4
each

Krossi
Fixed Height Desk Installation Guide (SI-P-22)
Page 3
Step 1
Step 2
Place worktop upside down so that you see the
beam.
Note: ensure your worktop is on a clean flat surface.
Remove the 4 x M6 Screws in the beam and set aside.
Note: Leave the screws that fix the worktop to the beam.

Krossi
Fixed Height Desk Installation Guide (SI-P-22)
Page 4
Step 3
Step 4
Remove the screws in the worktop and set
aside separately.
Position leg as per below.

Krossi
Fixed Height Desk Installation Guide (SI-P-22)
Page 5
Step 5
Step 6
Loosely screw in 4 x M4 screws to allow leg
adjustment and hole alignment.
Repeat steps 4 and 5 with other leg

Krossi
Fixed Height Desk Installation Guide (SI-P-22)
Page 6
Step 7
Step 8
Tightly fix the legs to the beam by fastening the
M6 screws into position
Force beam to create alignment of holes
(if required)
Tighten all M4 screws to ensure securely
fastened

Krossi
Fixed Height Desk Installation Guide (SI-P-22)
Page 7
Step 9
Flip the desk over
For further assistance, please contact your
Schiavello representative or head office on
03 9330 8888
